DVR Storage Chart
GB of storage capacity Alternative Configurations
Video
Inputs
4 ECO4-40, 30pps 8 0.75 N/A 2 1
ECO4CD-40, 30pps 8 0.75 N/A 2 1
ECO4-80, 30pps 16.5 0.75 N/A 5 3
ECO4CD-80, 30pps 16.5 0.75 N/A 5 3
ECO4-160, 30pps 33 0.75 N/A 10 5
ECO4CD-160, 30pps 33 0.75 N/A 10 5
SD4N30-160, 60pps 30 5.00 30 10 5
SD4N60-250, 60pps 60 5.00 60 16 8
6 DS2PD 6-250, 120pps 26 0.38 40 10 5
DS2PD 6-500, 120pps 52 0.38 80 21 11
DS2PD 6-750, 120pps 78 0.38 120 32 16
8 SD8N30-250, 60pps 30 5.00 30 8 4
SD8N60-500, 60pps 60 5.00 60 16 8
9 ECO9-80CD, 60pps 8 0.67 N/A 2 1
ECO9-160CD, 60pps 16.5 0.67 N/A 4 2
ECO9-300CD, 60pps 33 0.67 N/A 9 5
DS2PD 9-250, 120pps 26 0.67 25 7 4
DS2PD 9-500, 120pps 52 0.67 50 14 7
DS2PD 9-750, 120pps 78 0.67 75 21 11
12 SD12N30-320, 90pps 30 5.00 30 6 3
SD12N60-750, 90pps 60 5.00 60 16 8
16 ECO16-160CD, 60pps 16.5 0.38 N/A 2 1
ECO16-300CD, 60pps 33 0.38 N/A 4 2
ECO16-500DC 60 pps 55 0.38 N/A 6 3
SD16M30-250, 60pps 30 2.00 30 5 3
SD16N30-500, 120pps 30 5.00 30 8 4
SD16N60-1TB, 120pps 60 5.00 60 16 8
DS2PD 16-250, 120pps 26 0.38 15 4 2
DS2PD 16-500, 120pps 52 0.38 30 8 4
DS2PD 16-750, 120pps 78 0.38 45 12 6
DS2PD 16-1TB, 120pps 104 0.38 60 16 8
DS2PD 16-1.5TB, 120pps 156 0.38 90 24 12
BX2PD-16-1.2TB, 120pps 125 0.38 72 19 10
BX2PD-16-2TB, 120pps 208 0.38 120 32 16
BX2PD-16-3TB, 120pps 312 0.38 180 47 24
BX2CA-16-1.2TB(2*600gb), 120 pps 125 0.38 36 9 5
BX2CA-16-2 TB,(2*1TB) 120 pps 208 0.38 60 16 8
32 SD32L30-250, 60pps 30 1.00 30 5 3
SD32M30-500, 120pps 30 2.00 30 5 3
SD32L60-500, 60pps 60 1.00 60 10 5
SD32M60-1TB, 120pps 60 2.00 60 10 5
Model 40 80 160 250
300/
320
500 750 1 TB 1.2 TB 1.5TB 2TB 3TB
Default Default
Days Storage
Rate (PPS)*
Individual
Camera
Recording
Days Storage
at 5 PPS
MPEG4 CIF
Days Storage
5pps/camera
2CIF JPEG
50% motion
activity rate
Days Storage
5pps/camera,
2CIF JPEG,
continuous
The ECO, Digital Sprite2, BX2, and DV-IP series DVRs use a default global record rate. The DVR automatically adjusts the individual camera record rate based on the number of
* Notes:
cameras attached. This chart assumes that all video inputs are being used. The data is calculated as the pictures per second captured for each individual camera and not the global
record rate of the DVR.
The SD Series DVR uses a default record rate for each individual camera. The record rate doesn't change with the number of cameras attached to the DVR.
These values are the default settings and do not prevent the user from increasing or decreasing the record rate of each camera.
Default recording settings for different models:
ECO 4 = 3pps total at 2CIF JPEG, 18kb pic file
ECO9, 16, DS2, BX2 = 6pps total, 2CIF JPEG 18kb pic file
SD N = 5pps/camera at MPEG4, 1 CIF
SD M = 2pps/camera at MPEG4, 1CIF
SD L = 1pps/camera at MPEG4, 1CIF
