T7 USER MANUAL

Safety Precautions

Read these safety instructions before using your device
and store them for possible future reference. Always
follow these basic safety precautions when using your
Mobile device. This reduces the risk of fire, electric shock,
and injury.

* Do not expose this product to rain or moisture.
* Keep the device out of direct sunlight and heat sources.
* Protect the power cord. Route power cords so that they
are not likely to be walked on or pinched by items placed
on or against them. Pay particular attention to the point
where the cord attaches to the device.
* Only use the AC adapter included with the device. Using
any other power adapter voids your warranty.
* Do not remove the cover. There are no user-serviceable
parts inside.
* If the charger cord is damaged, have it repaired by the
manufacturer, its service or a similarly qualified person in
order to avoid any hazard.
* The charger is not intended for use by persons
(including children) with reduced physical, sensory or
mental capacity. Persons who have not read the manual,
unless they have received explanations by a person
responsible for their safety and supervision should not
use this unit.

1

* Children should be monitored to ensure that they do not
play with the charger.
* The charger should always be readily accessible.
* The device should not be exposed to dripping or
splashing water.
* No objects filled with liquids such as vases shall be
placed on the device.
* Always leave a minimum distance of 10 cm around the
unit to ensure sufficient ventilation.
* Naked flame sources, such as candles, should not be
placed on top of the device.
* The device is intended for use only in a temperate
climate.
* CAUTION: Danger of explosion if battery is incorrectly
replaced or not replaced by the same type or equivalent.
* The battery should not be exposed to excessive heat
such as sunshine, fire or similar.
* Different types of batteries, new and used batteries
should not be mixed.
* The battery must be installed according to the polarity.
* If the battery is worn, it must be removed from the
product.
* The battery must be disposed of safely. Always use the
collection bins provided (check with your dealer) to protect
the environment.

2

CLEAN YOUR DEVICE

Treat the screen gently. To clean fingerprints or dust from
the screen, we recommend using a soft, non-abrasive
cloth such as a camera lens cloth.

SWITCH OFF IN RESTRICTED AREAS

Turn off the power when the use of the mobile device is not
authorized or when it may cause interference or danger,
for example; on board an aircraft, near medical
equipment, fuel, chemicals or blasting sites.

ROAD SAFETY COMES FIRST

Check the current laws and regulations in the area where
you drive, regarding the use of mobile devices such as this
mobile device.
* Do not hold this mobile device while driving
* Concentrate fully on the driving
* Radio Frequency (RF) can affect certain electronic
systems in your car, such as the audio-stereo system or
security equipment.
* An airbag inflates with great force. Do not store the
mobile device or any of its accessories in the area above
the bag or in its deployment area.

INTERFERENCE

All wireless devices are susceptible to interference which
can affect their performance.

3

AUTHORISED PERSONNEL

Only qualified personnel are authorized to install or repair
this product

ACCESSORIES

Only use batteries, chargers and other accessories which
are compatible for this device. Do not connect
incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water proof. Keep it dry.

CHILDREN

Keep the mobile device in a safe place out of the reach of
young children. Your mobile device contains small pieces
which can present a choking hazard.

Specification

Display Type: 7 inch TFT panel
Max. Resolution: 800 x 480
Processor Type: 1.2 GHz
Storage drive type: 16GB
System RAM: 512M DDRIII
Operating System: Android 4.1
Touch Panel: Capacitive
Wireless connection: 802.11b/g/n

Built-in battery capacity: 2500mAH Li-Ion rechargeable

battery.
Input: DC 5V---2A

4

1. Outlook Description

Charger Port

Microphone

Power Button

USB Port

Earphones

Volume +

Volume -

MicroSD Slot

2. Power Button Usage

Starting up: Long press the power button for 3 seconds.
 

Screen off and on: Short press power button to turn off or
turn on screen
Mandatory shutdown: If the device has no response, long
press the power button for 6 seconds to perform
mandatory power off

3．Standby screen and applications

5

3-1 Introduction of Main Interface

Press and hold the power button to boot up the machine,
the screen after boot-up is in a locked state, slide on unlock
icon to unlock, then you will enter the main interface as
shown below.
Through this interface you can browse menu used recently,
replace wallpaper, add widgets or program shortcut, open
procedures or carry out the other operations.

3-1-1. Status bar: tap on status bar at the lower right corner
with finger, you can open notification bar to read prompt
message, networking status, battery status, and can also
see today's date and time.
3-1-2. Return button: tap with finger, you can return to
the previous operation or exit the application program.
3-1-3. Main interface: tap main interface button to enter
the main interface:

6

3-1-4. Menu button recently used: touch to pop up
functional menus recently used as follows: Through this
shortcut button, you can quickly access to application
programs running in the backstage and browse traces of
recent use.
3-1-5. Volume - / Volume +: touch this buttons to volume
up or down the device.
3-1-6. Main menu button: touch to open a full-function
menu as follows:

This window shows all functional icons in this machine,
touch any icon to enter the relevant functional interface,
functions of these icons are introduced briefly as follows:

Browser: touch to enter Internet interface and
browsing websites.

Calendar: view calendar and settings.

Calculator.

7

Clock: can set alarm clock.

Music: can play music. Please refer to the
introduction of (3-1.Music) for the method of
operation.

Video: please refer to the introduction of (3-2.
Video) for the method of operation.

Recorder: enter recording interface for recording.
Please refer to the introduction of (3-3. Recording)
for the method of operation.

Camera: please refer to the introduction of (3-4.
Camera) for the method of operation.

3-2．Applications Installation
This machine is free to install APK (abbreviation of Android

Package, namely Android installation package) program,
you can get third-party application programs suitable for
the Android system on the electronic market or through
Internet, and can install it on this machine by yourself.

First open "Settings/Security", tick items behind "Unknown
Source".

8

9

3-2-1．Program access：
Download through Internet, then copy the application

program into TF card or U disk and then insert it into the
machine; or copy files from your computer through USB
cable to the machine.

3-2-2．Program Installation：
Touch main interface shortcut, select "File manager" and

then enter root directory in the SD card, internal storage
or USB (corresponding U disk), then touch the file
manager to be installed in accordance with the Setup
Wizard.

3-2-3．Program Uninstall：
Touch main interface shortcut, select "Play Store" and

then select "Manager" to enter software list, touch the
program to be uninstalled, select "Uninstall" in the pop-up
check box, then touch "OK" to finish uninstall.

3-3． Text input
When you start up a program or select the text edit box

needed for input texts or numbers, a screen keyboard will
appear.

10

4．Internet

4-1．Network setting
Touch status bar at the bottom right, select "Set/Wireless

and Network" to enter network setting interface:

11
