Delock Converter SATA 6 Gb/s > USB 3.0 type B female
Description
This converter by Delock enables you to connect your drive
with SATA interface via the USB interface. The converter is
suitable for all SATA devices, e.g. SSD, HDD, DVD,
CD-ROM.
Specification
• Connector:
1 x SATA 6 Gb/s 22 pin male >
1 x USB 3.0 type B female
1 x SATA 15 pin power connector
• Data transfer rate up to 5 Gb/s
• Pin header for LED
• Supports ATA/ATAPI Packet command set and ATA/ATAPI LBA 48 addressing mode
• Write protect function prevents the writing of data to the SATA drive
• Compatible with OHCI 1.0a specification
• Supports Spread Spectrum
Item No. 62652
EAN
Country of origin
4043619626526
Taiwan, Republic of
China
System requirements
• Drive with SATA 22 pin connector
• One free USB port
Package content
• Converter
Package
• Box
