Delock Crimpbox 70 pieces 75 Ohm with BNC, TNC and F
connectors
Description
This high-quality box by Delock contains various highfrequency technology connectors for connecting
components.
BNC connectors
BNC connectors are used especially in radio and video
applications. The bayonet lock holds the connector firmly
in place even under high tensile stress.
TNC connectors
Unlike BNC connectors, TNC connectors are not
connected by a bayonet, but are screwed on by means of a
thread. The application, however, is the same as for BNC
in the radio and video sector.
F connectors
F connectors are mostly commonly found in the satellite
television sector. However, they are also used in the cable
television sector.
Specification
• Content:
10 x BNC plug for RG-59
10 x BNC plug for RG-6
5 x BNC plug for RG-11
5 x BNC jack for RG-59
5 x BNC jack for RG-6
5 x TNC jack for RG-59
10 x TNC plug for RG-59
10 x F plug for RG-59
10 x F plug for RG-6
• Housing material: brass nickel plated
• Impedance: 75 Ohm
• Frequency range: DC - 500 MHz
• Box dimensions (LxWxH): ca. 265 x 180 x 30 mm
Item no. 66811
EAN: 4043619668113
Country of origin: Taiwan, Republic of
China
Package: Box
Powered by TCPDF (www.tcpdf.org)
System requirements
• Coaxial cable suitable for crimping
Package content
• 70 x crimping connector
Images
