Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway
Getting Started Guide
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
This Getting Started Guide provides instructions for basic installation and configuration of the Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway.
Document Contents
1 Getting Started with the Dell PowerConnect J-Series J-SRX100S/SU Services Gateway .......3
2 Setting Up Your Network
3 Performing Advanced Network Configuration
4 Enabling Security Services
5 Powering Off the Device
6 Support and Training Options
2 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
.............................................................6
..........................................19
...........................................................25
.............................................................40
........................................................41
1 Getting Started with the Dell PowerConnect J-Series J-SRX100S/SU Services Gateway
The Dell PowerConnect J-Series J-SRX100S/SU Services Gateway offers features that provide complete functionality and flexibility
for delivering secure Internet and intranet access. The services gateway offers stable, reliable, and efficient IP routing in addition to
switching support and LAN connectivity. The device provides firewall, anti-virus, anti-spam, anti-spyware, Web filtering, IP Security
(IPsec), and virtual private network (VPN) services for small-sized and medium-sized companies. The services gateway can be
connected directly to traditional private networks such as leased lines, Frame Relay, or MPLS or to the public Internet. The services
gateway runs the Junos operating system (Junos OS).
This chapter provides the Dell PowerConnect J-Series J-SRX100S/SU Services Gateway front and back panel views and the package
content information.
Section 1 Contents
1.1 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Front Panel .................4
1.2 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Back Panel..................4
1.3 Checking the Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Package
Contents ..........................................................................5
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 3
1.1 Dell PowerConnect J-Series J-SRX100S/SU
Po
Services Gateway Front Panel
1.2 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Back Panel
Console Port
For connecon to
Junos Command-line
interface
USB Port
For use with Dell-supported
USB storage devices
wer Buon
On (I) and Off (o)
power
LED
ALARM - minor/major alarm
POWER - device is powered on
STATUS - device is funconing
HA - device is part of chassis
clustering
Reset Config Buon
Restore the device to the
factory default
configuraon
4 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
10/100 Ethernet
Provide 10/100 Ethernet
connecvity vlan0
192.168.1.1/24
10/100 Ethernet
fe-0/0/0
DHCP Client
Grounding Point
For grounding the
device to earth
Lock
For securing the device to
the installaon site
Power Supply Point
DC power connecon
for use with
the supplied power cable
Cable Tie Holder
For holding the
power cord on the
power supply
1.3 Checking the Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Package Contents
Before setting up your Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway, verify that your package
contains the following parts:
• Dell PowerConnect J-Series J-SRX100S/SU Services Gateway
• DB9 > RJ-45 cable
1.3.1 Any Items Missing?
If any items are missing from your package, contact Dell
customer support at
NOTE: If you have purchased a UTM subscription, the
license authorization codes certificate will be shipped
separately in an envelope. You will need this certificate
to set up security services for your gateway.
www.support.dell.com.
• Quick Start Guide
• Getting Started Guide
• Safety and Environmental Regulation Information (SERI)
• End-User License Agreement (EULA)
• Registration and Software Updates information
• Warranty and support Information (WSI)
• Open Source Code Notice
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 5
NOTE: The power supply adapter and the power cord are
shipped in a separate box.
2 Setting Up Your Network
This chapter provides preconfiguration and configuration instructions for connecting your Dell PowerConnect J-Series J-SRX100S/SU
Services Gateway. Review this chapter to set up your services gateway.
Section 2 Contents
2.1 Recording Configuration Information.................................................7
2.2 Connecting the Device..............................................................8
2.3 Verifying Internet Connectivity .....................................................10
2.4 Understanding the Default Configuration Settings..................................... 11
2.5 Verifying the System Requirements .................................................. 11
2.6 Accessing the J-Web Interface......................................................11
2.7 Configuring the Basic Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.8 Verifying the Configuration ........................................................17
6 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
2.1 Recording Configuration Information
This section provides the following information:
2.1.1 Registration Information
2.1.2 Login Information
2.1.3 Internet Service Provider Information
2.1.1 Registration Information
NOTE: If you have not purchased the UTM or IDP
licenses, do not proceed with the instructions provided
in this section.
Authorization Code Record the authorization code provided
by Dell.
NOTE: Use the authorization
code only if you have purchased
subscription licenses for UTM and
IDP.
2.1.2 Login Information
Use the following default username and password information
for the first time login. Record this information for your future
reference.
Username Select an administrator account name.
Default is root.
Use the following information when you are enabling Unified
Threat Management (UTM)/Intrusion Detection and Prevention
Password Password is not required. Leave this box
blank.
(IDP) licenses on the device.
Serial Number Record the serial number found on
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 7
the bottom of the chassis of your Dell
PowerConnect J-Series J-SRX100S/SU
Services Gateway.
2.1.3 Internet Service Provider Information
Use the following information to connect to the Internet when
your Internet Service Provider (ISP) provides the static settings
such as IP address, Domain Name Server (DNS), and so on.
IF YOU CONNECT USING PLEASE RECORD
IP Address:
Subnet Mask:
NOTE: Do not use this information if your ISP uses
Dynamic Host Configuration Protocol (DHCP).
IF YOU CONNECT USING PLEASE RECORD
No information is usually required,
DHCP
8 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
although some providers may require a
hostname.
Hostname:
Default Gateway:
Static IP
Primary DNS:
DNS 2 (optional):
DNS 3 (optional):
2.2 Connecting the Device
This section covers the following tasks:
2.2.1 Connecting the Power Cable to the Device
2.2.2 Connecting the Management Device
2.2.3 Connecting to Your Internet Service Provider
2.2.1 Connecting the Power Cable to the Device
Internet
Trust Zone
Untrust Zone
DHCP Client
Vlan0
Management
Devices
fe-0/0/0
fe-0/0/1 to fe-0/0/7
DHCP Server
To connect the power cable to the device:
1. Plug the DC connector end of the power cable in to the
power connector on the back of the device.
NOTE: You must allow the device between 5 and 7
minutes to boot fully after you have powered it on. Wait
until the STATUS LED is steadily green before proceeding
to “2.2.2 Connecting the Management Device.”
2. Plug the AC adapter end of the power cable in to an AC
power outlet. We recommend using a surge protector.
Note the following indications (see
“1.1 Dell PowerConnect
J-Series J-SRX100S/SU Services Gateway Front Panel”):
- POWER LED (green): The device is receiving power.
- STATUS LED (green): The device is operating normally.
- ALARM LED (amber): The device is operating normally, but a
2.2.2 Connecting the Management Device
Connect the management device to the services gateway using
an RJ-45 cable (Ethernet cable) from any one of the fe-0/0/1
through fe-0/0/7 ports on the front panel to the Ethernet port
on the management device.
Figure 1: Connecting the Management Device to the Services
Gateway
rescue configuration has not yet been set. This is not a panic
condition, however.
NOTE: Initially, if the rescue configuration has not been
set, a steadily amber ALARM LED indicates a minor alarm
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 9
condition, and a steadily red ALARM LED indicates that a
major alarm condition on the services gateway.
After you connect the management device to the services
gateway, the DHCP server process on the services gateway
automatically assigns an IP address to the management device.
Ensure that the management device acquires an IP address in
the range of 192.168.1.2 through 192.168.1.254 from the services
gateway.
NOTE: If you are using a static IP address to connect to
the provider’s network, do not perform “2.3 Verifying
Internet Connectivity.” To access the Internet from your
management device (workstation or laptop), you need
to first configure the static IP address on the fe-0/0/0
interface and configure a default route.
NOTE: For the services gateway to assign an IP address
to the management device, the management device
must be set up to connect using DHCP.
If an IP address is not assigned to the management
device, you can manually configure an IP address in
the range of 192.168.1.2/24 through 192.168.1.99/24.
Ensure you do not use 192.168.1.1, as this IP address is
configured on the services gateway.
2.2.3 Connecting to Your Internet Service Provider
Connect the fe-0/0/0 port on the Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway to your ISP or Internet (see
“Figure 1: Connecting the Management Device to the Services
Gateway”). The DHCP server that resides in your ISP network
provides the necessary settings (such as default route, DNS, and
so on) to the services gateway to connect to the Internet.
10 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
2.3 Verifying Internet Connectivity
With a default configuration of the Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway, you can access the Internet
when you connect the management device into any one of
the Ethernet ports (fe-0/0/1 through fe-0/0/7) and your ISP is
connected to the fe-0/0/0 port. For more information on default
configuration, see
Settings.”
Now you can browse the Internet from your management
device. For example, type
NOTE: If you are using DHCP to verify the network
settings from your service provider, verify your Internet
connectivity. If you are using a static IP address to
connect to the provider’s network, do not verify the
internet connectivity.
“2.4 Understanding the Default Configuration
www.dell.com in your browser.
2.4 Understanding the Default Configuration
Settings
The device has the following default configuration settings when
you power it on for the first time (for more information on trust
and untrust zones, see
Factory Default Settings
PORT
LABEL
0/0 fe-0/0/0 untrust client Unassigned
0/1 to 0/7 fe-0/0/1 to
SOURCE ZONE DESTINATION ZONE POLICY ACTION
For Security Policies
For NAT Rule
INTERFACE
fe-0/0/7
trust untrust permit
trust trust permit
untrust trust deny
trust untrust source NAT to untrust
“3.1 Zones and Interfaces Overview”):
SECU RIT Y
ZONE
trust server 192.168.1.1/24
DHCP
STAT E
IP ADDRESS
zone interface
2.5 Verifying the System Requirements
Before you begin the setup process, verify that you have one of
the following supported browsers:
ICON ACCEPTED BROWSER
Internet Explorer
Mozilla Firefox
BROWSER VERSION
NUMBER
7.0 and later
3.0 and later
2.6 Accessing the J-Web Interface
To access the J-Web interface:
1. Launch a Web browser on the management device or PC.
2. Enter http://192.168.1.1 in the URL address box. The J-Web
login page appears.
3. Specify the default username as root. Do not enter any value
in the Password box.
4. Click Log In. The first time you log in, the J-Web Initial Setup
page appears.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 11
NOTE: The J-Web interface will take between 1 and 2
minutes for displaying the initial setup page, only Host
Name and Root Password is mandatory. Other fields are
optional.
5. Enter the hostname and root password. You can also
configure DNS server, time zone, and so on, on this page.
6. Click Apply.
7. Click Commit Options on the top right corner and click
Commit.
8. If you have used a static IP address to configure an IP
address on your services gateway, ensure that you make the
following J-Web modifications:
a. Clear the Enable DHCP on fe-0/0/0.0 check box.
b. Enter the manual IP address provided by your ISP in the
fe-0/0/0.0 address box. The IP address must be entered
in the a.b.c.d/xx format, where xx is the subnet mask.
c. Enter the IP address of the gateway in the Default
Gateway box. Your ISP provides the IP address for the
gateway.
d. Enter server names in the DNS name servers box. Your
ISP provides the server names.
e. Click Apply. The J-Web login page appears again.
f. Enter the username and password and click Log In. After
successful login, the Dashboard page appears.
12 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
2.7 Configuring the Basic Settings
This section covers the following configuration tasks:
2.7.1 Setting the System Hostname, Domain Name Server, and
Root Authentication
2.7.2 Setting the Date and Time
2.7.3 Creating a User Account
2.7.4 Assigning a Static IP Address to the WAN-Facing Interface
9. Access the Internet from your management device.
For example, type
connectivity ensures that you can pass traffic through the
services gateway. For more information on verification, see
“2.8 Verifying the Configuration.”
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 13
www.dell.com in your browser. This
2.7.5 Creating a Default Route to the WAN Interface
2.7.6 Applying the Basic Configuration Settings
2.7.1 Setting the System Hostname, Domain Name
Server, and Root Authentication
If you have not configured the hostname and DNS settings in the
J-Web Initial Setup page, to set or change the hostname, DNS
settings, or the root authentication password:
1. Click the Configure tab at the top of the page and navigate
to System Properties > System Identity.
2. Click Edit and enter the hostname and root password.
3. Click Add and enter the DNS server IP address. For example,
208.67.222.222.
4. Click OK and then click OK again.
5. Click Commit to save the basic configuration.
2.7.2 Setting the Date and Time
You can synchronize the Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway clock using three options:
Manual, management device clock, or NTP Server.
To set the date and time:
1. Click the Configure tab at the top of the page and navigate
to System Properties > Date Time.
2. Click Edit at the top right corner of the page, and then select
your required time zone from the list.
14 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
3. Select the set time options in Set time.
4. Click OK.
2.7.3 Creating a User Account
To configure a user (other than an administrative account) and to
set different permissions while accessing the Dell PowerConnect
J-Series J-SRX100S/SU Services Gateway:
1. Click the Configure tab at the top of the page and choose
System Properties > User Management.
2. Click Edit at the top right corner of the page, and then click
Add.
3. Enter the username and password.
4. Select the required permission from the list in Login class.
5. Click OK.
2.7.4 Assigning a Static IP Address to the WAN-Facing
Interface
To assign a static IP address to the WAN-facing (internet)
interface:
1. Click the Configure tab at the top of the page and navigate
to Interfaces.
2. Expand fe-0/0/0 and select the logical interface.
3. Click Edit and select the zone as untrust from the list.
4. Click the IPv4 Address tab.
5. Select Enable address configuration and then select the
IPv4 Address check box
NOTE: The IPv4 Address check box must be selected
before the Add button is automatically enabled.
.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 15
6. Click Add and enter the IP address and subnet mask provided
by your ISP.
7. Click OK.
2.7.5 Creating a Default Route to the WAN Interface
NOTE: Creating a default route is required only if you
have used a static IP address.
To create a default route to the WAN interface:
1. Click the Configure tab at the top of the page and navigate
to Routing > Static Routing.
2. Click Add.
3. Enter the IP address as 0.0.0.0 and the Subnet mask as
0.0.0.0.
NOTE: While adding the next hop, the field is separated
by tabs instead of dots.
16 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
4. Click Add in Nexthop and enter the default gateway IP
address provided by your ISP.
5. Click OK.
2.7.6 Applying the Basic Configuration Settings
When you edit a configuration, you work in a copy of the current
configuration to create a candidate configuration. The changes
you make to the candidate configuration are visible through
the user interface immediately, but do not take effect on the
device until you commit the changes. When you commit the
configuration, the candidate file is checked for proper syntax,
activated, and marked as the current, operational software
configuration file.
To save the configuration, select Commit Options on the top
right corner of the page and click Commit.
NOTE: You can commit your configuration settings at the
end of each task or you can commit all the configuration
settings at one time.
2.8 Verifying the Configuration
To verify the basic configuration, access any external website (for
example,
the Internet.
If you are unable to connect to Internet from your management
PC, verify the following:
1. In the J-Web interface, click the Troubleshoot tab and then
2. Enter www.dell.com in Remote Host and click Start. If your
3. Ensure the Management PC has acquired IP address (in the
www.dell.com), to ensure that you are connected to
click Ping Host.
ping is successful go to Step 3, otherwise go to Step 4.
range 192.168.1.2 through 192.168.1.99) and DNS settings
from the services gateway. If the PC acquired the correct IP
address/DNS and you are still not able to access internet, go
to Step 5.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 17
4. To ensure that the services gateway has the default route
(0.0.0.0) when you are using DHCP:
a. Click the Monitor tab and navigate to Routing >
Route Information.
b. Select inet.0 from the Route Table list and then click
Generate Report.
c. Save the report on your local disk.
5. Contact Dell customer support at www.support.dell.com.
18 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
3 Performing Advanced Network Configuration
This chapter provides the security zone and policies configuration instructions for connecting your Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway.
Section 3 Contents
3.1 Zones and Interfaces Overview......................................................20
3.2 Creating a New Security Zone and Adding an Interface to the New Zone..................20
3.3 Configuring Security Policies .......................................................22
3.4 Enabling Remote Access to the Dell PowerConnect J-Series J-SRX100S/SU Services
Gateway
3.5 Enabling System Services ..........................................................23
3.6 Allowing Host Inbound Traffic ......................................................24
3.7 Applying the Security Policy Configuration ...........................................24
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 19
............................................................................23
3.1 Zones and Interfaces Overview
Zones split a network infrastructure into logical areas, each with
its own set of usage rules, security services, and policies. Most
networks include multiple definitions of zones, including those
for trusted, untrusted, public, encrypted, and wireless traffic. The
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway
comes preconfigured with basic zones, such as:
• Untrust zone—Zone through which you connect to the
Internet.
• Trust zone—Zone that contains all the trusted local network
resources.
The security features and settings that zones carry are enforced
by binding one or more physical interfaces (fe-0/0/1 through
fe-0/0/7) on services gateway to a zone.
3.2 Creating a New Security Zone and Adding an Interface to the New Zone
This example shows how to create a new zone, DMZ, and assign
interface fe-0/0/2 to it. This example also shows how to make
fe-0/0/2 an L3 interface and assign an IP address to it.
To create and assign an interface port to the DMZ zone:
1. Click the Configure tab at the top of the page, navigate to
Security > Zones/Screens, and then click Add.
2. Enter the Zone name as DMZ and select the zone type as
security.
3. In the Interfaces in this zone field, move fe-0/0/2 from the
Available list to the Selected list.
20 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
4. Click the Host inbound traffic – Zone tab.
6. To modify the fe-0/0/2 interface to be an L3 interface (by
default, it is Layer 2):
NOTE: This step is optional. However, you must select
the required services and protocols to enable any kind of
service or protocol (DHCP, OSPF, and so on).
5. Select the required services and protocols and move them to
Selected and click OK.
a. Click the Configure tab at the top of the page and
navigate to Interfaces.
b. Expand fe-0/0/2, select the logical interface (fe-0/0/2.0),
and then click Edit.
c. Clear the Ethernet switching check box and select the
IPv4 Address check box.
d. Select the IPv4 Address check box.
e. Click Add and enter the IP address.
f. Click OK.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 21
3.3 Configuring Security Policies
Security policies provide a set of rules for transit traffic to use
to identify which traffic can pass through the firewall and what
actions to take on the traffic as it passes through the firewall. To
assign an IP address:
For example, to define a security policy between the untrust and
the DMZ zones that will allow HTTP/SSH traffic between them:
2. In the Policy tab, enter the policy name and select the Policy
Action as permit from the list.
3. In the Policy tab, select untrust from the list for From Zone
and DMZ from the list for To Zone.
4. In the Source Address and Destination Address areas, move
any to Matched.
1. Click the Configure tab, choose Security > Policy > FW
Policies, and then click Add.
22 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
NOTE: For any specific source or destination address,
select Add new destination address.
5. In Applications, move junos-https and junos-ssh to Matched
and then click OK.
NOTE: To allow HTTP/SSH traffic from the DMZ to
the untrust zone, create a new policy and configure
a security policy from the DMZ to the untrust zone.
To perform this, follow the steps mentioned in “3.3
Configuring Security Policies;” however, you need
select DMZ from the list for From Zone and untrust from
the list for To Zone.
3.4 Enabling Remote Access to the Dell PowerConnect J-Series J-SRX100S/SU Services Gateway
To manage the Dell PowerConnect J-Series J-SRX100S/SU
Services Gateway from a remote location, for example through
fe-0/0/0 that is connected to your Internet Service Provider, you
must:
• enable system services like HTTP/Telnet/SSH.
• allow host-inbound-traffic at the zone or specific interface
level (in this case, zone is untrust and interface is fe-0/0/0).
3.5 Enabling System Services
To enable system services like HTTP, Telnet, and SSH:
1. Click the Configure tab at the top of the page, navigate to
System Properties >
Access Configuration page appears.
2. Click Edit.
3. Click the Services tab.
4. In Services, select the check box for the service that you
want to enable.
Management Access. The Management
NOTE: By default, Telnet and SSH are enabled.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 23
5. In Enable HTTP/HTTPS, to enable HTTP/HTTPs on all
available interfaces:
5. Select the required services and protocols and move them to
Selected.
a. Click the Enable on all interfaces check box or
b. To add HTTP/HTTPS only to certain interfaces move the
required interfaces to
NOTE: Before enabling HTTPS access, ensure that the
system date and time is set accurate.
6. Click OK.
selected interfaces.
3.6 Allowing Host Inbound Trac
To allow host-inbound service for a zone/interface:
1. Click the Configure tab at the top of the page, navigate to
Security > Zones/Screens.
2. Click the security zone that you want to modify (for example,
untrust).
3. In the Main tab, ensure fe-0/0/0 interface is in the Selected
column.
4. Click the Host inbound traffic – Zone tab.
6. Optionally, to allow host inbound traffic at interface level
(instead of allowing to the entire zone):
a. Click the Host inbound traffic – Interface tab.
b. Click on the fe-0/0/0 interface (for this example).
c. Follow step 4 and step 5.
7. Click OK.
3.7 Applying the Security Policy Configuration
Once the configuration is complete, you can save the changes.
To save the configuration, select Commit Options on the top
right corner of the page and click Commit.
24 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
4 Enabling Security Services
This chapter provides the Unified Threat Management (UTM) and Intrusion Detection and Prevention (IDP) policy configuration and
installation instructions for accessing your Dell PowerConnect J-Series J-SRX100S/SU Services Gateway.
NOTE: If you have not purchased the UTM or IDP licenses, do not proceed with the instructions provided in this chapter.
Section 4 Contents
4.1 Activating Licenses on the Device ...................................................26
4.2 Installing and Verifying a License....................................................26
4.3 Unified Threat Management ........................................................26
4.4 Intrusion Detection and Prevention .................................................35
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 25
4.1 Activating Licenses on the Device
Before you can configure any UTM features, the UTM feature
license must be installed on the device.
Follow the licensing activation instructions included with your
license authorization code.
4.2 Installing and Verifying a License
To automatically add subscription licenses to the Dell
PowerConnect J-Series J-SRX100S/SU Services Gateway after
registering, ensure that you are connected to the Internet and
that DNS is configured.
To install and verify the installed license:
1. Click the Maintain tab at the top of the page and navigate to
Licenses.
2. Click Download Keys to download the licenses
automatically.
3. In the Feature Summary, check that all the licenses are
installed.
26 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
4.3 Unified Threat Management
This section provides the Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway configuration instructions for
using a UTM policy to secure the network:
4.3.1 Enabling Anti-Virus
4.3.2 Enabling Web Filtering
4.3.3 Enabling Anti-Spam
4.3.4 Applying the UTM Configuration Settings
4.3.5 Verifying the UTM Configuration Settings
4.3.1 Enabling Anti-Virus
This section provides an example for configuring the full
file-based anti-virus scanning feature using the default
junos-av-defaults anti-virus profile. To enable anti-virus, you
must perform the following configuration steps:
4.3.1.1 Applying an Anti-Virus Profile to a UTM Policy
4.3.1.2 Applying the UTM Policy to a Firewall Policy
4.3.1.3 Creating an Anti-Virus Profile
4.3.1.1 Applying an Anti-Virus Profile to a UTM Policy
To apply an anti-virus profile to a UTM policy:
NOTE: You can either create a new UTM policy or use an
existing UTM policy (if any exits) to add Anti-Virus to it. If
you want to create a new anti-virus profile, see “4.3.1.3
Creating an Anti-Virus Profile.”
1. Click the Configure tab, choose Security > Policy > UTM
Policies, and then click Add.
2. Click the Main tab and enter the policy name as
custom-utm-policy.
3. Click the Anti-Virus profiles tab, select junos-av-defaults
from the list in HTTP Profile box, and then click OK.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 27
4.3.1.2 Applying the UTM Policy to a Firewall Policy
To inspect transit traffic and evaluate it against the anti-virus
profile, you must apply the UTM policy to a firewall policy.
4.3.1.3 Creating an Anti-Virus Profile
This task is optional and can be performed if you want to
configure a new anti-virus profile.
To apply the UTM policy to a firewall policy:
1. Click the Configure tab and choose Security > Policy > FW
Policies.
2. Click Edit to edit an existing policy.
3. Click the Application Services tab.
4. In UTM Policy, select custom-utm-policy from the list.
5. Click OK.
28 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
To create an anti-virus profile:
1. Click the Configure tab and choose Security > UTM >
Anti-Virus.
2. Click Add for a new anti-virus profile.
3. Do the following:
a. Enter a Profile name.
For example, custom-antivirus-profile.
b. Select Profile Type as Kaspersky.
c. Enter the Trickling timeout.
4. In the Scan options, do the following:
a. Select the Intelligent prescreening as yes.
b. Enter the Content size Limit.
c. Enter the Decompress layer limit.
5. In the Scan mode, select Scan all files.
6. Click OK.
4.3.2 Enabling Web Filtering
This section provides an example for configuring the Web
filtering feature using the default junos-wf-cps-default Web
filtering profile. To enable Web filtering, you must perform the
following configuration tasks:
4.3.2.1 Applying a Web Filtering Profile to a UTM Policy
4.3.2.2 Applying a UTM Policy to a Firewall Policy
4.3.2.3 Creating a Web Filtering Profile
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 29
4.3.2.1 Applying a Web Filtering Profile to a UTM Policy
To configure the predefined Web filtering profile to use the
configured UTM policy:
4.3.2.2 Applying a UTM Policy to a Firewall Policy
To inspect transit traffic and evaluate it against the Web filtering
profile, you must apply the UTM policy to a firewall policy.
1. Click the Configure tab and choose Security > Policy >
UTM Policies.
2. Click Add.
3. Click the Main tab and enter the policy name as
web-filtering-policy.
4. Click the Web filtering profiles tab.
5. In HTTP Profile, select junos-wf-cpa-default from the list.
6. Click OK.
NOTE: If you want to create a new Web filtering profile,
see “4.3.2.3 Creating a Web Filtering Profile.”
30 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
To apply a UTM policy to a firewall policy:
1. Click the Configure tab and choose Security > Policy >
FW Policies.
2. Click Edit to edit an existing policy.
3. Click the Application Services tab.
4. In UTM Policy, select web-filtering-policy from the list.
5. Click OK.
6. Click Commit Options on the top right corner of the page
and click Commit.
4.3.2.3 Creating a Web Filtering Profile
This task is optional and can be performed if you want to
configure a new Web filtering profile.
To create a Web filtering profile:
1. Click the Configure tab and choose Security > UTM >
Web Filtering.
2. Click Global Options at the top right corner of the page.
3. In Filtering type, select Surf Control Integrated.
4. In Surf Control Integrated Options, enter the value for Cache
time out and Cache size.
5. Click OK.
6. Click Add on the top right corner.
7. In the Main tab, do the following:
a. Enter the Profile name.
For example, custom-web-filtering-profile.
b. Select Permit in default action.
c. Enter the timeout value.
8. Click OK.
4.3.3 Enabling Anti-Spam
This section provides an example for configuring the anti-spam
feature using the default junos-as-defaults anti-spam profile. To
enable UTM anti-spam on the Dell PowerConnect J-SRX100S/SU
Services Gateway, you must perform the following tasks:
4.3.3.1 Applying an Anti-Spam Profile to a UTM Policy
4.3.3.2 Applying a UTM Policy to a Firewall Policy
4.3.3.3 Creating an Anti-Spam Profile
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 31
4.3.3.1 Applying an Anti-Spam Profile to a UTM Policy
To configure the predefined anti-spam profile to use a UTM
policy:
4.3.3.2 Applying a UTM Policy to a Firewall Policy
To inspect transit traffic and evaluate it against the anti-spam
profile, you must apply the UTM policy to a firewall policy.
1. Click the Configure tab and choose Security > Policy >
UTM Policies.
2. Click Edit.
3. Click the Anti-Spam profiles tab.
4. In SMTP profile, select junos-as-defaults from the list.
5. Click OK.
NOTE: If the configuration delivery status is fail, click
Details for more information. If you want to create a new
anti-spam profile, see “4.3.3.3 Creating an Anti-Spam
Profile.”
32 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
To apply a UTM policy to a firewall policy:
1. Click the Configure tab and choose Security > Policy >
FW Policies.
2. Click Edit to edit an existing policy.
3. Click the Application Services tab.
4. In UTM Policy, select the required UTM policy from the list.
5. Click OK.
4.3.3.3 Creating an Anti-Spam Profile
This task is optional and can be performed if you want to
configure a new anti-spam profile.
To create a new anti-spam profile:
1. Click the Configure tab and choose Security > UTM > Anti-
Spam.
2. Click Add.
NOTE: By default, the Default SBL server is yes and the
Default action is Block email.
4. Click OK. The download successful message appears.
5. Click OK.
NOTE: If the configuration delivery status is Fail, click
Details for more information.
4.3.4 Applying the UTM Configuration Settings
To save the UTM configuration settings, select Commit Options
at the top right corner of the page and click Commit.
4.3.5 Verifying the UTM Configuration Settings
To verify the UTM configuration settings, perform the following
tasks:
3. Enter the profile name.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 33
4.3.5.1 Verifying an Anti-Virus Configuration
4.3.5.2 Verifying a Web Filtering Configuration
4.3.5.3 Verifying an Anti-Spam Configuration
4.3.5.1 Verifying an Anti-Virus Configuration
To verify an anti-virus configuration:
1. Click the Monitor tab.
2. Choose Security > UTM > Anti-Virus.
4.3.5.2 Verifying a Web Filtering Configuration
To verify a Web filtering configuration:
1. Click the Monitor tab.
2. Choose Security > UTM > Web Filtering.
NOTE: Click the plus sign (+) to view the UTM anti-virus
statistics. If you want to clear the data, click
Clear Anti-Virus Statistics.
34 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
NOTE: If you want to clear the data, click Clear Web
Filtering Statistics.
4.3.5.3 Verifying an Anti-Spam Configuration
To verify an anti-spam configuration:
1. Click the Monitor tab.
2. Choose Security > UTM > Anti-Spam.
4.4 Intrusion Detection and Prevention
This section provides the Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway configuration instructions for
using a predefined IDP Series policy to secure the network:
4.4.1 Downloading and Installing the Latest Security Package
NOTE: If you want to clear the data, click
Clear Anti-Spam Statistics.
4.4.2 Downloading and Installing the IDP Security Policy
Templates
4.4.3 Loading the Policy Templates File
4.4.4 Configuring an Active IDP Policy
4.4.5 Enabling IDP Series Detection on the Existing Firewall
Security Policy
4.4.6 Applying the IDP Configuration Settings
4.4.7 Verifying the IDP Configuration Settings
4.4.1 Downloading and Installing the Latest Security
Package
To download and install the latest security package:
1. Click the Configure tab and choose Security > IDP >
Signature Update.
2. Click the Download tab and select Latest Version from the
list.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 35
6. Click Install.
3. Select Full Package and click OK. The downloading message
appears.
NOTE: It will take a few minutes to download. You can
verify the progress of download by clicking Check Status
> Download Status.
4. Click OK.
5. Click the Install tab in the Security IDP Signature
Configuration page.
36 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
NOTE: The request will be processed in asynchronous
mode. It will take a few minutes to install. You can verify
the progress of an installation by clicking Check Status >
Install Status.
7. Click OK. The installation successful message appears.
8. Click OK.
4.4.2 Downloading and Installing the IDP Security Policy
Templates
To download and install the IDP security policy templates:
1. Click the Configure tab and choose Security > Policy > IDP
Policies.
2. Click the Template tab and select Download Template.
3. Click OK.
4. Click the Template tab and select Install Template.
5. Click OK.
NOTE: You can verify the progress of a download or
installation by clicking Check Status > Download Status
or Check Status > Install Status.
4.4.3 Loading the Policy Templates File
To view all the pre-defined IDP templates available on the Dell
PowerConnect J-Series J-SRX100S/SU Services Gateway, you
must load the policy templates file.
To load the policy templates file:
1. Click the Configure tab and choose Security > Policy > IDP
Policies.
2. Click the Template tab and select Load Template.
NOTE: It will take a few minutes to load the Templates
file.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 37
3. Click OK.
NOTE: If the configuration delivery status is fail, click
Details for more information.
4.4.4 Configuring an Active IDP Policy
NOTE: Before you use one of the predefined Junos IDP
policies as an active policy, you must load the policy
templates. See “4.4.3 Loading the Policy Templates File.”
To configure an active IDP policy:
1. Click the Configure tab and choose Security > Policy > IDP
Policies.
2. Click the Recommended policy link, and then click Activate
at the top right corner of the page.
38 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
4.4.5 Enabling IDP Series Detection on the Existing
Firewall Security Policy
To enable IDP series detection on the existing firewall security
policy from the trust zone to the untrust zone:
1. Click the Configure tab and choose Security > Policy >
FW Policies.
2. Click Edit to edit a policy.
3. Click the Application Services tab and select Enable IDP.
4. Click OK.
4.4.6 Applying the IDP Configuration Settings
To save the IDP configuration settings, select Commit Options at
the top right corner of the page and click Commit.
4.4.7 Verifying the IDP Configuration Settings
To verify the IDP configuration settings:
1. Click the Monitor tab.
2. Choose Security > IDP > Status.
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 39
5 Powering Off the Device
To power off the services gateway, you can shut it down in one of the following ways:
• Graceful shutdown—Press and immediately release the Power button. The device begins gracefully shutting down the operating
system.
• Forced shutdown—Press the Power button and hold it for 10 seconds. The device immediately shuts down. Press the Power button
again to power on the device.
NOTE: You can reboot or halt the system in J-Web by selecting Maintain > Reboot.
40 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
6 Support and Training Options
This chapter provides a link to customer support and technical documentation information for the Dell PowerConnect J-Series
J-SRX100S/SU Services Gateway device.
Section 6 Contents
6.1 Customer Support.................................................................42
6.2 Technical Documentation ..........................................................42
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 41
6.1 Customer Support
If there are any technical issues while setting up Dell
PowerConnect J-Series J-SRX100S/SU Services Gateway, contact
Dell customer support
www.support.dell.com.
6.2 Technical Documentation
For Technical documentation, refer to
www.support.dell.com/manuals.
42 Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide
Dell PowerConnect J-Series J-SRX100S/SU Services Gateway Getting Started Guide 43
Information in this document is subject to change without notice. All rights reserved. Reproduction of these materials in any manner whatsoever without the written permission of Juniper Networks is strictly
forbidden. Trademarks used in this text: Dell™, the DELL™ logo, and PowerConnect™ are trademarks of Dell Inc. Juniper Networks® and G33® are registered trademarks of Juniper Networks, Inc. in the
United States and other countries. All other trademarks, service marks, registered trademarks, or registered service marks are the property of their respective owners. Juniper Networks assumes no responsibil-
ity for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice. Products made or sold by Juniper Networks or
components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650,
6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785. Copyright© 2010, Juniper Networks, Inc. All rights reserved. Printed in USA.
Printed o n recycled pap er
Part Nu mber 530-036 103, Revision 1 , August 2010
Loading...
