Page 1
H
G
RoHS compliant
Unit:mm
F
E
D
C
B
A
5
USB 2.0 COMPLIANT
1 2 3
7
21
ANG.
Angle
TOL
±5°
DIM
TOL
X.XX
±0.2
X.X
±0.3
Scale
TOLERANCE
Free
4
Id.
2
3
4
5
Update
Add P/N with 30u" gold flash selective
Update
07.06.2013 Winnie
Update
19.08.2013 Winnie
Approved
3
Modification Date
4
Name
07.07.2009 Stefanie
Lucas
17.04.2012
7
6
Update dimension
Add wave solder information
16.05.2017
18.09.2013 Winnie
S.Bölling
Drawn
4
4
4
4
4
4
5 6
26.01.2005
18.09.2013
Date
A-USB A-E-30
WSW-P/N Contact Area plating
A-USB A-E 1u"Gold Flash Selective
7.PACKIING: Tray
4.4 Insulation Resistance:1000 MΩ Min
4.1 Current Rating:1.5A
4.2 Dielectric Strength:500V AC FOR 1 MINUTE
4.3 Contact Resistance:30mΩ Max
6
5.Operating temperature: -55°C TO +85°C
6.For wave soldering temperature : 235°C±5°C for 5±1sec
3.MECHANICAL:
Under: Ni Plated
3.1 Mating Force:3.57kgf Max.
3.2 Unmating Force:1.02kgf Min
3.3 Durability:1500 cycles Min
4.ELECTRICAL:
2. FINISH:
2.1 Contact Area: 1u"Au-flash/Selective
Solder Area:Tin Plated
1.2 Cover: PBT +30%GF UL94V-0,Color White
1.3 Shell: Brass
1.4 Contact :Phosphor Bronze
4
1.Material:
NOTES:
1.1 Housing: PBT+30%GF UL94V-0,Color White
Hellwig
ASSMANN WSW-No.
G
Name
Customer-No.
30u"Gold Flash Selective
LCP+30%GF
F
PBT+30%GF
Housing / Cover
E
D
30u"Au/Selective
C
LCP+30%GF UL94V-0,Color White
LCP+30%GF UL94V-0,Color White
B
A
7
Winnie
65
Replace
Drawing-No.
ASS 1413B CO
A-USB A-E
A-USB A-E-30
7
rev07
SHEET
3
