d&b Z5038 User Manual

Z5038 Fixing plate M10
Mounting instructions (1.0 EN)

General information

Z5038 Fixing plate M10
Mounting instructions

Version: 1.0 EN, 06/2011, D2963.EN.01

Copyright © 2011 by d&b audiotechnik GmbH; all rights
reserved.

Keep this manual with the product or in a safe place
so that it is available for future reference.

When reselling this product, hand over this manual to the new
customer.

d&b audiotechnik GmbH
Eugen-Adolff-Strasse 134, D-71522 Backnang, Germany
T [phone], F [phone]
[e-mail], www.dbaudio.com

1. Z5038 Fixing plate M10

1.1. Scope of supply

Please verify the shipment for completeness and proper condition
of the items.

Fig. 1: Scope of supply

Qty.

1

d&b Code Description

Z5038

Fixing plate M10

Including:

1 D2963 Mounting instructions

1.2. Safety precautions

General safety

Installation and setup should only be carried out by qualified and
authorized personnel observing the valid national Rules for the
Prevention of Accidents (RPA).

It is the responsibility of the person installing the assembly to ensure
that the suspension/fixing points are suitable for the intended use.

Always carry out a visual and functional inspection of the items
before use. In case you have any doubt as to the proper
functioning and safety of the items, do not use them.

Load safety information

The maximum permitted working load of the Z5038 Fixing plate
M10 is 2.5 kg (5.5 lb) (according to BGV C1).

1.3. Intended use

The d&b Z5038 Fixing plate M10 must only be used in
conjunction with applicable d&b loudspeakers.

It can be mounted directly to walls, ceilings or other suitable
surfaces.

NOTICE!

Only use mounting parts (fixing anchors and screws) that are
suitable for the intended application.

An additional 12 mm (0.47") hole is provided on the fixing plate
as a feed-through for the connection cable.

A corresponding fixing template is supplied with these mounting
instructions. Refer to Þ Chapter 1.4. "Fixing template"
on page 4.

d&b Z5038 Fixing plate M10, Mounting instructions (1.0 EN) 3

Fig. 2: Application examples:

E4 wall mounted
E5 ceiling mounted

Application

The M10 bolt of the fixing plate allows the relevant loudspeaker to
be connected to different d&b mounting accessories.

Note: Refer to the specific mounting instructions for assembly
and operation of these accessories.

1.4. Fixing template

Note: Mind your printer settings and scaling.

d&b Z5038 Fixing plate M10, Mounting instructions (1.0 EN)4

2. Declarations

2.1. Manufacturer's declaration

This declaration covers:

– d&b Z5038, Fixing plate M10.

National standards and technical specifications
applied:

DIN 18 800, DIN 1055, BGV C1, BGI 810-3.

Backnang, 2011-06-22

Frank Bothe,
Managing Director
d&b audiotechnik GmbH

2.2. Disposal

Please dispose of this product according to the respective national
regulations.

Ensure that damaged rigging components are disposed of in a
way that they cannot be used again.

d&b Z5038 Fixing plate M10, Mounting instructions (1.0 EN) 5

D2963.EN.01, 06/2011 © d&b audiotechnik GmbH
