Delock USB Type-C™ Adapter to VGA (DP Alt Mode) 1080p –
compact design
Description
This adapter by Delock is suitable for the connection of a
VGA monitor to a computer with USB-C™ interface and
DisplayPort alternate mode support. Thus, the adapter
can be connected to different laptops like MacBook,
Chromebook and similar. In addition, the adapter can also
be operated on a Thunderbolt™ 3 interface.
Small sturdy helper
Due to its small dimensions and its stable metal
housing, this Delock adapter is especially suitable for
travelling. Thanks to its small size, the USB adapter fits in
every trouser pocket or can be packed together with the
laptop or tablet in the bag and used as needed.
Specification
• Connectors:
1 x SuperSpeed USB (USB 3.2 Gen 1) USB Type-C™ male
1 x VGA 15 pin female
• Chipset: Algotek AG9300
• Resolution up to 1920 x 1080 @ 60 Hz (depending on the system and the connected
hardware)
• Transfer of digital video signals
• USB bus powered
• Plug & Play
• Dimensions (LxWxH): ca. 42 x 25 x 12 mm
• Colour: grey
Item no. 64002
EAN: 4043619640027
Country of origin: China
Package: • Retail Box
System requirements
• Android 9.0 or above
• Chrome OS 83.0 or above
• iPad Pro (3rd Generation) or above
• Linux Kernel 5.4 or above
• Mac OS 10.15.6 or above
• Windows 8.1/8.1-64/10/10-64
• PC or mobile devices with a free USB Type-C™ or Thunderbolt™ 3 port
Package content
• USB-C™ to VGA adapter
Images
Page 2
General
Function: Plug & Play
Supported operating system: Android 9.0 or above
Chrome OS 83.0 or above
Linux Kernel 5.4 or above
Mac OS 10.15.6 or above
Windows 10 32-bit
Windows 10 64-bit
Windows 8.1 32-bit
Windows 8.1 64-bit
Interface
Output: 1 x VGA 15 pin female
Input: 1 x USB Type-C™ male
Technical characteristics
Chipset: Algotek AG9300
Maximum screen resolution: 1920 x 1080 @ 60 Hz
Signal transmission: video
Physical characteristics
Length: 42 mm
Width: 25 mm
Height: 12 mm
Colour: grey
