Z5024
Loudspeaker stand adapter
Mounting instructions
(5.0E)
WARNING!
This refers to a potentially dangerous situation
which may lead to personal injury.
This refers to a potentially dangerous situation
which may lead to damage to the equipment.
This refers to a situation which may cause the
CAUTION!
References in the manual
IMPORTANT!
equipment to malfunction.
Symbols on the equipment
Please refer to the information in the operating
manual.
General Information
Mounting instructions
Z5024 Loudspeaker stand adapter
Version 5.0E, 11/2003, D2908.E.05
©
by d&b audiotechnik AG 2003; all rights reserved.
The information contained in this manual has been carefully
checked for accuracy, at the time of going to press, however no
guarantee is given with respect to the correctness.
d&b audiotechnik AG accepts no responsibility for any errors or
inaccuracies that may appear in this manual or the products and
software described in it.
Technical specifications, dimensions, weights and properties do not
represent guaranteed qualities.
As manufacterers we reserve the right to make alterations and
modifications within the framework of legal provisions, as well as
changes aimed at improving quality.
d&b audiotechnik AG
Eugen-Adolff-Strasse 134, D-71522 Backnang, Germany
Telephone +49-7191-9669-0, Fax +49-7191-95 00 00
E-mail: docadmin@dbaudio.com, Internet: www.dbaudio.com
Z5024 Mounting instructions
Z5024 Loudspeaker stand adapter
The adapter must never be used to suspend a
The handbolt fitted to the adapter is not intended to
fully secure the adapter to the stand column - it is
when flying or fixing loudspeaker loads overhead.
The maximum permitted safe working load (SWL) for
Additionally, the load force must only act vertically on
Also ensure that the maximum permitted safe
working load (SWL) for the loudspeaker stand used
with the adapter is not exceeded.
This adapter is used to mount loudspeakers on to the standard
35 mm diameter column commonly used for loudspeaker stands.
−
Direct assembly to E1 or E3 loudspeakers
−
Direct assembly to 2 x E3 using Z5031 E3 Standard bracket
−
Z5023 02 Flying bracket
−
Z0124 E1 Vertical bracket
−
Z0126 E1 Horizontal bracket
−
Z5032 E3 Swivel bracket
−
Z5028 E3/Ci80 Horizontal bracket
−
Z5030 E3 x 2 Angle bracket
−
Z5052 Flying bracket CI6/CI9
−
Z5150 Q Swivel bracket
Safety instructions
WARNING!
WARNING!
Installation should only be carried out by fully
trained personel. There are certain rules for
installation that must be complied with.
loudspeaker cabinet.
provided only to lock the loudspeaker cabinet to a set
horizontal angle and prevent it from turning.
Secondary safeties must always be provided and used
Load safety information
this adapter is 40 kg and this value must on no
account ever be exceeded.
the fixing plate - any type of shear load must be
avoided.
(5.0E) Page 3 of 6
Z5024 Mounting instructions
Part list Z5024 Loudspeaker stand adapter
[2]
[1]
[3]
[4]
[5]
−
Weight Z5024 Loudspeaker stand adapter
washers
[2]
Fitting the adapter using the hex head
screw [3] spring [4] and plain [5]
1 x Z5024 Adapter für Boxenstativ
−
3 x Fixing bolt M8x30
−
2 x Hex head screw DIN 933-M8x18-8.8
−
2 x Spring washer 8.2
−
2 x Plain washer 8.4
[2]
[4]
[5]
[1]
[3]
0.6 kg/1.3 lb
Assembly
Each adapter is supplied with two M8x18mm hex head screws
spring
[4]
and plain
[5]
washers. The adapter is either fitted to the
[3]
accessories described above or directly fitted to E1 or E3
loudspeakers.
Fixing screws longer than those supplied must not be used. Longer
screws can punch in the E1 or E3 threaded inserts and breach the
cabinet’s air-tight seal. The adapter may also be fitted using two M8
Safety eyebolts (Q9031).
Alternatively the adapter can be fittet using the two fixing bolts
In this case the spring
[4]
and plain
[5]
washers are not used.
[2]
,
.
Fitting the adapter using the
fixing bolt [2]
Rigging examples
Operation
The horizontal angle can be set by slakening the fixing bolt
After horizontal alignment retighten the fixing screw
[2]
[2]
.
.
(5.0E) Page 4 of 6
Z5024 Mounting instructions
Z5024 dimensions in mm
16
9
36
40
170
40
115
100
20
4
M8
(5.0E) Page 5 of 6
Z5024 Mounting instructions
Declaration of Conformity to BGV C1
Z5024 Loudspeaker stand adapter
Z5024 Loudspeaker stand adapter
We hereby declare that the above listed product(s)
This declaration applies to the following component(s) of the d&b
Rigging Accessories:
supplied by d&b audiotechnik AG comply with the
relevant requirements of BGV C1(GUV 6.15).
d&b audiotechnik AG, Eugen-Adolff-Str. 134, D-71522 Backnang, Germany, Phone +49-7191-9669-0, Fax +49-7191-95 00 00
(5.0E) Page 6 of 6
