Defy MAC 7030 W User Manual

MAC 7030 W
AUTO
AIR COOLER
Small Appliance
Instruction manual
Please read this user manual rst!
Thank you for preferring a Defy product. We hope that you get the best results
from your product which has been manufactured with high quality and state-of­the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use. If you handover the product to someone else, give the user manual as well. Follow all warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
Important information or useful
C
A
hints about usage.
Warning for hazardous situations with regard to life and property.
Warning to actions that must never perform.
B
Complies with the WEEE Regulation.
Warning for electric shock.
Warning for danger of fire.
Warning for hot surfaces.
This product has been produced in environmentally friendly, modern facilities
CONTENTS
1 Safety nstructons 4
2 Installaton nstructons 5
2.1 Name of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3 Instructons for use 6
3.1 Instructions for key of remote controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.2 Instructions for operation of body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4 Other 8
4.1 Maintenance instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.2 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.3 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Air cooler / User Manual
3 / 12 EN
1 Safety nstructons
Warnng
Read rules for safe operation and instructions carefully.
If the supply cord is damaged, it must be replaced by manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
Household Indoor use only.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.Young children should be supervised to ensure that they do not play with the appliance.
Unplug the appliance during filling and cleaning.
Prior to cleaning or other maintenance, the appliance must be disconnected from the supply mains.
Correct disposal of this product
This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.
4 / 12 EN
Air cooler / User Manual
2 Installaton nstructons
2.1 Name of components
1 2
45
1. Honeycomb filter frame
2. Pre-filter
3. Ice box
4. Water tank
5. Wheel
3
Air cooler / User Manual
Foot-wheel installation
Front foot-wheel
Rear foot-wheel
5 / 12 EN
3 Instructons for use
3.1 Instructons for key of remote controller
AUTO
C
6 / 12 EN
Battery installation
Pull notch
Locking latch
Considerate hint:
1. Install the battery with positive side facing up.
2. Effective range of remote control: within 5m distance and 30-degree deflection in front of product.
Air cooler / User Manual
3 Instructons for use
3.2 Instructons for operaton of body
Press a key on the unit to activate a corresponding function.
For instance:
•
Press [OSC] key to activate or deactivate swing function.
•
Press [Speed] key to adjust 3 speeds of air flow.
•
Press [Style] key to switch between normal, natural and sleep functions.
•
Press [Timer] key to set 1-12 hour timer setting.
•
Press [Ion] key to activate or deactivate negative Ion function.
•
When [Eva./Cooler] key is pressed, the indicator lights up constantly if the operation is normal; when the indicator flashes, it denotes a water shortage, please add water immediately.
Considerate hint:
C
C
Air cooler / User Manual
Push buttons on the unit may differ based on the actual product model.
Considerate hint:
When humidifying, water level in the water tank must remain under max indication; replenish water if level gets lower than min indication.
Power
Using the ice box
Water + ice
Water level
7 / 12 EN
4 Other
4.1
1.
2. Do
3.
4.
5.
4.2
1.
2.
4.3
Power supply: 220V-240V, 50Hz
Fan sound power level L
ISO 5801: 1997
8 / 12 EN
Symbol Value
F 7.5 m
3
P 100 W
SV 0.08 (m
P
SB
WA
0.5 W
65 dB(A)
3
C 27.00 meters/sec
Record in the space below the listed information for future reference.
SERIAL NUMBER……………………………..
DATE OF PURCHASE………………………..
PURCHASED FROM…………………………..
Branches
If you have followed the instructions and still have a problem, contact the customer care line on 086 100 3339. They will be able to advise you on any aspect of the appliance.
5
Sub-Saharan Africa Branches:
ZAMBIA: SOUTHGATE INVESTMENTS LTD
Plot 1606, Sheki Sheki Road P.O. Box 33681 Lusaka, 10101, Zambia Tel: +260 0211 242332/3 Fax: +260 0211 242933 sgiservicecentre@microlink.zm
NAMIBIA: ATLANTIC DISTRIBUTORS (PTY) LTD
10 Tienie Louw Street, Northern Industrial Area P.O. Box 21158, Windhoek, Namibia Tel: (061) 216162 Fax: (061) 216134 atlantic@mweb.com.na
ZIMBABWE: TRADECOMAFRICA
Trade Com Africa, 183 Loreley Crescent Msasa, Harare, Zimbabwe Tel: +263 4 486165/6 Cell: +263 772 469010 Cell: +263 772 469011
BOTSWANA: RAY MORGAN AGENCIES
RMA Service Centre, Plot 48, East Gate Gaborone International Commerce Park Kgale View, Gaborone Botswana Tel: +267 390 3996 / 390 3912 Fax: +267 318 7376 Cell: +267 7134 6539 service@rma.co.bw; raja@rma.co.bw
SWAZILAND: LYNDS DISTRIBUTORS
P.O Box 716, Mbabane, Swaziland, H100 Tel: (00268) 2515 4310/8 Fax: (00268) 2518 4318
MOZAMBIQUE: COOL WORLD. LDA
Rua da Resistencia No. 97B R/C Cell: +258 84 44 61 234 coolworldlda@hotmail.com Nosso Show Room Av: da Industrias, Parcela No.735 * 735A Machava, Maputo
South African Branches:
BLOEMFONTEIN
Unit Number 5 Monument Business Park 50 Monument Road Oranjesig, Bloemfontein Bloemfontein.Service@defy.co.za
CAPE TOWN
5A Marconi Rd. Montague Gardens, 7441 CapeTown.Service@defy.co.za
DURBAN
135 Teakwood Road, Jacobs, Durban, 4052 Durban.Service@defy.co.za
EAST LONDON
Robbie de Lange Road, Wilsonia, East London, 5201 EastLondon.Service@defy.co.za
GAUTENG, MIDRAND
127 15th Road, Cnr Pharmaceutical &15th Rd, Midrand, Gauteng Gauteng.Service@defy.co.za
POLOKWANE
87 Nelson Mandela Drive, Superbia 0699 Polokwane.Service@defy.co.za
PORT ELIZABETH
112 Patterson Road, North End, Port Elizabeth 6001 PortElizabeth.Service@defy.co.za
Warranty
6
This certificate is issued by DEFY APPLIANCES (PTY) LIMITED manufacturers of Defy and Ocean products, hereinafter the Company, to the original purchaser only, of the appliance described on the certificate and shall constitute the only warranty given in respect of this appliance.
The Company warrants to the original purchaser that for a period of TWO YEARS from date of purchase the appliance is free from defect under normal domestic use, both in workmanship and material, subject to the following conditions.
1. Carry-in service. Small appliances are repaired in our service centres and are not collected from the customers home. Faulty units must be delivered to the purchasing dealer or to the nearest Company Service Centre for warranty repairs.
2. Vitreous enamelware, fuses and lamps are specifically excluded from these warranties. It is an express condition of these warranties that the purchaser takes due care and attention in the use and maintenance of the appliance. Abuse, misuse in conflict with operating instructions, connection to incorrect voltages and subjection to commercial use shall release the Company from its obligations.
3. This warranty shall become void and cease to operate if the appliance is dismantled by, or any repairs to the appliance are effected by any persons not duly authorised by the Company, or if substitute parts not approved by the Company are used in the appliance, or if the serial number of the appliance is removed.
4. The Company shall not be responsible for damages resulting from fire, flood, civil disturbances or any Act of God. The Company shall not, in terms of these warranties be responsible nor held liable for any consequential loss or damage of any kind caused by or due to the failure or malfunction of the appliance. The Company shall not be responsible for damages caused by insect and/or animal infestation.
5. The Company shall not be responsible for transportation or other costs other than those incurred within the provisions of Point 1 of this Certificate.
6. For warranties in the Republic of South Africa and Sub-Saharan Africa, please contact your nearest Defy office. Please refer to the previous page for respective South African branches and Sub-Saharan Africa branches.
7. Where service is requested under warranty and no fault or defect can be found by the
Company, all costs incurred will be for the purchaser's account.
8. This Certificate as well as your invoice will serve as proof of purchase. For the purpose of warranty, it will be essential to produce this Certificate and invoice. Failure to do so, will render the purchaser liable for service costs.
KEEP THIS CERTIFICATE AND SALES INVOICE AS PROOF OF
PURCHASE FOR WARRANTY PURPOSES.
