CsIII Cesium Frequency Standard
Features
Portable model with carrying case
• Accuracy <2.0E-12
• RS232 Monitoring & Control
• 5 & 10 MHz RF Outputs
• E1 & T1 Telecom Outputs
• 1 PPS Output / 1 PPS Sync Input
• Portable
smaller IS BETTER!
The CsIII is the world’s smallest
and most economical solution for any
application that requires the accuracy
and stability of a cesium instrument.
Housed in a 2U high, 19-inch rack mounted package and weighing in at just 28
pounds, the CsIII can be implemented in most any location.
DATUM CsIII TECHNOLOGY represents a leap
forward in terms of making cesium beam frequency standard
technology available to an ever-increasing base of demanding
users in communications, timing, synchronization and test and
measurement applications.
As a result of this advanced technology we are able to offer a
primary reference standard at a fraction of the price of currently
available products on the market today.
A “hands-off” approach to network timing is what
you get when you install a CsIII as your stratum 1 reference. You no longer need to
worry about the availability of GPS or the cost of installing and maintaining the required
infrastructure of a GPS-based system. The long life of the CsIII provides years of maintenance free operation while achieving exceptional stability and accuracy.
CESIUM PRODUCTS
Modules, Instruments, Militarized Instruments and Replacement Tubes
Applications
• Stratum 1 Primary Reference Source
• Calibration Standard
• Satellite Tracking Stations
• Master Reference For Broadcast Communications
• Positioning & Navigation
TEST & MEASUREMENT applications depend on the
versatility of the CsIII. As a house standard, there is no better
method for calibration of equipment. The CsIII can be optionally
configured with a portability kit that allows for easy transportation
to field based locations. The light-weight and muliple outputs of
the CsIII make it an ideal instrument for base station calibration.
Datum - TT&M will be there for you today and
tomorrow. Dependability is a unique intrinsic feature of all
Datum - TT&M products. Time and Frequency has been our
focus for thirty years and our enthusiasm and excitement has not
wavered. In today’s world of consolidations and ever changing
business conditions, long-term commitment is often overlooked.
When you implement a Datum-based time and frequency system,
you can count on state-of-the-art products and technical expertise
that will be there when you need it.
CsIII Cesium Frequency Standard
Specifications
CESIUM PRODUCTS
Modules, Instruments, Militarized Instruments and Replacement Tubes
Panel Indicators:
Power Green LED indicates there is power
to the instrument.
Lock Green LED indicates proper operation.
Major Alarm Red LED indicates improper operation.
AC Power Requirements:
Operating Voltage 85 to 265 V
Frequency Range 47 to 63 Hz
400 Hz
Power:
(operating) 110 VA, 65 W, 0.6A @ 115V
(warm-up) 140 VA, 90 W, 0.8A @ 115V
Dimensions:
Height 3.50” (88.9 mm)
Width (front panel) 19.00” (483 mm)
(instrument) 17.31” (440 mm)
Depth 15.0” (381 mm)
Weight ~28 lbs (13.0 kg)
Performance Perimeters: Standard Performance
Accuracy
1
<2.0E-12
Warm-up Time (typical) 30 minutes
Reproducibility <1.2E-12
Stability
Averaging Time(s) Allan Deviation
10
0
<1.2E-11
10
1
<8.5E-12
10
2
<2.7E-12
*10
3
<8.5E-13
*10
4
<2.7E-13
*10
5
<8.5E-14
*floor <5.0E-14
SSB Phase Noise Offset (Hz) 5 MHz
10
0
-106 dBc **
10
1
-135 dBc
10
2
-145 dBc
10
3
-155 dBc
10
4
-160 dBc
10
5
-160 dBc
Settability
Range ±1E-9
Resolution 1E-15
Control via RS232 port
1
100% verified & calibrated against Datum-Beverly in-house standard
*Excluding environmental effects
** With 10 second Tau loop
RF Output:
Frequency 1 each 5 MHz and 10 MHz
Amplitude 1 Vrms
Harmonic <-40 dBc
Spurious <-80 dBc
Connector type BNC
Load Impedance 50 ohms
Location rear panel
1 PPS Output / 1 PPS SYNC Input
Frequency One pulse per second
Amplitude/wave shape >3.0 V pk into 50 ohms
(TTL compatible)
Width 20 m s
Rise Time <5 ns
Jitter <1 ns rms
Connector type BNC
Location rear panel
Options and Modules Available
Datum 6502 RF Distribution, Datum 6602 Pulse Distribution
Datum 6705 Telecom Synthesizer
Transport Case, E1 output module, T1 output module
