USER MANUAL
Item Number: 82-18295
Thank you for purchasing our products. Please read the manual
carefully before operating.
Safety Precaution
Warning
* Please make sure the power adapter is consistent with product specifications,
otherwise it might cause fire, electric shock or damage.
* Pay attention to polarity of the power adapter connection to prevent possible
causes of fire.
* Please avoid connecting multiple cameras to the same adapter to prevent
overloading/over-heating the power adapter, which could cause a fire.
* Power supply must be firmly fixed so as not to cause fires.
* Please do not dismantle the camera as this will void the warranty. If the camera
is not operating properly, please contact your local distributor or dealer for
service.
* Please do not splash water on the product components when cleaning.
Technical Specifications
Item Number: 82-18295
Signal System: NTSC
Sensor: Color CMOS
Horizontal resolution : 1000 TV lines
Lens: 2.8-12mm
Minimum Illumination: 0 LUX (IR ON)
IR CUT: YES
S/N Ratio: More than 48 dB
Distance: 30-35Metres
LED : 36PCS
OSD Menu: YES
Video Output: 1Vp-p 75Ω . Y/C Separated
Connector video : BNC
Operation Temperature: -20°C to +50°C
Supplied Power: 12VDC (+/-10%);
IP Rating: IP65
Installation
1. Connect the DC power barrel plug from the power supply to the DC power jack
from the camera’s power output cable lead.
2. Connect the BNC connector from the DVR video channel to the camera’s video
cable lead, or directly to a DVR / Observation System, or to a TV/Monitor.
3. Mount the camera bracket to a ceiling or wall using the included fasteners.
4. Position the camera in the correct direction to capture the image and field of
view (a field focus test monitor is recommended) and secure the camera in place.
Troubleshooting
1. If there is no picture or the picture is unstable
Check the connection of video line or power line
2. If the image is blurred
a) Check the lens for dirt or debri (clean with isopropyl alcohol and lens cloth)
b) Check the focus length and OSD settings
3. If the image is dim
Adjust the CNT of monitor and iris
4. If there is not a motion detection frame or privacy masking area/frame
Check the OSD to ensure the option is ON or OFF. Also, check the menu
parameters
5. If there is a color cast when using the camera in the special environment
Adjust WEB mode or direction
6. If there is excessive glare on the screen
The camera might be facing into the sun, or capturing too much sunlight
7. If the OSD functions are disorganized, or fail to initiate.
Restore default settings
WARNING: If you see any smoke from the camera, cut off the power supply
immediately.
Accessory List
No.
Name
Quantity
Remark
1
CCTV Camera
1
2
User Manual
1
3 Screw
1
