Dell E-Port Plus II Setting Up

CAUTION: Before you set up

and use your E-Port Plus II, see the
support documentation that shipped
with your computer or go to
dell.com/regulatory_compliance for
regulatory and safety information.

NOTE: Before you initially connect
your laptop to the E-Port Plus II, the
operating system must complete its
setup process. For further information
see the Dell™ E-Port Plus II User’s

Guide on support.dell.com/support/
systemsinfo/documentation.aspx.

Set ting Up Your Dell™ E-Port Plus II

1

Connect power

2

Slide switch left if battery extends from back of laptop

4

Center laptop with E-Port Plus II and push down to click into place

3

Adjust lock/unlock switch

XOOOOO

RMSD

XOXOOO

XOXOOO
