these instructions on to the owner of this equipment.
the Installation Instructions provided in this manual. Please pass
knowledgeable in swimming pool plumbing requirements following
The installation of this product should be carried out by a person
INTRODUCTION
CARTRIDGE FILTERS
500, 750, 1000 & 1500
DAVEY EASY CLEAR
INSTALLATION AND OPERATION MANUAL
P/N 48521-6 supersedes P/N 48521-5
Website: daveynz.co.nz
Fax: 09 527 7654
Ph: 0800 654 333
Penrose, Auckland 1061
7 Rockridge Avenue,
Customer Service Centre
NEW ZEALAND
Website: davey.com.au
Fax: 1300 369 119
Ph: 1300 367 866
Scoresby, Australia 3179
6 Lakeview Drive,
Customer Service Centre
AUSTRALIA
They may also be found on our website.
* Installation and operating instructions are included with the product when purchased new.
© Davey Water Products Pty Ltd 2011.
® Davey & Easy Clear are registered trade marks of Davey Water Products Pty Ltd.
ABN 18 066 327 517
Member of the GUD Group
Davey Water Products Pty Ltd
For a complete list of Davey Dealers visit our website (davey.com.au) or call:
or phone the Davey Customer Service Centre on the number listed below.
Should your Davey product require repair or service after the guarantee period; contact your nearest Davey Dealer
to be of acceptable quality and the failure does not amount to a major failure.
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail
In Australia, you are entitled to a replacement or refund for a major failure and for compensation for any other
Australian or New Zealand Consumer Legislation.
or New Zealand legislation and does not affect any rights or remedies that may be available to you under the
of Davey for failure to comply with a consumer guarantee applicable to your Davey product under the Australian
any kind whatsoever arising directly or indirectly from Davey products. This limitation does not apply to any liability
Davey shall not be liable for any loss of prots or any consequential, indirect or special loss, damage or injury of
Davey Guarantee.
receipt as proof of purchase; you MUST provide evidence of the date of original purchase when claiming under the
Your Davey Guarantee does not cover freight or any other costs incurred in making a claim. Please retain your
connected to the voltage shown on the nameplate.
voltage spikes, or unauthorized persons attempting repairs. Where applicable, your Davey product must only be
operating instructions, failure to carry out maintenance, corrosive or abrasive water or other liquid, lightning or high
use for which the product was not designed or advertised, failure to properly follow the provided installation and
mechanical seals, bearings or capacitors), loss or damage resulting from misuse or negligent handling, improper
Your Davey Guarantee naturally does not cover normal wear or tear, replacement of product consumables (i.e.
defective, advise you on how to have your Davey product repaired, obtain a replacement or a refund.
listed below. On receipt of your claim, Davey will seek to resolve your difculties or, if the product is faulty or
line on 1300 367 866 in Australia, or 0800 654 333 in New Zealand, or send a written letter to Davey at the address
the Davey Dealer from which you purchased the Davey product. Alternatively you can phone our Customer Service
Should you experience any difculties with your Davey product, we suggest in the rst instance that you contact
– 2 –
Your Davey Cartridge Filter
Congratulations on your purchase of a quality product from the Davey range
of Pool and Spa Equipment. You are assured of many years of reliable and
efcient performance from your Davey Filter backed by Davey’s 5 year tank
guarantee.*
Davey Easy Clear™ Cartridge Filters have been specically designed for
the ltration of spa and swimming pool water. They should not be used for
any other purpose without rst consulting your Davey Dealer or Davey Cus-
tomer Service Centre.
Tank - Five Years Other Components - One Year
Davey Guarantee Period
Repair or Replacement Guarantee
®
– 3 –
Weather Protection
Davey Cartridge Filters are constructed of corrosion resistant materials.
However, to ensure years of reliable performance, it is recommended that
the ltration system is adequately protected from the weather.
Assembly
Assemble the pressure gauge to the lter lid using Teon tape on the male
thread. Do not over-tighten.
repair or replace it for you free of charge, subject to the conditions below.
periods beginning from the date of original purchase due to faulty materials or manufacture, Davey will at our option
In the unlikely event in Australia or New Zealand that this Davey product develops any malfunction within warranty
Davey
Davey Cartridge Filters provide economy, high performance and convenience in a well-designed pressure lter. The polyester element can be removed quickly for rinse cleaning without water loss. Davey Cartridge Filters
feature large lter areas which ensure even water distribution, peak ltration
performance and longer lter cycles.
The corrosion-resistant construction of Davey Cartridge Filters provides
long-life and durability. Davey Cartridge Filters are capacity matched with
Davey pool pumps forming a total pool ltration system that lasts and lasts.
Davey Cartridge Filters are also very suitable for use with other pool pumps.
Take care to match the pump and lter capacities to gain maximum performance and efciency.
The Sparkling Clear Water Difference
Cartridge ltration is an effective trouble-free proven method of ltration.
Pool water enters the lter and passes through a polyester element car-
tridge. Suspended particles are trapped and the water is returned to the
pool. As the build-up of dirt in the element increases, so the water pressure
rises and the ow decreases. When the pressure reaches an unacceptable
level, the element must be removed and cleaned. (Spray washing with a
common garden hose is generally sufcient).
* Refer to guarantee statement for full details
Installation and Operating Instructions Location
The lter should be placed in its permanent location, preferably as close to
the pool as practicable. Position the lter tank and pump on a level concrete
slab or similar base. Allow sufcient space around the lter for routine main-
tenance and provide for adequate ventilation and drainage.
Pipe Connections
Piping should be independently supported and not impose heavy loads on
the lter or pump. Use 40mm or 50mm pipe for pump and pool return lines.
50mm should always be used if length of piping is over 15m.
If the pump and lter are located below pool water level, it is necessary to
t isolating valves in the pipe between the pump and the pool, and in the
return line from the lter to the pool.
Barrel unions need to be hand tightened on. No sealant, glues or
silicones are required.
1. Pump to the Filter
Davey Cartridge Filters are equipped with two inlet ports marked ‘INLET’.
Select the inlet port most suitable for the installation and plug the other
inlet port with the blanking cap provided. Using quick connect couplings,
connect the pool pump delivery piping to the selected inlet port. Tighten by
hand only. Ensure the oring on the tting is clean, lubricated with oring lubricant and in the correct position.
2. Filter to Pool Return
Using quick connect couplings, connect the pool return piping to the lter
tting marked ‘OUTLET’. Tighten the tting by hand only. Ensure the oring
on the tting is clean, lubricated with oring lubricant and in the correct posi-
tion.
Place the pump in position on the slab and locate the lter alongside with
the appropriate pump inlet connection oriented towards the pump. Refer to
the specication section for the minimum clearance measurements required
for each model.
The lter base is provided with four mounting holes to enable it to be secured, if required.
– 4 –
– 5 –
Filter Operation
1. Make sure the pump is primed according to manufacturer’s directions.
2. Be sure all valves are open on suction and discharge lines. Ensure
the air bleed valve on the lter lid is open and the lid lock ring is in
place and secure.
3. Start the pump. Close the air bleed valve when water is expelled.
4. To determine the correct operating conditions with a clean lter, check
that the pressure gauge reading is 80kPa or below.
5. Record the pressure gauge reading or mark the needle position on
the face of the pressure gauge.
6. Operate the lter for a sufcient time to circulate the total pool water
volume daily. The lter should also be operated at all times the pool is
in use and for about one hour afterwards. During winter, the
running time may be reduced. Filter operating requirements will vary
for spa applications, depending upon the system design, type and
size of spa. Consult your builder or spa supplier.
7. When the pressure gauge reading is 50 - 70kPa higher than the
‘clean lter’ reading as in (4) above, it is time to clean the element/s.
(See “Cartridge cleaning procedure”)
Cartridge Cleaning Procedure
When the lter gauge reading is 50 - 70kPa above the clean lter gauge
reading, cleaning the element cartridge is required. To perform the cleaning
procedure :
1. Switch off the pump.
2. Close isolating valves on suction and discharge lines where tted.
3. Open the air bleed valve on the lter lid, unscrew the lock ring and
remove the lter lid.
4. Lift the element/s out.
5. In most cases the element can be easily cleaned with a garden hose,
using good velocity sprayed directly on the pleats.
NOTE:
Algae, calcium, clay, sun tan oil and body oils can form a coating on
the element which may not be easily removed with normal hosing.
These materials can be removed by soaking the element in a degreaser and/or de-scaler. Your local Davey Dealer will be able to
recommend suitable products.
Cartridge Re-Assembly Instructions
1. Install the cartridge/s & centre pipe so that it is located in the bottom
spigot.
2. Ensure the lter lid oring is clean, lubricated with oring lubricant and
located in the bottom groove of the lid.
3. Replace the lid and press rmly in place. Screw down the lock ring,
hand tight is sufcient - DO NOT OVERTIGHTEN.
4. Make sure the pump is primed according to manufacturer’s direc-
tions.
5. Ensure all valves are open on suction and discharge lines.
6. Start the pump.
7. Close the air bleed valve when water is expelled.
Water Quality
Maintaining balanced water chemistry is important to the life of your pool
pump. This pump is designed to be used with Pool & Spa water, balanced
in accordance with Langlier Saturation Index, with a pH level of between
7.2 and 7.8 and is regularly treated with a chlorine sanitising agent with the
level not exceeding 3000PPM.
Please consult your local pool shop regularly to have your water tested.
Filter Care
The Davey Cartridge Filter is the heart of the pool equipment installation.
Proper care and maintenance will add many years of service and enjoyment to your pool. Keep the exterior of the lter clean using a mild detergent and water.
Trouble Shooting
Reduced ow of water to the pool generally indicates the lter is ready to
be cleaned. Check the lter pressure gauge. (See section on ‘Filter Operation’). If cartridge cleaning is required, perform the steps described earlier in
‘Cartridge Cleaning Procedure’. If there is still reduced ow after cleaning,
check for blocked or plugged lines which could restrict the volume of water
entering the pool.
Dirt & debris returning to your pool may indicate the pressure relief
valve has been activated. Remove & clean the element and check
that valve inside base of lter is free of foreign matter.
Failure to undertake regular maintenance may cause damage not
covered by warranty.
– 6 –
Removal of the Filter
Danger HIGH PRESSURE. Relieve internal pressure before adjusting clamps
or opening lter.
Should it be necessary to remove the lter, the following procedure should
be followed :
1. Switch off the pump and remove the plug from the power point.
2. Open the air bleed valve on the lter lid.
3. Close isolating valves where tted.
4. Remove: – piping connection to the pump
– piping connection to the pool return
5. Remove lter.
In the event of installation or operation difculties with your Davey Filtration
Equipment, contact the supplier from whom the lter was purchased or your
nearest Authorised Davey Pool Equipment Service Centre. For assistance
in locating your nearest dealer contact the Davey Customer Service Centre.
– 7 –
WARNING! Pump suction is hazardous and can trap and drown or disembowel bathers. Do not block suction. Do not use or operate swimming
pools, spas or spa baths if a suction cover is broken, missing or loose.
Two suction covers and inlets must be provided into every pump to avoid
suction entrapment.
Specications
CLEARANCE TO REMOVE CARTRIDGE
NOTE: When making any enquiries about your Davey Filtration Equipment,
be certain to quote the Model Number from the nameplate on the equipment.
To avoid explosion and possible severe or fatal injury, lter pressure must
not exceed 280kPa. Do not test lter with compressed air. Check that all
clamps and fasteners are in good condition and are rmly secured before
pressurising system. Never adjust clamps or fasteners while lter is pres-
surised.
DANGER - Hazardous suction. Do not block water entry into ltration
system with any part of your body as the pressure can trap hair or body
parts, causing severe injury or death. Do not block suction. Turn off
pump immediately if someone becomes trapped.
Caution! Do not add chemicals directly to the pool skimmer. Adding undi-
luted chemicals may damage pump and lter and void warranty.
Small children using the pool or spa must ALWAYS have close adult supervision.
Routine Maintenance tasks – to maximise the life of your pool equipment & personal
safety, use this checklist once a week. Turn pump off rst.
a. Make sure that any pressure gauges are in working condition and the operating pres-
sure is within limits as specied on the product.
b. Make sure that each suction inlet, and main drain has a cover that is securely attached
and in safe working condition.
c. Make sure that all skimmer covers are securely attached and in safe working condition.
These should be replaced every 3 to 4 years.
d. Remove any obstructions or debris from the main drain cover.
e. Ensure the skimmer baskets and the pump hair and lint pots are free of leaves and de-
bris at least once a week.
f. Remove obstructions and combustibles from around the pump motor.
g. Make sure all wiring connections are clean and that all wiring and electrical equipment
is in good condition. Damaged wiring must be repaired or replaced by a qualied electri-
cian as soon as damage is discovered.
h. Check water balance and sanitiser levels at your local pool shop.
Technical Data
Max Max Filtration Filtration
Max Flow 6 Hour 8 Hour Operating Operating Area Area
Model Rate (lpm) Turnover Turnover Pressure Temp (sq metres) (sq feet)
(kPa) (°C)
EC 500 205 73,800 98,400 280 45 4.67 50
EC 750 270 97,200 129,600 280 45 7.08 75
EC 1000 340 122,400 163,200 280 45 9.43 100
EC 1500 450 162,000 216,000 280 45 14.16 150
Dimensions (mm)
Model A B C D
EC 500 270 60 540 875
EC 750 270 60 540 875
EC 1000 270 60 635 1000
EC 1500 270 60 820 1360
Loading...
