Delock Adapter mini Displayport 1.2 male with screw > DVI female
4K Active black
Description
This adapter enables you to connect e.g. a DVI monitor
through a free mini Displayport interface. The adapter
supports a resolution up to Ultra HD (4K) and is backward
compatible to Full-HD 1080p. The adapter offers an active
conversion, thus it is also suitable for graphics cards that
are not capable of outputting DP++ signals. The screw of
the mini Displayport connector secures the connection and
prevents accidental unplugging of the cable.
Specification
• Connector:
mini Displayport 20 pin male with screw >
DVI-I (Dual Link) 24+5 female
• Screw type: #4-40, thread type UNC, thread class 3A, American Standard Screw
• Chipset: Parade PS171
• Displayport 1.2 specification
• Cable gauge: 32 AWG
• Cable diameter: ca. 5.5 mm
• Gold-plated connector
• Active converter, for graphics cards with DP and DP++ output
• Supports a resolution up to 4K (4096 x 2160 pixel @ 24 Hz or 3840 x 2160 pixel @ 30
Hz) - depending on the system and the connected hardware
• Supports HDCP 1.3
• Supports Eyefinity
• 1 x ferrite core
• Cable length: ca. 25 cm (incl. connector)
• Colour: black
• OS independent, no driver installation necessary
Item No. 62639
EAN: 4043619626397
Country of origin: China
Package: Poly bag
Powered by TCPDF (www.tcpdf.org)
System requirements
• A free mini Displayport female port
Package content
• Adapter mini Displayport to DVI
Images
© 2016 by Delock. All names and symbols mentioned here are property of the respective producer. Printing errors, changes
and errors excepted.
www.delock.com
62639
1 / 1
09.05.2016
