DeLOCK 42514 User Manual

Delock 2.5″ External Enclosure SATA HDD > Multiport USB 3.0 + eSATAp

Description

This aluminium-enclosure by Delock enables you to install a 2.5″ SATA HDD or SSD and provides up to 4 different connecting options due to its special Multiport USB 3.0 + eSATAp interface. The Multiport is a combination of eSATA and USB 3.0 interface, which supports a fast data transfer and a voltage supply of up to 5 V. For extra voltage supply, when connecting via eSATA, you will find an additional power cable included in delivery.

Connecting options:

1. USB 3.0 (Power via USB)

2. USB 2.0 (Power via USB)

3. eSATAp (Power Over eSATA combo-connection eSATA+USB eSATA for data and USB for power)

4. eSATA (eSATA for data and power via included USB power cable)

Specification

• External aluminium-enclosure for 2.5″ SATA 1.5 Gb/s, 3 Gb/s and 6 Gb/s HDD or SSD

• HDD installation height up to 9.5 mm

• Connector external: 1 x Multiport USB 3.0 + eSATAp 1 x DC for power when connecting via eSATA internal: SATA 22 pin (data + power)

• Dimension DC connector: Length of pin: 9.5 mm ø 3.5 / 1.3 mm Polarity: ground outside, plus inside

• Data transfer rate: USB 3.0 up to 5 Gb/s USB 2.0 up to 480 Mb/s eSATA up to 6 Gb/s

• Enclosure with full-PCB

• LED indicator for power and access

• Dimension (LxWxH): 136 mm x 80 mm x 16 mm

• Hot Swap, Plug & Play

Item No. 42514

EAN

Country of origin

4043619425143

Taiwan, Republic of China

www.delock.com

System requirements

Package content

• Windows 2000/Server-2003/XP/Vista/7/7-64/8/8-64, Mac OS 10.8.2

• PC or notebook with

1. a free USB 3.0 port

2. or a free USB 2.0 port

3. or a free eSATAp port

4. or o free eSATA port and a free USB port for power

Images

• 2.5″ external enclosure

• USB 3.0-A/A cable, DC-USB power cable

• eSATAp cable

• Cover, screwdriver, screws

• User manual

Package

• Retail Box

www.delock.com
