Inspiron 5584
Setup and Specifications
Regulatory Model: P85F
Regulatory Type: P85F001
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
Other trademarks may be trademarks of their respective owners.
2019 - 7
Rev. A01
Contents
1 Set up your Inspiron 5584..............................................................................................................4
2 Create a USB recovery drive for Windows...................................................................................... 6
3 Views of Inspiron 5584..................................................................................................................7
Front........................................................................................................................................................................................ 7
Right........................................................................................................................................................................................ 7
Left.......................................................................................................................................................................................... 8
Base.........................................................................................................................................................................................8
Bottom.................................................................................................................................................................................... 9
4 Specifications of Inspiron 5584....................................................................................................10
Dimensions and weight........................................................................................................................................................10
Processors............................................................................................................................................................................ 10
Chipset.................................................................................................................................................................................. 10
Operating system..................................................................................................................................................................11
Memory.................................................................................................................................................................................. 11
Ports and connectors........................................................................................................................................................... 11
Communications...................................................................................................................................................................12
Audio...................................................................................................................................................................................... 13
Storage.................................................................................................................................................................................. 13
Intel Optane memory (optional)......................................................................................................................................... 13
Media-card reader................................................................................................................................................................14
Keyboard............................................................................................................................................................................... 14
Camera.................................................................................................................................................................................. 14
Touchpad.............................................................................................................................................................................. 15
Touchpad gestures........................................................................................................................................................ 15
Power adapter......................................................................................................................................................................15
Battery...................................................................................................................................................................................16
Display....................................................................................................................................................................................16
Fingerprint reader (optional)...............................................................................................................................................17
Video...................................................................................................................................................................................... 17
Computer environment....................................................................................................................................................... 18
5 Keyboard shortcuts.....................................................................................................................19
6 Getting help and contacting Dell.................................................................................................. 21
Contents 3
Set up your Inspiron 5584
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
1. Connect the power adapter and press the power button.
NOTE: To conserve battery power, the battery might enter power saving mode. Connect the power adapter and
press the power button to turn on the computer.
2. Finish operating system setup.
For Ubuntu:
Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, see the
knowledge base articles SLN151664 and SLN151748 at www.dell.com/support.
For Windows:
Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
• Connect to a network for Windows updates.
NOTE:
prompted.
• If connected to the internet, sign-in with or create a Microsoft account. If not connected to the internet, create an offline account.
• On the Support and Protection screen, enter your contact details.
3. Locate and use Dell apps from the Windows Start menu—Recommended
Table 1. Locate Dell apps
If connecting to a secured wireless network, enter the password for the wireless network access when
1
Resources Description
My Dell
Centralized location for key Dell applications, help articles, and other important information about your
computer. It also notifies you about the warranty status, recommended accessories, and software updates
if available.
SupportAssist
Pro-actively checks the health of your computer’s hardware and software. The SupportAssist OS Recovery
tool troubleshoots issues with the operating system. For more information, see the SupportAssist
documentation at
NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty.
4 Set up your Inspiron 5584
www.dell.com/support.
Resources Description
Dell Update
Updates your computer with critical fixes and latest device drivers as they become available. For more
information about using Dell Update, see the knowledge base article SLN305843 at www.dell.com/support.
Dell Digital Delivery
Download software applications, which are purchased but not pre-installed on your computer. For more
information about using Dell Digital Delivery, see the knowledge base article 153764 at www.dell.com/
support.
4. Create recovery drive for Windows.
NOTE: It is recommended to create a recovery drive to troubleshoot and fix problems that may occur with Windows.
For more information, see Create a USB recovery drive for Windows.
Set up your Inspiron 5584 5
Create a USB recovery drive for Windows
Create a recovery drive to troubleshoot and fix problems that may occur with Windows. An empty USB flash drive with a minimum
capacity of 16 GB is required to create the recovery drive.
NOTE: This process may take up to an hour to complete.
NOTE: The following steps may vary depending on the version of Windows installed. Refer to the Microsoft support site
for latest instructions.
1. Connect the USB flash drive to your computer.
2. In Windows search, type Recovery.
3. In the search results, click Create a recovery drive.
The User Account Control window is displayed.
4. Click Yes to continue.
The Recovery Drive window is displayed.
5. Select Back up system files to the recovery drive and click Next.
6. Select the USB flash drive and click Next.
A message appears, indicating that all data in the USB flash drive will be deleted.
7. Click Create.
8. Click Finish.
For more information about reinstalling Windows using the USB recovery drive, see the Troubleshooting section of your product's
Service Manual at www.dell.com/support/manuals.
2
6 Create a USB recovery drive for Windows
Front
3
Views of Inspiron 5584
1. Left microphone
Provides digital sound input for audio recording and voice calls.
2. Camera
Enables you to video chat, capture photos, and record videos.
3. Camera-status light
Turns on when the camera is in use.
4. Right microphone
Provides digital sound input for audio recording and voice calls.
Right
1. SD-card slot
Reads from and writes to the SD card.
2. USB 2.0 port
Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps.
3. Security-cable slot (wedge-shaped)
Connect a security cable to prevent unauthorized movement of your computer.
Views of Inspiron 5584 7
Left
1. Power-adapter port
Connect a power adapter to provide power to your computer.
2. USB 3.1 Gen 1 (Type-C) port (optional)
Connect to external storage devices. Provides data transfer speeds up to 5 Gbps.
NOTE:
NOTE: This port is only present on computers ordered with a discrete graphics configuration.
3. HDMI port
Connect to a TV or another HDMI-in enabled device. Provides video and audio output.
4. Network port
Connect an Ethernet (RJ45) cable from a router or a broadband modem for network or Internet access.
5. USB 3.1 Gen 1 ports (2)
Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps.
6. Headset port
Connect headphones or a headset (headphone and microphone combo).
This port does not support video/audio streaming.
Base
1. Left-click area
Press to left-click.
2. Touchpad
Move your finger on the touchpad to move the mouse pointer. Tap to left-click and two finger tap to right-click.
3. Right-click area
Press to right-click.
4. Power button with optional fingerprint reader
Press to turn on the computer if it is turned off, in sleep state, or in hibernate state.
When the computer is turned on, press the power button to put the computer into sleep state; press and hold the power button for 4
seconds to force shut-down the computer.
Views of Inspiron 5584
8
If the power button has a fingerprint reader, place your finger on the power button to log in.
NOTE: You can customize power-button behavior in Windows. For more information, see
www.dell.com/support/manuals.
Me and My Dell
at
Bottom
1. Left speaker
Provides audio output.
2. Service Tag label
The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your
computer and access warranty information.
3. Right speaker
Provides audio output.
Views of Inspiron 5584
9
Specifications of Inspiron 5584
Dimensions and weight
Table 2. Dimensions and weight
Description Values
Height:
4
Front
Rear
Width
Depth
Weight (maximum)
18 mm (0.71 in.)
22.45 mm (0.88 in.)
365 mm (14.3 in.)
249 mm (9.8 in.)
2.05 kg (4.52 lb)
NOTE: The weight of your computer depends on the configuration
ordered and the manufacturing variability.
Processors
Table 3. Processors
Description Values
Processors
Wattage
Core count
Thread count
8th Generation Intel Core i3 8th Generation Intel Core i5 8th Generation Intel Core i7
15 W 15 W 15 W
2 4 4
4 8 8
Speed
Cache
Integrated graphics
Up to 3.9 GHz Up to 3.9 GHz Up to 4.6 GHz
4 MB 6 MB 8 MB
Intel UHD Graphics 620 Intel UHD Graphics 620 Intel UHD Graphics 620
Chipset
Table 4. Chipset
Description Values
Chipset
Processor
DRAM bus width
10 Specifications of Inspiron 5584
Intel PCH-LP
8th Generation Intel Core i3/i5/i7
64-bit
Description Values
Flash EPROM
PCIe bus
16 MB
Up to Gen3
Operating system
• Windows 10 Home (64-bit)
• Windows 10 Professional (64-bit)
• Ubuntu
Memory
Table 5. Memory specifications
Description Values
Slots
Type
Speed
Maximum memory
Two SODIMM slots
Dual-channel DDR4
Up to 2400 MHz
16 GB
Minimum memory
Memory size per slot
Configurations supported
4 GB
4 GB, 8 GB, 16 GB
• 4 GB DDR4 at 2400 MHz (1 x 4 GB)
• 8 GB DDR4 at 2400 MHz (1 x 8 GB)
• 12 GB DDR4 at 2400 MHz (1 x 8 GB + 1 x 4 GB)
• 16 GB DDR4 at 2400 MHz (2 x 8 GB)
• 16 GB DDR4 at 2400 MHz (1 x 16 GB)
Ports and connectors
Table 6. External ports and connectors
Description Values
External:
Network
USB
One RJ-45 port
• Two USB 3.1 Gen 1 ports
• One USB 2.0 port
• One USB 3.1 Gen 1 (Type-C) port
NOTE: The USB 3.1 Gen 1 (Type-C) port is optional
and will only be present on computers ordered with a
discrete graphics configuration.
Audio
Video
Media card reader
One headset (headphone and microphone combo) port
One HDMI 1.4b port
One SD-card slot
Specifications of Inspiron 5584 11
Description Values
Docking port
Power adapter port
Security
Table 7. Internal ports and connectors
Description Values
Internal:
M.2
Not supported
One 4.5 mm x 2.9 mm DC in
One security-cable slot (wedge-shaped)
• One M.2 2230 slot for Wi-Fi and Bluetooth combo card
• One M.2 slot for 2230/2280 solid-state drive or 2280 Intel
Communications
Ethernet
Table 8. Ethernet specifications
Description Values
Optane
NOTE: To learn more about the features of different
types of M.2 cards, see the knowledge base article
SLN301626.
Model number
Transfer rate
Wireless module
Table 9. Wireless module specifications
Description Values
Model number
Transfer rate
Frequency bands
supported
Wireless standards
Encryption
Qualcomm QCA9565
(DW1707)
Up to 150 Mbps Up to 433 Mbps Up to 867 Mbps Up to 433 Mbps Up to 867 Mbps
Dual band 2.4 GHz Dual band 2.4 GHz/5
WiFi 802.11b/g/n WiFi
• 64-bit/128-bit
WEP
• AES-CCMP
• TKIP
Qualcomm QCA9377
(DW1810)
GHz
802.11a/b/g /n/ac
• 64-bit/128-bit
WEP
• AES-CCMP
• TKIP
Realtek RTL8107E Ethernet controller
10/100 Mbps
Qualcomm
QCA61x4A
(DW1820)
Dual band 2.4 GHz/5
GHz
WiFi
802.11a/b/g /n/ac
• 64-bit/128-bit
WEP
• AES-CCMP
• TKIP
Intel 9462 Intel 9560
Dual band 2.4 GHz/5
GHz
WiFi
802.11a/b/g /n/ac
• 64-bit/128-bit
WEP
• AES-CCMP
• TKIP
Dual band 2.4 GHz/5
GHz
WiFi
802.11a/b/g /n/ac
• 64-bit/128-bit
WEP
• AES-CCMP
• TKIP
Bluetooth
12 Specifications of Inspiron 5584
Bluetooth 4.0 Bluetooth 4.2 Bluetooth 4.2 Bluetooth 4.2 Bluetooth 5.0
Audio
Table 10. Audio specifications
Description Values
Controller
Stereo conversion
Internal interface
External interface
Speakers
Internal speaker amplifier
External volume controls
Speaker output:
Subwoofer output
Microphone
Storage
Average
Peak
Realtek ALC3204-CG
Supported
High-definition audio
Headset combo jack (stereo headphones/microphone-in)
Two
Supported
Keyboard shortcuts
2 W
2.5 W
Not supported
Digital-array microphones in camera assembly
Table 11. Storage specifications
Storage type Interface type Capacity
One 2.5-inch hard drive SATA AHCI, up to 6 Gbps Up to 2 TB
One M.2 2230/2280 solid-state drive PCIe Gen3.0x4 NVMe, up to 32 Gbps Up to 512 GB
Intel Optane memory (optional)
Intel Optane memory functions only as a storage accelerator. It neither replaces nor adds to the memory (RAM) installed on your
computer.
NOTE:
• 7th Generation or higher Intel Core i3/i5/i7 processor
• Windows 10 64-bit version or higher (Anniversary Update)
• Latest version of Intel Rapid Storage Technology driver
Table 12. Intel Optane memory
Description Values
Type
Interface
Intel Optane memory is supported on computers that meet the following requirements:
Storage accelerator
PCIe Gen3.0x2, NVMe
Connector
M.2 2280
Specifications of Inspiron 5584 13
Description Values
Configurations supported
Capacity
16 GB, 32 GB
Up to 32 GB
Media-card reader
Table 13. Media-card reader specifications
Description Values
Type
Cards supported
One SD-card slot
• Secure Digital (SD)
• Secure Digital High Capacity(SDHC)
• Secure Digital Extended Capacity(SDXC)
Keyboard
Table 14. Keyboard specifications
Description Values
Type
Layout
Backlit keyboard
QWERTY
Number of keys
Size
Shortcut keys
• United States and Canada: 101 keys
• United Kingdom: 102 keys
• Japan: 105 keys
X = 18.70 mm key pitch
Y = 18.05 mm key pitch
Some keys on your keyboard have two symbols on them. These
keys can be used to type alternate characters or to perform
secondary functions. To type the alternate character, press Shift
and the desired key. To perform secondary functions, press Fn and
the desired key.
NOTE: You can define the primary behavior of the
function keys (F1–F12) changing Function Key Behavior
in BIOS setup program.
Keyboard shortcuts
Camera
Table 15. Camera specifications
Description Values
Number of cameras
One
Type
Location
Sensor type
14 Specifications of Inspiron 5584
HD RGB camera
Front (above the LCD screen)
CMOS sensor technology
Description Values
Resolution:
Still image
Video
Diagonal viewing angle
Touchpad
Table 16. Touchpad specifications
Description Values
Resolution:
Horizontal
Vertical
Dimensions:
Horizontal
Vertical
3215
2429
105.00 mm (4.13 in.)
80.00 mm (3.15 in.)
0.92 megapixel
1280 x 720 (HD) at 30 fps
78.6 degrees
Touchpad gestures
For more information about touchpad gestures for Windows 10, see the Microsoft knowledge base article 4027871 at
support.microsoft.com.
Power adapter
Table 17. Power adapter specifications
Description Values
Type
Diameter (connector)
Input voltage
Input frequency
Input current (maximum)
Output current (continuous)
Rated output voltage
Temperature range:
E4 45 W E4 65 W
4.5 mm x 2.9 mm 4.5 mm x 2.9 mm
100 VAC–240 VAC 100 VAC–240 VAC
50 Hz–60 Hz 50 Hz–60 Hz
1.30 A 1.6 A/1.70 A
2.31 A 3.34 A
19.50 VDC 19.50 VDC
Operating
Storage
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F)
–40°C to 70°C (–40°F to 158°F) –40°C to 70°C (–40°F to 158°F)
Specifications of Inspiron 5584 15
Battery
Table 18. Battery specifications
Description Values
Type
Voltage
Weight (maximum)
Dimensions:
Height
Width
Depth
Temperature range:
Operating
Storage
Operating time Varies depending on operating conditions and can significantly
Charging time (approximate)
3-cell "smart" lithium-ion (42 WHr)
11.4 VDC
0.20 kg (0.44 lb)
5.90 mm (0.23 in.)
90.73 mm (3.57 in.)
184.15 mm (7.25 in.)
0°C to 35°C (32°F to 95°F)
–40°C to 65°C (–40°F to 149°F)
reduce under certain power-intensive conditions.
4 hours (when the computer is off)
NOTE: Control the charging time, duration, start and end
time, and so on using the Dell Power Manager
application. For more information on the Dell Power
Manager see,
Me and My Dell
on https://www.dell.com/
Life span (approximate) 300 discharge/charge cycles
Coin-cell battery
Operating time Varies depending on operating conditions and can significantly
CR-2032
reduce under certain power-intensive conditions.
Display
Table 19. Display specifications
Description Values
Type
Panel technology
Luminance (typical)
Dimensions (Active area):
Height
Width
Diagonal
High Definition (HD) Full High Definition (FHD)
Twisted Nematic (TN) Twisted Nematic (TN)
220 nits 220 nits
193.6 mm (8.46 in.) 193.6 mm (8.46 in.)
344.2 mm (15.04 in.) 344.2 mm (15.04 in.)
438.38 mm (15.6 in.) 438.16 mm (15.6 in.)
Native resolution
16 Specifications of Inspiron 5584
1366 x 768 1920 x 1080
Description Values
Megapixels
Pixels per inch (PPI)
Contrast ratio (min)
Response time (max)
Refresh rate
Horizontal view angle
Vertical view angle
Pixel pitch
Power consumption (maximum)
Anti-glare vs glossy finish
Touch options
1 2
100 141
500:1 500:1
25 ms 25 ms
60 Hz 60 Hz
• Left: 40 degrees
• Right: 40 degrees
• Left: 10 degrees
• Right: 30 degrees
0.252 mm 0.179 mm
4.0 W 3.7 W
Anti-glare • Touchscreen: TrueLife (Glossy)
Not supported Supported
• Left: 40 degrees
• Right: 40 degrees
• Left: 10 degrees
• Right: 30 degrees
• Non-touchscreen: Anti-glare
Fingerprint reader (optional)
Table 20. Fingerprint reader specifications
Description Values
Sensor technology
Sensor resolution
Sensor area
Sensor pixel size
Capacitive
500 PPI
4.06 mm x 3.25 mm (0.16 in. x 0.13 in.)
64 pixels x 80 pixels
Video
Table 21.
Discrete graphics
Controller External display support Memory size Memory type
NVIDIA GeForce MX130 One HDMI 1.4b port 2 GB/4 GB GDDR5
Table 22. Integrated graphics specifications
Integrated graphics
Controller External display support Memory size Processor
Discrete graphics specifications
Intel UHD Graphics 620 One HDMI 1.4b port Shared system memory 8th Generation Intel
Core i3/i5/i7
Specifications of Inspiron 5584 17
Computer environment
Airborne contaminant level: G1 as defined by ISA-S71.04-1985
Table 23. Computer environment
Description Operating Storage
Temperature range
Relative humidity (maximum)
Vibration (maximum)
Shock (maximum)
Altitude (maximum)
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse when the hard drive is in use.
*
0°C to 35°C (32°F to 95°F) –40°C to 65°C (–40°F to 149°F)
10% to 90% (non-condensing) 0% to 95% (non-condensing)
0.66 GRMS 1.30 GRMS
110 G† 160 G‡
–15.2 m to 3048 m (–50 ft to 10,000 ft) –15.2 m to 10,668 m (–50 ft to 35,000 ft)
18 Specifications of Inspiron 5584
5
Keyboard shortcuts
NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts
remain the same across all language configurations.
Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary
functions. The symbol shown on the lower part of the key refers to the character that is typed out when the key is pressed. If you press
shift and the key, the symbol shown on the upper part of the key is typed out. For example, if you press 2, 2 is typed out; if you press
Shift + 2, @ is typed out.
The keys F1-F12 at the top row of the keyboard are function keys for multi-media control, as indicated by the icon at the bottom of the
key. Press the function key to invoke the task represented by the icon. For example, pressing F1 mutes the audio (refer to the table
below).
However, if the function keys F1-F12 are needed for specific software applications, multi-media functionality can be disabled by pressing
Fn + Esc. Subsequently, multi-media control can be invoked by pressing Fn and the respective function key. For example, mute audio by
pressing Fn + F1.
NOTE: You can also define the primary behavior of the function keys (F1–F12) by changing Function Key Behavior in
BIOS setup program.
Table 24. List of keyboard shortcuts
Function key Redefined key (for multimedia control) Behavior
Mute audio
Decrease volume
Increase volume
Play/Pause
Toggle keyboard backlight
(optional)
NOTE: Non-backlight
keyboards have F5
function key without
the backlight icon and
does not support toggle
keyboard backlight
function.
Decrease brightness
Keyboard shortcuts 19
Function key Redefined key (for multimedia control) Behavior
Increase brightness
Switch to external display
Print screen
Home
End
The Fn key is also used with selected keys on the keyboard to invoke other secondary functions.
Table 25. List of keyboard shortcuts
Function key Behavior
Pause/Break
Toggle scroll lock
System request
Open application menu
Toggle Fn-key lock
20 Keyboard shortcuts
Getting help and contacting Dell
Self-help resources
You can get information and help on Dell products and services using these self-help resources:
Table 26. Self-help resources
Self-help resources Resource location
Information about Dell products and services www.dell.com
My Dell
Tips
Contact Support In Windows search, type Contact Support, and press Enter.
Online help for operating system www.dell.com/support/windows
www.dell.com/support/linux
6
Troubleshooting information, user manuals, setup instructions,
product specifications, technical help blogs, drivers, software
updates, and so on.
Dell knowledge base articles for a variety of computer concerns.
Learn and know the following information about your product:
• Product specifications
• Operating system
• Setting up and using your product
• Data backup
• Troubleshooting and diagnostics
• Factory and system restore
• BIOS information
Contacting Dell
To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell.
NOTE:
NOTE: If you do not have an active internet connection, you can find contact information on your purchase invoice,
packing slip, bill, or Dell product catalog.
Availability varies by country/region and product, and some services may not be available in your country/region.
www.dell.com/support
1. Go to www.dell.com/support.
2. Type the subject or keyword in the Search box.
3. Click Search to retrieve the related articles.
See Me and My Dell at www.dell.com/support/manuals.
To locate the Me and My Dell relevant to your product, identify
your product through one of the following:
• Select Detect Product.
• Locate your product through the drop-down menu under View
Products.
• Enter the Service Tag number or Product ID in the search
bar.
Getting help and contacting Dell 21
Loading...
