DC/DC Converters
25.4
20.3
32
10.2
3.8
15.24
11
9
22
23
2
3
14
16
Bottom view
2.54
15.24
2.4
5.08
(0.6)
(0.8)
(0.1)
(0.4)
(0.15)
(1.25)
(1.0)
(0.1)
(0.2)
(0.6)
Insulated Baseplate
2.0
2.54
(0.08)
(0.1)
1
() = Inches Pin Ø 0.5 mm (0.02)
TEN 8 Series, 8 Watt
= High Power Density in DIL-24 Metal Package
= Wide 2:1 Input Range
= High Efficiency up to 85%
= Operating Temperature Range –40°C to +85°C
= I/O Isolation 1500 VDC
= Short Circuit Protection
Input Filter to meet EN 55022, Class A
=
= Remote On/Off
= Industry Standard Pinout
Line regulation:
Load regulation:
Ripple & Noise: <50 mVpk-pk (20 MHz BW)
Conducted EMI: EN 55022, class A and FCC, level A (internal filter)
Short circuit protection: continuous, automatic recovery
Efficiency: 83% typ.
Operating temperature range: –40°C … +85°C above 60°C derating 2%/°C
I/O isolation voltage: 1500 VDC
Safety standards / approvals: cUL /UL 60950, IEC/EN 60950
Case: metal, 6-side shielded with insulated baseplate
Remote On/Off: shutdown input for low input current (2.5 mA) in standby operation
±0.2% max.
– Single output models: ±0.2% max.
– Dual output models: ±1.0% max.
Models
Order Code Input voltage Output voltage Output current
TEN 8-1210 3.3 VDC 2000 mA
TEN 8-1211 5 VDC 1500 mA
TEN 8-1212 12 VDC 665 mA
TEN 8-1213 9 – 18 VDC 15 VDC 535 mA
TEN 8-1221 ±5 VDC ±800 mA
TEN 8-1222 ±12 VDC ±335 mA
TEN 8-1223 ±15 VDC ±265 mA
TEN 8-2410 3.3 VDC 2000 mA
TEN 8-2411 5 VDC 1500 mA
TEN 8-2412 12 VDC 665 mA
TEN 8-2413 18 – 36 VDC 15 VDC 535 mA
TEN 8-2421 ±5 VDC ±800 mA
TEN 8-2422 ±12 VDC ±335 mA
TEN 8-2423 ±15 VDC ±265 mA
TEN 8-4810 3.3 VDC 2000 mA
TEN 8-481
TEN 8-4812 12 VDC 665 mA
TEN 8-4813 36 – 75 VDC 15 VDC 535 mA
TEN 8-4821
TEN 8-4822 ±12 VDC ±335 mA
TEN 8-4823 ±15 VDC ±265 mA
1 5 VDC 1500 mA
±5 VDC ±800 mA
max.
Pin Single Output Dual Output
1 Remote On/Off Remote On/Off
2
3
9 No con. Common
1
1
14
16 – Vout Common
22
23
Pin-Out
– Vin (GND) – Vin (GND)
in (GND)
– V
No con.
+ V
+ V
+ V
in (GND)
out
in (Vcc)
in (Vcc)
– V
out
– V
out
+ V
+ Vin (Vcc)
in (Vcc)
+ V
