Delock USB Type-C™ Adapter to HDMI (DP Alt Mode) 4K 60 Hz
+ HDR – compact design
Description
This adapter by Delock is suitable for the connection of a
HDMI monitor to a computer with USB-C™ interface
and DisplayPort alternate mode support. Thus, the
adapter can be connected to different laptops like
MacBook, Chromebook and similar. In addition, the
adapter can also be operated on a Thunderbolt™ 3
interface.
Small sturdy helper
Due to its small dimensions and its stable metal
housing, this Delock adapter is especially suitable for
travelling. Thanks to its small size, the USB adapter fits in
every trouser pocket or can be packed together with the
laptop or tablet in the bag and used as needed.
Specification
• Connectors:
1 x SuperSpeed USB (USB 3.2 Gen 1) USB Type-C™ male
1 x HDMI-A 19 pin female
• Chipset: Realtek RTD2172U
• DisplayPort 1.2 and High Speed HDMI with Ethernet (HEC) specification
• Resolution up to 3840 x 2160 @ 60 Hz (depending on the system and the connected
hardware)
• Transmission of audio and video signals
• Supports HDR
• Supports HDCP 1.4 and 2.2
• USB bus powered
• Plug & Play
• Dimensions (LxWxH): ca. 42 x 22 x 8 mm
• Colour: grey
Item no. 64119
EAN: 4043619641192
Country of origin: China
Package: • Retail Box
System requirements
• Android 9.0 or above
• Chrome OS 83.0 or above
• iPad Pro (3rd Generation) or above
• Linux Kernel 5.4 or above
• Mac OS 10.15.6 or above
• Windows 8.1/8.1-64/10/10-64
• PC or mobile devices with a free USB Type-C™ or Thunderbolt™ 3 port
Package content
• USB-C™ to HDMI adapter
Images
Page 2
General
Function: Plug & Play
Specification: DisplayPort 1.2
High Speed HDMI with Ethernet
HDCP 1.4
HDCP 2.2
Supported operating system: Android 9.0 or above
Chrome OS 83.0 or above
Linux Kernel 5.4 or above
Mac OS 10.15.6 or above
Windows 10 32-bit
Windows 10 64-bit
Windows 8.1 32-bit
Windows 8.1 64-bit
Interface
Output: 1 x HDMI-A female
Input: 1 x USB Type-C™ male
Technical characteristics
Chipset: Realtek RTD2172U
Maximum screen resolution: 4096 x 2160 @ 60 Hz
Signal transmission: video
audio
Voltage: USB bus powered
Physical characteristics
Length: 42 mm
Width: 22 mm
Height: 8 mm
Colour: grey
