F13 Series
Service and Installation Manual
Please read this manual completely before attempting to install or operate this equipment!
Notify carrier of damage! Inspect all components immediately. See page 2.
Ice Cream Cabinets
F13WR MODELS F13BC MODELS
REMOTE SELF CONTAINED
Lid, large 3234188 Lid, small 3234187
Leg, 6" S/S, w/mount plate (4) 3234645 Pump, chocolate 3234113
Valve, expansion, 1/4 Low, 4Q4A 3516225 Jar, syrup, white "poly" 3234100
Pump, regular syrup 3234114
F13WC MODELS Cover, lift, lid & spoon 3234051
SELF-CONTAINED Jar, crushed fruit 3234099
Lid, large 3234188 Louver, 18"
Louver, 14" SMK00039 Leg, 6" S/S, w/mount plate (4) 3234645
Leg, 6" S/S, w/mount plate (4) 3234645 Condensing unit, 1/3 H.P., Low 404A 3526710
Condensing unit, 1/3 HP., Low
Valve, expansion, 1/4 Low, 404A 3516225 Valve, expansion, 1/4 Low, 404A 3516225
Cord & plug 2183348 Valve, EPR 3/8 ODF, inlet/outlet 3516265
Control, low pressure 2193927
F13BR MODELS Cord & plug 2183348
REMOTE
Lid, small 3234187
Pump, chocolate 3234113
Jar, syrup, white "poly" 3234100
Pump, regular syrup 3234114
Cover, lift, lid & spoon 3234051
Jar, crushed fruit 3234099
Leg, 6" S/S, w/mount plate (4) 3234645
Valve, expansion, 1/4 Low, 404A 3516225
3526710
Condensing unit, 1/2 H.P., Low 404A (72"
SMK0004
3526711
1/3 low — 1/3 HP. 24 oz. 404A
1/2 low — 1/2 HP. 40 oz. 404A
Advice and recommendations given by Delfield Service Technicians do not constitute or guarantee any special coverage.
• A maximum of 1-hour is allowed to diagnose a defective component.
• A maximum of 1-hour is allowed for retrieval of parts not in stock.
• A maximum travel distance of 100 miles round trip and 2-hours will be reimbursed.
• Overtime, installation/start-up, normal control adjustments, general maintenance, glass breakage, freight damage, and/or
correcting and end-user installation error will not be reimbursed under warranty unless pre-approved with a Service Work
Authorization from Delfield. You must submit the number with the service claim.
L
ABOR OF 1-HOUR IS ALLOWED TO REPLACE:
Thermostat
•
Infinite Switch
•
Door Jamb Switch
•
Solenoid Coil
•
Hi-limit/Thermal Protector Switch
•
Fan Delay/Defrost Termination Switch
•
Compressor Start Components and Overload Protector
•
Defrost Timer
•
Thermometer
•
Gear Box
•
Contactor/Relay
•
Transformer
•
Evaporator/Condenser Fan Motor and Blade
•
Circulating Fan Motor and Blade
•
Microprocessor Control
•
Water Level Sensor/Probe
•
Door Hinges, Locks, and Gaskets
•
Condensate Element
•
Springs/Lowerator
•
L
ABOR OF 2 HOURS TO REPLACE:
Drawer Tracks/Cartridges
•
Pressure Control
•
Solenoid Valve
•
Defrost Element
•
Heating Element
•
Locate/Repair Leak
•
LABOR OF 3 HOURS TO REPLACE:
EPR or CPR Valve
•
Expansion Valve
•
LABOR OF 4 HOURS TO REPLACE
• Compressor
This includes recovery of refrigerant and leak check.
$35.00 maximum reimbursement for refrigerant recovery (includes recovery machine, pump, torch, oil, flux, minor fittings,
solder, brazing rod, nitrogen, or similar fees.)
Condenser or Evaporator Coil
•
REFRIGERANTS
• R22 A maximum of $4.00/lb. or 250/oz. will be reimbursed.
• R134A A maximum of $5.00/lb. or 310/oz. will be reimbursed.
• R404A A maximum of $12.00/lb. or750/oz. will be reimbursed.
