ISSUED
06/08/16
TYPE
AEHHXU
PERFORMANCE DATA
3-PHASE INDUCTION MOTOR
NAMEPLATE INFORMATION
OUTPUT
HP KW
400 298 60
POLE
2
FRAME
SIZE
5009A
VOLTAGE
460
TYPICAL PERFORMANCE
FULL
LOAD
RPM
FULL LOAD
MIN. % NOM. %
EFFICIENCY
3/4 LOAD
%
1/2 LOAD
95.0
HZ
RATED
AMBIENT
40oC
%
INS.
CLASS
F
POWER FACTOR
F. L.
%
3/4 LOAD%1/2 LOAD
88.395.8 95.4 84.6
ENCLOSURE
CATALOG#
NEMA
DESIGN
B
%
87.7 84.6
TEXP
XP4002
TIME
RATING
CONT.
POWER FACTOR
CORRECTION
SERVICE
FACTOR
1.15
MAXIMUM
KVAR603574
NO LOAD
76 443
TORQUE
FULL LOAD
lb-ft
LOCKED
ROTOR
%FLT
81 100 90
SAFE STALL
TIME IN
SECONDS
COLD HOT
2 1
APPROVED:
CURRENTS
FULL LOAD
PULL
UP
%FLT
ALLOWABLE
STARTS
PER HOUR
COLD
M. PRATER
LOCKED ROTOR
2900
BREAK
DOWN
%FLT
ROTOR
WR
lb-ft
65.8
SOUND
PRESSURE
LEVEL @ 3 FT
HOT
1
DRAWING NO.
CODE LETTER
2
2
dB(A)
882
NEMA KVA
G
INERTIA
NEMA
LOAD
WK
lb-ft
314
2
2
MAX
ALLOWABLE
WK
lb-ft
2
2
314
31057XP4002
ACCEL TIME
NEMA
LOAD
WK
Sec
2
MAX
ALLOWABLE
WK
Sec
2
36.27200 36.27
REVISION
0
