Datasheet UG-277 Datasheet (ANALOG DEVICES)

SDP User Guide

UG-277

One Technology Way • P. O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: [phone] • Fax: [phone] • www.analog.com

SDP-B Controller Board

INTRODUCTION

This user guide describes the EVAL-SDP-CB1Z system
demonstration platform—Blackfin® (SDP-B) controller board
from Analog Devices, Inc. The SDP-B controller board is part
of the Analog Devices system demonstration platform (SDP).
The SDP consists of a series of controller boards, interposer
boards, and daughter boards.

SDP controller boards provide a means of communicating with
the PC from the system under evaluation. Interposer boards
route signals between two connectors. Daughter boards are a
collection of product evaluation boards and Circuits from the
Lab™ reference circuit boards. The SDP-B is used as part of the
evaluation system for many Analog Devices components and
reference circuits. The primary audience for this user guide is a
system engineer who seeks to understand how to set up the
SDP-B board and begin USB communications to the PC.

The SDP-B board is designed to be used in conjunction with
various Analog Devices component evaluation boards and
Circuits from the Lab reference circuits as part of a customer
evaluation environment. The SDP-B provides USB connectivity
through a USB 2.0 high speed connection to the computer
allowing users to evaluate components on this platform from a
PC application. The SDP-B is based on ADSP-BF527 Blackfin
processor, with the Blackfin processor peripheral communi­cation lines available to the component daughter board through
two identical 120-pin small footprint connectors.

The SDP-B user guide provides instructions for installing the
SDP-B hardware (EVAL-SDP-CB1Z board) and software onto
your computer. The necessary installation files are provided
with the evaluation daughter board package. The Getting
Started section provides software and hardware installation
procedures, PC system requirements, and basic board informa­tion. The Hardware Description section provides information
on the E VAL-SDP-CB1Z components. The EVAL-SDP-CB1Z
schematics are provided in the Schematics section.

PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.

Rev. B | Page 1 of 24

UG-277 SDP User Guide

TABLE OF CONTENTS

Introduction ...................................................................................... 1

Revision History ............................................................................... 2

Product Overview ............................................................................. 3

Technical or Customer Support.................................................. 3

Product Information .................................................................... 3

Regulatory Compliance ............................................................... 3

Getting Started .................................................................................. 4

Package Contents .......................................................................... 4

PC Configuration ......................................................................... 4

REVISION HISTORY

12/11—Rev. A to Rev. B

Changes to Figure 7 ........................................................................ 14

Changes to Figure 8 ........................................................................ 15

Changes to Figure 9 ........................................................................ 16

Changes to Figure 10 ...................................................................... 17

Changes to Figure 11 ...................................................................... 18

Changes to Figure 12 ...................................................................... 19

Changes to Figure 13 ...................................................................... 20

10/11—Rev. 0 to Rev. A

Change to Product Overview Section ............................................ 3

Replaced Hardware Description Section ..................................... 15

Replaced Schematics Section ........................................................ 13

6/11—Revision 0: Initial Version

USB Installation .............................................................................4

Powering Up/Powering Down the SDP .....................................4

Hardware Description.......................................................................5

LEDs ................................................................................................5

Connector Details .........................................................................5

Power............................................................................................ 10

Daughter Board Design Guidelines ......................................... 10

Mechanical Specifications ......................................................... 12

Schematics ....................................................................................... 13

Rev. B | Page 2 of 24

SDP User Guide UG-277

PRODUCT OVERVIEW

The SDP-B board features

• Analog Devices ADSP-BF527 Blackfin processor

• Core performance up to 600 MHz

• 208-ball CSP-BGA package

• 24 MHz CLKIN oscillator

• 5 Mb of internal RAM memory

• 32 Mb flash memory

• Numonyx M29W320EB or

• Numonyx M25P32

• SDRAM memory

• Micron MT48LC16M16A2P-6A - 16 Mb x 16 bits

(256 Mb/32 MB)

• 3 × 120-pin small foot print connectors

• Hirose FX8-120P-SV1(91), 120-pin header

• Blackfin processor peripherals exposed

• SPI

• SPORT

• TWI/I

• GPIO

• PPI

• Asynchronous parallel

• Timers

For more information, go to http://www.analog.com/sdp.

2

C

TECHNICAL OR CUSTOMER SUPPORT

You can reach Analog Devices customer support in the
following ways:

• Visit the SDP website at

http://www.analog.com/sdp

• Email processor questions to

• [e-mail] (worldwide support)

• [e-mail] (Europe support)

• [e-mail] (China support)

• Phone questions to

1-800-ANALOGD

• Contact your Analog Devices local sales office or

authorized distributor.

• Send questions by mail to

Analog Devices, Inc.
Three Tec hnolo g y Wa y
P.O. Box 9106
Norwood, MA 02062-9106
USA

PRODUCT INFORMATION

Product information can be obtained from the Analog Devices
website.

Analog Devices Web Site

The Analog Devices website, www.analog.com, provides
information about a broad range of products—analog
integrated circuits, amplifiers, converters, and digital signal
processors.

Note that MyAnalog.com is a free feature of the Analog Devices
website that allows customization of a web page to display only
the latest information about products of interest to you. You can
choose to receive weekly email notifications containing updates
to the web pages that meet your interests, including
documentation errata against all documents. MyAnalog.com
provides access to books, application notes, data sheets, code
examples, and more.

Visit MyAnalog.com to sign up. If you are a registered user, just
log on. Your user name is your email address.

REGULATORY COMPLIANCE

The E VA L -SDP-CB1Z is designed to be used solely in a labor-
atory environment. The board is not intended for use as a
consumer end product or as a portion of a consumer end
product. The board is an open system design, which does not
include a shielded enclosure and therefore may cause interfer­ence to other electrical devices in close proximity. This board
should not be used in or near any medical equipment or
RF devices. Store unused boards in the protective shipping
package.

The E VA L -SDP-CB1Z board has been certified to comply with
the essential requirements of the European EMC directive
89/36/EC amended by 93/68/EEC and therefore carries the
CE mark.

Rev. B | Page 3 of 24

UG-277 SDP User Guide

09865-001

GETTING STARTED

This section provides specific information to assist you with
using the SDP-B board as part of your evaluation system.

The following topics are covered:

• Package contents

• PC configuration

• USB installation

• Powering up/powering down the SDP

PACKAGE CONTENTS

You r EVA L -SDP-CB1Z board package contains the following:

• EVAL-SDP-CB1Z board

• 1 m USB Standard-A to Mini-B cable

Contact the vendor where you purchased your SDP-B board or
contact Analog Devices if anything is missing.

PC CONFIGURATION

For correct operation of the SDP board, your computer must
have the following minimum configuration:

• Windows XP Service Pack 2 or Windows Vista®

• USB 2.0 port

Verifying Driver Installation

Before using the SDP-B board, verify the driver software has
installed properly.

Open the Windows Device Manager and verify the SDP board
appears under ADI Development Too ls as shown in Figure 1.

When removing the SDP-B board from the package, handle the
board carefully to avoid the discharge of static electricity, which
can damage some components.

USB INSTALLATION

Perform the following tasks to safely install the SDP-B board
onto the computer. There are two stages in the software
application installation procedure. The first stage installs the
application software. The second stage installs the .NET
Framework 3.5 and the necessary drivers.

Installing the Software

1. Run the application install provided. The first stage installs

the applications GUI and the necessary support files onto
the computer

2. Immediately following the application install, the .NET

Framework 3.5 and the driver package for the SDP board is
installed. If the .NET Framework 3.5 is already preinstalled
on the computer in question, this stage is skipped and Step
2 will consist of a driver package installation only

Connecting the SDP-B Board to the PC

Attach the SDP-B board to a USB 2.0 port on the computer via
the Standard-A to Mini-B cable provided.

Figure 1. Device Manager

POWERING UP/POWERING DOWN THE SDP

The following sections describe how to safely power up and
power down the SDP-B.

Powering Up the SDP-B Board

1. Connect the SDP-B board to the daughter evaluation board

through the 120-pin mating connectors.

2. Power the daughter board.

3. Connect the USB port on the computer to the SDP-B

board.

Powering Down the SDP-B Board

1. Power down the daughter evaluation board.

2. Disconnect the USB port on the computer from the SDP-B

board.

3. Disconnect the SDP-B board from the daughter evaluation

board.

Rev. B | Page 4 of 24

SDP User Guide UG-277

09865-002

POWER

CON B

CON C

STATUS

CON A

LED

LED

HARDWARE DESCRIPTION

This section describes the hardware design of the EVA L-SDP-

CB1Z board.

The following topics are covered:

• LEDs—This section describes the SDP on-board LEDs.

• Connector Details—This section details the pin

assignments on the 120-pin connectors.

• Power—This section lists power requirements of the SDP

and identifies connector power inputs and output pins.

• Daughter board design guidelines—This section provides

guidelines on how to design daughter boards for use with
the SDP.

• Mechanical specifications—This section provides

dimensional information.

LEDS

There are two LEDs located on the SDP-B board (see Figure 2).

POWER LED

The green power LED indicates that the SDP-B board is
powered. This is not an indication of USB connectivity between
the SDP-B and the PC.

STATUS LED

The orange status LED is an LED used as a diagnostic tool for
evaluation application developers. When there are two or more
identical SDP controller board and daughter board combin­ations connected to the PC simultaneously, the status LED
flashes during the connect routine to help the user identify
which board they will communicate with.

CONNECTOR DETAILS

The SDP-B board contains three Hirose FX8-120P-SV1(91),
120-pin header connectors. Connector A and Connector B share
identical pinouts and through these connectors, the peripheral
communication interfaces of ADSP-BF527 Blackfin processor are
exposed. The exposed peripherals are

• SPI

• SPORT

2

• I

C/TWI

• GPIO

• Asynchronous parallel

• PPI

• UART

• Timers

Figure 2. SDP-B Board LEDs

In addition, included on the connector specification are input
and output power pins, ground pins, and pins reserved for
future use. For further details on the peripheral interfaces,
including timing diagrams, see the ADSP-BF52x Blackfin
Processor Hardware Reference.

Connector C exposes the entire Blackfin memory space, but is
not used as part of the SDP platform.

Connector Pin Assignments

The connector pin assignments for Connector A and
Connector B have been defined independently of the any
internal pin sharing that occurs on the Blackfin processor.
Table 1 lists the connector pins and identifies the functionality
assigned to each connector pin for Connector A and
Connector B on the SDP-B board.

Rev. B | Page 5 of 24

UG-277 SDP User Guide

Pin No.

Pin Name

Description

13

PAR_D13

Parallel Data Bus Bit 13.

18

PAR_D5

Parallel Data Bus Bit 5.

23

GND

Connect to ground plane of board.

24

PAR_A3

Parallel Address Bus Bit 3.

35

SERIAL_INT

Serial Interrupt. Used to trigger a nonperiodic serial event.

Table 1. 120-Pin Connector Pin Assignments

1 VIN Power to SDP Board. Requires 200 mA at 5 V.
2 NC No Connect. Leave this pin unconnected. Do not ground.
3 GND Connect to ground plane of board.
4 GND Connect to ground plane of board.
5 USB_VBUS Connected directly to the USB +5 V supply.
6 GND Connect to ground plane of board.
7 PAR_D23 Parallel Data Bus Bit 23. (No connect.)1
8 PAR_D21 Parallel Data Bus Bit 21. (No connect.)1
9 PAR_D19 Parallel Data Bus Bit 19. (No connect.)1
10 PAR_D17 Parallel Data Bus Bit 17. (No connect.)1
11 GND Connect to ground plane of board.
12 PAR_D14 Parallel Data Bus Bit 14.

14 PAR_D11 Parallel Data Bus Bit 11.
15 PAR_D9 Parallel Data Bus Bit 9.
16 PAR_D7 Parallel Data Bus Bit 7.
17 GND Connect to ground plane of board.

19 PAR_D3 Parallel Data Bus Bit 3.
20 PAR_D1 Parallel Data Bus Bit 1.
21
22

Asynchronous Parallel Read Strobe.

PAR_RD

Asynchronous Parallel Chip Select.

PAR_CS

25 PAR_A1 Parallel Address Bus Bit 1.
26 PAR_FS3 Synchronous (PPI) Parallel Frame Sync 3.
27 PAR_FS1 Synchronous (PPI) Parallel Frame Sync 1.
28 GND Connect to ground plane of board.
29 SPORT_TDV0 SPI Data Line 3. (No connect.)1
30 SPORT_TDV1 SPI Data Line 2. (No connect.)1
31 SPORT_DR1 SPORT Data Receive 1. Secondary SPORT data into processor.
32 SPORT_DT1 SPORT Data Transmit 1. Secondary SPORT data from processor.
33 SPI_D2 SPORT Data Line. (No connect.)1
34 SPI_D3 SPORT Data Line. (No connect.)1

36 GND Connect to ground plane of board.
37
38
39

40 GND Connect to ground plane of board.
41 SDA_1 I2C Data 1.
42 SCL_1 I2C Data 1.2
43 GPIO0 General-Purpose Input/Output.
44 GPIO2 General-Purpose Input/Output.
45 GPIO4 General-Purpose Input/Output.
46 GND Connect to ground plane of board.
47 GPIO6 General-Purpose Input/Output.2
48 TMR_A Timer A Flag Pin. Use as first timer, if required.
49 TMR_C Timer C Flag Pin.1 (No connect.)
50 NC No Connect. Leave this pin unconnected. Do not ground.

SPI_SEL_B
SPI_SEL_C
SPI_SEL1/SPI_SS

SPI Chip Select B. Use this to control a second device on the SPI bus.
SPI Chip Select C. Use this for a third device on the SPI bus.

SPI Chip Select 1.2 Used to connect to SPI boot flash, if required. Also used as chip select when Blackfin

processor is operating as SPI slave.

Rev. B | Page 6 of 24

SDP User Guide UG-277

55

NC

No Connect. Leave this pin unconnected. Do not ground.

71

CLKOUT

CLKOUT from processor.

72

TMR_D

Timer D Flag Pin.2

83

SPI_MISO

SPI Master In, Slave Out Data.

99

PAR_INT

Parallel Interrupt. Used to trigger a nonperiodic parallel event.

100

Asynchronous Parallel Write Strobe.

Pin No. Pin Name Description

51 NC No Connect. Leave this pin unconnected. Do not ground.
52 GND Connect to ground plane of board.
53 NC No Connect. Leave this pin unconnected. Do not ground.
54 NC No Connect. Leave this pin unconnected. Do not ground.

56 EEPROM_A0 EEPROM A0. Connect to A0 address line of the EEPROM.
57
58 GND Connect to ground plane of board.
59 UART_RX UART Receive Data.2
60
61 BMODE1 Boot Mode 1. Pull up with 10 kΩ resistor to set SDP to boot from SPI Flash. Enabled on Connector A only.
62 UART_TX UART Transmit Data2.
63 GND Connect to ground plane of board.
64
65 WAKE External wake up to processor board.
66 NC No Connect. Leave this pin unconnected. Do not ground.
67 NC No Connect. Leave this pin unconnected. Do not ground.
68 NC No Connect. Leave this pin unconnected. Do not ground.
69 GND Connect to ground plane of board.
70 NC No Connect. Leave this pin unconnected. Do not ground.

RESET_OUT

RESET_IN

SLEEP

Active low reset signal from processor board.

Active low pin to reset controller board.

Active low sleep from processor board.

73 TMR_B Timer B Flag Pin. Use as second timer, if required.
74 GPIO7 General-Purpose Input/Output.
75 GND Connect to ground plane of board.
76 GPIO5 General-Purpose Input/Output.
77 GPIO3 General-Purpose Input/Output.
78 GPIO1 General-Purpose Input/Output.
79 SCL_0 I2C Clock 0. Daughter board EEPROM must be connected to this bus.
80 SDA_0 I2C Data 0. Daughter board EEPROM must be connected to this bus.
81 GND Connect to ground plane of board.
82 SPI_CLK SPI Clock.

84 SPI_MOSI SPI Master Out, Slave In Data.
85
86 GND Connect to ground plane of board.
87 SPORT_TSCLK SPORT Transmit Clock.
88 SPORT_DT0 SPORT Data Transmit 0. Primary SPORT data from processor.
89 SPORT_TFS SPORT Transmit Frame Sync.
90 SPORT_RFS SPORT Receive Frame Sync.
91 SPORT_DR0 SPORT Data Receive 0. Primary SPORT data into processor.
92 SPORT_RSCLK SPORT Receive Clock.
93 GND Connect to ground plane of board.
94 PAR_CLK Clock for Synchronous Parallel Interface (PPI).
95 PAR_FS2 Synchronous (PPI) Parallel Frame Sync 2.
96 PAR_A0 Parallel Address Bus Bit 0.
97 PAR_A2 Parallel Address Bus Bit 2.
98 GND Connect to ground plane of board.

SPI_SEL_A

SPI Chip Select A. Use this to control the first device on the SPI bus.

PAR_WR
101 PAR_D0 Parallel Data Bus Bit 0.
102 PAR_D2 Parallel Data Bus Bit 2.
103 PAR_D4 Parallel Data Bus Bit 4.

Rev. B | Page 7 of 24

UG-277 SDP User Guide

Pin No.

Pin Name

Description

111

PAR_D16

Parallel Data Bus Bit 16.1 (No connect.)1

104 GND Connect to ground plane of board.
105 PAR_D6 Parallel Data Bus Bit 6.
106 PAR_D8 Parallel Data Bus Bit 8.
107 PAR_D10 Parallel Data Bus Bit 10.
108 PAR_D12 Parallel Data Bus Bit 12.
109 GND Connect to ground plane of board.
110 PAR_D15 Parallel Data Bus Bit 15.

112 PAR_D18 Parallel Data Bus Bit 18.1 (No connect.)1
113 PAR_D20 Parallel Data Bus Bit 20.1 (No connect.)1
114 PAR_D22 Parallel Data Bus Bit 22. (No connect.)1
115 GND Connect to ground plane of board.
116 VIO (+3.3 V) +3.3 V Output. 20 mA maximum current available to power IO voltage on daughter board.
117 GND Connect to ground plane of board.
118 GND Connect to ground plane of board.
119 NC No Connect. Leave this pin unconnected. Do not ground.
120 NC No Connect. Leave this pin unconnected. Do not ground.

1

Functionality not implemented on the SDP board.

2

Shared across both connectors.

Each interface provided by the SDP-B is available on unique pins of the SDP-B 120-pin connector. The connector pin numbering scheme
is outlined in Figure 3.

Rev. B | Page 8 of 24

SDP User Guide UG-277

09865-003

*NC ON BLACKFI N S DP

*

*

*

*

*

*

*

*

*

*

*

*

*

TIMERS

INPUT/OUTPUT

GENERAL

I2C

SPI

SPORT

PORT

PARALLEL

SDP

STANDARD

CONNECTOR

120

NC

119

NC

118

GND

117

GND

116

VIO(+3.3V)

115

GND

114

PAR_D22

113

PAR_D20

112

PAR_D18

111

PAR_D16

110

PAR_D15

109

GND

108

PAR_D12

107

PAR_D10

106

PAR_D8

105

PAR_D6

104

GND

103

PAR_D4

102

PAR_D2

101

PAR_D0

100

PAR_WR

99

PAR_INT

98

GND

97

PAR_A2

96

PAR_A0

95

PAR_FS2

94

PAR_CLK

93

GND

92

SPORT_RSCLK

91

SPORT_DR0

90

SPORT_RFS

89

SPORT_TFS

88

SPORT_DT0

87

SPORT_TSCLK

86

GND

85

SPI_SEL_A

84

SPI_MOSI

83

SPI_MISO

82

SPI_CLK

81

GND

80

SDA_0

79

SCL_0

78

GPIO1

77

GPIO3

76

GPIO5

75

GND

74

GPIO7

73

TMR_B

72

TMR_D

71

NC

70

NC

69

GND

68

NC

67

NC

66

NC

65

WAKE

64

SLEEP

63

GND

62

UART_TX

61

BMODE1

60

RESET_IN

59

UART_RX

58

GND

57

RESET_OUT

56

EEPROM_A0

55

NC

54

NC

53

NC

52

GND

51

NC

50

NC

49

TMR_C

48

TMR_A

47

GPIO6

46

GND

45

GPIO4

44

GPIO2

43

GPIO0

42

SCL_1

41

SDA_1

40

GND

39

SPI_SEL1/SPI_SS

38

SPI_SEL_C

37

SPI_SEL_B

36

GND

35

SERIAL_INT

34

SPI_D3

33

SPI_D2

32

SPORT_DT1

31

SPORT_DR1

30

SPORT_TDV1

29

SPORT_TDV0

28

GND

27

PAR_FS1

26

PAR_FS3

25

PAR_A1

24

PAR_A3

23

GND

22

PAR_CS

21

PAR_RD

20

PAR_D1

19

PAR_D3

18

PAR_D5

17

GND

16

PAR_D7

15

PAR_D9

14

PAR_D11

13

PAR_D13

12

PAR_D14

11

GND

10

PAR_D17

9

PAR_D19

8

PAR_D21

7

PAR_D23

6

GND

5

USB_VBUS

4

GND

3

GND

2

NC

1

VIN

Figure 3. 120-Pin Connector Outline

Rev. B | Page 9 of 24

UG-277 SDP User Guide

Pin Sharing

Two types of pin sharing occur on the SDP-B board and must
be considered when using two or more of the connector’s
peripheral interfaces between a daughter board and the SDP
board. The first type is pin sharing that occurs internally in the
Blackfin processor. The second type is pin sharing that occurs
when a single Blackfin processor output pin is shared across
both Connector A and Connector B.

Internal Blackfin processor pin sharing can restrict the
simultaneous availability of peripheral interfaces on a single
connector or across both connectors. The Blackfin processor's
internal design has multiple signals physically sharing each
single output pin. As mentioned previously, the pins on the 120­pin connector were defined independently of this pin sharing.
This has the effect of limiting the peripherals, which can be
used simultaneously on the SDP. A system designer must
consult the ADSP-BF52x Blackfin Processor Hardware
Reference for the ADSP-BF527 processor to ensure the selected
peripherals are available simultaneously and their signals do not
share Blackfin processor output pins. An example of this
sharing is that the SPORT and PPI peripherals physically share
the same Blackfin processor pins. Therefore, these two
interfaces cannot be utilized in a single application. Pin sharing
also occurs from certain Blackfin processor output pins to both
Connector A and Connector B. The following signals are
connected from a single Blackfin processor output pin to both
Connector A and Connector B:

2

• I

C Bus 1, Pin 41 and Pin 42

• SCL 0 on I

2

C Bus 0, Pin 79

• GPIO 6 and GPIO 7, Pin 47 and Pin 67

• Timer D, Pin 72

• UA RT, Pin 59 and Pin 62

POWER

The SDP-B board requires that any daughter board connected
to the SDP-B board provides the SDP-B board with 5 V at 200
mA. This supply should be made available on Pin 1 (VIN) of
the 120-pin connector. This supply is required to power the
Blackfin processor, the memory, and the other components on
the SDP-B board. The SDP board also provides 3.3 V at 20 mA
on Pin 116 (VIO_3.3) to connected daughter boards as the VIO
voltage for the daughter board. Pin 5 (USB_VBUS) is connected
to the +5 V line of the USB connector, providing 5 V ±10% as
an output of the SDP board.

DAUGHTER BOARD DESIGN GUIDELINES

The daughter board design guidelines specify the layout,
connector position, keep out areas, and dimensions of potential
daughter boards. This guidance is to ensure that a daughter
board can connect off either Connector A or Connector B of
the SDP-B board. Following these guidelines ensures that both
connectors on the SDP can have any one of the catalogue of
daughter boards physically attached to the connectors
simultaneously.

Connector Location

The daughter board connector and securing screw holes are to
be located in the top left hand corner. This arrangement can
be seen for Daughter Board A in Figure 4. Note that Daughter
Board B is the same as Daughter Board A rotated clockwise
through 90°. The exact location of the connector from the
board's edge is important in order to allow both boards connect
at the same time. As seen in Figure 4, if either board exceeds
these dimensions, it is not possible to connect the other. Every
effort was made to extend the 5.9 mm dimension as large as
possible in order to allow space for vias between the connector
and the edge of the board. These are absolute maximum
dimensions and should not be exceeded.

Rev. B | Page 10 of 24

SDP User Guide UG-277

5.9mm

3.3mm

3.3mm

5.9mm

DAUGHTERBOARD B

DAUGHTERBOARD A

09865-004

1.75mm

5.90mm

3.30mm

5.15mm

60 61

1 120

50.50mm

ORIGIN (0,0)

NO RIGHT-ANGLED CONNECTORS ALLOWED ALONG THIS EDGE

x = 5.9mm, y = –3.3mm

x = 5.95mm, y = –53.8mm

EVAL-xxxxx-DB
Rev. D

D3.10mm

12.65mm

PLACEMENT KEEPOUT FOR COMPONENTS
OVER 3mm IN HEIGHT
(EXTENDS DOWN ENTIRE HEIGHT O F LEFT HAND SIDE OF PCB)

D3.10mm

x = 5.95mm, y = –28.55mm (CE NTER OF CONNECTOR)

09865-005

Figure 4. Maximum Board Dimensions for Connector Placement

The full specification drawing for the connector location on the daughter board can be seen in Figure 5.

Figure 5. Connector Placement on Compatible Daughter Boards

Rev. B | Page 11 of 24

UG-277 SDP User Guide

09865-006

POWER

CON B

STATUS

CON C

CON A

CON B A

0.152”/8.86mm

LED

LED

CON B

CON A

2.75”

69.85mm

2.25”

57.15mm

0.125”/3.17mm

0.21875”/5.54mm

CON C

The mating daughter board 120-pin connector is the Hirose
FX8-120S-SV(21), 120-pin receptacle, FEC 132-4660, Digi-Key
H1219-ND. Consult the connector's data sheet for full details
on the connector. Note that Pin 1 to Pin 60 are placed on the
left side of the connector and Pin 61 to Pin 120 are placed on
the right side of the connector.

Keep Out Area

In order to allow the greatest flexibility for future controller
boards, a keep out area is established for components higher
that 3 mm. The keep out area is 12.65 mm wide and extends
down the entire left side of the daughter board.

Restriction on Right Angle Connectors

Due to the close proximity of the edges of the A and B daughter
boards (seen in Figure 4) right angle connectors are not allowed

on the top and left edges of the daughter boards and (if
required) should be placed on the right or bottom edges. The
phrase "right angle connector" is used to describe any connector
that requires the connection to protrude over the edge of the
board (for example, right angle SMB or screw terminal)

MECHANICAL SPECIFICATIONS

The mechanical specifications of the SDP-B board are 2.75" ×

2.25" (69.85 mm × 27.15 mm). The height of the 120-pin con­nectors from the bottom of the board is approximately 0.152"
(3.86 mm). The tallest component on the top is approximately

0.125" (3.175 mm), and the tallest components on the bottoms
are the connectors at approximately 0.152" (3.86 mm). Refer to
Figure 6.

Figure 6. SDP-B Board Mechanical Specifications

Rev. B | Page 12 of 24

SDP User Guide UG-277

SCHEMATICS

This section provides the schematic drawings for the E VA L -SDP-CB1Z board. The schematic pages include

• SDP-B—Power

• SDP-B—Memory

• SDP-B—Clocks_USB

• SDP-B—Blackfin_I/O

• SDP-B—Connector A

• SDP-B—Connector B

• SDP-B—Connector C

Rev. B | Page 13 of 24

UG-277 SDP User Guide

09865-007

Figure 7. SDP-B —Power

Rev. B | Page 14 of 24

SDP User Guide UG-277

09865-008

Figure 8. SDP-B —Memory

Rev. B | Page 15 of 24

UG-277 SDP User Guide

09865-009

Figure 9. SDP-B —Clocks_USB

Rev. B | Page 16 of 24

SDP User Guide UG-277

09865-010

Figure 10. SDP-B —Blackfin_I/O

Rev. B | Page 17 of 24

UG-277 SDP User Guide

09865-011

Figure 11. SDP-B —Connector A

Rev. B | Page 18 of 24

SDP User Guide UG-277

09865-012

Figure 12. SDP-B —Connector B

Rev. B | Page 19 of 24

UG-277 SDP User Guide

09865-013

Figure 13. SDP-B —Connector C

Rev. B | Page 20 of 24

SDP User Guide UG-277

NOTES

Rev. B | Page 21 of 24

UG-277 SDP User Guide

NOTES

Rev. B | Page 22 of 24

SDP User Guide UG-277

NOTES

Rev. B | Page 23 of 24

UG-277 SDP User Guide

omer understands and agrees that the Evaluation Board is provided

LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF

NOTES

ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection

circuitry, damage may occur on devices subjected to high e nergy ESD. Therefore, proper ESD precaution s should be taken to avoid performance degradation or loss of functionality.

Legal Terms and Conditions

By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be boun d by the terms and condition s
set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation Board until you
have read and agreed to the Agreement . Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer ”) and Analog Devices, Inc.
(“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. Subject to the terms and conditions of the Agreement, ADI hereby grants to Customer a free, limited, personal,
temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Cust
for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Further more, the license granted is expressly made subject to the following additional
limitations: Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board; and (ii) permit any Third Party to access the Evaluation Board. As used herein, the term
“Third Party” includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is NOT sold to Customer; all rights not expressly granted herein, including
ownership of t he Evaluation Board, are res erved by ADI. CONFIDENTI ALIT Y. This Agreement and the Evaluation Board shall all be considered the confidential and proprietary information of ADI. Customer may
not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of use of the Evaluation Board or termination of this Agreement, Customer agrees to
promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any
occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited to soldering or any other activity that affects the material content of the Evaluation Board.
Modifications to th e Evaluation Board must comply wi th applicable law, including but not limit ed to the RoHS Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice
to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDE D “AS IS” AND ADI MAKES NO
WARRANTIES OR REPRES ENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICAL LY DISC LAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUA RANTEES, OR WARRANT IES, EXPRESS OR IMPLIED, RE LATE D
TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL
PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS LICENSORS BE
THE EVALUAT ION BOARD, INCLUDING BUT NOT LIMI TED TO LOST PROFITS, DE LAY COSTS, LABOR COSTS OR LOSS OF GOODWI LL. ADI’S TOTAL LIA BILITY FROM AN Y AND ALL CAUSES S HALL BE LIMITE D TO THE
AMOUNT OF ONE HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable
United States federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and construed in accordance with the substantive laws of the Commonwealth of
Massachusetts (excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby
submits to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the International Sale of Goods shall no t apply to this Agreement and is exp ressly disclaimed.

©2011 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
UG09865-0-12/11(B)

Rev. B | Page 24 of 24
