SMD Aluminum Electrolytic Capacitors
VEH
Features
‧
4 ~ 10φ, 105℃, 2,000 hours assured
‧
Vertical chip type miniaturized
‧
Low impedance capacitors
‧
Designed for surface mounting on high density PC board
‧
RoHS Compliance
SPECIFICATIONS
Items
Category Temperature Range
Capacitance Tolerance
Leakage Current (at 20℃)
Dissipation Factor
(Tanδ at 120Hz, 20℃)
Low Temperature
Characteristics (at 120Hz) Impedance
Endurance
Shelf Life Test
Ripple Current &
Frequency Multipliers
DIAGRAM OF DIMENSIONS
LEAD SPACING AND DIAMETER Unit: mm
L
φD±
0.5
0.3 Max
I = 0.01CV or 3 (μA) whichever is greater (after 2 minutes)
Where, C = rated capacitance in μF V = rated DC working voltage in V
Rated Voltage
Capacitance Change
* The above specifications shall be satisfied when the capacitors are restored to 20℃after the rated voltage applied
for 2,000 hours at 105℃.
Capacitance Change
* The above specifications shall be satisfied when the capacitors are restored to 20℃after exposing them for 1,000
hours at 105℃ without voltage applied.
Tanδ(max)
Impedance ratio shall not exceed the values given in the table below.
Rated Voltage
Z(-25℃)/Z(+20℃)
Ratio Z(-55℃)/Z(+20℃)
Test Time 2,000 Hrs
Dissipation Factor Less than 200% of specified value
Leakage Current Within specified value
Test Time 1,000 Hrs
Dissipation Factor Less than 200% of specified value
Leakage Current Within specified value
Frequency (Hz) 50, 60 120 1k 10k up
Multiplier 0.64 0.8 0.93 1.0
6.3 10 16 25 35 50
0.30 0.26 0.22 0.16 0.13 0.13
B±0.2
0.4 max
0.2
±
A
W
P
C±0.2
MARKING
φ
D ≦ 6.3mm
Negative
polarity
a1
10
16h
Date code
Rated cap.
Rated voltage
& Series code
φ
D = 8 ~ 10 mm
Negative
polarity
a1
VEH
470
6.3V
Date code
Series name
Rated cap
.
Rated voltage
Performance
-55℃ ~ +105℃
± 20% (at 120Hz, 20℃)
6.3 10 16 25 35 50
4 3 2 2 2 2
10 7 5 3 3 3
Within ±25% of initial value for φD ≦ 6.3 mm;
Within ±20% of initial value for φD ≧ 8 mm
Within ±25% of initial value for φD ≦ 6.3 mm;
Within ±20% of initial value for φD ≧ 8 mm
φD
4 5.7 ± 0.3 4.3 4.3 5.1 0.5 ~ 0.8 1.0
5 5.7 ± 0.3 5.3 5.3 6.1 0.5 ~ 0.8 1.5
6.3 5.7 ± 0.3 6.6 6.6 7.4 0.5 ~ 0.8 2.0
8 10 ± 0.5 8.4 8.4 9.2 0.7 ~ 1.1 3.1
10 10 ± 0.5 10.4 10.4 11.2 0.7 ~ 1.1 4.7
10 10.3 ± 0.5 10.4 10.4 11.2 0.7 ~ 1.1 4.7
L A B C W
Marking color: Black
P ± 0.2
2011 Version
Page 2
SMD Aluminum Electrolytic Capacitors
VEH
Dimension: φD × L(mm)
Ripple Current: mA/rms at 100k Hz, 105°C
DIMENSION & PERMISSIBLE RIPPLE CURRENT
V. DC
µ
F Contents
3.3 3R3 4×5.7 5.0 30
4.7 4R7 4×5.7 3.2 65 4×5.7 3.2 65 4×5.7 5.0 30
10 100
22 220
33 330 4×5.7 3.2 65 5×5.7 1.5 110 6.3×5.7 0.85 170 6.3×5.7 0.85 170 6.3×5.7 0.85 170 8×10 0.6 300
47 470 5×5.7 1.5 110 6.3×5.7 0.85 170 6.3×5.7 0.85 170 6.3×5.7 0.85 170 8×10 0.45 450 8×10 0.6 300
100 101 6.3×5.7 0.85 170 6.3×5.7 0.85 170 8×10 0.45 450 8×10 0.45 450 8×10 0.45 450 8×10 0.6 300
150 151 6.3×5.7 0.85 170 6.3×5.7 0.85 170 8×10 0.45 450 8×10 0.45 450 8×10 0.45 450 10×10 0.3 500
220 221 6.3×5.7 0.85 170 8×10 0.45 450 8×10 0.45 450
330 331 8×10 0.45 450 8×10 0.45 450 8×10 0.45 450 10×10.3 0.25 670
470 471 8×10 0.45 450 8×10 0.45 450 10×10 0.25 670
820 821 10×10 0.25 670 10×10 0.25 670
1,000 102 10×10 0.25 670
6.3V (0J) 10V (1A) 16V (1C) 25V (1E) 35V (1V) 50V (1H)
φD×L
Imp. mA
4×5.7 3.2 65 5×5.7 1.5 110 5×5.7 1.5 110 5×5.7 3.0 50
4×5.7 3.2 65 5×5.7 1.5 110 6.3×5.7 0.85 170 6.3×5.7 0.85 170 6.3×5.7 2.0 70
φD×L
Imp. mA
φD×L
Imp. mA
φD×L
8×10
10×10
Impedance: Ω/ at 100k Hz, 20℃
Imp. mA
0.45
450
0.25
670
φD×L
10×10 0.25 670
Imp. mA
φD×L
Imp. mA
