TRANSCEND ELECTROLYTIC CO., LTD.
.
TRANSCEND ELECTROLYTIC (SHENZHEN) CO., LTD
RoHS Compliant ALUMINIUM ELECTROLYTIC CAPACITOR BA Series
FEATURES
◆
1000Hz bipolar, excellent high frequency response characteristics
◆
Load life of 1000 hours at 85°C
◆
Applications for use in crossovers networks in Hi-Fi speaker systems
OUTLINE
D 6 8 10131618
0.6 0.8
SPECIFICATIONS
Items
Capacitance Tolerance
(120Hz, 25°C)
Rated Working Voltage Range 63 ~ 100Vdc
Characteristics
± 20% (M)
d
mm
Operation Temperature
Leakage Current (25°C)
Surge Voltage (25°C)
Dissipation Factor (120Hz, 25°C)
Temperature Characteristics
Load Test
-40°C ~ +85°C
(Value measured 5 minutes after applying rated voltage)
I ≤ 0.01CV or 3 (uA)
◆ I : Leakage Current (uA)
W.V.
S.V. 79
W.V.
tan
δ
W.V.
- 25°C / + 25°C
- 40°C / + 25°C
◆ Impedance ratio at 120Hz
After 1000 hours application of WV at +85°C, the capacitor shall meet the following limits:
Capacitance Change
tan
δ
Leakage Current
After 500 hours, no voltage applied at +85°C, the capacitor shall meet the following limits:
≤ ± 20% of initial value
≤ 200% of initial specified value
≤ initial specified value
◆ C : Rated Capacitance (uF)
63
63
0.10
63
4
6
◆ V : Working Voltage (V)
100
125
100
100
4
6
Shelf Test
Capacitance Change
δ
tan
Leakage Current
Products Catalogue 12th Edition BA-1
≤ ± 25% of initial value
≤ 200% of initial specified value
≤ 200% of initial specified value
Page 2
TRANSCEND ELECTROLYTIC CO., LTD.
TRANSCEND ELECTROLYTIC (SHENZHEN) CO., LTD.
RoHS Compliant ALUMINIUM ELECTROLYTIC CAPACITOR BA Series
DIMENSIONS D x L (mm)
WV
uF
1
1.5
2.2
3.3
4.7
5.6
6.8
8.2
10 10x19 13x27
15
22 13x27 16x27
33
47
68
100
63 100
8x17 13x27
8x17 13x27
8x17 13x27
8x17
8x17 13x27
8x17
8x17
10x19
13x27
13x27
13x27 16x34
13x30 18x40
13x27
13x27
13x278x17
13x27
13x27
16x34
16x34
PERMISSIBLE RIPPLE CURRENT
WV
uF Item
1 15.9
1.5
2.2
3.3 165
4.7
5.6
6.8
8.2
10
15
22
33
47
68
100
RC IMP RC
86
95 10.6 100 10.6
125 7.23 135 7.23
155 4.82
180 3.38 195 3.38
210
230 2.34 270 2.34
260 1.94 290 1.94
310 1.59 360 1.59
360 1.05 560 1.05
520 0.72 580 0.72
610 0.48 760 0.48
730 0.336 860 0.336
950 0.228 1080 0.228
1400 0.156 1640 0.156
63 100
15.9 90
2.84 230 2.84
RC: mA (rms) at 1KHz 85°C
ESR: Ω (ohm) at 1KHz 25°C
IMP
4.82
Products Catalogue 12th Edition BA-2
