Daymak Eagle User Manual

Eagle Manual Book

Protect the Environment Safeguard the Planet

Table of Contents

1. Electric vehicle component description and indicator function

2. Essentials of safety riding

3. Operation instruction & notice

4. Electric vehicle’s check, maintenance and quick-fix

5. Main specification and electric scheme

6. Malfunction & Troubleshooting

1. Electric ve hi cle components name and indicator function：

★ Each component name and its position
Figure 1

1-Back wheel 2- motor 3-rear lamp, rear turning lamp 4- rear st ock rack 5-controller 6- rear
shock absorber 7- seat 8- charger 9- battery 10- support 11- rearview mirror 12-

instrument 13- front lamp， front turning lamp 14- front box 15-front shock absorber
16- front wheel 17- motor number 18- frame number 19- charger plug 20- name plate 21- model

22- mark
★ Actuation device name its place

Figure 2
1- Rear braking bar 2- left handlebar 3- turning lamp switch 4- front lamp light variation

switch 5- horn switch 6- instrument 7- general electri c lock 8- general lamp switch 9­front braking bar 10- gearing turning bar
