Delock Thunderbolt™ 4 Hub 3 Port with additional SuperSpeed
USB 10 Gbps Type-A Port - 8K
Description
This solid Thunderbolt™ 4 hub by Delock with metal
housing can be connected to a computer or laptop via the
Thunderbolt™ interface. It expands the computer by three
Thunderbolt™ 4 ports andone SuperSpeed USB TypeA port.
Thunderbolt™ 4 hub
There are three complete Thunderbolts™ 4 ports ready to
transfer up to 40 Gbps data. In addition, two 4K monitors
or one 8K monitor can be connected, as the Thunderbolt™
port supports DP Alternate Mode. All USB-C™ devices
can also be connected.
Additional USB Type-A port
The USB Type-A port supports data transmission up to10
Gbps. Various USB devices, such as USB memory or
external hard drives, can be connected.
USB Power Delivery and dynamic power distribution
with max. 85 watts
The included power supply supplies the hub, the devices
connected to the hub and the host device with power,
maximum 85 watts. There is a dynamic distribution of
power. This means that the laptop can be charged with a
maximum of 60 watts and then 25 watts are available for
the hub. If the laptop requires less power to charge, there
is correspondingly more power available for the hub, but a
maximum of 54.5 watts. Each of the three downstream
Thunderbolt™ ports offers a maximum power of 15 watts,
while the USB Type-A port offers max. 4.5 watts.
Note
Only one additional external monitor can be connected to MacBook devices with M1
chipset.
Specification
• Connectors:
1 x Thunderbolt™ 4 female >
3 x Thunderbolt™ 4 female
1 x SuperSpeed USB 10 Gbps (USB 3.2 Gen 2) Type-A female
1 x 20 V DC jack
• Data transfer rate up to:
Thunderbolt™ 4 40 Gbps,
Thunderbolt™ 3 40 Gbps,
USB4™ 40 Gbps,
SuperSpeed USB 10 Gbps,
SuperSpeed USB 5 Gbps,
Hi-Speed 480 Mbps,
Full-Speed 12 Mbps,
Low-Speed 1.5 Mbps
• Resolution up to 7680 x 4320 @ 30 Hz
(depending on the system and the connected hardware)
• Power supply: Self-powered
• Electrical power:
Thunderbolt™: max. 15 watt (5 V / 3 A)
USB Type-A: max. 4.5 watt (5 V / 0.9 A)
• Robust metal housing
Item no. 64157
EAN: 4043619641574
Country of origin: China
Package: Retail Box
© 2022 by Delock. All names and symbols mentioned here are property of the respective producer. Printing errors,
changes and errors excepted.
www.delock.de
64157
1 / 3
04.01.2022
Page 2
• Colour: grey
• Plug & Play
• Dimensions (LxWxH): ca. 124 x 74 x 13 mm
Power supply specification
• Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 1.5 A
• Output: 20 V / 5 A
• Ground outside, plus inside
• Dimensions:
inside: ø ca. 2.5 mm
outside: ø ca. 5.5 mm
length: ca. 10 mm
System requirements
• Linux Kernel 5.8 or above
• Mac OS 11.2.3 or above
• Windows 8.1/8.1-64/10/10-64
• PC or laptop with a free Thunderbolt™ 4 port
Package content
• Thunderbolt™ 4 hub
• Thunderbolt™ 4 cable, length ca. 80 cm
• External power supply
• User manual
Images
© 2022 by Delock. All names and symbols mentioned here are property of the respective producer. Printing errors,
changes and errors excepted.
www.delock.de
64157
2 / 3
04.01.2022
Page 3
General
Supported operating system: Linux Kernel 5.8.0 or above
Windows 10 32-bit
Windows 10 64-bit
Windows 8.1 32-bit
Windows 8.1 64-bit
Mac OS 11.2.3 or above
Interface
Connector 1: 4 x Thunderbolt™ 4 female
Connector 2: 1 x SuperSpeed USB 10 Gbps (USB 3.2 Gen 2) Type-A female
connector 3: 1 x DC jack
Technical characteristics
Data transfer rate: 40 Gbps
Maximum screen resolution: 7680 x 4320 @ 30 Hz
Physical characteristics
Housing material: Aluminium
Length: 124 mm
Width: 74 mm
Height: 13 mm
Colour: grey
