BDA OVERVIEW:
The Bi-Directional Amplifier (BDA) assembly provides an exceptional repeater/booster performances to
extend the coverage area of radio communications in buildings and RF shielded environments.
Features such as high linearity power amplifiers are contributing for the overall improved system
linearity performances. The unit is based on a duplexed path configuration, having sharp out of band
attenuation for improved isolation between the receiving and transmitting paths.
BDA BLOCK DIAGRAM
RF
AMPLIFIER
TO
BASE
STATION
ANTENNA
(N-TYPE)
Duplexer
RF
AMPLIFIER
Downlink
Duplexer
TO
AREA
ANTENNA
(N-TYPE)
Uplink
DC
POWER
SUPPLY
INPUT AC
CONNECTOR
(STANDARD
3 WIRE)
Page 3 of 13 CBDA-800A-1W60-PG2 INST2.doc REV. 0 09.03
Dekolink WIRELESS Ltd.
16 Bazel St. Qiryat-Arieh Petah-Tikva, Israel, 49510
Tel- 972-3-9180-180 Fax-972-3- 190-9180
e-mail: marketing@dekolink.com
web www.dekolink.com
BLOCK DIAGRAM DESCRIPTION:
The amplifiers in this BDA have an AGC option switch. When switched on, the AGC circuit limits the
amplifier output power. The AGC circuit senses the output power and introduces more attenuation,
when the output power exceeds the preset level of +27dBm*. This way the gain of the amplifier is
reduced, its output power is limited and the intermodulations products are kept below the desired level.
In this manner the output power cannot exceed the +27 dBm* preset power and the IMD levels are
always kept below –13 dBm.
The AGC amplifier has a Power LED lamp that illuminates when the output power has reached the
preset power limit.
*note
: AGC preset level can be factory modified to +24dBm upon customer request.
In addition the BDA has a trimmer that enables the reduction of the gain by 15 dB.
TO
BASE
STATION
ANTENNA
(N-TYPE)
MGC
Duplexer
BDA with AGC & MGC
RF BLOCK DIAGRAM
AGC RF AMPLIFIER
DETECTER
AGC CIRCUIT
DETECTER
AGC CIRCUIT
COUPLER
AGC RF AMPLIFIER
COUPLER
Downlink
Duplexer
MGC
Uplink
TO
AREA
ANTENNA
(N-TYPE)
Page 4 of 13 CBDA-800A-1W60-PG2 INST2.doc REV. 0 09.03
