DSE8800 Operator Manual ISSUE 1

DEEP SEA ELECTRONICS PLC

DSE8810 Colour Autostart Load Share Controller

Operator Manual

Document Number 057-163

Author: Anthony Manton

DSE8800 Operator Manual

DEEP SEA ELECTRONICS PLC

Highfield House Hunmanby North Yorkshire YO14 0PH ENGLAND

Sales Tel: +44 (0) 1723 890099 Sales Fax: +44 (0) 1723 893303

E-mail : sales@deepseaplc.com Website : www.deepseaplc.com

DSE8810 Colour Autostart Load Share Controller Operator Manual

© Deep Sea Electronics Plc All rights reserved. No part of this publication may be reproduced in any material form (including photocopying or storing in any medium by electronic means or other) without the written permission of the copyright holder except in accordance with the provisions of the Copyright, Designs and Patents Act 1988. Applications for the copyright holder’s written permission to reproduce any part of this publication should be addressed to Deep Sea Electronics Plc at the address above.

The DSE logo is a UK registered trademarks of Deep Sea Electronics PLC. Any reference to trademarked product names used within this publication is owned by their respective

companies. Deep Sea Electronics Plc reserves the right to change the contents of this document without prior

notice.

Amendments List

Issue Comments Minimum

Module version

required

Minimum

Configuration Suite

Version required

1 Initial release

Typeface: The typeface used in this document is Arial. Care should be taken not to mistake the upper case letter I with the numeral 1. The numeral 1 has a top serif to avoid this confusion.

Clarification of notation used within this publication.

NOTE:

Highlights an essential element of a procedure to ensure correctness.

CAUTION!

Indicates a procedure or practice, which, if not strictly observed, could result in damage or destruction of equipment.

WARNING!

Indicates a procedure or practice, which could result in injury to personnel or loss of life if not followed correctly.

DSE8800 Operator Manual

TABLE OF CONTENTS

Section Page

1 BIBLIOGRAPHY .............................................................................................. 7

1.1 INSTALLATION INSTRUCTIONS .................................................................................. 7

1.2 TRAINING GUIDES ........................................................................................................ 7

1.3 MANUALS ...................................................................................................................... 8

1.4 THIRD PARTY DOCUMENTS ........................................................................................ 8

2 INTRODUCTION .............................................................................................. 9

3 SPECIFICATIONS .......................................................................................... 10

3.1 PART NUMBERING ......................................................................................................10

3.1.1 SHORT NAMES .....................................................................................................10

3.2 TERMINAL SPECIFICATION ........................................................................................11

3.3 POWER SUPPLY REQUIREMENTS .............................................................................11

3.3.1 PLANT SUPPLY INSTRUMENTATION DISPLAY ...................................................11

3.4 GENERATOR VOLTAGE / FREQUENCY SENSING ....................................................12

3.5 GENERATOR CURRENT SENSING .............................................................................13

3.5.1 VA RATING OF THE CTS ......................................................................................13

3.5.2 CT POLARITY ........................................................................................................14

3.5.3 CT PHASING ..........................................................................................................14

3.5.4 CT CLASS ..............................................................................................................14

3.6 INPUTS .........................................................................................................................15

3.6.1 DIGITAL INPUTS ....................................................................................................15

3.6.2 ANALOGUE RESISTIVE INPUTS...........................................................................15

3.6.2.1 OIL PRESSURE ..............................................................................................15

3.6.2.2 COOLANT TEMPERATURE ............................................................................15

3.6.3 FUEL LEVEL (FLEXIBLE) INPUTS .........................................................................16

3.6.3.1 FUEL LEVEL INPUT AS DIGITAL ....................................................................16

3.6.3.2 FUEL LEVEL INPUT AS RESISTIVE ...............................................................16

3.6.3.3 FUEL LEVEL INPUT AS 0-10V ........................................................................16

3.6.3.4 FUEL LEVEL INPUT AS 4-20MA .....................................................................16

3.6.4 ANALOGUE FLEXIBLE INPUT ...............................................................................17

3.6.4.1 FLEXIBLE SENSOR AS DIGITAL ....................................................................17

3.6.4.2 FLEXIBLE SENSOR AS RESISTIVE ...............................................................17

3.6.4.3 FLEXIBLE SENSOR AS 0-10V ........................................................................17

3.6.4.4 FLEXIBLE SENSOR AS 4-20MA .....................................................................17

3.6.5 CHARGE FAIL INPUT ............................................................................................18

3.6.6 MAGNETIC PICKUP ...............................................................................................18

3.7 OUTPUTS .....................................................................................................................19

3.7.1 OUTPUTS A & B ....................................................................................................19

3.7.2 CONFIGURABLE OUTPUTS C & D (LOAD SWITCHING) .....................................19

3.7.3 OUTPUTS E,F,G,H, I, J ..........................................................................................19

3.8 COMMUNICATION PORTS ..........................................................................................20

3.9 COMMUNICATION PORT USAGE ..............................................................................20

3.9.1 CAN INTERFACE ..................................................................................................20

3.9.2 USB CONNECTION ...............................................................................................21

3.9.3 USB HOST-MASTER (USB DRIVE CONNECTION) ...............................................21

3.9.4 RS232.....................................................................................................................22

3.9.4.1 RECOMMENDED PC RS232 SERIAL PORT ADD-ONS .................................22

3.9.4.2 RECOMMENDED EXTERNAL MODEMS: .......................................................23

3.9.5 RS485.....................................................................................................................24

3.9.5.1 RECOMMENDED PC RS485 SERIAL PORT ADD-ONS .................................24

3.9.6 ETHERNET ............................................................................................................25

3.9.6.1 DIRECT PC CONNECTION .............................................................................25

3.9.6.2 CONNECTION TO BASIC ETHERNET ...........................................................26

3.9.6.3 CONNECTION TO COMPANY INFRASTRUCTURE ETHERNET ...................27

DSE8800 Operator Manual

3.9.6.4 CONNECTION TO THE INTERNET ................................................................28

3.9.6.5 FIREWALL CONFIGURATION FOR INTERNET ACCESS ..............................30

3.10 DSENET® FOR EXPANSION MODULES ................................................................31

3.10.1 DSENET® USED FOR MODBUS ENGINE CONNECTION ....................................31

3.11 SOUNDER .................................................................................................................32

3.11.1 ADDING AN EXTERNAL SOUNDER TO THE APPLICATION ................................32

3.12 ACCUMULATED INSTRUMENTATION .....................................................................32

3.13 DIMENSIONS AND MOUNTING ................................................................................33

3.13.1 DIMENSIONS .........................................................................................................33

3.13.2 PANEL CUTOUT ....................................................................................................33

3.13.3 WEIGHT .................................................................................................................33

3.13.4 FIXING CLIPS ........................................................................................................33

3.13.5 CABLE TIE FIXING POINTS ..................................................................................34

3.13.6 SILICON SEALING GASKET ..................................................................................34

3.14 APPLICABLE STANDARDS ......................................................................................35

3.14.1 ENCLOSURE CLASSIFICATIONS .........................................................................38

3.14.2 NEMA CLASSIFICATIONS .....................................................................................39

4 INSTALLATION ............................................................................................. 40

4.1 TERMINAL DESCRIPTION ...........................................................................................40

4.1.1 DC SUPPLY, FUEL AND START OUTPUTS, OUTPUTS E-J .................................41

4.1.2 ANALOGUE SENSOR ............................................................................................42

4.1.3 MAGNETIC PICKUP, CAN AND EXPANSION ........................................................43

4.1.4 LOAD SWITCHING AND V1 GENERATOR VOLTAGE SENSING .........................44

4.1.5 V2 BUS/MAINS VOLTAGE SENSING ....................................................................44

4.1.6 GENERATOR CURRENT TRANSFORMERS .........................................................45

4.1.7 CONFIGURABLE DIGITAL INPUTS .......................................................................47

4.1.8 PC CONFIGURATION INTERFACE CONNECTOR................................................47

4.1.9 RS485 CONNECTOR .............................................................................................48

4.1.10 RS232 CONNECTOR .............................................................................................48

4.2 TYPICAL WIRING DIAGRAMS .....................................................................................49

4.2.1 DSE8810 3 PHASE, 4 WIRE WITH RESTRICTED EARTH FAULT PROTECTION 50

4.3 ALTERNATIVE TOPOLOGIES .....................................................................................51

4.3.1 3 PHASE 4 WIRE WITH UNRESTRICTED EARTH FAULT MEASURING..............51

4.4 EARTH SYSTEMS ........................................................................................................52

4.4.1 NEGATIVE EARTH.................................................................................................52

4.4.2 POSITIVE EARTH ..................................................................................................52

4.4.3 FLOATING EARTH .................................................................................................52

4.5 TYPICAL ARRANGEMENT OF DSENET® ...................................................................52

5 DESCRIPTION OF CONTROLS .................................................................... 54

5.1 DSE8810 AUTO START CONTROL MODULE .............................................................54

5.2 QUICKSTART GUIDE ...................................................................................................55

5.2.1 STARTING THE ENGINE .......................................................................................55

5.2.2 STOPPING THE ENGINE.......................................................................................55

5.3 VIEWING THE INSTRUMENT PAGES..........................................................................56

5.3.1 DISPLAY OVERVIEW ............................................................................................56

5.3.2 PAGE INDICATORS ...............................................................................................56

5.3.3 SIDE SCROLL BAR ................................................................................................57

5.3.4 SUMMARY AREA ...................................................................................................57

5.3.5 HOME .....................................................................................................................58

5.3.6 ENGINE ..................................................................................................................59

5.3.7 GENERATOR .........................................................................................................60

5.3.8 BUS ........................................................................................................................61

5.3.9 ALARMS .................................................................................................................62

5.3.10 SCHEDULE ............................................................................................................63

5.3.11 STATUS .................................................................................................................64

6 OPERATION .................................................................................................. 69

6.1 CONTROL .....................................................................................................................69

DSE8800 Operator Manual

6.2 CONTROL PUSH-BUTTONS ........................................................................................70

6.3 ALTERNATIVE CONFIGURATIONS .............................................................................71

6.4 DUMMY LOAD / LOAD SHEDDING CONTROL ...........................................................72

6.5 STOP MODE .................................................................................................................73

6.5.1 ECU OVERRIDE.....................................................................................................73

6.6 AUTOMATIC MODE......................................................................................................74

6.6.1 WAITING IN AUTO MODE .....................................................................................74

6.6.2 STARTING SEQUENCE .........................................................................................74

6.6.3 ENGINE RUNNING ................................................................................................75

6.6.4 STOPPING SEQUENCE ........................................................................................75

6.7 MANUAL MODE ............................................................................................................76

6.7.1 WAITING IN MANUAL MODE ................................................................................76

6.7.2 STARTING SEQUENCE .........................................................................................76

6.7.3 ENGINE RUNNING ................................................................................................77

6.7.4 STOPPING SEQUENCE ........................................................................................77

7 PROTECTIONS .............................................................................................. 78

7.1 PROTECTIONS DISABLED ..........................................................................................78

7.1.1 INDICATION / WARNING ALARMS .......................................................................79

7.1.2 SHUTDOWN / ELECTRICAL TRIP ALARMS..........................................................79

7.1.3 CAN ALARMS ........................................................................................................80

7.2 INDICATIONS ...............................................................................................................81

7.3 WARNINGS ...................................................................................................................82

7.4 HIGH CURRENT WARNING ALARM ............................................................................83

7.5 SHUTDOWNS ...............................................................................................................84

7.6 ELECTRICAL TRIPS ....................................................................................................86

7.7 HIGH CURRENT SHUTDOWN / ELECTRICAL TRIP ALARM ......................................87

7.7.1 IMMEDIATE WARNING..........................................................................................87

7.7.2 IDMT ALARM..........................................................................................................87

7.8 EARTH FAULT SHUTDOWN / ELECTRICAL TRIP ALARM ........................................90

7.9 SHORT CIRCUIT ALARM .............................................................................................91

7.10 MAINTENANCE ALARM............................................................................................92

8 SCHEDULER ................................................................................................. 93

8.1.1 STOP MODE ..........................................................................................................93

8.1.2 MANUAL MODE .....................................................................................................93

8.1.3 AUTO MODE ..........................................................................................................93

9 FRONT PANEL CONFIGURATION ............................................................... 94

9.1 ACCESSING THE MAIN FRONT PANEL CONFIGURATION EDITOR .........................95

9.1.1 EDITING A PARAMETER .......................................................................................96

9.1.2 ADJUSTABLE PARAMETERS................................................................................97

9.2 ACCESSING THE ‘MAINTENANCE’ CONFIGURATION EDITOR ................................97

9.2.1 ADJUSTABLE PARAMETERS (MAINTENANCE CONFIGURATION EDITOR) ......98

9.3 ACCESSING THE ‘RUNNING’ CONFIGURATION EDITOR .........................................99

9.3.1 ADJUSTABLE PARAMETERS (RUNNING CONFIGURATION EDITOR) ...............99

10 COMMISSIONING ..................................................................................... 100

10.1 PRE-COMMISSIONING ........................................................................................... 100

11 FAULT FINDING ....................................................................................... 101

11.1 STARTING ............................................................................................................... 101

11.2 LOADING................................................................................................................. 101

11.3 ALARMS .................................................................................................................. 102

11.4 COMMUNICATIONS ................................................................................................ 103

11.5 INSTRUMENTS ....................................................................................................... 104

11.6 MISCELLANEOUS .................................................................................................. 104

12 DSE 4 STEPS TO SUCCESSFUL SYNCHRONISING ............................. 105

12.1 CONTROL ............................................................................................................... 105

DSE8800 Operator Manual

12.2 METERING .............................................................................................................. 105

12.3 COMMUNICATIONS ................................................................................................ 105

12.4 SYNC CHECKS ....................................................................................................... 105

13 MAINTENANCE, SPARES, REPAIR AND SERVICING............................ 106

13.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE ........................... 106

13.1.1 PACK OF PLUGS ................................................................................................. 106

13.1.2 INDIVIDUAL PLUGS ............................................................................................. 106

13.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE ....................................... 106

13.3 PURCHASING ADDITIONAL SEALING GASKET FROM DSE ............................... 106

13.4 DSENET EXPANSION MODULES .......................................................................... 107

14 WARRANTY .............................................................................................. 108

15 DISPOSAL ................................................................................................ 108

15.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT) ......................... 108

15.2 ROHS (RESTRICTION OF HAZARDOUS SUBSTANCES) ..................................... 108

Bibliography

1 BIBLIOGRAPHY

This document refers to and is referred to by the following DSE publications which can be obtained from the DSE website: www.deepseaplc.com

1.1 INSTALLATION INSTRUCTIONS

Installation instructions are supplied with the product in the box and are intended as a ‘quick start’ guide only.

DSE PART DESCRIPTION

053-137 DSE8810 Installation Instructions 053-138 DSE8820 Installation Instructions 053-139 DSE8860 Installation Instructions 053-032 DSE2548 LED Expansion Annunciator Installation Instructions 053-033 DSE2130 Input Expansion Installation Instructions 053-034 DSE2157 Output Expansion Installation Instructions 053-125 DSE2131 Ratio-metric Input Expansion Installation Instructions 053-126 DSE2133 RTD/Thermocouple Input Expansion Installation Instructions 053-134 DSE2152 Ratio-metric Output Expansion Installation Instructions

1.2 TRAINING GUIDES

Training Guides are produced to give ‘handout’ sheets on specific subjects during training sessions

DSE PART DESCRIPTION

056-005 Using CTs With DSE Products 056-006 Introduction to Comms 056-010 Overcurrent Protection 056-013 Load Demand Scheme 056-018 Negative Phase Sequence 056-019 Earth Fault Protection 056-020 Loss of Excitation 056-021 Mains Decoupling 056-022 Breaker Control 056-023 Adding New CAN Files 056-024 GSM Modem 056-026 kW & kVAr 056-029 Smoke Limiting

056-030 Module PIN Codes 056-032 xx60 With No Bus Breaker 056-042 Bus or Mains Mode 056-057 SW1 and SW2 056-059 xx10 in Fixed Export

Bibliography

1.3 MANUALS

Product manuals are can be downloaded from the DSE website: www.deepseaplc.com

DSE PART DESCRIPTION

057-004 Electronic Engines and DSE Wiring 057-045 Guide to Synchronising and Load Sharing Part 1 057-046 Guide to Synchronising and Load Sharing Part 2 057-047 Load Share Design and Commissioning 057-164 DSE8800 Series Configuration Software Manual 057-082 DSE2130 Input Expansion Manual 057-083 DSE2157 Output Expansion Manual 057-084 DSE2548 Annunciator Expansion Manual 057-139 DSE2131 Ratio-metric Input Expansion Manual 057-140 DSE2133 RTD/Thermocouple Expansion Manual 057-141 DSE2152 Ratio-metric Output Expansion Manual

1.4 THIRD PARTY DOCUMENTS

The following third party documents are also referred to:

REFERENCE DESCRIPTION

ISBN 1-55937-879-4 IEEE Std C37.2-1996 IEEE Standard Electrical Power System Device Function

Numbers and Contact Designations. Institute of Electrical and Electronics Engineers

Inc ISBN 0-7506-1147-2 Diesel generator handbook. L.L.J.Mahon ISBN 0-9625949-3-8 On-Site Power Generation. EGSA Education Committee.

Introduction

2 INTRODUCTION

This document details the installation and operation requirements of the DSE8800 Series modules, part of the DSEGenset® range of products.

The manual forms part of the product and should be kept for the entire life of the product. If the product is passed or supplied to another party, ensure that this document is passed to them for reference purposes. This is not a controlled document. You will not be automatically informed of updates. Any future updates of this document will be included on the DSE website at www.deepseaplc.com

The DSE8800 series is designed to provide differing levels of functionality across a common platform. This allows the generator OEM greater flexibility in the choice of controller to use for a specific application.

The DSE8810 controller has been designed to allow the operator to start and stop the generator, and if required, transfer the load to the generator either manually (via fascia mounted push-buttons) or automatically. Additionally, the DSE8860 automatically starts and stops the generator set depending upon the status of the mains (utility) supply. The user also has the facility to view the system operating parameters via the LCD display.

The DSE8800 module monitors the engine, indicating the operational status and fault conditions, automatically shutting down the engine and giving a true first up fault condition of an engine failure by a COMMON AUDIBLE ALARM. The LCD display indicates the fault.

The powerful ARM microprocessor contained within the module allows for incorporation of a range of complex features:

• Text and graphical colour LCD display (supporting multiple languages).

• True RMS Voltage, Current and Power monitoring with minimum and maximum holt

• Harmonic Display

• Communications capability (RS485, RS232 and Ethernet)

• Engine parameter monitoring.

• Event log and instrumentation data log

• Fully configurable inputs for use as alarms or a range of different functions.

• Synchronising and load sharing with load demand start/stop

• Integral PLC to help provide customisation where required

• Fuel tank level monitoring to track fuel filling operations and detect fuel leak/theft

• Engine ECU interface to electronic engines.

Using a PC and the DSE Configuration Suite software allows alteration of selected operational sequences, timers, alarms and operational sequences. Additionally, the module’s integral fascia configuration editor allows adjustment of a subset of this information.

A robust plastic case designed for front panel mounting houses the module. Connections are via locking plug and sockets..

Access to critical operational sequences and timers for use by qualified engineers, can be protected by a security code. Module access can also be protected by PIN code. Selected parameters can be changed from the module’s front panel.

The module is housed in a robust plastic case suitable for panel mounting. Connections to the module are via locking plug and sockets.

Specification

3 SPECIFICATIONS

3.1 PART NUMBERING

8810 - 001 - 01

At the time of this document production, there have been no revisions to the module hardware.

3.1.1 SHORT NAMES

Short name Description

DSE8000,DSE8xxx All modules in the DSE8000 range. DSE8800,DSE88xx All modules in the DSE8800 range.

Product type

DSE8810 Autostart Module

8810

Variant

Standard version 01

Hardware revision

Initial Release

001

UL approved version 32

Specification

3.2 TERMINAL SPECIFICATION

Connection type Two part connector.

• Male part fitted to module

• Female part supplied in module packing case Screw terminal, rising clamp, no internal spring.

Example showing cable entry and screw

terminals of a 10 way connector

Minimum cable size 0.5 mm² (AWG 24) Maximum cable size 2.5 mm² (AWG 10)

NOTE: - For purchasing additional connector plugs from DSE, please see the section

entitled Maintenance, Spares, Repair and Servicing elsewhere in this document.

3.3 POWER SUPPLY REQUIREMENTS

Minimum supply voltage 8 V continuous Cranking dropouts

Able to survive 0 V for 50 mS providing the supply was at least

10 V before the dropout and recovers to 5 V afterwards. Maximum supply voltage 35 V continuous (60 V protection) Reverse polarity protection -35 V continuous

Maximum operating current

300 mA at 24 V

600 mA at 12 V Maximum standby current

160 mA at 24 V

330 mA at 12 V

3.3.1 PLANT SUPPLY INSTRUMENTATION DISPLAY

Range 0 V-70 V DC (note Maximum continuous operating voltage of

35 V DC) Resolution 0.1 V Accuracy 1 % full scale (±0.7 V)

Specification

3.4 GENERATOR VOLTAGE / FREQUENCY SENSING

Measurement type True RMS conversion Sample Rate 5 KHz or better Harmonics Up to 10th or better Input Impedance

300 K Ω ph-N

Phase to Neutral 15 V

(minimum required for sensing frequency

)

to 333 V AC

(absolute

maximum)

Suitable for 110 V to 277 V nominal

(±20 % for under/overvoltage detection)

Phase to Phase 26 V

(minimum required for sensing frequency

)

to 576 V AC

(absolute

maximum)

Suitable for 19 0 V ph-ph to 479 V ph-ph nominal

(±20 % for under/overvoltage detection)

Common mode offset from Earth 100 V AC (max) Resolution 1V AC phase to neutral

2V AC phase to phase

Accuracy ±1 % of full scale phase to neutral

±2 % of full scale phase to phase Minimum frequency 3.5 Hz Maximum frequency 75.0 Hz Frequency resolution 0.1 Hz Frequency accuracy ±0.2 Hz

Specification

3.5 GENERATOR CURRENT SENSING

Measurement type True RMS conversion Sample Rate 5 kHz or better Harmonics Up to 10th or better Nominal CT secondary rating 1 A or 5 A (5 A recommended) Maximum continuous current 5 A Overload Measurement 3 x Nominal Range setting Absolute maximum overload 50 A for 1 second Burden

0.5 VA (0.02 Ω current shunts) common mode offset ±2 V peak plant ground to CT common terminal Resolution 0.5 % of 5 A Accuracy ±1 % of Nominal (1 A or 5 A) (excluding CT error)

3.5.1 VA RATING OF THE CTS

The VA burden of the module on the CTs is 0.5 VA. However depending upon the type and length of cabling

between the CTs and the module, CTs

with a greater VA rating than the module are required.

The distance between the CTs and the

measuring module should be estimated and cross-referenced against the chart opposite to find the VA burden of the cable itself.

If the CTs are fitted within the alternator top box, the star point (common) of the CTs should be

connected to system ground (earth) as

close as possible to the CTs. This minimises the length of cable used to connect the CTs to the DSE module.

Example. If 1.5 mm² cable is used and the

distance from the CT to the measuring

module is 20 m, then the burden of the cable alone is approximately 15 VA. As the burden of the DSE controller is

0.5 VA, then a CT with a rating of at least 15+0.5 V = 15.5 VA must be used. If 2.5 mm² cables are used over the same distance of 20 m, then the burden of the cable on the CT is approximately 7 VA. CT’s required in this instance is at least 7.5 VA (7+0.5).

NOTE: - Details for 4 mm² cables are shown for reference only. The connectors on the

DSE modules are only suitable for cables up to 2.5 mm².

NOTE: - CTs with 5 A secondary windings are recommended with DSE modules. 1 A CTs can be used if necessary however, the resolution of the readings is 5 times better when using 5 A CTs.

Specification

3.5.2 CT POLARITY

Take care to ensure the correct polarity of the CTs. Incorrect CT orientation will lead to negative kW readings when the set is supplying power. Take note that paper stick-on labels on CTs that show the orientation are often incorrectly placed on the CT (!). It is more reliable to use the labelling in the case moulding as an indicator to orientation (if available). To test orientation, run the generator in island mode (not in parallel with any other supply) and load the generator to around 10 % of the set rating. Ensure the DSE module shows positive kW for all three individual phase readings.

TO GENERATOR

TO LOAD SWITCH DEVICE

POLARITY OF CT PRIMARY

NOTE:- Take care to ensure correct polarity of the CT primary as shown above. If in doubt, check with the CT supplier.

3.5.3 CT PHASING

Take particular care that the CTs are connected to the correct phases. For instance, ensure that the CT on phase 1 is connected to the terminal on the DSE module intended for connection to the CT for phase 1. Additionally ensure that the voltage sensing for phase 1 is actually connected to generator phase 1. Incorrect connection of the phases as described above will result in incorrect power factor (pf) measurements, which in turn results in incorrect kW measurements. One way to check for this is to make use of a single-phase load. Place the load on each phase in turn, run the generator and ensure the kW value appears in the correct phase. For instance if the load is connected to phase 3, ensure the kW figure appears in phase 3 display and not in the display for phase 1 or 2.

3.5.4 CT CLASS

Ensure the correct CT type is chosen. For instance if the DSE module is providing overcurrent protection, ensure the CT is capable of measuring the overload level you wish to protect against, and at the accuracy level you require. For instance, this may mean fitting a protection class CT (P10 type) to maintain high accuracy while the CT is measuring overload currents. Conversely, if the DSE module is using the CT for instrumentation only (current protection is disabled or not fitted to the controller), then measurement class CTs can be used. Again, bear in mind the accuracy you require. The DSE module is accurate to better than 1% of the full-scale current reading. To maintain this accuracy you should fit Class 0.5 or Class 1 CTs.

You should check with your CT manufacturer for further advice on selecting your CTs

labelled as p1,

or K

labelled as p2,

or L

Specification

3.6 INPUTS

3.6.1 DIGITAL INPUTS

Number

11 configurable inputs. A future firmware update to the controller will enable an additional input. Check with DSE Technical Support

for further details. Arrangement Contact between terminal and ground Low level threshold 2.1 V minimum High level threshold 6.6 V maximum Maximum input voltage +50 V DC with respect to plant supply negative Minimum input voltage -24 V DC with respect to plant supply negative Contact wetting current 7 mA typical Open circuit voltage 12 V typical

3.6.2 ANALOGUE RESISTIVE INPUTS

3.6.2.1 OIL PRESSURE

Configurable if engine ECU link provides oil pressure measurement Measurement type Resistance measurement by measuring voltage across sensor

with a fixed current applied Arrangement Differential resistance measurement input Measurement current 15 mA Full scale

240 Ω Over range / fail

270 Ω Resolution 0.1 Bar (1 PSI -2 PSI) Accuracy

±2 % of full scale resistance (±4.8 Ω) excluding transducer error Max common mode voltage ±2 V Display range 13.7 bar (0 PSI - 200 PSI) subject to limits of the sensor

3.6.2.2 COOLANT TEMPERATURE

Configurable if engine ECU link provides coolant temp measurement Measurement type Resistance measurement by measuring voltage across sensor with

a fixed current applied Arrangement Differential resistance measurement input Measurement current 10 mA Full scale

480 Ω Over range / fail

540 Ω Resolution

1 °C (2 °F) Accuracy

+/-2 % of full scale resistance (±9.6 Ω) excluding transducer error Max common mode voltage ±2 V Display range

0 °C -140 °C (32 °F - 284 °F) subject to limits of the sensor

Specification

3.6.3 FUEL LEVEL (FLEXIBLE) INPUTS

The Fuel level input is also configurable as a ‘Ratiometric’ analogue inputs are provided. This is able to be configured as Digital, Resistive, 0-10 V or 4-20 mA.

3.6.3.1 FUEL LEVEL INPUT AS DIGITAL

Arrangement Contact between input terminal and battery negative Low level threshold 2.1 V minimum High level threshold 6.6 V maximum Max input voltage +60 V DC with respect to battery negative Min input voltage -24 V DC with respect to battery negative Contact wetting current 7 mA typical Open circuit voltage 12 V typical

3.6.3.2 FUEL LEVEL INPUT AS RESISTIVE

Arrangement Differential resistance measurement input with individual common

terminals for each sensor input Measurement current 9.3 mA typical Full scale

480 Ω Sensor fail Values greater than full scale return an over range sentinel that may be

interpreted as sensor fail if appropriate (host controller dependant) Resolution 1% of full scale Accuracy ±-2 % of full scale resistance, excluding transducer (sensor) error Maximum common mode voltage

3 V Transducer

(sensor type)

Configurable in host controller Use with contacts Inputs may be used with a contact to ground providing the corresponding

common terminal is grounded. (ie can be used as digital inputs if correctly

configured in the host controller)

3.6.3.3 FUEL LEVEL INPUT AS 0-10V

A future firmware update to the controller will enable this feature. Check with DSE Technical Support for further details.

3.6.3.4 FUEL LEVEL INPUT AS 4-20MA

A future firmware update to the controller will enable this feature. Check with DSE Technical Support for further details.

Specification

3.6.4 ANALOGUE FLEXIBLE INPUT

An additional flexible analogue input is provided and can be configured as Digital or Resistive.

3.6.4.1 FLEXIBLE SENSOR AS DIGITAL

3.6.4.2 FLEXIBLE SENSOR AS RESISTIVE

Arrangement Differential resistance measurement input with individual common

terminals for each sensor input Measurement current 9.3 mA typical Full scale

480 Ω Sensor fail Values greater than full scale return an over range sentinel that may be

3 V Transducer

(sensor type)

Configurable in host controller Use with contacts Inputs may be used with a contact to ground providing the corresponding

common terminal is grounded. (ie can be used as digital inputs if correctly

configured in the host controller)

3.6.4.3 FLEXIBLE SENSOR AS 0-10V

A future firmware update to the controller will enable this feature. Check with DSE Technical Support for further details.

3.6.4.4 FLEXIBLE SENSOR AS 4-20MA

A future firmware update to the controller will enable this feature. Check with DSE Technical Support for further details.

Specification

3.6.5 CHARGE FAIL INPUT

Minimum voltage 0V Maximum voltage 35V (plant supply) Resolution 0.2V Accuracy ± 1% of max measured voltage Excitation Active circuit constant power output Output Power 2.5W Nominal @12V and 24V Current at 12V 210mA Current at 24V 105mA

The charge fail input is actually a combined input and output. Whenever the generator is required to run, the terminal provides excitation current to the charge alternator field winding. When the charge alternator is correctly charging the battery, the voltage of the terminal is close to the plant battery supply voltage. In a failed charge situation, the voltage of this terminal is pulled down to a low voltage. It is this drop in voltage that triggers the charge failure alarm. The level at which this operates and whether this triggers a warning or shutdown alarm is configurable using the DSE Config Suite Software.

3.6.6 MAGNETIC PICKUP

Type Single ended input, capacitive coupled Minimum voltage 0.5V RMS Max common mode voltage ±2V Maximum voltage Clamped to ±70V by transient suppressers, dissipation not to

exceed 1W. Maximum frequency 10,000Hz Resolution 6.25 RPM Accuracy ±25 RPM Flywheel teeth 10 to 500

NOTE : DSE can supply a suitable magnetic pickup device, available in two body thread lengths : DSE Part number 020-012 - Magnetic Pickup probe 5/8 UNF 2½” thread length DSE Part number 020-013 - Magnetic Pickup probe 5/8 UNF 4” thread length

Magnetic Pickup devices can often be ‘shared’ between two or more devices. For example, one device can often supply the signal to both the module and the engine governor. The possibility of this depends upon the amount of current that the magnetic pickup can supply.

Specification

3.7 OUTPUTS

Ten (10) outputs are fitted to the controller.

3.7.1 OUTPUTS A & B

Type Normally used for Fuel / Start outputs. Fully configurable for other purposes if the

module is configured to control an electronic engine. Supplied from Emergency Stop terminal 3.

Rating 15A resistive @ 35V

3.7.2 CONFIGURABLE OUTPUTS C & D (LOAD SWITCHING)

Type Fully configurable volts free relays. Output C – Normally Closed, Output D – Normally

Open Rating 8A resistive@ 250V AC Protection Protected against over current & over temperature. Built in load dump feature.

3.7.3 OUTPUTS E,F,G,H, I, J

Number

6. A future firmware update to the controller will enable an additional two outputst.

Check with DSE Technical Support for further details. Type Fully configurable, supplied from DC supply terminal 2. Rating 2A resistive @ 35V

Specification

3.8 COMMUNICATION PORTS

USB Port USB2.0 Device for connection to PC running DSE configuration

suite only Max distance 6m (yards)

Serial Communication A single RS232 and two RS485 ports are both fitted and provide

independent operation

RS232 Serial port

Non – Isolated port Max Baud rate 115K baud subject to S/W TX, RX, RTS, CTS, DSR, DTR, DCD Male 9 way D type connector Max distance 15m (50 feet)

2 x RS485 Serial ports

Isolated Data connection 2 wire + common Half Duplex Data direction control for Transmit (by s/w protocol) Max Baud Rate 19200 External termination required (120Ω) Max common mode offset 70V (on board protection transorb) Max distance 1.2km (¾ mile)

CAN Port Engine CAN Port

Standard implementation of ‘Slow mode’, up to 250K bits/s Non-Isolated. Internal Termination provided (120Ω) Max distance 40m (133 feet)

NOTE:- For additional length, the DSE124 CAN Extender is available. Please refer to DSE Publication: 057-116 DSE124 Operator Manual for more information.

Ethernet Auto detecting 10/100 Ethernet port.

3.9 COMMUNICATION PORT USAGE

3.9.1 CAN INTERFACE

Modules are fitted with the CAN interface as standard and are capable of receiving engine data from engine CAN controllers compliant with the CAN standard. CAN enabled engine controllers monitor the engine’s operating

parameters such as engine speed, oil pressure, engine temperature (among others) in order to closely monitor and control the engine. The industry standard communications interface (CAN) transports data gathered by the engine controller interface. This allows generator controllers to access these engine parameters with no physical connection to the sensor device.

NOTE:- For further details for connections to CAN enabled engines and the functions available with each engine type, refer to the manual Electronic Engines and DSE Wiring. Part No. 057-004

Specification

3.9.2 USB CONNECTION

The USB port is provided to give a simple means of connection between a PC and the controller. Using the DSE Configuration Suite Software, the operator is then able to control the module, starting or stopping the generator, selecting operating modes, etc. Additionally, the various operating parameters (such as output volts, oil pressure, etc.) of the remote generator are available to be viewed or changed.

To connect a module to a PC by USB, the following items are required:

• DSE8800 series module

• DSE Configuration Suite PC Software

(Supplied on configuration suite software CD or available from www.deepseaplc.com).

• USB cable Type A to Type B. (This is the same cable as often used between a PC and a USB printer)

DSE can supply this cable if required : PC Configuration interface lead (USB type A – type B) DSE Part No 016-125

NOTE:- The DC supply must be connected to the module for configuration by PC.

NOTE:- Refer to DSE8800 Series Configuration Suite Manual (DSE part 057-164) for further

details on configuring, monitoring and control.

3.9.3 USB HOST-MASTER (USB DRIVE CONNECTION)

USB Type A connection for USB Host facility for USB storage device for data recording. Maximum size of externally storage device is 16Gb.(see viewing the instrument pages)

NOTE:- Refer to DSE8800 Series Configuration Suite Manual (DSE part 057-164) for further

details on configuring, monitoring and control.

Specification

3.9.4 RS232

The RS232 port on the controller supports the Modbus RTU protocol. The Gencomm register table for the controller is available upon request from the DSE Technical Support Department.

RS232 is for short distance communication (max 15m) and is typically used to connect the controller to a telephone or GSM modem for more remote communications.

Many PCs are not fitted with an internal RS232 serial port. DSE DO NOT recommend the use of USB to RS232 convertors but can recommend PC add-ons to provide the computer with an RS232 port.

3.9.4.1 RECOMMENDED PC RS232 SERIAL PORT ADD-ONS

Remember to check these parts are suitable for your PC. Consult your PC supplier for further advice.

• Brainboxes PM143 PCMCIA RS232 card (for laptop PCs)

• Brainboxes VX-001 Express Card RS232 (for laptops and nettops PCs)

• Brainboxes UC246 PCI RS232 card (for desktop PCs)

• Brainboxes PX-246 PCI Express 1 Port RS232 1 x 9 Pin (for desktop

PCs)

Supplier:

Brainboxes Tel: +44 (0)151 220 2500 Web: http://www.brainboxes.com Email: Sales: sales@brainboxes.com

NB DSE Have no business tie to Brainboxes. Over many years, our own engineers have used these

products and are happy to recommend them.

Specification

3.9.4.2 RECOMMENDED EXTERNAL MODEMS:

• Multitech Global Modem – MultiModem ZBA (PSTN) DSE Part Number 020-252 (Contact DSE Sales for details of localisation kits for these modems)

• Sierra Fastrak Xtend GSM modem kit (PSU, Antenna and modem)* DSE Part number 0830-001-01

NOTE: *For GSM modems a SIM card is required, supplied by your GSM network

provider:

• For SMS only, a ‘normal’ voice SIM card is required. This enables the controller to send SMS messages to designated mobile phones upon status and alarm conditions.

• For a data connection to a PC running DSE Configuration Suite Software, a ‘special’ CSD (Circuit Switched Data) SIM card is required that will enable the modem to answer an incoming data call. Many ‘pay as you go’ services will not provide a CSD (Circuit Switched Data) SIM card.

Specification

3.9.5 RS485

The RS485 ports on the controller support the Modbus RTU protocol. The DSE Gencomm register table for the controller is available upon request from the DSE Technical Support Department.

RS485 is used for point-to-point cable connection of more than one device (maximum 32 devices) and allows for connection to PCs, PLCs and Building Management Systems (to name just a few devices).

One advantage of the RS485 interface is the large distance specification (1.2km when using Belden 9841 (or equivalent) cable. This allows for a large distance between the module and a PC running the DSE Configuration Suite software. The operator is then able to control the module, starting or stopping the generator, selecting operating modes, etc. The various operating parameters (such as output volts, oil pressure, etc.) of the remote generator can be viewed or changed.

NOTE:- For a single module to PC connection and distances up to 6m (8yds) the USB

connection method is more suitable and provides for a lower cost alternative to RS485 (which is more suited to longer distance connections).

3.9.5.1 RECOMMENDED PC RS485 SERIAL PORT ADD-ONS

Remember to check these parts are suitable for your PC. Consult your PC supplier for further advice.

• Brainboxes PM154 PCMCIA RS485 card (for laptops PCs) Set to ‘Half Duplex, Autogating” with ‘CTS True’ set to ‘enabled’

• Brainboxes VX-023 ExpressCard 1 Port RS422/485 (for laptops and nettop PCs)

• Brainboxes UC320 PCI Velocity RS485 card (for desktop PCs) Set to ‘Half Duplex, Autogating” with ‘CTS True’ set to ‘enabled’

• Brainboxes PX-324 PCI Express 1 Port RS422/485 (for desktop PCs)

Supplier:

Brainboxes Tel: +44 (0)151 220 2500 Web: http://www.brainboxes.com Email: Sales: sales@brainboxes.com

NB DSE have no business tie to Brainboxes. Over many years,our own engineers have used these products and are happy to recommend them.

Specification

3.9.6 ETHERNET

The module is fitted with ETHERNET socket for connection to LAN (local area networks)

Description

TX+

TX-

RX+

Do not connect

RX-

Do not connect

3.9.6.1 DIRECT PC CONNECTION Requirements

• DSE8800 series module

• Crossover Ethernet cable (see Below)

• PC with Ethernet port

Crossover network cable

Specification

Crossover cable wiring detail

Two pairs crossed, two pairs uncrossed 10baseT/100baseTX crossover

Connection 1 (T568A)

Connection 2 (T568B)

white/green stripe

white/orange stripe

green solid

orange solid

white/orange stripe

white/green stripe

blue solid

white/blue stripe

orange solid

green solid

white/brown stripe

brown solid

NOTE:- This cable can be purchased from any good PC or IT store.

3.9.6.2 CONNECTION TO BASIC ETHERNET Requirements

• DSE8800 series module

• Ethernet cable (see below)

• Working Ethernet (company or home network)

• PC with Ethernet port

For the advanced Engineer, a crossover cable is a CAT5 cable with one end terminated as T568A and the other end terminated as T568B.

Ethernet router or ADSL router

Ethernet cable

Specification

Ethernet cable wiring detail

10baseT/100baseT

Connection 1 (T568A)

Connection 2 (T568A)

white/green stripe

green solid

white/orange stripe

blue solid

white/blue stripe

orange solid

white/brown stripe

brown solid

NOTE:- DSE Stock a 2m (2yds) Ethernet Cable – Part number 016-137. Alternatively they

can be purchased from any good PC or IT store.

3.9.6.3 CONNECTION TO COMPANY INFRASTRUCTURE ETHERNET Requirements

• DSE8800 series module

• Ethernet cable (see below)

• Working Ethernet (company or home network)

• PC with Ethernet port

For the advanced Engineer, this cable has both ends terminated as T568A (as shown below) or T568B.

Ethernet cable

PC Network wall connection sockets

Ethernet router or ADSL router

Specification

Ethernet cable wiring detail

10baseT/100baseT

Connection 1 (T568A)

Connection 2 (T568A)

white/green stripe

green solid

white/orange stripe

blue solid

white/blue stripe

orange solid

white/brown stripe

brown solid

NOTE:- DSE Stock a 2m (2yds) Ethernet Cable – Part number 016-137. Alternatively they

can be purchased from any good PC or IT store.

3.9.6.4 CONNECTION TO THE INTERNET

Requirements

• Ethernet cable (see below)

• Working Ethernet (company or home network)

• Working Internet connection (ADSL or DSL recommended)

For the advanced Engineer, this cable has both ends terminated as T568A (as shown below) or T568B.

DSL or ADSL

router

Optional ‘Local’

site PC

INTERNET

DSL or ADSL

router

PC remote

from generator

The DSL/ADSL router will route external network traffic.

Ethernet cable

Specification

Ethernet cable wiring detail

10baseT/100baseT

Connection 1 (T568A)

Connection 2 (T568A)

white/green stripe

green solid

white/orange stripe

blue solid

white/blue stripe

orange solid

white/brown stripe

brown solid

NOTE:- DSE Stock a 2m (2yds) Ethernet Cable – Part number 016-137. Alternatively they

can be purchased from any good PC or IT store.

For the advanced Engineer, this cable has both ends terminated as T568A (as shown below) or T568B.

Specification

3.9.6.5 FIREWALL CONFIGURATION FOR INTERNET ACCESS

As modem/routers differ enormously in their configuration, it is not possible for DSE to give a complete guide to their use with the module. However it is possible to give a description of the requirements in generic terms. For details of how to achieve the connection to your modem/router you are referred to the supplier of your modem/router equipment.

The module makes its data available over Modbus TCP and as such communicates over the Ethernet using a Port configured via the DSE Configuration Suite software..

You must configure your modem/router to allow inbound traffic on this port. For more information you are referred to your WAN interface device (modem/router) manufacturer.

It is also important to note that if the port assigned (setting from software “Modbus Port Number”) is already in use on the LAN, the module cannot be used and another port must be used .

Outgoing Firewall rule

As the module makes its user interface available to standard web browsers, all communication uses the chosen port. It is usual for a firewall to make the same port outgoing open for communication.

Incoming traffic (virtual server)

Network Address and Port Translation (NAPT) allows a single device, such as the modem/router gateway, to act as an agent between the Internet (or "public external network") and a local (or "internal private") network. This means that only a single, unique IP address is required to represent an entire group of computers.

For our application, this means that the WAN IP address of the modem/router is the IP address we need to access the site from an external (internet) location.

When the requests reach the modem/router, we want this passed to a ‘virtual server’ for handling, in our case this is the module.

Result : Traffic arriving from the WAN (internet) on port xxx is automatically sent to IP address set within the configuration software on the LAN for handling.

NOTE:- Refer to DSE8800 Series Configuration Suite Manual (DSE part 057-164) for further

details on configuring, monitoring and control.

Specification

3.10 DSENET® FOR EXPANSION MODULES

DSENet® is the interconnection cable between the host controller and the expansion module(s) and must not be connect to any device other than DSE equipment designed for connection to the DSENet®

Cable type Two core screened twisted pair Cable characteristic impedance

120Ω

Recommended cable Belden 9841

Belden 9271

Maximum cable length 1200m (¾ mile) when using Belden 9841 or direct equivalent.

600m (666 yds) when using Belden 9271 or direct equivalent. DSENet® topology “Daisy Chain” Bus with no stubs (spurs) DSENet® termination

120Ω. Fitted internally to host controller. Must be fitted externally to

the ‘last’ expansion module by the customer. Maximum expansion modules

Total 20 devices made up of DSE2130 (up to 4), DSE2131 (up to 4),

DSE2133 (up to 4), DSE2152 (up to 4), DSE2157 (up to 10), DSE2548

(up to 10)

This gives the possibility of :

Maximum 32 additional 0-10V or 4-20mA outputs (DSE2152)

Maximum 80 additional volt-free relay outputs (DSE2157)

Maximum 80 additional LED indicators

Maximum 24 additional Ratio-metric or Thermocouple inputs

(DSE2133).

Maximum 40 additional inputs (All can be configured as either digital,

resistive, 0-10V or 4-20mA when using DSE2131 or as digital /

resistive when using DSE2130)

NOTE: As a termination resistor is internally fitted to the host controller, the host controller must be the ‘first’ unit on the DSENet®. A termination resistor MUST be fitted to the ‘last’ unit on the DSENet®. For connection details, you are referred to the section entitled ‘typical wiring diagram’ elsewhere in this document.

NOTE : DSE8800 series module does not support the DSE2510/2520 display modules.

3.10.1 DSENET® USED FOR MODBUS ENGINE CONNECTION

As DSENet® utilises an RS485 hardware interface, this port can be configured for connection to Cummins Modbus engines (Engines fitted with Cummins GCS). This leaves the RS485 interfaces free for connection to remote monitoring equipment (i.e. Building Management System, PLC or PC RS485 port).

While this is a very useful feature in some applications, the obvious drawback is that the DSENet® interface is no longer available for connection to expansion devices.

Example of configuring the DSENet® for connection to Cummins QST GCS using the DSE Configuration Suite Software:

Specification

3.11 SOUNDER

The module features an internal sounder to draw attention to warning, shutdown and electrical trip alarms.

Sounder level 64db @ 1m

3.11.1 ADDING AN EXTERNAL SOUNDER TO THE APPLICATION

Should an external alarm or indicator be required, this can be achieved by using the DSE Configuration Suite PC software to configure an auxiliary output for “Audible Alarm”, and by configuring an auxiliary input for “Alarm Mute” (if required). The audible alarm output activates and de-activates at the same time as the module’s internal sounder. The Alarm mute input and internal alarm mute button activate ‘in parallel’ with each other. Either signal will mute both the internal sounder and audible alarm output.

Example of configuration to achieve external sounder with external alarm mute button:

3.12 ACCUMULATED INSTRUMENTATION

Accumulated instrumentation along with Engine Hours and Number of Starts can be set/reset using the DSE Configuration Suite PC software. Depending upon module configuration, this may have been PIN number locked by your generator supplier.

Specification

3.13 DIMENSIONS AND MOUNTING

3.13.1 DIMENSIONS

245 mm x 184 mm x 50 mm

(9.6” x 7.2” x 2.0”)

3.13.2 PANEL CUTOUT

220mm x 160mm

(8.7” x 6.3”)

3.13.3 WEIGHT

0.7kg (1.4lb)

3.13.4 FIXING CLIPS

The module is held into the panel fascia using the supplied fixing clips.

• Withdraw the fixing clip screw (turn anticlockwise) until only the pointed end is protruding from the clip.

• Insert the three ‘prongs’ of the fixing clip into the slots in the side of the module case.

• Pull the fixing clip backwards (towards the back of the module) ensuring all three prongs of

the clip are inside their allotted slots.

• Turn the fixing clip screws clockwise until they make contact with the panel fascia.

• Turn the screws a little more to secure the module into the panel fascia. Care should be taken

not to over tighten the fixing clip screws.

NOTE:- In conditions of excessive vibration, mount the module on suitable anti-vibration

mountings.

Fixing clip fitted to module

Fixing clip

Specification

3.13.5 CABLE TIE FIXING POINTS

Integral cable tie fixing points are included on the rear of the module’s case to aid wiring. This additionally provides strain relief to the cable loom by removing the weight of the loom from the screw connectors, thus reducing the chance of future connection failures. Care should be taken not to over tighten the cable tie (for instance with cable tie tools) to prevent the risk of damage to the module case.

Cable tie fixing point With cable and tie in place

3.13.6 SILICON SEALING GASKET

The supplied silicon gasket provides improved sealing between module and the panel fascia. The gasket is fitted to the module before installation into the panel fascia. Take care to ensure the gasket is correctly fitted to the module to maintain the integrity of the seal.

Gasket fitted to module

Sealing gasket

Specification

3.14 APPLICABLE STANDARDS

BS 4884-1

This document conforms to BS4884-1 1992 Specification for presentation of essential information.

BS 4884-2 This document conforms to BS4884-2 1993 Guide to content BS 4884-3 This document conforms to BS4884-3 1993 Guide to presentation BS EN 60068-2-1

(Minimum temperature)

-30°C (-22°F)

BS EN 60068-2-2

(Maximum temperature)

+70°C (158°F)

BS EN 60950

Safety of information technology equipment, including electrical business equipment

BS EN 61000-6-2

EMC Generic Immunity Standard (Industrial)

BS EN 61000-6-4

EMC Generic Emission Standard (Industrial) BS EN 60529 (Degrees of protection

provided by enclosures)

IP65 (front of module when installed into the control panel with the

supplied sealing gasket)

IP42 (front of module when installed into the control panel WITHOUT

being sealed to the panel)

UL508 NEMA rating

(Approximate)

12 (Front of module when installed into the control panel with the supplied

sealing gasket).

2 (Front of module when installed into the control panel WITHOUT being

sealed to the panel)

IEEE C37.2

(Standard Electrical Power System Device Function Numbers and Contact Designations)

Under the scope of IEEE 37.2, function numbers can also be used to

represent functions in microprocessor devices and software programs.

The controller is device number 11L-8000 (Multifunction device protecting

Line (generator) –module).

As the module is configurable by the generator OEM, the functions

covered by the module will vary. Under the module’s factory configuration,

the device numbers included within the module are :

2 – Time Delay Starting Or Closing Relay

3 – Checking Or Interlocking Relay

5 – Stopping Device

6 – Starting Circuit Breaker

8 – Control Power Disconnecting Device

10 – Unit Sequence Switch

11 – Multifunction Device

12 – Overspeed Device

14 – Underspeed Device

15 – Speed Or Frequency Matching Device.

23 – Temperature Control Device

25 – Synchronising Or Synchronism Check Relay

26 – Apparatus Thermal Device

27AC – AC Undervoltage Relay

27DC – DC Undervoltage Relay

29 – Isolating Contactor Or Switch

30 – Annunciator Relay

31 – Separate Excitation Device

37 – Undercurrent Or Underpower Relay (

USING INTERNAL PLC EDITOR

) 41 – Field Circuit Breaker 42 – Running Circuit Breaker 44 – Unit Sequence Relay 46 – Reverse-Phase Or Phase-Balance Current Relay 48 – Incomplete Sequence Relay 49 – Machine Or Transformer Thermal Relay

Specification

Continued overleaf.

Specification

IEEE C37.2

(Standard Electrical Power System Device Function Numbers and Contact Designations)

Continued… 50 – Instantaneous overcurrent relay

51 – AC time overcurrent relay 52 – AC circuit breaker 53 – Exciter or DC generator relay 54 – Turning gear engaging device 55 – Power factor relay (USING

INTERNAL PLC EDITOR

) 59AC – AC overvoltage relay 59DC – DC overvoltage relay 62 – Time delay stopping or opening relay 63 – Pressure switch 71 – Level switch 74 – Alarm relay 77 – Telemetering Device 78 – Phase-angle measuring relay 79 – Reclosing relay (USING INTERNAL PLC EDITOR) 81 – Frequency relay 83 – Automatic selective control or transfer relay 86 – Lockout relay

In line with our policy of continual development, Deep Sea Electronics, reserve the right to change specification without notice.

Specification

3.14.1 ENCLOSURE CLASSIFICATIONS

IP CLASSIFICATIONS

The modules specification under BS EN 60529 Degrees of protection provided by enclosures

IP65 (Front of module when module is installed into the control panel with the optional sealing gasket).

IP42 (front of module when module is installed into the control panel WITHOUT being sealed to the panel)

First Digit Second Digit

Protection against contact and ingress of solid objects Protection against ingress of water 0 No protection 0 No protection

1 Protected against ingress solid objects with a diameter of

more than 50 mm. No protection against deliberate access, e.g. with a hand, but large surfaces of the body are prevented from approach.

1 Protection against dripping water falling vertically. No harmful

effect must be produced (vertically falling drops).

2 Protected against penetration by solid objects with a

diameter of more than 12 mm. Fingers or similar objects prevented from approach.

2 Protection against dripping water falling vertically. There must

be no harmful effect when the equipment (enclosure) is tilted at an angle up to 15° from its normal position (drops falling at an angle).

3 Protected against ingress of solid objects with a diameter

of more than 2.5 mm. Tools, wires etc. with a thickness of more than 2.5 mm are prevented from approach.

3 Protection against water falling at any angle up to 60° from

the vertical. There must be no harmful effect (spray water).

4 Protected against ingress of solid objects with a diameter

of more than 1 mm. Tools, wires etc. with a thickness of more than 1 mm are prevented from approach.

4 Protection against water splashed against the equipment

(enclosure) from any direction. There must be no harmful effect (splashing water).

5 Protected against harmful dust deposits. Ingress of dust

is not totally prevented but the dust must not enter in sufficient quantity to interface with satisfactory operation of the equipment. Complete protection against contact.

5 Protection against water projected from a nozzle against the

equipment (enclosure) from any direction. There must be no harmful effect (water jet).

6 Protection against ingress of dust (dust tight). Complete

protection against contact.

6 Protection against heavy seas or powerful water jets. Water

must not enter the equipment (enclosure) in harmful quantities (splashing over).

Specification

3.14.2 NEMA CLASSIFICATIONS

The modules NEMA Rating (Approximate)

12 (Front of module when module is installed into the control panel with the optional sealing gasket).

2 (front of module when module is installed into the control panel WITHOUT being sealed to the panel)

NOTE: - There is no direct equivalence between IP / NEMA ratings. IP figures shown are

approximate only.

IP30

Provides a degree of protection against contact with the enclosure equipment and against a limited amount of falling dirt.

IP31

Provides a degree of protection against limited amounts of falling water and dirt.

IP64

Provides a degree of protection against windblown dust, rain and sleet; undamaged by the formation of ice on the enclosure.

IP32

Provides a degree of protection against rain and sleet:; undamaged by the formation of ice on the enclosure.

4 (X)

IP66

Provides a degree of protection against splashing water, windblown dust and rain, hose directed water; undamaged by the formation of ice on the enclosure. (Resist corrosion).

12/12K

IP65

Provides a degree of protection against dust, falling dirt and dripping non corrosive liquids.

IP65

Provides a degree of protection against dust and spraying of water, oil and non corrosive coolants.

Installation

4 INSTALLATION

The module is designed to be mounted on the panel fascia. For dimension and mounting details, see the section entitled Specification, Dimension and mounting elsewhere in this document.

4.1 TERMINAL DESCRIPTION

To aid user connection, icons are used on the rear of the module to help identify terminal functions. An example of this is shown below.

NOTE : Availability of some terminals depends upon module version. Full details are

given in the section entitled Terminal Description elsewhere in this manual.

Terminals 1-15 Terminals 15-20 Terminals 22-38

Terminals 39-46 Terminals 47-50 Terminals 51-57 Terminals 59-70

USB PC Configuration

USB Host Data Logging

Serial

Ethernet

Installation

4.1.1 DC SUPPLY, FUEL AND START OUTPUTS, OUTPUTS E-J

DESCRIPTION CABLE

SIZE

NOTES

DC Plant Supply Input (Negative)

2.5mm²

AWG 13

DC Plant Supply Input (Positive)

2.5 mm²

AWG 13

(Recommended Maximum Fuse 15A anti-surge) Supplies the module (2A anti-surge requirement) and Output relays E,F,G & H

3 Emergency Stop Input

2.5mm²

AWG 13

Plant Supply Positive. Also supplies outputs 1 & 2. (Recommended Maximum Fuse 20A)

4 Output relay A (FUEL)

2.5mm²

AWG 13

Plant Supply Positive from terminal 3. 15 Amp rated. Fixed as FUEL relay if electronic engine is not configured.

5 Output relay B (START)

2.5mm²

AWG 13

Plant Supply Positive from terminal 3. 15 Amp rated. Fixed as START relay if electronic engine is not configured.

6 Charge fail / excite

2.5mm²

AWG 13

Do not connect to ground (battery negative). If charge alternator is not fitted, leave this terminal disconnected.

7 Functional Earth

2.5mm²

AWG 13

Connect to a good clean earth point.

8 Output relay E

1.0mm²

AWG 18

Plant Supply Positive from terminal 2. 2 Amp rated.

9 Output relay F

1.0mm²

AWG 18

Plant Supply Positive from terminal 2. 2 Amp rated.

10 Output relay G

1.0mm²

AWG 18

Plant Supply Positive.from terminal 2. 2 Amp rated.

11 Output relay H

1.0mm²

AWG 18

Plant Supply Positive from terminal 2. 2 Amp rated.

12 Output relay I

1.0mm²

AWG 18

Plant Supply Positive from terminal 2. 2 Amp rated.

13 Output relay J

1.0mm²

AWG 18

Plant Supply Positive from terminal 2. 2 Amp rated.

14 Output relay K

1.0mm²

AWG 18

Plant Supply Positive from terminal 2. 2 Amp rated.

15 Output relay L

1.0mm²

AWG 18

Plant Supply Positive from terminal 2. 2 Amp rated.

NOTE:- Outputs K and L (terminals 14 and 15) are NOT used – Reserved for future use.

NOTE:- When the module is configured for operation with an electronic engine, FUEL and START output requirements may be different. Refer to Electronic Engines and DSE Wiring for further information. Part No. 057-004.

Installation

4.1.2 ANALOGUE SENSOR

DESCRIPTION CABLE

SIZE

NOTES

16 Sensor Common Return

0.5mm²

AWG 20

Return feed for sensors

17 Oil Pressure Input

0.5mm²

AWG 20

Connect to Oil pressure sensor

18 Coolant Temperature Input

0.5mm²

AWG 20

Connect to Coolant Temperature sensor

19 Fuel sensor input

0.5mm²

AWG 20

Connect to fuel sensor (user configurable) can also be configured to flexible sensor for alternative use.

20 Flexible sensor 2

0.5mm²

AWG 20

Connect to additional sensor (user configurable)

NOTE:- Terminal 21 is not fitted to the controller.

NOTE: - It is VERY important that terminal 16 (sensor common) is soundly connected to an earth point on the ENGINE BLOCK, not within the control panel, and must be a sound electrical connection to the sensor bodies. This connection MUST NOT be used to provide an earth connection for other terminals or devices. The simplest way to achieve this is to run a SEPARATE earth connection from the system earth star point, to terminal 16 directly, and not use this earth for other connections.

NOTE: - If you use PTFE insulating tape on the sensor thread when using earth return sensors, ensure you do not insulate the entire thread, as this will prevent the sensor body from being earthed via the engine block.

Installation

4.1.3 MAGNETIC PICKUP, CAN AND EXPANSION

DESCRIPTION CABLE

SIZE

NOTES

22 Magnetic pickup Positive

0.5mm²

AWG 20

Connect to Magnetic Pickup device

23 Magnetic pickup Negative

0.5mm²

AWG 20

Connect to Magnetic Pickup device

24 Magnetic pickup screen Shield Connect to ground at one end only

25 CAN port H

0.5mm²

AWG 20

Use only 120Ω CAN approved cable

26 CAN port L

0.5mm²

AWG 20

Use only 120Ω CAN approved cable

27 CAN port Common

0.5mm²

AWG 20

Use only 120Ω CAN approved cable

28 DSENet expansion A

0.5mm²

AWG 20

Use only 120Ω RS485 approved cable

29 DSENet expansion B

0.5mm²

AWG 20

Use only 120Ω RS485 approved cable

30 DSENet expansion SCR

0.5mm²

AWG 20

Use only 120Ω RS485 approved cable

MSC

31 Multiset Comms (MSC) Link H

0.5mm²

AWG 20

Use only 120Ω RS485 approved cable

32 Multiset Comms (MSC) Link L

0.5mm²

AWG 20

Use only 120Ω RS485 approved cable

33 Multiset Comms (MSC) Link SCR

0.5mm²

AWG 20

Use only 120Ω RS485 approved cable

GOV

34 Analogue Governor Output B

0.5mm²

AWG 20

35 Analogue Governor Output A

0.5mm²

AWG 20

36 DO NOT CONNECT

AVR

37 Analogue AVR Output B

0.5mm²

AWG 20

38 Analogue AVR Output A

0.5mm²

AWG 20

NOTE:- Terminal 36 is not fitted to the controller

NOTE:- Screened cable must be used for connecting the Magnetic Pickup, ensuring that the screen is earthed at one end ONLY.

NOTE:- Screened 120ΩΩΩΩ impedance cable specified for use with CAN must be used for the CAN link and the Multiset comms link. DSE stock and supply Belden cable 9841 which is a high quality 120ΩΩΩΩ impedance cable suitable for CAN use (DSE part number 016-030)

NOTE:- When the module is configured for CAN operation, terminals 22, 23 & 24 should be left unconnected. Engine speed is transmitted to the controller on the CAN link. Refer to Electronic Engines and DSE Wiring for further information. Part No. 057-004.

Installation

4.1.4 LOAD SWITCHING AND V1 GENERATOR VOLTAGE SENSING

DESCRIPTION CABLE

SIZE

NOTES

39 Output relay C

1.0mm

AWG 18

Normally configured to control mains contactor coil (Recommend 10A fuse)

40 Output relay C

1.0mm

AWG 18

Normally configured to control mains contactor coil

41 Output relay D

1.0mm

AWG 18

Normally configured to control generator contactor coil (Recommend 10A fuse)

42 Output relay D

1.0mm

AWG 18

Normally configured to control generator contactor coil

Generator L1 (U) voltage monitoring

1.0mm²

AWG 18

Connect to generator L1 (U) output (AC) (Recommend 2A fuse)

Generator L2 (V) voltage monitoring input

1.0mm²

AWG 18

Connect to generator L2 (V) output (AC) (Recommend 2A fuse)

Generator L3 (W) voltage monitoring input

1.0mm²

AWG 18

Connect to generator L3 (W) output (AC) (Recommend 2A fuse)

46 Generator Neutral (N) input

1.0mm²

AWG 18

Connect to generator Neutral terminal (AC)

NOTE:- The above table describes connections to a three phase, four wire alternator. For alternative wiring topologies, please see the ALTERNATIVE AC TOPOLOGIES section of this manual.

4.1.5 V2 BUS/MAINS VOLTAGE SENSING

DESCRIPTION CABLE

SIZE

NOTES

Bus/Mains L1 (R) voltage monitoring

1.0mm

AWG 18

Connect to Mains L1 (R) incoming supply (AC) (Recommend 2A fuse)

Bus/Mains L2 (S) voltage monitoring

1.0mm

AWG 18

Connect to Mains L1 (S) incoming supply (AC) (Recommend 2A fuse)

Bus/Mains L3 (T) voltage monitoring

1.0mm

AWG 18

Connect to Mains L1 (T) incoming supply (AC) (Recommend 2A fuse)

50 Bus/Mains Neutral (N) input

1.0mm

AWG 18

Connect to Mains N incoming supply (AC)

NOTE:- Mains connection is used for sensing of the mains or other supply voltage during “fixed export” operation. Bus connection is used for sensing of the common bus voltage during “multiset load

Installation

4.1.6 GENERATOR CURRENT TRANSFORMERS

WARNING!:- Do not disconnect this plug when the CTs are carrying current. Disconnection will open circuit the secondary of the C.T.’s and dangerous voltages may then develop. Always ensure the CTs are not carrying current and the CTs are short circuit connected before making or breaking connections to the module.

NOTE:- The module has a burden of 0.5VA on the CT. Ensure the CT is rated for the burden of the controller, the cable length being used and any other equipment sharing the CT. If in doubt, consult your CT supplier.

DESCRIPTION CABLE

SIZE

NOTES

51 CT Secondary for Gen L1

2.5mm²

AWG 13

Connect to s1 secondary of L1 monitoring CT

52 CT Secondary for Gen L2

2.5mm²

AWG 13

Connect to s1 secondary of L2 monitoring CT

53 CT Secondary for Gen L3

2.5mm²

AWG 13

Connect to s1 secondary of L3 monitoring CT

Connection to terminals 54 & 55

The function of terminals 54 and 55 change position depending upon wiring topology as follows:

Topology Pin

Description CABLE

SIZE

No earth fault measuring

54 DO NOT CONNECT

Connect to s2 of the CTs connected to L1,L2,L3,N

2.5mm²

AWG 13

Restricted earth fault measuring

Connect to s2 of the CTs connected to L1,L2,L3,N

2.5mm²

AWG 13

Connect to s1 of the CT on the neutral conductor

2.5mm²

AWG 13

Un-restricted earth fault measuring (Earth fault CT is fitted in the neutral to earth link)

Connect to s1 of the CT on the neutral to earth conductor.

2.5mm²

AWG 13

Connect to s2 of the CT on the neutral to earth link. Also connect to the s2 of CTs connected to L1, L2, L3.

2.5mm²

AWG 13

NOTE: - Terminal 58 is not fitted to the controller.

Installation

CT CONNECTIONS

p1, k or K is the primary of the CT that ‘points’ towards the GENERATOR

p2, l or L is the primary of the CT that ‘points’ towards the LOAD s1 is the secondary of the CT that connects to the DSE Module’s input for the CT measuring

(I1,I2,I3)

s2 is the secondary of the CT that should be commoned with the s2 connections of all the other CTs and connected to the CT common terminal of the module.

CT labelled as p1, k or K

CT labelled as p2, l or L

To Supply

To Load

Installation

4.1.7 CONFIGURABLE DIGITAL INPUTS

DESCRIPTION CABLE

SIZE

NOTES

59 Configurable digital input A

0.5mm²

AWG 20

Switch to negative

60 Configurable digital input B

0.5mm²

AWG 20

Switch to negative

61 Configurable digital input C

0.5mm²

AWG 20

Switch to negative

62 Configurable digital input D

0.5mm²

AWG 20

Switch to negative

63 Configurable digital input E

0.5mm²

AWG 20

Switch to negative

64 Configurable digital input F

0.5mm²

AWG 20

Switch to negative

65 Configurable digital input G

0.5mm²

AWG 20

Switch to negative

66 Configurable digital input H

0.5mm²

AWG 20

Switch to negative

67 Configurable digital input I

0.5mm²

AWG 20

Switch to negative

68 Configurable digital input J

0.5mm²

AWG 20

Switch to negative

69 Configurable digital input K

0.5mm²

AWG 20

Switch to negative

70 Configurable digital input L

0.5mm²

AWG 20

Switch to negative

NOTE:- Input L (terminal 70) is NOT used – Reserved for future use.

NOTE:- See the software manual for full range of configurable outputs available.

4.1.8 PC CONFIGURATION INTERFACE CONNECTOR

DESCRIPTION CABLE

SIZE

NOTES

Socket for connection to PC with DSE Configuration Suite Software

0.5mm²

AWG 20

This is a standard USB type A to type B connector.

NOTE:- The USB connection cable between the PC and the module must not be extended beyond 5m (yards). For distances over 5m, it is possible to use a third party USB extender. Typically, they extend USB up to 50m (yards). The supply and support of this type of equipment is outside the scope of Deep Sea Electronics PLC.

CAUTION!: Care must be taken not to overload the PCs USB system by connecting more than the recommended number of USB devices to the PC. For further information, consult your PC supplier.

CAUTION!: This socket must not be used for any other purpose.

Installation

4.1.9 RS485 CONNECTOR

Two, independently configurable RS485 ports are provided. Typical examples of devices that can be connected to these ports are PCs, PLCs, HMIs, Modbus engines

PIN No NOTES

Port1

A (-)

Two core screened twisted pair cable. 120Ω impedance suitable for RS485 use. Recommended cable type - Belden 9841 Max distance 1200m (1.2km) when using Belden 9841 or direct equivalent.

Port1

B (+)

Port1

SCR

Port2

A (-)

Two core screened twisted pair cable. 120Ω impedance suitable for RS485 use. Recommended cable type - Belden 9841 Max distance 1200m (1.2km) when using Belden 9841 or direct equivalent.

Port2

B (+)

Port2

SCR

4.1.10 RS232 CONNECTOR

PIN No NOTES

1 Received Line Signal Detector (Data Carrier Detect) 2 Received Data 3 Transmit Data 4 Data Terminal Ready 5 Signal Ground 6 Data Set Ready 7 Request To Send 8 Clear To Send 9 Ring Indicator

View looking into the male connector on the module

Location of RS232

connector

Location of the two RS485 connector ports

Installation

4.2 TYPICAL WIRING DIAGRAMS

As every system has different requirements, these diagrams show only a TYPICAL system and do not intend to show a complete system.

Genset manufacturers and panel builders may use these diagrams as a starting point; however, you are referred to the completed system diagram provided by your system manufacturer for complete wiring detail.

Further wiring suggestions are available in the following DSE publications, available at www.deepseaplc.com to website members.

DSE PART DESCRIPTION

056-022 Breaker Control (Training guide) 057-004 Electronic Engines and DSE Wiring

Installation

4.2.1 DSE8810 3 PHASE, 4 WIRE WITH RESTRICTED EARTH FAULT PROTECTION

NOTE:- Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’ the neutral CT allows the module to read earth faults ‘before’ the CT only (Restricted to generator / upstream of the CT)

Installation

4.3 ALTERNATIVE TOPOLOGIES

The controller is factory configured to connect to a 3 phase, 4 wire Star connected alternator. This section details connections for alternative AC topologies. Ensure to configure the controller to suit the required topology.

NOTE:- Refer to DSE8800 Series Configuration Suite Manual (DSE part 057-164) for further details on configuring, monitoring and control.

4.3.1 3 PHASE 4 WIRE WITH UNRESTRICTED EARTH FAULT MEASURING

NOTE:- Unrestricted Earth Fault Protection detects earth faults in the load and in the generator. Be sure to measure the natural earth fault of the site before deciding upon an earth fault alarm trip level.

Installation

4.4 EARTH SYSTEMS

4.4.1 NEGATIVE EARTH

The typical wiring diagrams located within this document show connections for a negative earth system (the battery negative connects to Earth)

4.4.2 POSITIVE EARTH

When using a DSE module with a Positive Earth System (the battery positive connects to Earth), the following points must be followed:

• Follow the typical wiring diagram as normal for all sections EXCEPT the earth points

• All points shown as Earth on the typical wiring diagram should connect to BATTERY

NEGATIVE (not earth).

4.4.3 FLOATING EARTH

Where neither the battery positive nor battery negative terminals are connected to earth the following points must to be followed

• Follow the typical wiring diagram as normal for all sections EXCEPT the earth points

• All points shown as Earth on the typical wiring diagram should connect to BATTERY

NEGATIVE (not earth).

4.5 TYPICAL ARRANGEMENT OF DSENET®

Twenty (20) devices can be connected to the DSENet®, made up of the following devices :

Device Max Number

Supported

DSE2130 Input Expansion 4 DSE2131 Ratio-metric Input Expansion 4 DSE2133 RTD/Thermocouple Intput Expansion

DSE2152 Ratio-metric Output Expansion 4 DSE2157 Relay Output Expansion 10 DSE2548 LED Expansion 10

For part numbers of the expansion modules and their documentation, see section entitled DSENet Expansion Modules elsewhere in this manual.

Installation

Description Of Controls

5 DESCRIPTION OF CONTROLS

5.1 DSE8810 AUTO START CONTROL MODULE

Menu Navigation Buttons

Select Stop

ode

Select Manual

ode

Select Auto

ode

Mute alarm /

Lamp test

Start Engine (When in

Close Generator (Manual Mode Only)

Open Generator (Manual Mode Only)

Main Status and Instrumentation Display

Close Generator LED. On When the Generator is On Load.

Generator Available LED. On When the Generator is Within Limits and Able to Take Load.

Description Of Controls

5.2 QUICKSTART GUIDE

This section provides a quick start guide to the module’s operation.

5.2.1 STARTING THE ENGINE

NOTE:- For further details, see the section entitled ‘OPERATION’ elsewhere in this manual.

5.2.2 STOPPING THE ENGINE

NOTE:- For further details, see the section entitled ‘OPERATION’ elsewhere in this manual.

First, Select Manual Mode…

…Then Press the Start Button to Crank the Engine.

Select Stop/Reset Mode. The Generator is Stopped.

Description Of Controls

5.3 VIEWING THE INSTRUMENT PAGES

5.3.1 DISPLAY OVERVIEW

5.3.2 PAGE INDICATORS

Alarms Schedule Status Home Engine Generator Bus

Pressing the next / previous page buttons scrolls between the available pages.

Example

Alarms Schedule Status Home Engine Generator Bus

Press Page Right to move to the next page.

Schedule Status Home Engine Generator Bus Alarms

Press Page Right to move to the next page.

Status Home Engine Generator Bus Alarms Schedule

It May be Quicker to Scroll Left Through the Pages Rather Than Right!

The Bottom Line of the Instrument Display Indicates the Currently Selected Page

Main Instrumentation Display

Side Scroll Bar

The Top Section Shows a Summary of the Status

Description Of Controls

5.3.3 SIDE SCROLL BAR

While a page is being viewed, the scroll bar at the side of the display represents how ‘far down’ the page you are

currently viewing. Pressing the scroll buttons moves up and down the currently selected page.

Examples

The complete order and contents of each information page are given in the following sections Once selected the page will remain on the LCD display until the user selects a different page, or after an extended

period of inactivity (configurable page timer), the module will revert to the status display.

5.3.4 SUMMARY AREA

An all grey vertical bar shows there is no further information to display, the whole page is currently being displayed.

The blue section indicates that you are currently viewing the ‘bottom’ half of a page. Press scroll up/down to move through the page

The blue section indicates that you are currently viewing a small part of a page. Press scroll up/down to move through the page

Summary Area When Configured to Show Load Switches

Summary Area When Configured to Show Bar Graph Information

Summary Area During Synchronising

Load Switch Position

Generator Available LED

Actual Generator Loading

Generator Loading as a Percentage of Full Load

Voltage Difference Between the Generator and the Bus

Phase of the Two Supplies. The ‘Barred’ Section is the Configurable Phase Window.

Actual Generator Loading

Description Of Controls

5.3.5 HOME

In addition to the common display area, the following instruments are displayed on the home page. Example image :

Bus

• Bus Voltage (ph-N)

• Bus Voltage (ph-ph)

Generator

• Generator Voltage (ph-N)

• Generator Voltage (ph-ph)

• Generator Current

• Generator Earth Current

• Generator Load (kW)

• Generator Load (kV A)

• Generator Power Factor

• Generator Load (kV Ar)

Description Of Controls

5.3.6 ENGINE

In addition to the common display area, the following instruments are displayed on the home page. Example image:

• Engine Speed (RPM)

• Oil Pressure

• Coolant Temperature

• Engine Battery Volts

• Charge Alternator Volts

• Engine Hours

• Engine Starts

• Est. Fuel Remaining

• Instrumentation from CAN ECU.*

• Tier 4 “DM1 Lamps” will also be available if used with a Tier 4 suitable engine / ECU.*

• CAN Link Status is also shown* :

Link OK ECU OFF Link LOST

Link Status

*When connected to suitably configured and compatible engine ECU. For details of supported engines see ‘Electronic Engines and DSE wiring’ (DSE Part number 057-004).

Description Of Controls

5.3.7 GENERATOR

Contains electrical values of the generator (alternator), measured or derived from the module’s voltage and current inputs.

Example image:

• Generator Voltage (ph-ph)

• Generator Voltage (ph-N)

• Generator Frequency

• Generator Current

• Generator Earth Current

• Generator Load (kW)

• Generator Load (kV A)

• Generator Load (kV Ar)

• Generator Power Factor

Averages

• Average Voltage (pn-N),

• Average Voltage (ph-ph)

• Average Current

• Average Load (kW)

• Average Load (kV A)

• Average Load (kV Ar)

• Average Power Factor

AC System

• Generator Configuration (AC System diagram)

• Generator Configuration (Nominals)

Accumulated

• kW h

• kV A h

• kV Ar h

Total kW

• Generator Load (L1 %, L2 %, L3 %, Total %)

Total kV A

• Generator Load (L1, L2, L3, Total)

Total kV Ar

• Generator Load (L1 %, L2 %, L3 %, Total %)

Minimum and Maximum hold for the selected instrument. This can be reset in the

Description Of Controls

Total

• Generator Load (kW, kV A, kV Ar, Power Factor)

Mains Decoupling

• R.O.C.O.F (Instantaneous reading and peak hold)

• Vector Shift (Instantaneous reading and peak hold)

5.3.8 BUS

Example image:

• Bus Voltage (ph-ph)

• Bus Voltage (ph-N)

• Bus Frequency

Averages

• Average Voltage (ph-ph)

• Average Voltage (pn-N),

AC System

• Bus Configuration (AC System diagram)

• Bus Configuration (Nominals)

Bus Load

• Bus Load (kW)

• Bus Load (kV Ar)

Description Of Controls

5.3.9 ALARMS

• List of currently active alarms

Example image:

Event Log

• Alarm History containing up to 250 past events logged. Where more than 250 events are logged, the last 250 are displayed.

• Press Tick to enter the event log, then press scroll up/down to navigate through the past events.

• Press Tick again to return to the main instrument navigation.

Example

Event Log

Date Time Hrs

02/29/2012 07:42:23 115:12

Index Event Details

1 Warning Failed to Stop



2 Shutdown Emergency Stop



3 Restart Power Up 4 Warning Low Oil Pressure

1 of 250

5 Warning Low Battery Volts

Date, Time and Engine Hours of the currently viewed Event.

Indicator to show the currently selected Event

Number of events currently logged

Description Of Controls

5.3.10 SCHEDULE

Allows the user to view the run schedule and maintenance alarm settings. Example images:

Description Of Controls

5.3.11 STATUS

Allows the user to view status information about the controller. Depending upon configuration of the controller, the information displayed will change.

Information

Model 8810 USB ID 0x0000BC12563 Control V1.00.02 Graphics V1.00.03 Analogue V3.00.02 Engine V1.18 Bootloader Control V1.00 Bootloader Graphics V1.02.03

This section contains important information about the module and the firmware versions. This information may be asked for when contacting DSE Technical Support Department for advice.

RS232 No Modem

Slave ID 10 Baud Rate 115200 Tx Packets 1562 Rx Packets 1562 Exception Packets 3

This section is included to give information about the RS232 serial port and external modem (if connected). The items displayed on this page will change depending upon configuration of the module. You are referred to your system supplier for further details.

NOTE:- Factory Default settings are for the RS232 port to be enabled with no modem connected,

operating at 19200 baud, modbus slave address 10.

Example 1 – Module connected to an RS232 telephone modem.

When the module is powered up, it will send ‘initialisation strings’ to the connected modem. It is important therefore that the modem is already powered, or is powered up at the same time as the module. At regular intervals after power up, the modem is reset, and reinitialised, to ensure the modem does not ‘hang up’.

If the module does not correctly communicate with the modem, “Modem initialising’ appears on the Serial Port instrument screen as shown overleaf.

If the module is set for “incoming calls” or for “incoming and outgoing calls”, then if the modem is dialled, it will answer after two rings (using the factory setting ‘initialisation strings)’. Once the call is established, all data is passed from the dialling PC and the module.

If the module is set for “outgoing calls” or for “incoming and outgoing calls”, then the module will dial out whenever an alarm is generated. Note that not all alarms will generate a dial out; this is dependant upon module configuration of the event log. Any item configured to appear in the event log will cause a dial out.

Description Of Controls

Many GSM modems are fitted with a status LED to show operator cell status and ringing indicator. These can be a useful troubleshooting tool.

In the case of GSM connection problems, try calling the DATA number of the SIMCARD with an ordinary telephone. There should be two rings, followed by the modem answering the call and then ‘squealing’. If this does not happen, you should check all modem connections and double check with the SIM provider that it is a DATA SIM and can operate as a data modem. DATA is NOT the same as FAX or GPRS and is often called Circuit Switched Data (CSD) by the SIM provider.

NOTE: In the case of GSM modems, it is important that a DATA ENABLED SIM is used. This is often a different number than the ‘voice number’ and is often called Circuit Switched Data (CSD) by the SIM provider.

If the GSM modem is not purchased from DSE, ensure that it has been correctly set to operate at 9600 baud. The DSE Modbus Gencomm document containing register mappings inside the DSE module is available upon

request from support@deepseaplc.com. Email your request along with the serial number of your DSE module to ensure the correct information is sent to you.

Description Of Controls

RS485 Port 1 / Port 2

Slave ID 10 Baud Rate 115200 Tx Packets 1562 Rx Packets 1562 Exception Packets 3

This section is included to give information about the currently selected serial port and external modem (if connected). The items displayed on this page will change depending upon configuration of the module. You are referred to your system supplier for further details.

NOTE:- Factory Default settings are for the RS485 port to operating at 19200 baud, modbus slave address 10.

Module RS485 port configured for connection to a modbus master.

The modules operate as a modbus RTU slave device. In a modbus system, there can be only one Master, typically a PLC, HMI system or PC SCADA system.

This master requests for information from the modbus slave (The module) and may (in control systems) also send request to change operating modes etc. Unless the Master makes a request, the slave is ‘quiet’ on the data link.

The factory settings are for the module to communicate at 19200 baud, modbus slave address 10. The DSE Modbus Gencomm document containing register mappings inside the DSE module is available upon

request from support@deepseaplc.com. Email your request along with the serial number of your DSE module to ensure the correct information is sent to you.

Typical requests (using Pseudo code)

BatteryVoltage=ReadRegister(10,0405,1)

: reads register (hex) 0405 as a single register (battery volts) from slave

address 10.

WriteRegister(10,1008,2,35701, 65535-35701)

: Puts the module into AUTO mode by writing to (hex) register 1008, the

values 35701 (auto mode) and register 1009 the value 65535-35701 (the bitwise opposite of auto mode)

Shutdown=(ReadRegister(10,0306,1) >> 12) & 1)

: reads (hex) 0306 and looks at bit 13 (shutdown alarm present)

Warning=(ReadRegister(10,0306,1) >> 11) & 1)

: reads (hex) 0306 and looks at bit 12 (Warning alarm present)

ElectricalTrip=(ReadRegister(10,0306,1) >> 10) & 1)

: reads (hex) 0306 and looks at bit 11 (Electrical Trip alarm

present)

ControlMode=ReadRegister(10,0304,2);

reads (hex) register 0304 (control mode).

Description Of Controls

Ethernet Port Up

DHCP enable Disabled Host Name IP address 192.168.10.23 Modbus Port Number 502 Subnet Mask 255.255.255.0 Gateway IP 0.0.0.0 DNS IP 0.0.0.0 MAC Address 008080EF1F2F3

Ethernet Traffic

DHCP enable Disabled Tx Packets 1562 Rx Packets 1562 Exception Packets 3

USB Traffic

Tx Packets 1562 Rx Packets 1562 Exception Packets 3

Logging

Log State Enabled Log Destination Internal Log Mode Newest Total Log Memory 2048k Log Memory Free 1463k USB Drive State Not Detected Logging Time Remaining 26hr 52m

Status

Supervisor State Alarm Stop Engine State Failed To Stop Load State Generator Open Protections Protections Enabled

Description Of Controls

Identity

Site Identity Deep Sea Electronics Genset Identity Generator #5 Load State Generator Open Protections Protections Enabled

SPI Status

AC Packets Rx 11363 Engine Packets Rx 11363 NV Packets Rx 11363 SMS Packets Rx 0 Reconnect Attempts 3

Operation

6 OPERATION

6.1 CONTROL

Control of the module is via push buttons mounted on the front of the module with STOP/RESET, MANUAL, TEST, AUTO, ALARM MUTE and START functions. For normal operation, these are the only controls which need

to be operated. The smaller push buttons are used to access further information such as generator voltage or to change the state of the load switching devices when in manual mode. Details of their operation are provided later in this document.

The following descriptions detail the sequences followed by a module containing the standard ‘factory configuration’. Always refer to your configuration source for the exact sequences and timers observed by any particular module in the field.

CAUTION: - The module may instruct an engine start event due to external influences. Therefore, it is possible for the engine to start at any time without warning. Prior to performing any maintenance on the system, it is recommended that steps are taken to remove the battery and isolate supplies.

NOTE: - This control module has PLC functionality built in. This can have change the standard operation when used. (Default configuration the no PLC is set. See software manual for more information)

Operation

6.2 CONTROL PUSH-BUTTONS

Stop / Reset

This button places the module into its Stop/Reset mode. This will clear any alarm conditions for which the triggering criteria have been removed. If the engine is running and the module is in Stop mode, the module will automatically instruct the changeover device to unload the generator (‘Close Generator’ becomes inactive (if used)). The fuel supply de-energises and the engine comes to a standstill. Should a remote start signal be present while operating in this mode, a remote start will not occur. Manual This mode allows manual control of the generator functions. Once in Manual mode the

module will respond to the start button, start the engine, and run off load. If the engine is running off-load in the Manual mode and a remote start signal becomes present, the module will automatically instruct the changeover device to place the generator on load (‘Close Generator’ becomes active (if used)). Upon removal of the remote start signal, the generator remains on load until either selection of the ‘STOP/RESET’ or ‘AUTO’ modes.

For further details, please see the more detailed description of ‘Manual operation’ elsewhere in this manual.

Auto This button places the module into its ‘Automatic’ mode. This mode allows the module to control the function of the generator automatically. The module will monitor the remote start input and mains supply status and once a start request is made, the set will be automatically started and placed on load. Upon removal of the starting signal, the module will automatically transfer the load from the generator and shut the set down observing the stop delay timer and cooling timer as necessary. The module will then await the next start event. For further details, please see the more detailed description of ‘Auto operation’ elsewhere in this manual.

Mute / Lamp Test

This button silences the audible alarm if it is sounding and illuminates all of the LEDs as a lamp test feature/ When correctly configured and fitted to a compatible engine ECU, pressing this button in

STOP/RESET mode after pressing the START button (to power the ECU) will cancel any “passive” alarms on the engine ECU.

Start

This button is only active in STOP/RESET or MANUAL mode. Pressing this button in manual or test mode will start the engine and run off load (manual) or on load (test). Pressing this button in STOP/RESET mode will turn on the CAN engine ECU (when correctly configured and fitted to a compatible engine ECU)

NOTE:- Different modes of operation are possible - Please refer to your configuration source for details.

Close generator

Operative in Manual Mode only Allows the operator to close the generator (when in Manual mode only)

Synchronisation takes place where necessary, followed by a soft ramp process.

Open generator

Allows the operator to open the generator (when in Manual mode only) Soft ramp down of load takes place if the module is configured to do so.

Operation

Menu navigation Used for navigating the instrumentation, event log and configuration screens.

For further details, please see the more detailed description of these items elsewhere in this manual.

6.3 ALTERNATIVE CONFIGURATIONS

Depending upon the configuration of your system by the generator supplier, the system may have selectable configurations (for example to select between 50Hz and 60Hz running). If this has been enabled your generator supplier will advise how this selection can be made (usually by externally operated selector switch or by selecting the required configuration file in the module front panel configuration editor).

Operation

6.4 DUMMY LOAD / LOAD SHEDDING CONTROL

This feature may be enabled by the system designer to ensure the loading on the generator is kept to a nominal amount. If the load is low, ‘dummy loads’ (typically static load banks) can be introduced to ensure the engine is not too lightly loaded. Conversely as the load increases towards the maximum rating of the set, non-essential loads can be shed to prevent overload of the generator.

6.2.1 DUMMY LOAD CONTROL

The dummy load control feature (if enabled) allows for a maximum of five dummy load steps. When the set is first started, all configured Dummy Load Control outputs are de-energised. Once the generator is placed onto load, the generator loading is monitored by the Dummy Load Control scheme.

If the generator loading falls below the Dummy Load Control Trip setting (kW), the Dummy Load Control Trip Delay is displayed on the module display. If the generator loading remains at this low level for the duration of the timer, the first Dummy Load Control output is energised. This is used to energise external circuits to switch in (for instance) a static load bank.

The generator loading has now been increased by the first dummy load. Again the generator loading is monitored. This continues until all configured Dummy Load Control outputs are energised. Should the generator loading rise above the Dummy Load Return level, the Dummy Load Return Delay begins. If the loading remains at these levels after the completion of the timer, the ‘highest’ active Dummy Load Control output is de-energised. This continues until all Dummy Load Control outputs have been de-energised.

6.2.2 LOAD SHEDDING CONTROL

The Load Shedding Control feature (if enabled) allows for a maximum of five load shedding steps. When the generator is about to take load, the configured number of Load Shedding Control Outputs at Startup will energise. This configurable setting allows (for instance) certain loads to be removed from the generator prior to the set’s load switch being closed. This can be used to ensure the initial loading of the set is kept to a minimum, below the Load Acceptance specification of the generating set.

The generator is then placed on load. The Load Shedding Control scheme begins. When the load reaches the Load Shedding Trip level the Trip Delay timer will start. If the generator loading is still high when the timer expires, the first Load shedding Control output will energise. When the load has been above the trip level for the duration of the timer the ‘next’ Load shedding Control output will energise and so on until all

Load Shedding Control outputs are energised.

If at any time the load falls back below the Load Shedding Return level, the Return Time will start. If the load remains below the return level when the timer has expired the ‘highest’ Load Shedding Control output that has been energised will be de-energised. This process will continue until all outputs have been de-energised. When the set enters a stopping sequence for any reason the Load Shedding control’ outputs will de-energise at the same time as the generator load switch is signalled to open.

NOTE:- Refer to DSE8800 Series Configuration Suite Manual (DSE part 057-164) for further details on configuration.

Operation

6.5 STOP MODE

STOP mode is activated by pressing the button. In STOP mode, the module will immediately remove the generator from load (if necessary) before stopping the

engine if it is already running. No cooling run is provided for this operation. Where a cooling run is required, switch to MANUAL mode and open the breaker manually. Allow the set to cool off load, before pressing the STOP button to stop the engine.

If the engine does not stop when requested, the FAIL TO STOP alarm is activated (subject to the setting of the Fail to Stop timer). To detect the engine at rest the following must occur:

• Engine speed is zero as detected by the Magnetic Pickup or CANbus ECU (depending upon module variant).

• Generator frequency must be zero.

• Oil pressure switch must be closed to indicate low oil pressure (MPU version only)

When the engine has stopped, it is possible to send configuration files to the module from DSE Configuration Suite PC software and to enter the Front Panel Editor to change parameters.

Any latched alarms that have been cleared will be reset when STOP mode is entered. The engine will not be started when in STOP mode. If remote start signals are given, the input is ignored until

AUTO mode is entered. When configured to do so, when left in STOP mode for five minutes with no presses of the fascia buttons, the

module enters low power mode. To ‘wake’ the module, press the button or any other fascia control button.

6.5.1 ECU OVERRIDE

NOTE:- Depending upon system design, the ECU may be powered or unpowered when the module is

in STOP mode. ECU override is only applicable if the ECU is unpowered when in STOP mode.

When the ECU is powered down (as is normal when in STOP mode), it is not possible to read the diagnostic trouble codes or instrumentation. Additionally, it is not possible to use the engine manufacturers’ configuration tools.

As the ECU is usually unpowered when the engine is not running, it must be turned on manually as follows:

• Select STOP mode on the DSE controller.

• Press and hold the START button to power the ECU. As the controller is in STOP mode, the engine

will not be started.

• Continue to hold the start button for as long as you need the ECU to be powered.

• The ECU will remain powered until a few seconds after the START button is released.

This is also useful if the engine manufacturer’s tools need to be connected to the engine, for instance to configure the engine as the ECU needs to be powered up to perform this operation.

Sleep mode configuration in the DSE Configuration Suite Software

Operation

6.6 AUTOMATIC MODE

NOTE:- If a digital input configured to panel lock is active, changing module modes will not be

possible. Viewing the instruments and event logs is NOT affected by panel lock.

Activate auto mode be pressing the pushbutton. An LED indicator beside the button confirms this action. Auto mode will allow the generator to operate fully automatically, starting and stopping as required with no user

intervention.

6.6.1 WAITING IN AUTO MODE

If a starting request is made, the starting sequence will begin. Starting requests can be from the following sources:

• Activation of an auxiliary input that has been configured to remote start on load or remote start off load.

• Request from DSE8x60 mains controller or from another DSE8x10 controller over the MSC link.

• Activation of the inbuilt exercise scheduler.

• Instruction from external remote telemetry devices using the RS232 or RS485 interface.

6.6.2 STARTING SEQUENCE

To allow for ‘false’ start requests such as mains brownouts, the start delay timer begins. There are individual start delay timers for each of the different start request types.

Should all start requests be removed during the start delay timer, the unit will return to a stand-by state. If a start request is still present at the end of the start delay timer, the fuel relay is energised and the engine will be

cranked.

NOTE:- If the unit has been configured for CAN, compatible ECU’s will receive the start command via

CAN.

If the engine fails to fire during this cranking attempt then the starter motor is disengaged for the crank rest duration after which the next start attempt begins. Should this sequence continue beyond the set number of attempts, the start sequence will be terminated and the display shows Fail to Start.

The starter motor is disengaged when the engine fires. Speed detection is factory configured to be derived from the main alternator output frequency, but can additionally be measured from a Magnetic Pickup mounted on the flywheel (Selected by PC using the Configuration Suite Software).

Additionally, rising oil pressure or charge alternator voltage can be used to disconnect the starter motor (but cannot detect underspeed or overspeed).

NOTE:- If the unit has been configured for CAN, speed sensing is via CAN.

After the starter motor has disengaged, the Safety On timer activates, allowing Oil Pressure, High Engine Temperature, Under-speed, Charge Fail and any delayed Auxiliary fault inputs to stabilise without triggering the fault.

Operation

6.6.3 ENGINE RUNNING

Once the engine is running, the Warm Up timer, if selected, begins, allowing the engine to stabilise before accepting the load.

If the common bus is measured to be ‘dead bus’, the load breaker is closed. If the bus is measured to be ‘live bus’, synchronising takes place before the breaker is closed.

NOTE:-The load transfer signal remains inactive until the Oil Pressure has risen. This prevents

excessive wear on the engine.

As the load increases and decreases, the controller (may (depending upon configuration) add dummy loads or remove non-essential loads. This is configured as part of the Load Shedding and Dummy Load control settings in the DSE Configuration Suite Software. See section entitled Dummy Load / Load Shedding elsewhere in this document for further details.

Additionally, when configured as part of a multiset package, the generator may be automatically started and stopped depending upon load requirements.

If in doubt, consult your system supplier for details of how your particular system has been configured. If all start requests are removed, the stopping sequence will begin.

6.6.4 STOPPING SEQUENCE

The return delay timer operates to ensure that the starting request has been permanently removed and is not just a short-term removal. Should another start request be made during the cooling down period, the set will return on load.

If there are no starting requests at the end of the return delay timer, the load is ramped off the generator being the breaker is opened and the cooling timer is initiated.

The cooling timer allows the set to run off load and cool sufficiently before being stopped. This is particularly important where turbo chargers are fitted to the engine.

If the set is called to return to load before the cooling timer has expired, the Engine Running operation is again followed.

After the cooling timer has expired, the set is stopped.

Operation

6.7 MANUAL MODE

NOTE:- If a digital input configured to panel lock is active, changing module modes will not be

possible. Viewing the instruments and event logs is NOT affected by panel lock.

Activate Manual mode be pressing the pushbutton. An LED indicator beside the button confirms this action. Manual mode allows the operator to start and stop the set manually, and if required change the state of the load

switching devices.

6.7.1 WAITING IN MANUAL MODE

When in manual mode, the set will not start automatically. To begin the starting sequence, press the

button.

6.7.2 STARTING SEQUENCE

NOTE:- There is no start delay in this mode of operation.

The fuel relay is energised and the engine is cranked.

NOTE:- If the unit has been configured for CAN, compatible ECU’s will receive the start command via

CAN.

If the engine fails to fire during this cranking attempt then the starter motor is disengaged for the crank rest duration after which the next start attempt is made. Should this sequence continue beyond the set number of attempts, the start sequence will be terminated and the display shows Fail to Start.

When the engine fires, the starter motor is disengaged. Speed detection is factory configured to be derived from the main alternator output frequency but can additionally be measured from a Magnetic Pickup mounted on the flywheel (Selected by PC using the 8600 series configuration software).

Additionally, rising oil pressure or charge alternator voltage can be used to disconnect the starter motor (but cannot detect underspeed or overspeed).

NOTE:- If the unit has been configured for CAN, speed sensing is via CAN.

Operation

6.7.3 ENGINE RUNNING

In manual mode, the load is not transferred to the generator unless a ‘loading request’ is made. A loading request can come from a number of sources.

• Pressing the transfer to generator button.

• Request from DSE8x60 mains controller or from another DSE8x10 controller over the MSC link.

• Activation of an auxiliary input that has been configured to remote start on load

• Activation of the inbuilt exercise scheduler if configured for ‘on load’ runs.

NOTE:-The load transfer signal remains inactive until the Oil Pressure has risen. This prevents

excessive wear on the engine.

If the common bus is measured to be ‘dead bus’, the load breaker is closed. If the bus is measured to be ‘live bus’, synchronising takes place before the breaker is closed.

Once the load has been transferred to the generator, the load switch will not be automatically opened unless:

• Press the Open Generator button (DSE8810 only)

• Press the auto mode button to return to automatic mode.

6.7.4 STOPPING SEQUENCE

In manual mode the set will continue to run until either :

• The stop button is pressed – The set will immediately stop

• The auto button is pressed. The set will observe all auto mode start requests and stopping timers

before beginning the Auto mode stopping sequence.

Protections

7 PROTECTIONS

When an alarm is present, the Audible Alarm will sound and the LCD display indicates the alarm(s) that are present :

The audible alarm can be silenced by pressing the Mute button

To reset the alarm, address the cause of the alarm, then press the Stop/Reset button .

7.1 PROTECTIONS DISABLED

User configuration is possible to prevent Shutdown / Electrical Trip alarms from stopping the engine. Under such conditions, Protections Disabled will appear on the module display to inform the operator of this status.

This feature is provided to assist the system designer in meeting specifications for “Warning only”, “Protections Disabled”, “Run to Destruction”, “War mode” or other similar wording.

When configuring this feature in the PC software, the system designer chooses to make the feature either permanently active, or only active upon operation of an external switch. The system designer provides this switch (not DSE) so its location will vary depending upon manufacturer, however it normally takes the form of a key operated switch to prevent inadvertent activation. Depending upon configuration, a warning alarm may be generated when the switch is operated.

The feature is configurable in the PC configuration software for the module. Writing a configuration to the controller that has “Protections Disabled” configured, results in a warning message appearing on the PC screen for the user to acknowledge before the controller’s configuration is changed. This prevents inadvertent activation of the feature.

Shutdown

Low Oil Pressure

1 of 1

Protections

7.1.1 INDICATION / WARNING ALARMS

Under Indication or Warning alarms:

• The module operation is unaffected by the Protections Disabled feature. See sections entitled Indications and Warnings elsewhere in this document.

7.1.2 SHUTDOWN / ELECTRICAL TRIP ALARMS

NOTE:- The EMERGENCY STOP input and shutdown alarm continues to operate even

when Protections Disabled has been activated.

Under Shutdown or Electrical Trip alarm conditions (excluding Emergency Stop):

• The alarm is displayed on the screen as detailed in the section entitled Shutdown alarms elsewhere in this document.

• The set continues to run.

• The load switch maintains its current position (it is not opened if already closed)

• Shutdown Blocked also appears on the LCD screen to inform the operator that the

Protections Disabled feature has blocked the shutdown of the engine under the normally critical fault.

• The ‘shutdown’ alarm is logged by the controllers Event Log (if configured to log shutdown alarms) and logs that the Shutdown was prevented.

Protections

7.1.3 CAN ALARMS

NOTE:- Please refer to the engine manufacturer’s documentation for ECU CAN error

message information.

CAN alarms are messages sent from the CAN ECU to the DSE controller and displayed as follows in the below tables.

DM1 Signals. Messages from the CAN ECU that are configurable within the DSE module for:-

Warning, Electrical Trip, shutdown or None

Display Reason

Amber Warning

The CAN ECU has detected a Amber warning.

Red Shutdown

The CAN ECU has detected a Red Shutdown.

Malfunction

The CAN ECU has detected a Malfunction message.

Protect

The CAN ECU has detected a Protect message

Advanced CAN alarms Allows configuration of additional can messages from the engine ECU.

Display Reason

Water in Fuel

The ECU has detected water in the fuel action taken is set by settings in advanced.

After Treatment

The ECU has detected “After Treatment alarm” consult engine manufacturer for details” action taken by DSE controller is set by settings in advanced

NOTE:- For CAN ECU error code meanings, refer to the ECU documentation provided by

the engine manufacturer, or contact the engine manufacturer for further assistance.

Display Reason

CAN ECU Warning

The engine ECU has detected a warning alarm and has informed the DSE module of this situation. The exact error is also indicated on the module’s display and action taken depending upon the setting for the DM1 signals

ECU Shutdown

The engine ECU has detected a shutdown alarm and has informed the DSE module of this situation. The exact error is also indicated on the module’s display.

ECU Data Fail

The module is configured for CAN operation and does not detect data on the engine CAN datalink, the engine shuts down.

Protections

7.2 INDICATIONS

Indications are non-critical and often status conditions. They do not appear on the LCD of the module as a text message. However, an output or LCD indicator can be configured to draw the operator’s attention to the event.

Example

• Input configured for indication.

• The LCD text will not appear on the module display

but can be added in the configuration to remind the system designer what the input is used for.

• As the input is configured to Indication there is no alarm generated.

• LCD Indicator to make LCD1 illuminate when the module is in Stop Mode.

• The Insert Card Text allows the system designer to print an insert card detailing the LCD function.

• Sample showing operation of the LCD indicators.

Text scrolls if it’s too long to fit onto the display !

Protections

7.3 WARNINGS

Warnings are non-critical alarm conditions and do not affect the operation of the generator system, they serve to draw the operators attention to an undesirable condition.

By default, warning alarms are self-resetting when the fault condition is removed. However enabling ‘all warnings are latched’ will cause warning alarms to latch until reset manually. This is enabled using the DSE Configuration Suite in conjunction with a compatible PC.

Display Reason

Auxiliary Inputs

If an auxiliary input has been configured as a warning the appropriate LCD message will be displayed and the COMMON ALARM LED will illuminate.

Charge Failure

The auxiliary charge alternator voltage is low as measured from the W/L terminal.

Battery Under Voltage

The DC supply has fallen below the low volts setting level for the duration of the low battery volts timer

Battery Over Voltage

The DC supply has risen above the high volts setting level for the duration of the high battery volts timer

Fail To Stop

The module has detected a condition that indicates that the engine is running when it has been instructed to stop.

NOTE:- ‘Fail to Stop’ could indicate a faulty oil pressure sensor or switch - If the engine is at rest check oil sensor wiring and configuration.

Fuel Usage

Indicates the amount of fuel measured by the fuel level sensor is in excess of the Fuel Usage alarm settings. This often indicates a fuel leak or potential fuel theft.

Low Fuel Level

The level detected by the fuel level sensor is below the low fuel level setting.

CAN ECU Error

The engine ECU has detected a warning alarm and has informed the DSE module of this situation. The exact error is also indicated on the module’s display.

Kw Overload

The measured Total kW is above the setting of the kW overload warning alarm

Earth Fault

The measured Earth Fault Current has been in excess of the earth fault trip and has surpassed the IDMT curve of the Earth Fault alarm.

Negative Phase Sequence

Indicates ‘out of balance’ current loading of the generator. Sometimes also called Negative Sequence Current or Symmetry Fault

Maintenance Due

Indicates that the maintenance alarm has triggered. A visit is required by the Generator service company.

Loading Voltage Not Reached

Indicates that the generator voltage is not above the configured loading voltage. The generator will not take load when the alarm is present after

the safety timer.

Loading Frequency Not Reached

Indicates that the generator frequency is not above the configured loading frequency. The generator will not take load when the alarm is present after the safety timer.

Display Reason

Protections Disabled

Shutdown and electrical trip alarms can be disabled by user configuration. In this case, Protections Disabled will appear on the module display; The alarm text is displayed but the engine will continue to run. This is ‘logged’ by the module to allow DSE Technical Staff to check if the protections have been disabled on the module at any time.

Low Oil Pressure

The module detects that the engine oil pressure has fallen below the

Protections

low oil pressure pre-alarm setting level after the Safety On timer has expired.

Engine High Temperature

The module detects that the engine coolant temperature has exceeded the high engine temperature pre-alarm setting level after the Safety On timer has expired.

Engine Low Temperature

The module detects that the engine coolant temperature has fallen below the high engine temperature pre-alarm setting level.

Overspeed

The engine speed has risen above the overspeed pre alarm setting

Underspeed

The engine speed has fallen below the underspeed pre alarm setting

Generator Over Frequency

The generator output frequency has risen above the pre-set pre-alarm setting.

Generator Under Frequency

The generator output frequency has fallen below the pre-set pre-alarm setting after the Safety On timer has expired.

Generator Over Voltage

The generator output voltage has risen above the pre-set pre-alarm setting.

Generator Under Voltage

The generator output voltage has fallen below the pre-set pre-alarm setting after the Safety On timer has expired.

Insufficient Capacity

f the generator reach full load when they are in parallel with the mains (utility). The LCD will indicate ‘INSUFFICIENT CAPACITY’ and the

COMMON ALARM LED will illuminate.

Mains Failed To Close

If the mains breaker fails to close, a warning is initiated. The LCD will indicate ‘MAINS FAILED TO CLOSE’ and the COMMON ALARM LED will illuminate.

Mains Failed To Open

If the mains breaker fails to open, a warning is initiated. The LCD will indicate ‘MAINS FAILED TO OPEN’ and the COMMON ALARM LED will illuminate.

Ecu Warning

The engine ECU has detected a warning alarm and has informed the DSE module of this situation. The exact error is also indicated on the module’s display.

If the module is configured for, CAN and receives an “error” message from the engine control unit, ‘CAN ECU Warning” is shown on the module’s display and a warning alarm is generated.

7.4 HIGH CURRENT WARNING ALARM

GENERATOR HIGH CURRENT, if the module detects a generator output current in excess of the

pre-set trip a warning alarm initiates. The module shows Alarm Warning High Current. If this high current condition continues for an excess period, then the alarm escalates to a shutdown condition. For further details of the high current alarm, please see High Current Shutdown Alarm.

By default, High Current Warning Alarm is self-resetting when the overcurrent condition is removed. However enabling ‘all warnings are latched’ will cause the alarm to latch until reset manually. This is enabled using the DSE Configuration Suite in conjunction with a compatible PC.

Protections

7.5 SHUTDOWNS

NOTE:- Shutdown and Electrical Trip alarms can be disabled by user configuration. See

the section entitled Protections Disabled elsewhere in this document.

Shutdowns are latching alarms and stop the Generator. Clear the alarm and remove the fault then press Stop/Reset to reset the module.

NOTE:- The alarm condition must be rectified before a reset will take place. If the alarm condition remains, it will not be possible to reset the unit (The exception to this is the Low Oil Pressure alarm and similar ‘active from safety on’ alarms, as the oil pressure will be low with the engine at rest).

Display Reason

Earth Fault

The measured Earth Fault Current has been in excess of the earth fault trip and has surpassed the IDMT curve of the Earth Fault alarm.

Fail To Start

The engine has not fired after the preset number of start attempts

Emergency Stop

The emergency stop button has been depressed. This a failsafe (normally closed to battery positive) input and will immediately stop the set should the signal be removed. Removal of the battery positive supply from the emergency stop input will also remove DC supply from the Fuel and Start outputs of the controller.

NOTE:- The Emergency Stop Positive signal must be

present otherwise the unit will shutdown.

Low Oil Pressure

The engine oil pressure has fallen below the low oil pressure trip setting level after the Safety On timer has expired.

Engine High Temperature

The engine coolant temperature has exceeded the high engine temperature trip setting level after the Safety On timer has expired.

Fuel Usage

Indicates the amount of fuel measured by the fuel level sensor is in excess of the Fuel Usage alarm settings. This often indicates a fuel leak or potential fuel theft.

Phase Rotation

The phase rotation is measured as being different to the configured direction.

Overspeed

The engine speed has exceeded the pre-set trip

NOTE:-During the start-up sequence, the overspeed trip logic can be configured to allow an extra trip level margin. This is used to prevent nuisance tripping on startup - Refer to the DSE8800 series configuration software manual under heading ‘Overspeed Overshoot’ for details.

Underspeed

The engine speed has fallen below the pre-set trip after the Safety On timer has expired.

Protections

Display Reason

Generator Over Frequency

The generator output frequency has risen above the preset level

Generator Under Frequency

The generator output frequency has fallen below the preset level

Generator Over Voltage

The generator output voltage has risen above the preset level

Generator Under Voltage

The generator output voltage has fallen below the preset level

Oil Pressure Sensor Open Circuit

The oil pressure sensor is detected as not being present (open circuit)

Auxiliary Inputs

An active auxiliary input configured as a shutdown will cause the engine to shut down. The display shows the text as configured by the user.

Loss Of Speed Signal

The speed signal from the magnetic pickup is not being received by the DSE controller.

ECU Data Fail

The module is configured for CAN operation and does not detect data on the engine Can datalink, the engine shuts down.

ECU Shutdown

The engine ECU has detected a shutdown alarm and has informed the DSE module of this situation. The exact error is also indicated on the module’s display.

kW Overload

The measured Total kW is above the setting of the kW overload shutdown alarm

Negative Phase Sequence

Indicates ‘out of balance’ current loading of the generator. Sometimes also called Negative Sequence Current or Symmetry Fault

Maintenance Due

Indicates that the maintenance alarm has triggered. A visit is required by the Generator service company.

Generator High Current

A High Current condition has continued for an excess period, then the alarm escalates to either a shutdown or electrical trip condition (depending upon module configuration). For further details of the high current alarm, please see High Current Shutdown / Electrical Trip Alarm.

Loading Voltage Not Reached

Indicates that the generator voltage is not above the configured loading voltage after the safety timer. The generator will shutdown.

Loading Frequency Not Reached

Indicates that the generator frequency is not above the configured loading frequency after the safety timer. The generator will shutdown.

Protections Disabled

Shutdown and electrical trip alarms can be disabled by user configuration. In this case, Protections Disabled will appear on the module display; The alarm text will be displayed but the engine will continue to run. This is ‘logged’ by the module to allow DSE Technical Staff to check if the protections have been disabled on the module at any time.

Protections

7.6 ELECTRICAL TRIPS

NOTE:- Shutdown and Electrical Trip alarms can be disabled by user configuration. See

the section entitled Protections Disabled elsewhere in this document.

Electrical trips are latching and stop the Generator but in a controlled manner. On initiation of the electrical trip condition the module will de-energise the ‘Close Generator’ Output to remove the load from the generator. Once this has occurred the module will start the Cooling timer and allow the engine to cool off-load before shutting down the engine. The alarm must be accepted and cleared, and the fault removed to reset the module.

Electrical trips are latching alarms and stop the Generator. Remove the fault then press Stop/Reset

to reset the module.

Display Reason

Generator High Current

If a generator output in excess of the high current alarm point, a warning alarm occurs. If this high current condition continues for an excess period, then the alarm escalates to either a shutdown or electrical trip condition (depending upon module configuration). For further details of the high current alarm, please see High Current Shutdown / Electrical Trip Alarm.

Auxiliary Inputs

If an auxiliary input configured as an electrical trip is active, the user configured message shows on the display.

Kw OVERLOAD

The measured Total kW is above the setting of the kW overload Electrical Trip alarm

Earth Fault

The measured Earth Current is above the setting of the Earth fault alarm.

Negative Phase Sequence

Indicates ‘out of balance’ current loading of the generator. Sometimes also called Negative Sequence Current or Symmetry Fault

Fuel Usage

Indicates the amount of fuel used is in excess of the Fuel Usage alarm settings. This often indicates a fuel leak or potential fuel theft.

Loading Voltage Not Reached

Indicates that the generator voltage is not above the configured loading voltage after the safety timer. The generator will shutdown.

Loading Frequency Not Reached

Indicates that the generator frequency is not above the configured loading frequency after the safety timer. The generator will shutdown.

Protections Disabled

Shutdown and electrical trip alarms is disabled by user configuration. In this case, Protections Disabled will appear on the module display; The alarm text is displayed but the engine will continue to run. This is ‘logged’ by the module to allow DSE Technical Staff to check if the protections have been disabled on the module at any time.

Generator Under Frequency

The generator output frequency has fallen below the preset level

Generator Under Voltage

The generator output voltage has fallen below the preset level

Insufficient Capacity

If the module is configured for Mains CT and the load levels are so high that the generator is unable to supply enough load to maintain the configured mains level, insufficient capacity will be displayed and the COMMON ALARM LED will flash. The generator will provide 100% of its capacity and the loading on the mains will increase.

Underspeed

The engine speed has fallen below the underspeed setting

Protections

7.7 HIGH CURRENT SHUTDOWN / ELECTRICAL TRIP ALARM

The overcurrent alarm combines a simple warning trip level with a fully functioning IDMT curve for thermal protection.

7.7.1 IMMEDIATE WARNING

If the Immediate Warning is enabled, the controller generates a warning alarm as soon as the Trip level is reached. The alarm automatically resets once the generator loading current falls below the Trip level (unless All Warnings are latched is enabled). For further advice, consult your generator supplier.

7.7.2 IDMT ALARM

If the IDMT Alarm is enabled, the controller begins following the IDMT ‘curve’ when the trip level is passed.

If the Trip is surpassed for an excess amount of time the IDMT Alarm triggers (Shutdown or Electric trip as selected in Action).

High current shutdown is a latching alarm and stops the Generator. Remove the fault then press Stop/Reset to reset the module.

High current electrical trip is a latching alarm and removes the generator from the load, before stopping the Generator after the off load cooling timer.

Remove the fault then press Stop/Reset to reset the module.

The higher the overload, the faster the trip. The speed of the trip is dependent upon the fixed formula:

T = t / ((IA / I T) – 1)

Where: T is the tripping time in seconds

IA is the actual current of the most highly loaded line (L1 or L2 or L3) IT is the delayed over-current trip point t is the time multiplier setting and also represents the tripping time in seconds at twice full load (when IA / IT = 2).

Factory settings for the IDMT Alarm when used on a brushless alternator are as follows (screen capture from the DSE Configuration Suite PC software :

These settings provide for normal running of the generator up to 100% full load. If full load is surpassed, the Immediate Warning alarm is triggered, the set continues to run. The effect of an overload on the generator is that the alternator windings begin to overheat; the aim of the IDMT alarm is to prevent the windings being overload (heated) too much. The amount of time that the set can be safely overloaded is governed by how high the overload condition is.

With typical settings as above, the tripping curve is followed as shown below.

(Trip setting value)

(time multiplier)

Protections

This allows for overload of the set to the limits of the Typical Brushless Alternator whereby 110% overload is permitted for 1 hour.

If the set load reduces, the controller then follows a cooling curve. This means that a second overload condition may trip much sooner than the first as the controller knows if the windings have not cooled sufficiently.

For further details on the Thermal damage curve of your alternator, you are referred to your alternator manufacturer and generator supplier.

Protections

Factory setting (Time Multiplier = 36

‘Fastest’ trip setting (Time Multiplier = 1

Slower than Factory setting (Time Multiplier = 72

Faster than Factory setting (Time Multiplier = 18

Protections

7.8 EARTH FAULT SHUTDOWN / ELECTRICAL TRIP ALARM

When the module is suitably connected using the ‘Earth Fault CT’. The module measures Earth Fault and can optionally be configured to generate an alarm condition (shutdown or electrical trip) when a specified level is surpassed.

If the Earth Fault alarm is enabled, the controller begins following the IDMT ‘curve’. If the Trip is surpassed for an excess amount of time the Alarm triggers (Shutdown or Electric trip as selected in Action).

The higher the Earth Fault, the faster the trip. The speed of the trip is dependent upon the fixed formula :

T = K x 0.14 / ((I / Is)

0.02

-1)

Where: T is the tripping time in seconds (accurate to +/- 5% or +/- 50ms (whichever is the greater)

K is the time multiplier setting I is the actual earth current measured

Is is the trip setting value

The settings shown in the example above are a screen capture of the DSE factory settings, taken from the DSE Configuration Suite software.

IS (Trip setting

K (time multiplier setting)

Protections

7.9 SHORT CIRCUIT ALARM

If the Short Circuit alarm is enabled, the controller begins following the IDMT ‘curve’. If the Trip is surpassed for an excess amount of time the Alarm triggers (Shutdown or Electrical trip as selected in Action).

The higher the Short Circuit, the faster the trip. The speed of the trip is dependent upon the fixed formula :

T = K x 0.14 / ((I / Is)

0.02

-1)

Where: T is the tripping time in seconds (accurate to +/- 5% or +/- 50ms (whichever is the greater)

K is the time multiplier setting I is the actual current measured Is is the trip setting value

The settings shown in the example above are a screen capture of the DSE factory settings, taken from the DSE Configuration Suite software.

IS (Trip setting

K (time multiplier setting)

Maintenance Alarm

7.10 MAINTENANCE ALARM

Depending upon module configuration one or more levels of maintenance alarm may occur based upon a configurable schedule.

Example 1 Screen capture from DSE Configuration Suite

Software showing the configuration of Maintenance Alarm 1 and Maintenance Alarm

2. When activated, the maintenance alarm can

be either a warning (set continues to run) or shutdown (running the set is not possible). Resetting the maintenance alarm is normally actioned by the site service engineer after performing the required maintenance. The method of reset is either by:

• Activating a input that has been configured to maintenance x reset, where x is the number of the maintenance alarm (1 to 3).

• Pressing the maintenance reset button in the DSE Configuration Suite, Maintenance section.

Example 2

Screen capture from DSE Configuration Suite Software showing the configuration of a digital input for Reset Maintenance Alarm 1.

Example 3

Screen capture from DSE Configuration Suite Software showing the Maintenance Alarm Reset ‘button’ in the DSE Configuration Suite SCADA | MAINTENANCE section.

Front Panel Configuration

8 SCHEDULER

The controller contains an inbuilt exercise run scheduler, capable of automatically starting and stopping the set. Up to 16 scheduled start/stop sequences can be configured to repeat on a 7-day or 28-day cycle. Scheduled runs may be on load or off load depending upon module configuration.

Example

Screen capture from DSE Configuration Suite Software showing the configuration of the Exercise Scheduler.

In this example the set will start at 09:00 on Monday and run for 5 hours, then start at 13:30 on Tuesday and run for 30 minutes.

8.1.1 STOP MODE

• Scheduled runs will not occur when the module is in STOP/RESET mode.

8.1.2 MANUAL MODE

• Scheduled runs will not occur when the module is in MANUAL mode.

• Activation of a Scheduled Run ‘On Load’ when the module is operating OFF LOAD in Manual

mode will have no effect, the set continues to run OFF LOAD

8.1.3 AUTO MODE

• Scheduled runs will operate ONLY if the module is in AUTO mode with no Shutdown or Electrical Trip alarm present.

• If the module is in STOP or MANUAL mode when a scheduled run begins, the engine will not be started. However, if the module is moved into AUTO mode during a scheduled run, the engine will be called to start.

• Depending upon configuration by the system designer, an external input can be used to inhibit a scheduled run.

• If the engine is running OFF LOAD in AUTO mode and a scheduled run configured to ‘On Load’ begins, the set is placed ON LOAD for the duration of the Schedule.

Front Panel Configuration

9 FRONT PANEL CONFIGURATION

This configuration mode allows the operator limited customising of the way the module operates. Use the module’s navigation buttons to traverse the menu and make value changes to the

parameters:

Increase Value / Next Item

Decrease Value / Next item

Front Panel Configuration

9.1 ACCESSING THE MAIN FRONT PANEL CONFIGURATION EDITOR

• Ensure the engine is at rest and the module is in STOP mode by pressing the Stop/Reset button.

• Press and hold the the Stop button and Tick button together.

• If a module security PIN has been set, the PIN number request is then

shown .

• Press , the first ‘#’ changes to ‘0’. Press (up) or (down) to adjust it to the correct value.

• Press (right) when the first digit is correctly entered. The digit you have just entered will now show ‘#’ for security.

• The other digits of the PIN number. You can press (left) if you need to move back to adjust one of the previous digits.

• When is pressed after editing the final PIN digit, the PIN is checked for validity. If the number is not correct, you must re-enter the PIN.

• If the PIN has been successfully entered (or the module PIN has not been enabled), the editor is displayed.

• To edit the parameter, press to enter edit mode. The parameter begins to flash to indicate that you are editing the value.

• Press the up or down buttons to change the parameter to the required value.

• Press to save the value. The parameter ceases flashing to indicate that it has been

saved.

• To exit the editor at any time, press and hold the or button.

NOTE: The PIN number is not set by DSE when the module leaves the factory. If the module has a PIN code set, this has been affected by your generator supplier who should be contacted if you require the code. If the code has been ‘lost’ or ‘forgotten’, the module must be returned to the DSE factory to have the module’s code removed. A charge will be made for this procedure.

Front Panel Configuration

9.1.1 EDITING A PARAMETER

• Enter the editor as described above.

• Press the (up) (down) and (right) to cycle to the section you wish to

view/change.

• Then press (up) or (down) to cycle to the parameter within the section you have chosen.

• To edit the parameter, press to enter edit mode. The parameter begins to flash to indicate that you are editing the value.

• Press the up or down buttons to change the parameter to the required value.

• Press to save the value. The parameter ceases flashing to indicate that it has been

saved.

• To exit the editor at any time, press and hold the or button.

NOTE: - The editor automatically exits after 5 minutes of inactivity to ensure security.

NOTE: - The PIN number is automatically reset when the editor is exited (manually or

automatically) to ensure security.

NOTE: - More comprehensive module configuration is possible using the DSE8800 series

PC configuration software – DSE Part 057-164. Please contact us for further details.

Front Panel Configuration

9.1.2 ADJUSTABLE PARAMETERS

Section

Parameter

Detail of Parameter

Parameter Action

Values

Inputs

Oil Pressure Low Oil Pressure Shutdown Trip 0.00 Bar

Warning Trip 0.00 Bar

Coolant Temperature High Coolant Alarms Pre-Alarm Trip 00 Deg C

Electrical Trip 00 Deg C Shutdown Trip 00 Deg C

Low Coolant Alarms Pre Alarm Trip 00 Deg C

Fuel Level Fuel Usage Alarm Running Rate Up / down

Stopped Rate Up / down

Timers

Start Timers Start Delay Remote Start Off Load s

Remote start On Load s Telemetry Start s

Start Timers Preheat s

Cranking Time s Crank Rest Time s Smoke Limit s Smoke Limit Off s Safety on Delay s Warming up Timer s

Stopping Timers Stopping Timers Return Delay s

Cooling Time mm:ss Fail To Stop Delay 0s Gen Transient Delay 0s

Display Page Timer mm: ss

Scroll Timer s

Generator

Generator Options AC System

3 Phase, 4 wire Delta 2 Phase, 3 Wire L1-L3 2 Phase, 3 Wire L1-L2 3 Phase, 3 Wire Single Phase, 2 Wire 3 Phase, 4 Wire

Generator Rating KW Rating 0 KW

kVAr Rating 0 kVAr

Generator Current Current Options CT Primary (L1,L2,L3,N) 0A

CT Secondary 5Amp / 1 Amp 5 / 1 Amp Full Load Rating 0A

Earth Fault Earth CT Primary 0A

Trip Action Enabled / Disabled Trip Percentage 0%

Over Current Alarm IDMT Alarm Enabled / Disabled

Trip 0% 0.0A

Short Circuit Trip 0% 0.0A

Generator Voltage Under Voltage Alarms Alarm Trip 0%

Pre-Alarm Trip 0A Nominal Voltage Nominal Voltage 0V Over Voltage Alarms Pre-alarm ttrip 0V

Alarm Trip 0V

Generator Frequency Under Frequency Alarms Alarm Trip

Pre-Alarm Trip

0.0Hz

0.0Hz Nominal Frequency Nominal Frequency 0.0Hz Pre-Alarm Trip

Alarm Trip

0.0Hz

Generator Power Overload Protection Overload Protection Trip 0% (0 kW)

Reverse Power Trip (Delay) 0kW (0.0 s)

Synchronising Load Control

Reactive Load Mode

KVAr Fixed Export kVAr Share None

Ramp Speed Ramp Speed 0.0 %/s Load Demand Calling For More Sets 0 %

Calling For Less Sets 0 %

Insufficient Capacity Action

Warning / Shutdown / None / Indication / Electrical Trip

Engine

Engine Options Overspeed Options Overspeed Overshoot 0%

Overshoot Delay s

Droop Enable Enabled / Disabled

Percent 0.0%

Speed Settings Under Speed Alarm Enable Enabled / Disabled

Alarm Trip 0000 RPM Warning Enable Enabled / Disabled Warniing Trip 0000 RPM

Over Speed Alarm Trip 0000 RPM

Pre-Alarm Enable Enabled / Disabled Pre-Alarm Trip 0000 RPM

Plant Battery Under Voltage Alarms Under Volts Enable Enabled / Disabled

Under Volts Delay mm:ss Under Volts Pre-Alarm 0.0v

Over Voltage Alarms Over Volts Enable Enabled / Disabled

Over volts Delay mm:ss Over Volts Pre-Alarm 0.0v

Charge Alt Alarm Alarm Enable Enabled / Disabled

Alarm Trip 0.0v Alarm Delay s

Charge Alt Pre-Alarm Pre-Alarm Enable Enabled / Disabled

Pre-Alarm Trip 0.0v Pre-Alarm Delay s

Alt. Config Options

Default Configuration

Alternative Configuration 3 Alternative Configuration 2 Alternative Configuration 1 Main Configuration

9.2 ACCESSING THE ‘MAINTENANCE’ CONFIGURATION EDITOR

Front Panel Configuration

• Press (up) or (down) buttons together.

•

Press ,(Up) or(down) (right) to cycle to the Parameter you wish to action.

Description Action Activation

USB Stick Removal Request

Press

Button

Override Starting Alarms Request Clear AMF Alarm Clear Manual Fuel Pump Inactive Min / Max Session Reset Request Cancel Telemetry

Request

To exit the editor at any time, press and hold the Tick button.

9.2.1 ADJUSTABLE PARAMETERS

(MAINTENANCE CONFIGURATION EDITOR)

• Press the (up) or (down) buttons to cycle to the section you wish to view / change.

• To Edit the parameter press the Tick button to enter edit mode. The parameter begins to flash to

indicate that you are editing the value.

• Press the (up) or (down) buttons to change the parameter to the required value.

• Press the Tick button to save the value. The parameter ceases flashing to indicate that it has been

saved.

• Press and hold Tick button to exit the “Running Configuration Editor”.

Front Panel Configuration

9.3 ACCESSING THE ‘RUNNING’ CONFIGURATION EDITOR

• The ‘running’ or editor can be entered while the engine is running. All protections remain active if the engine is running while the running editor is entered.

• Press and hold the button to enter the running editor.

9.3.1 ADJUSTABLE PARAMETERS

(RUNNING CONFIGURATION EDITOR)

• Press the (up) or (down) buttons to cycle to the section you wish to view / change.

• To edit the parameter press the Tick button to enter edit mode. The parameter begins to flash to

indicate that you are editing the value.

• Press the (up) or (down) buttons to change the parameter to the required value.

• Press the Tick button to save the value. The parameter ceases flashing to indicate that it has been

saved.

• Press and hold Tick button to exit the “Running Configuration Editor”.

Section Parameter Detail Of Parameter Values

Language

Language other English (United Kingdon)

Generator

Running Load Power Factor 0%

0.00pf 0kVAr Load Parallel Power 0% 0kW Load Priority Load Priority 1 Options Starting Alarms Disabled / Enabled Decoupling Test Mode Disabled / Enabled Voltage Voltage Adjust 0% Frequency Frequency Adjust 0%

Display

Press/ Temp Units Pressure kPA / PSI / Bar Temperature Deg F / Deg C Volume Units Volume Litre / Gallons US / Gallons (UK) Display LCD Backlight 0% AC Graphics AC Min / Max Enable Enabled / Disabled AC Meter Enable Enabled / Disabled THD Screen Enable Enabled / Disabled Engine Multi Meter Mode Enabled / Disabled Tier 4 Screen Enabled / Disabled Alarm Alarm Alert Box Enabled / Disabled Summary Summary Area Graphic Bars / Connectors Home Commissioning Screens Enabled / Disabled

Engine Speed Adjust Up / Down buttons

Time

Module Time hh:mm:ss Module Date DD/ MM/ YYYY Date Format MM/ DD/ YYYY OR DD/ MM/ YYYY MM/ DD/ YYYY OR DD/ MM/ YYYY

Commissioning

100

10 COMMISSIONING

10.1 PRE-COMMISSIONING

Before the system is started, it is recommended that the following checks are made:-

• The unit is adequately cooled and all the wiring to the module is of a standard and rating compatible with the system. Check all mechanical parts are fitted correctly and that all electrical connections (including earths) are sound.

• The unit DC supply is fused and connected to the battery and that it is of the correct polarity.

• The Emergency Stop input is wired to an external normally closed switch connected to DC

positive.

NOTE:- If Emergency Stop feature is not required, link this input to the DC Positive. The module will not operate unless either the Emergency Stop is fitted correctly OR terminal 3 is connected to DC positive.

• To check the start cycle operation, take appropriate measures to prevent the engine from starting

(disable the operation of the fuel solenoid). After a visual inspection to ensure it is safe to proceed, connect the battery supply. Select and then press the unit start sequence will

commence.

• The starter will engage and operate for the pre-set crank period. After the starter motor has

attempted to start the engine for the pre-set number of attempts, the LCD will display ‘Failed to start. Select the position to reset the unit.

• Restore the engine to operational status (reconnect the fuel solenoid). Select and then

press . This time the engine should start and the starter motor should disengage automatically. If not then check that the engine is fully operational (fuel available, etc.) and that the fuel solenoid is operating. The engine should now run up to operating speed. If not, and an alarm is present, check the alarm condition for validity, then check input wiring. The engine should continue to run for an indefinite period. It will be possible at this time to view the engine and alternator parameters - refer to the ‘Description of Controls’ section of this manual.

• Select on the front panel, the engine will run for the pre-set cooling down period, then stop.

The generator should stay in the standby mode. If not check that there is not a signal present on the Remote start input.

• Initiate an automatic start by supplying the remote start signal (if configured). The start sequence

will commence and the engine will run up to operational speed. Once the generator is available a load transfer will take place (if configured), the Generator will accept the load. If not, check the wiring to the Generator Contactor Coil (if used). Check the Warming timer has timed out.

• Remove the remote start signal. The return sequence will begin. After the pre-set time, the

generator is unloaded. The generator will then run for the pre-set cooling down period, then shutdown into its standby mode.

• Set the modules internal clock/calendar to ensure correct operation of the scheduler and event

logging functions. For details of this procedure see section entitled Front Panel Configuration – Editing the date and time.

• If, despite repeated checking of the connections between the controller and the customer’s

system, satisfactory operation cannot be achieved, then the customer is requested to contact the factory for further advice on:- support@deepseaplc.com
