DaytonAudio WAVE-LINK WLRX User Manual

WAVE-LINK WLRX

2.4 GHZ EXPANSION
RECEIVER

Model: WAVE-LINK WLRX User Manual

Introduction

Installation of a subwoofer or second audio zone can be next to
impossible in a finished home. Lack of access from below or above the
room limits your ability to run the required cables from the A/V receiver
to your subwoofer or speakers.

The Dayton Audio Wave-Link™ WLRX 2.4 GHz Expansion Receiver
lets you introduce an additional wireless audio zone into your Wave­Link WLS System.

NOTE: A Wave-Link WLS Wireless System is required to use this receiver.
*5 receivers can be used with one transmitter.

The stereo capability of the Dayton Audio Wave-Link Wireless Audio
System extends the options and uses of your primary audio system.
Use the Wave-Link to add speakers to your patio, around your pool, or
anywhere you’d like to enjoy music. Connect the Wave-Link to your PC
and stream music from an Internet source or your music library to your
main audio system.

Connection

The Dayton Audio Wave-Link WLRX Wireless Audio Receiver includes all
of the accessories you need for monaural or stereo installations. The 3.5
mm to RCA cable is used for mono applications such as connecting a
subwoofer. The 3.5 mm to dual RCA cable is used for stereo applications
such as adding rear speakers to your home theater system.

System Includes

• 1 x Receiver

• 1 x 3.5 mm to single RCA

• 1 x 3.5 mm to dual RCA

• 1 x 3.5 mm to 3.5 mm cable

• 1 x 5 VDC power adapter

Operation

Start by powering your receiver. To do so, connect a USB power
adapter to the receiver. Plug the USB power adapter into a 120 VAC
outlet. Now, press the pair button on the top of the WLRX receiver unit.
When unit has a steady blue light, it is paired.

Connect your cable to the line input of your subwoofer, powered
speakers, or remote amplifier, and the 3.5 mm plug into the receiver
line output.
