DeLOCK 47198 User Manual

Delock 3.5″ Mobile Rack for 1 x 2.5″ SATA HDD

Description

This Delock Mobile Rack is designed for external or internal connection of a 2.5″ SATA HDD. Place the HDD directly into the frame and connect it either externally to a free USB port or internally to SATA. The dimension of the frame complies to a standard 3.5″ HDD. Thus you can install the frame into a 3.5″ slot as well as into a 5.25″ mobile rack.

Specification

• 3.5″ HDD dimension

• Connector: inside: 1 x SATA 22 pin male outside: 1 x SATA 22 pin female 1 x Mini USB 2.0 female

• Suitable for 2.5″ SATA HDD / SSD: HDD height 9.5 mm SATA HDD / SSD up to 6 Gb/s support 5 V HDD / SSD

• Data transfer rate up to 6 Gb/s

• Hot Swap

• OS independent, no driver installation necessary

Item No. 47198

EAN

Country of origin

4043619471980

China

System requirements

• For external using:

1. PC with one free USB port

2. PC with one free Power Over eSATA port (optional eSATAp cable item 84397 / 84396 / 84432)

• For internal using:

Package content

• Mobile Rack

• USB 2.0 cable

• User manual

Package

1. PC with a free 3.5″ bay

2. PC with one free SATA port

• Retail Box

3. SATA connecting cable

www.delock.com
