Vent≧8φ×10L
SMD Aluminum Electrolytic Capacitors
Features
‧
4 ~ 18φ, 105℃, 3,000 ~ 5,000 hours assured
‧
Long life assured
‧
Designed for surface mounting on high density PC board
‧
RoHS Compliance
VEU
SPECIFICATIONS
Items Performance
Category Temperature Range
Capacitance Tolerance
Leakage Current (at 20℃)
Dissipation Factor Rated Voltage 6.3 10 16 25 35 50 63 80 100
(Tanδ at 120Hz, 20℃)
Low Temperature Rated Voltage 6.3 10 16 25 35 50 63 80 100
Characteristics (at 120Hz) Impedance
Ratio
Test Time
Endurance Capacitance Change Within ±30% of initial value
Dissipation Factor Less than 300% of specified value
Leakage Current Within specified value
Test Time 1,000 Hrs
Capacitance Change Within ±30% of initial value
Shelf Life Test Dissipation Factor Less than 300% of specified value
Leakage Current Within specified value
Ripple Current &
Frequency Multipliers
DIAGRAM OF DIMENSIONS
I = 0.01CV or 3 (µA) whichever is greater (after 2 minutes)
Where, C = rated capacitance in µF V = rated DC working voltage in V
* The above specifications shall be satisfied when the capacitors are restored to 20℃after the rated voltage applied for
3,000~5,000 hours at 105℃.
* The above specifications shall be satisfied when the capacitors are restored to 20℃after exposing them for 1,000
hours at 105℃ without voltage applied.
Frequency (Hz)
Tanδ(max)
Z(-25℃)/Z(+20℃)
Z(-55℃)/Z(+20℃)
Cap.(μF)
1,000 < C ≦ 1,500
0.30 0.24 0.20 0.16 0.13 0.12 0.09 0.08 0.07
Impedance ratio shall not exceed the values given in the table below.
Under 1,000 0.70 1.00 1.30 1.40
Fig. 1 LEAD SPACING AND DIAMETER Unit: mm
L
φD±
0.5
0.2
±
A
0.3 Max
B±0.2
C±0.2
0.4 max
W
P
Fig. 2
φD±0.5
Vent
B±0.2
1.0 Max
L
0.4 Max
A±0.2
P
C±0.2
W
-55℃ ~ +105℃
±20% (at 120Hz, 20℃)
4 3 2 2 2 2 2 2 2
10 7 5 3 3 3 3 3 3
3,000 Hrs for φD ≦ 10 mm;
5,000 Hrs for φD ≧ 12.5 mm
50 120 1k 10k up
0.85 1.00 1.13 1.15
φD
4 5.7 ± 0.3 4.3 4.3 5.1 0.5 ~ 0.8 1.0 1
5 5.7 ± 0.3 5.3 5.3 6.1 0.5 ~ 0.8 1.5 1
6.3 5.7 ± 0.3 6.6 6.6 7.4 0.5 ~ 0.8 2.0 1
6.3 7.7 ± 0.3 6.6 6.6 7.4 0.5 ~ 0.8 2.0 1
8 10 ± 0.5 8.4 8.4 9.2 0.7 ~ 1.1 3.1 1
10 10 ± 0.5 10.4 10.4 11.2 0.7 ~ 1.1 4.7 1
12.5 13.5 ± 0.5 13.0 13.0 15.0 1.1 ~ 1.4 4.4 2
12.5 16 ± 0.5 13.0 13.0 15.0 1.1 ~ 1.4 4.4 2
16 16.5 ± 0.5 17.0 17.0 19.0 1.1 ~ 1.4 6.4 2
18 16.5 ± 0.5 19.0 19.0 21.0 1.1 ~ 1.4 6.4 2
L A B C W
Marking color: Black
P ± 0.2
Fig. No.
2011 Verison
Page 2
mA
SMD Aluminum Electrolytic Capacitors
VEU
MARKING
φ
D ≦ 6.3mm
Negative
polarity
a1
10
16U
Date code
Rated cap.
Rated voltage
& Series code
φ
D = 8 ~ 10 mm
Negative
polarity
a1
VEU
470
6.3V
Date code
Series name
Rated cap
.
Rated voltage
φ
D ≧ 12.5mm
Negative
polarity
a1
VEU
1500
35V
Date
code
Series
name
Rated
cap.
Rated
voltage
Dimension: φD × L(mm)
DIMENSION & PERMISSIBLE RIPPLE CURRENT
V. DC
µF Contents
0.1 0R1
0.22 R22
0.33 R33
0.47 R47
1 010
2.2 2R2
3.3 3R3
4.7 4R7
10 100
22 220 4×5.7 22 4×5.7 30 5×5.7 30 6.3×5.7 44 6.3×5.7 44 6.3×7.7 58
33 330 5×5.7 35 5×5.7 35 6.3×5.7 48 6.3×5.7 50 6.3×7.7 57 8×10 130
47 470 5×5.7 38 6.3×5.7 50 6.3×5.7 50 6.3×7.7 63 8×10 92 8×10 141
100 101 6.3×5.7 69 6.3×7.7 81 6.3×7.7 81 8×10 116 10×10 151 10×10 310 12.5×13.5 220
150 151
220 221 6.3×7.7 120 8×10 141 8×10 141 10×10 290 10×10 320 12.5×13.5 280 12.5×16 320 16×16.5 410
330 331 8×10 290 10×10 290 10×10 290 10×10 320 12.5×13.5 320 12.5×16 360 16×16.5 450 16×16.5 510
470 471 10×10 320 10×10 320 10×10 320 12.5×16 410 16×16.5 510 16×16.5 540 18×16.5 650
1,000 102 10×10 410
1,500 152
V. DC
µF
Contents
68 680 12.5×13.5 180
100 101 12.5×16 240
150 151 16×16.5 340
220 221 16×16.5 410
330 331 18×16.5 540
6.3V (0J) 10V (1A) 16V (1C) 25V (1E) 35V (1V) 50V (1H) 63V (1J) 80V (1K)
φD×L
φD×L
mA
φD×L
4×5.7 1
4×5.7 2.6
4×5.7 3.2
4×5.7 5
4×5.7 8
4×5.7 12
4×5.7 17
4×5.7 16 5×5.7 22
4×5.7 18 5×5.7 27 5×5.7 27 6.3×5.7 32
12.5×13.5 240 12.5×16 290
18×16.5 900
100V (2A)
mA
mA
φD×L
16×16.5 690 18×16.5 780
mA
φD×L
φD×L
mA
Ripple Current: mA/rms at 120 Hz, 105°C
φD×L
mA
φD×L
mA
φD×L
mA
2011 Version
