Dell PowerConnect 5500
Series
CLI Reference Guide
Regulatory Model: PC5524, PC5524P,
PC5548 and PC5548P
Page 2
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax CLI\files\New
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 – FOR PROOF ONLY
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
COMMENT
Remove paragraph if it does not apply to your publication.
____________________
Information in this publication is subject to change without notice.
© 2011-2012 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, Dell Precision™, OptiPlex™, Latitude™,
PowerEdge™, PowerVault™, PowerConnect™, OpenManage™, EqualLogic™, KACE™,
FlexAddress™ and Vostro™ are trademarks of Dell Inc. Intel
®
, Pentium®, Xeon®, Core™ and
Celeron
®
are registered trademarks of Intel Corporation in the U.S. and other countries. AMD® is a
registered trademark and AMD Opteron™, AMD Phenom™, and AMD Sempron™ are trademarks
of Advanced Micro Devices, Inc. Microsoft
®
, Windows®, Windows Server®, MS-DOS® and
Windows V ista
®
are either trademarks or registered trademarks of Microsoft Corporation in the United
States and/or other countries. Red Hat Enterprise Linux
®
and Enterprise Linux® are registered
trademarks of Red Hat, Inc. in the United States and/or other countries. Novell
®
is a registered
trademark and SUSE ™ is a trademark of Novell Inc. in the United States and other countries. Oracle
®
is a registered trademark of Oracle Corporation and/or its affiliates. Citrix
®
, Xen®, XenServer® and
XenMotion
®
are either registered trademarks or trademarks of Citrix Systems, Inc. in the United States
and/or other countries. VMware
®
, Vir tual SMP®, vMotion®, vCenter®, and vSphere® are registered
trademarks or trademarks of VMWare, Inc. in the United States or other countries.
Other trademarks and trade names may be used in this publication to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Regulatory Models: PC5524, PC5524P, PC5548 and PC5548P
May 2012 Rev. A03
Page 3
3
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
Contents
1 Preface.................................................................... 33
2 User Interface Commands . . . . . . . . . . . . 41
enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
exit (Configuration). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
exit (EXEC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
history size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
terminal history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
terminal history size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
terminal datadump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
debug-mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
show history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
show privilege. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
do . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
banner exec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Page 4
4
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
banner login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
banner motd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
exec-banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
login-banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
motd-banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
show banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
3 Macro Commands . . . . . . . . . . . . . . . . . . 63
macro name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
macro apply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
macro description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
macro global. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
macro global description . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
show parser macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4 System Management Commands . . . . . . 71
ping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
traceroute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
telnet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
resume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
hostname . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
reload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
stack master . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
system light. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
switch renumber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
show switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Page 5
5
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
service cpu-utilization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
show cpu utilization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
clear cpu counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
service cpu-counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
show cpu counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
show users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
show sessions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
show system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
show version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
system resources routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
show system resources routings. . . . . . . . . . . . . . . . . . . . . . 95
show system tcam utilization. . . . . . . . . . . . . . . . . . . . . . . . . 96
show system defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
show tech-support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
system fans always-on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
show system fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
asset-tag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
show system id . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
5 Clock Commands . . . . . . . . . . . . . . . . . . 107
clock set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
clock source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
clock timezone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
clock summer-time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
sntp authentication-key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
sntp authenticate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Page 6
6
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
sntp trusted-key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
sntp client poll timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
sntp broadcast client enable. . . . . . . . . . . . . . . . . . . . . . . . 115
sntp anycast client enable. . . . . . . . . . . . . . . . . . . . . . . . . . 115
sntp client enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
sntp client enable (Interface) . . . . . . . . . . . . . . . . . . . . . . . 117
sntp unicast client enable . . . . . . . . . . . . . . . . . . . . . . . . . . 118
sntp unicast client poll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
sntp server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
sntp port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
show clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
show sntp configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
show sntp status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
6 Configuration/Image File Commands . . 127
copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
write memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
pwd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
dir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
more . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
cd. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
rename . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
boot system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
show running-config. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
show startup-config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Page 7
7
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
show bootvar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
7 Auto-Update and Auto-Configuration . . 143
boot host auto-config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
boot host auto-update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
boot host dhcp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
boot host auto-save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
show boot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
ip dhcp tftp-server ip addr. . . . . . . . . . . . . . . . . . . . . . . . . . . 148
ip dhcp tftp-server file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
show ip dhcp tftp-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
8 Management ACL Commands. . . . . . . . . 151
management access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
permit (Management). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
deny (Management) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
management access-class . . . . . . . . . . . . . . . . . . . . . . . . . . 155
show management access-list . . . . . . . . . . . . . . . . . . . . . . 155
show management access-class . . . . . . . . . . . . . . . . . . . . 156
9 SNMP Commands . . . . . . . . . . . . . . . . . . 159
snmp-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
snmp-server community . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
snmp-server view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
snmp-server group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Page 8
8
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
snmp-server user . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
snmp-server filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
snmp-server host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
snmp-server engineID local. . . . . . . . . . . . . . . . . . . . . . . . . 171
snmp-server engineID remote . . . . . . . . . . . . . . . . . . . . . . 172
snmp-server enable traps. . . . . . . . . . . . . . . . . . . . . . . . . . . 173
snmp-server trap authentication. . . . . . . . . . . . . . . . . . . . . 174
snmp-server contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
snmp-server location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
snmp-server set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
show snmp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
show snmp engineID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
show snmp views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
show snmp groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
show snmp filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
show snmp users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
10 RSA and Certificate Commands . . . . . . 183
crypto key generate dsa . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
crypto key generate rsa . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
show crypto key mypubkey . . . . . . . . . . . . . . . . . . . . . . . . . 184
crypto certificate generate . . . . . . . . . . . . . . . . . . . . . . . . . 185
crypto certificate request. . . . . . . . . . . . . . . . . . . . . . . . . . . 187
crypto certificate import. . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
crypto certificate export pkcs12. . . . . . . . . . . . . . . . . . . . . 190
crypto certificate import pkcs12. . . . . . . . . . . . . . . . . . . . . 191
Page 9
9
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
show crypto certificate mycertificate . . . . . . . . . . . . . . . . 193
11 Web Server Commands . . . . . . . . . . . . . 195
ip http server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
ip http port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
ip http timeout-policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
ip http secure-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
ip http secure-port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
ip https certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
show ip http . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
show ip https . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
12 Telnet, SSH and Slogin Commands . . . . 203
ip telnet server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
ip ssh port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
ip ssh server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
ip ssh pubkey-auth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
crypto key pubkey-chain ssh . . . . . . . . . . . . . . . . . . . . . . . . 206
user-key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
key-string . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
show ip ssh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
show crypto key pubkey-chain ssh. . . . . . . . . . . . . . . . . . . 211
13 Line Commands. . . . . . . . . . . . . . . . . . . . 213
line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Page 10
10
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
autobaud . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
exec-timeout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
show line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
14 AAA Commands. . . . . . . . . . . . . . . . . . . 219
aaa authentication login. . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
aaa authentication enable . . . . . . . . . . . . . . . . . . . . . . . . . . 221
login authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
enable authentication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
ip http authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224
show authentication methods. . . . . . . . . . . . . . . . . . . . . . . 225
password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
service password-recovery. . . . . . . . . . . . . . . . . . . . . . . . . 227
enable password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
username . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
show user accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
aaa accounting login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
aaa accounting dot1x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
show accounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
passwords min-length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
passwords strength-check enable. . . . . . . . . . . . . . . . . . . 236
passwords strength minimum character-classes. . . . . . 237
passwords strength max-limit repeated-characters . . . 238
passwords aging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
passwords history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240
Page 11
11
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
passwords history hold-time . . . . . . . . . . . . . . . . . . . . . . . . 241
passwords lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
aaa login-history file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
set username active . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
set line active . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
set enable-password active . . . . . . . . . . . . . . . . . . . . . . . . . 245
show passwords configuration . . . . . . . . . . . . . . . . . . . . . . 246
show users login-history. . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
15 RADIUS Commands. . . . . . . . . . . . . . . . . 249
radius-server host. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
radius-server key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
radius-server retransmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
radius-server source-ip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
radius-server source-ipv6. . . . . . . . . . . . . . . . . . . . . . . . . . . 254
radius-server timeout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
radius-server deadtime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
show radius-servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
16 TACACS+ Commands . . . . . . . . . . . . . . . 259
tacacs-server host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
tacacs-server key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260
tacacs-server timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
tacacs-server source-ip . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
show tacacs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263
Page 12
12
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
17 Syslog Commands . . . . . . . . . . . . . . . . . 265
logging on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Logging host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
logging console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
logging buffered. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
clear logging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
logging file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
clear logging file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
aaa logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271
file-system logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
management logging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
show logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
show logging file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
show syslog-servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
18 RMON Commands . . . . . . . . . . . . . . . . . 277
show rmon statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
rmon collection stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
show rmon collection stats . . . . . . . . . . . . . . . . . . . . . . . . . 280
show rmon history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
rmon alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
show rmon alarm-table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
show rmon alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
rmon event. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289
show rmon events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
show rmon log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Page 13
13
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
rmon table-size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
19 802.1x Commands . . . . . . . . . . . . . . . . . . 295
aaa authentication dot1x. . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
dot1x system-auth-control . . . . . . . . . . . . . . . . . . . . . . . . . . 296
dot1x port-control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
dot1x re-authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
dot1x timeout reauth-period . . . . . . . . . . . . . . . . . . . . . . . . 298
dot1x re-authenticate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
dot1x timeout quiet-period . . . . . . . . . . . . . . . . . . . . . . . . . . 300
dot1x timeout tx-period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 301
dot1x max-req . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
dot1x timeout supp-timeout . . . . . . . . . . . . . . . . . . . . . . . . . 303
dot1x timeout server-timeout . . . . . . . . . . . . . . . . . . . . . . . . 304
show dot1x. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 305
show dot1x users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308
show dot1x statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310
clear dot1x statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 311
dot1x auth-not-req . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312
dot1x host-mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313
dot1x violation-mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 314
dot1x guest-vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315
dot1x guest-vlan timeout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 316
dot1x guest-vlan enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . 317
dot1x mac-authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . 318
dot1x traps mac-authentication success. . . . . . . . . . . . . . 319
Page 14
14
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
dot1x traps mac-authentication failure. . . . . . . . . . . . . . . 319
dot1x radius-attributes vlan. . . . . . . . . . . . . . . . . . . . . . . . . 320
dot1x radius-attributes filter-id. . . . . . . . . . . . . . . . . . . . . . 321
dot1x radius-attributes errors . . . . . . . . . . . . . . . . . . . . . . . 322
dot1x legacy-supp-mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 322
show dot1x advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
dot1x system-auth-control monitor . . . . . . . . . . . . . . . . . . 324
show dot1x monitoring result . . . . . . . . . . . . . . . . . . . . . . . 325
20 Ethernet Configuration Commands . . . . 329
interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 329
interface range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 329
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330
speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330
duplex. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
negotiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 332
flowcontrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 333
flowcontrol (Global) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 334
show flowcontrol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335
mdix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 336
back-pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 337
port jumbo-frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 337
clear counters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 338
set interface active . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 339
show interfaces configuration . . . . . . . . . . . . . . . . . . . . . . 339
show interfaces status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 340
Page 15
15
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
show interfaces advertise . . . . . . . . . . . . . . . . . . . . . . . . . . 341
show interfaces description. . . . . . . . . . . . . . . . . . . . . . . . . 342
show interfaces counters . . . . . . . . . . . . . . . . . . . . . . . . . . . 343
show port jumbo-frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 346
show errdisable interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . 346
storm-control broadcast enable . . . . . . . . . . . . . . . . . . . . . 347
storm-control broadcast level kbps . . . . . . . . . . . . . . . . . . 348
storm-control include-multicast . . . . . . . . . . . . . . . . . . . . . 349
show storm-control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350
21 PHY Diagnostics Commands. . . . . . . . . . 351
test cable-diagnostics tdr . . . . . . . . . . . . . . . . . . . . . . . . . . . 351
show cable-diagnostics tdr . . . . . . . . . . . . . . . . . . . . . . . . . 352
show cable-diagnostics cable-length . . . . . . . . . . . . . . . . 353
show fiber-ports optical-transceiver . . . . . . . . . . . . . . . . . 353
22 Power over Ethernet (PoE) Commands . 357
power inline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 357
power inline powered-device . . . . . . . . . . . . . . . . . . . . . . . 358
power inline priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
power inline usage-threshold . . . . . . . . . . . . . . . . . . . . . . . 359
power inline traps enable. . . . . . . . . . . . . . . . . . . . . . . . . . . 360
power inline limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 361
show power inline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 361
show power inline consumption . . . . . . . . . . . . . . . . . . . . . 365
show power inline version . . . . . . . . . . . . . . . . . . . . . . . . . . 366
Page 16
16
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
23 EEE Commands . . . . . . . . . . . . . . . . . . . 369
eee enable (global) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 369
eee enable (interface). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 369
eee lldp enable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
show eee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
24 Green Ethernet . . . . . . . . . . . . . . . . . . . 377
show green-ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 377
green-ethernet short-reach (global). . . . . . . . . . . . . . . . . . 379
green-ethernet short-reach (interface) . . . . . . . . . . . . . . . 379
green-ethernet short-reach force. . . . . . . . . . . . . . . . . . . . 380
green-ethernet short-reach threshold . . . . . . . . . . . . . . . . 381
green-ethernet power-meter reset. . . . . . . . . . . . . . . . . . . 382
25 Port Channel Commands. . . . . . . . . . . . 383
port-channel load-balance . . . . . . . . . . . . . . . . . . . . . . . . . 384
show interfaces port-channel. . . . . . . . . . . . . . . . . . . . . . . 385
26 Address Table Commands. . . . . . . . . . . 387
bridge multicast filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . 387
bridge multicast address . . . . . . . . . . . . . . . . . . . . . . . . . . . 388
bridge multicast forbidden address . . . . . . . . . . . . . . . . . . 389
bridge multicast unregistered. . . . . . . . . . . . . . . . . . . . . . . 390
bridge multicast forward-all . . . . . . . . . . . . . . . . . . . . . . . . 391
bridge multicast forbidden forward-all. . . . . . . . . . . . . . . 392
Page 17
17
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
mac address-table static . . . . . . . . . . . . . . . . . . . . . . . . . . . 393
clear mac address-table . . . . . . . . . . . . . . . . . . . . . . . . . . . 394
mac address-table aging-time . . . . . . . . . . . . . . . . . . . . . . 395
port security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 396
port security mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397
port security max . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397
port security routed secure-address. . . . . . . . . . . . . . . . . . 398
show mac address-table . . . . . . . . . . . . . . . . . . . . . . . . . . . 399
show mac address-table count . . . . . . . . . . . . . . . . . . . . . . 401
show bridge multicast address-table. . . . . . . . . . . . . . . . . 401
show bridge multicast address-table static . . . . . . . . . . . 405
show bridge multicast filtering . . . . . . . . . . . . . . . . . . . . . . 408
show bridge multicast unregistered. . . . . . . . . . . . . . . . . . 409
show ports security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 410
show ports security addresses . . . . . . . . . . . . . . . . . . . . . . 411
27 Port Monitor Commands . . . . . . . . . . . . . 413
port monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 413
show ports monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 415
28 sFlow Commands . . . . . . . . . . . . . . . . . . 417
sflow receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 417
sflow flow-sampling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 418
sflow counters-sampling . . . . . . . . . . . . . . . . . . . . . . . . . . . 419
clear sflow statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 419
show sflow configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 420
Page 18
18
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
show sflow statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 421
29 LLDP Commands . . . . . . . . . . . . . . . . . . 423
lldp run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 423
lldp transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 423
lldp receive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 424
lldp timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 425
lldp hold-multiplier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 426
lldp reinit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 427
lldp tx-delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 428
lldp optional-tlv . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 428
lldp management-address . . . . . . . . . . . . . . . . . . . . . . . . . . 429
lldp notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 430
lldp notifications interval. . . . . . . . . . . . . . . . . . . . . . . . . . . 431
lldp optional-tlv 802.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 432
lldp med enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 433
lldp med notifications topology-change . . . . . . . . . . . . . . 434
lldp med fast-start repeat-count . . . . . . . . . . . . . . . . . . . . . 435
lldp med network-policy (global) . . . . . . . . . . . . . . . . . . . . 435
lldp med network-policy (interface) . . . . . . . . . . . . . . . . . 436
clear lldp table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 437
lldp med location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 438
show lldp configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 439
show lldp med configuration. . . . . . . . . . . . . . . . . . . . . . . . 441
show lldp local tlvs-overloading . . . . . . . . . . . . . . . . . . . . 443
show lldp local. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 444
Page 19
19
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
show lldp neighbors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 446
show lldp statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 451
30 Spanning-Tree Commands . . . . . . . . . . . 453
spanning-tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 453
spanning-tree mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 453
spanning-tree forward-time . . . . . . . . . . . . . . . . . . . . . . . . . 454
spanning-tree hello-time. . . . . . . . . . . . . . . . . . . . . . . . . . . . 455
spanning-tree max-age . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 456
spanning-tree priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 457
spanning-tree disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 458
spanning-tree cost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 459
spanning-tree port-priority . . . . . . . . . . . . . . . . . . . . . . . . . . 460
spanning-tree portfast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 460
spanning-tree link-type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 461
spanning-tree pathcost method . . . . . . . . . . . . . . . . . . . . . . 462
spanning-tree bpdu (Global). . . . . . . . . . . . . . . . . . . . . . . . . 463
spanning-tree bpdu (Interface) . . . . . . . . . . . . . . . . . . . . . . 464
spanning-tree guard root. . . . . . . . . . . . . . . . . . . . . . . . . . . . 465
spanning-tree bpduguard . . . . . . . . . . . . . . . . . . . . . . . . . . . 466
clear spanning-tree detected-protocols . . . . . . . . . . . . . . 467
spanning-tree mst priority. . . . . . . . . . . . . . . . . . . . . . . . . . . 467
spanning-tree mst max-hops . . . . . . . . . . . . . . . . . . . . . . . . 468
spanning-tree mst port-priority . . . . . . . . . . . . . . . . . . . . . . 469
spanning-tree mst cost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 470
spanning-tree mst configuration . . . . . . . . . . . . . . . . . . . . . 471
Page 20
20
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
instance (MST) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 472
name (MST) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 473
revision (MST) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 473
show (MST) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 474
exit (MST) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 475
abort (MST) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 476
show spanning-tree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 476
show spanning-tree bpdu. . . . . . . . . . . . . . . . . . . . . . . . . . . 491
31 VLAN Commands . . . . . . . . . . . . . . . . . . 493
vlan database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 493
vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 493
interface vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 494
interface range vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 495
name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 496
switchport protected-port . . . . . . . . . . . . . . . . . . . . . . . . . . 497
switchport community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 498
show interfaces protected-ports . . . . . . . . . . . . . . . . . . . . 498
switchport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 499
switchport mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500
switchport access vlan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 501
switchport access multicast-tv vlan . . . . . . . . . . . . . . . . . 502
switchport trunk allowed vlan . . . . . . . . . . . . . . . . . . . . . . 503
switchport trunk native vlan . . . . . . . . . . . . . . . . . . . . . . . . 504
switchport general allowed vlan . . . . . . . . . . . . . . . . . . . . 505
switchport general pvid . . . . . . . . . . . . . . . . . . . . . . . . . . . . 506
Page 21
21
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
switchport general ingress-filtering disable . . . . . . . . . . 507
switchport general acceptable-frame-type . . . . . . . . . . . 508
switchport customer vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . 509
switchport general forbidden vlan . . . . . . . . . . . . . . . . . . . 509
map protocol protocols-group . . . . . . . . . . . . . . . . . . . . . . . 510
switchport general map protocols-group vlan . . . . . . . . . 511
private-vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 512
private-vlan association . . . . . . . . . . . . . . . . . . . . . . . . . . . . 513
switchport private-vlan mapping . . . . . . . . . . . . . . . . . . . . 514
switchport private-vlan host-association . . . . . . . . . . . . . 515
show vlan private-vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 516
ip internal-usage-vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 516
show vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 518
show vlan multicast-tv . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 519
show vlan protocols-groups. . . . . . . . . . . . . . . . . . . . . . . . . 519
show vlan internal usage . . . . . . . . . . . . . . . . . . . . . . . . . . . 520
show interfaces switchport . . . . . . . . . . . . . . . . . . . . . . . . . 521
32 IGMP Snooping Commands . . . . . . . . . . 523
ip igmp snooping (Global) . . . . . . . . . . . . . . . . . . . . . . . . . . . 523
ip igmp snooping vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 523
ip igmp snooping mrouter . . . . . . . . . . . . . . . . . . . . . . . . . . 524
ip igmp snooping mrouter interface . . . . . . . . . . . . . . . . . . 525
ip igmp snooping forbidden mrouter interface . . . . . . . . 526
ip igmp snooping static . . . . . . . . . . . . . . . . . . . . . . . . . . . . 527
ip igmp snooping multicast-tv . . . . . . . . . . . . . . . . . . . . . . . 528
Page 22
22
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
ip igmp snooping querier . . . . . . . . . . . . . . . . . . . . . . . . . . . 529
ip igmp snooping querier address . . . . . . . . . . . . . . . . . . . 530
ip igmp robustness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 531
ip igmp query-interval. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 531
ip igmp query-max-response-time . . . . . . . . . . . . . . . . . . . 532
ip igmp last-member-query-count . . . . . . . . . . . . . . . . . . . 533
ip igmp last-member-query-interval . . . . . . . . . . . . . . . . . 534
ip igmp snooping vlan immediate-leave . . . . . . . . . . . . . . 534
show ip igmp snooping mrouter . . . . . . . . . . . . . . . . . . . . . 535
show ip igmp snooping interface . . . . . . . . . . . . . . . . . . . . 536
show ip igmp snooping groups . . . . . . . . . . . . . . . . . . . . . . 537
show ip igmp snooping multicast-tv . . . . . . . . . . . . . . . . . 538
33 LACP Commands . . . . . . . . . . . . . . . . . . 541
lacp system-priority. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 541
lacp port-priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 542
lacp timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 542
show lacp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 543
show lacp port-channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 546
34 GVRP Commands . . . . . . . . . . . . . . . . . . 547
gvrp enable (Global) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 547
gvrp enable (Interface) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 547
garp timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 548
gvrp vlan-creation-forbid . . . . . . . . . . . . . . . . . . . . . . . . . . . 550
gvrp registration-forbid. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 550
Page 23
23
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
clear gvrp statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 551
show gvrp configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 552
show gvrp statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 553
show gvrp error-statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . 554
35 Voice VLAN Commands . . . . . . . . . . . . . 557
voice vlan oui-table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 558
voice vlan cos mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 559
voice vlan cos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 560
voice vlan aging-timeout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 560
voice vlan enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 561
voice vlan secure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 562
show voice vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 563
36 DHCP Snooping and ARP Inspection Commands
567
ip dhcp snooping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 567
ip dhcp snooping vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 568
ip dhcp snooping trust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 568
ip dhcp snooping information option allowed-untrusted 569
ip dhcp snooping verify . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 570
ip dhcp snooping database. . . . . . . . . . . . . . . . . . . . . . . . . . 571
ip dhcp snooping database update-freq. . . . . . . . . . . . . . . 572
ip dhcp snooping binding . . . . . . . . . . . . . . . . . . . . . . . . . . . 572
clear ip dhcp snooping database . . . . . . . . . . . . . . . . . . . . 574
show ip dhcp snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 574
Page 24
24
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
show ip dhcp snooping binding . . . . . . . . . . . . . . . . . . . . . 575
ip arp inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 576
ip arp inspection vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 577
ip arp inspection trust. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 578
ip arp inspection validate. . . . . . . . . . . . . . . . . . . . . . . . . . . 579
ip arp inspection list create. . . . . . . . . . . . . . . . . . . . . . . . . 580
ip mac. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 580
ip arp inspection list assign. . . . . . . . . . . . . . . . . . . . . . . . . 581
ip arp inspection logging interval. . . . . . . . . . . . . . . . . . . . 582
show ip arp inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 583
show ip arp inspection list. . . . . . . . . . . . . . . . . . . . . . . . . . 584
show ip arp inspection statistics . . . . . . . . . . . . . . . . . . . . 584
clear ip arp inspection statistics . . . . . . . . . . . . . . . . . . . . 585
ip dhcp information option. . . . . . . . . . . . . . . . . . . . . . . . . . 586
show ip dhcp information option . . . . . . . . . . . . . . . . . . . . 586
37 iSCSI Commands . . . . . . . . . . . . . . . . . . 589
iscsi enable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 589
iscsi target port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 590
iscsi cos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 591
iscsi aging-time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 593
iscsi max-tcp-connections . . . . . . . . . . . . . . . . . . . . . . . . . 594
show iscsi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 595
show iscsi sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 596
Page 25
25
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
38 IP Addressing Commands. . . . . . . . . . . . 599
address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 599
ip address dhcp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 601
renew dhcp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 602
ip default-gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 603
show ip interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 603
arp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 604
arp timeout (Global) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 605
arp timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 606
ip arp proxy disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 607
ip proxy-arp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 607
clear arp-cache. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 608
show arp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 608
show arp configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 609
interface ip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 610
directed-broadcast. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 611
broadcast-address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 612
ip helper-address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 612
show ip helper-address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 614
source-precedence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 615
ip domain lookup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 616
ip domain name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 616
ip name-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 617
ip host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 619
clear host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 620
clear host dhcp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 620
Page 26
26
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
show hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 621
39 IPv6 Addressing Commands . . . . . . . . . 623
ipv6 enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 623
ipv6 address autoconfig . . . . . . . . . . . . . . . . . . . . . . . . . . . . 624
ipv6 icmp error-interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . 625
show ipv6 icmp error-interval . . . . . . . . . . . . . . . . . . . . . . . 626
ipv6 address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 627
ipv6 address link-local . . . . . . . . . . . . . . . . . . . . . . . . . . . . 628
ipv6 unreachables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 629
ipv6 default-gateway. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 630
show ipv6 interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 631
show IPv6 route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 633
ipv6 nd dad attempts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 634
ipv6 host. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 635
ipv6 neighbor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 636
ipv6 set mtu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 637
ipv6 mld version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 638
ipv6 mld join-group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 639
show ipv6 neighbors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 640
clear ipv6 neighbors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 641
40 Tunnel Commands . . . . . . . . . . . . . . . . . 643
interface tunnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 643
tunnel mode ipv6ip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 643
tunnel isatap router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 644
Page 27
27
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
tunnel source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 645
tunnel isatap query-interval . . . . . . . . . . . . . . . . . . . . . . . . . 646
tunnel isatap solicitation-interval. . . . . . . . . . . . . . . . . . . . 647
tunnel isatap robustness . . . . . . . . . . . . . . . . . . . . . . . . . . . . 648
show ipv6 tunnel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 649
41 DHCP Relay Commands . . . . . . . . . . . . . 651
ip dhcp relay enable (Global) . . . . . . . . . . . . . . . . . . . . . . . . 651
ip dhcp relay enable (Interface). . . . . . . . . . . . . . . . . . . . . . 651
ip dhcp relay address (Global) . . . . . . . . . . . . . . . . . . . . . . . 652
ip dhcp relay address (Interface). . . . . . . . . . . . . . . . . . . . . 653
show ip dhcp relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 654
ip dhcp information option . . . . . . . . . . . . . . . . . . . . . . . . . . 655
show ip dhcp information option. . . . . . . . . . . . . . . . . . . . . 656
42 DHCP Server Commands . . . . . . . . . . . . 657
ip dhcp server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 657
ip dhcp pool host. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 657
ip dhcp pool network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 658
address (DHCP Host) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 659
address (DHCP Network) . . . . . . . . . . . . . . . . . . . . . . . . . . . 660
lease . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 661
client-name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 663
default-router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 663
dns-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 664
domain-name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 665
Page 28
28
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
netbios-name-server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 666
netbios-node-type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 667
next-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 667
next-server-name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 668
bootfile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 669
time-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 670
option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 671
ip dhcp excluded-address . . . . . . . . . . . . . . . . . . . . . . . . . . 672
ip dhcp ping enable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 673
ping enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 674
ip dhcp ping count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 675
ip dhcp ping timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 676
clear ip dhcp binding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 677
show ip dhcp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 677
show ip dhcp excluded-addresses . . . . . . . . . . . . . . . . . . 678
show ip dhcp pool host. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 678
show ip dhcp pool network . . . . . . . . . . . . . . . . . . . . . . . . . 680
show ip dhcp binding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 681
show ip dhcp server statistics . . . . . . . . . . . . . . . . . . . . . . 683
show ip dhcp allocated . . . . . . . . . . . . . . . . . . . . . . . . . . . . 684
show ip dhcp declined . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 686
show ip dhcp expired . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 687
show ip dhcp pre-allocated. . . . . . . . . . . . . . . . . . . . . . . . . 688
43 IP Routing Protocol-Independent Commands 691
ip route. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 691
Page 29
29
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
ip routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 692
show ip route. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 692
44 ACL Commands . . . . . . . . . . . . . . . . . . . . 695
permit ( IP ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 696
deny ( IP ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 698
ipv6 access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 702
permit ( IPv6 ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 703
deny ( IPv6 ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 705
mac access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 708
permit ( MAC ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 708
service-acl input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 710
service-acl output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 711
service-acl input block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 712
time-range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 713
absolute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 714
periodic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 715
show time-range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 716
show access-lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 717
show interfaces access-lists . . . . . . . . . . . . . . . . . . . . . . . . 719
clear access-lists counters . . . . . . . . . . . . . . . . . . . . . . . . . 719
show interfaces access-lists counters . . . . . . . . . . . . . . . 720
45 Quality of Service (QoS) Commands . . . 723
qos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 723
show qos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 724
Page 30
30
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
class-map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 725
show class-map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 726
match . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 727
policy-map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 727
class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 729
show policy-map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 730
trust. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 731
set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 732
police . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 733
service-policy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 735
qos aggregate-policer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 735
show qos aggregate-policer . . . . . . . . . . . . . . . . . . . . . . . . 737
police aggregate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 737
wrr-queue cos-map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 738
wrr-queue bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 740
priority-queue out num-of-queues . . . . . . . . . . . . . . . . . . . 741
traffic-shape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 742
traffic-shape queue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 743
rate-limit (Ethernet) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 744
qos wrr-queue wrtd. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 744
show qos interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 745
qos wrr-queue threshold . . . . . . . . . . . . . . . . . . . . . . . . . . . 748
qos map policed-dscp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 749
qos map dscp-queue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 750
qos map dscp-dp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 751
qos trust (Global) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 752
Page 31
31
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
qos trust (Interface) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 753
qos cos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 754
qos dscp-mutation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 755
qos map dscp-mutation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 755
show qos map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 756
clear qos statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 758
qos statistics policer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 759
qos statistics aggregate-policer . . . . . . . . . . . . . . . . . . . . . 760
qos statistics queues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 760
show qos statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 761
Page 32
32
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Dell_ContaxTOC.fm
DELL CONFIDENTIAL – PRELIMINARY 2012 - FOR PROOF ONLY
Page 33
33
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Preface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
1
Preface
About this Document
This CLI Reference Guide describes how to use the CLI and a list of the CLI
commands and their arguments.
The CLI commands described in this document are organized according to
feature groups in separate sections.
This section describes how to use the CLI. It contains the following topics:
• CLI Command Modes
• Starting the CLI
• CLI Command Conventions
• Entering Commands
CLI Command Modes
To configure devices, the CLI is divided into various command modes. Each
command mode has its own set of specific commands. Entering a question
mark "?" at the console prompt displays a list of commands available for that
particular command mode.
A specific command, which varies from mode to mode, is used to navigate
from one mode to another. The standard order to access the modes is as
follows:
User EXEC
mode,
Privileged EXEC
mode,
Global Configuration
mode, and
Interface Configuration
modes.
When starting a session, the initial mode for non-privileged users is the User
EXEC mode. Only a limited subset of commands is available in the User
EXEC mode. This level is reserved for tasks that do not change the
configuration.
Page 34
34
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Preface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Privileged users enter the Privileged EXEC mode directly using a password.
This mode provides access to the device Configuration modes.
The modes are described below.
User EXEC Mode
After logging into the device, the user is automatically in
User EXEC
command mode unless the user is defined as a privileged user. In general, the
User EXEC
commands enable the user to perform basic tests, and display
system information.
The user-level prompt consists of the device "host name" followed by the
angle bracket (>).
console>
The default host name is "console" unless it has been changed using the
hostname command in the
Global Configuration
mode.
Privileged EXEC Mode
Privileged access is password-protected to prevent unauthorized use, because
many of the privileged commands set operating system parameters: The
password is not displayed on the screen and is case sensitive.
Privileged users enter directly into the
Privileged EXEC
mode.
Use disable to return to the
User EXEC
mode.
Global Configuration Mode
Global Configuration
mode commands apply to features that affect the
system as a whole, rather than just a specific interface.
To enter the
Global Configuration
mode, enter configure in the Privileged
EXEC mode, and press <Enter>.
The
Global Configuration
mode prompt is displayed.
console(config)#
Use exit, end or ctrl/z to return to the Privileged EXEC mode.
Interface Configuration Modes
Commands in the following modes perform specific interface operations:
Page 35
35
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Preface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
•
Line Interface
— Contains commands to configure the management
connections. These include commands such as line speed, timeout
settings, etc. The
Global Configuration
mode command
line
is used to
enter the
Line Configuration command
mode.
•
VLAN Database
— Contains commands to create a VLAN as a whole.
The Global Configuration mode command
vlan database
is used to enter
the
VLAN Database Interface Configuration
mode.
•
Management Access List
— Contains commands to define management
access-lists. The
Global Configuration
mode command management
access-list is used to enter the
Management Access List Configuration
mode.
•
Port Channel
— Contains commands to configure port-channels, for
example, assigning ports to a VLAN or port-channel. The
Global
Configuration
mode command interface
port-channel
is used to enter the
Port Channel Interface Configuration
mode.
•
SSH Public Key-Chain
— Contains commands to manually specify other
device SSH public keys. The
Global Configuration
mode command crypto
key pubkey-chain
ssh
is used to enter the
SSH Public Key-chain
Configuration
mode.
•
Interface
— Contains commands that configure the interface. The
Global
Configuration
mode command
interface
is used to enter the
Interface
Configuration
mode.
Starting the CLI
The switch can be managed over a direct connection to the switch console
port, or via a Telnet connection. The switch is managed by entering
command keywords and parameters at the prompt. Using the switch CLI
commands is similar to entering commands on a UNIX system.
If access is via a Telnet connection, ensure the device has an IP address
defined, corresponding management access is granted, and the workstation
used to access the device is connected to the device prior to using CLI
commands.
Accessing the CLI from the Console Line
1. Start the device and wait until the startup procedure is complete. The User
Exec mode is entered, and the prompt "console>" is displayed.
Page 36
36
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Preface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
2. Configure the device an d enter the necessary commands to complete the
required tasks.
3. When finished, exit the session with the quit or exit comma nd.
Accessing the CLI from Telnet
1. Enter telnet and the IP address of the device. A User Name prompt is
displayed.
2. Enter the User Name and Password. You are in the Privileged Exec mode.
3. Configure the device an d enter the necessary commands to complete the
required tasks.
4. When finished, exit the session with the quit or exit command.
When another user is required to log onto the system, the login command is
entered in the Privileged EXEC command mode,. This effectively logs off the
current user and logs on the new user.
CLI Command Conventions
The following table describes the command syntax conventions.
Conventions Description
[ ] In a command line, square brackets indicates
an optional entry.
{ } In a command line, curly brackets indicate a
selection of compulsory parameters separated
by the | character. One option must be
selected. For example: flowcontrol
{auto|on|off} means that for the flowcontrol
command either auto, on or off must be
selected.
Italic font Indicates a parameter.
<Enter> Any individual key on the keyboard. For
example click <Enter>.
Ctrl+F4 Any combination keys pressed simultan eously
on the keyboard.
Page 37
37
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Preface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Entering Commands
A CLI command is a series of keywords and arguments. Keywords identify a
command, and arguments specify configuration parameters. For example, in
the command "show interfaces status gi1/0/5" show, interfaces and status are
keywords, gi is an argument that specifies the interface type, and 1/0/5 is an
argument that specifies the port.
To enter commands that require parameters, enter the required parameters
after the command keyword. For example, to set a password for the
administrator, enter:
console(config)# username admin password smith
Help information can be displayed in the following ways:
•
Keyword Lookup
— The character ? is entered in place of a command. A
list of all valid commands and corresponding help messages are displayed.
•
Partial Keyword Lookup
— A command is incomplete and the character ?
is entered in place of a parameter. The matched parameters for this
command are displayed.
The following describes features that assist in using the CLI:
Terminal Command Buffer
Every time a command is entered in the CLI, it is recorded on an internally
managed Command History buffer. Commands stored in the buffer are
maintained on a First In First Out (FIFO) basis.These commands can be
Screen Display Indicates system messages and prompts
appearing on the console.
all When a parameter is requi red to defin e a range
of ports or paramete rs and all is an option, the
default for the command is all when no
parameters are defined. For example, the
command interface range port-channel has
the option of either entering a range of
channels, or selecting all. When the command
is entered without a parameter, it automatically
defaults to all.
Conventions Description
Page 38
38
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Preface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
recalled, reviewed, modified, and reissued. This buffer is not preserved across
device resets. The keys that can be used to access the history buffer are
described in Tab l e 1 .
By default, the history buffer system is enabled, but it can be disabled at any
time. For information about the command syntax to enable or disable the
history buffer, see the history command.
There is a standard default number of commands that are stored in the buffer.
The standard number of 10 commands can be increased to 256. By
configuring 0, the effect is the same as disabling the history buffer system. For
information about the command syntax for configuring the command history
buffer, see the history size command.
To display the history buffer, see show history command.
Negating the Effect of Commands
For many configuration commands, the prefix keyword "no" can be entered to
cancel the effect of a command or reset the configuration to the default
value. This guide describes the negation effect for all applicable commands.
Command Completion
If the command entered is incomplete, invalid, or has missing or invalid
parameters, an appropriate error message is displayed.
To complete an incomplete command, press the <Tab> button. If the
characters already entered are not enough for the system to identify a single
matching command, press "?" to display the available commands matching
the characters already entered.
Incorrect or incomplete commands are automatically re-entered next to the
cursor. If a parameter must be added, the parameter can be added to the basic
command already displayed next to the cursor. The following example
indicates that the command interface requires a missing parameter.
(config)#interface
%missing mandatory parameter
(config)#interface
Page 39
39
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Preface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Keyboard Shortcuts
The CLI has a range of keyboard shortcuts to assist in entering the CLI
commands.
The following table describes these shortcuts:
Table 1: Keyboard Keys
Keyboard Key Description
Up-arrow key Recalls commands from the history buffer,
beginning with the most recent command.
Repeat the key sequence to recall successively
older commands.
Down-arrow key Returns the most recent commands from the
history buffer after recalli ng commands with the
up arrow key. Repeating the key sequence will
recall successively more recent commands.
Ctrl+A Moves the cursor to the beginning of the
command line.
Ctrl+E Moves the cursor to the end of the command
line.
Ctrl+Z / End Returns back to the Privileged EXEC mode
from any mode.
Backspace key Moves the cursor back one space.
Up-arrow key Recalls commands from the history buffer,
beginning with the most recent command.
Repeat the key sequence to recall successively
older commands.
Page 40
40
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\CLI_Preface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Page 41
User Interface Commands 41
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
2
User Interface Commands
enable
The enable EXEC mode command enters the Privileged EXEC mode.
Syntax
enable [
privilege-level
]
Parameters
privilege-level—Specifies the privilege level at which to enter the system.
(Range: 1–
15)
Default Configuration
The default privilege level is 15.
Command Mode
EXEC mode
Example
The following example enters the Privileged EXEC mode.
Console>
enable
enter password:
Console#
Page 42
42 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
disable
The disable Privileged EXEC mode command leaves the Privileged EXEC
mode and returns to the User EXEC mode.
Syntax
disable [
privilege-level
]
Parameters
privilege-level—Specifies the privilege level at which to enter the system.
(Range: 1–
15)
Default Configuration
The default privilege level is 1.
Command Mode
Privileged EXEC mode
Example
The following example returns to the User EXEC mode.
Console#
disable
Console>
login
The login EXEC mode command changes a user’s login.
Syntax
login
Command Mode
EXEC mode
Page 43
User Interface Commands 43
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example enters Privileged EXEC mode and logs in with
username ‘admin’.
Console>
login
User Name:admin
Password:*****
Console#
configure
The configure Privileged EXEC mode command enters the Global
Configuration mode.
Syntax
configure [
terminal
]
Parameters
terminal—Enter the Global Configuration mode with or without the
keyword terminal.
Command Mode
Privileged EXEC mode
Example
The following example enters Global Configuration mode.
Console#
configure
Console(config)#
exit (Configuration)
The exit command exits any configuration mode to the next highest mode in
the CLI mode hierarchy.
Page 44
44 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Syntax
exit
Command Mode
All commands in configuration modes.
Examples
The following examples change the configuration mode from Interface
Configuration mode to Privileged EXEC mode.
Console(config-if)#
exit
Console(config)#
exit
Console#
Router(config-if)#
exit
Router(config)#
exit
Router#
exit (EXEC)
The exit EXEC mode command closes an active terminal session by logging
off the device.
Syntax
exit
Command Mode
EXEC mode
Example
The following examples close an active terminal session.
Console>
exit
Router>
exit
Page 45
User Interface Commands 45
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
end
The end command ends the current configuration session and returns to the
Privileged EXEC mode.
Syntax
end
Command Mode
All configuration modes
Example
The following examples end the Global Configuration mode session and
return to the Privileged EXEC mode.
Console(config)#
end
Console#
Router(config-if)#
end
Router#
help
The help command displays a brief description of the Help system.
Syntax
help
Command Mode
All command modes
Example
The following example describes the Help system.
Console#
help
Page 46
46 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Help may be requested at any point in a command by entering
a question mark '
?
'. If nothing matches the currently
entered incomplete command, the help list is empty. This
indicates that there is no command matching the input as it
currently appears. If the request is within a command, press
the Backspace key and erase the entered characters to a
point where the request results in a match.
Help is provided when:
1. There is a valid command and a help request is made for
entering a parameter or argument (e.g. 'show ?'). All
possible parameters or arguments for the entered command are
then displayed.
2. An abbreviated argument is entered and a help request is
made for arguments matching the input (e.g. 'show pr?').
history
The history Line Configuration mode command enables the command
history function. Use the no form of this command to disable the command
history function.
Syntax
history
no history
Default Configuration
The history command is enabled.
Command Mode
Line Configuration mode
User Guidelines
This command enables the command history function for a specified line.
Use the terminal history EXEC mode command to enable or disable the
command history function for the current terminal session.
Page 47
User Interface Commands 47
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example enables the command history function for Telnet.
Console(config)#
line telnet
Console(config-line)#
history
history size
The history size Line Configuration mode command changes the command
history buffer size for a particular line. Use the no form of this command to
reset the command history buffer size to the default value.
Syntax
history size
number-of-commands
no history size
Parameters
number-of-commands—Specifies the number of commands the system
records in its history buffer. (Range: 0–
256)
Default Configuration
The default command history buffer size is 10 commands.
Command Mode
Line Configuration mode
User Guidelines
This command configures the command history buffer size for a particular
line. Use the terminal history size EXEC mode command to configure the
command history buffer size for the current terminal session.
The allocated command history buffer is per terminal user, and is taken from
a shared buffer. If there is not enough space available in the shared buffer, the
command history buffer size () cannot be increased above the default size.
Page 48
48 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example changes the command history buffer size to 100
entries for a particular line
Console(config)#
line telnet
Console(config-line)#
history size
100
terminal history
The terminal history EXEC mode command enables the command history
function for the current terminal session. Use the no form of this command
to disable the command history function.
Syntax
terminal history
terminal no history
Default Configuration
The default configuration for all terminal sessions is defined by the history
Line Configuration mode command.
Command Mode
EXEC mode
User Guidelines
The command enables the command history for the current session. The
default is determined by the history Line Configuration mode command.
Example
The following example disables the command history function for the current
terminal session.
Console>
terminal no history
Page 49
User Interface Commands 49
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
terminal history size
The terminal history size EXEC mode command changes the command
history buffer size for the current terminal session. Use the no form of this
command to reset the command history buffer size to the default value.
Syntax
terminal history size
number-of-commands
terminal no history size
Parameters
number-of-commands—Specifies the number of commands the system
maintains in its history buffer. (Range: 10–
256)
Default Configuration
The default configuration for all terminal sessions is defined by the history
size Line Configuration mode command.
Command Mode
EXEC mode
User Guidelines
The terminal history size EXEC command changes the command history
buffer size for the current terminal session. Use the history Line
Configuration mode command to change the default command history
buffer size.
The maximum number of commands in all buffers is 256.
Example
The following example sets the command history buffer size to 20 commands
for the current terminal session.
Console>
terminal history size
20
Page 50
50 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
terminal datadump
The terminal datadump EXEC mode command enables dumping all the
output of a show command without prompting. Use the no form of this
command to disable dumping.
Syntax
terminal datadump
terminal no datadump
Default Configuration
Dumping is disabled.
Command Mode
EXEC mode
User Guidelines
By default, a More prompt is displayed when the output contains more lines
than can be displayed on the screen. Pressing the Enter key displays the next
line; pressing the Spacebar displays the next screen of output. The terminal
datadump command enables dumping all output immediately after entering
the show command.
This command is relevant only for the current session.
Example
The following example dumps all output immediately after entering a show
command.
Console>
terminal datadump
debug-mode
The debug-mode Privileged EXEC mode command mode switches to debug
mode.
Page 51
User Interface Commands 51
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Syntax
debug-mode
Command Mode
Privileged EXEC mode
Example
The following example enters Debug mode.
Console#
debug-mode
show history
The show history EXEC mode command lists commands entered in the
current session.
Syntax
show history
Command Mode
EXEC mode
User Guidelines
The buffer includes executed and unexecuted commands.
Commands are listed from the first to the most recent command.
The buffer remains unchanged when entering into and returning from
configuration modes.
Example
The following example displays all the commands entered while in the
current Privileged EXEC mode.
Console#
show version
SW version 3.131 (date 23-Jul-2005 time 17:34:19)
HW version 1.0.0
Console#
show clock
Page 52
52 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
15:29:03 Jun 17 2005
Console#
show history
show version
show clock
show history
3 commands were logged (buffer size is 10)
show privilege
The show privilege EXEC mode command displays the current privilege
level.
Syntax
show privilege
Command Mode
EXEC mode
Example
The following example displays the current privilege level for the Privileged
EXEC mode.
Console#
show privilege
Current privilege level is 15
do
The do command executes an EXEC-level command from Global
Configuration mode or any configuration submode.
Syntax
do
command
Parameters
command—Specifies the EXEC-level command to execute.
Page 53
User Interface Commands 53
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Command Mode
All configuration modes
Example
The following example executes the show vlan Privileged EXEC mode
command from Global Configuration mode.
Example
Console (Config)#
do show vlan
Vlan Name Ports Type Authorization
---- ---- --------------------------- -------- ------------ 1 1 gi1/0/1-39,Po1,Po2, other Required
Po3,Po4,Po5,Po6,Po7,Po8
2 2 gi1/0/1 dynamicGvrp Required
10 v0010 gi1/0/1 permanent Not Required
11 V0011 gi1/0/1,gi1/0/13 permanent Required
20 20 gi1/0/1 permanent Required
30 30 gi1/0/1,gi1/0/13 permanent Required
31 31 gi1/0/1 permanent Required
91 91 gi1/0/1,gi1/0/40 permanent Required
4093 guest-vlan gi1/0/1,gi1/0/13 permanent Guest
console(config)#s
banner exec
Use the banner exec command to specify and enable a message to be
displayed when an EXEC process is created (The user has successfully logged
in), use the banner exec command in Global Configuration mode. Use the no
form of this command to delete the existing EXEC banner.
Syntax
banner exec
d message-text d
no banner exec
Page 54
54 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Parameters
•
d
—Delimiting character of your choice—a pound sign (#), for example.
You cannot use the delimiting character in the banner message.
•
message-text
—The message must start in a new line. You can enter multi-
line messages. You can include tokens in the form of
$(token)
in the
message text. Tokens are replaced with the corresponding configuration
variable. Tokens are described in the User Guidelines. The message can
contain up to 2000 characters (after every 510 characters, you must press
<Enter> to continue).
Default Configuration
Disabled (no EXEC banner is displayed).
Command Mode
Global Configuration mode
User Guidelines
Follow this command with one or more blank spaces and a delimiting
character of your choice. Then enter one or more lines of text, terminating
the message with the second occurrence of the delimiting character.
When a user connects to a device, the message-of-the-day (MOTD) banner
appears first, followed by the login banner and prompts. After the user logs in
to the device, the EXEC banner is displayed.
Use tokens in the form of $(token) in the message text to customize the
banner. The tokens are described in the table below:
Token Information displayed in the banner
$(hostname) Displays the host name for the device.
$(domain) Displays the domain name for the device.
$(bold) Indicates that the next text is a bold text. Using this token
again indicates the end of the bold text.
$(inverse) Indicates that the next text is an inverse text. Using this
token again indicates the end of the inverse text.
$(contact) Displays the system contact string.
Page 55
User Interface Commands 55
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Use the no exec-banner line configuration command to disable the EXEC
banner on a particular line or lines.
Example
The following example sets an EXEC banner that uses tokens. The percent
sign (%) is used as a delimiting character. Note that the $(token) syntax is
replaced by the corresponding configuration variable.
Device(config)#
banner exec
%
Enter TEXT message. End with the character '%'.
$(bold)Session activated.$(bold) Enter commands at the prompt.
%
When a user logs on to the system, the following output is displayed:
Session activated. Enter commands at the prompt.
banner login
Use the banner login command in Global Configuration mode to specify and
enable a message to be displayed before the username and password login
prompts. Use the no form of this command to delete the existing Login
banner.
Syntax
banner login
d message-text d
no banner login
Parameters
•
Delimiting character of your choice
—A pound sign (#), for example. You
cannot use the delimiting character in the banner message.
$(location) Displays the system location string.
$(mac-
address)
Displays the base MAC address of the device.
Page 56
56 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
•
message-text
—Message text. The message must start on a new line. You
can enter multi-line messages. You can include tokens in the form of
$(token)
in the message text. Tokens are replaced with the corresponding
configuration variable. Tokens are described in the User Guidelines. The
message can contain up to 2000 characters (after every 510 characters, you
must press <Enter> to continue).
Default Configuration
Disabled (no Login banner is displayed).
Command Mode
Global Configuration mode
User Guidelines
Follow this command with one or more blank spaces and a delimiting
character of your choice. Then enter one or more lines of text, terminating
the message with the second occurrence of the delimiting character.
When a user connects to a device, the message-of-the-day (MOTD) banner
appears first, followed by the login banner and prompts. After the user logs in
to the device, the EXEC banner is displayed.
Use tokens in the form of $(token) in the message text to customize the
banner. The tokens are described in the table below:
Token Information displayed in the banner
$(hostname) Displays the host name for the device.
$(domain) Displays the domain name for the device.
$(bold) Indicates that the next text is a bold text. Using this
token again indicates the end of the bold text.
$(inverse) Indicates that the next text is an inverse text. Using this
token again indicates the end of the inverse text.
$(contact) Displays the system contact string.
$(location) Displays the system location string.
$(mac-
address)
Displays the base MAC address of the device.
Page 57
User Interface Commands 57
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Use the no login-banner line configuration command to disable the Login
banner on a particular line or lines.
Example
The following example sets a Login banner that uses tokens. The percent sign
(%) is used as a delimiting character. Note that the $(token) syntax is
replaced by the corresponding configuration variable.
Device(config)# banner login %
Enter TEXT message. End with the character '%'.
You have entered $(hostname).$(domain)
%
When the login banner is executed, the user will see the following banner:
You have entered host123.ourdomain.com
banner motd
Use the banner motd command in Global Configuration mode to specify and
enable a message-of-the-day banner. Use the no form of this command to
delete the existing MOTD banner.
Syntax
banner motd
d message-text d
no banner motd
Parameters
•
d
—Delimiting character of your choice—a pound sign (#), for example.
You cannot use the delimiting character in the banner message.
•
message-text
—The message must start on a new line. You can enter multi-
line messages. You can include tokens in the form of
$(token)
in the
message text. Tokens are replaced with the corresponding configuration
variable. Tokens are described in the User Guidelines. The message can
contain up to 2000 characters (after every 510 characters, you must press
<Enter> to continue).
Page 58
58 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Default Configuration
Disabled (no MOTD banner is displayed).
Command Mode
Global Configuration mode
User Guidelines
Follow this command with one or more blank spaces and a delimiting
character of your choice. Then enter one or more lines of text, terminating
the message with the second occurrence of the delimiting character.
When a user connects to a device, the message-of-the-day (MOTD) banner
appears first, followed by the login banner and prompts. After the user logs in
to the device, the EXEC banner is displayed.
Use tokens in the form of $(token) in the message text to customize the
banner. The tokens are described in the table below:
Use the no motd-banner line configuration command to disable the MOTD
banner on a particular line or lines.
Example
The following example sets an MOTD banner that uses tokens. The percent
sign (%) is used as a delimiting character. Note that the $(token) syntax is
replaced by the corresponding configuration variable.
Token Information displayed in the banner
$(hostname) Displays the host name for the device.
$(domain) Displays the domain name for the device.
$(bold) Indicates that the next text is a bold text. Using this token
again to indicates the end of the bold text.
$(inverse) Indicates that the next text is an inverse text. Using this
token again indicates the end of the inverse text.
$(contact) Displays the system contact string.
$(location) Displays the system location string.
$(mac-address) Displays the base MAC address of the device.
Page 59
User Interface Commands 59
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Device(config)#
banner motd
%
Enter TEXT message. End with the character '%'.
$(bold)Upgrade$(bold) to all devices begins at March 12
%
When the login banner is executed, the user will see the following banner:
Upgrade to all devices begins at March 12
exec-banner
Use the exec-banner command in Line Configuration mode to enable the
display of exec banners. Use the no form of this command to disable the
display of exec banners.
Syntax
exec-banner
no exec-banner
Parameters
This command has no arguments or keywords.
Default Configuration
Disabled
Command Mode
Line Configuration mode
Example
console#
configure
console(config)# line console
console(config-line)# exec-banner
console(config-line)# exit
console(config)# line telnet
console(config-line)# exec-banner
console(config-line)# exit
Page 60
60 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
console(config)# line ssh
console(config-line)# exec-banner
login-banner
Use the login-banner command in Line Configuration mode to enable the
display of login banners. Use the no form of this command to disable the
display of login banners.
Syntax
login-banner
no login-banner
Parameters
This command has no arguments or keywords.
Default Configuration
Enabled
Command Mode
Line Configuration mode
Example
console#
configure
console(config)# line console
console(config-line)# login-banner
console(config-line)# exit
console(config)# line telnet
console(config-line)# login-banner
console(config-line)# exit
console(config)# line ssh
console(config-line)# login-banner
Page 61
User Interface Commands 61
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
motd-banner
Use the motd-banner command in Line Configuration mode to enable the
display of message-of-the-day banners. Use the no form of this command to
disable the display of MOTD banners.
Syntax
motd-banner
no motd-banner
Parameters
This command has no arguments or keywords.
Default Configuration
Enabled
Command Mode
Line Configuration mode
Example
console#
configure
console(config)# line console
console(config-line)# motd-banner
console(config-line)# exit
console(config)# line telnet
console(config-line)# motd-banner
console(config-line)# exit
console(config)# line ssh
console(config-line)# motd-banner
show banner
Use the show banner command in EXEC mode to display the configuration
of banners.
Page 62
62 User Interface Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\User_Interface.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Syntax
show banner motd
show banner login
show banner exec
Parameters
This command has no arguments or keywords.
Command Mode
EXEC mode
Examples
Device> show banner motd
Banner: MOTD
Line SSH: Enabled
Line Telnet: Enabled
Line Console: Enabled
10000 giga ports switch
console#
console# show banner login
-------------------------------------------------------------
Banner: Login
Line SSH: Enabled
Line Telnet: Enabled
Line Console: Enabled
console#
console# show banner exec
Banner: EXEC
Line SSH: Enabled
Line Telnet: Enabled
Line Console: Enabled
console#
Page 63
Macro Commands 63
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\750_Macro.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
3
Macro Commands
macro name
Use the Macro Name Global Configuration mode command to create a user
defined macro.
Use the no form of this command to delete the macro definition.
Syntax
macro name
[macro-name]
no macro name
[macro-name]
Parameters
macro-name—Name of the macro. Macro names are case sensitive.
Default Configuration
The command has no default setting.
Command Mode
Global Configuration mode
User Guidelines
A macro can contain up to 3000 characters and up to 200 lines. Enter one
macro command per line. Use the @ character to end the macro. Use the #
character at the beginning of a line to enter comment text within the macro.
You can define mandatory keywords within a macro by using a help string to
specify the keywords. Enter #macro keywords word to define the keywords
that are available for use with the macro. The keyword name is case sensitive.
You can enter up to three keywords separated by a space. Only the first three
Page 64
64 Macro Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\750_Macro.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
keywords are visible if you enter more than three macro keywords. The
command can be anywhere within the macro.
When creating a macro, do not use the exit or end commands or change the
command mode using interface interface-id. Doing so might cause
commands that follow exit, end or interface interface-id to be executed in a
different command mode.
You can modify a macro by creating a new macro with the same name as the
existing macro. The newer macro overwrites the existing macro.
Examples
The following example shows how to create a macro that defines the duplex
mode and speed:
Switch(config) # macro name dup
Enter macro commands one per line. End with the character ‘@’.
macro description dup
duplex full
speed auto
The following example shows how to create a macro with #macro keywords:
Switch(config) # macro name duplex
Enter macro commands one per line. End with the character ‘@’.
macro description duplex
duplex $DUPLEX
speed $SPEED
#macro keywords $ DUPLEX $ SPEED
@
The following example shows how to apply the macros to an interface:
Switch(config-if) # macro apply duplex $DUPLEX full $SPEED auto
Switch(config-if) # macro apply duplex ?
WORDkeyword to replace with value e.g. $DUPLEX, $SPEED
<cr>
Page 65
Macro Commands 65
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\750_Macro.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Switch(config-if) # macro apply duplex $DUPLEX ?
WORDValue of the first keyword to replace
<cr>
Switch(config-if) # macro apply duplex $DUPLEX full $SPEED ?
WORDValue of the second keyword to replace
macro apply
Use the macro apply interface configuration command to apply a macro to an
interface or to apply and trace a macro configuration on an interface.
Syntax
macro {
apply | trace} macro-name [parameter {value}] [parameter {value}]
[parameter {value}
]
Parameters
•
apply
—Apply a macro to the specific interface.
•
trace
—Apply and trace a macro to the specific interface.
•
macro-name
—Specify the name of the macro.
•
parameter
—(Optional) Specify unique parameter values that are specific
to the interface. You can enter up to three keyword-value pairs. Parameter
keyword matching is case sensitive. All matching occurrences of the
keyword are replaced with the corresponding value.
Default Configuration
The command has no default setting.
Command Mode
Interface Configuration mode
User Guidelines
You can use the macro trace macro-name Interface Configuration command
to apply and show the macros running on an interface or to debug the macro
to find any syntax or configuration errors.
If a command fails because of a syntax error or a configuration error the
macro continues to apply t) in the interface. Use the parameter value
Page 66
66 Macro Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\750_Macro.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
keywords to designate values specific to the interface when creating a macro
that requires the assignment of a unique value.
Keyword matching is case sensitive. All matching occurrences of the keyword
are replaced with the corresponding value. Any full match of a keyword, even
if it is part of a large string, is considered a match and replaced by the
corresponding value.
Some macros might contain keywords that require a parameter value. You can
use the macro apply macro-name command to display a list of any required
values in the macro. If you apply a macro without entering the keyword
values, the commands are invalid and are therefore not applied.
When you apply a macro to an interface, the macro name is automatically
added to the interface. You can display the applied commands and macro
names by using the show running-configuration interface interface-id user
EXEC mode command.
A macro applied to an interface range behaves the same way as a macro
applied to a single interface. When a macro is applied to an interface range, it
is applied sequentially to each interface within the range. If a macro
command fails on one interface, it is nonetheless applied to the remaining
interfaces.
Example
Switch(config) # interface gigabitethernet 1/0/2
Switch(config-if) # macro trace dup
Applying command… ‘duplex full’
Applying command… ‘speed auto’
Switch(config) # interface gigabitethernet 1/0/2
Switch(config-if) # macro apply duplex $DUPLEX full $SPEED auto
Switch(config-if) # exit
Switch(config) # interface gigabitethernet 1/0/3
Switch(config-if) # macro apply dup
Switch(config-if) # exit
Page 67
Macro Commands 67
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\750_Macro.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
macro description
Use the macro description Interface Configuration mode command to enter
a description about which macros are applied to an interface. Use the no form
of this command to remove the description.
Syntax
macro description
text
no macro description
Parameters
text—Description text. The text can contain up to 160 characters.
Default Configuration
The command has no default setting.
Command Mode
Interface Configuration mode
User Guidelines
When multiple macros are applied on a single interface, the description text
is a concatenation of texts from a number of previously applied macros.
You can verify your setting by entering the show parser macro description
privileged EXEC modecommand.
Example
Switch(config) # interface gigabitethernet 1/0/2
Switch(config-if) # macro apply dup
Switch(config-if) # end
Switch(config) # interface gi1/0/3
Switch(config-if) # macro apply duplex $DUPLEX full $SPEED auto
Switch(config-if) # end
Switch # show parser macro description
InterfaceMacro Description
-----------------------------------------------------------------
Page 68
68 Macro Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\750_Macro.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
1/2 dup
1/3 duplex
----------------------------------------------------------------Switch(config) # interface gigabitethernet 1/0/2
Switch(config-if) # no macro description
Switch(config-if) # end
Switch # show parser macro description
InterfaceMacro Description
----------------------------------------------------------------1/3 duplex
-----------------------------------------------------------------
macro global
Use the macro global Global Configuration command to apply a macro to a
switch or to apply and trace a macro configuration on a switch.
Syntax
macro global {
apply | trace} macro-name [parameter {value}] [parameter
{value}] [parameter {value}
]
Parameters
•
apply
—Apply a macro to the switch.
•
trace
—Apply and trace a macro to the switch.
•
macro-name
—Specify the name of the macro.
•
paramete
—(Optional) Specify unique parameter values that are specific
to the switch. You can enter up to three keyword-value pairs. Parameter
keyword matching is case sensitive. All matching occurrences of the
keyword are replaced with the corresponding value.
Default Configuration
The command has no default setting.
Command Mode
Global Configuration mode
Page 69
Macro Commands 69
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\750_Macro.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
User Guidelines
You can use the macro global trace macro-name Global Configuration mode
command to apply and show the macros running on the switch or to debug
the macro in order to locate any syntax or configuration errors.
If a command fails because of a syntax error or a configuration error when you
apply a macro, the macro nonetheless continues to apply the remaining
commands to the interface.
Use the parameter value keywords to designate values specific to the switch
when creating a macro that requires the assignment of unique value.
Keyword matching is case sensitive. All matching occurrences of the keyword
are replaced with the corresponding value. Any full match of a keyword, even
if it is part of a large string, is considered a match and replaced by the
corresponding value.
Some macros might contain keywords that require a parameter value. You can
use the macro global apply macro-name command to display a list of any
required values in the macro. If you apply a macro without entering the
keyword values, the commands are considered invalid and are not applied.
When you apply a macro to the switch, the macro name is automatically
added to the switch. You can display the applied commands and macro names
by using the show running-configuration interface user EXEC mode
command.
macro global description
Use the macro global description Global Configuration command to enter a
description about which macros are applied to the switch. Use the no form of
this command to remove the description.
Syntax
macro global description
text
no macro global description
Parameters
text—Description text. The text can contain up to 160 characters.
Page 70
70 Macro Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\750_Macro.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Default Configuration
The command has no default setting.
Command Mode
Global Configuration mode
User Guidelines
When multiple global macros are applied to a switch, the global description
text is a concatenation of texts from a number of previously applied macros.
You can verify your settings by entering the show parser macro description
privileged EXEC mode command.
show parser macro
Use the show parser macro User EXEC mode command to display the
parameters for all configured macros or for one macro on the switch.
Syntax
show parser macro [
{brief | description [interface interface-id] | name
macro-name}
]
Parameters
•
brief—(Optional) Display the name of each macro.
•
description [interface]—(Optional) Display all macro descriptions.
•
interface-id—Or the description of a specific interface.
•
name macro-name—(Optional) Display information about a single macro
identified by the macro name.
Command Mode
User EXEC mode
Page 71
System Management Commands 71
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
4
System Management Commands
ping
Use the ping command to send ICMP echo request packets to another node
on the network.
Syntax
ping [ip]
{ipv4-address | hostname} [size packet_size] [count packet_count]
[timeout time_out]
ping ipv6
{ipv6-address | hostname} [size packet_size] [count
packet_count] [timeout time_out]
Parameters
•
ip
—Use IPv4 to check the network connectivity.
•
ipv6
—Use IPv6 to check the network connectivity.
•
ipv4-address
—IPv4 address to ping.
•
ipv6-address
—Unicast or multicast IPv6 address to ping. When the IPv6
address is a Link Local address (IPv6Z address), the outgoing interface
name must be specified. Refer to the User Guidelines for the interface
name syntax.
•
hostname
—Hostname to ping (160 characters. Maximum label size: 63.)
•
packet_size
—Number of bytes in the packet not including the VLAN tag.
The default is 64 bytes. (IPv4:64-1518, IPv6: 68-1518)
•
packet_count
—Number of packets to send, from 1 to 65535 packets. The
default is 4 packets. If 0 is entered, it pings until stopped (0–65535).
•
time-out
—Timeout in milliseconds to wait for each reply, from 50 to
65535 milliseconds. The default is 2000 milliseconds (50–65535).
Page 72
72 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Command Mode
EXEC mode
User Guidelines
Press Esc to stop pinging. Following are sample results of the ping command:
•
Destination does not respond
—If the host does not respond, a “no answer
from host” appears within 10 seconds.
•
Destination unreachable
—The gateway for this destination indicates that
the destination is unreachable.
•
Network or host unreachable
—The switch found no corresponding entry
in the route table.
The format of an IPv6Z address is: <
ipv6-link-local-address>%<interface-
name
>
•
interface-name
=
vlan<integer> | ch<integer> | isatap<integer> |
<physical-port-name> | 0
•
integer
= <
decimal-number> | <integer><decimal-number
>
•
decimal-number
=
0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
•
physical-port-name
= Designated port number, for example
gi1/0/1
When using the ping ipv6 command to check network connectivity of a
directly attached host using its link local address, the egress interface may be
specified in the IPv6Z format. If the egress interface is not specified, the
default interface is selected. Specifying interface zone=0 is equivalent to not
defining an egress interface.
When using the ping ipv6 command with MC address, the information
displayed is taken from all received echo responses.
Examples
Console> ping ip 10.1.1.1
Pinging 10.1.1.1 with 64 bytes of data:
64 bytes from 10.1.1.1: icmp_seq=0. time=11 ms
64 bytes from 10.1.1.1: icmp_seq=1. time=8 ms
64 bytes from 10.1.1.1: icmp_seq=2. time=8 ms
Page 73
System Management Commands 73
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
64 bytes from 10.1.1.1: icmp_seq=3. time=7 ms
----10.1.1.1 PING Statistics---4 packets transmitted, 4 packets received, 0% packet loss
round-trip (ms) min/avg/max = 7/8/11
Console> ping ip yahoo.com
Pinging yahoo.com [66.218.71.198] with 64 bytes of data:
64 bytes from 10.1.1.1: icmp_seq=0. time=11 ms
64 bytes from 10.1.1.1: icmp_seq=1. time=8 ms
64 bytes from 10.1.1.1: icmp_seq=2. time=8 ms
64 bytes from 10.1.1.1: icmp_seq=3. time=7 ms
----10.1.1.1 PING Statistics---4 packets transmitted, 4 packets received, 0% packet loss
round-trip (ms) min/avg/max = 7/8/11
Console> ping ip oob/176.16.1.1
Pinging oob/176.16.1.1 with 64 bytes of data:
64 bytes from oob/176.16.1.1: icmp_seq=0. time=5 ms
64 bytes from oob/176.16.1.1: icmp_seq=1. time=5 ms
64 bytes from oob/176.16.1.1: icmp_seq=2. time=5 ms
64 bytes from oob/176.16.1.1: icmp_seq=3. time=5 ms
----10.1.1.1 PING Statistics---4 packets transmitted, 4 packets received, 0% packet loss
round-trip (ms) min/avg/max = 5/5/5
console> ping ipv6 3003::11
Pinging 3003::11 with 64 bytes of data:
64 bytes from 3003::11: icmp_seq=1. time=0 ms
64 bytes from 3003::11: icmp_seq=2. time=50 ms
64 bytes from 3003::11: icmp_seq=3. time=0 ms
Page 74
74 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
64 bytes from 3003::11: icmp_seq=4. time=0 ms
----3003::11 PING Statistics---4 packets transmitted, 4 packets received, 0% packet loss
round-trip (ms) min/avg/max = 0/12/50
console> ping ipv6 FF02::1
Pinging FF02::1 with 64 bytes of data:
64 bytes from 3003::11: icmp_seq=1. time=0 ms
64 bytes from 3003::33: icmp_seq=1. time=70 ms
64 bytes from 3003::11: icmp_seq=2. time=0 ms
64 bytes from 3003::55: icmp_seq=1. time=1050 ms
64 bytes from 3003::33: icmp_seq=2. time=70 ms
64 bytes from 3003::55: icmp_seq=2. time=1050 ms
64 bytes from 3003::11: icmp_seq=3. time=0 ms
64 bytes from 3003::33: icmp_seq=3. time=70 ms
64 bytes from 3003::11: icmp_seq=4. time=0 ms
64 bytes from 3003::55: icmp_seq=3. time=1050 ms
64 bytes from 3003::33: icmp_seq=4. time=70 ms
64 bytes from 3003::55: icmp_sq=4. time=1050 ms
---- FF02::1 PING Statistics---4 packets transmitted, 12 packets received
traceroute
To discover (?) the routes that packets will take when traveling to their
destination, use the traceroute EXEC command.
Syntax
traceroute ip
{ipv4-address | hostname} [size packet_size] [ttl max-ttl]
[count packet_count] [timeout time_out] [source ip-address] [tos tos
]
traceroute ipv6
{ipv6-address | hostname} [size packet_size] [ttl max-ttl]
[count packet_count] [timeout time_out] [source ip-address] [tos tos
]
Page 75
System Management Commands 75
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Parameters
•
ip
—Use IPv4 to discover the route.
•
ipv6
—Use IPv6 to discover the route.
•
ipv4-address
—IPv4 address of the destination host. (Range: Valid IP
address)
•
ipv6-address
—IPv6 address of the destination host.
•
hostname
—Hostname of the destination host. (Range: 1–160 characters.
Maximum label size: 63.)
•
packet_size
—Number of bytes in the packet not including the VLAN tag.
The default is 64 bytes. (IPv4:64-1518, IPv6: 68-1518)
•
ttl max-ttl
—The largest TTL value that can be used. The default is 30.
The
traceroute
command terminates when the destination is reached or
when this value is reached. (Range: 1–255)
•
count packet_count
—The number of probes to be sent at each TTL level.
The default count is 3. (Range: 1–10)
•
timeout time_out
—The number of seconds to wait for a response to a
probe packet. The default is 3 seconds. (Range: 1–60)
•
source ip-address
—One of the interface addresses of the device to use as a
source address for the probes. The device will normally pick what it feels is
the best source address to use. (Range: Valid IP address)
•
tos tos
—The Type-Of-Service byte in the IP Header of the packet.(Range:
0—255)
Command Mode
EXEC mode
User Guidelines
The traceroute command works by taking advantage of the error messages
generated by routers when a datagram exceeds its time-to-live (TTL) value.
The traceroute command starts by sending probe datagrams with a TTL
value of one. This causes the first router to discard the probe datagram and
send back an error message. The traceroute command sends several probes at
each TTL level and displays the round-trip time for each.
Page 76
76 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
The traceroute command sends out one probe at a time. Each outgoing
packet can result in one or two error messages. A "time exceeded” error
message indicates that an intermediate router has seen and discarded the
probe. A "destination unreachable" error message indicates that the
destination node has received the probe and discarded it because it could not
deliver the packet. If the timer goes off before a response comes in, the
traceroute command prints an asterisk (*).
The traceroute command terminates when the destination responds, when
the maximum TTL is exceeded, or when the user interrupts the trace with
Esc.
The traceroute command is not relevant to IPv6 link local addresses.
Example
Router> traceroute ip umaxp1.physics.lsa.umich.edu
Type Esc to abort.
Tracing the route to umaxp1.physics.lsa.umich.edu (141.211.101.64)
1 i2-gateway.stanford.edu (192.68.191.83) 0 msec 0 msec 0 msec
2 STAN.POS.calren2.NET (171.64.1.213) 0 msec 0 msec 0 msec
3 SUNV--STAN.POS.calren2.net (198.32.249.73) 1 msec 1 msec 1 msec
4 Abilene--QSV.POS.calren2.net (198.32.249.162) 1 msec 1 msec 1 msec
5 kscyng-snvang.abilene.ucaid.edu (198.32.8.103) 33 msec 35 msec 35
msec
6 iplsng-kscyng.abilene.ucaid.edu (198.32.8.80) 47 msec 45 msec 45
msec
7 so-0-2-0x1.aa1.mich.net (192.122.183.9) 56 msec 53 msec 54 msec
8 atm1-0x24.michnet8.mich.net (198.108.23.82) 56 msec 56 msec 57 msec
9 * * *
10 A-ARB3-LSA-NG.c-SEB.umnet.umich.edu (141.211.5.22) 58 msec 58 msec 58
msec
11 umaxp1.physics.lsa.umich.edu (141.211.101.64) 62 msec 63 msec 63 msec
Trace completed
Page 77
System Management Commands 77
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
The following table describes the significant fields shown in the display:
The following are characters that can appear in the traceroute command
output:
telnet
The telnet EXEC mode command enables logging on to a host that supports
Tel ne t.
Syntax
telnet {
ip-address
|
hostname
} [
port
] [
keyword
...]
Field Description
1 Indicates the sequence number of the router in the
path to the host.
i2-gateway.stanford.edu Host name of this router.
192.68.191.83 IP address of this router.
1 msec 1 msec 1 msec Round-trip time for each of the probes that are
sent.
Field Description
* The probe timed out.
? Un known packet type.
A Administratively unreachable. Usually, this output indicates that
an access list is blocking traffic.
F Fragmentation required and DF is set.
H Host unreachable.
N Network unrea chable.
P Protocol unreachable.
Q Source quench.
R Fragment reassembly time exceeded
S Source route failed.
U P ort unreachable.
Page 78
78 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Parameters
•
ip-address—Specifies the destination host IP address.
•
hostname—Specifies the destination host name. (Length: 1-160
characters. Maximum label length: 63 characters.)
•
port—Specifies the decimal TCP port number or one of the keywords
listed in the Ports table in the User Guidelines.
•
keyword
—Specifies the one or more keywords listed in the Keywords table
in the User Guidelines.
Default Configuration
The default port is the Telnet port (23) on the host.
By default, Telnet is enabled.
Command Mode
EXEC mode
User Guidelines
Telnet software supports special Telnet commands in the form of Telnet
sequences that map generic terminal control functions to operating systemspecific functions. To enter a Telnet sequence, press the escape sequence keys
(Ctrl-shift-6) followed by a Telnet command character.
Special Telnet Sequences
At any time during an active Telnet session, available Telnet commands can
be listed by pressing the Ctrl-shift-6-? keys at the system prompt.
Telnet Sequence Purpose
Ctrl-shift-6-b Break
Ctrl-shift-6-c Interrupt Process (IP)
Ctrl-shift-6-h Erase Character (EC)
Ctrl-shift-6-o Abort Output (AO)
Ctrl-shift-6-t Are You There? (AYT)
Ctrl-shift-6-u Erase Line (EL)
Page 79
System Management Commands 79
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
A sample of this list follows. Note that the Ctrl-shift-6 sequence appears as
^^ on the screen.
Console> ‘Ctrl-shift-6’ ?
[Special telnet escape help]
^^ B sends telnet BREAK
^^ C sends telnet IP
^^ H sends telnet EC
^^ O sends telnet AO
^^ T sends telnet AYT
^^ U sends telnet EL
Ctrl-shift-6 x suspends the session (return to system
command prompt)
Several concurrent Telnet sessions can be opened, enabling switching
between the sessions. To open a subsequent session, the current connection
has to be suspended by pressing the escape sequence keys (Ctrl-shift-6) and x
to return to the system command prompt. Then open a new connection with
the telnet EXEC mode command.
This command lists concurrent Telnet connections to remote hosts that were
opened by the current Telnet session to the local device. It does not list Telnet
connections to remote hosts that were opened by other Telnet sessions.
Keywords Table
Options Description
/echo Enables local echo.
/quiet Prevents onscreen display of all messages from
the software.
/source-interface Specifies the source interface.
Page 80
80 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Ports Table
/stream Turns on stream processi ng, which enables a raw
TCP stream with no Telnet control sequences. A
stream connection does not process Telnet options
and can be appropriate for connections to ports
running UNIX-to-UNIX Copy Program (UUCP) and
other non-Telnet protocols.
Ctrl-shift-6 x Returns to the System Command Prompt.
Keyword Description Port Number
BGP Border Gateway Proto co l 179
chargen Character generator 19
cmd Remote commands 514
daytime Daytime 13
discard Discard 9
domain Domain Name Service 53
echo Echo 7
exec Exec 512
finger Finger 79
ftp File Transfer Protocol 21
ftp-data FTP data connections 20
gopher Gopher 70
hostname NIC hostname server 101
ident Ident Protocol 113
irc Interne t Re la y C ha t 194
klogin Kerberos login 543
kshell Kerberos shell 544
login Login 513
lpd Printer service 515
nntp Network News Transport Protocol 119
Options Description
Page 81
System Management Commands 81
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example displays logging in to IP address 176.213.10.50 via
Tel ne t.
Console>
telnet
176.213.10.50
Esc U sends telnet EL
resume
The resume EXEC mode command enables switching to another open Telnet
session.
Syntax
resume [
connection
]
Parameters
connection—Specifies the connection number. (Range: 1-4 connections.)
pim-auto-rp PIM Auto-RP 496
pop2 Post Office Protocol v2 109
pop3 Post Office Protocol v3 110
smtp Simple Mail Transport Protocol 25
sunrpc Sun Remote Procedure Call 111
syslog Syslog 514
tacacs TAC Access Control System 49
talk Talk 517
telnet Telnet 23
time Time 37
uucp Unix-to-Unix Copy Program 540
whois Nickname 43
www World Wide Web 80
Keyword Description Port Number
Page 82
82 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Default Configuration
The default connection number is that of the most recent connection.
Command Mode
EXEC mode
Example
The following command switches to open Telnet session number 1.
Console>
resume
1
hostname
The hostname Global Configuration mode command specifies or modifies
the device host name. Use the no form of the command to remove the
existing host name.
Syntax
hostname
name
no hostname
Parameters
Name—specifies The Device Host Name. (Length: 1-160 Characters.
Maximum label length: 63 characters.)
Default Configuration
No host name is defined.
Command Mode
Global Configuration mode
Example
The following example specifies the device host name as ‘enterprise’.
Console(config)#
hostname
enterprise
enterprise(config)#
Page 83
System Management Commands 83
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
reload
The reload Privileged EXEC mode command reloads the operating system.
Syntax
reload [slot
stack-member-number]
Command Mode
Privileged EXEC mode
Parameters
stack-member-number —Specifies the new master unit number. (Range:
1–8). If unspecified, reloads all the units.
Example
The following example reloads the operating system on all units.
Console#
reload
This command will reset the whole system and disconnect your
current session. Do you want to continue? (y/n) [n]
stack master
The stack master Global Configuration mode command forces a stack master
selection. Use the no form of this command to restore the default
configuration.
Syntax
stack master unit
unit
no stack master
Parameters
unit —Specifies the new master unit number. (Range: 1–2)
Default Configuration
The default is no forced master.
Page 84
84 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Command Mode
Global Configuration mode
Example
The following example forces the stack master to be unit 2.
Console(config)#
stack master unit
2
system light
Use the system light EXEC command to light LEDs on a specific unit.
Syntax
system light [
unit unit-number] [duration seconds
]
system light stop
Parameters
•
unit-number
—Specify unit number or all.
•
seconds
—The number of seconds to light the LEDs. If unspecified,
defaults to 5 seconds. (Range: 2–6)
•
stop
—Stop lighting the LEDs.
Command Mode
EXEC mode
switch renumber
Use the switch renumber Global Configuration command to change the unit
ID of a specific unit.
Syntax
switch
current-unit-number renumber new-unit-number
Parameters
•
current-unit-number
—Specify Unit number. (Range: 1–
8)
Page 85
System Management Commands 85
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
•
new-unit-number
—The new unit number. (Range:
1–8)
Command Mode
Global Configuration mode
show switch
The show switch EXEC mode command displays stack status information for
the stack or stack member.
Syntax
show switch [
stack-member-number
]
Parameters
stack-member-number— Specifies the unit number. (Range: 1–6)
Command Mode
EXEC mode
Example
The following examples display the stack status information.
Console>
show switch
Unit
----
1
3
4
5
6
7
8
2
MAC Address
-----------------
00:00:b0:87:12:11
00:00:b0:87:12:13
00:00:b0:87:12:14
00:00:b0:87:12:15
00:00:b0:87:12:16
00:00:b0:87:12:17
00:00:b0:87:12:18
00:00:b0:87:12:12
SW
------
3.30
3.30
3.30
3.30
3.30
3.30
3.30
3.30
Master
------
Enabled
Forced
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Uplink
-----
2
1
3
4
5
6
7
8
Down
link
-----
3
4
5
6
7
8
2
1
Status
------
Slave
Master
Slave
Slave
Slave
Slave
Slave
Slave
Page 86
86 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
service cpu-utilization
The service cpu-utilization Global Configuration mode command enables
measuring CPU utilization. Use the no form of this command to restore the
default configuration.
Syntax
service cpu-utilization
no service cpu-utilization
Default Configuration
Measuring CPU utilization is disabled.
Command Mode
Global Configuration mode
User Guidelines
Use the show cpu utilization Privileged EXEC command to view
information on CPU utilization.
Configured order: Unit 1 at Top, Unit 2 at bottom
Console>
show switch
1
Unit 1:
MAC address: 00:00:b0:87:12:11
Master: Forced.
Product: Fonseca 48 . Sof tw ar e : 3. 30
Uplink unit: 8. Downlink unit: 2.
Status: Master
Active image: image-1.
Selected for next bo ot : im ag e -2 .
Page 87
System Management Commands 87
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example enables measuring CPU utilization.
Console(config)#
service cpu-utilization
show cpu utilization
The show cpu utilization Privileged EXEC mode command displays
information about CPU utilization.
Syntax
show cpu utilization
Command Mode
Privileged EXEC mode
User Guidelines
Use the service cpu-utilization Global Configuration mode command to
enable measuring CPU utilization.
Example
The following example displays CPU utilization information.
Console#
show cpu utilization
CPU utilization service is on.
CPU utilization
-------------------------------------------------five seconds: 5%; one minute: 3%; five minutes: 3%
clear cpu counters
The clear cpu counters EXEC mode command clears traffic counters to and
from the CPU.
Syntax
clear cpu counters
Page 88
88 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Command Mode
EXEC mode
Example
The following example clears the CPU traffic counters.
Console#
clear cpu counters
service cpu-counters
The service cpu-counters Global Configuration mode command enables
traffic counting to and from the CPU. To disable counting, use the no form of
this command.
Syntax
service cpu-counters
no service cpu-counters
Command Mode
Global Configuration mode
User Guidelines
Use the show cpu counters command to display the CPU traffic counters.
Example
The following example enables counting CPU traffic.
Console(config)#
service cpu-counters
show cpu counters
The show cpu counters EXEC mode command displays traffic counter
information to and from the CPU.
Syntax
show cpu counters
Page 89
System Management Commands 89
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Command Mode
EXEC mode
User Guidelines
Use the service cpu-counters command to enable traffic counting to and
from the CPU.
Example
The following example displays the CPU traffic counters.
Console#
show cpu counters
CPU counters are active.
In Octets: 987891
In Unicast Packets: 3589
In Multicast Packets: 29
In Broadcast Packets: 8
Out Octets: 972181
Out Unicast Packets: 3322
Out Multicast Packets: 22
Out Broadcast Packets: 8
show users
The show users EXEC mode command displays information about the active
users.
Syntax
show users
Command Mode
EXEC mode
Page 90
90 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example displays information about the active users.
show sessions
The show sessions EXEC mode command displays open Telnet sessions.
Syntax
show sessions
Command Mode
EXEC mode
User Guidelines
The command displays Telnet sessions to remote hosts opened by the current
Telnet session to the local device. It does not display Telnet sessions to
remote hosts opened by other Telnet sessions to the local device.
Console#
show users
Username
---------Bob
John
Robert
Betty
Sam
Protocol
----------Serial
SSH
HTTP
Telnet
Location
------------
172.16.0.1
172.16.0.8
172.16.1.7
172.16.1.6
Page 91
System Management Commands 91
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example displays open Telnet sessions.
The following table describes significant fields shown above.
show system
The show system EXEC mode command displays system information.
Syntax
show system [unit
unit
]
Parameters
unit unit — Specifies the unit number. (Range: 1–8)
Command Mode
EXEC mode
Console#
show sessions
Connection
---------1
2
Host
------------Remote router
172.16.1.2
Address
----------
172.16.1.1
172.16.1.2
Port
----23
23
Byte
---89
8
Field Description
Connection The connection number.
Host The remote host to which the device is connected through a
Telnet session.
Address The remote host IP address.
Port The Telnet TCP port number.
Byte The number of unread bytes for the user to see on the
connection.
Page 92
92 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example displays the system information.
console# show system
Unit Type
---- --------------------- 1 PowerConnect 5524
2 PowerConnect 5524
3 PowerConnect 5524
4 PowerConnect 5524
5 PowerConnect 5524
6 PowerConnect 5524
7 PowerConnect 5524
8 PowerConnect 5524
Unit Main Power Supply Redundant Power Supply
---- ----------------- --------------------- 1 OK
2 OK
3 OK
4 OK
5 OK
6 OK
7 OK
8 OK NOT OPERATIONAL
Unit Fans Status
---- ------------ 1 OK
2 OK
3 OK
4 OK
5 IDLE
6 OK
7 OK
8 FAILURE
Page 93
System Management Commands 93
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Unit Temperature (Celsius) Temperature Sensor
Status
---- ------------------------- -------------- 1 47 OK
2 45 OK
3 49 OK
4 36 OK
5 35 OK
6 45 OK
7 40 OK
8 56 OK
Unit Up time
---- -------------- 1 00,00:31:24
2 00,00:31:19
3 00,00:31:24
4 00,00:31:24
5 00,00:31:24
6 00,00:31:24
7 00,00:31:25
8 00,00:31:25
console# show system unit 2
System Type: PowerConnect 5548
System Up Time (days,hour:min:sec): 08,23:03:46
System Contact:
System Name:
System Location:
System MAC Address: 00:99:88:66:33:33
System Object ID: 1.3.6.1.4.1.674.10895.3031
Type: PowerConnect 5548
Main Power Supply Status: OK
Page 94
94 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Fans Status: OK
Unit Temperature (Celsius) Status
------------- ------------------- ------------ 2 42 OK
show version
The show version EXEC mode command displays system version
information.
Syntax
show version [unit
unit
]
Parameters
unit
unit
— Specifies the unit number. (Range: 1–8)
Command Mode
EXEC mode
Example
The following example displays system version information.
console >
show version
Unit
SW Version Boot Version HW Version
------ ----------- ------------ ----------
1 3.131 2.178 1.0.0
2
3.131 2.178 1.0.0
system resources routing
The system resources routing Global Configuration mode command
configures the routing table maximum size. Use the no form of this
command to return to the default size.
Syntax
system resources routing
routes hosts interfaces
Page 95
System Management Commands 95
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
no system resources routing
Parameters
•
routes
—Specifies the maximum number of remote networks in the
routing table.
•
hosts
—Specifies the maximum number of directly attached hosts.
•
interfaces
—Specifies the maximum number of IP interfaces.
Default Configuration
Hosts: 200, Routes: 64, IP Interfaces: 32
Command Mode
Global Configuration mode
User Guidelines
The settings are effective after reboot.
Example
The following example configures the routing table maximum size.
Console#
system resources routing
20 23 5
show system resources routings
The show system resources routings EXEC mode command displays system
routing resources information.
Syntax
show system resources routings
Command Mode
EXEC mode
Page 96
96 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example displays the system routing resources information.
Console>
show system resources routings
Parameters Current value After reboot Value
-------------- ---------------- ------------------Hosts: 100 100
Routes: 32 32
IP Interfaces: 32 32
show system tcam utilization
The show system tcam utilization EXEC mode command displays the
Ternary Content Addressable Memory (TCAM) utilization.
Syntax
show system tcam utilization [
unit unit
]
Parameters
unit unit—Specifies the unit number. (Range: 1–8)
Command Mode
EXEC mode
Example
The following example displays TCAM utilization information.
Console>
show system tcam utilization
System: 75%
Unit
---1
2
TCAM utilization [%]
-------------------58
57
Page 97
System Management Commands 97
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
show system defaults
Use the show system defaults command to display system defaults.
Syntax
show system defaults [
section
]
Parameters
section—Show information for specific session only. Available values are:
management, 802.1x, port, fdb, port-mirroring, spanning-tree, vlan, voicevlan, ip-addressing, network-security and qos-acl.
Command Mode
EXEC mode
Examples
console# show system defaults
System Mode: Router
Maximum units in stack: 8
# Management defaults
Telnet: Enabled (Maximum 4 sessions, shared with SSH)
SSH: Enabled (Maximum 4 sessions, shared with Telnet)
HTTP: Enabled, port 80 (Maximum 27 sessions)
HTTPS: Disabled
SNMP: Enabled.
User: first
SNMP version: V3
SNMP Local Engine ID: 0000000001
SNMP Notifications: Enabled
SNMP Authentication Notifications: Enabled
Console: Enabled.
Cryptographic keys are not generated
HTTPS certificate is not generated
Management ACL: No ACL is defined
AAA Telnet authentication login: Local user data base
Page 98
98 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
AAA HTTP authentication login: Local data base
AAA HTTPS authentication login: Local data base
Radius accounting: Disabled
Radius: No server is defined
Tacacs: No server is defined
Syslog: No server is defined
Logging: Enabled
Logging to console: Informational messages
Logging to internal buffer: Informational messages
Logging to file: Error messages
Logging to remote server: Informational messages
Maximum no. of syslog messages: 200
SNTP: supported
SNTP Port No.: 123
SNTP Interface: Enabled
IP Domain Naming System: Enabled
DHCP Server: Enabled
DHCP Auto Configuration: Enabled
DHCP Option 67: Enabled
DHCP Option 82: Disabled
# IPv6 defaults
# 802.1x defaults
802.1X is disabled
Mode: Multiple host
Guest VLAN: Not defined
# Interface defaults in present unit
48 GE regular
2 10G fiberOptics
PoE: Enabled
POE mode: Port Limit
Duplex: Full
Negotiation: Enabled
Flow control: Off
Page 99
System Management Commands 99
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Mdix mode: auto
LAGs: No LAG is defined
Storm control: Disabled
Storm control mode: unknown unicast, broadcast, multicast
Port security: Disabled
LLDP: Enabled
LLDPDU Handeling: Filtering
Jumbo frames: Disabled
Port-Channel Load Balancing: Layer 2
# Bridging defaults
Maximum 16K entries
Aging time: 5 minutes
iSCSI: Enabled
iSCSI cos: 5, with no remark
# Multicast defaults
Multicast filtering: Disabled
IGMP snooping: Disabled
IGMP Querier: Disabled
Multicast TV Vlan Interface: disabled
# Port monitoring defaults
Port monitor is not defined
Maximum source port: 4
Maximum destination ports for mirroring: 2
# Spanning tree defaults
Spanning tree is Enabled
Spanning tree mode is Classic
Spanning tree interface: Enabled
Port fast: Disabled
BPDU handling: Filtering
BPDU Guard: Disabled
# Vlan defaults
Page 100
100 System Management Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\System_Management.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Maximum Vlans: 4094
Default VLAN: Enabled
Default VLAN id: 1
GVRP: Disabled
Port mode: undefined
PVID: 1
VLAN membership: 1
# Voice vlan defaults
Voice VLAN: Disabled
Cos: 6 with no remark
OUI table:
00:E0:BB 3COM
00:03:6B Cisco
00:E0:75 Veritel
00:D0:1E Pingtel
00:01:E3 Simens
00:60:B9 NEC/Philips
00:0F:E2 Huawei-3COM
00:09:6E Avaya
# Network security defaults
DHCP snooping: Disabled
ARP inspection: Disabled
ARP inspection Validation: Disabled
# DOS attacks
# IP addressing defaults
No IP interface is defined
# QOS and ACLs defaults
QoS mode is basic
QoS Basic Trust Mode: CoS
QoS Advanced Trust Mode: CoS-DSCP
Queue default mapping:
