Rickshaw Deluxe
User Manual
About Daymak
Daymak, a Toronto-based company, incorporated in 2002, is a leading developer and
distributor of personal light electric vehicles. Daymak’s goal is to reduce the carbon footprint one electric vehicle at a time! Please visit www.daymak.com for more information.
Our electric bicycles represent an energy-e cient and eco-friendly alternative for people
who need to get around the city. They greatly increase the practicality of bicycle transportation in urban centres. Costing only a few cents to charge, an e-bike can make city life
more convenient and much less expensive.
While there are many new Green technologies that are still in their infancy, electric bicycles
have been developing over the last 40 years or more. E-bike technology has been dramatically re ned since the introduction of the rst custom-conversion bicycles. Today, electric
bicycles are a supremely reliable and a ordable means of transportation.
Daymak is constantly developing new eco-friendly alternative transportation strategies,
led by its own Research and Development department in Toronto, Canada. We are always
improving our products. Our innovative in-house engineering and quality testing provide
customers with many new kinds of reliable, eco-friendly vehicles, designed to help change
the lives of our customers and the world.
Daymak warranties, services, and stocks parts for everything it sells.
We support our products.
Table of Contents
Introduction......................................................................................................................................................4
Scooter Diagram .............................................................................................................................................5
Riding Instructions .........................................................................................................................................6
Operating Instructions ...............................................................................................................................10
The Battery .....................................................................................................................................................12
Technical Data ...............................................................................................................................................17
Maintenance and Troubleshooting .......................................................................................................20
E-Bikes and Canadian Law ........................................................................................................................25
TPS Training Bulletin.....................................................................................................................................27
Introduction
Electric Mobility Scooter
Riding an electric mobility scooter is a great way to hop around town conveniently and
cheaply. Electric mobility scooters represent a natural progression in the development of
urban transportation.
Using only small amounts of electricity, electric scooters have the potential to radically
reduce the amount of pollution in our cities. As well, they are very quiet, so they do not
add to the high levels of noise pollution which we often take for granted. They are easy,
and usually free to park. They are unobtrusive and highly practical additions to the urban
landscape.
Electric scooters are also inexpensive. They (currently) require no registration, no insurance, no licence and do not incur parking charges. As well, compared to internal combustion engines, the engines in electric vehicles have fewer moving parts and require far less
maintenance.
Your Daymak product is the result of Daymak’s years of experience, the highly trained technical skills of our sta and careful, ongoing design work by our engineers. We hope you
enjoy using this product and welcome any feedback that you may have.
Liability
Daymak does not assume any liability for damages, loss of pro ts, or claims from third
parties due to improper use of this product. Daymak does not assume any liability for damages due to problems with the product resulting from service by a third party that is not
certi ed by Daymak.
The information in this guide may be subject to change without notice. For the latest information available, please contact your local Daymak dealer or visit our website.
We have taken all possible measures to ensure the accuracy and completeness of the information in this guide. However, if you do nd anything missing, incomplete or wrong, do
not hesitate to contact us.
4
Bicycle Part Diagrams
Diagram 1: The Rickshaw Deluxe Electric Mobility Scooter
This diagram illustrates the various parts of your vehicle. Please note that many of these parts are not user-serviceable and should be repaired only by trained professionals. This is especially true of the electrical
systems and the mechanical components.
1
17
14
19
15
16
18
3
6
4
1. Seat
2. Taillight
3. Rear Bumper
4. Rear Wheel
5. Charger port
6. Hub Motor
7. Controller (inside)
2
8
13
5
7
9
8. Front Fender
9. Battery (inside)
10. Front Brake Caliper
11. Front Shock Absorber
11
10
12
15. Brake Lever
16. On / Off key switch
17. Mirrors
18. Front Turn Signal Lights
12. Wheel Rims
13. Tire
14. Front Light
5
Riding Instructions
This guide assumes that you already know how to ride a standard mobility scooter. Before
you try to ride an electric mobility scooter, you should be very familiar with controlling a
mobility scooter.
Important Notes
• This electric mobility scooter is capable of traveling at higher speeds than many
bicycle riders are accustomed to. Use caution at all times, especially when travel
ling in mixed tra c. Always take into account driving and traveling conditions.
• Obey the Law. Be sure to follow all provincial and city traffi c laws. This includes
obeying stop signs, checking carefully when turning, and riding defensively. An
e-bike is a motorized vehicle, even though it is classed as a bicycle. You must fol low the law.
• Stay Sober. Never ride your bicycle while intoxicated. An e-bike is capable of trav-
eling faster than a normal bicycle, and you should always be in control of it.
• Share the Road. Be careful in mixed traffi c. When on bicycle paths, traveling near
pedestrians, or on recreational trails, try to be polite and courteous to those using
the paths with you. E-bikes are new in most cities, so other users of the roads and
recreational paths may not know how to deal with e-bike riders. Bear in mind that,
in a sense, e-bike riders are “ambassadors” for this new method of transportation.
Items to Carry with the Electric Bike
It is a good idea to carry the following items with you at all times when you ride your mobility scooter.
• The charger, to charge the bike in case the battery power runs out
• 30 Amp Fuse, spares for the batteries, in case the fuses blow
• A helmet, if required by safety laws
6
Inspecting your Electric Scooter
Always inspect your mobility scooter before you ride it, to make sure its safety features are
operating properly. Many accidents can be avoided with routine inspections. Once you
are comfortable with your mobility scooter, you will be able to detect small changes in the
way it feels. If anything changes between uses, make sure to have it properly examined.
Also, be sure to listen for changes in the sounds your e-bike makes over time. Any mechanical or power issues may have e ects on the sounds the bicycle makes.
Holding the Handlebars
As with a normal bicycle or gas scooter, place your ngers over the brake levers, using the
palms of your hand and your thumbs to wrap around and under the handlegrips. Doing
this allows you to activate the brakes easily, by squeezing your hand, in case you have to
stop quickly. This is the safe way to control your electric bicycle.
Turning your E-scooter On and Off
To turn on your scooter, insert the key into the “ignition”, located just below the dash
board, and turn the key to the right. When your scooter is activated, the power indicator
will light and the battery charge indicator will jump, showing you how much power your
e-bike has. To turn o the e-bike, simply turn the key to the left, and remove the key.
Warning
When you activate the e-scooter, the electrical system becomes live. Do not try to a ect
changes to the scooter (such as removing the battery or repairing electrical components)
while the scooter is activated. Turn the scooter o and remove the key before you attempt
to access any of the electrical components. Also, the battery carries a signi cant electric
charge and can injure people if not treated properly and with respect.
Accelerating and Decelerating
The throttle is found on the right-side hand grip on the handlebars. Turn the grip forward
(away from you) to accelerate. To decelerate, release the grip (turn it towards you). Don’t
over-rotate the accelerator, as this could damage the battery and electrical components.
Warning
Do not activate the accelerator until you are seated on the bicycle and are ready to accelerate. The scooter can easily escape from your control, possibly injuring you or others, and
the scooter may be damaged by being dropped.
7
Stopping
Your scooter has two sets of brakes, at the front and at the rear. The lever attached on the
right throttle grip activate the brakes. Pull the lever toward you to activate the brakes.
You can use both brakes to come to a stop more quickly, or you can use one of the brakes
to come to a gentle stop, depending on your riding needs at the moment.
When the brakes are activated, the power to the engine is automatically turned o , until
you release the brakes. This allows you to stop safely.
Safety Tips
• When you are traveling in wet weather, water may cause your brakes to function
less e ciently because it reduces friction between the brake pads and the wheels.
Take care to slow down and give yourself more room to stop or slow if necessary.
• It is a good idea to have your brakes and brake pads checked regularly. The brake
pads will eventually wear down through friction, and after signi cant use will have
to be replaced.
Signalling
The Horn
The scooter has a horn. The horn button is on the left handlebar. Simply press it to activate
the horn.
Turning Signal Lights
Your scooter has turn signal lights. The turn signal activator is on the left handlebar. Push it
left or right to activate it to indicate that you are turning in the appropriate direction, and
press the middle of the button to turn it o . The turn signals also emit a noise, to ensure
that everyone knows you are turning. This turn signal cannot be disabled without also
disabling the visual signal.
Lights
The headlight and taillight are useful features when you are riding at night or in dark areas.
They radically improve your safety in mixed tra c. The switch is located on the left handlebar. The lights on your scooter consume some electricity. Keeping them on may reduce the
maximum distance you can travel on one charge by about 5 %.
8
Riding in Wet Weather
Your scooter is designed to function in wet conditions, such as when it is raining. However,
because the motor is on the rear wheel, it is easy to slip when moving at high speeds. If it
is very wet, be sure to avoid high speeds.
When you are traveling in wet weather, water may cause your brakes to function less ef ciently because it reduces friction between the brake pads and the wheels. Take care to
slow down and give yourself more room to stop or slow if necessary.
The Motor and Water
Your scooter is not designed to be immersed in water. Always ensure that the water level
does not go above the middle of the tire, to prevent water from getting inside the motor.
Water in the motor can cause short-circuits and may damage the electrical systems in your
scooter.
Riding in Cold Weather
Your scooter is designed to operate year-round. However, in very cold conditions or when
there is a lot of snow or slush on the ground, it is possible for the motor in the scooter to
get wet or for the brakes to function less e ciently, just as can happen in wet weather.
Below -10 degrees Celsius, the battery will not work as well as it would in warmer temperatures. While Lithium-Ion batteries perform better than Lead-Acid batteries in temperature
extremes, both will experience reduced performance in cold temperatures.
Also, riding the scooter in cold temperatures may require you to replace the battery sooner rather than later.
9
Operating Instructions
Opening the Seat Trunk
To open the seat trunk, insert the key into the lock on the left side of the e-bike just below
the seat. Turn it all the way to the right. The seat will fold and lift to reveal the compartment.
To close the seat trunk, make sure that there is nothing blocking the locking mechanism,
such as items you have placed in the storage compartment, and push the seat down with
force. You will hear a “click” sound when it is properly closed.
Parking and Locking your E-scooter
When you want to park your scooter for a short time, turn the key to the o position and
simply dismount the scooter. The scooter also has a steering lock mechanism when engaged in the lock position.
To lock the steering for the handlebars, turn the key to the o position in the ignition. Turn
the handlebars either to the left or right, then push the key while further turning to the left
most position, to the lock position. This locks the steering when parked.
To unlock the steering column, depress the key and twist clockwise.
10
Maximum Load
Do not exceed the maximum load capabilities of your scooter. You can nd the exact loading capacity listed in the technical speci cations in this guide.
If you exceed the maximum load, the performance of the scooter will su er.
Exceeding the maximum load of your scooter could cause damage to the shocks, to the
mechanism and, ultimately, even to the frame. It could also cause your motor to work too
aggressively, and it may burn out.
Disconnecting the Circuit Breaker*
When the circuit breaker is disconnected, all power from the battery to the scooter is
blocked. This is useful if you are going to store your scooter or if it is damaged and you
wish to bring it to be serviced.
Disable the circuit breaker using the following very simple procedure.
1. Open the seat compartment.
2. Find the circuit breaker switch (it should be very obvious).
3. Activate the switch. The power to the scooter will be disabled.
Long-Term Storage of your Scooter
If you are storing your scooter for a long period, disconnect the circuit breaker. This is a safer way to store the scooter, as it prevents accidental activation of the scooter and makes it
impossible to activate it even with the key. The circuit breaker is found by opening up the
battery case. It sits between the battery and the controller.
Please see the section titled “Your Battery” for instructions on battery maintenance while
your scooter is being stored.
*Your scooter may or may not have a circuit breaker. If it is not clearly visible in the seat compartment, it is likely that your bike does not
have a circuit breaker and thus this section does not apply.
11
The Battery
This section details what you need to know about the battery that powers your scooter
Always remember to treat your e-bike’s electrical systems with respect.
Battery Power
The dashboard has a battery charge indicator. When the scooter is activated, the needle
will jump and indicate the currently available battery power.
If the power has dropped signi cantly, you should charge your scooter.
Distance and Power
Your battery has the capacity to carry you anywhere from 35 to 50 km before it must be
recharged. The ability of your battery to power your bicycle depends on many variables.
These variables include the weight of the rider, the prevailing wind resistance, the rider’s
driving habits, the presence of steep hills and inclines, and other issues such as proper air
pressure in the tires.
Saving Power
If you are traveling long distances, you can save a lot of electricity by using better driving
habits:
• Coasting: When going downhill or over long, at road surfaces, try using your e-
bike’s momentum and allow it to coast, without drawing power from the motor.
• Stopping and Starting: Try to avoid stop and go movements. The motor draws
more power when starting from a full stop.
• Weight: Remove unnecessary weight from the bike. This reduces the amount of
power the motor must draw.
• Air Pressure: Make sure your tires have the proper air pressure. Proper pressure
reduces drag on the tires and radically increases the e ciency of any vehicle.
• Head and Tail Lights: Turn o the lights to conserve power, if it is safe to do so.
The lights will reduce the distance you can travel by about 5%.
12
Charging your E-Bike
Charging your e-bike is a simple process. You require the following:
• The charger that came with your e-bike.
• A 110V household electrical outlet.
Charger Warning
Only use the chargers that were supplied with your scooter. Using chargers that do not
have speci cations identical to those which came with the e-bike could irreparably damage your scooter’s battery and electrical systems, and may cause injury.
To charge your e-bike, follow these steps:
1. Turn o the scooter and remove the key from the “ignition.”
2. Plug the female end of the charger cable into the charging slot on the scooter.
This is found on the outside casing of the scooter, in front of and just underneath
the seat.
3. Plug the male end of the charger power cable into your wall socket. This should
be a110v household electricity supply. You can also use a portable generator, if
necessary, but make sure it provides 110V current.
4. Allow the scooter’s battery to charge for the appropriate amount of time (6-12
hours).
5. Disconnect the charger when the LED light on the charger is green. The batteries
have been fully charged.
If your charger’s LED status light does not change from red to green over an extended
period of time, for perhaps more than 14 hours, and the battery is very hot, the battery or
charger may need replacing. Stop charging and bring both to your Daymak dealer immediately. Do not charge the battery.
13
Battery Care
Follow these suggestions to maintain your battery’s optimal performance. If you do not
follow these suggestions, your battery may lose its ability to maintain a charge and might
have to be replaced sooner than would otherwise be necessary.
• Charge it: Charge your battery immediately after riding it.
• Full Charge: Do not allow the battery to run down completely and lie in storage
without a charge. This signi cantly reduces the battery’s lifespan and may cause
damage.
• Keep it Charged: When being stored, charge the battery occasionally to make sure
its power supply does not run down. Charging it once every 21 days should be
su cient.
• Storage Conditions: Store the battery on a at, cool, dry surface. Do not allow the
battery temperature to drop below 10 degrees Celsius for extended periods of
time.
14
Cold Weather and your Battery
Below -10 degrees Celsius, the battery will not work as well as it would in warmer temperatures. While Lithium-Ion batteries perform better than Lead-Acid batteries in temperature
extremes, both will experience reduced performance in cold temperatures.
Also, repeatedly riding the scooter in cold temperatures may cause your battery to have
to be replaced sooner.
Handling the Battery
The battery contains large amounts of electrical power. You must use caution and respect
when handling it. Not following these instructions can result in serious injury.
Warning
Follow these instructions closely. Use care when handling your battery.
• Always lift the battery with both hands, and carry it with care. Never drop the
battery. If the case is damaged, the contents may leak out.
• Never puncture or open the battery case. The contents are dangerous and may
cause injury. Do not touch the contents of a leaking battery. Seek help immediate ly.
• Do not touch the two metal poles on the battery box at the same time. This can
cause a short-circuit. It could injure you or others and cause serious damage to
the electrical systems in the e-bike. Your battery contains signi cant amounts of
electrical power.
• Do not handle your battery if either you or the battery are wet. Water is an ex-
cellent conductor of electricity. You may experience an electrical shock, and you
may be injured.
15
Replacement and Disposal
After approximately 300 charges, a lead-acid battery will need to be replaced. A lithium-ion
battery will last approximately 1500 charges. When the battery has to be replaced, you will
notice that your battery cannot carry as much of a charge as it could initially.
Contact your local Daymak dealer to purchase a new battery.
When replacing your battery, dispose of it at a proper municipal battery recycling facility.
If none is available, please contact your local Daymak dealer.
Warning
Be absolutely sure that you replace the battery with an identical or
very similar battery. While it is possible to change the battery format or power levels, this
requires advanced knowledge of electrical systems. If improperly done, this can result in
immediate and irreparable damage to the electronic controller and electrical systems. Be
absolutely certain of what you are doing before you replace the
battery with a di erent type of battery.
Using the wrong type of battery will also void your warranty.
16
Technical Data
This section provides you with the technical speci cations for your e-bike.
The Motor and Wheel Assembly
The Scooter has a 500 Watt magnetic DC brushless motor on the rear wheel hub. This type of motor has ex-
cellent low-end torque and high effi ciency when working within its range. Note that while the motor is very
quiet, it does produce some noise. Also attached to the rear hub are speed reduction gear and the speed
free clutch.
The Freewheel
The wheels have freewheels, so the e-bike’s drive train is not xedly geared. This means that when coasting
or traveling downhill, you can turn o the engine and your e-bike will continue to move without slowing.
This feature will allow you to achieve faster speeds when coasting, moving downhill or moving with the
wind. It will also allow you to conserve electrical power, because you will be able to let to the motor rest
while moving.
The Controller
Daymak pioneered the development of intelligent component control in e-bikes. The “D- Drive” technology
developed by Daymak is the brain of your e-bike. It allows your e-bike to achieve faster acceleration, to climb
steeper hills, and to save energy. In future, it will allow for other ways of recharging your e-bike’s batteries,
such as by using solar or wind power.
The electronic controller is located under the seat assembly. This controller e ciently regulates the speed
and electronic functions of the bicycle. It allows for stepless speed adjustment, shuts o the motor when
the brakes are activated, has low voltage protection and has fuses to prevent excess current from damaging
the e-bike’s systems.
The Governor
A key component of the controller is the Governor. The Governor regulates the speed of the e-bike. It prevents the motor from assisting riders when the e-bike’s speed surpasses
32 km per hour.
The governor’s primary function is to make sure that the motor functions e ciently. If the governor is not
functioning, the mileage of the e-bike will be dramatically reduced, and its performance will su er.
Disabling the governor voids the warranty, and may damage your controller.
This speed limitation to 32 km per hour is required by government regulations. Traveling faster than 32 km
per hour through motor power alone is illegal in Canada and could result in serious nes or penalties, unless
your vehicle is insured for liability, is registered and you are licensed to drive.
17
The Brakes
Front & Rear Brakes
The brakes on your e-bike are Hydraulic-disc brakes. They generally provide for very ne stopping and control. This is a very tested and well-designed technology, but even so, the brakes will require servicing from
time to time, and may have to be adjusted for tension.
The brakes are contained within a sealed unit, and are very nely adjusted and tted.
The rear brakes are standard motor brakes.
Shock Absorbers
Your e-bike is equipped with Reverse Shock System shock absorbers. These e ective but simple devices
absorb the energy from bumps and dips, and allow you to have a much more comfortable ride. The Reverse
Shock System is superior to normal Monoshock shock absorbers usually found on e-bikes, and provides for
a much more comfortable ride.
While they are very resilient, please note that very sharp or large shocks, such as drops from a height of 15
cm or more, can cause serious damage to your shock absorbers. Replacing them is a complex and time-consuming task, so do be careful when dropping from larger heights.
18
Basic Statistics
Dimensions
Wheel Size: 3.0”x16”
Body Size: 152x71x104cm
Seat Height 75cm (29”)
Weight
100 kg without battery
110 kg with battery
Electrical System Statistics
Motor Statistics
Voltage: 24V
Working e ciency: 70-80%
Max. Climbing Angle: 12-15
Degrees
Charger Statistics
Charger Input: AC 100 – 240V
Standard Input voltage: 110V
+/- 10%
Charge Time: 6-12 hours
Loading Capacity
Standard: 75 kg
Maximum: 150 kg
Speed and Mileage
Max. Speed: 20 km/h
Max. Mileage: 40 km
Battery Statistics
Type: Lead Acid
Rated Voltage: 24V
Battery Life: 300 charges
Rated Total Capacity: 400Wh
Wiring Diagram
19
Maintenance and Troubleshooting
This section outlines problems you may have and solutions you may be able to use.
Many of the parts in this product are not user-serviceable and should be repaired by
trained professionals. This is especially true of the electrical systems and the mechanical
components. Alteration of these components voids the warranty.
Tire Pressure
Maintain the air pressure in your tires at the appropriate level. If the air pressure is too low,
your e-bike’s performance will su er and it will become damaged more easily.
Cold weather and lower temperatures will cause the air pressure in your tires to drop, and
warmer weather will cause it to increase, even if there are no leaks in the tire tube. To replace the air in your tires, follow this procedure:
1. Identify the required pressure by examining the text along the side of the tire
rim. This text should indicate the recommended pressure for your tire.
2. Locate the air valve on the inner surface of the tire rim.
3. Remove the valve cap and place in a secure location.
4. Place the nozzle end of an air pump (hand-power or mechanical) over the valve.
5. Pump up the air in the tire, being careful not to let the pressure go above the
level prescribed on the side of the tire wall.
6. Remove the pump nozzle from the air valve without allowing much air to escape
from the tire.
7. Replace the valve cap on the air valve.
20
Maintaining the proper air pressure will allow you to travel much further on a single charge,
because the motor will not have to work as hard to move the e-bike.
Replacing Flat Tires
Replacing at tire tubes is a more complicated and labour-intensive process with e-bikes
than it is with regular bicycles. It requires proper tools, more skill and more patience.The
front wheel is easier to service when changing a at tire than the rear wheel, as the rear
wheel is connected to the hub motor and other mechanical parts.
Unless you are very familiar with the mechanical components of the rear motor, attempting to change a at rear tire may cause serious problems. Please contact your Daymak
dealer for speci c instructions on how to remove your wheel and tires safely, and how to
replace the tubes.
It may be easier – and safer - to have the tubes replaced by your Daymak dealer.
The Brakes
The drum brakes on your Scooter allow you to stop and are a critical safety feature. Make
sure you test them regularly. Take the e-bike to your Daymak dealer if the brakes appear
to be losing their stopping power or feel looser than they were previously.
The brakes on your scooter may require servicing from time to time. The brake pads will
need to be replaced as they wear down, usually after about a year to a year and a half or
so, depending on how the e-bike is ridden. Also, the brake cables may have to be adjusted
for tension.
You can only service the brakes yourself if you have extensive experience servicing drum
brakes. Please do not attempt to service the drum brakes if you are not absolutely sure
how to do it.
Adjusting the Brake Cable Tension
From time to time, you may need to adjust the brake cable tension, to loosen or tighten
the drum brakes.
On your drum brakes, a small wing nut rides up and down a threaded bolt, moving the
brake cable and tightening or loosening the brake pads.
Just outside the casing, near the drum brake, the brake cable joins the drum brake. A
small wing nut allows you to adjust the tension.
1. Locate the wing nut on the drum brake.
2. To tighten the brakes, turn the wing nut clockwise.
3. To loosen the brakes, turn the wing nut counter-clockwise.
4. Adjust the tension until the drum brakes are tight enough to provide for proper
safety but are loose enough to allow the wheel to move freely when the brake is
not engaged.
Warning
Your brakes are a critical safety feature. Do not excessively loosen the drum brakes. If you
do not keep them su ciently tight, your drum brakes will fail and your scooter will not be
able to stop properly.
*Your scooter or e-bike may or may not have drum brakes and as such do not have the same
confi guration for servicing.
21
The Motor
Do not service the motor yourself. Bring the e-bike to your Daymak dealer for service. The
motor in your e-bike is a highly complex and ne-tuned mechanism. Repairing it requires
signi cant expertise.
We suggest maintenance every 100 running hours or so.
Shock Absorbers and Comfort
If your riding experience feels bumpier than usual, and you suspect that your shock absorbers are experiencing di culties, check the air pressure in your tires. If the air pressure
is too low, this may be the reason you feel less comfortable. It may have nothing to do with
your shock absorbers.
If the problem persists, take your e-bike to your Daymak dealer for servicing.
Bringing in your E-scooter for Service
Do not attempt to service the electronic or mechanical parts of your e-bike unless you are
absolutely sure of what you are doing and have a solid understanding of electrical and
mechanical equipment.
If your e-bike is not performing properly, disconnect the circuit breaker and bring the
e-bike to your local Daymak dealer.
Do not store the e-bike without disconnecting the circuit breaker.
Liability
Daymak will not be held responsible for damage or injuries resulting from errors resulting
from improperly serviced parts.
22
Ebike Maintenance
Cleaning
Cleaning is extremely important this will ensure your scooter will serve you for a long
time. In the long run, it will save you money and a lot of time waiting for the bike to be
repaired. You should clean your scooter weekly.
Do not use aggressive power jets or water sprays when washing the ebike and keep water
o the battery as much as you can. Clean gently but thoroughly and make sure that all the
outer casing of the electric parts are dry and clean.
Remove any dirt, debris, sand, mud, grit, grime that got caught on the bike and dry it o .
While cleaning, it is a good opportunity to look closely for a worn, loose, cracked, rust,
teared or damaged parts. Buckled paint can also be a hint for some parts that need closer
inspection.
Lubricating
It is also recommended to lubricate the chain, levers, derailleur, cables, etc. A clean, lubricated scooter tends to be faster, smoother and quieter. It’s like having a little extra push
for free.
Apply the lubricant to the di erent parts and let it sit a few minutes and then wipe o
the excess lubricant with a rag. After a while, clean the di erent parts with a degreaser to
remove any excess dirt that has been collected.
Weather
Don’t leave the scooter out in the rain or snow.
Store it somewhere dry and out of direct sunlight. Overheating the batteries, for example,
can cause problems.
Do not open up casings, chargers, etc as you are unlikely to be able to reseal them effectively afterward, making them more susceptible to water damage and other extreme
weather conditions.
Batteries should be removed from the ebike if not used and charged once a month regardless of usage.
23
Schedule
The frequency of maintenance depends on how much you ride and under which conditions. Recreational
riders needs far less maintenance then o -road riders. The harder you ride, the more you have to take care of
your bike if you want it to last. There are various time intervals for proper maintenance. Quick maintenance
should be done before & after every ride.
Time after purchase Action Suggested
Everytime before
you ride
The 60 second check
30 days
(every month)
90 days
(every 3 months)
Check tire pressure, check brakes that they work,
check lights, check bolts ( make s ure everything is
tight), check battery gauge. Do not ride the ebike
unless everything is functional and proper.
Completely clean the bike, including the dust on the
motor and under the seat. Check for any abnormal
wear and tear or alignment problems.
Inspect frame and fork for paint cracks or bulges that
may indicate frame or part damage; pay particular
attention to all frame j oints. Check wear and tear on
tires. Check range of battery.
180 days
(every 6 months)
360 days
(every 12 months)
24
Inspect all components of the ebike. Check that
connections are nice and tight. Look inside where you
controller is and clean i n detail. Check that all p lugs.
Go over every bolt and nut in your ebike.
Bring ebike for complete tune-up. Varying on the
ebike the ebike shop should complete a battery
discharge, tires s hould be changed depending on
wear and tear. All connections should be checked for
rust and looseness. All components should be
checked including charger, ignition and gauges.
Ebikes and Canadian Law
British Columbia, Alberta, Saskatchewan, Manitoba, Quebec, Nova Scotia,
Newfoundland and Labrador, Yukon
Currently, eight Canadian jurisdictions (British Columbia, Alberta, Saskatchewan, Manitoba, Quebec, Nova
Scotia, Newfoundland and Labrador and Yukon Territory) have legalized power-assisted bicycles for public
road use and are treating these vehicles as conventional bicycles and not as motor vehicles. As such, they
do not require insurance, registration or licences. E-bike technical speci cations must fall within certain
parameters, however,
The rules are similar in every province, with minor variations, and are not considered controversial. Consult
your local ministry or department of transportation for guidelines.
New Ontario Regulations
Ontario is currently running a pilot program to determine whether or not e-bikes should be allowed on
Ontario roads and under what conditions. The pilot program ends in 2009, at which point decisions will be
made as to the future of e-bikes on Ontario roads. Because the program in Ontario is new, and the rules are
often unfamiliar even to law enforcement o cials, we have included a synopsis of the regulations here.
These rules are very similar to the rules currently in place in other Canadian provinces. Print the “TPS Training Bulletin” at the end of this manual and keep it with you when you
are traveling. If you are stopped by tra c authorities who are unfamiliar with e-bikes or the regulations
concerning them, show them this bulletin. They should allow you to continue.
Defi nition of an E-bike
An e-bike is a bicycle with an added battery powered electric motor that does not exceed 500 watts and
can assist the cyclist up to a speed of 32 km/h. It can also be driven like a bicycle without any power assist.
The addition of the power assist enables the rider to pedal with less e ort, to achieve a greater distance, to
climb hills and ride against the wind more easily. In its size, weight, speed and the driving skills required,
the e-bike is similar to the conventional bicycle. A power-assisted bicycle is the same as an e-bike. An
e-bike is considered a power- assisted bicycle as long as it meets all the requirements of the Motor Vehicle
Safety Act.
Traveling by E-bike
Power-assisted bicycles will be able to travel anywhere a bicycle travels. They will be permitted on trails
and paths where municipal by-laws permit bicycles. Power-assisted bicycles, like bicycles, are not allowed
on controlled-access highways such as the 400 series highways, the Queen Elizabeth Way, the Queensway
in Ottawa or the Kitchener- Waterloo Expressway, or on municipal roads, including sidewalks where bicycles are banned under municipal by-laws.
Who Can Ride an E-bike
Anyone who is 16 years of age or older and wears an approved bicycle helmet at all times while operating
an e-bike can ride one.
25
Specifi c Riding Requirements
Power-assisted bicycles are treated as bicycles. This means:
• No driver’s licence is required
• No written test is required
• No vehicle registration or license plate is required
• No motor vehicle liability insurance is required
• Operators must be 16 years of age and older
• All persons are required to wear an approved bicycle helmet
• Only electric bicycles that conform to the federal Motor Vehicle Safety Act regula-
tions and are labelled as a “power-assisted bicycle” are eligible for the pilot program.
Equipment
A power-assisted bicycle (e-bike):
• Has steering handlebars and is equipped with pedals
• Is designed to be propelled primarily by muscular power and to travel on not
more than three wheels
• Has a motor that has a power output rating of 500W or less. The motor is electric,
and is incapable of propelling the cycle at speed of 32km/h or greater on level
ground, without pedaling.
• It must bear label indicating that it is a “Power-Assisted Bicycle.”
Safety Equipment
Power-assisted bicycles will require the same safety equipment as bicycles under the
Highway Tra c Act:
• Proper lights
• Proper brakes
• Proper bell
Bicycle Helmets
Anyone operating an e-bike will be required to wear an approved bicycle helmet. There will be no age exemptions.
Fines and Penalties
All the set nes established for violating rules of the road and equipment standards that apply to bicyclists
would apply to drivers of e-bikes. However, o ences directly related to the pilot program (i.e.; riding an
e-bike under the age of 16 or anyone riding an e-bike without a helmet) would be subject to the higher nes
set for pilot projects, ranging from
$250 to $2,500.
Drinking and Driving
Drinking and driving a motor vehicle is a Criminal Code o ence and charges are laid under the Criminal Code
of Canada. Under the Criminal Code, the de nition of a “motor vehicle” would include an e-bike and anyone
operating an e-bike intoxicated could be charged for impaired driving. If convicted, the o ender would be
subject to the Criminal Code penalties, including a ne or jail time, and a driving prohibition. However, under
this pilot regulation, an e-bike would not be a motor vehicle under the Highway Tra c Act, so penalties for
impaired driving under the Act would not apply.
26
TPS Training Bulletin
TPS Training Bulletin
Attention Tra c and Training Sergeants:
Recently we have had some enquiries from o cers in the eld and members of the public
regarding e-bikes and have found that there is some confusion over the de nition of a
Power Assisted Bicycle (e-bike).
According to Ontario Regulation 473/06, an e-bike that meets the de nition is deemed
not
to be a motor vehicle, under the Highway Tra c Act, and is essentially treated as a bicycle.
Any person 16 years and over who wears a bicycle helmet as required by subsection 104
(2.1) of the HTA may ride a power assisted bicycle on the highway. There is no
requirement for a drivers license, a permit or insurance.
The main requirements for a bicycle to be designated a “power assisted bicycle” is that it
“is capable of being propelled by muscular power” and a “bears a label that is permanently
a xed by the manufacturer stating that the vehicle is a power assisted bicycle”. Obviously
while the e-bike is being operated on the road, the pedals must be attached and functional.
O. Reg 473 refers to federal Motor Vehicle Safety Regulations for a de nition. Rick Line, TC
4365,
TPS Training & Education Unit, Tra c & Provincial Statutes Section, C.O. Bick College,
4620 Finch Ave. E., Scarborough, On, M1S-4G2
Ph: 416-808-4877
“Committed to Lifelong Learning”
27
Loading...
