Dedicated Micros DM-ICE-DN3U-L-N Specsheet

• True Day/Night for sensitivity to IR light at night and true colour rendition in daylight

• Unshielded Active Twisted Pair (UTP) video output on Ice+ models allows video signals to
be transmitted further than coax cable will allow

• High Resolution 540 lines

• Backfocus thumbwheel for optimum picture quality & ease of setup

• High picture quality due to tailored digital signal processing settings and professional quality
optical filters

• Simple to install and configure with a streamlined range of configurable settings

• Accepts C/CS lenses without the need for adapters

• Compatible with all standard auto and manual iris lenses

• Protection against lightning strikes/spikes on power and coax lines

• Diecast zintec casing and cast zinc lens mount for superior build quality

• Compatible with Dennard Housings and Accessories

www.dedicatedmicros.com/baxall

DM/ICE-DN3U / DM/ICE+DN3XUT

1/3” DAY/NIGHT CAMERAS

www.dedicatedmicros.com/baxall

CAMERA FEATURES

Sensor

FEATURES DM/ICE-DN3U DM/ICE+DN3XUT

1/3” Sony Super HAD CCD™ 1/3” Sony EXview HAD™ CCD

Video Processing

DSP

Effective Pixels

752 (H) x 582 (V)

Sensitivity

0.7/ 0.1 lux; for usable picture (40%
video) with AGC on; lens at F1.2

0.4/0.1 lux; for usable picture (40%
video) with AGC on; lens at F1.2

Resolution

Ultra high resolution 540 TVL

Video Output

1V p-p composite video via 75ΩΩBNC
connector

Signal to Noise Ratio

Better than 50dB

Auto White Balance 2,500K ~ 9,500K 2,500K ~ 9,500K / Manual

AGC On / Off, max <28dB On/Off, Low/High, max < 28dB

Electronic Iris 1/50s~1/100,000s; On/ Off 1/50s~1/100,000s; On / Off

Gamma Correction 0.45 0.45/1.0

Additional Features

• User selectable day/night threshold

setting∑

• External D/N Contact

• Day/ Night High/ Low - user selectable
day/night threshold setting

• External D/N contact

• Sharpness On/ Off

• Digital Record Mode - to reduce
bandwidth or storage requirements

• Pk White Inversion

• Pk White Inversion Threshold Pot

• Manual white balance (push set)

• Unshielded Twisted Pair (UTP) video
output option

• Rotary BCD Shutter

Synchronisation System

Internal or Line lock (±180° adjustment)

On/Off, centre weighted, 7 user
selectable windows

• 1V p-p composite video via 75ΩΩBNC
connector

• Unshielded Twisted Pair (UTP) video
output

On/OffBacklight Compensation

Direct Drive (DC iris)

4-pin square type socket on the side of the camera. DC level is user defined
via a potentiometer located on the rear of the camera

Lens Options

Power Supply

Lens Mount and Focus ‘C’ or ‘CS’ mount, thumbwheel adjustment

Auto Iris Lens DC and Video via 4 pin socket

Mains Source / M version

Consumption

Input Connector

98~260V AC 50Hz

Less than 4.2W including 50mA DC lens

/L: 2-way terminal connector on rear panel
/M: 2m twin conductor mains cord (Class 2 product)

Power Indicator Blue LED on rear panel

Mechanical

Low Voltage Source / L version AC: 24V ±15% @50Hz DC: 12V -10% +15%

Camera Mount 1/4" 20 UNC top and bottom

Environmental

Operating Temperature -10 to +50°C (14 to 122°F)

Operating Humidity 20% to 80% relative humidity, non condensing

Storage Temperature -10 to +70°C (14 to 158°F)

Storage Humidity 20% to 90% relative humidity, non condensing

1/3” Day / Night Cameras

DM/ICE-DN3U/M

1/3” Ultra Resolution Day/Night, 540 TVL, 0.7 lux (Colour), 0.1 LUX
(Mono), C/CS , AI/DD/EI, 98-260V, 131x63x62mm

DM/ICE-DN3U/L (N)

(N) NTSC version available

1/3” Ultra Resolution Day/Night, 540 TVL, 0.7 lux (Colour), 0.1 LUX
(Mono), C/CS , AI/DD/EI, 12/24V, 131x63x62mm

DM/ICE-DN3XUT/M

1/3” Ultra Resolution Day/Night, 540 TVL, 0.4 lux (Colour), 0.1 LUX
(Mono), C/CS , AI/DD/EI, Peak White Inversion, 98-260V, 131x63x62mm

DM/ICE-DN3XUT/L

1/3” Ultra Resolution Day/Night, 540 TVL, 0.4 lux (Colour), 0.1 LUX
(Mono), C/CS , AI/DD/EI, Peak White Inversion, 12/24V, 131x63x62mm

Weight

/L: 0.4kg, shipping weight 0.53kg

/M: 0.52kg, shipping weight 0.62kg

Dimensions (mm) 131 (L) x 63 (H) x 62 (W)

Material Cast Zinc lens mount; zintec case; V0 ABS trim

SPECIFICATIONS

www.dedicatedmicros.com/baxall

DM/ICE-DN3U / DM/ICE+DN3XUT

D/N

D/N
EXT

D/N

D/N
EXT

110-240V
50/60Hz
AC~

DM/ICE-DN3U/L DM/ICE-DN3U/M

DM/ICE+DN3XUT/L DM/ICE+DN3XUT/M

DM/ICE-DN3U
DM/ICE+DN3XUT

www.dedicatedmicros.com/baxall

Super HAD CCD™ is a trademark of the Sony Corporation. Price and specification are subject to change without notice.
