SETUP GUIDE

Regulatory model: P11F Regulatory type: P11F001

SETUP GUIDE

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your

computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

If you purchased a Dell™ n Series computer, any references in this document to the Microsoft® Windows® operating systems are not applicable.

__________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, XPS, Solution Station, and DellConnect are trademarks of Dell Inc.; Intel,

Pentium, and Centrino are registered trademarks and Microsoft, Windows, and the

Corporation in the United States and/or other countries; Blu‑ray Disc is a trademark of the Blu‑ray Disc Association; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under license.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

Windows

start button logo are either trademarks or registered trademarks of Microsoft

July 2010 P/N N0KR7 Rev. A00

Core

is a trademark of Intel Corporation in the U.S. and other countries;

Contents

Setting Up Your XPS Laptop . . . . . . . .7

Before Setting Up Your Computer . . . . . . 7

Connect the AC Adapter . . . . . . . . . . . . . . 8

Connect the Network Cable

(Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Press the Power Button . . . . . . . . . . . . . .10

Set Up Microsoft Windows . . . . . . . . . . . 11

Create System Recovery Media

(Recommended). . . . . . . . . . . . . . . . . . . . 12

Install the SIM Card (Optional) . . . . . . . . 14

Enable or Disable Wireless

(Optional) . . . . . . . . . . . . . . . . . . . . . . . . . 16

Set Up Wireless Display (Optional) . . . . .18

Set Up the TV Tuner (Optional) . . . . . . . .19

Connect to the Internet (Optional). . . . .20

Using Your XPS Laptop. . . . . . . . . . . 22

Right View Features . . . . . . . . . . . . . . . . .22

Left View Features . . . . . . . . . . . . . . . . . .26

Front View Features . . . . . . . . . . . . . . . . .27

Back View Features . . . . . . . . . . . . . . . . .28

Computer Base and Keyboard

Features. . . . . . . . . . . . . . . . . . . . . . . . . . .30

Status Lights and Indicators. . . . . . . . . . .34

Disabling Battery Charging . . . . . . . . . . . 35

Touch Pad Gestures . . . . . . . . . . . . . . . . . 36

Multimedia Control Keys . . . . . . . . . . . . .38

Control Strip Features . . . . . . . . . . . . . . .40

Using the Optical Drive . . . . . . . . . . . . . . 42

Display Features . . . . . . . . . . . . . . . . . . . .44

Touch Screen Gestures (Optional) . . . . . 46

Contents

Removing and Replacing the

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Software Features. . . . . . . . . . . . . . . . . . .50

Dell DataSafe Online Backup. . . . . . . . . . 51

Dell Stage (Optional) . . . . . . . . . . . . . . . . 52

NVIDIA Optimus Technology. . . . . . . . . .54

Free Fall Sensor. . . . . . . . . . . . . . . . . . . . .55

Dell Dock (Optional). . . . . . . . . . . . . . . . .56

Solving Problems . . . . . . . . . . . . . . . .57

Beep Codes. . . . . . . . . . . . . . . . . . . . . . . . 57

Touch Screen Problems. . . . . . . . . . . . . .58

Network Problems . . . . . . . . . . . . . . . . . .59

Power Problems . . . . . . . . . . . . . . . . . . . .60

Memory Problems . . . . . . . . . . . . . . . . . . 61

Lockups and Software Problems . . . . . .62

Using Support Tools . . . . . . . . . . . . . 64

Dell Support Center . . . . . . . . . . . . . . . . .64

My Dell Downloads . . . . . . . . . . . . . . . . .65

System Messages . . . . . . . . . . . . . . . . . . .65

Hardware Troubleshooter . . . . . . . . . . . . 67

Dell Diagnostics . . . . . . . . . . . . . . . . . . . . 67

Restoring Your Operating

System . . . . . . . . . . . . . . . . . . . . . . . . .72

System Restore. . . . . . . . . . . . . . . . . . . . . 73

Dell DataSafe Local Backup. . . . . . . . . . . 74

System Recovery Media . . . . . . . . . . . . . . 76

Dell Factory Image Restore . . . . . . . . . . . 77

Contents

Getting Help. . . . . . . . . . . . . . . . . . . . 79

Technical Support and Customer

Service. . . . . . . . . . . . . . . . . . . . . . . . . . . .80

DellConnect . . . . . . . . . . . . . . . . . . . . . . .80

Online Services. . . . . . . . . . . . . . . . . . . . . 81

Automated Order‑Status Service . . . . . .82

Product Information. . . . . . . . . . . . . . . . .82

Returning Items for Repair Under

Warranty or for Credit . . . . . . . . . . . . . . . 83

Before You Call. . . . . . . . . . . . . . . . . . . . . 85

Contacting Dell. . . . . . . . . . . . . . . . . . . . .87

Finding More Information and

Resources . . . . . . . . . . . . . . . . . . . . . . 88

Specifications . . . . . . . . . . . . . . . . . . 90

Appendix. . . . . . . . . . . . . . . . . . . . . . . 97

Macrovision Product Notice . . . . . . . . . . 97

Information for NOM, or Official

Mexican Standard (Only for Mexico). . . .98

Index . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Contents

Setting Up Your XPS Laptop

This section provides information about setting up your Dell™ XPS™ laptop.

Before Setting Up Your Computer

When positioning your computer, ensure that you allow easy access to a power source, adequate ventilation, and a level surface to place your computer.

Restricting airflow around your laptop may cause it to overheat. To prevent overheating ensure that you leave a minimum of 5.1 cm (2 inches) on the right and left sides. You should never place your computer in an enclosed space, such as a cabinet or drawer while it is powered on.

WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not place your Dell computer in a low-airflow environment, such as a closed briefcase, or on fabric surfaces, such as carpets or rugs, while it is powered on. Restricting the airflow can damage the computer, deteriorate the computer performance, or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.

CAUTION: Placing or stacking heavy or sharp objects on the computer may result in permanent damage to the computer.

Setting Up Your XPS Laptop

Connect the AC Adapter

Connect the AC adapter to the computer and then plug it into an electrical outlet or surge protector.

WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. Using an incompatible cable or improperly connecting the cable to a power strip or electrical outlet may cause fire or permanent damage to your computer.

Setting Up Your XPS Laptop

Connect the Network Cable (Optional)

To use a wired network connection, connect the network cable.

Setting Up Your XPS Laptop

Press the Power Button

Setting Up Your XPS Laptop

Set Up Microsoft Windows

Your Dell computer is preconfigured with the Microsoft® Windows® operating system. To set up Windows for the first time, follow the instructions on the screen. These steps are mandatory and may take some time to complete. The Windows setup screens will take you through several procedures including accepting license agreements, setting preferences, and setting up an Internet connection.

CAUTION: Do not interrupt the operating system’s setup process. Doing so may render your computer unusable and you will need to reinstall the operating system.

NOTE: For optimal performance of your computer, it is recommended that you download and install the latest BIOS and drivers for your computer available at support.dell.com.

NOTE: For more information on the operating system and features, go to support.dell.com/MyNewDell.

Setting Up Your XPS Laptop

Create System Recovery Media (Recommended)

NOTE: It is recommended that you create a system recovery media as soon as you set up

Microsoft Windows.

The system recovery media can be used to restore your computer to the operating state it was in when you purchased the computer, while preserving data files (without the need of the Operating System disc). You can use the system recovery media if changes to the hardware, software, drivers, or other system settings have left the computer in an undesirable operating state.

You will require the following to create the system recovery media:

Dell DataSafe Local Backup•

USB key with a minimum capacity of 8 GB or DVD‑R/DVD+R/Blu‑ray Disc•

NOTE: Dell DataSafe Local Backup does not support rewritable discs.

™

Setting Up Your XPS Laptop

To create a system recovery media:

Ensure that the AC adapter is connected (see “Connect the AC Adapter” on page 1. 8).

Insert the disc or USB key in the computer.2.

Click 3. Start → All Programs→ Dell DataSafe Local Backup.

Click 4. Create Recovery Media.

Follow the instructions on the screen.5.

NOTE: For information on restoring your operating system using the system recovery media, see “System Recovery Media” on page 76.

Setting Up Your XPS Laptop

Install the SIM Card (Optional)

NOTE: Installing a SIM card is not required if you are using an EVDO card to access the

Internet.

NOTE: Installing a mini B‑CAS card into the SIM card slot is required to set up and view ISDB‑T digital TV in Japan.

Installing a Subscriber Identity Module (SIM) card on your computer allows you to connect to the Internet. To access the Internet you must be within the network of your cellular service provider.

To install the SIM card:

Turn off your computer.1.

Remove the battery (see “Removing and Replacing the Battery” on page 2. 48).

In the battery bay, slide the SIM card into the SIM card slot.3.

Replace the battery (see “Removing and Replacing the Battery” on page 4. 48).

Turn on your computer.5.

To remove the SIM card, press and eject the SIM card.

Setting Up Your XPS Laptop

1 battery bay 2 SIM card slot 3 SIM card

Setting Up Your XPS Laptop

Enable or Disable Wireless (Optional)

Setting Up Your XPS Laptop

To enable or disable wireless:

Ensure that your computer is turned on.1.

Press the wireless key 2. on the function key row on the keyboard. The current status of the wireless radios appears on the screen.

Wireless enabled

Wireless disabled

Press the wireless key 3. again to switch between the wireless enabled or disabled states.

NOTE: The wireless key allows you to quickly turn off wireless radios (Wi‑Fi and Bluetooth®), such as when you are asked to disable all wireless radios on an airplane flight.

Setting Up Your XPS Laptop

Set Up Wireless Display (Optional)

NOTE: Wireless display may not be

supported on all computers.

Wireless display can only be set up on computers with:

Processor Intel® Core™ i3‑3xx to i7‑6xx

Video controller

WLAN card Intel Centrino®

Operating system

Driver Download and install the

Intel HD Graphics

6100/6200/6300 or Intel Centrino Advanced‑N + WiMAX 6250

Windows 7 Home Premium, Professional, or Ultimate

latest driver for “Intel Wireless Display Connection Manager” available at support.dell.com.

To set up wireless display on your computer:

Ensure that your computer is turned on.1.

Ensure that wireless is enabled (see “Enable 2. or Disable Wireless” on page 16).

Connect the wireless display adapter to 3. the TV.

NOTE: The wireless display adapter does not ship with your computer and must be purchased separately.

Turn on the TV and the wireless display 4. adapter.

Select the appropriate video source 5. for your TV, such as HDMI1, HDMI2, or S‑Video.

Double‑click the Intel6. icon on the desktop. The Intel® Wireless Display window appears.

Wireless Display

Setting Up Your XPS Laptop

Select 7. Scan for available displays.

Select your wireless display adapter from 8. the Detected wireless displays list.

Enter the security code that appears on 9. your TV.

To enable wireless display:

Double‑click the Intel1. icon on the desktop. The Intel Wireless Display window appears.

Select 2. Connect to Existing Adapter.

NOTE: For more information on wireless display, see the documentation that shipped with your wireless display adapter.

Wireless Display

Set Up the TV Tuner (Optional)

NOTE: Availability of the TV tuner may

vary by region.

To set up the TV tuner:

If not already inserted, turn off the 1. computer and insert the mini B‑CAS card into the SIM card slot on your computer (Japan only).

Connect the TV/digital antenna cable 2. or the cable adapter to the antenna‑in connector on your computer.

Turn on your computer.3.

Click 4. Start → All Programs→ Windows

Media Center→ Tasks→ Settings→ TV.

Follow the instructions on the screen.5.

Setting Up Your XPS Laptop

Connect to the Internet (Optional)

To connect to the Internet, you need an external modem or network connection and an Internet Service Provider (ISP).

If an external USB modem or WLAN adapter is not a part of your original order, you can purchase one from www.dell.com.

Setting Up a Wired Connection

If you are using a dial‑up connection, • connect the telephone line to the optional external USB modem and to the telephone wall connector before you set up your Internet connection.

If you are using a DSL or cable/satellite • modem connection, contact your ISP or cellular telephone service for setup

instructions. To complete setting up your wired Internet connection, follow the instructions in “Setting Up Your Internet Connection” on page 21.

Setting Up a Wireless Connection

NOTE: To set up your wireless router,

see the documentation that shipped with your router.

Before you can use your wireless Internet connection, you need to connect to your wireless router.

To set up your connection to a wireless router:

Ensure that wireless is enabled on your 1. computer (see “Enable or Disable Wireless” on page 16).

Save and close any open files, and exit any 2. open programs.

Click 3. Start → Control Panel.

In the search box, type 4. network, and then click Network and Sharing Center→ Connect to a network.

Follow the instructions on the screen to 5. complete the setup.

Setting Up Your XPS Laptop

Setting Up Your Internet Connection

ISPs and ISP offerings vary by country. Contact your ISP for offerings available in your country.

If you cannot connect to the Internet but have successfully connected in the past, the ISP might have a service outage. Contact your ISP to check the service status, or try connecting again later.

Have your ISP information ready. If you do not have an ISP, the Connect to the Internet wizard can help you get one.

To set up your Internet connection:

Save and close any open files, and exit any 1. open programs.

Click 2. Start → Control Panel.

In the search box, type 3. network, and then click Network and Sharing Center→

Set up a new connection or network→ Connect to the Internet.

The Connect to the Internet window appears.

NOTE: If you do not know which type of connection to select, click Help me choose or contact your ISP.

Follow the instructions on the screen and 4. use the setup information provided by your ISP to complete the setup.

Using Your XPS Laptop

1 2 5 6 73 4

This section provides information about the features available on your Dell™ XPS™ laptop.

Right View Features

Using Your XPS Laptop

1 Optical drive — Plays or records CDs, DVDs, and Blu‑ray Discs (optional). For more

information, see “Using the Optical Drive” on page 42.

2 Optical drive light — Blinks when you press the optical drive eject button or when you

insert a disc and it is being read.

3 Optical drive eject button — Opens the optical drive tray when pressed.

4 Emergency eject hole — Use to open the optical drive tray if it does not open when you

press the eject button. For more information, see “Using the Emergency Eject Hole” on page 42.

Audio-out/Headphone connector — Connects to a pair of headphones or to a

powered speaker or sound system.

Headphone/digital S/PDIF combo connector — Connects to amplifiers, speakers, or

TVs for digital audio output. Can also be used to connect to a pair of headphones.

Audio-in/Microphone connector — Connects to a microphone or inputs signal for

use with audio programs.

NOTE: You can set up 5.1 channel speakers by using the three audio connectors (5, 6, and 7) or by using the S/PDIF connector (6).

Using Your XPS Laptop

eSATA/USB combo connector with USB PowerShare — Connects to eSATA

compatible storage devices (such as external hard drives or optical drives) or USB devices (such as a mouse, keyboard, printer, external drive, or MP3 player). The USB PowerShare feature allows you to charge USB devices when the computer is powered on/off or in sleep state.

NOTE: Certain USB devices may not charge when the computer is powered off or in sleep state. In such cases, turn on the computer to charge the device.

NOTE: If you turn off your computer while charging a USB device, the device stops

charging. To continue charging, disconnect the USB device and connect it again.

NOTE: The USB PowerShare feature is automatically shut off when only 10% of the total battery life remains.

Using Your XPS Laptop

Left View Features

USB 3.0 connector — Connects to USB devices, such as a mouse, keyboard, printer,

external drive, or MP3 player.

Front View Features

Using Your XPS Laptop

and share digital photos, music, videos, and documents stored on memory cards. For the supported memory cards, see “Specifications” on page 92.

NOTE: Your computer ships with a plastic blank installed in the media card slot. Blanks protect unused slots from dust and other particles. Save the blank for use when no media card is installed in the slot; blanks from other computers may not fit your computer.

9-in-1 Media Card Reader — Provides a fast and convenient way to view

Using Your XPS Laptop

1 2 3 4 65 7

Back View Features

Using Your XPS Laptop

Mini-DisplayPort connector — Digital interface standard connector that connects to

external DisplayPort monitors and projectors.

HDMI connector — Connects to a TV for both 5.1 audio and video signals.

NOTE: When used with a monitor, only the video signal is read.

Network connector — Connects your computer to a network or a broadband device

if you are using a wired network.

4 Antenna-in connector (on supported models) — Connects to an external antenna

(included) or coaxial cable (adapter included) to view programs using the TV tuner card (optional).

AC adapter connector — Connects to the AC adapter to power the computer and

charge the battery.

USB 3.0 connector — Connects to USB devices, such as a mouse, keyboard, printer,

external drive, or MP3 player.

7 Security cable slot — Attaches a commercially available security cable to the computer.

NOTE: Before you buy a security cable, ensure that it fits into the security cable slot on

your computer.

Using Your XPS Laptop

Computer Base and Keyboard Features

Using Your XPS Laptop

Battery status light — Indicates the battery charge status. For more information on

the battery status light, see “Status Lights and Indicators” on page 34.

Hard drive activity light — Turns on when the computer reads or writes data. A solid

white light indicates hard drive activity.

CAUTION: To avoid loss of data, never turn off the computer when the hard drive activity light is on.

3 Control strip — The power button, status lights, and touch‑sensitive controls are located

in this strip. For more information on the control strip, see “Control Strip Features” on page 40.

4 XPS logo light — The light on the XPS logo indicates the power states. For more

information on the logo light, see “Status Lights and Indicators” on page 34.

5 Function key row — The dual display enable or disable key , wireless enable or

disable key , battery charge status key , brightness increase and decrease

keys, touch pad enable or disable key , and the multimedia keys are located in

this row.

For more information on the multimedia keys, see “Multimedia Control Keys” on page 38.

Using Your XPS Laptop

9 8 7

Using Your XPS Laptop

6 Keyboard/Backlit Keyboard (optional) — The backlit keyboard provides visibility in dark

environments by illuminating all symbols on the keys.

Backlit keyboard brightness settings — Press the <F6> key to toggle the three

lighting states (in the given order):

half keyboard brightness•

full keyboard brightness•

no lighting•

7 Touch pad buttons — Provide left‑click and right‑click functions like those on a mouse.

8 Touch pad status light — Turns on if the touch pad is disabled.

9 Touch pad — Provides the functionality of a mouse to move the cursor, drag or move

selected items, and left‑click by tapping the surface.

The touch pad supports the Scroll, Flick, Zoom, and Rotate features. To change the touch pad settings, double‑click the Synaptics Pointing Device icon in the notification area of your desktop. For more information, see “Touch Pad Gestures” on page 36.

NOTE: To enable or disable the touch pad, press the key on the function key row on the keyboard.

Using Your XPS Laptop

Status Lights and Indicators

Battery Status Light

Indicator light status Computer state(s) Battery charge status

AC adapter solid white on/standby/off/

off on/standby/off/

Battery

solid amber on/standby low battery (<= 10%)

off on/standby/off/

hibernate

hibernate off/hibernate

charging

fully charged

not charging

Power Button Light

Indicator light status Computer state(s)

solid white breathing white off

NOTE: For information on power problems, see “Power Problems” on page 60.

or XPS Logo Light

on standby off/hibernate

Using Your XPS Laptop

Disabling Battery Charging

You may be required to disable the battery charging feature while on an airplane flight. To quickly disable the battery charging feature:

Ensure that your computer is turned on.1.

Press the battery health meter key 2. on the function key row on the keyboard.

In the 3. Battery Life tab, select the Disable battery charging check box.

NOTE: Battery charging can also be disabled in the System Setup (BIOS) utility.

Using Your XPS Laptop

Touch Pad Gestures

Scroll

Allows you to scroll through content. The scroll feature includes:

Scroll Vertical — Allows you to scroll up or down on the active window.

Move two fingers up or down to scroll the selected object.

Move two fingers up or down at a fast pace to activate vertical auto scrolling.

Tap on the touch pad to stop auto scrolling

Scroll Horizontal — Allows you to scroll left

or right on the active window.

Move two fingers left or right to scroll the selected object.

Move two fingers left or right at a fast pace to activate horizontal auto scrolling.

Tap on the touch pad to stop auto scrolling

Flick

Allows you to flip content forward or backward based on the direction of the flick.

Move three fingers quickly in the desired direction to flip content in the active window.

Using Your XPS Laptop

Zoom

Allows you to increase or decrease the magnification of the screen content. The zoom feature includes:

Pinch — Allows you to zoom‑in or zoom‑out by moving two fingers apart or bringing them closer together on the touch pad.

To zoom in: Move two fingers apart to enlarge the view of the active window.

To zoom out: Move two fingers close together to reduce the view of the active window.

Rotate

Allows you to rotate the active content on the screen. The rotate feature includes:

Twist — Allows you to rotate the active content using two fingers where one finger is anchored and the other rotates.

Keeping the thumb in place, move the index finger in an arced direction right or left to rotate the selected item clockwise or counterclockwise.

Using Your XPS Laptop

Multimedia Control Keys

The multimedia control keys are located on the function key row on the keyboard. To use the multimedia controls, press the required key. You can configure the multimedia control keys on the keyboard using the System Setup (BIOS) utility or Windows Mobility Center.

System Setup

Press <F2> during POST (Power On Self Test) to enter the System Setup (BIOS) utility.1.

In the 2. Function Key Behavior, select Multimedia Key First or Function Key First.

Multimedia Key First — This is the default option. Press any multimedia key to perform the associated multimedia action. For function, press <Fn> + the required function key.

Function Key First — Press any function key to perform the associated function. For multimedia action, press <Fn> + the required multimedia key.

NOTE: The Multimedia Key First option is active only in the operating system.

Windows Mobility Center

Press the <1. ><X> keys or touch the Windows Mobility Center control on the control

strip to launch Windows Mobility Center.

In the 2. Function Key Row, select Function Key or Multimedia Key.

Using Your XPS Laptop

Mute the sound Play the previous track or chapter

Decrease the volume level Play or pause

Increase the volume level Play the next track or chapter

Using Your XPS Laptop

1 2 3 4 5 6 7

Control Strip Features

Using Your XPS Laptop

Power button and light — Turns the computer on or off when pressed. The light on

the button indicates the power states. For more information on the power button light, see “Status Lights and Indicators” on page 34.

Caps lock status light — Turns on if the Caps Lock is enabled.

Wireless status light — Turns on if wireless is enabled. For more information, see

“Enable or Disable Wireless” on page 16.

Battery status light — Indicates the battery charge status. For more information on

the battery status light, see “Status Lights and Indicators” on page 34.

NOTE: The battery is charging when the computer is powered using the AC adapter.

Windows Mobility Center control — Touch to launch the Windows Mobility Center.

Instant launch control — Touch to launch a predefined application of your choice.

Audio control-panel control — Touch to launch the Dell Audio control panel. The

control panel allows you to setup studio‑quality audio output on your computer. You can also change the audio settings such as volume, external speaker setup, and microphone setup.

Using Your XPS Laptop

Using the Optical Drive

CAUTION: Do not press down on the optical drive tray when you open or close it. Keep the optical drive tray closed when you are not using the drive.

CAUTION: Do not move the computer while playing or recording a disc.

The optical drive plays or records CDs, DVDs, and Blu‑ray Discs (optional). Ensure that the side with print or writing is facing upward when placing discs on the optical drive tray.

To place a disc in the optical drive:

Press the eject button on the optical drive. 1.

Pull out the optical drive tray.2.

Place the disc, label‑side up, in the center of the optical drive tray and snap the disc onto 3.

the spindle.

Push the optical drive tray back into the drive. 4.

Using the Emergency Eject Hole

If the optical drive tray does not eject when you press the eject button, you can use the emergency eject hole to open the drive tray. To open the drive tray using the emergency eject hole:

Turn off the computer.1.

Insert a small pin or unfolded paper clip into the emergency eject hole and push firmly until 2.

the drive tray opens.

1 disc

2 spindle 3 optical drive tray

4 emergency eject hole

5 eject button

Using Your XPS Laptop

1 2 3 4

Display Features

Using Your XPS Laptop

1 Microphone — Provides high quality sound for video conferencing and voice recording.

2 Camera indicator light — Indicates if the camera is on or off.

3 Camera — Built‑in camera for video capture, conferencing, and chat. The camera

supports the H.264 video compression codec, which provides high quality video at low data transmission rates.

4 Display — Your display can vary based on selections you made when purchasing your

computer. The display may support the touch screen feature if you selected the option at the time of purchase. For information on the touch screen gestures, see “Touch Screen Gestures (Optional)” on page 46.

Using Your XPS Laptop

Touch Screen Gestures (Optional)

NOTE: Some of these gestures are

application‑specific and may not work across applications.

Zoom

Allows you to increase or decrease the magnification of the screen content. Pinch — Allows you to zoom‑in or zoom‑ out by moving two fingers apart or bringing them closer together on the screen.

To zoom in: Move two fingers apart to enlarge the view of the active window.

To zoom out: Move two fingers close together to reduce the view of the active window.

Dwell

Allows you to access additional information by simulating a right‑click.

Press and hold a finger on the touch screen, to open context‑sensitive menus.

Flick

Allows you to flip content forward or backward based on the direction of the flick.

Move a finger quickly in the desired direction to flip through content in the active window like pages in a book. Flick also works vertically when navigating content such as images or songs in a playlist.

Using Your XPS Laptop

Scroll

Allows you to scroll through content. The scroll features include:

Pan — Allows you to move the focus on the selected object when the entire object is not visible.

Move two fingers in the desired direction to pan scroll the selected object.

Scroll Vertical — Allows you to scroll up or scroll down on the active window.

Move a finger up or down to activate vertical scrolling.

Scroll Horizontal — Allows you to scroll right or left on the active window.

Move a finger to the right or left to activate horizontal scrolling.

Rotate

Allows you to rotate the active content on the screen.

Twist — Allows you to rotate the active content using two fingers.

Keeping a finger or thumb in place, move the other finger in an arced direction right or left. You can also rotate the active content by moving both the fingers in a circular motion.

Using Your XPS Laptop

Removing and Replacing the Battery

WARNING: Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer.

WARNING: Using an incompatible battery may increase the risk of fire or explosion. This computer should only use a battery purchased from Dell. Do not use batteries from other computers.

WARNING: Before removing the battery, shut down the computer, and remove external cables (including the AC adapter).

To remove the battery:

Turn off the computer and turn it over. 1.

Slide the battery release latch to the 2. unlock position.

Lift the battery up at an angle and remove 3. it from the battery bay.

To replace the battery:

Align the tabs on the battery with the slots 1. on the battery bay.

Press the battery down until the battery 2. release latch clicks.

Using Your XPS Laptop

1 battery release latch

2 battery 3 tabs (3)

Using Your XPS Laptop

Software Features

FastAccess Facial Recognition

Your computer may have the FastAccess facial recognition feature. This feature helps keep your Dell computer secure by learning the unique appearance of your face and uses this to verify your identity to automatically supply login information when you would normally enter this information yourself (such as for logging on to a Windows account or secure websites). For more information, click

Start → All Programs→ FastAccess.

Productivity and Communication

You can use your computer to create presentations, brochures, greeting cards, fliers, and spreadsheets. You can also edit and view digital photographs and images. Check your purchase order for software installed on your computer.

After connecting to the Internet, you can access websites, setup an e‑mail account, and upload or download files.

Using Your XPS Laptop

Entertainment and Multimedia

You can use your computer to watch videos, play games, create your own CDs/DVDs, listen to music and Internet radio stations.

You can download or copy pictures and video files from portable devices, such as digital cameras and cell phones. Optional software applications enable you to organize and create music and video files that can be recorded to disc, saved on portable products such as MP3 players and handheld entertainment devices, or played and viewed directly on connected TVs, projectors, and home theater equipment.

Dell DataSafe Online Backup

NOTE: Dell DataSafe Online is supported

only on Windows operating systems.

NOTE: A broadband connection is recommended for fast upload/download speeds.

Dell DataSafe Online is an automated backup and recovery service that helps protect your data and other important files from catastrophic incidents like theft, fire, or natural disasters. You can access the service on your computer using a password‑protected account.

For more information, go to

DellDataSafe.com.

To schedule backups:

Double‑click the Dell DataSafe Online 1. icon in the notification area of your desktop.

Follow the instructions on the screen.2.

Using Your XPS Laptop

Dell Stage (Optional)

The Dell Stage software provides access to your favorite media and multi‑touch applications.

To launch Dell Stage, click Start →

All Programs→ Dell Stage→ Dell Stage.

NOTE: Some of the applications on

Dell Stage can also be launched from the All Programs menu.

You can customize Dell Stage as follows:

Rearrange an application shortcut — Select •

and hold the application shortcut until

it blinks and then drag the application

shortcut to a desired location on Dell

Stage.

Minimize — Drag the Dell Stage window to •

the bottom of the screen.

Personalize — Select the settings icon and •

then choose the desired option.

The following are the applications available on Dell Stage:

NOTE: Some of the applications may not be available based on the selections you made while purchasing your computer.

MUSIC• — Play music or browse through your music files by album, artist, or song title. You can also listen to radio stations from across the globe. The optional Napster application allows you to download songs when connected to the Internet.

YOUPAINT• — Draw and edit pictures.

GAMES• — Play touch‑enabled games.

DOCUMENTS• — Provides quick access to the Documents folder on your computer.

Using Your XPS Laptop

PHOTO• — View, organize, or edit your pictures. You can create slideshows and collections of your pictures and upload them to Facebook or Flickr when connected to the Internet.

•DELL WEB — Provides a preview of up to four of your favorite web pages. Click or tap the web page preview to open it in the web browser.

VIDEO• — View videos. The optional CinemaNow application allows you to purchase or rent movies and TV shows when connected to the Internet.

SHORTCUTS• — Provides quick access to your frequently‑used programs.

STICKYNOTES• — Create notes or reminders using the keyboard or touch screen. These notes will appear on the bulletin board the next time you access STICKYNOTES. You can also save notes on your desktop.

Web Tile — Provides a preview of up to four • of your favorite web pages. The tile allows you to add, edit, or delete a web page preview. Click or tap the web page preview to open it in the web browser. You can also create multiple Web Tiles through the Apps Gallery.

Using Your XPS Laptop

NVIDIA Optimus Technology

Your XPS laptop is equipped with NVIDIA’s Optimus technology. The Optimus technology is designed to maximize performance and user experience on your computer, while minimizing the impact on battery life. It enables you to combine the graphic processing capability of the integrated Intel® graphic processing unit (GPU) with the discrete NVIDIA GPU while running graphic‑intensive applications such as 3D games. The NVIDIA GPU is turned on only for preset applications and thus extends the battery life.

The Optimus solution is enabled through an application profile. When an application is launched, the video drivers check if the application has an associated application profile.

If an application profile exists, the NVIDIA • GPU is turned on and the application runs in performance mode. The NVIDIA GPU is turned off automatically when the application is closed.

If an application profile does not exist, the • integrated Intel GPU is used.

The default list of application profiles is updated frequently by NVIDIA and is automatically downloaded to your computer when you are connected to the Internet.

You can also create application profiles for any application on your computer. This may be required for newly released games or applications that do not have a default application profile.

Using Your XPS Laptop

Changing the Application Profile Settings

Right‑click the desktop and select 1. NVIDIA Control Panel.

In the 2. NVIDIA Control Panel window, click 3D Settings to expand the selection (if not already expanded) and then click Manage 3D Settings.

In the 3. Program Settings tab, click Add and browse to select the application’s executable file (.exe). Once added, you can change the settings for that application.

To change the settings for a specific application, select the application in the Select a program to customize: list and make the desired changes.

NOTE: For more information on the options and settings available in the NVIDIA Control Panel, click Help.

Free Fall Sensor

Free fall sensor protects your computer hard drive from possible damage, by detecting a free fall state caused by accidentally dropping the computer. When a free fall state is detected, the hard drive is placed in a safe state to protect against damage to the read/write head and possible data loss. Your hard drive returns to normal operation, when the free fall state is no longer detected.

Using Your XPS Laptop

Dell Dock (Optional)

The Dell Dock is a group of icons that provides easy access to frequently‑used applications, files, and folders. You can personalize the Dock by:

Adding or removing icons•

Grouping related icons into categories•

Changing the color and location of the Dock•

Changing the behavior of the icons•

Add a Category

Right‑click the Dock, click 1. Add→ Category. The Add/Edit Category window appears.

Enter a title for the category in the 2. Title field.

Select an icon for the category from the 3. Select an image: box.

Click 4. Save.

Add an Icon

Drag and drop the icon to the Dock or a category.

Remove a Category or Icon

Right‑click the category or icon on the 1. Dock and click Delete shortcut or Delete category.

Follow the instructions on the screen.2.

Personalize the Dock

Right‑click the Dock and click 1. Advanced Setting...

Choose the desired option to personalize 2. the Dock.

Solving Problems

This section provides troubleshooting information for your computer. If you cannot solve your problem using the following guidelines, see “Using Support Tools” on page 64 or “Contacting Dell” on page 87.

WARNING: Only trained service personnel should remove the computer cover. See the support.dell.com/manuals for advanced service instructions.

Service Manual

Beep Codes

Your computer might emit a series of beeps during start‑up if there are errors or problems. This series of beeps, called a beep code, identifies a problem. If this occurs, write down the beep code and contact Dell (see “Contacting Dell” on page 87) for assistance.

NOTE: To replace parts, see the Service Manual at support.dell.com.

Beep Code Possible Problem

One Possible system board failure —

BIOS ROM checksum failure

Two No RAM detected

NOTE: If you installed or replaced the memory module, ensure that the memory module is seated properly.

Three Possible system board failure —

Chipset error

Four RAM read/write failure

Five Real Time Clock failure

Six Video card or chip failure

Seven Processor failure

Eight Display failure

Solving Problems

Touch Screen Problems

Some or all multi-touch features are not working —

Certain touch and multi‑touch features • may be disabled. To enable them, double‑ click the Flicks icon in the notification area of your desktop. In the Pen and Touch window, select the Touch tab and ensure that Use your finger as an input device and Enable multi-touch gestures and inking options are selected.

The multi‑touch feature may not be • supported by the application.

The touch screen is calibrated at the • factory, and does not require re‑ calibration. If you choose to calibrate the touch screen, click Start → Control

panel→ Hardware and Sound→ Tablet PC Settings→ Calibrate...

NOTE: Improper calibration may lead to

inaccurate touch sensitivity.

If the touch screen starts losing its sensitivity — The touch screen may have

foreign particles (such as sticky notes) that are blocking the touch sensors. To remove these particles:

Turn off the computer.1.

Disconnect the AC adapter from the wall 2. outlet.

CAUTION: Do not use water or a cleaning liquid to wipe the touch screen.

Use a clean, lint‑free cloth (can spray mild, 3. non abrasive cleaner or water on cloth if needed, but not on the screen) and wipe the surface and sides of the touch screen to remove any dirt or fingerprints.

Solving Problems

Network Problems

Wireless Connections

If the wireless network connection is lost —

The wireless router is offline or wireless has been disabled on the computer.

Check your wireless router to ensure it is • powered on and connected to your data source (cable modem or network hub).

Check if wireless is enabled on the • computer (see “Enable or Disable Wireless” on page 16).

Re‑establish your connection to the • wireless router (see “Setting Up a Wireless Connection” on page 20).

Interference may be blocking or • interrupting your wireless connection. Try moving the computer closer to your wireless router.

Wired Connections

If the wired network connection is lost —

The network cable is loose or damaged.

Check the network cable to ensure it is • plugged in and not damaged.

Solving Problems

Power Problems

If the power light is off — The computer is

either turned off, in hibernate mode, or is not receiving power.

Press the power button. The computer • resumes normal operation if it is off or in hibernate mode.

Reseat the AC adapter cable into both the • power connector on the computer and the electrical outlet.

If the AC adapter cable is plugged into a • power strip, ensure that the power strip is plugged into an electrical outlet and that the power strip is turned on. Also bypass power protection devices, power strips, and power extension cables to verify that the computer turns on properly.

Ensure that the electrical outlet is working • by testing it with another device, such as a lamp.

Check the AC adapter cable connections. • If the AC adapter has a light, ensure that the light on the AC adapter is on.

If the power light is solid white and the computer is not responding — The display

may not be responding.

Press the power button until the computer • turns off and then turn it back on.

If the problem persists, contact Dell (see • “Contacting Dell” on page 87).

Solving Problems

If the power light is breathing white — The

computer is in standby or the display may not be responding.

Press a key on the keyboard, move the • connected mouse or a finger on the touch pad, or press the power button to resume normal operation.

If the display is not responding, press the • power button until the computer turns off and then turn it back on.

If the problem persists, contact Dell (see • “Contacting Dell” on page 87).

If you encounter interference that hinders reception on your computer — An unwanted

signal is creating interference by interrupting or blocking other signals. Some possible causes of interference are:

Power, keyboard, and mouse extension • cables.

Too many devices connected to a • power strip.

Multiple power strips connected to the • same electrical outlet.

Memory Problems

If you receive an insufficient memory message —

Save and close any open files and exit any • open programs you are not using to see if that resolves the problem.

See the software documentation for • minimum memory requirements. If necessary, install additional memory (see the Service Manual at support.dell.com/manuals).

Reseat the memory module(s) into the • connector(s) (see the Service Manual at support.dell.com/manuals).

If the problem persists, contact Dell (see • “Contacting Dell” on page 87).

If you experience other memory problems —

Run Dell Diagnostics (see “Dell • Diagnostics” on page 67).

If the problem persists, contact Dell (see • “Contacting Dell” on page 87).

Solving Problems

Lockups and Software Problems

If the computer does not start up — Ensure

that the AC adapter cable is firmly connected to the computer and to the electrical outlet.

If a program stops responding —

End the program:

Press <Ctrl><Shift><Esc> simultaneously.1.

Click 2. Applications.

Select the program that is no longer 3. responding

Click 4. End Task.

If a program crashes repeatedly — Check the software documentation. If necessary, uninstall and then reinstall the program.

NOTE: Software usually includes installation instructions in its documentation or on the CD.

If the computer stops responding or a solid blue screen appears —

CAUTION: You might lose data if you are unable to perform an operating system shutdown.

If you are unable to get a response by pressing a key on your keyboard, or by moving your mouse, press the power button for at least 8 to 10 seconds until the computer turns off and then restart your computer.

If a program is designed for an earlier Microsoft® Windows® operating system —

Run the Program Compatibility Wizard. The Program Compatibility Wizard configures a program so that it runs in an environment similar to an earlier version of Microsoft Windows operating system.

Solving Problems

To run the Program Compatability Wizard:

Click 1. Start → Control Panel→

Programs→ Run programs made for previous versions of Windows.

In the welcome screen, click 2. Next.

Follow the instructions on the screen.3.

If you have other software problems —

Back up your files immediately.•

Use a virus‑scanning program to check the • hard drive or CDs.

Save and close any open files or programs • and shut down your computer through the Start menu.

Check the software documentation or • contact the software manufacturer for troubleshooting information:

Ensure that the program is compatible – with the operating system installed on your computer.

Ensure that your computer meets – the minimum hardware requirements needed to run the software. See the software documentation for information.

Ensure that the program is installed and – configured properly.

Verify that the device drivers do not – conflict with the program.

If necessary, uninstall and then reinstall – the program.

Write down any error message that is – displayed to help in troubleshooting when contacting Dell.

Using Support Tools

Dell Support Center

The Dell Support Center helps you find the service, support, and system‑specific information you need.

To launch the application, click the icon in the notification area of your desktop.

The Dell Support Center home page displays your computer’s model number, service tag, express service code, and service contact information.

The home page also provides links to access:

Self Help (Troubleshooting, Security, System Performance, Network/Internet, Backup/ Recovery, and Windows operating system)

Alerts (technical support alerts

relevant to your computer)

Assistance from Dell (Technical Support with DellConnect™, Customer Service, Training and Tutorials, How‑To Help with Solution Station™, and Online Scan with PC CheckUp)

About Your System (System Documentation, Warranty Information, System Information, Upgrades & Accessories)

For more information about Dell Support

Center and available support tools, go to DellSupportCenter.com.

Using Support Tools

My Dell Downloads

NOTE: My Dell Downloads may not be

available in all regions.

Some of the software pre‑installed on your new Dell computer do not include a backup CD or DVD. This software is available on the My Dell Downloads website. From this website you can download available software for reinstallation or create your own backup media.

To register and use My Dell Downloads:

Go to 1. DownloadStore.dell.com/media.

Follow the instructions on the screen to 2. register and download the software.

Reinstall the software or create a backup 3. media for future use.

System Messages

If your computer has an issue or error, it may display a system message that will help you identify the cause and action needed to resolve the issue.

NOTE: If the message that appeared is not listed in the following examples, see the documentation for either the operating system or the program that was running when the message appeared or contact Dell (see “Contacting Dell” on page 87) for assistance.

Using Support Tools

CMOS checksum error — Possible system

board failure or RTC battery low. Replace the battery (see the Service Manual at support.dell.com/manuals) or Contact Dell (see “Contacting Dell” on page 87) for assistance.

Hard-disk drive failure — Possible hard‑disk drive failure during POST. Contact Dell (see “Contacting Dell” on page 87) for assistance.

Hard-disk drive read failure — Possible hard‑disk drive failure during HDD boot test. Contact Dell (see “Contacting Dell” on page 87) for assistance.

No boot device available — No bootable partition on hard drive, the hard drive cable is loose, or no bootable device exists.

If the hard drive is your boot device, ensure • that the cables are connected and that the drive is installed properly and partitioned as a boot device.

Enter system setup and ensure that the • boot sequence information is correct (see the Service Manual at support.dell.com/

manuals).

CAUTION - Hard Drive SELF MONITORING SYSTEM has reported that a parameter has exceeded its normal operating range. Dell recommends that you back up your data regularly. A parameter out of range may or may not indicate a potential hard drive problem — S.M.A.R.T error, possible hard drive

failure. Contact Dell (see “Contacting Dell” on page 87) for assistance.

Using Support Tools

Hardware Troubleshooter

If a device is either not detected during the operating system setup or is detected but incorrectly configured, you can use the Hardware Troubleshooter to resolve the incompatibility.

To start the Hardware Troubleshooter:

Click 1. Start → Help and Support.

Type 2. hardware troubleshooter in the search field and press <Enter> to start the search.

In the search results, select the option that 3. best describes the problem and follow the remaining troubleshooting steps.

Dell Diagnostics

If you experience a problem with your computer, perform the checks in “Lockups and Software Problems” on page 62 and run Dell Diagnostics before you contact Dell for technical assistance.

NOTE: Dell Diagnostics works only on Dell computers.

NOTE: The Drivers and Utilities disc may not ship with your computer.

Ensure that the device that you want to test displays in the system setup program and is active. Press <F2> during POST (Power On Self Test) to enter the System Setup (BIOS) utility.

Start Dell Diagnostics from your hard drive or from the Drivers and Utilities disc.

Using Support Tools

Starting Dell Diagnostics From Your Hard Drive

Dell Diagnostics is located on a hidden diagnostic utility partition on your hard drive.

NOTE: If your computer cannot display a screen image, contact Dell (see “Contacting Dell” on page 87) for assistance.

Ensure that the computer is connected 1. to an electrical outlet that is known to be working properly.

Turn on (or restart) your computer.2.

When the DELL3. immediately. Select Diagnostics from the boot menu and press <Enter>. This may invoke the Pre‑Boot System Assessment (PSA) on your computer.

NOTE: If you wait too long and the operating system logo appears, continue to wait until you see the Microsoft® Windows® desktop; then, shut down your computer and try again.

™

logo appears, press <F12>

NOTE: If you see a message stating that no diagnostics utility partition has been found, run Dell Diagnostics from the

Drivers and Utilities disc.

If PSA is invoked:

The PSA will start running tests.a.

If the PSA completes successfully, b. the following message appears :

“No problems have been found with this system so far. Do you want to run the remaining memory tests? This will take about 30 minutes or more. Do you want to continue? (Recommended).”

Using Support Tools

If you are experiencing memory issues, c. press <y>, otherwise press <n>. The following message appears: “Booting

Dell Diagnostic Utility Partition. Press any key to continue.”

Press any key to go to the d. Choose An Option window.

If PSA is not invoked:

Press any key to start Dell Diagnostics from the diagnostic utility partition on your hard drive and to go to the Choose An Option window.

Select the test you want to run.4.

If a problem is encountered during a 5. test, a message with an error code and a description of the problem appears on your screen. Write down the error code and problem description and contact Dell (see “Contacting Dell” on page 87) for assistance.

NOTE: The Service Tag for your computer is displayed at the top of each test screen. The Service Tag helps you identify your computer when you contact Dell.

When the tests complete, close the test 6. screen to return to the Choose An Option window.

To exit Dell Diagnostics and restart the 7. computer, click Exit.

Using Support Tools

Starting Dell Diagnostics From the Drivers and Utilities Disc

NOTE: The Drivers and Utilities disc may

not ship with your computer.

Insert the1. Drivers and Utilities disc.

Shut down and restart the computer. 2. When the DELL™ logo appears, press <F12> immediately.

NOTE: If you wait too long and the operating system logo appears, continue to wait until you see the Microsoft Windows desktop; then, shut down your computer and try again.

NOTE: The next steps change the boot sequence for one time only. On the next start‑up, the computer boots according to the devices specified in the system setup program.

When the boot device list appears, 3. highlight CD/DVD/CD-RW and press <Enter>.

Select the 4. Boot from CD-ROM option from the menu that appears and press <Enter>.

Type 1 to start the CD menu and press 5. <Enter> to proceed.

Select 6. Run the 32 Bit Dell Diagnostics from the numbered list. If multiple versions are listed, select the version appropriate for your computer.

Select the test you want to run.7.

If a problem is encountered during a 8. test, a message with an error code and a description of the problem appears on your screen. Write down the error code and problem description and contact Dell (see “Contacting Dell” on page 87) for assistance.

NOTE: The Service Tag for your computer is displayed at the top of each test screen. The Service Tag helps you identify your computer when you contact Dell.

When the tests complete, close the test 9. screen to return to the Choose An Option window.

To exit Dell Diagnostics and restart the 10. computer, click Exit.

Remove the11. Drivers and Utilities disc.

Using Support Tools

Restoring Your Operating System

You can restore the operating system on your computer using any of the following options:

CAUTION: Using Dell Factory Image Restore or the your operating system permanently deletes all data files on your computer. If possible, backup your data files before using these options.

Option Use

System Restore as the first solution

Dell DataSafe Local Backup when System Restore does not resolve your problem

System recovery media when operating system failure prevents the use of

System Restore and DataSafe Local Backup

when installing the Dell factory‑installed software on a newly installed hard drive

Dell Factory Image Restore to restore your computer to the operating state it was in

when you received your computer

Operating System disc to reinstall only the operating system on your computer

NOTE: The Operating System disc may not ship with your computer.

Operating System

disc to restore

Restoring Your Operating System

System Restore

The Microsoft® Windows® operating systems provide a System Restore option which allows you to return your computer to an earlier operating state (without affecting data files) if changes to the hardware, software, or other system settings have left the computer in an undesirable operating state. Any changes that System Restore makes to your computer are completely reversible.

CAUTION: Make regular backups of your data files. System Restore does not monitor your data files or recover them.

Starting System Restore

Click 1. Start .

In the search box, type 2. System Restore and press <Enter>.

NOTE: The User Account Control window may appear. If you are an administrator on the computer, click Continue; otherwise, contact your administrator to continue the desired action.

Click 3. Next and follow the instructions on the screen.

In the event that System Restore did not resolve the issue, you may undo the last system restore.

Undoing the Last System Restore

NOTE: Before you undo the last system

restore, save and close all open files and exit any open programs. Do not alter, open, or delete any files or programs until the system restoration is complete.

Click 1. Start .

In the search box, type 2. System Restore and press <Enter>.

Click 3. Undo my last restoration and click

Next.

Restoring Your Operating System

Dell DataSafe Local Backup

CAUTION: Using Dell DataSafe Local Backup to restore your operating system permanently removes any programs or drivers installed after you received your computer. Create backup media of applications you need to install on your computer before using Dell DataSafe Local Backup. Use Dell DataSafe Local Backup only if System Restore did not resolve your operating system problem.

CAUTION: Although Dell Datasafe Local Backup is designed to preserve the data files on your computer, it is recommended that you backup your data files before using the Dell DataSafe Local Backup.

NOTE: If Dell DataSafe Local Backup is

not available on your computer, use Dell Factory Image Restore (see “Dell Factory Image Restore” on page 77) to restore your operating system.

You can use Dell DataSafe Local Backup to restore your hard drive to the operating state it was in when you purchased your computer, while preserving the data files.

Dell DataSafe Local Backup allows you to:

Backup and restore your computer to an • earlier operating state

Create system recovery media (see “Create • System Recovery Media (Recommended)“ on page 12)

Dell DataSafe Local Backup Basic

To restore the operating system and Dell factory‑installed software while preserving the data files:

Turn off your computer.1.

Disconnect all the devices (USB drive, 2. printer, and so on) connected to the computer and remove any newly added internal hardware.

NOTE: Do not disconnect the AC adapter.

Restoring Your Operating System

Turn on your computer.3.

When the DELL4. several times to access the Advanced Boot

Options window.

NOTE: If you wait too long and the

operating system logo appears, continue to wait until you see the Microsoft Windows desktop; then, shut down your computer and try again.

Select 5. Repair Your Computer.

Select 6. Dell DataSafe Restore and

Emergency Backup from the System Recovery Options menu and follow the

instructions on the screen.

NOTE: The restoration process may take an hour or more depending on the size of the data to be restored.

NOTE: For more information, see knowledge base article 353560 at support.dell.com.

™

logo appears, press <F8>

Upgrading to Dell DataSafe Local Backup Professional

NOTE: Dell DataSafe Local Backup

Professional may be installed on your computer, if you ordered it at the time of purchase.

Dell DataSafe Local Backup Professional provides additional features that allow you to:

Backup and restore your computer based • on file types

Backup files to a local storage device•

Schedule automated backups•

To upgrade to Dell DataSafe Local Backup Professional:

Double‑click the Dell DataSafe Local 1. Backup icon in the notification area of your desktop.

Click 2. UPGRADE NOW!

Follow the instructions on the screen.3.

Restoring Your Operating System

System Recovery Media

CAUTION: Although the system recovery media is designed to preserve the data files on your computer, it is recommended that you backup your data files before using the system recovery media.

You can use the system recovery media, created using Dell DataSafe Local Backup, to return your hard drive to the operating state it was in when you purchased the computer while preserving the data files on your computer.

Use the system recovery media in case of:

Operating system failure that prevents the • use of the recovery options installed on your computer.

Hard drive failure that prevents data from • being recovered.

To restore the operating system and Dell factory‑installed software on your computer using the system recovery media:

Insert the system recovery disc or USB key 1. and restart the computer.

When the DELL2. immediately.

NOTE: If you wait too long and the operating system logo appears, continue to wait until you see the Microsoft Windows desktop; then, shut down your computer and try again.

Select the appropriate boot device from 3. the list and press <Enter>.

Follow the instructions on the screen.4.

™

logo appears, press <F12>

Restoring Your Operating System

Dell Factory Image Restore

CAUTION: Using Dell Factory Image Restore to restore your operating system permanently deletes all data on the hard drive and removes any programs or drivers installed after you received your computer. If possible, back up the data before using this option. Use Dell Factory Image Restore only if System Restore did not resolve your operating system problem.

NOTE: Dell Factory Image Restore may

not be available in certain countries or on certain computers.

NOTE: If Dell Factory Image Restore is not available on your computer, use Dell DataSafe Local Backup (see “Dell DataSafe Local Backup” on page 74) to restore your operating system.

Use Dell Factory Image Restore only as the last method to restore your operating system.

This option restores your hard drive to the operating state it was in when you purchased the computer. Any programs or files added since you received your computer—including data files—are permanently deleted from the hard drive. Data files include documents, spreadsheets, e‑mail messages, digital photos, music files, and so on. If possible, back up all data before using Dell Factory Image Restore.

Starting Dell Factory Image Restore

Turn on the computer. 1.

When the DELL2. several times to access the Advanced Boot

Options window.

NOTE: If you wait too long and the

operating system logo appears, continue to wait until you see the Microsoft Windows desktop; then, shut down your computer and try again.

™

logo appears, press <F8>

Restoring Your Operating System

Select 3. Repair Your Computer. The System Recovery Options window appears.

Select a keyboard layout and click 4. Next.

To access the recovery options, log on 5. as a local user. To access the command prompt, type administrator in the User name field, then click OK.

Click 6. Dell Factory Image Restore. The Dell Factory Image Restore welcome screen appears.

NOTE: Depending upon your configuration, you may need to select

Dell Factory Tools, then Dell Factory Image Restore.

Click 7. Next. The Confirm Data Deletion screen appears.

NOTE: If you do not want to proceed with the Factory Image Restore, click

Cancel.

Select the check box to confirm that you 8. want to continue to reformat the hard drive and restore the system software to the factory condition, then click Next.

The restore process begins and may take five or more minutes to complete. A message appears when the operating system and factory‑installed applications have been restored to factory condition.

Click 9. Finish to restart the computer.

Getting Help

If you experience a problem with your computer, you can complete the following steps to diagnose and troubleshoot the problem:

See “Solving Problems” on page 1. 57 for information and procedures that pertain to the problem your computer is experiencing.

See “Dell Diagnostics” on page 2. 67 for procedures on how to run Dell Diagnostics.

Fill out the “Diagnostic Checklist” on 3. page 86.

Use Dell’s extensive suite of online 4. services available at Dell Support (support. dell.com) for help with installation and troubleshooting procedures. See “Online Services” on page 81 for a more extensive list of Dell Support online.

If the preceding steps have not resolved the 5. problem, see “Before You Call” on page 85.

NOTE: Call Dell Support from a telephone near or at the computer so that the support staff can assist you with any necessary procedures.

NOTE: Dell’s Express Service Code system may not be available in all countries.

When prompted by Dell’s automated telephone system, enter your Express Service Code to route the call directly to the proper support personnel. If you do not have an Express Service Code, open the Dell

Accessories folder, double‑click the Express Service Code icon, and follow the directions.

NOTE: Some of the services are not

always available in all locations outside the continental U.S. Call your local Dell representative for information on availability.

Getting Help

Technical Support and Customer Service

Dell’s support service is available to answer your questions about Dell hardware. Our support staff use computer‑based diagnostics to provide fast, accurate answers.

To contact Dell’s support service, see “Before You Call” on page 85 and then see the contact information for your region or go to

support.dell.com.

DellConnect

DellConnect™ is a simple online access tool that allows a Dell service and support associate to access your computer through a broadband connection, diagnose your problem and repair it all under your supervision. For more information, go to

www.dell.com/DellConnect.

Getting Help

Online Services

You can learn about Dell products and services on the following websites:

www.dell.com•

www.dell.com/ap• (Asian/Pacific countries

only)

www.dell.com/jp• (Japan only)

www.euro.dell.com• (Europe only)

www.dell.com/la• (Latin American and

Caribbean countries)

www.dell.ca• (Canada only)

You can access Dell Support through the following websites and e‑mail addresses:

Dell Support Websites

support.dell.com•

support.jp.dell.com• (Japan only)

support.euro.dell.com• (Europe only)

supportapj.dell.com• (Asia Pacific only)

Dell Support E-mail Addresses

mobile_support@us.dell.com•

support@us.dell.com•

la-techsupport@dell.com• (Latin America

and Caribbean countries only)

apsupport@dell.com• (Asian/Pacific countries only)

Dell Marketing and Sales E-mail Addresses

apmarketing@dell.com• (Asian/Pacific

countries only)

sales_canada@dell.com• (Canada only)

Anonymous File Transfer Protocol (FTP)

ftp.dell.com•

Getting Help

Automated Order-Status Service

To check on the status of any Dell products that you have ordered, you can go to support.dell.com, or you can call the automated order‑status service. A recording prompts you for the information needed to locate and report on your order.

If you have a problem with your order, such as missing parts, wrong parts, or incorrect billing, contact Dell for customer assistance. Have your invoice or packing slip handy when you call.

For the telephone number to call for your region, see “Contacting Dell” on page 87.

Product Information

If you need information about additional products available from Dell, or if you would like to place an order, go to the Dell website at www.dell.com. For the telephone number to call for your region or to speak to a sales specialist, see “Contacting Dell” on page 87.

Getting Help

Returning Items for Repair Under Warranty or for Credit

Prepare all items being returned, whether for repair or credit, as follows:

NOTE: Before you return the product to Dell, ensure that you back up any data on the hard drive(s) and on any other storage device in the product. Remove any and all confidential, proprietary and personal information, as well as removable media, such as CDs and media cards. Dell is not responsible for any of your confidential, proprietary or personal information; lost or corrupted data; or damaged or lost removable media that may be included with your return.

Call Dell to obtain a Return Material 1. Authorization Number, and write it clearly and prominently on the outside of the box. For the telephone number to call for your region, see “Contacting Dell” on page 87.

Include a copy of the invoice and a letter 2. describing the reason for the return.

Include a copy of the Diagnostics Checklist 3. (see “Diagnostic Checklist” on page 86), indicating the tests that you have run and any error messages reported by Dell Diagnostics (see “Dell Diagnostics” on page 67).

Include any accessories that belong with 4. the item(s) being returned (AC adapter cable, software, guides, and so on) if the return is for credit.

Getting Help

Pack the equipment to be returned in the 5. original (or equivalent) packing materials.

NOTE: You are responsible for paying shipping expenses. You are also responsible for insuring any product returned, and you assume the risk of loss during shipment to Dell. Collect On Delivery (C.O.D.) packages are not accepted.

NOTE: Returns that are missing any of the preceding requirements will be refused at Dell’s receiving dock and returned to you.

Getting Help

Before You Call

NOTE: Have your Express Service Code ready when you call. The code helps Dell’s

automated‑support telephone system direct your call more efficiently. You may also be asked for your Service Tag.

Locating Your Service Tag

The Service Tag for your computer can be found on a label at the bottom of your computer.

1 Service Tag

Getting Help

Remember to fill out the following Diagnostic Checklist. If possible, turn on your computer before you call Dell for assistance and call from a telephone at or near the computer. You may be asked to type some commands at the keyboard, relay detailed information during operations, or try other troubleshooting steps possible only at the computer itself. Ensure that the computer documentation is available.

Diagnostic Checklist

Name:•

Date:•

Address:•

Phone number:•

Service Tag (bar code on the bottom of the • computer):

Express Service Code:•

Return Material Authorization Number (if • provided by Dell support technician):

Operating system and version:•

Devices:•

Expansion cards:•

Are you connected to a network? Yes /No•

Network, version, and network adapter:•

Programs and versions:•

Getting Help

See your operating system documentation to determine the contents of the computer’s start‑up files. If the computer is connected to a printer, print each file. Otherwise, record the contents of each file before calling Dell.

Error message, beep code, or diagnostic • code:

Description of problem and • troubleshooting procedures you performed:

Contacting Dell

For customers in the United States, call 800‑WWW‑DELL (800‑999‑3355).

NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill, or Dell product catalog.

Dell provides several online and telephone‑ based support and service options. Availability varies by country and product, and some services may not be available in your area.

To contact Dell for sales, technical support, or customer service issues:

Go to 1. www.dell.com/ContactDell.

Select your country or region.2.

Select the appropriate service or support 3. link based on your requirement.

Choose the method of contacting Dell that 4. is convenient for you.

Finding More Information and Resources

If you need to: See:

reinstall your operating system “System Recovery Media” on page 76

run a diagnostic program for your computer “Dell Diagnostics” on page 67

reinstall system software “My Dell Downloads” on page 65

for more information about the Microsoft® Windows® operating system and features

support.dell.com

upgrade your computer with new or additional components like a new hard drive

reinstall or replace a worn or defective part

the Service Manual at

support.dell.com/manuals

NOTE: In some countries, opening and

replacing parts of your computer may void your warranty. Check your warranty and return policies before working inside your computer.

If you need to: See:

find safety best practices information for your computer

review Warranty information, Terms and Conditions (U.S. only), Safety instructions, Regulatory information, Ergonomics information, and End User License Agreement

find your Service Tag/Express Service Code — You must use the service tag to identify your computer on support.dell.com or to contact technical support

find drivers and downloads; readme files

access technical support and product help

check on your order status for new purchases

find solutions and answers to common questions

locate information for last‑minute updates about technical changes to your computer or advanced technical‑reference material for technicians or experienced users

the safety and regulatory documents that shipped with your computer and also see the Regulatory Compliance Homepage at

www.dell.com/regulatory_compliance

the bottom of your computer

the Dell Support Center. To launch the Dell Support Center, click the icon in the notification area of your desktop.

support.dell.com

Finding More Information and Resources

Specifications

This section provides information that you may need when setting up, updating drivers for, and upgrading your computer.

NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, see the About Your System section in the Dell Support Center. To launch the Dell Support Center, click the icon in the notification area of your desktop.

Computer Model

Dell™ XPS™ L501X

Computer Information

System chipset Mobile Intel® 5 series

express chipset HM57

Processor type Intel Core™ i3

Intel Core i5 Intel Core i7 Intel Pentium

Memory

Memory module connector

Memory module capacities

Minimum memory

Maximum memory

two user‑accessible SODIMM connectors

1 GB, 2 GB, and 4 GB

2 GB

8 GB

Speciﬁcations

Memory

Memory type 1066 MHz/1333 MHz

SODIMM DDR3

NOTE: For instructions on upgrading the memory, see the Service Manual at

support.dell.com/manuals.

Connectors

Audio one microphone‑in

connector, one stereo headphones/speakers connector

NOTE: You can also use the connectors to set up 5.1 channel speakers

S/PDIF one headphone/digital

S/PDIF combo connector

Mini‑Card one full Mini‑Card slot

one half Mini‑Card slot

Connectors

HDMI connector

Network adapter

USB two 4‑pin USB

Mini‑ DisplayPort

eSATA one 7‑pin/4‑pin eSATA/

Media Card Reader

Antenna‑in connector (optional)

one 19‑pin connector

one RJ45 connector

3.0‑compliant connectors

one 20‑pin connector

USB combo connector with PowerShare

one 9‑in‑1 slot

one MCX connector

Speciﬁcations

Media Card Reader

Cards supported

Secure Digital (SD) memory card

Secure Digital Input Output (SDIO)

Secure Digital High Capacity (SDHC)

Secure Digital eXtended Capacity (SDXC)

Memory Stick

Memory Stick PRO

MSXC Memory Card

MultiMedia Card (MMC)

xD‑Picture Card

Camera

Camera resolution

Video resolution 1280 x 720

2.0 megapixel HD

Communications

Modem (optional)

Network adapter

Wireless WLAN, WWAN (optional),

TV TV tuner card (optional)

external V.92 56 K USB modem

10/100/1000 Ethernet LAN on system board

WiMAX/Wi‑Fi abgn/agn, and Bluetooth® wireless technology (optional)/ WiDi (optional)

Audio

Audio controller

Speakers 2 x 1.5 Watt + 2.5 Watt

Volume controls

Realtek ALC665

software program menus and media controls

Speciﬁcations

Video

Integrated

Video Controller

Video Memory

Discrete

Video Controller

Video Memory

Intel HD Graphics

up to 256 MB

NVIDIA GeForce GT 420M

NVIDIA GeForce GT 435M

1 GB/2 GB DDR3

Display

Type 15.6‑inch HD WLED,

TrueLife

15.6‑inch Full HD RGBLED, TrueLife

Multi‑touch 15.6‑inch HD WLED, TrueLife (Optional)

Display

Dimensions:

Height 193.54 mm (7.62 inches)

Width 344.23 mm (13.55 inches)

Diagonal 396.42 mm (15.6 inches)

Maximum resolution

Refresh rate 60 Hz

Operating angle

Horizontal viewing angle

Vertical viewing angle

Pixel pitch 0.2265 mm x 0.2265 mm

1920 x 1080

0° (closed) to 135°

40/40

15/30 (H/L)

Speciﬁcations

Battery

9‑cell “smart” lithium ion:

Height 221.07 mm (8.70 inches)

Width 54.35 mm (2.14 inches)

Depth 42.53 mm (1.67 inches)

Weight 0.49 kg (1.08 lb)

6‑cell “smart” lithium ion:

Height 209.19 mm (8.24 inches)

Width 54.35 mm (2.14 inches)

Depth 20.40 mm (0.80 inches)

Weight 0.33 kg (0.73 lb)

Voltage 13.3 V (6‑/9‑cell)

Charge time (approximate)

4 hours (when the computer is turned off)

Battery

Operating time battery operating time

varies depending on operating conditions

Coin‑cell battery

CR‑2032

AC Adapter

NOTE: Use only AC adapters specified

for use with your computer. See the safety information that shipped with your computer.

Input voltage 100‑240 VAC/11‑16 VDC

Input current (maximum)

Input frequency

Output power 90 W/130 W

1.50 A/2.30 A/2.50 A

50‑60 Hz

Speciﬁcations

AC Adapter

Output current:

90 W 4.62 A (continuous)

130 W 6.70 A (continuous)

Rated output voltage

Operating temperature

Storage temperature

19.5 VDC

0° to 40°C (32° to 104°F)

–40° to 70°C (–40° to 158°F)

Keyboard (Backlit)

Number of keys

Layout QWERTY/AZERTY/Kanji

86 (U.S. and Canada);

87 (Europe); 90 (Japan);

87 (Brazil)

Touch Pad

X/Y position resolution (graphics table mode)

Size:

Width 100 mm (3.94 inches)

Height 56 mm (2.2 inches)

240 cpi

Physical

Height 32.2 mm to 38.2 mm

(1.27 inches to

1.50 inches)

Width 381 mm (15 inches)

Depth 265.4 mm (10.45 inches)

Weight (with 6‑cell battery)

configurable to less than

2.8 kg (6.17 lb)

Speciﬁcations

Computer Environment

Temperature range:

Operating 0° to 35°C

(32° to 95°F)

Storage –40° to 65°C

(–40° to 149°F)

Relative humidity (maximum):

Operating 10% to 90%

(noncondensing)

Storage 5% to 95%

(noncondensing)

Maximum vibration (using a random vibration spectrum that simulates user environment):

Operating 0.66 GRMS

Non‑ Operating

1.30 GRMS

Computer Environment

Maximum shock (for operating — measured with Dell Diagnostics running on the hard drive and a 2‑ms half‑sine pulse; for non‑operating — measured with the hard drive in head‑parked position and a 2‑ms half‑sine pulse):

Operating 110 G

Non‑ Operating

Altitude (maximum):

Operating –15.2 to 3048 m

Storage –15.2 to 10,668 m

Airborne contaminant level

160 G

( –50 to 10,000 ft)

(–50 to 35,000 ft)

G2 or lower as defined by ISA‑S71.04‑1985

Appendix

Macrovision Product Notice

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Appendix

Information for NOM, or Official Mexican Standard (Only for Mexico)

The following information is provided in the device(s) described in this document in accordance with the requirements of the Official Mexican Standard (NOM):

Importer:

Dell México S.A. de C.V.

Paseo de la Reforma 2620 – Flat 11°

Col. Lomas Altas

11950 México, D.F.

Regulatory model number Voltage Frequency

P11F 100‑240 VAC

11‑16 VDC

For details, read the safety information that shipped with your computer.

For additional safety best practices information, see the Regulatory Compliance Homepage at

www.dell.com/regulatory_compliance.

50‑60 Hz 1.50 A/2.30 A/

Electricity consumption

2.50 A

Output voltage Output intensity

19.5 VDC

4.62 A/6.70 A

Dell P11F User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Setting Up Your XPS Laptop

Before Setting Up Your Computer

Connect the AC Adapter

Connect the Network Cable (Optional)

Press the Power Button

Set Up Microsoft Windows

Create System Recovery Media (Recommended)

Install the SIM Card (Optional)

Enable or Disable Wireless (Optional)

Set Up Wireless Display (Optional)

Set Up the TV Tuner (Optional)

Connect to the Internet (Optional)

Using Your XPS Laptop

Right View Features

Left View Features

Front View Features

Back View Features

Computer Base and Keyboard Features

Status Lights and Indicators

Disabling Battery Charging

Touch Pad Gestures

Multimedia Control Keys

Control Strip Features

Using the Optical Drive

Display Features

Touch Screen Gestures (Optional)

Removing and Replacing the Battery

Software Features

Dell DataSafe Online Backup

Dell Stage (Optional)

NVIDIA Optimus Technology

Free Fall Sensor

Dell Dock (Optional)

Solving Problems

Beep Codes

Touch Screen Problems

Network Problems

Power Problems

Memory Problems

Lockups and Software Problems

Using Support Tools

Dell Support Center

My Dell Downloads

System Messages

Hardware Troubleshooter

Dell Diagnostics

Restoring Your Operating System

System Restore

Dell DataSafe Local Backup

System Recovery Media

Dell Factory Image Restore

Getting Help

Technical Support and Customer Service

DellConnect

Online Services

Automated Order-Status Service

Product Information

Returning Items for Repair Under Warranty or for Credit

Before You Call

Contacting Dell

Finding More Information and Resources

Specifications

Appendix

Macrovision Product Notice

Information for NOM, or Official Mexican Standard (Only for Mexico)
