057-236 ISSUE: 1

DEEP SEA ELECTRONICS PLC

DSE6110 MKII & DSE6120 MKII Operator

Manual

Document Number: 057-236

Author: Mark Graham

DSE6110 MKII & DSE6120 MKII Operator Manual

057-236 ISSUE: 1 Page 2 of 94

DEEP SEA ELECTRONICS PLC

Highfield House Hunmanby North Yorkshire YO14 0PH ENGLAND

Sales Tel: +44 (0) 1723 890099 Sales Fax: +44 (0) 1723 893303

E-mail: sales@deepseaplc.com Website: www.deepseaplc.com

DSE6110 MKII & DSE6120 MKII Operator Manual

© Deep Sea Electronics Plc All rights reserved. No part of this publication may be reproduced in any material form (including photocopying or storing in any medium by electronic means or other) without the written permission of the copyright holder except in accordance with the provisions of the Copyright, Designs and Patents Act 1988. Applications for the copyright holder’s written permission to reproduce any part of this publication should be addressed to Deep Sea Electronics Plc at the address above.

The DSE logo is a UK registered trademarks of Deep Sea Electronics PLC.

Any reference to trademarked product names used within this publication is owned by their respective companies.

Deep Sea Electronics Plc reserves the right to change the contents of this document without prior notice.

Amendments List

Issue Comments

Minimum

Module

Version Required

Minimum

Configuration

Suite Version

required

1 Initial release V 1.0.0 2014.103 V 2.17.3

Typeface: The typeface used in this document is Arial. Care should be taken not to mistake the upper case letter I with the numeral 1. The numeral 1 has a top serif to avoid this confusion.

Clarification of notation used within this publication.

NOTE

Highlights an essential element of a procedure to ensure correctness.

CAUTION!

Indicates a procedure or practice, which, if not strictly observed, could result in damage or destruction of equipment.

WARNING!

Indicates a procedure or practice, which could result in injury to personnel or loss of life if not followed correctly.

DSE6110 MKII & DSE6120 MKII Operator Manual

Page 3 of 94 057-236 ISSUE: 1

TABLE OF CONTENTS

Section Page

1 INTRODUCTION .............................................................................................. 6

1.1 BIBLIOGRAPHY ............................................................................................................. 7

1.1.1 INSTALLATION INSTRUCTIONS ............................................................................ 7

1.1.2 TRAINING GUIDES ................................................................................................. 7

1.1.3 MANUALS ................................................................................................................ 7

1.1.4 THIRD PARTY DOCUMENTS .................................................................................. 7

2 SPECIFICATION .............................................................................................. 8

2.1 SHORT NAMES .............................................................................................................. 8

2.2 OPERATING TEMPERATURE ....................................................................................... 8

2.2.1 SCREEN HEATER OPERATION ............................................................................. 8

2.3 REQUIREMENTS FOR UL CERTIFICATION ................................................................. 8

2.4 TERMINAL SPECIFICATION ......................................................................................... 9

2.5 POWER SUPPLY REQUIREMENTS .............................................................................. 9

2.5.1 MODULE SUPPLY INSTRUMENTATION DISPLAY ................................................ 9

2.6 VOLTAGE & FREQUENCY SENSING ......................................................................... 10

2.7 CURRENT SENSING .................................................................................................... 10

2.7.1 VA RATING OF THE CTS ...................................................................................... 11

2.7.2 CT POLARITY........................................................................................................ 12

2.7.3 CT PHASING ......................................................................................................... 12

2.7.4 CT CLASS ............................................................................................................. 12

2.8 INPUTS......................................................................................................................... 13

2.8.1 DIGITAL INPUTS ................................................................................................... 13

2.8.2 ANALOGUE INPUTS ............................................................................................. 13

2.8.2.1 ANALOGUE INPUT A ..................................................................................... 13

2.8.2.1.1 RESISTIVE CONFIGURATION.................................................................... 13

2.8.2.1.2 0-10V INPUT CONFIGURATION ................................................................ 14

2.8.2.1.3 4-20 MA INPUT CONFIGURATION ............................................................. 14

2.8.2.2 ANALOGUE INPUT B ..................................................................................... 14

2.8.2.3 ANALOGUE INPUT C ..................................................................................... 15

2.8.2.4 ANALOGUE INPUT D ..................................................................................... 15

2.8.3 CHARGE FAIL INPUT ............................................................................................ 16

2.8.4 MAGNETIC PICKUP .............................................................................................. 16

2.9 OUTPUTS..................................................................................................................... 16

2.9.1 DC OUTPUTS A & B (FUEL & START) .................................................................. 16

2.9.2 CONFIGURABLE DC OUTPUTS C, D, E & F ........................................................ 16

2.10 COMMUNICATION PORTS ...................................................................................... 17

2.10.1 CAN INTERFACE .................................................................................................. 17

2.10.2 USB CONNECTION ............................................................................................... 18

2.10.3 DSENET® (EXPANSION MODULES) ................................................................... 19

2.11 ADDING AN EXTERNAL SOUNDER ........................................................................ 20

2.12 ACCUMULATED INSTRUMENTATION .................................................................... 20

2.13 DIMENSIONS AND MOUNTING ............................................................................... 21

2.13.1 DIMENSIONS ........................................................................................................ 21

2.13.2 PANEL CUTOUT.................................................................................................... 21

2.13.3 WEIGHT ................................................................................................................ 21

2.13.4 FIXING CLIPS ........................................................................................................ 22

2.13.5 SILICON SEALING GASKET ................................................................................. 23

2.13.6 APPLICABLE STANDARDS ................................................................................... 24

2.13.7 ENCLOSURE CLASSIFICATIONS ......................................................................... 26

2.13.7.1 IP CLASSIFICATIONS .................................................................................... 26

2.13.7.2 NEMA CLASSIFICATIONS ............................................................................. 27

3 INSTALLATION ............................................................................................. 28

3.1 TERMINAL DESCRIPTION .......................................................................................... 28

DSE6110 MKII & DSE6120 MKII Operator Manual

057-236 ISSUE: 1 Page 4 of 94

3.1.1 DC SUPPLY, ESTOP INPUT, DC OUTPUTS & CHARGE FAIL INPUT ................. 29

3.1.2 ANALOGUE SENSORS, MPU, CAN ...................................................................... 30

3.1.3 DSENET® .............................................................................................................. 31

3.1.4 GENERATOR / MAINS VOLTAGE & FREQUENCY SENSING .............................. 31

3.1.5 CURRENT TRANSFORMERS ............................................................................... 32

3.1.5.1 CT CONNECTIONS ........................................................................................ 32

3.1.6 CONFIGURABLE DIGITAL INPUTS ...................................................................... 33

3.1.7 PC CONFIGURATION INTERFACE CONNECTOR ............................................... 33

3.2 TYPICAL WIRING DIAGRAM ....................................................................................... 34

3.2.1 DSE6110 MKII TYPICAL WIRING DIAGRAM (3 PHASE 4 WIRE) ......................... 35

3.2.2 DSE6120 MKII TYPICAL WIRING DIAGRAM (3 PHASE 4 WIRE) ......................... 36

3.3 ALTERNATE TOPOLOGY WIRING DIAGRAMS ......................................................... 37

3.3.1 GENERATOR ........................................................................................................ 37

3.3.2 MAINS (6120 MKII ONLY) ...................................................................................... 38

3.4 EARTH SYSTEMS ........................................................................................................ 39

3.4.1 NEGATIVE EARTH ................................................................................................ 39

3.4.2 POSITIVE EARTH ................................................................................................. 39

3.4.3 FLOATING EARTH ................................................................................................ 39

3.5 TYPICAL ARRANGEMENT OF DSENET® .................................................................. 40

4 DESCRIPTION OF CONTROLS .................................................................... 41

4.1 DSE6110 MKII .............................................................................................................. 42

4.2 DSE6120 MKII .............................................................................................................. 43

4.3 CONTROL PUSH-BUTTONS ....................................................................................... 44

4.4 VIEWING THE INSTRUMENT PAGES ......................................................................... 47

4.4.1 STATUS ................................................................................................................. 48

4.4.1.1 GENERATOR LOCKED OUT .......................................................................... 48

4.4.2 ENGINE ................................................................................................................. 49

4.4.3 GENERATOR ........................................................................................................ 50

4.4.4 MAINS (DSE6120 MKII ONLY)............................................................................... 50

4.4.5 EXPANSION .......................................................................................................... 51

4.4.6 ALARMS ................................................................................................................ 52

4.4.6.1 ECU ALARMS (CAN ERROR MESSAGE / DTC) ............................................ 53

4.4.7 EVENT LOG .......................................................................................................... 54

4.4.8 LCD INICATORS.................................................................................................... 55

4.4.9 USER DEFINED STRINGS .................................................................................... 55

4.4.10 ABOUT .................................................................................................................. 56

4.4.10.1 MODULE INFORMATION ............................................................................... 56

4.4.10.2 SUPPORT STRINGS ...................................................................................... 56

5 OPERATION .................................................................................................. 57

5.1 QUICKSTART GUIDE .................................................................................................. 57

5.1.1 STARTING THE ENGINE ...................................................................................... 57

5.1.2 STOPPING THE ENGINE ...................................................................................... 58

5.2 STOP/RESET MODE.................................................................................................... 59

5.3 MANUAL MODE ........................................................................................................... 60

5.3.1 STARTING SEQUENCE ........................................................................................ 60

5.3.2 ENGINE RUNNING ................................................................................................ 61

5.3.3 STOPPING SEQUENCE ........................................................................................ 61

5.4 TEST MODE ................................................................................................................. 62

5.4.1 STARTING SEQUENCE ........................................................................................ 62

5.4.2 ENGINE RUNNING ................................................................................................ 63

5.4.3 STOPPING SEQUENCE ........................................................................................ 63

5.5 AUTOMATIC MODE .................................................................................................... 64

5.5.1 WAITING IN AUTO MODE..................................................................................... 64

5.5.2 STARTING SEQUENCE ........................................................................................ 64

5.5.3 ENGINE RUNNING ................................................................................................ 65

5.5.4 STOPPING SEQUENCE ........................................................................................ 65

5.6 SCHEDULER ................................................................................................................ 66

5.6.1 STOP MODE ......................................................................................................... 66

DSE6110 MKII & DSE6120 MKII Operator Manual

Page 5 of 94 057-236 ISSUE: 1

5.6.2 MANUAL MODE..................................................................................................... 66

5.6.3 TEST MODE .......................................................................................................... 66

5.6.4 AUTO MODE ......................................................................................................... 66

6 PROTECTIONS ............................................................................................. 67

6.1 ALARMS ....................................................................................................................... 67

6.1.1 ECU ALARMS (CAN ERROR MESSAGE / DTC) ................................................... 68

6.2 INDICATIONS ............................................................................................................... 69

6.3 WARNING ALARMS ..................................................................................................... 70

6.4 ELECTRICAL TRIP ALARMS ...................................................................................... 72

6.5 SHUTDOWN ALARMS ................................................................................................. 74

6.6 HIGH CURRENT SHUTDOWN / ELECTRICAL TRIP ALARM ..................................... 76

6.6.1 IMMEDIATE WARNING ......................................................................................... 76

6.6.2 IDMT ALARM ......................................................................................................... 77

6.7 MAINTENANCE ALARM .............................................................................................. 79

7 FRONT PANEL CONFIGURATION ............................................................... 80

7.1 FRONT PANEL CONFIGURATION EDTIOR ................................................................ 81

7.1.1 ACCESSING THE FRONT PANEL CONFIGURATION EDITOR ............................ 81

7.1.2 ENTERING PIN ...................................................................................................... 81

7.1.3 EDITING A PARAMETER ...................................................................................... 82

7.1.4 EXITING THE FRONT PANEL CONFIGURATION EDITOR .................................. 82

7.1.5 ADJUSTABLE PARAMETERS ............................................................................... 83

7.2 ‘RUNNING’ CONFIGURATION EDITOR ...................................................................... 85

7.2.1 ACCESSING THE ‘RUNNING’ CONFIGURATION EDITOR................................... 85

7.2.2 ENTERING PIN ...................................................................................................... 85

7.2.3 EDITING A PARAMETER ...................................................................................... 85

7.2.4 EXITING THE ‘RUNNING’ CONFIGURATION EDITOR ......................................... 86

7.2.5 RUNNING EDITOR PARAMETERS ....................................................................... 86

8 COMMISSIONING .......................................................................................... 87

9 FAULT FINDING ............................................................................................ 88

9.1 STARTING ................................................................................................................... 88

9.2 LOADING ..................................................................................................................... 88

9.3 ALARMS ....................................................................................................................... 89

9.4 COMMUNICATIONS ..................................................................................................... 89

9.5 INSTRUMENTS ............................................................................................................ 89

9.6 MISCELLANEOUS ....................................................................................................... 90

10 MAINTENANCE, SPARES, REPAIR AND SERVICING ............................. 91

10.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE ............................ 91

10.1.1 PACK OF PLUGS .................................................................................................. 91

10.1.2 INDIVIDUAL PLUGS .............................................................................................. 91

10.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE ......................................... 91

10.3 PURCHASING ADDITIONAL SEALING GASKET FROM DSE ................................. 91

10.4 DSENET EXPANSION MODULES ............................................................................ 92

11 WARRANTY ................................................................................................ 93

12 DISPOSAL .................................................................................................. 93

12.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)........................... 93

Introduction

057-236 ISSUE: 1 Page 6 of 94

1 INTRODUCTION

This document details the installation and operation requirements of the DSE6110 MKII & DSE6120 MKII modules, part of the DSE

Genset® range of products.

The manual forms part of the product and should be kept for the entire life of the product. If the product is passed or supplied to another party, ensure that this document is passed to them for reference purposes. This is not a controlled document. DSE do not automatically inform on updates. Any future updates of this document are included on the DSE website at www.deepseaplc.com

The DSE61xx MKII series is designed to provide differing levels of functionality across a common platform. This allows the generator OEM greater flexibility in the choice of controller to use for a specific application.

The DSE61xx MKII series module has been designed to allow the operator to start and stop the generator, and if required, transfer the load to the generator either manually or automatically. Additionally, the DSE6120 MKII automatically starts and stops the generator set depending upon the status of the mains (utility) supply.

The user also has the facility to view the system operating parameters via the text LCD display.

The DSE61xx MKII module monitors the engine, indicating the operational status and fault conditions, automatically shutting down the engine and giving a true first up fault condition of an engine failure by the text LCD display.

The powerful ARM microprocessor contained within the module allows for incorporation of a range of complex features:

• Text based LCD display

• True RMS Voltage

• Current and Power monitoring

• USB Communications

• Engine parameter monitoring.

• Fully configurable inputs for use as alarms or a range of different functions.

• Engine ECU interface to electronic engines.

• Data Logging

Using a PC and the DSE Configuration Suite software allows alteration of selected operational sequences, timers, alarms and operational sequences. Additionally, the module’s integral front panel configuration editor allows adjustment of this information.

A robust plastic case designed for front panel mounting houses the module. Connections are via locking plug and sockets.

Access to critical operational sequences and timers for use by qualified engineers, can be protected by a security code. Module access can also be protected by PIN code. Selected parameters can be changed from the module’s front panel.

The module is housed in a robust plastic case suitable for panel mounting. Connections to the module are via locking plug and sockets.

Introduction

Page 7 of 94 057-236 ISSUE: 1

1.1 BIBLIOGRAPHY

This document refers to and is referred to by the following DSE publications which can be obtained from the DSE website: www.deepseaplc.com

1.1.1 INSTALLATION INSTRUCTIONS

Installation instructions are supplied with the product in the box and are intended as a ‘quick start’ guide only.

DSE Part Description

053-173 DSE6110 MKII & DSE6120 MKII Installation Instructions

1.1.2 TRAINING GUIDES

Training Guides are produced to give ‘handout’ sheets on specific subjects during training sessions

DSE Part Description

056-005 Using CTs With DSE Products 056-010 Over Current Protection 056-022 Breaker Control 056-029 Smoke Limiting 056-030 Module PIN Codes

1.1.3 MANUALS

Product manuals are can be downloaded from the DSE website: www.deepseaplc.com

DSE Part Description

057-004 Electronic Engines and DSE Wiring Guide 057-224 DSE6110 MKII & DSE6120 MKII Configuration Suite PC Software Manual

1.1.4 THIRD PARTY DOCUMENTS

The following third party documents are also referred to:

Reference Description

ISBN 1-55937-879-4

IEEE Std C37.2-1996 IEEE Standard Electrical Power System Device Function Numbers and Contact Designations. Institute of Electrical and

Electronics Engineers Inc ISBN 0-7506-1147-2 Diesel generator handbook. L.L.J. Mahon ISBN 0-9625949-3-8 On-Site Power Generation. EGSA Education Committee.

Specification

057-236 ISSUE: 1 Page 8 of 94

2 SPECIFICATION

2.1 SHORT NAMES

Short Name Description

DSE6000,DSE6xxx MKII All modules in the DSE6000 MKII range. DSE6100,DSE61xx MKII All modules in the DSE61xx MKII range. DSE6110 MKII DSE6110 MKII module/controller DSE6120 MKII DSE6120 MKII module/controller

2.2 OPERATING TEMPERATURE

Module Description

DSE61xx MKII -30 ºC +70 ºC (-22 ºF +158 ºF ) Display Heater Variants -40 ºC +70 ºC (-40 ºF +158 ºF )

2.2.1 SCREEN HEATER OPERATION

Screen Heater Function Description

Turn On When Temperature Falls Below -10 ºC (+14 ºF) Turn Off When Temperature Rises Above

-5 ºC (+23 ºF)

2.3 REQUIREMENTS FOR UL CERTIFICATION

Screw Terminal Tightening Torque

4.5 lb-in (0.5 Nm)

Conductors

• Terminals suitable for connection of conductor size 12 AWG to 26 AWG (0.5 mm² to 2.0 mm²).

• Conductor protection must be provided in accordance with NFPA 70, Article 240

• Low voltage circuits (35 volts or less) must be supplied from the engine starting battery or an isolated secondary circuit.

• The communication, sensor, and/or battery derived circuit conductors shall be separated and secured to maintain at least ¼” (6mm) separation from the generator and mains connected circuit conductors unless all conductors are rated 600 Volts or greater.

Current Inputs

Must be connected through UL Listed or Recognized isolating current

transformers with the secondary rating of 5A max. Communication Circuits

Must be connected to communication circuits of UL Listed equipment

Output Pilot Duty 0.5 A

Mounting

• Suitable for use in type 1 Enclosure Type rating with surrounding air temperature -22 ºF to +158 ºF (-30 ºC to +70 ºC)

• Suitable for pollution degree 3 environments when voltage sensing inputs do not exceed 300V. When used to monitor voltages over 300V device to be install in an unventilated or filtered ventilation enclosure to maintain a pollution degree 2 environment.

Operating Temperature

-22 ºF to +158 ºF (-30 ºC to +70 ºC)

Storage Temperature

-40 ºF to +176 ºF (-40 ºC to +80 ºC)

Specification

Page 9 of 94 057-236 ISSUE: 1

2.4 TERMINAL SPECIFICATION

NOTE: For purchasing additional connector plugs from DSE, please see the section

entitled Maintenance, Spares, Repair and Servicing elsewhere in this document.

Connection Type

Two part connector.

• Male part fitted to module

• Female part supplied in module packing case Screw terminal, rising clamp, no internal spring.

Example showing cable entry and screw

terminals of a 10 way connector

Minimum Cable Size 0.5 mm² (AWG 24) Maximum Cable Size 2.5 mm² (AWG 10)

2.5 POWER SUPPLY REQUIREMENTS

Minimum Supply Voltage 8 V continuous

Cranking Dropouts

Able to survive 0 V for 100 ms providing the supply was at

least 10 V before the dropout and recovers to 5 V afterwards. Maximum Supply Voltage 35 V continuous (60 V protection) Reverse Polarity Protection -35 V continuous

Maximum Operating Current

100 mA at 12 V

105 mA at 24 V

Maximum Standby Current

60 mA at 12 V

55 mA at 24 V Maximum Current When In Sleep Mode

40 mA at 12 V

35 mA at 24 V Typical Power (Controller On, Heater Off)

1.2 W to 2.4 W

Typical Power (Controller In Standby, Heater Off)

0.7 W to 1.2 W

2.5.1 MODULE SUPPLY INSTRUMENTATION DISPLAY

Range 0 V to 70 V DC (note Maximum continuous operating voltage of 35 V DC) Resolution 0.1 V Accuracy 1 % full scale (±0.7 V)

Specification

057-236 ISSUE: 1 Page 10 of 94

2.6 VOLTAGE & FREQUENCY SENSING

Measurement Type True RMS conversion Sample Rate 5 kHz or better Harmonics Up to 11th or better Input Impedance

300 kΩ phase to neutral

Phase To Neutral

15 V

(minimum required for sensing frequency

)

to 415 V AC

(absolute maximum)

Suitable for 345 V AC nominal

(±20 % for under/overvoltage detection)

Phase To Phase

25 V

(minimum required for sensing frequency

)

to 720 V AC

(absolute maximum)

Suitable for 600 V AC nominal

(±20 % for under/overvoltage detection)

Common Mode Offset From Earth 100 V AC (max)

Resolution

1 V AC phase to neutral

2 V AC phase to phase

Accuracy

±1 % of full scale phase to neutral

±2 % of full scale phase to phase Minimum Frequency 3.5 Hz Maximum Frequency 75.0 Hz Frequency Resolution 0.1 Hz Frequency Accuracy ±0.2 Hz

2.7 CURRENT SENSING

Measurement Type True RMS conversion Sample Rate 5 KHz or better Harmonics Up to 10th or better Nominal CT Secondary Rating 5 A Maximum Continuous Current 5 A Overload Measurement 3 x Nominal Range setting Absolute Maximum Overload 50 A for 1 second Burden

0.25 VA (0.01 Ω current shunts) Common Mode Offset ±1 V peak plant ground to CT common terminal Resolution 0.5 % of 5 A Accuracy ±1 % of Nominal (5 A) (excluding CT error)

Specification

Page 11 of 94 057-236 ISSUE: 1

2.7.1 VA RATING OF THE CTS

NOTE: Details for 4 mm² cables are shown for reference only. The connectors on the DSE

modules are only suitable for cables up to 2.5 mm².

The VA burden of the module on the CTs is 0.5 VA. However depending upon the type and length of cabling between the CTs and the module, CTs with a greater VA rating than the module are required.

The distance between the CTs and the

measuring module should be estimated and cross-referenced against the chart opposite to find the VA burden of the cable itself.

If the CTs are fitted within the alternator top box, the star point (common) of the CTs should be

connected to system ground (earth) as

close as possible to the CTs. This minimises the length of cable used to connect the CTs to the DSE module.

Example. If 1.5 mm² cable is used and the distance

from the CT to the measuring

module is 20 m, then the burden of the cable alone is approximately 15 VA. As the burden of the DSE controller is

0.5 VA, then a CT with a rating of at least 15 VA + 0.5 VA = 15.5 VA must be used. If 2.5 mm² cables are used over the same distance of 20 m, then the burden of the cable on the CT is approximately 7 VA. CT’s required in this instance is at least 7.5 VA (7 +

0.5).

Specification

057-236 ISSUE: 1 Page 12 of 94

2.7.2 CT POLARITY

NOTE: Take care to ensure correct polarity of the CT primary as shown above. If in doubt,

check with the CT supplier.

Take care to ensure the correct polarity of the CTs. Incorrect CT orientation leads to negative kW readings when the set is supplying power. Take note that paper stick-on labels on CTs that show the orientation are often incorrectly placed on the CT (!). It is more reliable to use the labelling in the case moulding as an indicator to orientation (if available).

To test orientation, run the generator in island mode (not in parallel with any other supply) and load the generator to around 10 % of the set rating. Ensure the DSE module shows positive kW for all three individual phase readings.

TO GENERATOR

TO LOAD

POLARITY OF CT PRIMARY

2.7.3 CT PHASING

Take particular care that the CTs are connected to the correct phases. For instance, ensure that the CT on phase 1 is connected to the terminal on the DSE module intended for connection to the CT for phase 1.

Additionally ensure that the voltage sensing for phase 1 is actually connected to generator phase 1. Incorrect connection of the phases as described above results in incorrect power factor (pf) measurements, which in turn results in incorrect kW measurements.

One way to check for this is to make use of a single-phase load. Place the load on each phase in turn, run the generator and ensure the kW value appears in the correct phase. For instance if the load is connected to phase 3, ensure the kW figure appears in phase 3 display and not in the display for phase 1 or 2.

2.7.4 CT CLASS

Ensure the correct CT type is chosen. For instance if the DSE module is providing overcurrent protection, ensure the CT is capable of measuring the overload level you wish to protect against, and at the accuracy level you require.

For instance, this may mean fitting a protection class CT (P10 type) to maintain high accuracy while the CT is measuring overload currents.

Conversely, if the DSE module is using the CT for instrumentation only (current protection is disabled or not fitted to the controller), then measurement class CTs can be used. Again, bear in mind the accuracy you require. The DSE module is accurate to better than 1% of the full-scale current reading. To maintain this accuracy you should fit Class 0.5 or Class 1 CTs.

You should check with your CT manufacturer for further advice on selecting your CTs

Labelled as

p1,

or K

Labelled as

p2,

or L

Specification

Page 13 of 94 057-236 ISSUE: 1

2.8 INPUTS

2.8.1 DIGITAL INPUTS

Number

6 configurable digital inputs

(10 when Analogue Inputs are configured as digital inputs) Arrangement Contact between terminal and ground Low Level Threshold 3.2 V minimum High Level Threshold 8.1 V maximum Maximum Input Voltage +60 V DC with respect to plant supply negative Minimum Input Voltage -24 V DC with respect to plant supply negative Contact Wetting Current 6 mA typical Open Circuit Voltage 15 V typical

2.8.2 ANALOGUE INPUTS

Analoge inputs A,B,C & D are flexible within the DSE6110 MKII & 6120 MKII modules

2.8.2.1 ANALOGUE INPUT A

Input Type

Flexible: Configured for Oil Sensor in the DSE default configuration. Flexible Options: Not used, Digital Input, Flexible Analogue & Oil

Sensor

Flexible Input Selection

Pressure Sensor Percentage Sensor Temperature Sensor

Flexible Measured Quantity (Analogue Input A only)

Current Restive Voltage

2.8.2.1.1 RESISTIVE CONFIGURATION

Number 4 configurable resistive type inputs

Measurement Type

Resistance measurement by measuring voltage across sensor with

a fixed current applied Arrangement Differential resistance measurement input Measurement Current 11 mA ±10 % Full Scale

240 Ω Over Range / Fail

360Ω Resolution 1 % Accuracy

+/-2 % of full scale resistance (±9.6 Ω) excluding transducer error Max Common Mode Voltage ±2 V

Display Range

0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar

(0 PSI to 250 PSI) subject to limits of the sensor and sensor

configuration

Specification

057-236 ISSUE: 1 Page 14 of 94

2.8.2.1.2 0-10V INPUT CONFIGURATION

Number 1 configurable ratiometric input Full Scale 0 V to 10 V Resolution 1% Accuracy +/-2% of full scale voltage (±0.2 V) excluding transducer error Max Common Mode Voltage ±2 V

Display Range

0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar

(0 PSI to 250 PSI) subject to limits of the sensor and sensor

configuration

2.8.2.1.3 4-20 MA INPUT CONFIGURATION

Number 1 configurable ratiometric input Full Scale 0 mA to 20 mA Resolution 1% Accuracy +/-2% of full scale resistance (±0.4 mA) excluding transducer error Max Common Mode Voltage ±2 V

Display Range

0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar

(0 PSI to 250 PSI) subject to limits of the sensor and sensor

configuration

2.8.2.2 ANALOGUE INPUT B

Input Type

Flexible: Configured for Coolant Temperature in the DSE default configuration. Flexible Options: Not used, Digital Input, Flexible Analogue & Coolant Temperature

Flexible Input Selection

Pressure Sensor Percentage Sensor Temperature Sensor

Measurement Type

Resistance measurement by measuring voltage across sensor with a

fixed current applied Arrangement Differential resistance measurement input Measurement Current 11 mA ±10 % Full Scale

480 Ω Over Range / Fail

540 Ω Resolution

1 °C (2 °F) Accuracy

+/-2 % of full scale resistance (±9.6 Ω) excluding transducer error Max Common Mode Voltage ±2 V

Display Range

0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar

(0 PSI to 250 PSI) subject to limits of the sensor and sensor

configuration

Specification

Page 15 of 94 057-236 ISSUE: 1

2.8.2.3 ANALOGUE INPUT C

Input Type

Flexible: Configured for Fuel Level Sensor in the DSE default configuration Flexible Options: Not used, Digital Input, Flexible Analogue & Fuel Level Sensor

Flexible Input Selection

Pressure Sensor Percentage Sensor Temperature Sensor

Measurement Type

Resistance measurement by measuring voltage across sensor with

a fixed current applied Arrangement Differential resistance measurement input Measurement Current 11 mA ±10 % Full Scale

480 Ω Over Range / Fail

540 Ω Resolution 1 % Accuracy

+/-2 % of full scale resistance (±9.6 Ω) excluding transducer error Max Common Mode Voltage ±2 V

Display Range

0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar

(0 PSI to 250 PSI) subject to limits of the sensor and sensor

configuration

2.8.2.4 ANALOGUE INPUT D

Input Type

Flexible: Configured for Flexible Sensor, Pressure Sensor in the DSE default configuration. Flexible Options: Not used, Digital Input, Flexible Analogue & Oil Sensor

Flexible Input Selection

Pressure Sensor Percentage Sensor Temperature Sensor

Measurement Type

Resistance measurement by measuring voltage across sensor with a

fixed current applied Arrangement Differential resistance measurement input Measurement Current 11 mA ±10 % Full Scale

240 Ω Over Range / Fail

270 Ω Resolution 1% Accuracy

±2 % of full scale resistance (±4.8 Ω) excluding transducer error Max Common Mode Voltage ±2 V

Display Range

0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar

(0 PSI to 250 PSI) subject to limits of the sensor and sensor

configuration

Specification

057-236 ISSUE: 1 Page 16 of 94

2.8.3 CHARGE FAIL INPUT

Minimum Voltage 0 V Maximum Voltage 35 V (plant supply) Resolution 0.2 V Accuracy ±1 % of max measured voltage Excitation Active circuit constant power output Output Power 2.5 W nominal at 12 V and 24 V Current At 12V 210 mA Current At 24V 105 mA

The charge fail input is actually a combined input and output. Whenever the generator is required to run, the terminal provides excitation current to the charge alternator field winding.

When the charge alternator is correctly charging the battery, the voltage of the terminal is close to the plant battery supply voltage. In a failed charge situation, the voltage of this terminal is pulled down to a low voltage. It is this drop in voltage that triggers the Charge Failure alarm. The level at which this operates and whether this triggers a warning or shutdown alarm is configurable using the DSE Configuration Suite Software.

2.8.4 MAGNETIC PICKUP

NOTE: DSE supply a suitable magnetic pickup device, available in two body thread lengths: DSE Part number 020-012 - Magnetic Pickup probe 5/8 UNF 2 ½” thread length DSE Part number 020-013 - Magnetic Pickup probe 5/8 UNF 4” thread length

Type Differential input Minimum Voltage 0.5 V RMS Max Common Mode Voltage ±2 V

Maximum Voltage

Clamped to ±70 V by transient suppressers, dissipation not to

exceed1 W. Maximum Frequency 10,000 Hz Resolution 6.25 RPM Accuracy ±25 RPM Flywheel Teeth 10 to 500

Magnetic Pickup devices can often be ‘shared’ between two or more devices. For example, one device can often supply the signal to both the DSE module and the engine governor. The possibility of this depends upon the amount of current that the magnetic pickup can supply.

2.9 OUTPUTS

2.9.1 DC OUTPUTS A & B (FUEL & START)

Type

Normally used as Fuel & Start outputs. Fully configurable for other purposes if the module is configured to control an electronic engine.

Rating 10 A resistive for 10 secs, 5 A resistive continuous at 35 V

2.9.2 CONFIGURABLE DC OUTPUTS C, D, E & F

Type Fully configurable, supplied from DC supply terminal 2. Rating 2 A resistive continuous at 35 V

Specification

Page 17 of 94 057-236 ISSUE: 1

2.10 COMMUNICATION PORTS

USB Port

USB 2.0 Device for connection to PC running DSE configuration suite only. Max distance 6m (18 yards)

CAN Port

NOTE: For additional length, the DSE124 CAN Extender is available. For

more information, refer to DSE Publication: 057-116 DSE124 Operator Manual

Engine CAN Port Standard implementation of ‘Slow mode’, up to 250 K bits/s Non-Isolated. Internal Termination provided (120 Ω) Max distance 40 m (133 feet)

DSENet (Expansion Comms) Port

Non-isolated Data connection 2 wire + common Half Duplex Data direction control for Transmit (by s/w protocol) Baud Rate 115K Internal termination fitted (120 Ω) Max common mode offset ±5 V Max distance 1.2 km (¾ mile)

2.10.1 CAN INTERFACE

NOTE: For further details on connection to electronic engines, refer to DSE Publication:

057-004 Electronic Engines And DSE Wiring

Modules are fitted with the CAN interface as standard and are capable of receiving engine data from engine CAN controllers compliant with the CAN standard. CAN enabled engine controllers monitor the engine’s operating

parameters such as engine speed, oil pressure, engine temperature (among others) in order to closely monitor and control the engine. The industry standard communications interface (CAN) transports data gathered by the engine controller interface. This allows generator controllers to access these engine parameters with no physical connection to the sensor device.

Specification

057-236 ISSUE: 1 Page 18 of 94

2.10.2 USB CONNECTION

NOTE: The DC supply must be connected to the module for configuration by PC.

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & 6120 MKII Configuration Software Manual

The USB port is provided to give a simple means of connection between a PC and the controller. Using the DSE Configuration Suite Software, the operator is then able to control the module, starting or stopping the generator, selecting operating modes, etc.

Additionally, the various operating parameters (such as output volts, oil pressure, etc.) of the remote generator are available to be viewed or changed.

To connect a module to a PC by USB, the following items are required:

• DSE6110 MKII & DSE6120 MKII Controller

• DSE Configuration Suite PC Software

(Supplied on configuration suite software CD or available from www.deepseaplc.com).

• USB cable Type A to Type B. (This is the same cable as often used between a PC and a USB printer)

DSE can supply this cable if required : PC Configuration interface lead (USB type A – type B) DSE Part No 016-125

Specification

Page 19 of 94 057-236 ISSUE: 1

2.10.3 DSENET® (EXPANSION MODULES)

NOTE: As a termination resistor is internally fitted to the controller, the controller must be the ‘first’ unit on the DSENet link. A termination resistor MUST be fitted to the ‘last’ unit on the DSENet® link. For connection details, refer to section entitled Typical Wiring Diagram elsewhere in this document.

NOTE: DSE6110 MKII & DSE6120 MKII modules does not support the DSE2510 or DSE2520 display modules.

DSENet® is the interconnection cable between the host controller and the expansion module(s) and must not be connect to any device other than DSE equipment designed for connection to the DSENet®

Cable Type Two core screened and shielded twisted pair

Cable Characteristics

120 Ω Low capacitance

Recommended Cable

Belden 9841 Belden 9271

Maximum Cable Length

1200 m (¾ mile) when using Belden 9841 or direct equivalent. 600 m (656 yards) when using Belden 9271 or direct equivalent.

DSENet® Topology “Daisy Chain” Bus with no stubs (spurs)

DSENet® Termination

120 Ω. Fitted internally to host controller. Must be fitted externally to the ‘last’ expansion module.

Maximum Expansion Modules

Total 6 devices made up of DSE2130 (up to 2), DSE2157 (up to 2), DSE2548 (up to 2)

This gives the possibility of : Maximum 16 additional relay outputs (DSE2157) Maximum 16 additional LED indicators (DSE2548) Maximum 16 additional inputs (Can be configured as 4 digital inputs & 4 analogue resistive type inputs or 8 digital inputs when using DSE2130)

Specification

057-236 ISSUE: 1 Page 20 of 94

2.11 ADDING AN EXTERNAL SOUNDER

Should an external alarm or indicator be required, this can be achieved by using the DSE Configuration Suite PC software to configure an auxiliary output for Audible Alarm, and by configuring an auxiliary input for Alarm Mute (if required).

The audible alarm output activates and de-activates at the same time as the module’s internal

sounder. The Alarm mute input and internal Lamp Test / Alarm Mute

button activate ‘in parallel’

with each other. Either signal mutes both the internal sounder and audible alarm output.

Example of configuration to achieve external sounder with external alarm mute button:

2.12 ACCUMULATED INSTRUMENTATION

NOTE: When an accumulated instrumentation value exceeds the maximum number as listed below, the value is reset and begins counting from zero again.

Engine Hours Run

Maximum 99999 hrs 59 minutes (Approximately 11yrs 4 months)

Accumulated Power 999999 kWh / kVArh / kVAh

The number of logged Engine Hours and Number of Starts can be set/reset using the DSE Configuration Suite PC software. Depending upon module configuration, this may have been PIN number locked by your generator supplier

Specification

Page 21 of 94 057-236 ISSUE: 1

2.13 DIMENSIONS AND MOUNTING

2.13.1 DIMENSIONS

216 mm x 158 mm x 43 mm (8.5” x 6.2” x 1.7”)

2.13.2 PANEL CUTOUT

184 mm x 137 mm (7.2” x 5.3”)

2.13.3 WEIGHT

0.45 kg (1.00 lb)

218 mm (8. 5 “) 43 mm (1.7 “)

33 mm (1.3 “)

158 mm (6.2 “)

Specification

057-236 ISSUE: 1 Page 22 of 94

2.13.4 FIXING CLIPS

NOTE: In conditions of excessive vibration, mount the module on suitable anti-vibration mountings.

The module is held into the panel fascia using the supplied fixing clips.

• Withdraw the fixing clip screw (turn anticlockwise) until only the pointed end is protruding from the clip.

• Insert the three ‘prongs’ of the fixing clip into the slots in the side of the module case.

• Pull the fixing clip backwards (towards the back of the module) ensuring all three prongs of

the clip are inside their allotted slots.

• Turn the fixing clip screws clockwise until they make contact with the panel fascia.

• Turn the screws a little more to secure the module into the panel fascia. Care should be

taken not to over tighten the fixing clip screws.

Fixing clip

fitted to module

Fixing clip

Specification

Page 23 of 94 057-236 ISSUE: 1

2.13.5 SILICON SEALING GASKET

NOTE: For purchasing a silicon gasket from DSE, see the section entitled Maintenance,

Spares, Repair and Servicing elsewhere in this document.

The optional silicon gasket provides improved sealing between module and the panel fascia. The gasket is fitted to the module before installation into the panel fascia. Take care to ensure the gasket is correctly fitted to the module to maintain the integrity of the seal.

Gasket fitted

to module

Sealing gasket

Specification

057-236 ISSUE: 1 Page 24 of 94

2.13.6 APPLICABLE STANDARDS

BS 4884-1

This document conforms to BS4884-1 1992 Specification for presentation of essential information.

BS 4884-2 This document conforms to BS4884-2 1993 Guide to content BS 4884-3 This document conforms to BS4884-3 1993 Guide to presentation BS EN 60068-2-1

(Minimum temperature)

-30 °C (-22 °F)

BS EN 60068-2-2

(Maximum temperature)

+70 °C (158 °F)

BS EN 60950

Safety of information technology equipment, including electrical business equipment

BS EN 61000-6-2

EMC Generic Immunity Standard (Industrial)

BS EN 61000-6-4

EMC Generic Emission Standard (Industrial)

BS EN 60529 (Degrees of protection provided by enclosures)

IP65 (front of module when installed into the control panel with the optional sealing gasket) IP42 (front of module when installed into the control panel WITHOUT being sealed to the panel)

UL508 NEMA rating

(Approximate)

12 (Front of module when installed into the control panel with the optional sealing gasket). 2 (Front of module when installed into the control panel WITHOUT being sealed to the panel)

IEEE C37.2

(Standard Electrical Power System Device Function Numbers and Contact Designations)

Under the scope of IEEE 37.2, function numbers can also be used to represent functions in microprocessor devices and software programs. The controller is device number 11L-8000 (Multifunction device protecting Line (generator) –module).

As the module is configurable by the generator OEM, the functions covered by the module vary. Under the module’s factory configuration, the device numbers included within the module are :

2 – Time Delay Starting Or Closing Relay 3 – Checking Or Interlocking Relay 5 – Stopping Device 6 – Starting Circuit Breaker 8 – Control Power Disconnecting Device 10 – Unit Sequence Switch 11 – Multifunction Device 12 – Overspeed Device 14 – Underspeed Device 26 – Apparatus Thermal Device 27AC – AC Undervoltage Relay 27DC – DC Undervoltage Relay 29 – Isolating Contactor Or Switch 30 – Annunciator Relay 31 – Separate Excitation Device 42 – Running Circuit Breaker

Continued overleaf...

Specification

Page 25 of 94 057-236 ISSUE: 1

IEEE C37.2

(Standard Electrical Power System Device Function Numbers and Contact Designations)

Continued

50 – Instantaneous Overcurrent Relay 52 – AC Circuit Breaker 53 – Exciter Or DC Generator Relay 54 – Turning Gear Engaging Device 59AC – AC Overvoltage Relay 59DC – DC Overvoltage Relay 62 – Time Delay Stopping Or Opening Relay 63 – Pressure Switch 71 – Level Switch 74 – Alarm Relay 81 – Frequency Relay 83 – Automatic Selective Control Or Transfer Relay 86 – Lockout Relay

In line with our policy of continual development, Deep Sea Electronics, reserve the right to change specification without notice.

Specification

057-236 ISSUE: 1 Page 26 of 94

2.13.7 ENCLOSURE CLASSIFICATIONS

2.13.7.1 IP CLASSIFICATIONS

The modules specification under BS EN 60529 Degrees of protection provided by enclosures

IP65 (Front of module when module is installed into the control panel with the optional sealing gasket).

IP42 (front of module when module is installed into the control panel WITHOUT being sealed to the panel)

First Digit Second Digit

Protection against contact and ingress of solid objects Protection against ingress of water

0 No protection 0 No protection

1 Protected against ingress solid objects with a

diameter of more than 50 mm. No protection against deliberate access, e.g. with a hand, but large surfaces of the body are prevented from approach.

1 Protection against dripping water falling vertically. No harmful

effect must be produced (vertically falling drops).

2 Protected against penetration by solid objects with a

diameter of more than 12 mm. Fingers or similar objects prevented from approach.

2 Protection against dripping water falling vertically. There

must be no harmful effect when the equipment (enclosure) is tilted at an angle up to 15° from its normal position (drops falling at an angle).

3 Protected against ingress of solid objects with a

diameter of more than 2.5 mm. Tools, wires etc. with a thickness of more than 2.5 mm are prevented from approach.

3 Protection against water falling at any angle up to 60° from

the vertical. There must be no harmful effect (spray water).

4 Protected against ingress of solid objects with a

diameter of more than 1 mm. Tools, wires etc. with a thickness of more than 1 mm are prevented from approach.

4 Protection against water splashed against the equipment

(enclosure) from any direction. There must be no harmful effect (splashing water).

5 Protected against harmful dust deposits. Ingress of

dust is not totally prevented but the dust must not enter in sufficient quantity to interface with satisfactory operation of the equipment. Complete protection against contact.

5 Protection against water projected from a nozzle against the

equipment (enclosure) from any direction. There must be no harmful effect (water jet).

6 Protection against ingress of dust (dust tight).

Complete protection against contact.

6 Protection against heavy seas or powerful water jets. Water

must not enter the equipment (enclosure) in harmful quantities (splashing over).

Specification

Page 27 of 94 057-236 ISSUE: 1

2.13.7.2 NEMA CLASSIFICATIONS

THE MODULES NEMA RATING (APPROXIMATE)

12 (Front of module when module is installed into the control panel with the optional sealing gasket).

2 (front of module when module is installed into the control panel WITHOUT being sealed to the panel)

NOTE: There is no direct equivalence between IP / NEMA ratings. IP figures shown are

approximate only.

IP30

Provides a degree of protection against contact with the enclosure equipment and against a limited amount of falling dirt.

IP31

Provides a degree of protection against limited amounts of falling water and dirt.

IP64

Provides a degree of protection against windblown dust, rain and sleet; undamaged by the formation of ice on the enclosure.

IP32

Provides a degree of protection against rain and sleet:; undamaged by the formation of ice on the enclosure.

4 (X)

IP66

Provides a degree of protection against splashing water, windblown dust and rain, hose directed water; undamaged by the formation of ice on the enclosure. (Resist corrosion).

12/12K

IP65

Provides a degree of protection against dust, falling dirt and dripping non corrosive liquids.

IP65

Provides a degree of protection against dust and spraying of water, oil and non corrosive coolants.

Installation

057-236 ISSUE: 1 Page 28 of 94

3 INSTALLATION

The module is designed to be mounted on the panel fascia. For dimension and mounting details, see the section entitled Specification, Dimension and mounting elsewhere in this document.

3.1 TERMINAL DESCRIPTION

NOTE: Availability of some terminals depends upon module version. Full details are

given in the section entitled Terminal Description elsewhere in this manual.

To aid user connection, icons are used on the rear of the module to help identify terminal functions. An example of this is shown below.

Terminals 1-10 Terminals 11-21

Terminals 38-43

USB

PC Configuration

Terminals 33-37 UL Ratings

Terminals 22-24

Terminals 25-32

Installation

Page 29 of 94 057-236 ISSUE: 1

3.1.1 DC SUPPLY, ESTOP INPUT, DC OUTPUTS & CHARGE FAIL INPUT

NOTE: When the module is configured for operation with an electronic engine, FUEL and START output requirements may be different. For further details on connection to electronic engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & 6120 MKII Configuration Software Manual.

Description

Cable

Size

Notes

DC Plant Supply Input (Negative)

2.5 mm²

AWG 13

DC Plant Supply Input (Positive)

2.5 mm²

AWG 13

Supplies the module and DC Outputs A, B, C, D, E & F

3 Emergency Stop Input

2.5 mm²

AWG 13

Plant Supply Positive. Also supplies DC Outputs A & B. (Recommended Maximum Fuse 20 A)

4 DC Output A (FUEL)

2.5 mm²

AWG 13

Plant Supply Positive from terminal 2. 10 A for 10 seconds, 5 A resistive continuous Fixed as FUEL relay if electronic engine is not configured.

5 DC Output B (START)

2.5 mm²

AWG 13

Plant Supply Positive from terminal 2. 10 A for 10 seconds, 5 A resistive continuous Fixed as START relay if electronic engine is not configured.

6 Charge Fail / Excite

2.5 mm²

AWG 13

Do not connect to ground (battery negative). If charge alternator is not fitted, leave this terminal disconnected.

7 DC Output C

1.0 mm²

AWG 18

Plant Supply Positive from terminal 2. 2 A rated.

8 DC Output D

1.0 mm²

AWG 18

Plant Supply Positive from terminal 2. 2 A rated.

9 DC Output E

1.0 mm²

AWG 18

Plant Supply Positive from terminal 2. 2 A rated.

10 DC Output F

1.0 mm²

AWG 18

Plant Supply Positive from terminal 2. 2 A rated.

Installation

057-236 ISSUE: 1 Page 30 of 94

3.1.2 ANALOGUE SENSORS, MPU, CAN

NOTE: It is VERY important that terminal 11 (sensor common) is soundly connected to an earth point on the ENGINE BLOCK, not within the control panel, and must be a sound electrical connection to the sensor bodies. This connection MUST NOT be used to provide an earth connection for other terminals or devices. The simplest way to achieve this is to run a SEPARATE earth connection from the system earth star point, to terminal 11 directly, and not use this earth for other connections.

NOTE: If you use PTFE insulating tape on the sensor thread when using earth return sensors, ensure you do not insulate the entire thread, as this prevents the sensor body from being earthed via the engine block.

NOTE: For further details on connection to electronic engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring

NOTE: Screened 120 ΩΩΩΩ impedance cable specified for use with CAN must be used for the CAN link. DSE stock and supply Belden cable 9841 which is a high quality 120 ΩΩΩΩ impedance cable suitable for CAN use (DSE part number 016-030)

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & 6120 MKII Configuration Software Manual.

Description

Cable

Size

Notes

11 Sensor Common Return

0.5 mm²

AWG 20

Return Feed For Sensors

12 Oil Pressure Input

0.5 mm²

AWG 20

Connect To Oil Pressure Sensor

13 Coolant Temperature Input

0.5mm²

AWG 20

Connect To Coolant Temperature Sensor

14 Fuel Level Input

0.5 mm²

AWG 20

Connect To Fuel Level Sensor

15 Flexible Sensor Input

0.5 mm²

AWG 20

Connect To Additional Sensor (User Configurable)

16 Magnetic Pickup Positive

0.5 mm²

AWG 20

Connect To Magnetic Pickup Device

17 Magnetic Pickup Negative

0.5 mm²

AWG 20

Connect To Magnetic Pickup Device

18 Magnetic Pickup Screen Shield Connect To Ground At One End Only

19 CAN Port H

0.5 mm²

AWG 20

Use Only 120 Ω CAN Approved Cable

20 CAN Port L

0.5 mm²

AWG 20

Use Only 120 Ω CAN Approved Cable

21 CAN Port Screen Shield Use Only 120 Ω CAN Approved Cable

Installation

Page 31 of 94 057-236 ISSUE: 1

3.1.3 DSENET®

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & 6120 MKII Configuration Software Manual.

Description

Cable

Size

Notes

22 DSENet Expansion B

0.5 mm²

AWG 20

Use only 120 Ω CAN and RS485 approved cable

23 DSENet Expansion A

0.5 mm²

AWG 20

Use only 120 Ω CAN and RS485 approved cable

DSENet Expansion Screen

Shield

Use only 120 Ω CAN and RS485 approved cable

3.1.4 GENERATOR / MAINS VOLTAGE & FREQUENCY SENSING

NOTE: Terminals 29 to 32 not fitted to DSE6110 MKII

NOTE: The below table describes connections to a three phase, four wire alternator. For alternative wiring topologies, see the section entitled Alternate Topology Wiring Diagrams elsewhere in this document.

Description

Cable

Size

Notes

Generator L1 (U) Voltage Monitoring

1.0 mm²

AWG 18

Connect to generator L1 (U) output (AC) (Recommend 2 A fuse)

Generator L2 (V) Voltage Monitoring

1.0 mm²

AWG 18

Connect to generator L2 (V) output (AC) (Recommend 2 A fuse)

Generator L3 (W) Voltage Monitoring

1.0 mm²

AWG 18

Connect to generator L3 (W) output (AC) (Recommend 2 A fuse)

28 Generator Neutral (N) Input

1.0 mm²

AWG 18

Connect to generator Neutral terminal (AC)

29 Mains L1 (R) Voltage Monitoring

1.0 mm²

AWG 18

Connect to Mains L1 (R) output (AC) (Recommend 2 A fuse)

30 Mains L2 (S) Voltage Monitoring

1.0 mm²

AWG 18

Connect to Mains L2 (S) output (AC) (Recommend 2 A fuse)

31 Mains L3 (T) Voltage Monitoring

1.0 mm²

AWG 18

Connect to Mains L3 (T) output (AC) (Recommend 2 A fuse)

32 Mains Neutral (N) Input

1.0 mm²

AWG 18

Connect to Mains Neutral terminal (AC)

Installation

057-236 ISSUE: 1 Page 32 of 94

3.1.5 CURRENT TRANSFORMERS

WARNING!: Do not disconnect this plug when the CTs are carrying current. Disconnection open circuits the secondary of the C.T.’s and dangerous voltages may then develop. Always ensure the CTs are not carrying current and the CTs are short circuit connected before making or breaking connections to the module.

NOTE: The module has a burden of 0.5VA on the CT. Ensure the CT is rated for the burden of the controller, the cable length being used and any other equipment sharing the CT. If in doubt, consult your CT supplier.

Description

Cable

Size

Notes

33 CT Secondary for L1

2.5 mm²

AWG 13

Connect to s1 secondary of L1 monitoring CT

34 CT Secondary for L2

2.5 mm²

AWG 13

Connect to s1 secondary of L2 monitoring CT

35 CT Secondary for L3

2.5 mm²

AWG 13

Connect to s1 secondary of L3 monitoring CT

CT Common

2.5 mm²

AWG 13

Connect to s2 secondary of L1, L2 & L3 monitoring CTs and ground

3.1.5.1 CT CONNECTIONS

p1, k or K is the primary of the CT that ‘points’ towards the GENERATOR

p2, l or L is the primary of the CT that ‘points’ towards the Load

s1 is the secondary of the CT that connects to the DSE Module’s input for the CT measuring

s2 is the secondary of the CT that should be commoned with the s2 connections of all the other CTs and connected to the CT common terminal of the module.

TO GENERATOR

TO LOAD

POLARITY OF CT PRIMARY

Labelled as

p1,

or K

Labelled as

p2,

or L

Installation

Page 33 of 94 057-236 ISSUE: 1

3.1.6 CONFIGURABLE DIGITAL INPUTS

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & 6120 MKII Configuration Software Manual.

Description

Cable

Size

Notes

38 Configurable Digital Input A

0.5 mm²

AWG 20

Switch To Negative

39 Configurable Digital Input B

0.5 mm²

AWG 20

Switch To Negative

40 Configurable Digital Input C

0.5 mm²

AWG 20

Switch To Negative

41 Configurable Digital Input D

0.5 mm²

AWG 20

Switch To Negative

42 Configurable Digital Input E

0.5 mm²

AWG 20

Switch To Negative

43 Configurable Digital Input F

0.5 mm²

AWG 20

Switch To Negative

3.1.7 PC CONFIGURATION INTERFACE CONNECTOR

NOTE: The USB connection cable between the PC and the module must not be extended beyond 5 m (yards). For distances over 5 m, it is possible to use a third party USB extender. Typically, they extend USB up to 50 m. The supply and support of this type of equipment is outside the scope of Deep Sea Electronics PLC.

CAUTION!: Care must be taken not to overload the PCs USB system by connecting more than the recommended number of USB devices to the PC. For further information, consult your PC supplier.

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & 6120 MKII Configuration Software Manual.

Description

Cable

Size

Notes

Socket for connection to PC with DSE Configuration Suite Software

0.5 mm²

AWG 20

This is a standard USB type A to type B connector.

Installation

057-236 ISSUE: 1 Page 34 of 94

3.2 TYPICAL WIRING DIAGRAM

As every system has different requirements, these diagrams show only a TYPICAL system and do not intend to show a complete system.

Genset manufacturers and panel builders may use these diagrams as a starting point; however, you are referred to the completed system diagram provided by your system manufacturer for complete wiring detail.

Further wiring suggestions are available in the following DSE publications, available at www.deepseaplc.com to website members.

DSE Part Description

056-022 Breaker Control (Training guide) 057-004 Electronic Engines and DSE Wiring

Installation

Page 35 of 94 057-236 ISSUE: 1

3.2.1 DSE6110 MKII TYPICAL WIRING DIAGRAM (3 PHASE 4 WIRE)

Installation

057-236 ISSUE: 1 Page 36 of 94

3.2.2 DSE6120 MKII TYPICAL WIRING DIAGRAM (3 PHASE 4 WIRE)

Installation

Page 37 of 94 057-236 ISSUE: 1

3.3 ALTERNATE TOPOLOGY WIRING DIAGRAMS

3.3.1 GENERATOR

Installation

057-236 ISSUE: 1 Page 38 of 94

3.3.2 MAINS (6120 MKII ONLY)

Installation

Page 39 of 94 057-236 ISSUE: 1

3.4 EARTH SYSTEMS

3.4.1 NEGATIVE EARTH

The typical wiring diagrams located within this document show connections for a negative earth system (the battery negative connects to Earth)

3.4.2 POSITIVE EARTH

When using a DSE module with a Positive Earth System (the battery positive connects to Earth), the following points must be followed:

• Follow the typical wiring diagram as normal for all sections EXCEPT the earth points

• All points shown as Earth on the typical wiring diagram should connect to BATTERY

NEGATIVE (not earth).

3.4.3 FLOATING EARTH

Where neither the battery positive nor battery negative terminals are connected to earth the following points must to be followed

• Follow the typical wiring diagram as normal for all sections EXCEPT the earth points

• All points shown as Earth on the typical wiring diagram should connect to BATTERY

NEGATIVE (not earth).

Installation

057-236 ISSUE: 1 Page 40 of 94

3.5 TYPICAL ARRANGEMENT OF DSENET®

NOTE: For further details of module configuration, refer to DSE Publication: 057-224 DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

Six (6) devices can be connected to the DSENet®, made up of the following devices :

Device Maximum Number Supported

DSE2130 Input Expansion 2 DSE2157 Relay Output Expansion 2 DSE2548 LED Expansion 2

Description Of Controls

Page 41 of 94 057-236 ISSUE: 1

4 DESCRIPTION OF CONTROLS

CAUTION: The module may instruct an engine start event due to external influences. Therefore, it is possible for the engine to start at any time without warning. Prior to performing any maintenance on the system, it is recommended that steps are taken to remove the battery and isolate supplies.

NOTE: The following descriptions detail the sequences followed by a module containing the standard ‘factory configuration’. Always refer to your configuration source for the exact sequences and timers observed by any particular module in the field.

Control of the module is via push buttons mounted on the front of the module with

Stop/Reset Mode

, Manual Mode , Test Mode (DSE6120 MKII Only), Auto Mode and

Start

functions. For normal operation, these are the only controls which need to be operated.

Details of their operation are provided later in this document.

Description Of Controls

057-236 ISSUE: 1 Page 42 of 94

4.1 DSE6110 MKII

Navigation

Module Display

Stop / Reset

Mode

Manual

Mode

Auto

Mode

Alarm Mute

& Lamp Test

Start

Fault LED.

constant on warning

and flash upon

Electrical Trip and

Shutdown Fault

Generator

(Manual Mode

Only)

Open

Generator

(Manual Mode

Only)

Generator

Breaker LED

Selected Mode

Indication LED

Generator

Available LED

Description Of Controls

Page 43 of 94 057-236 ISSUE: 1

4.2 DSE6120 MKII

Navigation

Module Display

Stop / Reset

Mode

Manual

Mode

Test

Mode

Auto

Mode

Alarm Mute

& Lamp Test

Start

Fault LED.

constant on warning

and flash upon

Electrical Trip and

hutdown Fault

Transfer to

Generator

(Manual Mode

Only)

Transfer to

Mains

(Manual Mode

Only)

Mains

Breaker LED

Generator

Breaker LED

Selected Mode

Indication LED

Generator

Available LED

Mains

Available LED

Description Of Controls

057-236 ISSUE: 1 Page 44 of 94

4.3 CONTROL PUSH-BUTTONS

Icon Description

Stop / Reset Mode

This button places the module into its Stop/Reset Mode

. This clears any alarm conditions for which the triggering criteria have been removed. If the engine is running and the module is put into Stop mode, the module automatically instructs the generator to unload (Close Generator and Delayed Load Output 1, 2, 3 & 4 become inactive (if used)). The fuel supply de-energises and the engine comes to a standstill. Should any form of remote start signal be present when in Stop Mode the generator remains at rest

Manual Mode

This button places the module into its Manual Mode

. Once in

Manual Mode

, the module responds to the Start button to start the

generator and run it off load.

To place the generator on load, use the Transfer to Generator button. The module automatically instructs the changeover device to place the generator on load (‘Close Generator’ and Delayed Load Output 1, 2, 3 & 4 becomes active (if

used)). To place the generator off load, use the Transfer to Mains

or Open

Generator

buttons. The module automatically instructs the changeover device to place the generator off load (Close Generator and Delayed Load Output 1, 2, 3 & 4 becomes inactive (if used)). Additional digital inputs can be assigned to perform these functions.

If the engine is running off-load in Manual Mode and a remote start signal becomes present, the module automatically instructs the changeover device to place the generator on load (‘Close Generator’ and ‘Delayed Load Output 1, 2, 3 & 4’ becomes active (if used)). Upon removal of the Remote Start Signal, the generator remains on load until either selection of the

Stop/Reset Mode

or Auto Mode .

For further details, please see section entitled ‘Operation’ elsewhere in this manual.

Test Mode (DSE6120 MKII Only)

This button places the module into its Test Mode

. Once in Test Mode , the

module responds to the Start

button to start the generator and run it off load.

Once the set has started the set automatically be placed on load (Close Generator and Delayed Load Output 1, 2, 3 & 4 become active in order from lowest to highest (if used)).

For further details, please see section entitled ‘Operation’ elsewhere in this manual.

Description Of Controls

Page 45 of 94 057-236 ISSUE: 1

Icon Description

Auto Mode

This button places the module into its Auto Mode

. This mode allows the module to control the function of the generator automatically. The module monitors the remote start input and once a start request is made, the set is automatically started and placed on load (Close Generator and Delayed Load Output 1, 2, 3 & 4 become active in order from lowest to highest (if used)).

Upon removal of the starting signal, the module removes the load from the generator and shut the set down observing the stop delay timer and cooling timer as necessary (Close Generator and Delayed Load Output 1, 2, 3 & 4 become

inactive at once (if used)). The module then waits for the next start event.

For further details, please see section entitled Operation elsewhere in this manual.

Alarm Mute / Lamp Test

This button de-activates the audible alarm output (if configured) and illuminates all of the LEDs on the module’s facia.

Start

This button is only active in the Stop/Reset Mode

, Manual Mode and

Test Mode

Pressing the Start

button in Stop/Reset Mode powers up the ECU but does not start the engine. This can be used to check the status of the CAN communication and to prime the fuel system.

Pressing the Start

button in Manual Mode or Test Mode starts the

generator and runs it off load in Manual Mode

or on load in Test Mode .

Description Of Controls

057-236 ISSUE: 1 Page 46 of 94

Icon Description

Menu Navigation

Used for navigating the instrumentation, event log and configuration screens.

For further details, please see section entitled ‘Operation’ elsewhere in this manual.

Transfer To Generator

This button is only active in the Manual Mode

and allows the operator to

transfer the load to the generator.

Open Generator (DSE6110 MKII Only)

This button is only active in the Manual Mode

and allows the operator to open

the generator breaker and remove the load.

Transfer To Mains (DSE6120 MKII Only)

This button is only active in the Manual Mode

and allows the operator to

transfer the load to the mains.

Description Of Controls

Page 47 of 94 057-236 ISSUE: 1

4.4 VIEWING THE INSTRUMENT PAGES

NOTE: Depending upon the module’s configuration, some display screens may be disabled. For further details of module configuration, refer to DSE Publication: 057-224 DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

It is possible to scroll to display the different pages of information by pressing and holding either of

the Menu Navigation

buttons for two seconds to move to the next or previous page.

Example

Status

Press

Hold

Generator

Press

Hold

Mains

And so on until the desired page is reached.

A further presses and holds of the Scroll Up button returns the Status page.

The complete order and contents of each information page are given in the following sections

Once selected, the page remains on the LCD display until the user selects a different page, or after an extended period of inactivity (LCD Page Timer), the module reverts to the status display.

If no buttons are pressed upon entering an instrumentation page, the instruments displayed are automatically subject to the setting of the LCD Scroll Timer.

The LCD Page and LCD Scroll timers are configurable using the DSE Configuration Suite Software or by using the Front Panel Editor.

The screenshot below shows the factory settings for the timers, taken from the DSE Configuration Suite PC Software.

Alternatively, to scroll manually through all instruments on the currently selected page, press either of

the Menu Navigation

buttons. The ‘auto scroll’ is disabled.

To re-enable ‘auto scroll’ press and hold either of the Menu Navigation

buttons to scroll to the ‘title’ of the instrumentation page (ie Engine). A short time later (the duration of the LCD Scroll Timer), the instrumentation display begins to auto scroll.

When scrolling manually, the display automatically returns to the Status page if no buttons are pressed for the duration of the configurable LCD Page Timer.

If an alarm becomes active while viewing the status page, the display shows the Alarms page to draw the operator’s attention to the alarm condition.

If you want to view one of the instrument pages

towards the end of the list, it may be quicker to scroll

down through the pages rather than right!

Description Of Controls

057-236 ISSUE: 1 Page 48 of 94

4.4.1 STATUS

This is the ‘home’ page, the page that is displayed when no other page has been selected, and the page that is automatically displayed after a period of inactivity (LCD Page Timer) of the module control buttons.

This page changes with the action of the controller, when the engine is running, that target speed is be displayed.

Status 22:31

Factory setting of Status screen showing engine stopped...

Engine at Rest

Stop Mode

Status 22:31

...and engine running

Generator Available

The contents of this display vary depending upon configuration by the engine manufacturer or supplier.

The display above is achieved with the factory settings, shown below in the DSE Configuration suite software:

4.4.1.1 GENERATOR LOCKED OUT

Status 22:31

Generator Locked Out indicates that the Generator cannot be started due to an active Shutdown or Electrical Trip Alarm on the

module. Press and hold either of the Menu Navigation buttons to scroll to the alarms page to investigate. Press the

Stop/Reset Mode button to clear the alarm, if the alarm does not clear the fault is still active.

Generator Locked Out

‘Stop Mode’ and generator

status is displayed on the

Home Page

With a summary of the

instrumentation shown

when the engine is running.

Other pages can be

configured to be shown,

automatically scrolling

when the set is running.

Description Of Controls

Page 49 of 94 057-236 ISSUE: 1

4.4.2 ENGINE

NOTE*: For further details of support engine, refer to DSE Publication: 057-004

Electronic Engines and DSE Wiring Guide.

These pages contain instrumentation gathered about the engine measured or derived from the module’s inputs, some of which may be obtained from the engine ECU.

Engine

1500 RPM

• Engine Speed

• Oil Pressure

• Coolant Temperature

• Engine Battery Volts

• Engine Run Time

• Engine Fuel Level

• Oil Temperature*

• Coolant Pressure*

• Inlet Temperature*

• Exhaust Temperature*

• Fuel Temperature*

• Turbo Pressure*

• Fuel Pressure*

• Fuel Consumption*

• Fuel Used*

• Fuel Level*

• Flexible Sensors

• Engine Maintenance Alarm 1

• Engine Maintenance Alarm 2

• Engine Maintenance Alarm 3

• Engine ECU Link*

• Tier 4 Engine Information*

Description Of Controls

057-236 ISSUE: 1 Page 50 of 94

4.4.3 GENERATOR

These pages contain electrical values of the generator, measured or derived from the module’s voltage inputs.

Generator

50.0

• Generator Voltage (ph-N)

• Generator Voltage (ph-ph)

• Generator Frequency

• Generator Current (A)

• Generator Load ph-N (kW)

• Generator Total Load (kW)

• Generator Load ph-N (kVA)

• Generator Total Load (kVA)

• Generator Power Factor Average

• Generator Load ph-N (kVAr)

• Generator Total Load (kVAr)

• Generator Accumulated Load (kWh, kVAh, kVArh)

• Generator Phase Sequence

• Active Configuration

4.4.4 MAINS (DSE6120 MKII ONLY)

NOTE*: Mains current and powering monitoring is only available when the CTs are configured for, and placed in the load. For further details of module configuration, refer to DSE Publication: 057-224 DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

These Pages contain electrical values of the mains, measured or derived from the module’s voltage inputs.

Mains

50.0

• Mains Voltage (ph-N)

• Mains Voltage (ph-ph)

• Mains Frequency

• Mains Current (A)*

• Mains Phase Sequence

• Mains Load ph-N (kW)*

• Mains Total Load (kW)*

• Mains Load ph-N (kVA)*

• Mains Total Load (kVA)*

• Mains Single Phase Power Factor*

• Mains Average Power Factor*

• Mains Load ph-N (kVAr)*

• Mains Total Load (kVAr)*

• Mains Accumulated Load (kWh, kVAh, kVArh)*

Description Of Controls

Page 51 of 94 057-236 ISSUE: 1

4.4.5 EXPANSION

When input expansion modules are configured, these pages contain measured values derived from the expansion analogue inputs.

Oil Temperature

80 °C

176 °F

• DSE2130 ID0 Analogue Input E

• DSE2130 ID0 Analogue Input F

• DSE2130 ID0 Analogue Input G

• DSE2130 ID0 Analogue Input H

• DSE2130 ID1 Analogue Input E

• DSE2130 ID1 Analogue Input F

• DSE2130 ID1 Analogue Input G

• DSE2130 ID1 Analogue Input H

Description Of Controls

057-236 ISSUE: 1 Page 52 of 94

4.4.6 ALARMS

When an alarm is active, the Common Alarm LED, illuminates and a message appears on the module’s display. If configured, the external audible alarm also sounds.

The external audible alarm is silenced by pressing the Alarm Reset / Lamp Test

button.

The LCD display jumps from the ‘Information page’ to display the Alarm Page

1/2 Alarms

Low Oil Pressure

Warning

The LCD displays multiple alarms such as “Coolant Temperature High”, “Emergency Stop” and “Low Coolant Warning”. These automatically scroll in the order that they occurred.

In the event of an alarm, the LCD displays the appropriate text. If an additional alarm then occurs, the module displays the appropriate text.

Example:

1/2 Alarms

2/2 Alarms

Low Oil Pressure

Warning

Coolant Temperature High

Shutdown

The type of alarm, e.g. Warning

The cause of alarm, e.g. Low Oil Pressure

Number of active alarms. This is

alarm 1 of a total of 2 active alarms

Description Of Controls

Page 53 of 94 057-236 ISSUE: 1

4.4.6.1 ECU ALARMS (CAN ERROR MESSAGE / DTC)

NOTE: For details on these code meanings, refer to the ECU instructions provided by the engine manufacturer, or contact the engine manufacturer for further assistance.

NOTE: For further details on connection to electronic engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring

When connected to a suitable CAN engine, the controller displays alarm status messages from the ECU.

1/1 Alarms

ECU Amber

Warning

Press and hold the Scroll Down

button to access the list of current active Engine DTCs

(Diagnostic Trouble Codes) from the ECU.

Engine DTCs

The code is interpreted by the module and shows on the display as a text message. Additionally, the manufacturer’s fault code is shown below.

Water Level Low

###,###,###

Type of alarm that is

triggered on the DSE

module, e.g. Warning

Description Of Controls

057-236 ISSUE: 1 Page 54 of 94

4.4.7 EVENT LOG

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

The module maintains a log of past alarms and/or selected status changes. The log size has been increased in the module over past module updates and is always subject to change. At the time of writing, the modules log is capable of storing the last 50 log entries.

Under default factory settings, the event log is configured to include all possible options; however, this is configurable by the system designer using the DSE Configuration Suite software.

When the event log is full, any subsequent event overwrites the oldest entry. Hence, the event log always contains the most recent events. The module logs the event type, along with the date and time (or engine running hours if configured to do so).

To view the event log, press and hold either of the Menu Navigation

buttons to scroll to the

Event Log page.

1 Event Log

Oil Pressure Low Shutdown Warning

Press the Scroll Down

button to view the next most recent event.

Continuing to press the Scroll Down

button cycles through the past events after which, the display shows the most recent alarm and the cycle begins again. To exit the event log and return to viewing the instruments, press and hold either of the

Menu Navigation buttons to select the next instrumentation page.

Example showing the possible

configuration of the event log

(DSE Configuration Suite

Software).

This also shows the factory

settings of the module.

This is event 1

Description Of Controls

Page 55 of 94 057-236 ISSUE: 1

4.4.8 LCD INICATORS

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

These LCD Indicators are configured by the user to indicate any one of 100+ different functions based around the following:-

• Indications - Monitoring of a digital input and indicating associated functioning user’s equipment -

Such as Battery Charger On or Louvres Open, etc.

• Warnings, Electrical Trip & Shutdowns Alarms - Specific indication of a particular warning or

shutdown condition, backed up by LCD indication - Such as Low Oil Pressure Shutdown, Low

Coolant level, etc.

• Status Indications - Indication of specific functions or sequences derived from the modules

operating state - Such as Safety On, Pre-heating, Panel Locked, etc.

The display below example screen is achieved using the settings shown in the below screen shot of the DSE Configuration Suite Software:

LCD Indicators

Remote Start Active

Auto Start Inhibit

Louvre Control

4.4.9 USER DEFINED STRINGS

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

The user define strings are intended to contain generic important information about the generator such as oil service internal information. The contents of these screens vary depending upon configuration by the engine manufacturer or supplier.

Under default factory settings the support strings are not viewable. They are configurable by the system designer using the DSE Configuration Suite software.

The display below example screen is achieved using the settings shown in the below screen shot of the DSE Configuration Suite Software:

Oil Service Interval

Every 500 Hours

Every 5 Months

Description Of Controls

057-236 ISSUE: 1 Page 56 of 94

4.4.10 ABOUT

4.4.10.1 MODULE INFORMATION

Contains important information about the module and the firmware versions. This information may be asked for when contacting DSE Technical Support Department for advice.

About

Variant Application USB ID

6120H V1.1.5 BC614E

Press the Scroll Down

button to access more information about the module.

About

Bootloader Analogue

V1.4.0 V2.0.1

About

Engine Type Version

Volvo EMS2b V1.21

4.4.10.2 SUPPORT STRINGS

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

The support string pages are intended to contain important information about the generator supplier company such as contact information. The contents of these screens vary depending upon configuration by the engine manufacturer or supplier.

Under default factory settings the support strings are not viewable. They are configurable by the system designer using the DSE Configuration Suite software.

The display below example screen is achieved using the settings shown in the below screen shot of the DSE Configuration Suite Software:

Support

Deep Sea Electronics +44 (0)1723 890099 support@deepseaplc.com

• Variant (61xx MKII)

• Application Version – The version of the module’s

main firmware file (Updatable using the Firmware Update Wizard in the DSE Configuration Suite Software).

• USB ID – Unique identifier for PC USB connection

• Bootloader - Firmware Update bootloader software

version

• Analogue – Analogue measurements software version

• Engine Type – The name of the engine file selected in the configuration

• Engine – Engine type file version.

Operation

Page 57 of 94 057-236 ISSUE: 1

5 OPERATION

5.1 QUICKSTART GUIDE

This section provides a quick start guide to the module’s operation.

5.1.1 STARTING THE ENGINE

NOTE: For further details, see the section entitled ‘OPERATION’ elsewhere in this manual.

...followed by

the Start button

Press the Manual

Mode button...

Operation

057-236 ISSUE: 1 Page 58 of 94

5.1.2 STOPPING THE ENGINE

NOTE: For further details, see the section entitled ‘OPERATION’ elsewhere in this manual.

Select Stop/Reset

mode. The

generator is stopped

Operation

Page 59 of 94 057-236 ISSUE: 1

5.2 STOP/RESET MODE

NOTE: If a digital input configured to Panel Lock is active, changing module modes is not possible. Viewing the instruments and event logs is NOT affected by Panel Lock.

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

Stop/Reset Mode is activated by pressing the Stop/Reset Mode

button.

In Stop/Reset Mode

, the module removes the generator from load (if necessary) before stopping

the engine if it is already running.

If the engine does not stop when requested, the Fail To Stop alarm is activated (subject to the setting of the Fail to Stop timer). To detect the engine at rest the following must occur :

• Engine speed is zero as detected by the CAN ECU

• Generator AC Voltage and Frequency must be zero.

• Engine Charge Alternator Voltage must be zero.

• Oil pressure sensor must indicate low oil pressure

When the engine has stopped, it is possible to send configuration files to the module from DSE Configuration Suite PC software and to enter the Front Panel Editor to change parameters.

Any latched alarms that have been cleared are reset when Stop/Reset Mode

is entered.

The engine is not started when in Stop/Reset Mode

. If remote start signals are given, the input is

ignored until Auto Mode

is entered.

When left in Stop/Reset Mode

with no presses of the fascia buttons and configured for Power Save Mode, the module enters Power Save Mode. To ‘wake’ the module, press any fascia control buttons.

Power Save Mode in the

DSE Configuration Suite

Software

Operation

057-236 ISSUE: 1 Page 60 of 94

5.3 MANUAL MODE

NOTE: If a digital input configured to Panel Lock is active, changing module modes is

not be possible. Viewing the instruments and event logs is NOT affected by panel lock.

Manual Mode is activated by pressing the Manual Mode

button.

In Manual Mode

, the set does not start automatically

To begin the starting sequence, press the Start

button.

5.3.1 STARTING SEQUENCE

NOTE: There is no start delay in this mode of operation.

NOTE: If the unit has been configured for CAN, compatible ECU’s receives the start

command via CAN.

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

The fuel relay is energised and the engine is cranked.

If the engine fails to fire during this cranking attempt then the starter motor is disengaged for the Crank Rest Timer duration after which the next start attempt is made. Should this sequence continue beyond the set Number Of Attempts, the start sequence is terminated and the display shows

Fail to

Start.

The starter motor is disengaged when the engine fires. Speed detection is factory configured to be derived from the AC alternator output frequency, but can additionally be measured from a Magnetic Pickup mounted on the flywheel or from the CANbus link to the engine ECU depending on module configuration.

Additionally, rising oil pressure can be used to disconnect the starter motor (but cannot detect underspeed or overspeed).

After the starter motor has disengaged, the Safety On Delay timer activates, allowing Oil Pressure, High Engine Temperature, Under-speed, Charge Fail and any delayed Auxiliary fault inputs to stabilise without triggering the fault.

Operation

Page 61 of 94 057-236 ISSUE: 1

5.3.2 ENGINE RUNNING

NOTE: The load transfer signal remains inactive until the Oil Pressure has risen. This

prevents excessive wear on the engine.

In Manual Mode

, the load is not transferred to the generator unless a ‘loading request’ is made.

A loading request can come from a number of sources.

• Press the Transfer to Generator button

• Failure of mains supply (DSE6120 MKII only)

• Activation of an auxiliary input that has been configured to Remote Start On Load or Auxiliary

Mains Fail (DSE6120 MKII Only).

• Activation of the inbuilt exercise scheduler if configured for ‘on load’ runs.

Once the generator has been placed on load, it is not automatically removed. To manually remove the load either:

• Press the Open Generator (DSE6110 MKII Only) or Transfer to Mains (DSE6120 MKII Only) button

• Press the Auto Mode

button to return to automatic mode. The set observes all

Auto Mode

start requests and stopping timers before beginning the Auto Mode Stopping

Sequence.

• Press the Stop/Reset Mode button to remove load and stop the generator.

• Activation of an auxiliary input that has been configured to Generator Load Inhibit.

5.3.3 STOPPING SEQUENCE

In Manual Mode

the set does not continue to run until either:

• The Stop/Reset Mode

button is pressed – The delayed load outputs are de-activated

immediately and the set immediately stops.

• The Auto Mode

button is pressed. The set observes all Auto Mode start requests and

stopping timers before beginning the Auto Mode Stopping Sequence.

Operation

057-236 ISSUE: 1 Page 62 of 94

5.4 TEST MODE

NOTE: If a digital input configured to Panel Lock is active, changing module modes is

not be possible. Viewing the instruments and event logs is NOT affected by Panel Lock.

Test Mode is activated by pressing the Test Mode

button.

In Test Mode

, the set does not start automatically.

To begin the starting sequence, press the Start

button.

5.4.1 STARTING SEQUENCE

NOTE: There is no Start Delay in this mode of operation.

NOTE: If the unit has been configured for CAN, compatible ECU’s receives the start

command via CAN.

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

The fuel relay is energised and the engine is cranked.

If the engine fails to fire during this cranking attempt then the starter motor is disengaged for the crank rest duration after which the next start attempt is made. Should this sequence continue beyond the set number of attempts, the start sequence is terminated and the display shows

Fail to Start.

Additionally, rising oil pressure can be used to disconnect the starter motor (but cannot detect underspeed or overspeed).

Operation

Page 63 of 94 057-236 ISSUE: 1

5.4.2 ENGINE RUNNING

NOTE: The load transfer signal remains inactive until the Oil Pressure has risen. This

prevents excessive wear on the engine.

In Test Mode

, the load is automatically transferred to the generator.

Once the generator has been placed on load, it is not automatically removed. To manually remove the load either:

• Press the Manual Mode

button followed by the Open Generator (DSE6110 MKII Only)

or Transfer to Mains

(DSE6120 MKII Only) button.

• Press the Auto Mode

button to return to automatic mode. The set observes all

Auto Mode

start requests and stopping timers before beginning the Auto Mode Stopping

Sequence.

• Press the Stop/Reset Mode button to remove load and stop the generator.

• Activation of an auxiliary input that has been configured to Generator Load Inhibit.

5.4.3 STOPPING SEQUENCE

In Test Mode

the set continues to run until either:

• The Stop/Reset Mode

button is pressed – The delayed load outputs are de-activated

immediately and the set immediately stops.

• The Auto Mode

button is pressed. The set observes all Auto Mode start requests and

stopping timers before beginning the Auto Mode Stopping Sequence.

Operation

057-236 ISSUE: 1 Page 64 of 94

5.5 AUTOMATIC MODE

NOTE: If a digital input configured to external Panel Pock is active, changing module modes is not possible. Viewing the instruments and event logs is NOT affected by Panel Lock.

Auto Mode is activated by pressing the Auto Mode

button.

Auto Mode

allows the generator to operate fully automatically, starting and stopping as required

with no user intervention.

5.5.1 WAITING IN AUTO MODE

If a starting request is made, the starting sequence begins. Starting requests can be from the following sources:

• Failure of mains supply (DSE6120 MKII only)

• Activation of an auxiliary input that has been configured to Remote Start or Auxiliary Mains

Fail (DSE6120 MKII Only).

• Activation of the inbuilt exercise scheduler.

5.5.2 STARTING SEQUENCE

NOTE: If the unit has been configured for CAN, compatible ECU’s receive the start command via CAN and transmit the engine speed to the DSE controller.

NOTE: For further details of module configuration, refer to DSE Publication: 057-224

DSE6110 MKII & DSE6120 MKII Configuration Software Manual.

To allow for ‘false’ start requests, the start delay timer begins.

Should all start requests be removed during the start delay timer, the unit returns to a stand-by state.

If a start request is still present at the end of the start delay timer, the fuel relay is energised and the engine is cranked.

If the engine fails to fire during this cranking attempt then the starter motor is disengaged for the Crank Rest duration after which the next start attempt is made. Should this sequence continue beyond the Set Number Of Attempts, the start sequence is terminated and the display shows

Fail to

Start.

Additionally, rising oil pressure can be used to disconnect the starter motor (but cannot detect underspeed or overspeed).

Operation

Page 65 of 94 057-236 ISSUE: 1

5.5.3 ENGINE RUNNING

NOTE: The load transfer signal remains inactive until the Oil Pressure has risen. This prevents excessive wear on the engine.

The generator is placed on load if configured to do so.

If all start requests are removed, the stopping sequence begins.

5.5.4 STOPPING SEQUENCE

The Return Delay timer operates to ensure that the starting request has been permanently removed and isn’t just a short term removal. Should another start request be made during the cooling down period, the set returns on load.

If there are no starting requests at the end of the Return Delay timer, the load is removed from the generator to the mains supply and the cooling timer is initiated.

The Cooling Down timer allows the set to run off load and cool sufficiently before being stopped. This is particularly important where turbo chargers are fitted to the engine.

After the Cooling Down timer has expired, the set is stopped.

Operation

057-236 ISSUE: 1 Page 66 of 94

5.6 SCHEDULER

The controller contains an inbuilt exercise run scheduler, capable of automatically starting and stopping the set. Up to 8 scheduled start/stop sequences can be configured to repeat on a 7-day or 28-day cycle.

Scheduled runs may be on load or off load depending upon module configuration.

Example

Screen capture from DSE Configuration Suite Software showing the configuration of the Exercise Scheduler.

In this example the set starts at 09:00 on Monday and run for 5 hours, then start at 13:30 on Tuesday and run for 30 minutes.

5.6.1 STOP MODE

• Scheduled runs do not occur when the module is in Stop/Reset Mode

5.6.2 MANUAL MODE

• Scheduled runs do not occur when the module is in Manual Mode

waiting for a start

request.

• Activation of a Scheduled Run ‘On Load’ when the module is operating OFF LOAD in Manual

Mode

forces the set to run ON LOAD.

5.6.3 TEST MODE

• Scheduled runs do not occur when the module is in Test Mode

waiting for a start request.

5.6.4 AUTO MODE

• Scheduled runs operate ONLY if the module is in Auto Mode

with no Shutdown or

Electrical Trip alarm present.

• If the module is in Stop/Reset Mode

or Manual Mode when a scheduled run begins,

the engine is not started. However, if the module is moved into Auto Mode

during a

scheduled run, the engine is called to start.

• Depending upon configuration by the system designer, an external input can be used to inhibit a scheduled run.

• If the engine is running OFF LOAD in Auto Mode

and a scheduled run configured to ‘On

Load’ begins, the set is placed ON LOAD for the duration of the Schedule.

Protections

Page 67 of 94 057-236 ISSUE: 1

6 PROTECTIONS

6.1 ALARMS

When an alarm is active, the Common Alarm LED, illuminates and a message appears on the module’s display. If configured, the external audible alarm also sounds.

The external audible alarm is silenced by pressing the Alarm Reset / Lamp Test

button.

The LCD display jumps from the ‘Information page’ to display the Alarm Page

1/2 Alarms

Low Oil Pressure

Warning

The LCD displays multiple alarms such as “Coolant Temperature High”, “Emergency Stop” and “Low Coolant Warning”. These automatically scroll in the order that they occurred.

In the event of an alarm, the LCD displays the appropriate text. If an additional alarm then occurs, the module displays the appropriate text.

Example:

1/2 Alarms

2/2 Alarms

Low Oil Pressure

Warning

Coolant Temperature High

Shutdown

The type of alarm, e.g. Warning

The cause of alarm, e.g. Low Oil Pressure

Number of active alarms. This is

alarm 1 of a total of 2 active alarms

Protections

057-236 ISSUE: 1 Page 68 of 94

6.1.1 ECU ALARMS (CAN ERROR MESSAGE / DTC)

NOTE: For details on these code meanings, refer to the ECU instructions provided by the

engine manufacturer, or contact the engine manufacturer for further assistance.

NOTE: For further details on connection to electronic engines, refer to DSE Publication:

057-004 Electronic Engines And DSE Wiring

When connected to a suitable CAN engine, the controller displays alarm status messages from the ECU.

1/1 Alarms

ECU Amber

Warning

Press and hold the Scroll Down

button to access the list of current active Engine DTCs

(Diagnostic Trouble Codes) from the ECU.

Engine DTCs

The code is interpreted by the module and shows on the display as a text message. Additionally, the manufacturer’s fault code is shown below.

Water Level Low

###,###,###

Type of alarm that is

triggered on the DSE

module, e.g. Warning

Protections

Page 69 of 94 057-236 ISSUE: 1

6.2 INDICATIONS

Indications are non-critical and often status conditions. They do not appear on the LCD display of the module as a text message in the Status, Event Log or Alarms pages. However, an output or LCD indicator is configured to draw the operator’s attention to the event.

Example

• Input configured for indication.

• The LCD text does not appear on the module display but can be added in the configuration to remind the system designer what the input is used for.

• As the input is configured to Indication there is no alarm generated.

• LCD Indicator 1 ‘illuminates’ when Digital Input A is active.

• The LCD Description allows the system designer to detail the LCD Indicator function.

Example

The LCD Indicators on the module display show the status of the configured indicator.

LCD Indicators

Panel Door Open

LCD Indicator 2

LCD Indicator 3

Protections

057-236 ISSUE: 1 Page 70 of 94

6.3 WARNING ALARMS

Warnings are non-critical alarm conditions and do not affect the operation of the engine system, they serve to draw the operators attention to an undesirable condition.

Example

1/2 Alarms

High Coolant Temperature

Warning

In the event of an alarm the LCD jumps to the alarms page, and scroll through all active alarms.

By default, warning alarms are self-resetting when the fault condition is removed. However enabling ‘all warnings are latched’ causes warning alarms to latch until reset manually. This is enabled using the DSE Configuration Suite in conjunction with a compatible PC.

If the module is configured for CAN and receives an “error” message from the ECU, ‘CAN ECU Amber” is shown on the module’s display as a warning alarm.

Fault Description

Analogue Input A to D

The module detects that an input configured to create a fault condition has become active and the appropriate LCD message is displayed.

Battery Over Voltage

The DC supply has risen above the high volts pre-set pre-alarm setting.

Battery Under Voltage

The DC supply has fallen below or risen above the low volts pre- set pre-alarm setting.

CAN ECU Data Fail

The module is configured for CAN operation and does not detect data on the engine Can data link.

Charge Alternator Failure

The auxiliary charge alternator voltage is low as measured from the W/L terminal.

Coolant Temperature Sensor Fault

The module detects that the circuit to the coolant temperature sensor has been broken.

Delayed Over Current

The measured current has risen above the configured trip level for a configured duration.

Digital Inputs A to F

The module detects that a digital input which has been user configured to create a fault condition has become active and the appropriate LCD message is displayed.

ECU Amber

The module detects that the engine ECU has detected a fault causing an Amber alarm.

ECU After Treatment

The module detects that the engine ECU has detected that the after treatment is currently in progress.

ECU Malfunction

The module detects that the engine ECU has detected a fault causing a Malfunction alarm.

ECU Protect

The module detects that the engine ECU has detected a fault causing a Protect alarm.

ECU Red

The module detects that the engine ECU has detected a fault causing a Red alarm.

ECU Water In Fuel

The module detects that the engine ECU has detected that there is water in the fuel.

Expansion Unit Failure

The module detects the DSE Net link to the expansion module has failed or communications to the expansion module has been lost.

Protections

Page 71 of 94 057-236 ISSUE: 1

Fault Description

Fail To Stop

NOTE: Fail to Stop could indicate a faulty oil pressure sensor. If engine is at rest check oil sensor wiring and configuration.

The module has detected a condition that indicates that the engine is running when it has been instructed to stop.

Generator kW Overload

The

measured

kW has risen above the

configured trip level for a

configured duration.

High Fuel Level

The level detected by the fuel level sensor is above the high fuel level pre-set pre-alarm setting.

Immediate Over Current The measured current has risen above the configured trip level.

Low Fuel Level

The level detected by the fuel level sensor is below the low fuel level pre-set pre-alarm setting.

Loss Of Speed Sensing Signal

The speed signal from the magnetic pickup is not being received by the DSE controller.

Maintenance Alarm 1

The module detects that the Maintenance Alarm 1 is due creating a fault condition, the appropriate LCD message is displayed.

Maintenance Alarm 2

The module detects that the Maintenance Alarm 2 is due creating a fault condition, the appropriate LCD message is displayed.

Maintenance Alarm 3

The module detects that the Maintenance Alarm 3 is due creating a fault condition, the appropriate LCD message is displayed.

Oil Pressure Sensor Fault.

The module detects that the circuit to the oil pressure sensor has been broken.

2130 ID0 Analogue Input E to H

The module detects that an analogue input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID0.

2130 ID0 Digital Input A to H

The module detects that a digital input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID0.

2130 ID1 Analogue Input E to H

The module detects that an analogue input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID1.

2130 ID1 Digital Input A to H

The module detects that a digital input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID1.

Protections

057-236 ISSUE: 1 Page 72 of 94

6.4 ELECTRICAL TRIP ALARMS

NOTE: The alarm condition must be rectified before a reset takes place. If the alarm condition remains, it is not possible to reset the unit (The exception to this is the Low Oil Pressure alarm and similar active from safety on alarms, as the oil pressure is low with the engine at rest).

Electrical trips are latching and stop the Generator but in a controlled manner. On initiation of the electrical trip condition the module de-energises all the Delayed Load Output and the Close Gen Output outputs to remove the load from the generator. Once this has occurred the module starts the Cooling timer and allows the engine to cool off-load before shutting down the engine. The alarm must be accepted and cleared, and the fault removed to reset the module.

Example

1/2 Alarms

Generator Overcurrent

Electrical Trip

Electrical trips are latching alarms and to remove the fault, press the Stop/Reset Mode

button on

the module.

Fault Description

Analogue Input A to D

The module detects that an input configured to create a fault condition has become active and the appropriate LCD message is displayed.

CAN ECU Data Fail

The module is configured for CAN operation and does not detect data on the engine Can data link.

Delayed Over Current

The measured current has risen above the configured trip level for a configured duration.

Digital Inputs A to F

The module detects that a digital input which has been user configured to create a fault condition has become active and the appropriate LCD message is displayed.

ECU Amber

The module detects that the engine ECU has detected a fault causing an Amber alarm.

ECU After Treatment

The module detects that the engine ECU has detected that the after treatment is currently in progress.

ECU Malfunction

The module detects that the engine ECU has detected a fault causing a Malfunction alarm.

ECU Protect

The module detects that the engine ECU has detected a fault causing a Protect alarm.

ECU Red

The module detects that the engine ECU has detected a fault causing a Red alarm.

ECU Water In Fuel

The module detects that the engine ECU has detected that there is water in the fuel.

Expansion Unit Failure

The module detects the DSE Net link to the expansion module has failed or communications to the expansion module has been lost.

Generator kW Overload

The measured kW has risen above the configured trip level for a configured duration.

High Fuel Level

The level detected by the fuel level sensor is above the high fuel level pre-set pre-alarm setting.

Low Fuel Level

The level detected by the fuel level sensor is below the low fuel level pre-set pre-alarm setting.

Protections

Page 73 of 94 057-236 ISSUE: 1

Fault Description

Maintenance Alarm 1

The module detects that the Maintenance Alarm 1 is due creating a fault condition, the appropriate LCD message is displayed.

Maintenance Alarm 2

The module detects that the Maintenance Alarm 2 is due creating a fault condition, the appropriate LCD message is displayed.

Maintenance Alarm 3

The module detects that the Maintenance Alarm 3 is due creating a fault condition, the appropriate LCD message is displayed.

2130 ID0 Analogue Input E to H

The module detects that an analogue input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID0.

2130 ID0 Digital Input A to H

The module detects that a digital input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID0.

2130 ID1 Analogue Input E to H

The module detects that an analogue input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID1.

2130 ID1 Digital Input A to H

The module detects that a digital input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID1.

Protections

057-236 ISSUE: 1 Page 74 of 94

6.5 SHUTDOWN ALARMS

NOTE: The alarm condition must be rectified before a reset takes place. If the alarm condition remains, it is not be possible to reset the unit (The exception to this is the Low Oil Pressure alarm and similar active from safety on alarms, as the oil pressure is low with the engine at rest).

Shutdown alarms are latching and immediately stop the Generator. On initiation of the shutdown condition the module de-energises all the Delayed Load Output and the Close Gen Output outputs to remove the load from the generator. Once this has occurred, the module shuts the generator set down immediately to prevent further damage. The alarm must be accepted and cleared, and the fault removed to reset the module.

Example

1/2 Alarm Low Oil Pressure

Shutdown

Shutdowns are latching alarms and to remove the fault, press the Stop/Reset Mode

button on the

module.

Fault Description

Analogue Input A to D

The module detects that an input configured to create a fault condition has become active and the appropriate LCD message is displayed.

CAN ECU Data Fail

The module is configured for CAN operation and does not detect data on the engine Can data link.

Charge Alternator Failure

The auxiliary charge alternator voltage is low as measured from the W/L terminal.

Coolant Temperature Sensor Fault

The module detects that the circuit to the coolant temperature sensor has been broken.

Emergency Stop

The emergency stop button is pressed. This failsafe (normally closed to emergency stop) input and immediately stops the set when the signal is removed.

Delayed Over Current

The measured current has risen above the configured trip level for a configured duration.

Digital Inputs A to F

The module detects that a digital input which has been user configured to create a fault condition has become active and the appropriate LCD message is displayed.

ECU Amber

The module detects that the engine ECU has detected a fault causing an Amber alarm.

ECU After Treatment

The module detects that the engine ECU has detected that the after treatment is currently in progress.

ECU Malfunction

The module detects that the engine ECU has detected a fault causing a Malfunction alarm.

ECU Protect

The module detects that the engine ECU has detected a fault causing a Protect alarm.

ECU Red

The module detects that the engine ECU has detected a fault causing a Red alarm.

ECU Water In Fuel

The module detects that the engine ECU has detected that there is water in the fuel.

Protections

Page 75 of 94 057-236 ISSUE: 1

Fault Description

Expansion Unit Failure

The module detects the DSE Net link to the expansion module has failed or communications to the expansion module has been lost.

Generator kW Overload

The

measured

kW has risen above the

configured trip level for a

configured duration.

Generator Over Frequency

The generator output frequency has risen above the trip alarm setting.

Generator Over Voltage

The generator output voltage has risen above the trip alarm setting.

Generator Under Frequency

The generator output frequency has fallen below the trip alarm setting after the Safety On timer has expired.

Generator Under Voltage

The generator output voltage has fallen below the pre-set alarm setting after the Safety On timer has expired.

High Coolant Temperature

The module detects that the engine coolant temperature has exceeded the high engine temperature trip alarm setting level after the Safety On timer has expired.

High Fuel Level

The level detected by the fuel level sensor is above the high fuel level trip alarm setting.

Low Fuel Level

The level detected by the fuel level sensor is below the low fuel level trip alarm setting.

Low Oil Pressure

The module detects that the engine oil pressure has fallen below the low oil pressure trip alarm setting level after the Safety On timer has expired.

Loss Of Speed Sensing Signal

There is no speed signal received from the magnetic pickup connected to the controller. Check distance and position of magnetic pickup in relation to engine flywheel.

Maintenance Alarm 1

The module detects that the Maintenance Alarm 1 is due creating a fault condition, the appropriate LCD message is displayed.

Maintenance Alarm 2

The module detects that the Maintenance Alarm 2 is due creating a fault condition, the appropriate LCD message is displayed.

Maintenance Alarm 3

The module detects that the Maintenance Alarm 3 is due creating a fault condition, the appropriate LCD message is displayed.

Oil Pressure Sensor Fault.

The module detects that the circuit to the oil pressure sensor has been broken.

Over Speed

The engine speed has risen above the over speed trip alarm setting

Under Speed

The engine speed has fallen below the under speed trip alarm setting

2130 ID0 Analogue Input E to H

The module detects that an analogue input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID0.

2130 ID0 Digital Input A to H

The module detects that a digital input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID0.

2130 ID1 Analogue Input E to H

The module detects that an analogue input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID1.

2130 ID1 Digital Input A to H

The module detects that a digital input that has been user configured to create a fault condition has become active on the DSE2130 expansion module with ID1.

Protections

057-236 ISSUE: 1 Page 76 of 94

6.6 HIGH CURRENT SHUTDOWN / ELECTRICAL TRIP ALARM

The overcurrent alarm combines a simple warning trip level with a fully functioning IDMT curve for thermal protection.

6.6.1 IMMEDIATE WARNING

If the Immediate Warning is enabled, the controller generates a warning alarm as soon as the Trip level is reached. The alarm automatically resets once the generator loading current falls below the Trip level (unless All Warnings are latched is enabled). For further advice, consult your generator supplier.

Protections

Page 77 of 94 057-236 ISSUE: 1

6.6.2 IDMT ALARM

If the IDMT Alarm is enabled, the controller begins following the IDMT ‘curve’ when the trip level is passed.

If the Trip is surpassed for an excess amount of time the IDMT Alarm triggers (Shutdown or Electric trip as selected in Action).

High current shutdown is a latching alarm and stops the Generator.

Remove the fault then press the Stop/Reset Mode

button to reset the module.

High current electrical trip is a latching alarm and removes the generator from the load, before stopping the Generator after the off load cooling timer.

Remove the fault then press the Stop/Reset Mode

button to reset the module.

The higher the overload, the faster the trip. The speed of the trip is dependent upon the fixed formula:

T = t / ((IA / IT) – 1)

Where: T is the tripping time in seconds

is the actual current of the most highly loaded line (L1 or L2 or L3)

is the delayed over-current trip point

t is the time multiplier setting and also represents the tripping time in seconds at twice full load (when I

/ IT = 2).

Factory settings for the IDMT Alarm when used on a brushless alternator are as follows (screen capture from the DSE Configuration Suite PC software :

These settings provide for normal running of the generator up to 100% full load. If full load is surpassed, the Immediate Warning alarm is triggered, the set continues to run. The effect of an overload on the generator is that the alternator windings begin to overheat; the aim of the IDMT alarm is to prevent the windings being overload (heated) too much. The amount of time that the set can be safely overloaded is governed by how high the overload condition is.

With typical settings as above, the tripping curve is followed as shown below.

This allows for overload of the set to the limits of the Typical Brushless Alternator whereby 110% overload is permitted for 1 hour.

If the set load reduces, the controller then follows a cooling curve. This means that a second overload condition may trip much sooner than the first as the controller knows if the windings have not cooled sufficiently.

For further details on the Thermal damage curve of your alternator, you are referred to your alternator manufacturer and generator supplier.

(Trip setting value)

(time multiplier)

Protections

057-236 ISSUE: 1 Page 78 of 94

Slower than Factory

setting

Factory setting (Time Multiplier = 36

Faster than Factory setting (Time Multiplier = 18

‘Fastest’ trip setting (Time Multiplier = 1

Protections

Page 79 of 94 057-236 ISSUE: 1

6.7 MAINTENANCE ALARM

Depending upon module configuration one or more levels of engine maintenance alarm may occur based upon a configurable schedule.

Example 1

Screen capture from DSE Configuration Suite Software showing the configuration of the Maintenance Alarm for 1, 2 and 3.

When activated, the maintenance alarm is either a Warning (set continues to run) or Shutdown (running the set is not possible).

Resetting the maintenance alarm is normally actioned by the site service engineer after performing the required maintenance. The method of reset is either by:

• Activating an input that has been

configured to Reset Maintenance Alarm 1, 2 or 3.

• Pressing the maintenance reset

button in the DSE Configuration Suite, Maintenance section.

Example 2

Screen capture from DSE Configuration Suite Software showing the configuration of a digital input for Reset Maintenance Alarm 1.

Example 3

Screen capture from DSE Configuration Suite Software showing the Maintenance Alarm Reset ‘button’ in the DSE Configuration Suite SCADA | MAINTENANCE section.

Front Panel Configuration

057-236 ISSUE: 1 Page 80 of 94

7 FRONT PANEL CONFIGURATION

This configuration mode allows the operator to fully configure the module through its display without the use of the DSE Configuration Suite PC Software.

Use the module’s facia buttons to traverse the menu and make value changes to the parameters:

Next Section

(Generator, Engine)

Previous Section

(Generator,Engine)

Next Parameter

Edit or Save

Parameter

Front Panel Configuration

Page 81 of 94 057-236 ISSUE: 1

7.1 FRONT PANEL CONFIGURATION EDTIOR

7.1.1 ACCESSING THE FRONT PANEL CONFIGURATION EDITOR

NOTE: More comprehensive module configuration is possible via PC configuration software. For further details of module configuration, refer to DSE Publication: 057- 224 DSE6110 MKII & DSE6110 MKII Configuration Software Manual.

• Ensure the engine is at rest and the module by pressing the Stop/Reset Mode

button.

• Press the Stop/Reset Mode

and Tick  buttons together to enter the front panel

configuration editor.

7.1.2 ENTERING PIN

NOTE: The PIN is not set by DSE when the module leaves the factory. If the module has a PIN code set, this has been affected by your engine supplier who should be contacted if you require the code. If the code has been ‘lost’ or ‘forgotten’, the module must be returned to the DSE factory to have the module’s code removed. A charge is made for this procedure. NB - This procedure cannot be performed away from the DSE factory.

NOTE: The PIN is automatically reset when the editor is exited (manually or automatically) to ensure security.

• If a module security PIN has been set, the PIN request is then shown.

• Press the Tick



button, the first ‘#’ changes to ‘0’. Press the Previous

& Next

buttons to

adjust it to the correct value.

• Press the Next

button when the first digit is correctly entered. The digit you have just entered

now shows as ‘#’ for security.

• Press the Scroll Down

button to move back to adjust one of the previous digits.

• After editing the final PIN digit, press the Tick  button. The PIN is then checked for validity. If

the number is not correct, the PIN must re-entered.

• If the PIN has been successfully entered (or the module PIN has not been enabled), the editor is

displayed.

Front Panel Configuration

057-236 ISSUE: 1 Page 82 of 94

7.1.3 EDITING A PARAMETER

NOTE: Pressing and holding the Menu Navigation buttons provides the autorepeat functionality. Values can be changed quickly by holding the navigation buttons for a prolonged period of time.

• Press and hold either of the Menu Navigation

buttons to cycle to the section which is

required to be edited.

• Press the Menu Navigation buttons to cycle to the parameter within the section chosen

to be edited.

• Press the Tick



button to edit the parameter. The parameter begins to flash to indicate that the

parameter is being edited.

• Press the Previous

─

& Next

buttons to adjust the parameter to the required value.

• Press the Tick



button to stop editing the paramter. The parameter ceases flashing to indicate

that it the parameter is no longer being edited.

7.1.4 EXITING THE FRONT PANEL CONFIGURATION EDITOR

NOTE: The editor automatically exits after 5 minutes of inactivity to ensure security.

• Press and hold the Stop/Reset Mode

button to exit the editor without saving changes.

• Press and hold the Tick  button to exit the editor and save the changes.

Front Panel Configuration

Page 83 of 94 057-236 ISSUE: 1

7.1.5 ADJUSTABLE PARAMETERS

Section Parameter as Shown on Display Values

Pin Pin Entry # # # # Display Contrast 0% Language

English - Others

LCD Page Timer 0 s Scroll Delay 2 s Current Date and Time Day - hh:mm:ss Alt Config Default Config Default Config Engine Oil Pressure Low Shutdown 0 bar Coolant Temp High Shutdown 0 ºC Start Delay 0 s Pre Heat Timer 0 s Crank Duration 0 s Crank Rest Time 0 s Safety On Delay 0 s Smoke Limiting 0 s Smoke Limiting Off 0 s Warm Up Time 0 s Cool Down Time 0 s Fail To Stop Delay 0 s Battery Under Voltage Warning

Active, Inactive

Battery Under Voltage Warning 0 V Battery Under Voltage Warning Delay 0 s Battery Over Voltage Warning

Active, Inactive

Battery Over Voltage Warning 0 V Battery Over Voltage Warning Delay 0 s Charge Alternator Failure Warning

Active, Inactive

Charge Alternator Failure Warning 0 V Charge Alternator Failure Warning Delay 0 s Charge Alternator Failure Shutdown

Active, Inactive

Charge Alternator Failure Shutdown 0 V Charge Alternator Failure Shutdown Delay 0 s Low Battery Start

Active, Inactive

Low Battery Start Level 0 V Low Battery Start Delay 0 s Low Battery Run Time 0 s

Front Panel Configuration

057-236 ISSUE: 1 Page 84 of 94

Section Parameter as Shown on Display Values

Generator Under Voltage Shutdown 0 V Loading Voltage 0 V Nominal Voltage 0 V Over Voltage Shutdown 0 V Under Frequency Shutdown 0 Hz Loading Frequency 0 Hz Nominal Frequency 0 Hz Over Frequency Shutdown 0 Hz

Full Load Rating

0 A

Delayed Over Current

Active, Inactive

Delayed Over Current 0 %

AC System Single Phase, 2 Wire

3 Phase, 4 Wire

2 Phase, 3 Wire (L1 & L3) 3 Phase, 4 Wire (Delta) 2 Phase, 3 Wire (L1 & L2) 3 Phase, 3 Wire

CT Primary

0 A

Transient Delay

0.0 s

Mains

Under Voltage Trip 0 V Over Voltage Trip 0 V Under Frequency Trip 0 Hz Over Frequency Trip 0 Hz Transient Delay 0 s Return Delay 0 s Transfer Time 0 s

Timers LCD Page Timer 0 s Scroll Delay 0 s Pre Heat Timer 0 s Crank Duration 0 s Crank Rest Time 0 s Safety On Delay 0 s Smoke Limiting 0 s Smoke Limiting Off 0 s Warm Up Time 0 s Cool Down Time 0 s Fail To Stop Delay 0 s Battery Under Voltage Warning Delay 0 s Battery Over Voltage Warning Delay 0 s Return Delay 0 s Generator Transient Delay 0 s Mains Transient Delay (DSE6120 MKII only) 0 s Mains Transfer Time (DSE6120 MKII only) 0 s Scheduler Schedule

Active, Inactive Schedule Period Weekly, Monthly Schedule On Load Active, Inactive Schedule 1 - 8 Day, On Time, Run Time

Front Panel Configuration

Page 85 of 94 057-236 ISSUE: 1

7.2 ‘RUNNING’ CONFIGURATION EDITOR

7.2.1 ACCESSING THE ‘RUNNING’ CONFIGURATION EDITOR

• The ‘running’ editor can be entered whilst the engine is running. All protections remain active if the engine is running while the running editor is entered

• Press and hold together the Menu Navigation

buttons to access the Running Editor

7.2.2 ENTERING PIN

NOTE: The PIN is automatically reset when the editor is exited (manually or automatically) to ensure security.

• Even if a module security PIN has been set, the PIN is not requested whilst entering the ‘running’

editor.

7.2.3 EDITING A PARAMETER

• Press either of the Menu Navigation

buttons to cycle to the parameter within the section

chosen to be edited.

• Press the Tick



button to edit the parameter. The parameter begins to flash to indicate that the

parameter is being edited.

• Press the Previous

& Next

buttons to adjust the parameter to the required value.

• Press the Tick



button to stop editing the paramter. The parameter ceases flashing to indicate

that it the parameter is no longer being edited

Front Panel Configuration

057-236 ISSUE: 1 Page 86 of 94

7.2.4 EXITING THE ‘RUNNING’ CONFIGURATION EDITOR

NOTE: The editor automatically exits after 5 minutes of inactivity to ensure security.

• Press and hold the Stop/Reset Mode

button to exit the editor without saving changes.

• Press and hold the Tick  button to exit the editor and save the changes.

7.2.5 RUNNING EDITOR PARAMETERS

Section Parameter as Shown on Display Values

Display

Contrast 0% Language

English

Fault Finding

Page 87 of 94 057-236 ISSUE: 1

8 COMMISSIONING

NOTE: If Emergency Stop feature is not required, link the input to the DC Positive.

Before the system is started, it is recommended that the following checks are made:-

• The unit is adequately cooled and all the wiring to the module is of a standard and rating

compatible with the system. Check all mechanical parts are fitted correctly and that all electrical connections (including earths) are sound.

• The unit DC supply is fused and connected to the battery and that it is of the correct polarity.

• The Emergency Stop input is wired to an external normally closed switch connected to DC

positive.

• To check the start cycle operation, take appropriate measures to prevent the engine from starting

(disable the operation of the fuel solenoid). After a visual inspection to ensure it is safe to

proceed, connect the battery supply. Press the Manual Mode

button followed by the Start

button the unit start sequence commences.

• The starter engages and operates for the pre-set crank period. After the starter motor has

attempted to start the engine for the pre-set number of attempts, the LCD displays ‘Failed to

start. Press the Stop/Reset Mode button to reset the unit.

• Restore the engine to operational status (reconnect the fuel solenoid). Press the Manual Mode

button followed by the Start button. This time the engine should start and the starter motor should disengage automatically. If not then check that the engine is fully operational (fuel available, etc.) and that the fuel solenoid is operating. The engine should now run up to operating speed. If not, and an alarm is present, check the alarm condition for validity, then check input wiring. The engine should continue to run for an indefinite period. It is possible at this time to view the engine and alternator parameters - refer to the ‘Description of Controls’ section of this manual.

• Press the Auto Mode

button, the engine runs for the pre-set cooling down period, then stop. The generator should stay in the standby mode. If not check that there is not a signal present on the Remote start input.

• Initiate an automatic start by supplying the remote start signal (if configured). The start sequence commences and the engine runs up to operational speed. Once the generator is available the delayed load outputs activate, the Generator accepts the load. If not, check the wiring to the delayed load output contactors. Check the Warming timer has timed out.

• Remove the remote start signal. The return sequence begins. After the pre-set time, the generator is unloaded. The generator then runs for the pre-set cooling down period, then shutdown into its standby mode.

• Set the modules internal clock/calendar to ensure correct operation of the scheduler and event logging functions. For details of this procedure see section entitled Front Panel Configuration

• If, despite repeated checking of the connections between the controller and the customer’s system, satisfactory operation cannot be achieved, then the customer is requested to the DSE Technical Support Department

Fault Finding

057-236 ISSUE: 1 Page 88 of 94

9 FAULT FINDING

NOTE: The below fault finding is provided as a guide check-list only. As the module can be configured to provide a wide range of different features, always refer to the source of your module configuration if in doubt.

9.1 STARTING

Symptom Possible Remedy

Unit is inoperative

Read/Write configuration does not operate

Check the battery and wiring to the unit. Check the DC supply. Check the DC fuse.

Unit shuts down Check DC supply voltage is not above 35 Volts or below 9 Volts

Check the operating temperature is not above 70°C. Check the DC

fuse. Fail to Start is activated after pre-set number of attempts to start

Check wiring of fuel solenoid. Check fuel. Check battery supply.

Check battery supply is present on the Fuel output of the module.

Check the speed-sensing signal is present on the module’s inputs.

Refer to engine manual. Continuous starting of generator when in the

Auto Mode

Check that there is no signal present on the “Remote Start” input.

Check configured polarity is correct.

Check the mains supply is available and within configured limits

Generator fails to start on receipt of Remote Start signal.

Check Start Delay timer has timed out.

Check signal is on “Remote Start” input. Confirm correct

configuration of input is configured to be used as “Remote Start”.

Check that the oil pressure switch or sensor is indicating low oil

pressure to the controller. Depending upon configuration, the set

does not start if oil pressure is not low. Pre-heat inoperative Check wiring to engine heater plugs. Check battery supply. Check

battery supply is present on the Pre-heat output of module. Check

pre-heat configuration is correct. Starter motor inoperative Check wiring to starter solenoid. Check battery supply. Check battery

supply is present on the Starter output of module. Ensure oil

pressure switch or sensor is indicating the “low oil pressure” state to

the controller.

9.2 LOADING

Symptom Possible Remedy

Engine runs but generator does not take load

Check Warm up timer has timed out.

Ensure generator load inhibit signal is not present on the module

inputs.

Check connections to the switching device.

Note that the set does not take load in Manual Mode

unless there

is an active load signal. Incorrect reading on Engine gauges

Fail to stop alarm when engine is at rest

Check engine is operating correctly.

Check that sensor is compatible with the module and that the

module configuration is suited to the sensor.

Fault Finding

Page 89 of 94 057-236 ISSUE: 1

9.3 ALARMS

Symptom Possible Remedy

Low oil Pressure fault operates after engine has fired

Check engine oil pressure. Check oil pressure switch/sensor and

wiring. Check configured polarity (if applicable) is correct (i.e.

Normally Open or Normally Closed) or that sensor is compatible with

the module and is correctly configured. High engine temperature fault operates after engine has fired.

Check engine temperature. Check switch/sensor and wiring. Check

configured polarity (if applicable) is correct (i.e. Normally Open or

Normally Closed) or that sensor is compatible with the module. Shutdown fault operates Check relevant switch and wiring of fault indicated on LCD display.

Check configuration of input. Electrical Trip fault operates Check relevant switch and wiring of fault indicated on LCD display.

Check configuration of input. Warning fault operates Check relevant switch and wiring of fault indicated on LCD display.

Check configuration of input. CAN ECU WARNING CAN ECU SHUTDOWN

This indicates a fault condition detected by the engine ECU and

transmitted to the DSE controller. CAN DATA FAIL Indicates failure of the CAN data link to the engine ECU.

Check all wiring and termination resistors (if required). Incorrect reading on Engine gauges

Fail to stop alarm when engine is at rest

Check engine is operating correctly. Check sensor and wiring paying

particular attention to the wiring to terminal 10 (refer to appendix).

Check that sensor is compatible with the module and that the

module configuration is suited to the sensor.

9.4 COMMUNICATIONS

Symptom Possible Remedy

CAN DATA FAIL Indicates failure of the CAN data link to the engine ECU.

Check all wiring and termination resistors (if required).

9.5 INSTRUMENTS

Symptom Possible Remedy

Inaccurate generator measurements on controller display

Check that the CT primary, CT secondary and VT ratio settings are

correct for the application.

Check that the CTs are wired correctly with regards to the direction

of current flow (p1,p2 and s1,s2) and additionally ensure that CTs

are connected to the correct phase (errors occur if CT1 is connected

to phase 2).

Remember to consider the power factor (kW = kVA x powerfactor).

The controller is true RMS measuring so gives more accurate

display when compared with an ‘averaging’ meter such as an

analogue panel meter or some lower specified digital multimeters.

Accuracy of the controller is better than 1% of full scale. Generator

voltage full scale is 415 V ph-N, accuracy is ±4.15 V (1 % of 415 V ).

Fault Finding

057-236 ISSUE: 1 Page 90 of 94

9.6 MISCELLANEOUS

Symptom Possible Remedy

Module appears to ‘revert’ to an earlier configuration

When editing a configuration using the PC software it is vital that the

configuration is first ‘read’ from the controller before editing it. This

edited configuration must then be “written” back to the controller for

the changes to take effect.

When editing a configuration using the fascia editor, be sure to press

the the Auto Mode

() button to save the change before moving

to another item or exiting the fascia editor

Maintenance, Spares, Repair and Servicing

Page 91 of 94 057-236 ISSUE: 1

10 MAINTENANCE, SPARES, REPAIR AND SERVICING

The controller is Fit and Forget. As such, there are no user serviceable parts within the controller. In the case of malfunction, you should contact your original equipment manufacturer (OEM).

10.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE

If you require additional plugs from DSE, please contact our Sales department using the part numbers below.

10.1.1 PACK OF PLUGS

Module Type Plug Pack Part Number

DSE6110 MKII 007-869 DSE6120 MKII 007-870

10.1.2 INDIVIDUAL PLUGS

Module Terminal Designation Plug Description Part No.

1-10

10 way 5.08 mm 007-450

11-21

11 way 5.08 mm 007-451

22-24

3 way 5.08 mm 007-174

25-28

DSE6110 MKII Only 4 way 7.62 mm 007-171

25-32

DSE6120 MKII Only 8 way 7.62 mm 007-454

33-37

5 way 5.08 mm 007-445

38-43

6 way 5.08 mm 007-446

PC Configuration interface lead (USB type A – USB type B)

016-125

10.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE

Item Description Part No.

Module Fixing Clips (Packet Of 2) 020-406

10.3 PURCHASING ADDITIONAL SEALING GASKET FROM DSE

Item Description Part No.

Module Silicon Sealing Gasket 020-521

Warranty, Disposal

057-236 ISSUE: 1 Page 92 of 94

10.4 DSENET EXPANSION MODULES

NOTE: A maximum of six (6) expansion modules can be connected to the DSE6110 MKII

& DSE6120 MKII DSENet® Port

NOTE: DSENet® utilises an RS485 connection. Using Belden 9841 (or equivalent) cable allows for the expansion cable to be extended to a maximum of 1.2km. DSE Stock and supply Belden 9841 cable. DSE Part Number 016-030.

Item

Description

DSE Part Numbers

Max No.

supported

Model

order

number

Sales

literature

Operator

manual

Installation

Instructions

Model DSE2130 input module provides additional analogue and digital inputs for use with the controller.

2130-001-00 055-060 057-082 053-033

Model DSE2157 expansion relay module provides eight additional voltage free relays for use with the controller

2157-001-00 055-061 057-083 053-034

Model DSE2548 expansion LED module provides additional LED indications, internal sounder and remote lamp test/alarm mute for use with the controller.

2548-001-00 055-062 057-084 053-032

Warranty & Disposal

Page 93 of 94 057-236 ISSUE: 1

11 WARRANTY

DSE Provides limited warranty to the equipment purchaser at the point of sale. For full details of any applicable warranty, you are referred to our original equipment supplier (OEM)

12 DISPOSAL

12.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)

If you use electrical and electronic equipment you must store, collect, treat, recycle and dispose of WEEE separately from your other waste

This Page is Intentionally Left Blank
