1. INFORMAZIONI GENERALI
BENVENUTI!
Grazie per aver acquistato un prodotto progettato e sviluppato in Italia da dBTechnologies! Questo line-array attivo, potente ed adatto ai live più impegnativi è frutto di una lunga esperienza nel campo della diffusione sonora. Impiega soluzioni innovative ed ottimizzate in campo acustico ed elettronico, oltre che nella ricerca dei materiali.
PANORAMICA INTRODUTTIVA
Il modulo line-array attivo a 3 vie VIO-L212 segna una nuova tappa nel campo della ricerca ed ottimizzazione per le applicazioni professionali live indoor e outdoor di grandi dimensioni. Le caratteristiche più salienti sono:
• ottimizzazione tra prestazioni acustiche full-range e dimensioni
• sistema di appendimento a 3 punti per un
montaggio/smontaggio efciente
• linea di accessori professionali dedicati per la movimentazione ed il montaggio
sezione di amplicazione composta da 2 DIGIPRO G4 da 1600 W RMS ciascuno, controllati
da DSP a 32 bit (ltraggio FIR dedicato)
• tecnologia Floating ADC, sviluppata per un perfetto isolamento da interferenze, rumori o
ronzii, dell’ingresso audio
controllo da DSP e ltraggio in tempo reale con ltri FIR
• rilanci di alimentazione, audio e di rete per un cablaggio ottimizzato
• controllo RDNet on board, predisposizione per protocollo AoIP Audinate DanteTM
• software predittivi e di gestione remota (DBTECHNOLOGIES COMPOSER, EASE, EASE
FOCUS 3, AURORA NET)
32
4500
59
155
30
48,5
330
VIO-L212 Cod. 420120270 REV..1.0
5
CARATTERISTICHE MECCANICHE ED ACUSTICHE
CARATTERISTICHE ACUSTICHE
Italiano
B
A
D
C
D
B
F
E
F
E
A
A - [LF] 2 Woofer in Neodimio di diametro 12”, voice coil da 3”(congurazione reex). B - [MF] 4 Mid-Range in Neodimio di diametro 6.5”, voice coil da 2”. C - [HF] 2 Compression Driver in Neodimio, bocca da 1.4”, bobina in Titanio da 3” (caricamento a tromba). D - Phase plug con camera ottimizzata E - Guide d’onda F - Proli con andamento logaritmico della tromba
L’ottimizzazione acustica di VIO-L212 armonizza le prestazioni (SPL, risposta in fase e in frequenza, focus sonoro) con le dimensioni e i vincoli meccanici di progetto.
In particolare:
• i phase plug [D] con camera ottimizzata aumentano la coerenza delle medie frequenze
• il posizionamento e la distanza dei trasduttori Mid-Range concorre a un focus sonoro e ad un ascolto
fuori asse nettamente deniti
i proli con andamento logaritmico [F] della tromba, evitano tra l’altro, la creazione di riessioni costanti (modi) ed aumentando la coerenza del comparto medie-alte
le guide d’onda [F] controllano la direttività verticale delle alte frequenze
VIO-L212
6
Cod. 420120270 REV. 1.0
Italiano
MECCANICA E DOTAZIONI PRINCIPALI
U
T - PIN DI FISSAGGIO ANTERIORI U - STAFFE A SCOMPARSA PER
IL FISSAGGIO AD UN MODULO SUPERIORE V - SEDI PER IL FISSAGGIO AD UN MODULO INFERIORE
T
V
T
V
Y
W
W- STAFFA POSTERIORE X - GIUNTO MOBILE Y - PIN DI FISSAGGIO POSTERIORI Z - RAIN COVER
Z
X
Il sistema di ssaggio a 3 punti impiega, tramite l’utilizzo di pin:
• le staffe superiori U, sul lato frontale
• le sedi inferiori V, sul lato frontale
• la staffa W, con giunto X, sul lato posteriore.
Nelle immagini successive, per semplicità, non saranno più rafgurati i rain cover [Z].
Z
VIO-L212 Cod. 420120270 REV..1.0
7
Per il ssaggio di due moduli:
LATO ANTERIORE
Italiano
1) Sul modulo B estrarre verso l’altole staffe U e ssarle con i
relativi pin.
2) Estrarre i pin T dal modulo A
3) Avvicinare i 2 moduli
inserendo le staffe U nelle sedi V.
4) Inserire completamente i pin
T. In questo modo i moduli A e B sul lato frontale risultano
bloccati.
LATO POSTERIORE
5) Sul modulo A sbloccare il giunto X. Inserire quindi il pin Y nel foro relativo
all’inclinazione desiderata.
I dettagli relativi a questa operazione sono illustrati nella pagina successiva. Sono differenti a seconda
dell’installazione FLOWN o
STACK.
A
T
U
T
U
B
V
U
T
VIO-L212
8
B
A
X
W
Y
X
Y
W
Cod. 420120270 REV. 1.0
Italiano
PIN 2
PIN 1
INSTALLAZIONE FLOWN
X
E’ necessario un solo pin (PIN 1) per ssare l’angolo
sul retro. I fori di inserimento della staffa W, con colori differenziati, permettono le angolazioni: [0°, 0.5°, 1°, 2°,
3°, 4.5°, 6°, 8°]. L’asola della staffa consente di inserire i
pin senza dover sollevare il retro di VIO-L212.
INSTALLAZIONE STACKED
Sono necessari 2 pin (PIN1, PIN2) per ssare l’angolo
sul retro. Una volta inserito PIN1, come da procedura
FLOWN, si alza il retro di VIO-L212 nchè l’asola lo permette e si ssa la posizione con il PIN2.
W
VIO-L212 Cod. 420120270 REV..1.0
9
2. CONTROLLI LOCALI E CONNESSIONI
I 2 amplicatori DIGIPRO G4 sono in grado di erogare no a 3200 W RMS. Lo schema a blocchi dell’elettronica di VIO-L212 è rafgurato nella pagina
seguente.
Le due sezioni principali, presenti sul retro del modulo, e protette dagli apposti rain cover (che non
mostriamo qui) sono:
• CONNESSIONI E CONTROLLO
• ALIMENTAZIONE
La sezione CONNESSIONI E CONTROLLO, utilizza un DSP che
controlla, tra l’altro, il ltraggio FIR del segnale d’uscita.
Italiano
La sezione di ALIMENTAZIONE impiega un PFC che ne migliora
l’efcienza e protegge la sezione di amplicazione da oscillazioni
indesiderate delle grandezze elettriche in ingresso.
FILTRAGGIO FIR
L’equalizzazione del suono è controllata da un DSP a 32 bit.
I ltri FIR implementati minimizzano la
distorsione di fase del segnale equaliz­zato. Per i dettagli dell’equalizzazione
vedi il paragrafo: “PARAMETRI DSP
PRESET”.
PFC
La correzione del fattore di potenza (PFC) riduce lo sfasamento tra corrente e tensione erogata all’amplicatore. Entro un certo range, quindi, l’alimentazione
in ingresso risulta ideale, nonostante
piccole variazioni della fornitura elettri­ca a monte dell’impianto. Per dettagli ulteriori sulle raccomandazioni di ali­mentazione, vedi il paragrafo: “MON-
TAGGIO DEL LINE ARRAY E CABLAGGIO”.
AMP2-ALIMENTAZIONE
AMP1-CONNESSIONI E CONTROLLO
VIO-L212
10
Cod. 420120270 REV. 1.0
M A
I N
S F
U S E
1 0 0
­1 2 0 V
~
( T
1 0 A
L 2
5 0 V ~ )
2 2 0
­2 4 0 V
~
( T
5 A
L 2
5 0 V ~ )
M A
I N
S F
U S E
1 0 0
­1 2 0 V
~
( T
1 0 A
L 2
5 0 V ~ )
2 2 0
­2 4 0 V
~
( T
5 A
L 2
5 0 V ~ )
Italiano
AUTO-RANGE
MAINS LINK
MAINS INPUT
Link
Output
Input
Balanced Audio
BLOCK DIAGRAM
PUSH
M
(
(
T
T
1
5
A
0
A
2
I
A
1
2
N
L
0
0
L
S
2
0
­2
2
5
-
F
1
4
5
0
U
2
0
0
V
V
0
S
V
~
V
~
E
~
)
~
)
FUSE
Power Supply
FUSE
Power Supply
EMI FILTER
Amplifier Module
Amplifier Module
SMPS MAIN
Voltage
DIGIPRO G4
Amplifier
CLASS D
High
DIGIPRO G4
CLASS D
Voltage
DIGIPRO G4
Amplifier
CLASS D
M
(
(
T
T
1
5
A
0
A
2
I
A
1
2
N
L
0
0
L
S
2
0
­2
2
5
-
F
1
4
5
0
U
2
0
0
V
0
V
S
V
~
V
~
E
~
)
~
)
EMI FILTER
SMPS MAIN
High
DIGIPRO G4
CLASS D
Floating Input GroundFloating Input Ground
Low
Voltage
Low
Voltage
Low
Voltage
OPAMP
Floating ADC technology
ADC
Galvanic
Isolation
Preamplifier Module
DAC
Active
Link
NFC internal module
DSP
Out
Rs485
RDNET
Data
Data
In
RDNet
Rs485
CPU (MASTER)
Removable Card
SPEAKERS
COUPLING
D
USB Data Service
COMPENSATION
HIGH FREQ
5
F
E
C
B
7
6
4
3
G
A
8
1
2
Service / User
75
85
90
80
70
60
65
High Pass Filter [Hz]
Remote Preset
Active
Fullrange
1.4" C.D.
1.4" C.D.
12" WOOFER
12" WOOFER
6.5" MID-RANGE
6.5" MID-RANGE
6.5" MID-RANGE
6.5" MID-RANGE
Ready
Mute/Prot
Signal
Limiter
System Test
VIO-L212 Cod. 420120270 REV..1.0
11
1. INGRESSO E RILANCIO AUDIO (“Balanced audio”)
Ingresso e uscita compatibili con cavi XLR blanciati. In particolare, “Input” è utilizzato per il collegamento con il segnale audio proveniente dal mixer o da un altro diffusore, “Output Link” per il rilancio del segnale agli altri moduli del line-
array in congurazione daisy-chain.
2. HIGH PASS FILTER
Permette di applicare direttamente un ltro passa-alto (non applicato, la posizione stand-by è Fullrange). In
particolare le frequenze di taglio possono essere scelte tra:
(60,65,70,75,80,85,90 Hz)
3. INGRESSO E RILANCIO DELLA CONNESSIONE DI RETE RDNet
Sezione compatibile con cavi di rete dotati di connettori di tipo etherCON/RJ45. In particolare “Data in” deve essere collegato a dispositivi come RDNet Control 2 o Control 8, “Data Out” viene utilizzato per il rilancio della rete ad ulteriori moduli del line-array in
congurazione daisy-chain.
Italiano
4. DSP PRESET Rotary per il setup acustico del line-array.
E’ opportuno utilizzare questi controlli (o gli stessi parametri in remoto tramite connessione RDNet) per ottimizzare il
comportamento acustico in funzione del numero di moduli
ed al loro puntamento. Un approfondimento sull’utilizzo di
“SPEAKER COUPLING” e “HIGH FREQUENCY COMPENSATION” è presente nella sezione “PARAMETRI DSP PRESET E CONTROLLO
REMOTO”.
5. LED DI STATO
Led relativi al funzionamento del modulo. Una tabella nella
pagina seguente riepiloga e sintetizza il signicato dei vari LED.
6. LED DI CONTROLLO
Led relativi al funzionamento in rete (RDNet) del modulo.
In particolare, “Link” acceso segnala che la rete RDNet è attiva e ha riconosciuto il dispositivo, “Active” in modalità
lampeggiante che esiste trafco dati, “Remote Preset Active” che tutti i controlli locali sul pannello amplicatore sono by-
passati dal controllo remoto RDNet.
7. USB DATA SERVICE Porta di tipo mini-USB B, da utilizzare esclusivamente per
l’aggiornamento del rmware del prodotto. Vedi la sezione
“AGGIORNAMENTO DEL FIRMWARE” per ulteriori informazioni.
8. SYSTEM TEST
Effettua un test con segnale sweep per vericare l’integrità del woofer. Questo test non va considerato esaustivo, ma solo un primo controllo nell’analisi di
eventuali problematiche
9. FUSIBILE DI RETE Alloggio per il fusibile di rete della sezione AMP1.
VIO-L212
12
Cod. 420120270 REV. 1.0
Italiano
TIPO LED FASE DI ACCENSIONE
DELLO SPEAKER
IN FUNZIONE NORMALE
WARNING GENERICO
BLOCCO PER ANOMALIA DELLO SPEAKER
LIMITER SPENTO SPENTO, SI
ACCENDE SOLO IN CASO DI INTERVENTO
SIGNAL
MUTE/ PROT
READY SPENTO ACCESO FISSO ACCESO FISSO SPENTO
10. CONNETTORE DI ALIMENTAZIONE “MAINS INPUT” Compatibile con connettore powerCON TRUE1®,
l’alimentazione è dotata di funzione autorange. Una volta denito il range opportuno con l’eventuale cambio del fusibile, riconosce automaticamente la tensione all’interno dell’intervallo [100-120V~] oppure [220-240V~].
SPENTO LAMPEGGIO
ACCESO PER QUALCHE SECONDO
IN PRESENZA DI SEGNALE
SPENTO LAMPEGGIO
LAMPEGGIO MOMENTANEO
SEGNALAZIONE NORMALE DI AUDIO IN INGRESSO
MOMENTANEO
LAMPEGGIO CICLICO CONTINUO
SPENTO
ACCESSO FISSO
11. RILANCIO DI ALIMENTAZIONE “MAINS LINK” Compatibile con connettore tipo powerCON TRUE1® per il
rilancio dell’alimentazione ad altri moduli.
Per conoscere il numero massimo di moduli che si possono connettere in un sistema rilanciato, consultare la sezione
SPECIFICHE TECNICHE.
12. FUSIBILE DI RETE Alloggio per il fusibile di rete della sezione AMP2.
VIO-L212 Cod. 420120270 REV..1.0
13
3. PREDIZIONE ACUSTICA E VERIFICA MECCANICA: DBTECHNOLOGIES COMPOSER
Il software dBTechnologies Composer, gratuitamente scaricabile dal sito www.dbtechnologies.com, è lo strumento per la corretta progettazione di sistemi audio consigliato per tutta la serie VIO.
Suggerisce la soluzione per gli spazi da sonorizzare, indicando l’angolazione dei moduli del line-array per
ottenere la copertura desiderata ed il preset da utilizzare. Pur essendo uno strumento predittivo, permette comunque una serie di regolazioni manuali per
perfezionare la congurazione in base ad eventuali misure audio effettuate sul campo, o a speciche
esigenze.
E’ inne lo strumento efcace per valutare la sicurezza dell’installazione. Grazie infatti a una simulazione del comportamento statico dei y-bar ed una indicazione delle forze meccaniche in gioco permette di vericare quanti moduli installare prima di arrivare ad una condizione di sovraccarico.
Le sezioni principali di dBTechnologies Composer sono:
• COMPOSER - vista generale che permette l’inserimento dei dati iniziali di progetto
• LAs PREDICT - con la simulazione, congurazione e verica di sicurezza dei line-array
• SUBs PREDICT - con la simulazione, congurazione e verica di sicurezza dei subwoofer
Italiano
In questo capitolo vengono evidenziati alcuni dettagli del software relativi al montaggio e alla sicurezza, in
particolare per la congurazione FLOWN dei line-array VIOL212.
VIO-L212
14
Cod. 420120270 REV. 1.0
Italiano
La sezione LAs PREDICT contiene tutte le informazioni per la corretta congurazione own o stack di un sistema VIO. Per accedervi occorre completare prima l’inserimento dei dati di progetto, presenti nella
sezione Composer.
Nella sottopagina System Data, vengono suggeriti: l’angolazione dei vari moduli, vari parametri relativi alla sezione “DSP preset” e l’angolazione del y-bar DRK-212. Quest’ultima angolazione può essere rilevata sul campo tramite l’utilizzo di un inclinometro laser non incluso, il cui montaggio è illustrato nel manuale
di DRK-212.
VIO-L212 Cod. 420120270 REV..1.0
15
4. AURORA NET
AURORA NET, è un software di controllo remoto con queste caratteristiche:
multipiattaforma (Windows /MAC OS X)
• permette un controllo molto accurato dei parametri e della loro cronologia durante un evento
permette una gestione essibile anche in casi di grandi installazioni sse / live (con un controllo
avanzato dei gruppi)
• consente di richiamare diversi preset
• è ottimizzato per usabilità e velocità di visualizzazione dei dati
Per ulteriori informazioni si rimanda al manuale completo del software.
Italiano
VIO-L212
16
Cod. 420120270 REV. 1.0
Italiano
5. PARAMETRI DSP PRESET
L’utilizzo di un line-array comporta una serie di vantaggi in diversi contesti, in particolare:
• SPL omogeneo lungo la direttrice frontale degli speaker, effetto che si apprezza in particolare su
distanze medio-lunghe
• comportamento acustico direttivo, che permette di focalizzare in maniera precisa il suono sul pubblico,
evitando inutili dispersioni in zone dove una copertura acustica non è richiesta.
L’ottimizzazione attuabile del line-array tiene conto del comportamento del sistema rispetto alla frequenza:
all’aumentare della distanza dal line-array aumenta l’attenuazione dell’aria. Questo ha effetto in
particolare sulle alte frequenze.
all’aumentare dell’angolazione tra elementi del line-array diminuisce l’accoppiamento in fase delle
medie frequenze.
all’aumentare del numero di moduli del line-array le basse frequenze si sommeranno in maniera
acusticamente coerente.
La congurazone acustica in line-array dei moduli VIO L212 può essere ottimizzata, grazie alle funzioni di controllo gestite dal DSP. L’interfaccia locale per l’utilizzo è semplice e immediata: impiega due rotary della
sezione “DSP Preset” :
Il calcolo dei parametri è effettuato con dBTechnologies Composer. E’ possibile selezionare in modo locale tali parametri sul pannello di VIO-L212, ed utilizzare inoltre il controllo remoto tramite AURORA NE T.
• Posizionare il rotary “SPEAKER COUPLING” in base al numero di moduli impiegati nel line array. Questo rotary agisce sulle basse frequenze e va impostato nella posizione:
• Tutti questi parametri possono essere regolati attraverso il controllo remoto, una volta effettuate
correttamente le connessioni RDNet, attraverso l’utilizzo del software gratuito AURORA NET. Quando il
controllo è remoto, i controlli locali presenti sui pannelli dei moduli VIO-L212 sono by-passati.
Per ulteriori informazioni si rimanda al manuale completo del software.
VIO-L212 Cod. 420120270 REV..1.0
17
6. ACCESSORI, INSTALLAZIONE, CONFIGURAZIONE
FLY-BAR DRK-212
B2
Italiano
A
A
C
D2
B1
C
D1
DRK-212 è il y-bar per l’utilizzo FLOWN e STACK di VIO-L212. In FLOWN consente la possibilità di un doppio utilizzo, con line-array angolato verso il basso oppure verso l’alto. Vedere le istruzioni speciche dell’accessorio
per i dettagli di montaggio.
• A - Ganci di sollevamento motore
B - Giunto posteriore (in dipendenza dalla congurazione) FLOWN
• C - Staffe a scomparsa frontali per utilizzo STACK
D - Fissaggi anteriori FLOWN (in dipendenza dalla congurazione)
D2
ADATTATORI FRA MODELLI
NOME MODELLO ADATTATO
CARRELLI
VIO-L212
18
TF-VIO2
NOME UTILIZZO TOP
DT-VIOl212
DO-VIOl212
DT-DRK212 2 DRK212 (+ 2 TF-VIO2)
1-4 VIOL212
1 VIOL212
VIOL210
Cod. 420120270 REV. 1.0
Italiano
PREDIZIONE ACUSTICA / VALIDAZIONE MECCANICA
• Utilizzare DBTECHNOLOGIES COMPOSER per impostare i parametri di progetto.
Vericare che la validazione MECHANICAL SAFETY del software confermi la sicurezza della congurazione
scelta
Vericare che i parametri locali dei vari moduli siano impostati correttamente sui singoli pannelli
amplicatori. In particolare vericare secondo progetto le impostazioni Speaker Coupling e High Frequency Compensation. In alternativa è possibile modicare in tempo reale tutti i parametri da remoto se si effettua una connessione del line-array tramite rete RDNet (DBTECHNOLOGIES NETWORK). In questo caso comunque è buona norma che le impostazioni iniziali di progetto siano replicate sicamente sui moduli VIO-L210 prima dell’installazione. Per altre informazioni vedi la sezione PARAMETRI DSP PRESET E CONTROLLO REMOTO.
PREPARAZIONE DEL FLY-BAR E DEI MODULI
Predisporre i y bar DRK212 ed i moduli line-array VIO-L212. In questo esempio sono rafgurati i carrelli DT-
DRK212 e i carrelli DT-VIOL212 con i top DTT-VIOL212. La congurazione di esempio, puramente illustrativa, è
quella di un line-array a 8 moduli.
LE INDICAZIONI DI CABLAGGIO NELLE FIGURE SEGUENTI SONO PURAMENTE INDICATIVE.
VIO-L212 Cod. 420120270 REV..1.0
19
Italiano
MONTAGGIO DEL LINE-ARRAY E CABLAGGIO
Rimuovere la cinghia di sicurezza ed il top. Sul retro dei moduli inserire i pin per ssare gli angoli calcolati dal software.
Tramite i motori, sollevare dal carrello DT-DRK212 1 y bar e ssarlo in congurazione own sul top VIO-L212 superiore.
Sul y-bar, aver cura di far passare per la successiva connessione i cablaggi principali necessari.
• Effettuare i primi cablaggi tra i singoli moduli, in particolare quelli rilanciabili.
• Sollevare la parte superiore del line array
VIO-L212
20
Cod. 420120270 REV. 1.0
Italiano
• Portare il carrello con gli ulteriori 4 moduli sotto a quelli issati. Rimuovere cinghia e top dal secondo carrello.
• Operare agganciando un modulo alla volta, facendo salire/scendere leggermente le funi con i motori, prima con montaggio frontale, poi posteriore, come illustrato nella sezione MECCANICA E DOTAZIONI PRINCIPALI.
• Operare i cablaggi tra modulo e modulo, mano a mano che si procede col montaggio.
• Terminare la composizione ed il cablaggio del line-array.
ATTENZIONE!
Il prodotto e gli accessori devono essere utilizzati solo da personale esperto! Assicurarsi che l’installazione sia posizionata in modo stabile e sicuro per scongiurare ogni condizione di pericolo per persone, animali e/o cose. L’utilizzatore è tenuto a seguire le regolamentazioni e le leggi cogenti in materia di sicurezza nel Paese
in cui si utilizza il prodotto. Per l’utilizzo in sicurezza, vericare periodicamente la funzionalità di tutte le parti e l’integrità prima dell’utilizzo.
La progettazione, i calcoli, l’installazione, il collaudo e la manutenzione di sistemi sospesi o stack audio pro-
fessionali deve essere effettuata esclusivamente da personale autorizzato. AEB Industriale non è responsabile per installazioni improprie, effettuate in assenza dei requisiti di sicurezza.
A
B
VIO-L212 Cod. 420120270 REV..1.0
21
INDICAZIONI SULL’ALIMENTAZIONE ED IL COMPORTAMENTO DEL SISTEMA LINE-ARRAY
Occorre tenere presente che l’alimentazione dell’impianto, con un corretto dimensionamento della sorgente e dei cablaggi,
inuisce sulla corretta operatività dei moduli e del sistema.
1. La corrente fornita al modulo line-array ha un comporta­mento dinamico, (es. prima accensione, stato di idle, funzi-
onamento a pieno regime).
2. Esistono delle cadute di tensione legate a lunghezza e sezione del cavo. Di norma tali cadute sono direttamente proporzionali alla lunghezza ed inversamente alla sezione dei cavi.
Italiano
A
B
A
B
A
B
VIO-L212
22
Cod. 420120270 REV. 1.0
Italiano
ESEMPI DI CONFIGURAZIONI MISTE
D
C
D2
A
B
A
B
Tramite l’adattatore TF-VIO2, è possibile utilizzare un line-array VIO-L210 in funzione down-ll sotto ad uno composto da VIO-L212. La proporzione consigliata fra i 2 modelli è di 3:1 come illustrato, a puro titolo di esempio, qui sotto.
• A - Staffe frontali per VIO-L212
B - Sistemi di ssaggio anteriori per VIO-L210
• C - Giunto posteriore per VIO-L210
• D - Staffa di aggancio posteriore per VIO-L212
VIO-L212 Cod. 420120270 REV..1.0
23
ESEMPI DI CONFIGURAZIONI STACKED
Le principali congurazioni stack sono:
su subwoofer (tramite DRK-212)
diretta su carrello DT-VIOL212 con l’utilizzo
obbligatorio delll’accessorio EFK-1.
Italiano
Per i dettagli di montaggio e le congurazione ammesse riferirsi ai manuali dei singoli accessori.
VIO-L212
Cod. 420120270 REV. 1.0
24
Italiano
7. RISOLUZIONE DEI PROBLEMI
Il modulo non si accende:
1. Vericare la corretta presenza dell’alimentazione a monte dell’impianto.
2. Vericare che l’alimentazione o il collegamento di rilancio di alimentazione sia correttamente inserito.
3. Vericare che la sezione e la lunghezza dei cablaggi permettano, comprese le cadute di tensione, un
funzionamento all’interno del range consentito.
4. Vericare eventuali warning segnalati da AURORA NET (in collegamento RDNet)
Il modulo si accende ma non emette nessun suono:
1. Vericare che i collegamenti in ingresso del segnale audio o i rilanci del segnale audio siano correttamente effettuati.
2. Vericare che la sorgente audio (mixer) sia collegata correttamente ed attiva.
3. Vericare da controllo remoto tramite AURORA NET (in collegamento RDNet) che non siano inseriti
MUTE. Vericare inoltre eventuali warning segnalati.
Il modulo emette un suono non pienamente soddisfacente.
1. Rivericare il progetto e le speciche di installazione e congurazione tramite DBTECHNOLOGIES COMPOSER.
2. Vericare che i parametri di DSP PRESET siano effettivamente replicati sul pannello di controllo del
modulo (soprattutto in caso non si utilizzi il controllo remoto dei moduli).
3. Vericare che, in caso di connessione in rete RDNet e controllo con AURORA NET tutti i parametri, in particolare quelli di equalizzazione, siano impostati correttamente.
VIO-L212 Cod. 420120270 REV..1.0
25
Italiano
8. AGGIORNAMENTO DEL FIRMWARE
È molto importante mantenere aggiornato il rmware del prodotto, per garantirne una piena funzionalità. Controllare periodicamente il sito http://www.dbtechnologies.com nella sezione “DOWNLOADS”.
1. Scaricare ed installare USB BURNER MANAGER nella sezione “SOFTWARE & CONTROLLER” sul proprio computer.
2. Scaricare il le .zip dell’ultimo rmware nella sezione “DOWNLOADS” relativa al proprio prodotto.
3. Collegare il prodotto al PC tramite un cavo USB (non fornito) con il connettore del tipo corretto (vedere questo dettaglio nel capitolo CARATTERISTICHE DELLA SEZIONE DI AMPLIFICAZIONE E DI CONTROLLO).
4. Nella schermata dell’USB BURNER MANAGER, in alto a destra, selezionare “Apertura File”.
5. Selezionare il le del rmware precedentemente scaricato.
6. Seguire le operazioni mostrate a video.
7. Cliccare “AGGIORNA”.
VIO-L212
26
Cod. 420120270 REV. 1.0
Italiano
9. SPECIFICHE TECNICHE
GENERALE
Tipologia: Modulo line-array attivo a 3 vie
DATI ACUSTICI
Risposta in frequenza [- 10 dB]: 49.8 - 20000 Hz
Risposta in frequenza [- 6 dB]: 55 - 18600 Hz
Max SPL: 142 dB (frequency/preset dependent)
HF: 2 x 1.4” (Bobina: 3”)
Tipo di trasduttore HF: Titanio
MF: 4 x 6.5” (Bobina: 2”)
Tipo di trasduttore MF: Neodimio
LF: 2 x 12” (Voice Coil: 3”)
Tipo di trasduttore LF: Neodimio
Guida d’onda per le alte frequenze:
Direttività oizzontale: 90°
Direttività verticale: variabile, in dipendenza da congurazione e numero di moduli
AMPLIFICATORE
Tipologia: (2x) Digipro® G4
Classe di amplicazione: Classe D
Potenza di amplicazione (Picco) 2x 1600 W (3200 W)
Potenza di amplicazione (RMS): 2x 3200 W (6400 W)
Alimentazione: Fullrange con PFC, range 100-240V~ (50-60Hz)
Tecnica di rareddamento: Convezione + ventole con griglie di ventilazione inferiori
Temperatura di utilizzo (ambiente): da -15° a +55° [°C]
VIO-L212 Cod. 420120270 REV..1.0
27
PROCESSORE
Controller interno: DSP 32 bit
Conversione AD/DA: 24 bit / 96 kHz
Funzioni avanzate del DSP: Filtri FIR a fase lineare
Riconoscimento del posizionamento: inclinometro, modulo a tecnologia NFC
Funzione interna di primo test: test di impedenza con sweep
INTERFACCIA UTENTE
Controlli: HPF rotary, DSP Preset
Led di stato Ready, Mute/Prot, Signal, Limiter
Italiano
Led di interfaccia RDNet Link, Active, Remote Preset Active
INGRESSI ED USCITE
Ingressi e rilanci di alimentazione: PowerCON® True In/Link
Ingressi audio: 1x XLR IN bilanciato (isolamento: Floating ADC )
Uscite audio: 1x XLR link OUT bilanciato
Ingressi/uscite RDNet: Data In / Data Out (connettori etherCON®)
USB (aggiornamento del rmware): 1x USB MINI tipo B
COMPATIBILITA’ SOFTWARE
Soware predittivo/validazione dBTechnologies COMPOSER
Soware di controllo remoto: AURORA NET
Altri soware: Ease, Ease Focus 3
VIO-L212
28
Cod. 420120270 REV. 1.0
Italiano
SPECIFICHE DI ALIMENTAZIONE (ASSORBIMENTO)
Assorbimento a 1/8 della potenza in
condizioni medie di utilizzo (*):
Assorbimento a 1/3 della potenza in
condizioni massime di utilizzo (**):
Assorbimento con speaker acceso in
assenza di segnale (idle):
Corrente di inrush:
2 A (230V~) - 3.1 A (115V~)
4.9 A (230V~) - 7.5 A (115V~)
53 W
3.2 A
Numero di moduli massimo per linea di alimentazione (**)
1 + 2 (220-240V~) / 1 + 1 (100-120V~)
[mains input + mains link]:
* NOTA PER L’INSTALLATORE: Valori riferiti a 1/8 della potenza, in condizioni medie di funzionamento (programma musicale con clipping raro
o assente). Si consiglia per qualsiasi tipo di congurazione di considerarli i valori minimi di dimensionamento.
** NOTA PER L’INSTALLATORE: Valori riferiti a 1/3 della potenza, in condizioni pesanti di funzionamento (programma musicale con frequente
clipping e intervento del limiter). E’ consigliabile il dimensionamento secondo questi valori in caso di installazioni e tour professionali.
SPECIFICHE MECCANICHE
Materiale: cabinet in legno - nitura in polliurea nera
Griglia: interamente in metallo - lavorazione CNC
Maniglie integrate (2x lato)
Predisposizioni anteriori di montaggio: Predisposizioni posteriori di montaggio:
Stae a scomparsa, punti integrati nel cabinet con pin a sgancio
rapido
Staa graduata e giunto mobile con pin a sgancio rapido
Montaggio own e stacked: Con accessorio y -bar DRK-212
Larghezza: 1100 mm (43.31 inch.)
Altezza: 380 mm (14.96 inch.)
Profondità: 450 mm (17.72 inch.)
Peso: 54.4 kg (119.9 lbs.)
Le caratteristiche, le speciche e l’aspetto dei prodotti sono soggetti a possibili cambiamenti senza previa comunicazione. dBTechnologies si riserva il diritto di apportare cambiamenti o miglioramenti nel design o nelle lavorazioni senza assumersi l’obbligo di cambiare o migliorare anche i prodotti precedentemente realizzati.
A.E.B. Industriale Srl
Via Brodolini, 8
Località Crespellano
40053 VALSAMOGGIA
BOLOGNA (ITALIA)
Tel +39 051 969870
Fax +39 051 969725
www.dbtechnologies.com
info@dbtechnologies-aeb.com
VIO-L212 Cod. 420120270 REV..1.0
29
English
TABLE OF CONTENTS
TABLE OF CONTENTS
1. GENERAL INFORMATION ......................................................................................................31
WELCOME! .........................................................................................................................31
PRODUCT OVERVIEW .........................................................................................................31
MECHANICAL AND ACOUSTICAL FEATURES .....................................................................32
ACOUSTICAL FEATURES ............................................................................................................................. 32
MECHANICS AND MAIN EQUIPMENT ....................................................................................................... 33
2. LOCAL CONTROLS AND CONNECTIONS ..............................................................................36
3. ACOUSTIC PREDICTION AND MECHANICAL TESTING: DBTECHNOLOGIES COMPOSER 40
4. AURORA NET ..........................................................................................................................42
5. DSP PRESET PARAMETERS ....................................................................................................43
6. ACCESSORIES, INSTALLATION, CONFIGURATION ..............................................................44
FLY-BAR DRK-212 ................................................................................................................44
MOUNT SOCKETS FOR DIFFERENT MODELS ....................................................................44
DOLLIES ...............................................................................................................................44
ACOUSTIC PREDICTION / MECHANICAL TESTING .............................................................45
PREPARATION OF THE FLY-BAR AND MODULES ...............................................................45
LINE-ARRAY ASSEMBLY AND WIRING ...............................................................................46
EXAMPLES OF MIXED CONFIGURATIONS .........................................................................49
EXAMPLES OF STACKED CONFIGURATIONS .....................................................................50
7. TROUBLESHOOTING ..............................................................................................................51
8. FIRMWARE UPDATES .............................................................................................................52
9. SPECIFICATIONS .....................................................................................................................53
GENERAL .................................................................................................................................................... 53
ACOUSTICAL SPECIFICATIONS ................................................................................................................... 53
AMPLIFIER .................................................................................................................................................. 53
PROCESSOR ................................................................................................................................................ 54
USER INTERFACE ........................................................................................................................................ 54
INPUTS AND OUTPUTS .............................................................................................................................. 54
SOFTWARE COMPATIBILITY ...................................................................................................................... 54
POWER SUPPLY SPECIFICATIONS (ABSORPTION) .................................................................................... 55
MECHANICAL SPECIFICATIONS ................................................................................................................. 55
VIO-L212
30
Code 420120270 REV. 1.0
1100
380
330
English
1. GENERAL INFORMATION
WELCOME!
Thanks for purchasing a product designed and developed in Italy by dBTechnologies! This powerful active line-array, suitable for the most demanding live performances, is the result of years of experience
in the eld of sound reinforcement. It makes use of innovative optimized sound, electronic and material research
solutions.
PRODUCT OVERVIEW
The VIO-L212 3-way active line-array module marks
a new era in the research and optimization eld for
large-sized indoor and outdoor professional live applications. The key features are:
• optimization between full-range acoustic
performance and sizes
• a 3-point integrated rigging system for an
efcient assembly/disassembly
professional accessory line specic for handling
and assembly
amplication section comprising 2 DIGIPRO G4
1600 W RMS each, controlled by DSP at 32 bits
(special FIR ltering)
• ADC Floating technology, developed for a perfect
isolation from interference, noise or hums, of the audio input
DSP control and real-time ltering with FIR lters
• power, audio and mains daisy chains for
optimized wiring
• on-board RDNet control, pre-set for AoIP
Audinate DanteTM protocol
• predictive and remote management software
(DBTECHNOLOGIES COMPOSER, EASE, EASE
FOCUS 3, AURORA NET)
32
4500
59
155
30
48,5
VIO-L212 Code 420120270 REV. 1.0
31
MECHANICAL AND ACOUSTICAL FEATURES
ACOUSTICAL FEATURES
English
B
A
D
C
D
B
F
E
F
E
A
A - [LF] 2 Neodymium Woofer with a 12” diameter, 3” voice coil (reex conguration). B - [MF] 4 Neodymium Mid-Range with a 6.5” diameter, 2” voice coil. C - [HF] 2 Neodymium Compression Driver, 1.4” exit throat, 3” titanium diaphragm (horn driver).
D - Phase plug with optimized chamber E - Waveguides F - Proles with horn's logarithmic trend
VIO-L212's acoustic optimization harmonizes performance (SPL, phase and frequency response, sound focus)
with design sizes and mechanical constraints. Especially:
• the phase plugs [D] with optimized chamber increase the mid-frequency consistency
the positioning and the distance of Mid-Range transducers contribute to clearly dened sound focus and off-axis listening position
the logarithmic trend proles [F] of the horn, avoid among others, the creation of constant reections
(modes) and increase the consistency of the mid-high section
• the waveguides [F] control the vertical directivity of high frequencies
VIO-L212
32
Code 420120270 REV. 1.0
English
MECHANICS AND MAIN EQUIPMENT
U
T - FRONT FASTENING PINS U - RETRACTABLE BRACKETS FOR
FASTENING TO AN UPPER MODULE
V - S EATS FOR FASTENING TO A
LOWER MODULE
T
V
T
V
Y
W
W- REAR BRACKET X - MOVABLE JOINT Y - REAR FASTENING PINS Z - RAIN COVER
Z
X
The 3-point fastening system uses, by means of pins:
• the upper brackets U, on the front side
• the lower seats V, on the front side
• the W bracket, with movable joint X, on the rear side.
For simplicity's sake the next images are no longer shown with the rain covers [Z].
Z
VIO-L212 Code 420120270 REV. 1.0
33
For fastening two modules:
FRONT SIDE
English
1) On the B module move the U brackets upwards and fasten them with the related pins.
2) Remove the T pins from module A
3) Move the 2 modules close to
one another inserting the U brackets in the V seats.
4) Insert the T pins completely. By doing this the A and B modules at the front are blocked.
REAR SIDE
5) On module A release the movable joint X. Then insert the Y pin in the hole that corresponds to the desired tilt.
The details describing this operation are shown in the next page. They are different depending on the FLOWN or STACK installation.
A
T
U
T
U
B
V
U
T
VIO-L212
34
B
A
X
W
Y
X
Y
W
Code 420120270 REV. 1.0
English
PIN 2
PIN 1
FLOWN INSTALLATION
X
Only one pin (PIN 1) is required to fasten the angle at
the back. The differently coloured inserting holes of the W bracket, allow the following tilting: [0°, 0.5°, 1°, 2°, 3°, 4.5°, 6°, 8°]. The bracket slot allows inserting the pin without lifting the rear of VIO-L212.
STACKED INSTALLATION
Two pins (PIN1, PIN2) are necessary to fasten the angle
at the back. Once PIN1 has been introduced, according to the FLOWN procedure, the rear of VIO-L212 lifts as much as the slot allows it and the position is secured with PIN2.
W
VIO-L212 Code 420120270 REV. 1.0
35
2. LOCAL CONTROLS AND CONNECTIONS
The 2 DIGIPRO G4 ampliers can
supply up to 3200 W RMS. The block diagram of electronics of VIO-L212 is illustrated in the next page.
The two main sections, present at the rear of the module, and protected by
the specic rain covers (not shown here) are:
• CONNECTIONS AND CONTROL
• POWER SUPPLY
The CONNECTIONS AND CONTROL section uses a DSP that controls, among others, the output signal FIR
ltering.
English
The POWER SUPPLY section uses a
PFC which improves its efciency and protects the amplication section
from undesired oscillations of the input power supply.
FIR FILTERING
Sound equalization is controlled by a 32-bit DSP.
The implemented FIR lters minimize the phase distortion of the equalized signal. For more equalization informa­tion, please refer to paragraph: “DSP
PRESET PARAMETERS”.
PFC
The power factor correction (PFC) reduces the out of phase condition between current and voltage supplied to the amplier. Within a certain range the input power supply is ideal, regardless of small variations in the power supply before the system. For more information concerning power supply suggestions, please refer to section: “LINE-ARRAY
ASSEMBLY AND CONNECTIONS”.
AMP2-POWER SUPPLY
AMP1-CONNECTIONS AND CONTROL
VIO-L212
36
Code 420120270 REV. 1.0
M A
I N
S F
U S E
1 0 0
­1 2 0 V
~
( T
1 0 A
L 2
5 0 V ~ )
2 2 0
­2 4 0 V
~
( T
5 A
L 2
5 0 V ~ )
M A
I N
S F
U S E
1 0 0
­1 2 0 V
~
( T
1 0 A
L 2
5 0 V ~ )
2 2 0
­2 4 0 V
~
( T
5 A
L 2
5 0 V ~ )
English
AUTO-RANGE
MAINS LINK
MAINS INPUT
Link
Output
Input
Balanced Audio
BLOCK DIAGRAM
PUSH
M
(
(
T
T
1
5
A
0
A
2
I
A
1
2
N
L
0
0
L
S
2
0
­2
2
5
-
F
1
4
5
0
U
2
0
0
V
V
0
S
V
~
V
~
E
~
)
~
)
FUSE
Power Supply
FUSE
Power Supply
EMI FILTER
Amplifier Module
Amplifier Module
SMPS MAIN
Voltage
DIGIPRO G4
Amplifier
CLASS D
High
DIGIPRO G4
CLASS D
Voltage
DIGIPRO G4
Amplifier
CLASS D
M
(
(
T
T
1
5
A
0
A
2
I
A
1
2
N
L
0
0
L
S
2
0
­2
2
5
-
F
1
4
5
0
U
2
0
0
V
0
V
S
V
~
V
~
E
~
)
~
)
EMI FILTER
SMPS MAIN
High
DIGIPRO G4
CLASS D
Floating Input GroundFloating Input Ground
Low
Voltage
Low
Voltage
Low
Voltage
OPAMP
Floating ADC technology
ADC
Galvanic
Isolation
Preamplifier Module
DAC
Active
Link
NFC internal module
DSP
Out
Rs485
RDNET
Data
Data
In
RDNet
Rs485
CPU (MASTER)
Removable Card
SPEAKERS
COUPLING
D
USB Data Service
COMPENSATION
HIGH FREQ
5
F
E
C
B
7
6
4
3
G
A
8
1
2
Service / User
75
85
90
80
70
60
65
High Pass Filter [Hz]
Remote Preset
Active
Fullrange
1.4" C.D.
1.4" C.D.
12" WOOFER
12" WOOFER
6.5" MID-RANGE
6.5" MID-RANGE
6.5" MID-RANGE
6.5" MID-RANGE
Ready
Mute/Prot
Signal
Limiter
System Test
VIO-L212 Code 420120270 REV. 1.0
37
1. INPUT AND OUTPUT LINK (“Balanced audio”)
Input and output compatible with balanced XLR cables. In particular, "Input" is used to connect with the audio signal coming from the mixer or from another loudspeaker, "Output Link" is used to link the signal to the other modules of the line-
array, in daisy-chain conguration.
2. HIGH PASS FILTER
It enables to apply directly a high-pass lter (not applied, the stand-by position is Fullrange). Specically the cut-off frequencies may be chosen between: (60,65,70,75,80,85,90 Hz)
3. INPUT AND NETWORK CONNECTION LINK RDNet
Section compatible with network cables with etherCON/RJ45 connectors. In particular, "Data in" must be connected to devices such as RDNet Control 2 or Control 8; "Data Out" is used to link the network to additional modules of the line array in daisy-chain
conguration.
English
4. DSP PRESET Rotary for the acoustic setup of the line array. It is advisable to use these controls (or the same parameters
remotely via RDNet connection) to optimize the acoustic
behaviour as a function of the number of modules and their aiming. An in-depth analysis on the use of “SPEAKER COUPLING” and “HIGH FREQUENCY COMPENSATION” can be found in the “DSP PRESET PARAMETERS AND REMOTE
CONTROL” section.
5. STATUS LEDs
LEDs relating to module operation. A table in next page summarizes the meaning of the different LEDs.
6. CONTROL LEDs
LEDs relating to module network operation (RDNet).
In particular, if "Link" is on the RDNet network is active and has
acknowledged the device, if "Active" is ashing there is data trafc, if "Remote Preset Active" is on all local control on the amplier panel are by-passed by the RDNet remote control.
7. SERVICE DATA USB PORT
It is a mini-USB B port to be used only for product rmware
update. For further information refer to "FIRMWARE UPDATE".
8. SYSTEM TEST It carries out a test with sweep signal to check
woofer integrity. This test must not be considered as thorough, but just a rst check in the
analysis of any issues
9. NETWORK FUSE Housing for the network fuse of AMP1 section.
VIO-L212
38
Code 420120270 REV. 1.0
English
LED TYPE STARTING PHASE
OF THE SPEAKER
LIMITER OFF OFF, IT
SIGNAL
MUTE/ PROT
READY OFF STEADY ON STEADY ON OFF
10. “MAINS INPUT” POWER CONNECTOR Compatible with powerCON TRUE1® connector, the power supply features an auto-range function. Once the appropriate
range has been dened and the fuse has been changed, if
necessary, the system automatically recognizes the voltage
within the range [100-120V~] or [220-240V~].
OFF FLASHING
ON FOR A FEW SECONDS
IN NORMAL OPERATION
STARTS ONLY IN CASE OF TRIGGERING
IN THE PRESENCE OF A SIGNAL
OFF TEMPORARY
GENERIC WARNING
TEMPORARY FLASHING
INPUT AUDIO NORMAL WARNING
FLASHING
BLOCK FOR SPEAKER FAULT
CONTINUOUS CYCLIC FLASHING
OFF
STEADY ON
11. “MAINS LINK” POWER DAISY CHAIN Compatible with powerCON TRUE1® connector for power daisy chain to other modules.
To nd the maximum number of modules that can be
connected in a re-linked system, see the TECHNICAL
SPECIFICATIONS section.
12. NETWORK FUSE Housing for the network fuse of AMP2 section.
VIO-L212 Code 420120270 REV. 1.0
39
English
3. ACOUSTIC PREDICTION AND MECHANICAL TESTING: DBTECHNOLOGIES COMPOSER
dBTechnologies Composer software, available for free download from www.dbtechnologies.com, is a tool for the proper designing of the audio systems, recommended for the entire VIO series. It offers a solution for the spaces to sonorize, indicating the angle of the line-array modules in order to achieve the desired coverage and the preset to use. Besides being a predictive instrument, it also allows several manual adjustments to further improve the
conguration based on possible audio measurements made on the eld or on special needs. It is also the effective tool to assess installation safety level. In fact, thanks to the simulation of the y-bar's
static behaviour and an indication of the mechanical forces at play, it allows verifying how many modules should be installed before reaching an overload condition.
The main sections of dBTechnologies Composer are:
• COMPOSER - overview allowing to enter design start data
• LAs PREDICT - with the simulation, conguration and safety check of the line-arrays
• SUBs PREDICT - with the simulation, conguration and safety check of the subwoofers
This chapter describes some of the software's details relating to installation and safety, in particular for the FLOWN conguration of VIOL212 line arrays.
VIO-L212
40
Code 420120270 REV. 1.0
English
The LAs PREDICT section contains all the information necessary for the proper conguration, own or stack, of a VIO system. To access it, you need to rst enter the project's data, included in the Composer
section. The System Data sub-page provides the following suggestions: the angulation of the various modules,
various parameters relating to the “DSP preset” section and the angulation of the DRK-212 y-bar. This last angulation can be detected on the eld with the use of a laser inclinometer, not included, the assembly of
which is illustrated in the DRK-212 manual.
VIO-L212 Code 420120270 REV. 1.0
41
4. AURORA NET
AURORA NET, is a remote control software with the following features:
multi-platform (Windows /MAC OS X)
• it allows a more accurate control of the parameters and their history during an event
it allows a exible management even in the case of large xed/live installations (with advanced
group control)
• it allows recalling various presets
• is optimized for usability and speed of data displaying.
For further information, refer to the software complete manual.
English
VIO-L212
42
Code 420120270 REV. 1.0
English
5. DSP PRESET PARAMETERS
The use of a line array has a number of advantages in different contexts, in particular:
• Homogeneous SPL along the front line of the speakers, an effect that is particularly noticeable over medium to long distances
• directional acoustic behaviour, which allows the sound to be accurately focused on the audience, avoiding unnecessary dispersion in areas where sound coverage is not required.
The achievable optimization of the line array takes into account the behaviour of the system with respect to frequency:
• increasing the distance to the line array increases air attenuation. This has an effect especially on the high frequencies.
• as the angle between the line array elements increases, the mid-frequency phase coupling decreases.
• As the number of line array modules increases, the low frequencies will add up in an acoustically consistent manner.
The line array acoustic conguration of the VIO L212 modules can be optimized, thanks to the control
functions managed by the DSP. The local user interface is simple and immediate: it uses two rotary of the “DSP Preset” section:
• Parameter calculation is carried out with dBTechnologies Composer. It is possible to select locally said parameters on the VIO-L212 panel and use the remote control through AURORA NET.
• Position the rotary "SPEAKER COUPLING" according to the number of modules used in the line array. This rotary acts on the low frequencies and must be set in the position:
• All these parameters can be adjusted with the remote control, once the RDNet connections have been properly made, using the free AURORA NET software. When using the remote control, the local controls on the panels of the VIO-L212 modules are by-passed.
For further information, refer to the software complete manual.
VIO-L212 Code 420120270 REV. 1.0
43
6. ACCESSORIES, INSTALLATION, CONFIGURATION
FLY-BAR DRK-212
B2
English
A
A
C
D2
B1
C
D1
D2
DRK-212 is the y-bar for FLOWN and STACK use of VIO-L212. In FLOWN it may be used both with line-array angled downwards and upwards. For installation information, please refer to the specic instructions of the accessory.
• A - Motor lifting hooks
B - FLOWN rear joint (depending on the conguration)
• C - Front retractable brackets for STACK use
D - FLOWN front fastenings (depending on the conguration)
MOUNT SOCKETS FOR DIFFERENT MODELS
NAME ADAPTED MODEL
DOLLIES
VIO-L212
44
TF-VIO2
NAME USE TOP
DT-VIOl212
DO-VIOl212
DT-DRK212 2 DRK212 (+ 2 TF-VIO2)
1-4 VIOL212
1 VIOL212
VIOL210
Code 420120270 REV. 1.0
English
ACOUSTIC PREDICTION / MECHANICAL TESTING
• Use DBTECHNOLOGIES COMPOSER to set project parameters.
Make sure that the MECHANICAL SAFETY testing of the software conrms the safety of the selected
conguration
Make sure that the local parameters of the different modules are correctly set on the single amplier panels. In particular, verify according to the project the Speaker Coupling and High Frequency Compensation settings. As an alternative, all parameters can be remotely edited in real time if the line-array connection is carried out
through the RDNet network (DBTECHNOLOGIES NETWORK). Nevertheless, in this case, project initial settings
should be physically repeated on the VIO-L210 modules before installation. For further information see the
DSP PRESET PARAMETERS AND REMOTE CONTROL section.
PREPARATION OF THE FLY-BAR AND MODULES
Prepare the DRK212 y-bars and the line-array VIO-L212 modules. This example shows dollies DT-DRK212 and DT-VIOL212 with DTT-VIOL212 tops. The conguration in the example, for illustrative purposes only, is an
8-module line-array.
LE INDICAZIONI DI CABLAGGIO NELLE FIGURE SEGUENTI SONO PURAMENTE INDICATIVE.
VIO-L212 Code 420120270 REV. 1.0
45
English
LINE-ARRAY ASSEMBLY AND WIRING
• Remove the safety strap and the top. At the rear of the modules insert the pins for the fastening of the angles calculated by the software.
By means of motors, lift 1 y-bar from the DT-DRK212 dolly and secure it in own conguration to the upper VIO-L212 top.
For the following connection make sure to route the necessary main wirings on the y-bar.
Connect the rst individual modules, especially the re-linkable ones.
• Lift the upper part of the line-array
VIO-L212
46
Code 420120270 REV. 1.0
English
• Move the dolly with the rest of the 4 modules below the ones already lifted. Remove the belt and the top from the second dolly.
• Rig one module at a time and slightly lift/lower the ropes with the motors, initially with front installation and then with rear one, as shown in the MECHANICS AND MAIN EQUIPMENT section.
• Connect the modules with each other as the installation proceeds.
• End the composition and the line-array connections.
WARNING!
The product and accessories must be handled by experienced personnel only! Make sure that the installation is positioned in a stable and safe manner in order to avoid hazardous conditions for people, animals and/or objects. The user is required to follow regulations and mandatory laws on safety of the country in which the product is used. For safe use, regularly check the operation of all parts and integrity before use. Design, calculations, installation, testing and maintenance of suspended systems or professional audio stacks must be performed by authorized personnel only. AEB Industriale is not responsible for improper installations, non-compliant with safety requirements.
A
B
VIO-L212 Code 420120270 REV. 1.0
47
INDICATIONS ON POWER SUPPLY AND BEHAVIOUR OF THE LINE­ARRAY SYSTEM
Please bear in mind that the system's power supply, with a correct source and wiring sizing, affects the correct operation of the modules and the system.
1. The current supplied to the line-array
module behaves dynamically (i.e. rst start­up, idle condition, full range operation).
2. There are voltage drops due to cable length and cross-
section. Generally these drops are directly proportional to the length and inversely proportional to the cable cross-section.
English
A
B
A
B
A
B
VIO-L212
48
Code 420120270 REV. 1.0
English
EXAMPLES OF MIXED CONFIGURATIONS
D
C
D2
A
B
A
B
Through the TF-VIO2 mount socket, it is possible to use a VIO-L210 line-array in down-ll function under one consisting of VIO-L212. The suggested proportion between the 2 models is 3:1 as shown here below, for illustrative purposes only.
• A - Front brackets for VIO-L212
• B - Front fastening systems for VIO-L210
• C - Rear joint for VIO-L210
• D - Rear coupling bracket for VIO-L212
VIO-L212 Code 420120270 REV. 1.0
49
EXAMPLES OF STACKED CONFIGURATIONS
The main stack congurations are:
on subwoofer (through DRK-212)
• directly on DT-VIOL212 dolly by using the compulsory EFK-1 accessory.
English
For installation information and the congurations allowed, please refer to the manuals of individual accessories.
VIO-L212
Code 420120270 REV. 1.0
50
English
7. TROUBLESHOOTING
The module does not turn on:
1. Check that power supply is present upstream of the installation.
2. Check that the power supply or the re-link connection of the power supply is properly inserted.
3. Make sure that wiring length and cross-section allow, including voltage drops, operating within the allowed range.
4. Check any warning displayed by AURORA NET (in RDNet connection)
The module turns on but produces no sound:
1. Check that the audio signal input connections or the audio signal re-links are properly carried out.
2. Check that the audio source (mixer) is properly connected and active.
3. Check via remote control through AURORA NET (in RDNet connection) that MUTE is not active. Check also any displayed warning.
Module sound is not fully satisfactory.
1. Re-check the project, the installation and conguration specications using DBTECHNOLOGIES COMPOSER.
2. Verify that the DSP PRESET parameters are actually replicated on the control panel of the module
(especially if the remote control of the modules is not used).
3. Check that, in case of RDNet network connection and control with AURORA NET, all the parameters, especially the equalization ones, are properly set.
VIO-L212 Code 420120270 REV. 1.0
51
English
8. FIRMWARE UPDATES
IT IS very important to keep product rmware updated to the latest version to ensure full performance. Please check site http://www.dbtechnologies.com for updates under section “DOWNLOADS” periodically.
1. Download and install on your PC the USB BURNER MANAGER under the “SOFTWARE & CONTROLLER” section.
2. Download the .zip le of the latest rmware in the “DOWNLOADS” section of your product.
3. Connect the product to the PC using a USB cable (not provided) with a suitable connector type (see this detail in the FEATURES OF THE AMPLIFICATION AND CONTROL SECTION chapter).
4. In the top right corner of the USB BURNER MANAGER screen, select “File Opening”.
5. Select the le containing the previously downloaded rmware.
6. Follow the operations shown on the screen.
7. Click “UPDATE”.
VIO-L212
52
Code 420120270 REV. 1.0
English
9. SPECIFICATIONS
GENERAL
Type: Active 3-way line-array module
ACOUSTICAL SPECIFICATIONS
Frequency response [- 10 dB]: 49.8 - 20000 Hz
Frequency response [- 6 dB]: 55 - 18600 Hz
Max SPL: 142 dB (frequency/preset dependent)
HF: 2 x 1.4” (Coil: 3”)
Type of HF transducer: Titanium
MF: 4 x 6.5” (Coil: 2”)
Type of MF transducer: Neodymium
LF: 2 x 12” (Voice Coil: 3”)
Type of LF transducer: Neodymium
Waveguide for high frequencies: Yes
Horizontal directivity: 90°
Vertical directivity:
variable, depending on the conguration and the number of
modules
AMPLIFIER
Type: (2x) Digipro® G4
Amplication class: Class D
Amplication power (Peak) 2x 1600 W (3200 W)
Amplication power (RMS): 2x 3200 W (6400 W)
Power supply: Fullrange with PFC, range 100-240V~ (50-60Hz)
Cooling technique: Convection + fans with lower ventilation grilles
Operating temperature range (ambient): from -15° to + 55° [°C]
VIO-L212 Code 420120270 REV. 1.0
53
PROCESSOR
Internal controller: 32-bit DSP
AD/DA conversion: 24 bit / 96 kHz
DSP advanced functions: Linear-phase FIR lters
Position recognition: inclinometer, NFC technology module
First test internal function: impedance test with sweep
USER INTERFACE
Controls: HPF rotary, DSP Preset
Status LEDs Ready, Mute/Prot, Signal, Limiter
English
RDNet interface LED Link, Active, Remote Preset Active
INPUTS AND OUTPUTS
Power supply inputs and re-links: PowerCON® True In/Link
Audio inputs: 1x XLR IN balanced (insulation: Floating ADC)
Audio outputs: 1x XLR link OUT balanced
RDNet inputs/outputs: Data In / Data Out (etherCON® connectors)
USB (rmware update): 1x USB MINI type B
SOFTWARE COMPATIBILITY
Predictive/testing soware dBTechnologies COMPOSER
Remote control soware: AURORA NET
Other soware: Ease, Ease Focus 3
VIO-L212
54
Code 420120270 REV. 1.0
English
POWER SUPPLY SPECIFICATIONS (ABSORPTION)
Absorption at 1/8th of power in
average use conditions (*):
Absorption at 1/3rd of power in
maximum use conditions (**):
Absorption with speaker on in
no-signal condition (idle):
Inrush current:
2 A (230V~) - 3.1 A (115V~)
4.9 A (230V~) - 7.5 A (115V~)
53 W
3.2 A
Max number of modules per power supply line (**)
1 + 2 (220-240V~) / 1 + 1 (100-120V~)
[mains input + mains link]:
* NOTE FOR INSTALLER: Values refer to 1/8th of power, under average operating conditions (music programme with occasional or no
clipping). For any type of conguration we recommend to consider them as minimum sizing values.
** NOTE FOR INSTALLER: Values refer to 1/3rd of power, under heavy operating conditions (music programme with frequent clipping and
limiter activation). In case of professional installations and tours we recommend sizing according to these values.
MECHANICAL SPECIFICATIONS
Material: wooden cabinet - black polyurea nish
Grille: full metal - CNC machining
Handles integrated (2x side)
Front mounting pre-sets: Rear mounting pre-sets:
Retractable brackets, built-in cabinet points with quick-release pins
Graduated bracket and movable joint with quick-release pins
Flown and stacked assembly: With DRK-212 y-bar accessory
Width: 1100 mm (43.31 inches)
Height: 380 mm (14.96 inches)
Depth: 450 mm (17.72 inches)
Weight: 54.4 kg (119.9 lbs)
Product features, specications and appearance are subject to changes without prior notice. dBTechnologies reserves the right to make changes or improvements in design or manufacture without any obligation to incorporate such changes or improvements in previously manufactured products.
A.E.B. Industriale Srl
Via Brodolini, 8
Località Crespellano
40053 VALSAMOGGIA
BOLOGNA (ITALY)
Tel +39 051 969870
Fax +39 051 969725
www.dbtechnologies.com
info@dbtechnologies-aeb.com
VIO-L212 Code 420120270 REV. 1.0
55
Deutsch
INHALTSVERZEICHNIS
INHALTSVERZEICHNIS
1. ALLGEMEINE INFORMATIONEN ...........................................................................................57
WILLKOMMEN! ..................................................................................................................57
EINLEITENDER ÜBERBLICK .................................................................................................57
MECHANISCHE UND AKUSTISCHE EIGENSCHAFTEN ........................................................58
AKUSTISCHE EIGENSCHAFTEN .................................................................................................................. 58
MECHANIK UND HAUPTAUSSTATTUNGEN ............................................................................................... 59
2. LOKALE STEUERUNGEN UND VERBINDUNGEN .................................................................62
3. AKUSTISCHE VORHERSAGE UND MECHANISCHE ÜBERPRÜFUNG DBTECHNOLOGIES
COMPOSER .............................................................................................................................66
4. AURORA NET ..........................................................................................................................68
5. PARAMETER DER DSP VOREINSTELLUNG ...........................................................................69
6. ZUBEHÖR, INSTALLATION, KONFIGURATION ....................................................................70
FLY-BAR DRK-212 ................................................................................................................70
MODELLADAPTER ..............................................................................................................70
WAGEN ................................................................................................................................70
AKUSTISCHE VORHERSAGE / MECHANISCHE VALIDIERUNG ...........................................71
VORBEREITUNG DES FLUGRAHMENS UND DER MODULE ..............................................71
MONTAGE DES LINE ARRAY UND DER VERKABELUNG ....................................................72
BEISPIELE GEMISCHTER KONFIGURATIONEN ...................................................................75
BEISPIELE GESTAPELTER KONFIGURATIONEN ...................................................................76
7. PROBLEMABHILFE .................................................................................................................77
8. FIRMWARE-AKTUALISIERUNG .............................................................................................78
9. TECHNISCHE DATEN ..............................................................................................................79
ALLGEMEINE ANGABEN ............................................................................................................................ 79
AKUSTIK-DATEN ......................................................................................................................................... 79
VERSTÄRKER .............................................................................................................................................. 79
PROZESSOR ................................................................................................................................................ 80
BENUTZEROBERFLÄCHE ............................................................................................................................ 80
EINGÄNGE UND AUSGÄNGE ..................................................................................................................... 80
SOFTWARE-KOMPATIBILITÄT .................................................................................................................... 80
STROMSPEZIFIKATIONEN (ABSORPTION)................................................................................................. 81
MECHANISCHE SPEZIFIKATIONEN ............................................................................................................ 81
VIO-L212
56
Art.-Nr. 420120270 REV. 1.0
1100
380
Deutsch
1. ALLGEMEINE INFORMATIONEN
WILLKOMMEN!
Wir danken Ihnen, dass Sie sich für den Kauf eines von dBTechnologies in Italien entworfenen und entwickelten Produkts entschieden haben! Dieses aktive, leistungsstarke und für komplexe Live-Veranstaltungen geeignete Line Array ist das Ergebnis langjähriger Erfahrung im Bereich der Soundsysteme. Es implementiert innovative und optimierte Lösungen im akustischen und elektronischen Bereich sowie die Ergenisse unserer Materialrecherchen.
EINLEITENDER ÜBERBLICK
Mit dem aktiven 3-Wege-Line-Array-Modul VIO-L212 beginnt eine neue Ära der Forschung und Optimierung für große, professionelle Live-Innen- und Außenanwendungen. Die wichtigsten Merkmale sind:
• Optimierung zwischen den Fullrange­Akustikleistungen und den Dimensionen
3-Punkt-integriertes Takelage-System für efziente Montage/Demontage
Linie mit professionellem, spezischen Zubehör für das Handling und die Montage
• Verstärkungsbereich bestehend aus 2 DIGIPRO G4 mit jeweils 1600 W RMS, die vom DSP 32 bit
(spezielle FIR-Filtration) gesteuert werden
• Floating-ADC-Technologie für eine perfekte Isolierung von Interferenzen, Rauschen oder Brummen des Audio-Eingangs
• Steuerung vom DSP und Echtzeit-Filtration mit FIR-Filtern
• Strom-, Audio- und Netzwerkrelais für eine optimierte Verkabelung
• RDNet-Steuerung on board, Auslegung für AoIP Protokoll Audinate DanteTM
• Vorhersage- und Fernverwaltungssoftware (DBTECHNOLOGIES COMPOSER, EASE, EASE
FOCUS 3, AURORA NET)
32
4500
59
155
30
48,5
330
VIO-L212 Art.-Nr. 420120270 REV. 1.0
57
MECHANISCHE UND AKUSTISCHE EIGENSCHAFTEN
AKUSTISCHE EIGENSCHAFTEN
Deutsch
B
A
D
C
D
B
F
E
F
E
A
A - [LF] 2 Woofer aus Neodym, Durchmesser 12”, Schwingspule 3” (Reex-Konguration).
B - [MF] 4 Mid-Range aus Neodym, Durchmesser 6,5”, Schwingspule 2”.
C - [HF] 2 Kompressionstreiber aus Neodym, Öffnung 1,4”, Titanspule 3” (Hornladung). D - Phaseplug mit optimierter Kammer
E - Wellenleiter F - Prole mit logarithmischem Hornverlauf
Die akustische Optimierung von VIO-L212 harmonisiert die Leistungen (SPL, Antwort in Phase und in
Frequenz, Klangfokus) mit den Dimensionen und mechanischen Bindungen des Projekts.
Insbesondere:
• Die Phaseplugs [D] mit optimierter Kammer erhöhen die Kohärenz der mittleren Frequenzen
• Die Platzierung und Entfernung der Mid-Range Wandler begünstigt den Klangfokus und die außeraxiale
Wiedergabe, die klar deniert sind
Die Prole mit logarithmischem Hornverlauf [F] vermeiden u. a. die Bildung konstanter Reexionen (Modi) und erhöhen die Kohärenz des mittleren-hohen Bereichs
• Die Wellenleiter [F] steuern die Senkrechtrichtung der hohen Frequenzen
VIO-L212
58
Art.-Nr. 420120270 REV. 1.0
Deutsch
MECHANIK UND HAUPTAUSSTATTUNGEN
U
T - VORDERE BEFESTIGUNGSSTIFTE U - VERSENKBARE BÜGEL ZUR
BEFESTIGUNG AN EINEM DARÜBERLIEGENDEN MODUL
V - SITZE ZUR BEFESTIGUNG AN
EINEM DARUNTERLIEGENDEN MODUL
T
V
T
V
Y
W
W- HINTERER
BEFESTIGUNGSBÜGEL
X - BEWEGLICHES
VERBINDUNGSTEIL
Y - HINTERE BEFESTIGUNGSSTIFTE Z - REGENSCHUTZHÜLLE
Z
X
Das 3-Punkt-Befestigungssystem verwendet, anhand der Nutzung der Stifte:
• die oberen Bügel U an der Vorderseite
• die unteren Sitze V an der Vorderseite
• den Bügel W, das bewegliche Verbindungsteil X an der Rückseite. Zur Vereinfachung sind die Regenschutzhüllen [Z] auf den folgenden Abbildungen nicht zu sehen
Z
VIO-L212 Art.-Nr. 420120270 REV. 1.0
59
Befestigung von zwei Modulen:
VORDERSEITE
Deutsch
1) Am Modul B die Bügel U nach oben ziehen und mit den entsprechenden Stiften befestigen.
2) Die Stifte T aus dem Modul A herausziehen
3) Die 2 Module einander nähern
und die Bügel U in die Sitze V einfügen.
4) Die Stifte T vollkommen einfügen. Auf diese Weise ergibt sich die Arretierung der Module A und B an der Vorderseite.
RÜCKSEITE
5) Am Modul A das bewegliche Verbindungsteil X entriegeln. Dann der gewünschten Neigung entsprechend den Stift Y in die gewünschte Bohrung einfügen.
Die Einzelheiten dieses Vorgangs werden auf der nächsten Seite erläutert. Sie sind je nach FLOWN- oder STAPEL-
Installation unterschiedlich.
A
T
U
T
U
B
V
U
T
VIO-L212
60
A
B
X
W
Y
X
Y
W
Art.-Nr. 420120270 REV. 1.0
Deutsch
STIFT 2
STIFT 1
FLOWN-INSTALLATION
X
Zur Winkelxierung an der Rückseite ist nur ein Stift (STIFT 1) erforderlich. Die verschiedenfarbigen
Einsteckbohrungen des Bügels W ermöglichen folgende Winkelstellungen: [0°, 0.5°, 1°, 2°, 3°, 4.5°, 6°, 8°]. Das Langloch des Bügels ermöglicht das Einfügen der Stifte, ohne dass die Rückseite von VIO-L212 angehoben werden muss.
GESTAPELTE INSTALLATION
Zur Winkelxierung an der Rückseite sind zwei Stifte (STIFT 1, STIFT 2) erforderlich. Wurde der STIFT 1 gemäß
dem FLOWN Verfahren eingefügt, hebt sich die Rückseite von VIO-L212 so weit wie es das Langloch zulässt und
man kann diese Position mit dem STIFT 2 xieren.
W
VIO-L212 Art.-Nr. 420120270 REV. 1.0
61
2. LOKALE STEUERUNGEN UND VERBINDUNGEN
Die 2 Verstärker DIGIPRO G4 können bis zu 3200 W RMS abgeben. Das Blockschaltbild der Elektronik von VIO-L212 ist auf der nächsten Seite abgebildet.
Die zwei, von den (hier nicht
dargestellten) Regenschutzhüllen (Rain Cover) geschützten
Hauptbereiche an der Rückseite des Moduls sind:
• ANSCHLÜSSE UND STEUERUNG
• STROMVERSORGUNG
Der Bereich ANSCHLÜSSE UND STEUERUNG nutzt einen DSP, der u. a. die FIR-Filtration des Ausgangssignals steuert.
Deutsch
Der Bereich STROMVERSORGUNG
verwendet eine PFC, die deren Efzienz
verbessert und den Verstärkungsbereich gegen unerwünschte Eingangsstromschwankungen schützt.
FIR-FILTRATION
Die Klangentzerrung wird von einem
DSP 32 bit gesteuert.
Die implementierten Filter minimieren die
Phasenverzerrung des ausgeglichenen Signals. Für Einzelheiten zur Entzerrung
siehe Abschnitt: „PARAMETER DER DSP VOREINSTELLUNG“.
PFC
Die Leistungsfaktorkorrektur (PFC)
verringert die Phasenverschiebung
zwischen dem Strom und der vom Verstärker abgegebenen Spannung. Innerhalb eines bestimmten Bereichs ist
deshalb die, der Anlage vorgeschaltete
Eingangsstromversorgung trotz kleiner Schwankungen der Netzversorgung ideal. Für weitere Einzelheiten bezüglich der Empfehlungen zur Stromversorgung siehe Abschnitt: „MONTAGE DES LINE
ARRAY UND VERKABELUNG”.
AMP2-STROMVERSORGUNG
AMP1-ANSCHLÜSSE UND STEUERUNG
VIO-L212
62
Art.-Nr. 420120270 REV. 1.0
M A
I N
S F
U S E
1 0 0
­1 2 0 V
~
( T
1 0 A
L 2
5 0 V ~ )
2 2 0
­2 4 0 V
~
( T
5 A
L 2
5 0 V ~ )
M A
I N
S F
U S E
1 0 0
­1 2 0 V
~
( T
1 0 A
L 2
5 0 V ~ )
2 2 0
­2 4 0 V
~
( T
5 A
L 2
5 0 V ~ )
Deutsch
AUTO-RANGE
MAINS LINK
MAINS INPUT
Link
Output
Input
Balanced Audio
BLOCK DIAGRAM
PUSH
M
(
(
T
T
1
5
A
0
A
2
I
A
1
2
N
L
0
0
L
S
2
0
­2
2
5
-
F
1
4
5
0
U
2
0
0
V
V
0
S
V
~
V
~
E
~
)
~
)
FUSE
Power Supply
FUSE
Power Supply
EMI FILTER
Amplifier Module
Amplifier Module
SMPS MAIN
Voltage
DIGIPRO G4
Amplifier
CLASS D
High
DIGIPRO G4
CLASS D
Voltage
DIGIPRO G4
Amplifier
CLASS D
M
(
(
T
T
1
5
A
0
A
2
I
A
1
2
N
L
0
0
L
S
2
0
­2
2
5
-
F
1
4
5
0
U
2
0
0
V
0
V
S
V
~
V
~
E
~
)
~
)
EMI FILTER
SMPS MAIN
High
DIGIPRO G4
CLASS D
Floating Input GroundFloating Input Ground
Low
Voltage
Low
Voltage
Low
Voltage
OPAMP
Floating ADC technology
ADC
Galvanic
Isolation
Preamplifier Module
DAC
Active
Link
NFC internal module
DSP
Out
Rs485
RDNET
Data
Data
In
RDNet
Rs485
CPU (MASTER)
Removable Card
SPEAKERS
COUPLING
D
USB Data Service
COMPENSATION
HIGH FREQ
5
F
E
C
B
7
6
4
3
G
A
8
1
2
Service / User
75
85
90
80
70
60
65
High Pass Filter [Hz]
Remote Preset
Active
Fullrange
1.4" C.D.
1.4" C.D.
12" WOOFER
12" WOOFER
6.5" MID-RANGE
6.5" MID-RANGE
6.5" MID-RANGE
6.5" MID-RANGE
Ready
Mute/Prot
Signal
Limiter
System Test
VIO-L212 Art.-Nr. 420120270 REV. 1.0
63
1. AUDIO-EINGANG UND RÜCKLAUF („symmetrisches Audio“)
Eingang und Ausgang kompatibel mit symmetrischen XLR-Kabeln Insbesondere wird der „Eingang“ für die Verbindung mit dem vom Mischer oder einem anderen Lautsprecher stammenden Tonsignal verwendet, der „Ausgangs-Anschluss” hingegen für den Rücklauf des Signals zu den anderen Modulen des Line
Arrays in Daisy-Chain-Konguration.
2. HIGH PASS FILTER Ermöglicht die direkte Anwendung eines Hochpass-Filters
(nicht angewendet, die Stand-by Position ist Fullrange).
Insbesondere stehen folgende Trennfrequenzen zur Wahl:
(60,65,70,75,80,85,90 Hz)
3. EINGANG UND RÜCKLAUF DER RDNet-
NETZWERKVERBINDUNG Abschnitt ist mit Netzwerkkabel mit etherCON / RJ45­Steckverbindern kompatibel. Insbesondere sollte „Daten Ein“ mit Geräten wie RDNet Control 2 oder Control 8 verbunden sein; „Daten Aus“ kann für den Neustart des Netzwerks zu anderen Modulen des Line Arrays in
einer Daisy-Chain-Konguration verwendet werden.
4. DSP-VOREINSTELLUNG Drehregler zur Akustikeinstellung des Line Array.
Es empehlt sich, diese Bedienelemente (oder die gleichen Parameter über die RDNet-Verbindung entfernt) zu verwenden,
um das akustische Verhalten in Abhängigkeit von der Anzahl der Module und deren Orientierung zu optimieren. Weitere Einzelheiten zur Verwendung von „SPEAKER COUPLING“ und
„HIGH FREQUENCY COMPENSATION“ nden Sie im Abschnitt
PARAMETER DSP VOREINSTELLUNG UND FERNSTEUERUNG.
5. STATUS-LEDs
LEDs für den Betrieb des Moduls. Eine Tabelle auf der nächsten Seite fasst die Bedeutung der verschiedenen LEDs zusammen.
Deutsch
6. STEUER-LEDs
Betriebs-LEDs des Moduls mit Vernetzung (RDnet).
Wenn „Anschluss“ aktiviert ist, bedeutet dies insbesondere, dass das RDNet-Netzwerk aktiv ist und das Gerät erkannt hat. Wenn „Active“ blinkt, bedeutet dies, dass der Datenaustausch hergestellt ist. „Remote Preset Active“ zeigt an, dass alle lokalen Bedienelemente des Verstärker-Bedienfelds von der RDNet­Fernsteuerung umgangen werden.
7. USB-DATENSERVICE Ein Mini-USB-Port B, der nur für die Firmware-Aktualisierung des
Produkts verwendet wird. Weitere Informationen nden Sie im
Abschnitt „FIRMWARE-AKTUALISIERUNG“.
8. SYSTEM-TEST Führt einen Test mit dem Sweep-Signal aus, um die Integrität des Woofers zu überprüfen. Dieser Test sollte nicht als erschöpfend betrachtet werden, sondern nur als erste Kontrolle bei der Problemanalyse.
9. NETZWERKSICHERUNG Aufnahme für die Netzsicherung des Bereichs AMP1.
VIO-L212
Art.-Nr. 420120270 REV. 1.0
64
Deutsch
LED-TYP BEIM EINSCHALTEN
DES
BETRIEB NORMAL
LAUTSPRECHERS
LIMITER ERLOSCHEN AUSGESCHALTET,
EIGENSTÄNDIGES EINSCHALTEN NUR BEI EINEM EINGRIFF
SIGNAL
STUMM / PROT
BEREIT ERLOSCHEN DAUERHAFT
10. VERSORGUNGSVERBINDER „MAINS INPUT” Kompatibel mit dem powerCON TRUE1®-Verbinder ist die Stromversorgung mit der Auto-Bereich-Funktion ausgestattet.
Sobald der entsprechende Bereich deniert ist, wird bei
Bedarf durch Austausch der Sicherung die Spannung im
Intervall [100-120V ~] oder [220-240V ~] automatisch erkannt.
ERLOSCHEN BLINKEN
EINGESCHALTET EINIGE SEKUNDEN
MIT SIGNAL
ERLOSCHEN BLINKEN
LEUCHTEND
WARNING GENERISCHE
BLINKEN VORÜBERGEHENDES
SIGNAL NORMAL AUDIO-EIN EINGANG
VORÜBERGEHENDES
DAUERHAFT LEUCHTEND
ABSCHALTUNG WEGEN DES LAUTSPRECHERS
KONTINUIERLICHES ZYKLISCHES BLINKEN
ERLOSCHEN
DAUERHAFT LEUCHTEND
ERLOSCHEN
11. VERSORGUNGSRÜCKLAUF „MAINS-ANSCHLUSS” Kompatibel mit einem powerCON TRUE1®-Stecker zum Rücklauf der Stromversorgung anderer Module. Die maximale Anzahl der Module, die in einem neu
gestarteten System angeschlossen werden können, nden Sie
im Abschnitt TECHNISCHE DATEN.
12. NETZWERKSICHERUNG Aufnahme für die Netzsicherung des Bereichs AMP2.
VIO-L212 Art.-Nr. 420120270 REV. 1.0
65
Deutsch
3. AKUSTISCHE VORHERSAGE UND MECHANISCHE ÜBERPRÜFUNG DBTECHNOLOGIES COMPOSER
DBTechnologies Composer-Software, die zum kostenlosen Download unter www.dbtechnologies.com zur Verfügung steht, ist ein Instrument für die korrekte Gestaltung der für die gesamte VIO-Serie empfohlenen Audiosysteme.
Es empehlt die Lösung für die zu beschallenden Bereiche und gibt den Winkel der Line-Array-Module an,
der den Erhalt der gewünschten Abdeckung und Voreinstellung ermöglicht. Obwohl es sich um ein prädiktives Instrument handelt, erlaubt es eine Reihe von manuellen Einstellungen, um
die Konguration auf der Grundlage von Schallfeldmessungen oder spezischen Anforderungen zu verfeinern.
Schließlich ist es ein wirksames Instrument zur Beurteilung der Sicherheit der Anlage. Durch die Simulation des statischen Verhaltens der Flybar und die Anzeige der mechanischen Kräfte am Spiel ermöglicht es, zu überprüfen, wie viele Module installiert werden sollten, bevor ein Überlastungszustand erreicht wird.
Die Hauptabschnitte des dBTechnologies Composer sind:
• COMPOSER - allgemeine Ansicht, die die Eingabe der Projektdaten erlaubt
• LAs PREDICT - mit Sicherheitssimulation, Konguration und Test von Line Arrays
• SUBs PREDICT - mit Sicherheitssimulation, Konguration und Test von Subwoofern
Dieses Kapitel beschreibt einige Details der Software in Bezug auf Installation und Sicherheit, insbesondere
für die FLOWN-Konguration des VIOL212-Line-Arrays.
VIO-L212
66
Art.-Nr. 420120270 REV. 1.0
Deutsch
Der Abschnitt „LAs PREDICT“ enthält alle Informationen, die für die ordnungsgemäße Konguration, überogen oder gestapelt, eines VIO-Systems erforderlich sind. Um darauf zuzugreifen, müssen Sie zuerst
die Projektdaten eingeben, die im Abschnitt Komponieren enthalten sind. Die Systemdaten-Seite bietet die folgenden Vorschläge: die Winkeleinstellung der verschiedenen Module, verschiedene Parameter, die sich auf den Abschnitt „DSP-Voreinstellung“ und die Winkeleinstellung der DRK-212 Flybar beziehen. Diese letzte Winkeleinstellung kann auf dem Feld unter Verwendung eines Laser-Inklinometers detektiert werden, das nicht im Lieferumfang enthalten ist, dessen Aufbau im Handbuch des DRK-212 dargestellt ist.
VIO-L212 Art.-Nr. 420120270 REV. 1.0
67
4. AURORA NET
AURORA NET ist eine Fernsteuerungssoftware mit folgenden Eigenschaften:
Mehrfachplattform (Windows /MAC OS X)
• ermöglicht eine präzisere Kontrolle der Parameter und deren Chronologie im Laufe der ganzen
Veranstaltung
ermöglicht ein exibles Management auch bei Fest-/Live-Installationen (mit fortschrittlicher
Steuerung der Gruppen)
• ermöglicht den Aufruf verschiedener Voreinstellungen
• ist im Hinblick auf die Verwendbarkeit und Anzeigegeschwindigkeit der Daten optimiert
Weitere Informationen entnehmen Sie bitte dem kompletten Handbuch der Software.
Deutsch
VIO-L212
68
Art.-Nr. 420120270 REV. 1.0
Deutsch
5. PARAMETER DER DSP VOREINSTELLUNG
Der Einsatz eines Line Arrays bringt eine Reihe von Vorteilen in verschiedenen Kontexten mit sich, insbesondere:
• SPL homogen entlang Frontlinie der Lautsprecher, ein Effekt, der besonders bei mittleren bis langen Distanzen geschätzt wird
• leitfähiges akustisches Verhalten, mit dem Sie den Schall genau auf das Publikum konzentrieren können, um unnötige Verluste in Bereichen zu vermeiden, in denen keine akustische Abdeckung erforderlich ist.
Die umsetzbare Optimierung der Line Arrays berücksichtigt das Verhalten des Systems entsprechend der Frequenz:
• Bei Vergrößerung der Distanz vom Line Array erhöht sich die Luftdämpfung. Dies wirkt sich insbesondere auf hohe Frequenzen aus.
• Bei Vergrößerung des Winkels zwischen den Elementen des Line Arrays verringert sich die Mittenfrequenzphasenkopplung
• mit zunehmender Anzahl der Module der Line Array addieren sich die tiefen Frequenzen akustisch kohärent.
Die akustische Konguration in einem Line Array der VIO-L212 Module lässt sich dank der vom DSP verwalteten Steuerfunktionen optimieren. Die lokale Bedienoberäche ist einfach und direkt: sie
verwendet zwei Drehregler des Bereichs „DSP Voreinstellung“:
• Die Parameterberechnung erfolgt mit dBTechnologies Composer. Es ist möglich, diese Parameter im lokalen Modus auf dem Bedienfeld von VIO-L212 zu wählen sowie auch die Fernsteuerung über das AURORA NET zu verwenden.
• Stellen Sie den Drehregler „SPEAKER COUPLING“ entsprechend der im Line Array verwendeten Modulanzahl ein Der Drehregler wirkt auf die mittleren Frequenzen ein und sollte auf die folgenden Positionen gestellt werden:
• Alle diese Parameter können, sobald die RDNet-Verbindungen ordnungsgemäß hergestellt worden sind, mit der Fernsteuerung über die kostenlose Software AURORA NET eingestellt werden. Bei der Bedienung über Fernsteuerung werden die lokalen Bedienelemente in den Bedienfeldern des VIO­L212-Moduls umgangen.
Weitere Informationen entnehmen Sie bitte dem kompletten Handbuch der Software.
VIO-L212 Art.-Nr. 420120270 REV. 1.0
69
6. ZUBEHÖR, INSTALLATION, KONFIGURATION
FLY-BAR DRK-212
B2
Deutsch
A
A
C
D2
B1
C
D1
D2
DRK-212 ist der Flugrahmen (Flybar) für FLOWN- und STACK-Verwendung des VIO-L212. Die FLOWN-Verwendung
bietet die Möglichkeit einer Zweifachnutzung mit nach unten oder nach oben abgewinkeltem Line Array. Betreffs
der Montagedetails siehe spezische Zubehör-Anleitung.
• A - Motorhubhaken
B - Hinteres Verbindungsteil (abhängig von der Konguration) FLOWN
• C - Versenkbare, vordere Bügel für STACK-Verwendung
D - Vordere FLOWN Befestigungen (abhängig von der Konguration)
MODELLADAPTER
BEZEICHNUNG ANGEPASSTES MODELL
WAGEN
VIO-L212
70
TF-VIO2
BEZEICHNUNG VERWENDUNG TOP
DT-VIOl212
DO-VIOl212
DT-DRK212 2 DRK212 (+ 2 TF-VIO2)
1-4 VIOL212
1 VIOL212
VIOL210
Art.-Nr. 420120270 REV. 1.0
Deutsch
AKUSTISCHE VORHERSAGE / MECHANISCHE VALIDIERUNG
• Verwenden Sie den DBTECHNOLOGIES COMPOSER, um die Projektparameter einzustellen.
• Überprüfen Sie, ob die MECHANICAL SAFETY Validierung der Software die Sicherheit der gewählten
Konguration bestätigt.
• Überprüfen Sie, ob die lokalen Parameter der verschiedenen Module auf den einzelnen Verstärkerpanels richtig eingestellt sind. Überprüfen Sie insbesondere gemäß dem Projekt die Einstellungen Lautsprecherkopplung und Hochfrequenzkompensierung. Alternativ können Sie per Fernzugriff und in
Echtzeit alle Parameter ändern, wenn das Line Array über das RDNet Netzwerk (DBTECHNOLOGIES NETWORK)
angeschlossen ist. In diesem Fall ist es auch eine gute Praxis, die ursprünglichen Einstellungen des Projekts
auf den VIO-L210-Modulen vor der Installation physisch zu replizieren. Weitere Informationen nden Sie im
Abschnitt DSP-VOREINSTELLUNGSPARAMETER UND FERNSTEUERUNG.
VORBEREITUNG DES FLUGRAHMENS UND DER MODULE
• Die Flugrahmen DRK212 und die Line Array Module VIO-L212 vorbereiten Dieses Beispiel zeigt die Wagen DT-DRK212 und die Wagen DT-VIOL212 mit den Topteilen DTT-VIOL212. Das allein der Veranschaulichung
dienende Beispiel ist eine Line Array Konguration mit 8 Modulen.
LE INDICAZIONI DI CABLAGGIO NELLE FIGURE SEGUENTI SONO PURAMENTE INDICATIVE.
VIO-L212 Art.-Nr. 420120270 REV. 1.0
71
Deutsch
MONTAGE DES LINE ARRAY UND DER VERKABELUNG
• Den Sicherungsriemen und das Topteil entfernen. Hinten an den Modulen die Stifte zur Fixierung der von der Software berechneten Winkel einfügen.
Mithilfe der Motoren 1 Flugrahmen vom Wagen DT-DRK212 anheben und in Flown-Konguration am oberen Topteil VIO-L212 befestigen.
• Die erforderlichen Hauptverkabelungen für die nächste Verbindung durch den Flugrahmen führen.
• Die ersten Verkabelungen zwischen den einzelnen Modulen, insbesondere derer für den Rücklauf, vornehmen.
• Den oberen Teil des Line Array anheben.
VIO-L212
72
Art.-Nr. 420120270 REV. 1.0
Deutsch
• Den Wagen mit den anderen 4 Modulen unter die hochgezogenen Module schieben. Den Riemen und das Topteil vom zweiten Wagen entfernen.
• Die Seile mithilfe der Motoren etwas anheben/senken und jeweils ein Modul mit vorderer und dann hinterer Montage koppeln, dabei wie im Abschnitt MECHANIK UND HAUPTAUSSTATTUNGEN erläutert vorgehen.
• Im Weiterverlauf der Montage die Verkabelungen zwischen den Modulen vornehmen.
• Die Zusammensetzung und Verkabelung des Line Array fertigstellen.
ACHTUNG!
Produkt und Zubehör dürfen nur von qualiziertem Personal gehandhabt werden! Stellen Sie sicher, dass die Anlage stabil und sicher aufgestellt wird, um gefährliche Personen-, Tier- und / oder Sachschäden zu vermei­den. Der Benutzer ist verpichtet, die Vorgaben und die gesetzlichen Vorschriften über die Sicherheit des Landes, in dem das Produkt verwendet wird, zu befolgen. Für den sicheren Gebrauch regelmäßig die Funkti­onstüchtigkeit aller Teile und die Unversehrtheit vor Gebrauch überprüfen. Planung, Berechnungen, Installation, Testen und Wartung von Schranksystemen oder professionellen Audiost­apeln dürfen nur von autorisiertem Personal durchgeführt werden. AEB Industriale ist nicht verantwortlich für unsachgemäße Installationen, die nicht den Sicherheitsanforderungen entsprechen.
A
B
VIO-L212 Art.-Nr. 420120270 REV. 1.0
73
ANGABEN ZUR STROMVERSORGUNG UND VERHALTEN DES LINE ARRAY SYSTEMS
Es ist zu berücksichtigen, dass sich die
Stromversorgung der Anlage mit ordnungsgemäßer Dimensionierung der Quelle und Verkabelungen auf den Betrieb der Module und des Systems auswirkt.
1. Der an das Line Array Modul gelieferte
Strom hat ein dynamisches Verhalten (z. B.
erste Einschaltung, Idle-Status, Vollbetrieb).
2. Es kommen durch die Länge und den Querschnitt des Kabels
bedingte Spannungsabfälle vor. Normalerweise erfolgen diese Spannungsabfälle direkt proportional mit der Länge und umgekehrt proportional mit dem Kabelquerschnitt.
Deutsch
A
B
VIO-L212
A
B
A
B
Art.-Nr. 420120270 REV. 1.0
74
Deutsch
BEISPIELE GEMISCHTER KONFIGURATIONEN
D
C
D2
A
B
A
B
Über den Adapter TF-VIO2 ist die Verwendung eines Line Array VIO-L210 in Down-ll Funktion unter einem aus VIO-L212 zusammengesetzten Line Array möglich. Das empfohlene Verhältnis zwischen den 2 Modellen ist 3:1 wie als unverbindliches Beispiel nachstehend erläutert wird.
• A - Vordere Bügel für VIO-L212
• B - Vorderes Befestigungssystem für VIO-L210
• C - Hinteres Verbindungsteil für VIO-L210
• D - Hinterer Kopplungsbügel für VIO-L212
VIO-L212 Art.-Nr. 420120270 REV. 1.0
75
BEISPIELE GESTAPELTER KONFIGURATIONEN
Die hauptsächlichen Stapel-Kongurationen sind:
auf Subwoofer (mittels DRK-212)
• direkt am Wagen DT-VIOL212 mit
Verwendungspicht des Zubehörteils EFK-1.
Deutsch
Für die Einzelheiten über die Montage und zulässigen Kongurationen Bezug auf die Handbücher der jeweiligen
Zubehörteile nehmen.
VIO-L212
Art.-Nr. 420120270 REV. 1.0
76
Deutsch
7. PROBLEMABHILFE
Das Modul lässt sich nicht einschalten:
1. Überprüfen Sie das Vorhandensein der korrekten, der Anlage vorgeschalteten Versorgung.
2. Überprüfen Sie, ob die Stromversorgung oder der Rücklauf der Stromversorgung korrekt eingeschaltet sind.
3. Überprüfen Sie, ob der Querschnitt und die Länge der Verkabelungen, inklusive Spannungsabfälle, den Betrieb innerhalb des zulässigen Bereiches ermöglichen.
4. Überprüfen Sie etwaige, vom AURORA NET (in RDNet Verbindung) gemeldete Warnungen.
Das Modul lässt sich einschalten, gibt jedoch keine Töne ab:
1. Überprüfen Sie, dass die Anschlüsse zum Audiosignaleingang oder der Rücklauf des Audiosignals korrekt erfolgt sind.
2. Überprüfen Sie, ob die Audioquelle (Mischer) richtig angeschlossen und aktiv ist.
3. Überprüfen Sie an der Fernsteuerung über AURORA NET (in RDNet Verbindung), dass keine MUTE eingeschaltet sind. Überprüfen Sie auch eventuell gemeldete Warnungen.
Der Ton ist nicht völlig zufriedenstellend.
1. Überprüfen mithilfe der Software DBTECHNOLOGIES COMPOSER die Planung und die Installations- und
Kongurationsspezikationen.
2. Überprüfen Sie, ob die DSP-VOREINSTELLUNGS-Parameter tatsächlich auf dem Bedienfeld des Moduls
repliziert werden (insbesondere, wenn die Fernbedienung des Moduls nicht verwendet wird).
3. Überprüfen Sie im Falle einer RDNet-Netzwerkverbindung und -steuerung mit dem AURORA NET, dass alle Parameter und insbesondere die Entzerrungsparameter korrekt eingestellt sind.
VIO-L212 Art.-Nr. 420120270 REV. 1.0
77
Deutsch
8. FIRMWARE-AKTUALISIERUNG
ES ist sehr wichtig, die Produkt-Firmware auf dem neuesten Stand zu halten, um die volle Funktionalität zu gewährleisten. Überprüfen Sie regelmäßig die Website http://www.dbtechnologies.com unter dem Abschnitt
DOWNLOADS.
1. Laden und installieren Sie den USB BURNER MANAGER aus dem Abschnitt SOFTWARE & CONTROLLER auf Ihren PC.
2. Laden Sie die ZIP-Datei der neuesten Firmware aus dem Abschnitt DOWNLOADS Ihres Produkts herunter.
3. Verbinden Sie das Produkt mit einem USB-Kabel (nicht mitgeliefert) mit einem geeigneten Steckverbindertyp (siehe dieses Detail im Kapitel VERSTÄRKUNGS- UND STEUEREIGENSCHAFTEN).
4. Wählen Sie auf dem Bildschirm USB BURNER MANAGER oben rechts im Bildschirm „Datei öffnen“.
5. Wählen Sie die Datei mit der zuvor heruntergeladenen Firmware aus.
6. Folgen Sie den Anweisungen auf dem Bildschirm.
7. Klicken Sie auf „AKTUALISIEREN“.
VIO-L212
78
Art.-Nr. 420120270 REV. 1.0
Deutsch
9. TECHNISCHE DATEN
ALLGEMEINE ANGABEN
Typ: 3-Wege Line-Array-Modul
AKUSTIK-DATEN
Frequenzgang [- 10 dB]: 49.8 - 20000 Hz
Frequenzgang [- 6 dB]: 55 - 18600 Hz
Max. SPL: 142 dB (Frequenz / voreingestellt)
HF: 2 x 1.4“ (Spule: 3 “)
Typ des HF-Messumformers: Titan
MF: 4 x 6.5“ (Spule: 2 “)
Typ des MF-Messumformers: Neodym
LF: 2 x 12-Zoll (Schwingspule: 3 “)
Typ des LF-Messumformers: Neodym
Wellenleiter für hohe Frequenzen: Ja
Waagrechtrichtung: 90 GRAD
Senkrechtrichtung: veränderlich, je nach Konguration und Anzahl der Module
VERSTÄRKER
Typ: (2x) Digipro® G4
Verstärkungsklasse: Klasse D
Verstärkungsleistung (Peak) 2x 1600 W (3200 W)
Verstärkungsleistung (RMS): 2x 3200 W (6400 W)
Versorgung: Fullrange mit PFC, Bereich 100-240 V~ (50-60 Hz)
Kühltechnik: Konvektion + Lüer mit unteren Belüungsgittern
Betriebstemperaturbereich (Umge­bungstemperatur):
VIO-L212 Art.-Nr. 420120270 REV. 1.0
-15 ° bis +55 ° [°C]
79
PROZESSOR
Interner Controller: DSP 32 bit
Umwandlung AD/DA 24 bit / 96 kHz
Fortgeschrittene Funktionen des DSP FIR-Filter mit linearer Phase
Positionserkennung: Inklinometer, Modul mit NFC Technologie
Interne Funktion erster Test: Impedanztest mit Sweep
BENUTZEROBERFLÄCHE
Bedienelemente: HPF Drehregler, DSP Voreinstellung
Status-LEDs Ready, Mute/Prot, Signal, Limiter
Deutsch
Schnittstellen-LEDs RDNet Link, Active, Remote Preset Active
EINGÄNGE UND AUSGÄNGE
Eingänge und Wiedereinschaltung der Stromversorgung:
Audioeingänge: 1x XLR EIN symmetrisch (Isolierung: Floating ADC )
Audioausgänge: 1x XLR AUS-Anschluss, symmetrisch
RDNet Ein- / Ausgänge: Daten Ein / Daten Aus (etherCON® Anschlüsse)
USB (Firmware-Aktualisierung): 1x MINI-USB Typ B
PowerCON® True In/Link
SOFTWARE-KOMPATIBILITÄT
Vorhersage-/Validierungssoware dBTechnologies COMPOSER
Fernsteuerungssoware: AURORA NET
Andere Sowares: Ease, Ease Focus 3
VIO-L212
80
Art.-Nr. 420120270 REV. 1.0
Deutsch
STROMSPEZIFIKATIONEN (ABSORPTION)
Aufnahme bei 1/8 der Leistung unter durchschnittlichen Betriebsleistung
(*):
Aufnahme bei 1/3 der Leistung unter
maximalen Einsatzbedingungen (**):
Aufnahme bei eingeschaltetem
Lautsprecher ohne Signal (Leerlauf):
2 A (230V~) - 3.1 A (115V~)
4,9 A (230 V~) - 7,5 A (115 V~)
53 W
Einschaltstrom:
3.2 A
Max. Anzahl der Module pro Versorgungsleitung (**)
1 + 2 (220-240 V~) / 1 + 1 (100-120 V~)
[Netzeingang + Netzanschluss]:
*HINWEIS FÜR DEN INSTALLATEUR: Die Werte beziehen sich auf 1/8 der Leistung im mittleren Betriebszustand (Musikprogramm mit
seltenem oder ohne Clipping). Es wird für jede Art von Konguration empfohlen, diese als Mindestgrößen zu betrachten. ** HINWEIS FÜR DEN INSTALLATEUR: Die Werte beziehen sich auf 1/3 der Leistung im schweren Betriebszustand (Musikprogramm mit häugem
Clipping und Ansprechen des Limiters). Bei professionellen Installationen und Touren empehlt es sich, nach diesen Werten zu dimensionieren.
MECHANISCHE SPEZIFIKATIONEN
Material: Holzgehäuse - schwarze Polyurea-Beschichtung
Gitter: Vollmetall - CNC-Verarbeitung
Grie eingebaut (2 pro Seite)
Vordere Montageauslegungen:
Hintere Montageauslegungen: Verstellbare Halterung und beweglicher Arm mit Schnellspanner
Flown- und Stapelmontage: mit DRK-212 Flugrahmen
Breite: 1100 mm (43.31 in)
Versenkbare Halterungen, im Gehäuse eingebaute Haltepunkte mit
Schnellspannsti
Höhe: 380 mm (14.96 in)
Tiefe: 450 mm (17.72 in)
Gewicht: 54.4 kg (119.9 lbs)
Die Eigenschaften, die Spezikationen sowie das Erscheinungsbild der Produkte können ohne vorherige Ankündigung geändert werden. dBTechnologies behält
sich das Recht vor, Änderungen und Verbesserungen
am Design oder den Ausführungen vornehmen zu können, ohne die Verpichtung einzugehen, zuvor hergestellte Produkte ändern oder verbessern zu müssen.
info@dbtechnologies-aeb.com
VIO-L212 Art.-Nr. 420120270 REV. 1.0
A.E.B. Industriale Srl
Via Brodolini, 8
Località Crespellano
40053 VALSAMOGGIA
BOLOGNA (ITALIA)
Tel +39 051 969870 Tel +39 051 969725
www.dbtechnologies.com
81
Français
INDEX
INDEX
1. GÉNÉRALITÉS ..........................................................................................................................83
BIENVENUE ! .......................................................................................................................83
INTRODUCTION ..................................................................................................................83
CARACTÉRISTIQUES MÉCANIQUES ET ACOUSTIQUES .....................................................84
CARACTÉRISTIQUES ACOUSTIQUES .......................................................................................................... 84
MÉCANIQUE ET DOTATIONS PRINCIPALES ............................................................................................... 85
2. CONTRÔLES LOCAUX ET CONNEXIONS ..............................................................................88
3. PRÉDICTION ACOUSTIQUE ET VÉRIFICATION MÉCANIQUE : DBTECHNOLOGIES
COMPOSER .............................................................................................................................92
4. AURORA NET ..........................................................................................................................94
5. PARAMÈTRES DSP PRESET ....................................................................................................95
6. ACCESSOIRES, INSTALLATION, CONFIGURATION ..............................................................96
ADAPTATEURS ENTRE MODÈLES .......................................................................................96
CHARIOTS ............................................................................................................................96
PRÉDICTION ACOUSTIQUE / VALIDATION MÉCANIQUE ..................................................97
PRÉPARATION DU FLY-BAR ET DES MODULES ..................................................................97
MONTAGE DU LINE-ARRAY ET CÂBLAGE ..........................................................................98
EXEMPLES DE CONFIGURATIONS MIXTES ......................................................................101
EXEMPLES DE CONFIGURATIONS STACKED ....................................................................102
7. DÉPANNAGE .........................................................................................................................103
8. MISE À JOUR DU MICROLOGICIEL .....................................................................................104
9. SPÉCIFICATIONS TECHNIQUES ...........................................................................................105
GÉNÉRAL .................................................................................................................................................. 105
DONNÉES ACOUSTIQUES ........................................................................................................................ 105
AMPLIFICATEUR ....................................................................................................................................... 105
PROCESSEUR ............................................................................................................................................ 106
INTERFACE UTILISATEUR ......................................................................................................................... 106
ENTRÉES ET SORTIES................................................................................................................................ 106
COMPATIBILITÉ LOGICIEL ........................................................................................................................ 106
SPÉCIFICATIONS D’ALIMENTATION (ABSORPTION) ................................................................................ 107
SPÉCIFICATIONS MÉCANIQUES ............................................................................................................... 107
VIO-L212
82
Code 420120270 RÉV. 1.0
1100
380
330
Français
1. GÉNÉRALITÉS
BIENVENUE !
Merci d'avoir acheté un produit conçu et développé en Italie par dBTechnologies ! Ce line-array actif, puissant et approprié pour les évènements en direct plus importants, est le résultat d’une longue expérience dans le secteur de la diffusion sonore. Il adopte des solutions innovantes et optimisées dans le domaine acoustique et électronique ainsi que pour la recherche des matériaux utilisés.
INTRODUCTION
Le module line-array actif à 3 voies VIO-L212
franchit une nouvelle étape dans le domaine de la recherche et de l’optimisation pour les applications professionnelles live d’intérieur et d’extérieur de grandes dimensions. Les caractéristiques plus
marquantes sont :
• optimisation entre la plage complète de hautes performances et les dimensions
système de xation à 3 points pour un montage/
démontage efcace ;
ligne d’accessoires professionnels dédiés pour la manutention et le montage ;
section d’amplication composée de 2 DIGIPRO
G4 de 1600 W RMS chacun, contrôlés par DSP à 32 bits (ltrage FIR dédié) ;
technologie Floating ADC, développée pour une isolation parfaite des brouillages, bruits et
bourdonnements, de l’entrée audio ;
contrôle par DSP et ltrage en temps réel avec ltres FIR ;
relances d’alimentation, audio et de réseau pour un câblage optimisé
contrôle RDNet on board, prédisposition pour protocole AoIP Audinate DanteTM ;
logiciels prédictifs et de gestion à distance (DBTECHNOLOGIES COMPOSER, EASE, EASE
FOCUS 3, AURORA NET).
32
4500
59
155
30
48,5
VIO-L212 Code 420120270 RÉV. 1.0
83
CARACTÉRISTIQUES MÉCANIQUES ET ACOUSTIQUES
CARACTÉRISTIQUES ACOUSTIQUES
Français
B
A
D
C
D
B
F
E
F
E
A
A - [LF] 2 Woofers en Néodyme de diamètre 12”, voice coil de 3” (conguration reex). B - [MF] 4 Mid-Range en Néodyme de diamètre 6.5”, voice coil de 2”. C - [HF] 2 Compression Driver en Néodyme, bouche de 1,4”, bobine en titane de 3” (chargement à pavillon).
D - Phase plug avec chambre optimisée E - Guides d’onde F - Prols avec évolution logarithmique du pavillon
L’optimisation acoustique de VIO-L212 harmonise les performances (SPL, réponse en phase et en fréquence, focus sonore) avec les dimensions et les contraintes mécaniques de conception.
En particulier :
• les phases plug [D] avec chambre optimisée augmentent la cohérence des fréquences moyennes ;
• le positionnement et la distance des transducteurs Mid-Range contribuent à un focus sonore et à une
écoute désaxée nettement dénis ;
les prols avec évolution logarithmique [F] du pavillon, évitent entre autres, la création de réexions constantes (modes) et augmentent la cohérence de la gamme des fréquences moyennes supérieures ;
les guides d’onde [F] contrôlent la directivité verticale des hautes fréquences.
VIO-L212
84
Code 420120270 RÉV. 1.0
Français
MÉCANIQUE ET DOTATIONS PRINCIPALES
U
T - GOUJONS DE FIXATION AVANT U - ÉTRIERS ESCAMOTABLES POUR
LA FIXATION À UN MODULE SUPÉRIEUR
V - LOGEMENTS POUR LA FIXATION À
UN MODULE INFÉRIEUR
T
V
T
V
Y
W
W- ÉTRIER ARRIÈRE X - JOINT MOBILE Y - GOUJONS DE FIXATION
ARRIÈRE
Z - HOUSSE ANTI-PLUIE
Z
X
Le système de xation à 3 points emploie, avec l’utilisation de goujons :
les étriers supérieurs U, sur la partie frontale
les logements inférieurs U, sur la partie frontale
l’étrier W, avec joint mobile X, sur le côté arrière.
Dans les images suivantes, par souci de simplication, ne seront plus représentées les housses anti-pluie [Z].
Z
VIO-L212 Code 420120270 RÉV. 1.0
85
Pour la xation des deux modules :
CÔTÉ AVANT
Français
1) Sur le module B extraire vers le haut les étriers U et les xer
aux goujons relatifs.
2) Extraire les goujons T du module A
3) Approcher les 2 modules en insérant les étriers U dans les
logements V.
4) Insérer complètement les
goujons T. De cette façon les modules A et B sur la partie
frontale résultent bloqués.
CÔTÉ ARRIÈRE
5) Sur le module A débloquer le
joint mobile X. Insérer enn le goujon Y dans le trou relatif à
l’inclinaison souhaitée.
Les détails relatifs à cette opération sont illustrés dans
la page suivante. ls sont
différents en fonction du type d’installation FLOWN ou
STACK.
A
T
U
T
U
B
V
U
T
VIO-L212
86
B
A
X
Y
X
Y
W
W
Code 420120270 RÉV. 1.0
Français
GOUJON 2
GOUJON 1
INSTALLATION FLOWN
X
Il faut utiliser un seul goujon (GOUJON 1) pour xer l’angle sur l’arrière. Les trous d’introduction de l’étrier W, avec des couleurs différentes, permettent d’obtenir
les angles suivants : [0°, 0.5°, 1°, 2°, 3°, 4.5°, 6°, 8°]. La
fente de l’étrier permet d’insérer les goujons sans devoir
soulever la partie arrière du VIO-L212.
INSTALLATION STACKED (SUPERPOSÉE)
Il faut utiliser 2 goujons (GOUJON 1, GOUJON 2) pour xer l’angle sur l’arrière. Une fois inséré le GOUJON 1, selon la procédure FLOWN, l’arrière de VIO-L212 se soulève jusqu’à ce que la fente le permet et on xe la
position avec le GOUJON 2.
W
VIO-L212 Code 420120270 RÉV. 1.0
87
2. CONTRÔLES LOCAUX ET CONNEXIONS
Les 2 amplicateurs DIGIPRO G4 sont en mesure de débiter jusqu’à 3200 W
RMS.
Le schéma fonctionnel de l’électronique de VIO-L212 est représenté dans la page suivante.
Les deux sections principales,
présentes sur l’arrière du module et protégées par les housses anti-pluie (que nous ne montrons pas ci) sont :
• CONNEXIONS ET CONTRÔLE
• ALIMENTATION
La section CONNEXIONS ET CONTRÔLE, utilise un DSP qui
contrôle, entre autres, le ltrage FIR
du signal de sortie.
Français
La section D’ALIMENTATION emploie un PFC qui en améliore l’efcacité et protège la section d’amplication des oscillations indésirables des grandeurs électriques en entrée.
FILTRAGE FIR
L’égalisation du son est contrôlée par
un DSP à 32 bits.
Les ltres FIR implémentés minimisent la distorsion de phase du signal égalisé.
Pour les détails de l’égalisation se
référer au paragraphe : « PARAMÈTRES
DSP PRESET ».
PFC
La correction du facteur de puissance (PFC) réduit le déphasage entre courant et tension débitée à l’amplicateur. Dans les limites d’une certaine plage, donc, l’alimentation en entrée résulte idéale, malgré de petites variations dans l'alimentation électrique en amont de l’installation. Pour plus de détails sur les recommandations d’alimentation, voir le paragraphe : « MONTAGE DU LINE-ARRAY ET
CÂBLAGE ».
AMP2-ALIMENTATION
AMP1-CONNEXIONS ET CONTRÔLE
VIO-L212
88
Code 420120270 RÉV. 1.0
M A
I N
S F
U S E
1 0 0
­1 2 0 V
~
( T
1 0 A
L 2
5 0 V ~ )
2 2 0
­2 4 0 V
~
( T
5 A
L 2
5 0 V ~ )
M A
I N
S F
U S E
1 0 0
­1 2 0 V
~
( T
1 0 A
L 2
5 0 V ~ )
2 2 0
­2 4 0 V
~
( T
5 A
L 2
5 0 V ~ )
Français
AUTO-RANGE
MAINS LINK
MAINS INPUT
Link
Output
Input
Balanced Audio
BLOCK DIAGRAM
PUSH
M
(
(
T
T
1
5
A
0
A
2
I
A
1
2
N
L
0
0
L
S
2
0
­2
2
5
-
F
1
4
5
0
U
2
0
0
V
V
0
S
V
~
V
~
E
~
)
~
)
FUSE
Power Supply
FUSE
Power Supply
EMI FILTER
Amplifier Module
Amplifier Module
SMPS MAIN
Voltage
DIGIPRO G4
Amplifier
CLASS D
High
DIGIPRO G4
CLASS D
Voltage
DIGIPRO G4
Amplifier
CLASS D
M
(
(
T
T
1
5
A
0
A
2
I
A
1
2
N
L
0
0
L
S
2
0
­2
2
5
-
F
1
4
5
0
U
2
0
0
V
0
V
S
V
~
V
~
E
~
)
~
)
EMI FILTER
SMPS MAIN
High
DIGIPRO G4
CLASS D
Floating Input GroundFloating Input Ground
Low
Voltage
Low
Voltage
Low
Voltage
OPAMP
Floating ADC technology
ADC
Galvanic
Isolation
Preamplifier Module
DAC
Active
Link
NFC internal module
DSP
Out
Rs485
RDNET
Data
Data
In
RDNet
Rs485
CPU (MASTER)
Removable Card
SPEAKERS
COUPLING
D
USB Data Service
COMPENSATION
HIGH FREQ
5
F
E
C
B
7
6
4
3
G
A
8
1
2
Service / User
75
85
90
80
70
60
65
High Pass Filter [Hz]
Remote Preset
Active
Fullrange
1.4" C.D.
1.4" C.D.
12" WOOFER
12" WOOFER
6.5" MID-RANGE
6.5" MID-RANGE
6.5" MID-RANGE
6.5" MID-RANGE
Ready
Mute/Prot
Signal
Limiter
System Test
VIO-L212 Code 420120270 RÉV. 1.0
89
1. ENTRÉE ET RELANCE AUDIO (« Balanced audio ») Entrée et sortie compatible avec câbles XLR symétriques. En particulier, « Input » est utilisé pour le branchement avec le signal audio venant du mélangeur ou d’une autre enceinte,
« Output Link » pour la relance du signal aux autres modules du
line-array en conguration daisy-chain.
2. HIGH PASS FILTER
Il permet d’appliquer directement un ltre passe-haut (non appliqué, la position stand-by est Fullrange). En particulier la fréquence de coupure peut être choisie parmi : (60,65,70,75,80,85,90 Hz)
3. ENTRÉE ET RELANCE DE LA CONNEXION DE RÉSEAU RDNet
Section compatible avec les câbles de réseau avec connecteurs
type etherCON/RJ45.
En particulier « Data in » doit être relié à des dispositifs comme RDNet Control 2 ou Control 8, « Data Out » est utilisé pour la relance du réseau à d’autres modules du line-array en conguration daisy-chain.
Français
4. DSP PRESET
Commande rotative pour le réglage acoustique du line-array. Il convient d’utiliser ces commandes (ou les mêmes paramètres à distance avec la connexion RDNet) pour
optimiser la performance acoustique en fonction du nombre de modules et à leur pointage. Un approfondissement sur
l’utilisation de « SPEAKER COUPLING » et « HIGH FREQUENCY COMPENSATION » est présent dans la section «PARAMÈTRES
DSP PRESET ET CONTRÔLE À DISTANCE”.
5. LED D’ÉTAT
LED relatives au fonctionnement du module. Un tableau dans la
page suivante résume et synthétise la fonction des différentes
LED.
6. LED DE CONTRÔLE
LED relatives au fonctionnement en réseau (RDNet) du module. En particulier, « Link » allumé signale que le réseau RDNet est
actif et a reconnu le dispositif, « Active » en mode clignotant,
qu’il existe un trac de données, « Remote Preset Active » que toutes les commandes locales sur le panneau amplicateur sont by-passées par la commande à distance RDNet.
7. USB DATA SERVICE Port de type mini-USB B, à utiliser exclusivement pour la mise à jour du micrologiciel du produit. Voir la section « MISE À JOUR
DU MICROLOGICIEL » pour plus d’informations.
8. SYSTEM TEST
Il effectue un test avec signal sweep pour vérier l’intégrité du woofer. Ce test ne doit pas être considéré exhaustif, puisqu’il représente uniquement un premier contrôle lors de l’analyse de toute problématique.
9. FUSIBLE DE RÉSEAU.
Logement pour le fusible de réseau de la section AMP1.
VIO-L212
90
Code 420120270 RÉV. 1.0
Français
TYPE LED PHASE D’ALLUMAGE
DE L'ENCEINTE
EN FONCTION NORMALE
WARNING GÉNÉRIQUE
BLOCAGE POUR ANOMALIE DE L’ENCEINTE
LIMITER ÉTEINT ÉTEINT, IL S’ALLUME
SEULEMENT EN CAS
D’INTERVENTION
SIGNAL
SOURDINE/ PROT
PRÊT ÉTEINT ALLUMÉ FIXE ALLUMÉ FIXE ÉTEINT
10. CONNECTEUR D'ALIMENTATION « MAINS INPUT »
Compatible avec le connecteur powerCON TRUE1®,
l’alimentation est dotée de fonction autorange. Après avoir déni la plage opportune avec le remplacement éventuel du fusible, il reconnaît automatiquement la tension à l’intérieur de la plage [100-120V~] ou bien [220-240V~].
ÉTEINT CLIGNOTEMENT
EN PRÉSENCE DE SIGNAL
ALLUMÉ PENDANT QUELQUES SECONDES
ÉTEINT CLIGNOTEMENT
CLIGNOTEMENT MOMENTANÉ
SIGNALISATION NORMALE
D’AUDIO EN
ENTRÉE
MOMENTANÉ
CLIGNOTEMENT CYCLIQUE CONTINU
ÉTEINT
ALLUMÉ FIXE
11. RELANCE D'ALIMENTATION « MAINS INPUT »
Compatible avec connecteur type powerCON TRUE1® pour la
relance de l’alimentation à d’autres modules. Pour savoir le nombre maximum de modules pouvant être connectés dans un système relancé, consulter la section
SPÉCIFICATIONS TECHNIQUES.
12. FUSIBLE DE RÉSEAU.
Logement pour le fusible de réseau de la section AMP2.
VIO-L212 Code 420120270 RÉV. 1.0
91
Français
3. PRÉDICTION ACOUSTIQUE ET VÉRIFICATION MÉCANIQUE : DBTECHNOLOGIES COMPOSER
Le logiciel dBTechnologies Composer, peut être téléchargé gratuitement du site www.dbtechnologies.com, il s’agit de l’instrument conseillé pour la conception correcte de systèmes audio pour toute la série VIO. Il suggère la solution pour les espaces à sonoriser, en indiquant l’angle des modules du line-array pour obtenir la couverture souhaitée et le pré-réglage à utiliser. Bien qu’il s’agisse d’un instrument prédictif, il permet toutefois d’effectuer une série de réglages manuels pour perfectionner la conguration sur la base de mesures audio éventuelles effectuées sur le terrain, ou en fonction d’exigences spéciques. C’est enn l’instrument efcace pour évaluer la sécurité de l’installation. En effet grâce à une simulation du comportement statique des y-bar et à une indication des forces mécaniques en jeu, il permet de vérier combien de modules on peut installer avant d’arriver à une condition de surcharge.
Les sections principales de dBTechnologies Composer sont :
• COMPOSER - vue générale permettant la saisie des données initiales de conception
• LAs PREDICT - avec la simulation, la conguration et le contrôle de la sécurité des modules line-
array
• SUBs PREDICT - avec la simulation, la conguration et le contrôle de la sécurité des subwoofers
Dans ce chapitre sont mis en évidence certains détails du logiciel relatifs au montage et à la sécurité, en particulier pour la conguration FLOWN des line-array VIOL212.
VIO-L212
92
Code 420120270 RÉV. 1.0
Français
La section LAs PREDICT contient toutes les informations pour la conguration correcte en own ou stack d’un système VIO. Pour y accéder il faut compléter avant tout la saisie des données de conception, présentes dans la section Composer. Dans la page-écran System Data, sont suggérés : l’angle des différents modules, les différents paramètres relatifs à la section «DSP preset» et l’angle du y-bar DRK-212. Ce dernier angle peut être mesuré sur le terrain à l’aide d’un inclinomètre laser, non inclus, dont le montage est illustré dans le manuel du DRK-212.
VIO-L212 Code 420120270 RÉV. 1.0
93
4. AURORA NET
AURORA NET est un logiciel de commande à distance avec ces caractéristiques :
multiplateforme (Windows /MAC OS X)
elle permet d’effectuer un contrôle très attentif des paramètres et de leur chronologie pendant un
évènement
elle permet d’avoir une gestion exible même en cas d’installations xes / live de grandes
dimensions (avec un contrôle avancé des groupes)
elle permet de rappeler de différents preset
optimisé pour la facilité d'utilisation et la vitesse d’afchage des données
Pour plus d’informations, veuillez consulter le manuel complet du logiciel.
Français
VIO-L212
94
Code 420120270 RÉV. 1.0
Français
5. PARAMÈTRES DSP PRESET
L’utilisation d’un line-array comporte un certain nombre d’avantages dans des contextes différents, en particulier :
SPL homogène tout au long de la directrice frontale des enceintes, un effet que l’on peut apprécier sur les distances moyennes supérieures
comportement acoustique directif qui permet de focaliser de manière précise le son sur le public, en évitant des dispersions inutiles dans des zones où une couverture acoustique n’est pas nécessaire.
L’optimisation réalisable du line-array tient compte du comportement du système par rapport à la fréquence :
au fur et à mesure que la distance du line-array augmente, l’atténuation de l’air augmente aussi. Cela produit son effet en particulier sur les hautes fréquences.
Au fur et à mesure que l’angle entre les éléments du line-array augmente, le couplage acoustique synchronisé aux fréquences moyennes diminue.
Au fur et à mesure que le nombre de modules du line-array augmente, les basses fréquences s’ajoutent selon une acoustique cohérente.
La conguration acoustique en line-array des modules VIO L212 peut être optimisée, grâce aux fonctions de contrôle gérées par le DSP. L’interface locale pour l’utilisation est simple et immédiate : elle emploie
deux commandes rotatives de la section « DSP Preset » :
Le calcul des paramètres est effectué avec dBTechnologies Composer. Il est possible de sélectionner en
mode local ces paramètres sur le panneau de VIO-L212, et d’utiliser en outre la commande à distance
via AURORA NET.
• Positionner la commande rotative « SPEAKER COUPLING » en fonction du nombre de modules
employés dans le line array. Cette commande rotative agit sur les basses fréquences et doit être réglée
dans la position :
Tous les paramètres peuvent être réglés à l’aide de la commande à distance, après avoir réalisé
correctement les connexions RDNet, à l’aide du logiciel gratuit AURORA NET. Quand la commande est à distance, les commandes locales présentes sur le panneau des modules VIO-L212 sont by-passées.
Pour plus d’informations, veuillez consulter le manuel complet du logiciel.
VIO-L212 Code 420120270 RÉV. 1.0
95
6. ACCESSOIRES, INSTALLATION, CONFIGURATION
FLY-BAR DRK-212
B2
Français
A
A
C
D2
B1
C
D1
DRK-212 est le y-bar pour l’utilisation en conguration FLOWN et STACK de VIO-L212. La conguration FLOWN donne la possibilité d’une double utilisation, avec line-array incliné vers le bas ou bien vers le haut. Se référer aux instructions spéciques de l’accessoire pour les détails de montage.
• A - Crochets de levage moteur
B - Accouplement arrière (en fonction de la conguration) FLOWN
• C - Étriers escamotables frontaux pour utilisation STACK
D - Fixations avant FLOWN (en fonction de la conguration)
D2
ADAPTATEURS ENTRE MODÈLES
NOM MODÈLE ADAPTÉ
CHARIOTS
VIO-L212
96
TF-VIO2
NOM UTILISATION TOP
DT-VIOl212
DO-VIOl212
DT-DRK212 2 DRK212 (+ 2 TF-VIO2)
1-4 VIOL212
1 VIOL212
VIOL210
Code 420120270 RÉV. 1.0
Français
PRÉDICTION ACOUSTIQUE / VALIDATION MÉCANIQUE
Utiliser DBTECHNOLOGIES COMPOSER pour congurer les paramètres de conception.
Vérier que la validation MECHANICAL SAFETY du logiciel conrme la sécurité de la conguration choisie.
Vérier que les paramètres locaux des différents modules sont congurés correctement sur chaque panneau
amplicateur. En particulier, vérier selon le projet, les réglages des paramètres Speaker Coupling et High Frequency Compensation. Sinon il est possible de modier en temps réel ultérieurement tous les paramètres à distance si on effectue une connexion du line-array via réseau RDNet (DBTECHNOLOGIES NETWORK). Toutefois il convient de répliquer toutes les congurations initiales de conception physiquement sur les modules VIO-L210 avant d’effectuer l’installation. Pour de plus amples informations se référer à la section PARAMÈTRES
PRÉ-RÉGLAGE DSP ET COMMANDE À DISTANCE.
PRÉPARATION DU FLY-BAR ET DES MODULES
Préparer les y-bar DRK212 et les modules line-array VIO-L212. Dans cet exemple nous avons représenté les chariots DT-DRK212 et les chariots DT-VIOL212 avec les top DTT-VIOL212. La conguration d’exemple purement illustrative, est celle d’un line-array à 8 modules.
LE INDICAZIONI DI CABLAGGIO NELLE FIGURE SEGUENTI SONO PURAMENTE INDICATIVE.
VIO-L212 Code 420120270 RÉV. 1.0
97
Français
MONTAGE DU LINE-ARRAY ET CÂBLAGE
Retirer la sangle de sécurité et le top. Sur l'arrière des modules insérer les goujons pour xer les angles calculés par le logiciel.
À l’aide des moteurs, soulever du chariot DT-DRK212 1 y-bar et le xer dans la conguration own sur le top VIO-L212 supérieur.
Sur le y-bar, prendre soin de faire passer pour la connexion suivante les câblages principaux nécessaires.
Effectuer les premiers câblages entre chaque module, en particulier ceux qui peuvent être relancés.
Soulever la partie supérieure du line-array
VIO-L212
98
Code 420120270 RÉV. 1.0
Français
Porter le chariot avec les autres 4 modules sous ceux déjà hissés. Enlever la sangle et le top du deuxième chariot.
Agir en accrochant un module à la fois, en faisant monter/descendre légèrement les câbles avec les moteurs,
avant avec montage frontal, puis arrière, comme illustré dans la section MÉCANIQUE ET DOTATIONS
PRINCIPALES.
Réaliser les câblages entre module et module, au fur et à mesure que l’on procède avec le montage.
• Terminer la composition et le câblage du line-array.
ATTENTION !
Le produit et les accessoires doivent être utilisés uniquement par du personnel expérimenté ! S’assurer que l’installation est positionnée de façon stable et sûre pour éviter toute situation de danger pour les personnes, les animaux et/ou les choses. L’utilisateur est tenu de suivre les réglementations et les lois en vigueur en ma­tière de sécurité dans le pays où est utilisé le produit. Pour l’utilisation en sécurité, vérier périodiquement la fonctionnalité de toutes les parties et l’intégrité avant la mise en service. La conception, les calculs, l’installation, les essais et l’entretien des systèmes suspendus ou stack audio profes­sionnels doivent être effectués exclusivement par du personnel autorisé. AEB Industriale n’est pas responsable pour des installations non conformes, effectuées en l’absence des conditions requises de sécurité.
A
B
VIO-L212 Code 420120270 RÉV. 1.0
99
INDICATIONS SUR L’ALIMENTATION ET LE COMPORTEMENT DU SYSTÈME LINE-ARRAY
Il faut garder à l’esprit que l’alimentation du système, avec un
dimensionnement correct de la source et des câblages a une
inuence sur le bon fonctionnement des modules et du système.
1. Le courant fourni au module line-array a un
comportement dynamique, (ex. premier allumage, état inactif, fonctionnement à plein régime).
2. Il existe des chutes de tension liées à la longueur et
à la section du câble. En règle générale, ces chutes sont directement proportionnelles à la longueur et inversement proportionnelles à la section des câbles.
Français
A
B
VIO-L212
A
B
A
B
Code 420120270 RÉV. 1.0
100
Loading...
