Delock USB Type-C™ Adapter to DisplayPort (DP Alt Mode) 4K
60 Hz – compact design
Description
This adapter by Delock is suitable for the connection of
a DisplayPort monitor to a computer with USB-C™
interface and DisplayPort alternate mode support.
Thus, the adapter can be connected to different laptops
like MacBook, Chromebook and similar. In addition, the
adapter can also be operated on a Thunderbolt™ 3
interface.
Small sturdy helper
Due to its small dimensions and its stable metal
housing, this Delock adapter is especially suitable for
travelling. Thanks to its small size, the USB adapter fits in
every trouser pocket or can be packed together with the
laptop or tablet in the bag and used as needed.
Specification
• Connectors:
1 x SuperSpeed USB (USB 3.2 Gen 1) USB Type-C™ male
1 x DisplayPort female
• Chipset: Chrontel CH7213C
• DisplayPort 1.2 specification
• Signal direction: USB Type-C™ input > DisplayPort output
• Resolution up to 3840 x 2160 @ 60 Hz
(depending on the system and the connected hardware)
• Transmission of audio and video signals
• Supports HDR
• Supports HDCP 1.4 and 2.2
• USB bus powered
• Plug & Play
• Dimensions (LxWxH): ca. 41 x 22 x 9 mm
• Colour: grey
Item no. 64120
EAN: 4043619641208
Country of origin: China
Package: • Retail Box
System requirements
• Android 9.0 or above
• Chrome OS 83.0 or above
• Linux Kernel 5.4 or above
• Mac OS 10.15.6 or above
• Windows 8.1/8.1-64/10/10-64
• iPad Pro (3rd Generation) or above
• PC or mobile devices with a free USB Type-C™ or Thunderbolt™ 3 port
Package content
• USB-C™ to DisplayPort adapter
Images
Page 2
General
Function: Plug & Play
HDR / HDR10
Specification: DisplayPort 1.2
Supported operating system: Mac 10.11.4
Windows 10 32-bit
Windows 10 64-bit
Windows 10 Mobile
Windows 7 32-bit
Windows 7 64-bit
Windows 8.1 32-bit
Windows 8.1 64-bit
iPad Pro (2018)
Interface
Output: 1 x DisplayPort 20 pin female
Input: 1 x USB Type-C™ male
Technical characteristics
Chipset: Chrontel CH7213C
Maximum screen resolution: 4096 x 2160 @ 60 Hz
Signal transmission: video
audio
Physical characteristics
Length: 41 mm
Width: 22 mm
Height: 9 mm
Colour: grey
