Page 1
DATA SH EET
Product specification
File under Integrated Circuits, IC01
1997 Feb 20
INTEGRATED CIRCUITS
TDA8563AQ
2 × 40 W/2 Ω stereo BTL car radio
power amplifier with diagnostic
facility
Page 2
1997 Feb 20 2
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
FEATURES
• Requires very few external components
• High output power
• 4 Ω and 2 Ω load impedance
• Low output offset voltage
• Fixed gain
• Diagnostic facility (distortion, short-circuit and
temperature detection)
• Good ripple rejection
• Mode select switch (operating, mute and standby)
• Load dump protection
• Short-circuit safe to ground, to V
P
and across the load
• Low power dissipation in any short-circuit condition
• Thermally protected
• Reverse polarity safe
• Electrostatic discharge protection
• No switch-on/switch-off plop
• Flexible leads
• Low thermal resistance.
GENERAL DESCRIPTION
The TDA8563AQ is an integrated class-B output amplifier
in a 13-lead single-in-line (SIL) power package.
It contains 2 × 40 W/2 Ω amplifiers in BTL configuration.
The device is primarily developed for car radio
applications.
QUICK REFERENCE DATA
ORDERING INFORMATION
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
V
P
operating supply voltage 6.0 14.4 18 V
I
ORM
repetitive peak output current −−7.5 A
I
q(tot)
total quiescent current − 115 − mA
I
sb
standby current − 0.1 100 µA
I
sw
switch-on current −−40 µA
Z
I
input impedance 25 30 − kΩ
P
o
output power RL=4Ω; THD = 10% − 25 − W
R
L
=2Ω; THD = 10% − 40 − W
SVRR supply voltage ripple rejection R
s
=0Ω−60 − dB
α
cs
channel separation Rs=10kΩ−50 − dB
G
v
closed loop voltage gain 25 26 27 dB
V
no
noise output voltage Rs=0Ω−−120 µV
∆V
O
DC output offset voltage −−150 mV
TYPE NUMBER
PACKAGE
NAME DESCRIPTION VERSION
TDA8563AQ DBS13P plastic DIL-bent-SIL power package; 13 leads (lead length 12 mm) SOT141-6
Page 3
1997 Feb 20 3
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
BLOCK DIAGRAM
Fig.1 Block diagram.
handbook, full pagewidth
mode switch
MGL073
output 1A
15 kΩ
15 kΩ
x1
VA
stand-by
switch
V
P
mute
switch
stand-by
reference
voltage
PROTECTIONS
Load dump
Soar
Thermal
Short - circuit
Reverse polarity
3
10
V
P1
V
P2
20.7 kΩ
2.3
k
Ω
20.7 kΩ
2.3
k
Ω
20.7 kΩ
2.3
k
Ω
20.7 kΩ
2.3
k
Ω
mute switch
VA
C
m
power stage
mute switch
VA
C
m
power stage
30
kΩ
4
6
11
mute switchVAC
m
power stage
mute switch
VA
C
m
power stage
30
kΩ
9
7
258
ground (signal)
GND1 GND2
power ground (substrate)
output 2B
output 2A
output 1B
input 1
input 2
13
1
TDA8563AQ
mute
reference
voltage
input
reference
voltage
12 diagnostic
output
DIAGNOSTIC
INTERFACE
Page 4
1997 Feb 20 4
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
PINNING
SYMBOL PIN DESCRIPTION
IN 1 1 input 1
GND(S) 2 signal ground
V
P1
3 supply voltage 1
OUT 1A 4 output 1A
GND1 5 power ground 1
OUT 1B 6 output 1B
OUT 2A 7 output 2A
GND2 8 power ground 2
OUT 2B 9 output 2B
V
P2
10 supply voltage 2
MODE 11 mode switch input
V
DIAG
12 diagnostic output
IN 2 13 input 2
Fig.2 Pin configuration.
handbook, halfpage
1
2
3
4
5
6
7
8
9
10
11
12
13
MGL075
TDA8563AQ
IN 1
GND(S)
V
P1
OUT 1A
GND1
OUT 1B
OUT 2A
GND2
OUT 2B
V
P2
MODE
IN 2
DIAG
V
FUNCTIONAL DESCRIPTION
The TDA8563AQ contains two identical amplifiers and can
be used for bridge applications. The gain of each amplifier
is fixed at 26 dB. Special features of the device are as
follows.
Mode select switch (pin 11)
• Standby: low supply current (<100 µA)
• Mute: input signal suppressed
• Operating: normal on condition.
Since this pin has a very low input current (<40 µA), a low
cost supply switch can be applied.
To avoid switch-on plops, it is advised to keep the amplifier
in the mute mode during ≥100 ms (charging of the input
capacitors at pin 1 and pin 13). During switching from
standby to mute, the slope should be at least 18 V/s.
This can be achieved by:
• Microprocessor control
• External timing circuit (see Fig.7).
Diagnostic output (pin 12)
D
YNAMIC DISTORTION DETECTOR (DDD)
At the onset of clipping of one or more output stages, the
dynamic distortion detector becomes active and pin 12
goes low. This information can be used to drive a sound
processor or DC volume control to attenuate the input
signal and thus limit the distortion. The output level of
pin 12 is independent of the number of channels that are
clipping (see Fig.3).
Fig.3 Distortion detector waveform.
handbook, halfpage
V
0
V
P
V
O
0
t
MGA721
12
Page 5
1997 Feb 20 5
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
SHORT-CIRCUIT PROTECTION
When a short-circuit occurs at one or more outputs to
ground or to the supply voltage, the output stages are
switched off until the short-circuit is removed and the
device is switched on again, with a delay of approximately
20 ms, after removal of the short-circuit. During this
short-circuit condition, pin 12 is continuously low.
When a short-circuit across the load of one or both
channels occurs the output stages are switched off during
approximately 20 ms. After that time it is checked during
approximately 50 µs to see whether the short-circuit is still
present. Due to this duty cycle of 50 µs/20 ms the average
current consumption during this short-circuit condition is
very low (approximately 40 mA).
During this short-circuit condition, pin 12 is low for 20 ms
and high for 50 µs (see Fig.4).
The power dissipation in any short-circuit condition is
very low.
T
EMPERATURE DETECTION
When the virtual junction temperature Tvj reaches 150 °C,
pin 12 will become continuously low.
O
PEN COLLECTOR OUTPUT
Pin 12 is an open collector output, which allows pin 12 of
more devices being tied together.
Fig.4 Short-circuit waveform.
andbook, full pagewidth
MGA722
short-circuit over the load
20 ms
µ
50 s
t
t
V
P
current
in
output
stage
V
12
Page 6
1997 Feb 20 6
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
THERMAL CHARACTERISTICS
SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
V
P
supply voltage
operating − 18 V
non-operating − 30 V
load dump protection during 50 ms; t
r
≥ 2.5 ms − 45 V
V
psc
AC and DC short-circuit safe voltage − 18 V
V
pr
reverse polarity − 6V
I
OSM
non-repetitive peak output current − 10 A
I
ORM
repetitive peak output current − 7.5 A
P
tot
total power dissipation − 60 W
T
stg
storage temperature −55 +150 °C
T
amb
operating ambient temperature −40 +85 °C
T
vj
virtual junction temperature − 150 °C
SYMBOL PARAMETER VALUE UNIT
R
th j-a
thermal resistance from junction to ambient in free air 40 K/W
R
th j-c
thermal resistance from junction to case (see Fig.5) 1.3 K/W
Fig.5 Equivalent thermal resistance network.
handbook, halfpage
2.2 K/W
0.2 K/W
2.2 K/W
virtual junction
output 1 output 2
case
MBA624
Page 7
1997 Feb 20 7
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
DC CHARACTERISTICS
V
P
= 14.4 V; T
amb
=25°C; measured in Fig.6; unless otherwise specified.
Notes
1. The circuit is DC adjusted at V
P
= 6 to 18 V and AC operating at VP= 8.5 to 18 V.
2. At 18 V < VP< 30 V the DC output voltage ≤1⁄2VP.
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
Supply
V
P
supply voltage note 1 6.0 14.4 18 V
I
q
quiescent current RL= ∞−115 180 mA
Operating condition
V
11
mode switch voltage level 8.5 − V
P
V
I
11
mode switch current V11= 14.4 V − 15 40 µA
V
O
DC output voltage note 2 − 7.3 − V
∆V
O
DC output offset voltage −−150 mV
Mute condition
V
11
mode switch voltage level 3.3 − 6.4 V
V
O
DC output voltage note 2 − 7.3 − V
∆V
O
DC output offset voltage −−150 mV
Standby condition
V
11
mode switch voltage level 0 − 2V
I
sb
standby current − 0.1 100 µA
Diagnostic output
V
12
diagnostic output voltage any short-circuit or clipping −−0.6 V
Page 8
1997 Feb 20 8
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
AC CHARACTERISTICS
V
P
= 14.4 V; RL=2Ω; f = 1 kHz; T
amb
=25°C; measured in Fig.6; unless otherwise specified.
Notes
1. Dynamic distortion detector active.
2. Frequency response externally fixed.
3. V
ripple=Vripple(max)
= 2 V (p-p); Rs=0Ω.
4. B = 20 Hz to 20 kHz; Rs=0Ω.
5. B = 20 Hz to 20 kHz; Rs=10kΩ.
6. B = 20 Hz to 20 kHz; independent of Rs.
7. Po= 25 W; Rs=10kΩ.
8. Vi=V
i(max)
= 1 V (RMS).
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
P
o
output power THD = 0.5% 25 30 − W
THD = 10% 33 40 − W
THD = 30% 45 55 − W
P
o
output power THD = 0.5%; VP= 13.2 V − 25 − W
THD = 10%; V
P
= 13.2 V − 35 − W
THD total harmonic distortion P
o
=1W − 0.1 − %
V
12
≤ 0.6 V; note 1 − 2.2 − %
B power bandwidth THD = 0.5%;
P
o
= −1dB
with respect to 25 W
− 20 to 20000 − Hz
f
lr
low frequency roll-off at −1 dB; note 2 − 25 − Hz
f
hr
high frequency roll-off at −1dB 20 −−kHz
G
v
closed loop voltage gain 25 26 27 dB
SVRR supply voltage ripple rejection
on note 3 50 −−dB
mute note 3 50 −−dB
standby note 3 80 −−dB
Z
i
input impedance 25 30 38 kΩ
V
no
noise output voltage
on note 4 − 85 120 µV
on note 5 − 100 −µV
mute note 6 − 60 −µV
α
cs
channel separation note 7 45 −−dB
∆G
v
channel unbalance −− 1dB
V
o
output voltage in mute note 8 −− 2mV
Page 9
1997 Feb 20 9
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
AC CHARACTERISTICS
V
P
= 14.4 V; RL=4Ω; f = 1 kHz; T
amb
=25°C; measured in Fig.6; unless otherwise specified.
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
P
o
output power THD = 0.5% 16 19 − W
THD = 10% 21 25 − W
THD = 30% 28 35 − W
P
o
output power THD = 0.5%; VP= 13.2 V − 15 − W
THD = 10%; V
P
= 13.2 V − 21 − W
THD total harmonic distortion P
o
=1W − 0.1 − %
Page 10
1997 Feb 20 10
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
TEST AND APPLICATION INFORMATION
(1) To avoid high energy switching pulses which can feedback to the inputs it is advisable to ensure that the value of the resistor at pin 12 is ≥10 kΩ.
Fig.6 Stereo BTL test/application diagram.
handbook, full pagewidth
MGL074
100
nF
mode switch
11 3 10
470 nF
1
4
6
470 nF
13
9
7
58
V
P
TDA8563AQ
2200
µF
30
kΩ
reference
voltage
2
ground (signal)
30
kΩ
input 2
input 1
power ground (substrate)
12
10 kΩ
V
P
diagnostic
output
Page 11
1997 Feb 20 11
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
Fig.7 Mode select switch circuitry.
handbook, halfpage
+V
P
MODE
MGD959
BZX79C/3.9V
10 kΩ
47 µF
Diagnostic output
Special care must be taken in the printed-circuit board
layout to separate pin 12 from pin 1 and pin 13, to
minimize the crosstalk between the diagnostic output and
the inputs.
Mode select switch
To avoid switch-on plops, it is advised to keep the amplifier
in the mute mode during >100 ms (charging of the input
capacitors at pin 1 and pin 13).
The circuit in Fig.7 slowly ramps up the voltage at the
mode select switch pin when switching on and results in
fast muting when switching off.
(1) f = 10 kHz.
(2) f = 1 Hz.
(3) f = 100 Hz.
Fig.8 Total harmonic distortion as a function of output power; VP= 14.4 V; RL=2Ω.
handbook, full pagewidth
10
2
MLB667
10110
1
10
2
10
1
10
P (W)
o
10
2
1
10
2
THD
(%)
(1)
(2)
(3)
Page 12
1997 Feb 20 12
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
Fig.9 Output power as a function of supply voltage; f = 1 kHz; RL=2Ω.
(1) THD = 30%.
(2) THD = 10%.
(3) THD = 0.5%.
handbook, full pagewidth
18
70
0
810121416
MGA905
10
20
30
40
P
o
(W)
V (V)
P
(3)
(2)
50
60
(1)
Fig.10 Output power as a function of frequency; THD = 0.5%; VP= 14.4 V; RL=2Ω.
handbook, full pagewidth
23
10
5
MLB668
10
4
10
3
10
2
10
25
27
29
31
f (Hz)
P
o
(W)
33
Page 13
1997 Feb 20 13
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
(1) Po= 0.1 W.
(2) Po=1W.
(3) Po=10W.
Fig.11 Total harmonic distortion as a function of frequency; VP= 14.4 V; RL=2Ω.
handbook, full pagewidth
10
5
MLB669
10
4
10
3
10
2
10
1
10
2
f (Hz)
10
1
THD
(%)
(2)
(3)
(1)
(1) On condition.
(2) Mute condition.
Fig.12 Ripple rejection as a function of frequency; VP= 14.4 V; V
ripple
= 2 V (p-p); Rs=0Ω.
handbook, full pagewidth
80
10
5
MLB670
10
4
10
3
10
2
10
70
60
50
f (Hz)
SVRR
(dB)
(1)
(2)
Page 14
1997 Feb 20 14
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
Fig.13 Channel separation as a function of frequency; VP= 14.4 V; Po= 25 W; RL=2Ω; Rs=10kΩ.
handbook, full pagewidth
70
10
5
MLB671
10
4
10
3
10
2
10
60
50
40
f (Hz)
(dB)
α
cs
Fig.14 Quiescent current as a function of supply voltage; RL= ∞.
handbook, full pagewidth
18
150
50
8 10121416
MGA909
70
90
110
130
V (V)
P
I
q
(mA)
Page 15
1997 Feb 20 15
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
PACKAGE OUTLINE
UNIT A e
1
A2bpcD
(1)
E
(1)
Z
(1)
deD
h
LL3m
REFERENCES
OUTLINE
VERSION
EUROPEAN
PROJECTION
ISSUE DATE
IEC JEDEC EIAJ
mm
17.0
15.5
4.6
4.2
0.75
0.60
0.48
0.38
24.0
23.6
20.0
19.6
10 3.4
v
0.8
12.2
11.8
1.7
e
2
5.08
2.4
1.6
E
h
6
2.00
1.45
2.1
1.8
3.4
3.1
4.3
DIMENSIONS (mm are the original dimensions)
Note
1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.
12.4
11.0
SOT141-6
0 5 10 mm
scale
Qj
0.25w0.03
x
D
L
E
A
c
A
2
m
L
3
Q
w M
b
p
1
d
D
Z
e
2
e
e
x
h
113
j
E
h
non-concave
view B: mounting base side
92-11-17
95-03-11
DBS13P: plastic DIL-bent-SIL power package; 13 leads (lead length 12 mm)
SOT141-6
v M
B
Page 16
1997 Feb 20 16
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
SOLDERING
Introduction
There is no soldering method that is ideal for all IC
packages. Wave soldering is often preferred when
through-hole and surface mounted components are mixed
on one printed-circuit board. However, wave soldering is
not always suitable for surface mounted ICs, or for
printed-circuits with high population densities. In these
situations reflow soldering is often used.
This text gives a very brief insight to a complex technology.
A more in-depth account of soldering ICs can be found in
our
“IC Package Databook”
(order code 9398 652 90011).
Soldering by dipping or by wave
The maximum permissible temperature of the solder is
260 °C; solder at this temperature must not be in contact
with the joint for more than 5 seconds. The total contact
time of successive solder waves must not exceed
5 seconds.
The device may be mounted up to the seating plane, but
the temperature of the plastic body must not exceed the
specified maximum storage temperature (T
stg max
). If the
printed-circuit board has been pre-heated, forced cooling
may be necessary immediately after soldering to keep the
temperature within the permissible limit.
Repairing soldered joints
Apply a low voltage soldering iron (less than 24 V) to the
lead(s) of the package, below the seating plane or not
more than 2 mm above it. If the temperature of the
soldering iron bit is less than 300 °C it may remain in
contact for up to 10 seconds. If the bit temperature is
between 300 and 400 °C, contact may be up to 5 seconds.
DEFINITIONS
LIFE SUPPORT APPLICATIONS
These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.
Data sheet status
Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.
Limiting values
Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.
Application information
Where application information is given, it is advisory and does not form part of the specification.
Page 17
1997 Feb 20 17
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
NOTES
Page 18
1997 Feb 20 18
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
NOTES
Page 19
1997 Feb 20 19
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio power
amplifier with diagnostic facility
TDA8563AQ
NOTES
Page 20
Internet: http://www.semiconductors.philips.com
Philips Semiconductors – a worldwide company
© Philips Electronics N.V. 1997 SCA53
All rights are reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner.
The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed
without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof does not convey nor imply any license
under patent- or other industrial or intellectual property rights.
Netherlands: Postbus 90050, 5600 PB EINDHOVEN, Bldg. VB,
Tel. +31 40 27 82785, Fax. +31 40 27 88399
New Zealand: 2 Wagener Place, C.P.O. Box 1041, AUCKLAND,
Tel. +64 9 849 4160, Fax. +64 9 849 7811
Norway: Box 1, Manglerud 0612, OSLO,
Tel. +47 22 74 8000, Fax. +47 22 74 8341
Philippines: Philips Semiconductors Philippines Inc.,
106 Valero St. Salcedo Village, P.O. Box 2108 MCC, MAKATI,
Metro MANILA, Tel. +63 2 816 6380, Fax. +63 2 817 3474
Poland: Ul. Lukiska 10, PL 04-123 WARSZAWA,
Tel. +48 22 612 2831, Fax. +48 22 612 2327
Portugal: see Spain
Romania: see Italy
Russia: Philips Russia, Ul. Usatcheva 35A, 119048 MOSCOW,
Tel. +7 095 755 6918, Fax. +7 095 755 6919
Singapore: Lorong 1, Toa Payoh, SINGAPORE 1231,
Tel. +65 350 2538, Fax. +65 251 6500
Slovakia: see Austria
Slovenia: see Italy
South Africa: S.A. PHILIPS Pty Ltd., 195-215 Main Road Martindale,
2092 JOHANNESBURG, P.O. Box 7430 Johannesburg 2000,
Tel. +27 11 470 5911, Fax. +27 11 470 5494
South America: Rua do Rocio 220, 5th floor, Suite 51,
04552-903 São Paulo, SÃO PAULO - SP, Brazil,
Tel. +55 11 821 2333, Fax. +55 11 829 1849
Spain: Balmes 22, 08007 BARCELONA,
Tel. +34 3 301 6312, Fax. +34 3 301 4107
Sweden: Kottbygatan 7, Akalla, S-16485 STOCKHOLM,
Tel. +46 8 632 2000, Fax. +46 8 632 2745
Switzerland: Allmendstrasse 140, CH-8027 ZÜRICH,
Tel. +41 1 488 2686, Fax. +41 1 481 7730
Taiwan: Philips Semiconductors, 6F, No. 96, Chien Kuo N. Rd., Sec. 1,
TAIPEI, Taiwan Tel. +886 2 2134 2870, Fax. +886 2 2134 2874
Thailand: PHILIPS ELECTRONICS (THAILAND) Ltd.,
209/2 Sanpavuth-Bangna Road Prakanong, BANGKOK 10260,
Tel. +66 2 745 4090, Fax. +66 2 398 0793
Turkey: Talatpasa Cad. No. 5, 80640 GÜLTEPE/ISTANBUL,
Tel. +90 212 279 2770, Fax. +90 212 282 6707
Ukraine: PHILIPS UKRAINE, 4 Patrice Lumumba str., Building B, Floor 7,
252042 KIEV, Tel. +380 44 264 2776, Fax. +380 44 268 0461
United Kingdom: Philips Semiconductors Ltd., 276 Bath Road, Hayes,
MIDDLESEX UB3 5BX, Tel. +44 181 730 5000, Fax. +44 181 754 8421
United States: 811 East Arques Avenue, SUNNYVALE, CA 94088-3409,
Tel. +1 800 234 7381
Uruguay: see South America
Vietnam: see Singapore
Yugoslavia: PHILIPS, Trg N. Pasica 5/v, 11000 BEOGRAD,
Tel. +381 11 625 344, Fax.+381 11 635 777
For all other countries apply to: Philips Semiconductors, Marketing & Sales Communications,
Building BE-p, P.O. Box 218, 5600 MD EINDHOVEN, The Netherlands, Fax. +31 40 27 24825
Argentina: see South America
Australia: 34 Waterloo Road, NORTH RYDE, NSW 2113,
Tel. +61 2 9805 4455, Fax. +61 2 9805 4466
Austria: Computerstr. 6, A-1101 WIEN, P.O. Box 213,
Tel. +43 1 60 101, Fax. +43 1 60 101 1210
Belarus: Hotel Minsk Business Center, Bld. 3, r. 1211, Volodarski Str. 6,
220050 MINSK, Tel. +375 172 200 733, Fax. +375 172 200 773
Belgium: see The Netherlands
Brazil: see South America
Bulgaria: Philips Bulgaria Ltd., Energoproject, 15th floor,
51 James Bourchier Blvd., 1407 SOFIA,
Tel. +359 2 689 211, Fax. +359 2 689 102
Canada: PHILIPS SEMICONDUCTORS/COMPONENTS,
Tel. +1 800 234 7381
China/Hong Kong: 501 Hong Kong Industrial Technology Centre,
72 Tat Chee Avenue, Kowloon Tong, HONG KONG,
Tel. +852 2319 7888, Fax. +852 2319 7700
Colombia: see South America
Czech Republic: see Austria
Denmark: Prags Boulevard 80, PB 1919, DK-2300 COPENHAGEN S,
Tel. +45 32 88 2636, Fax. +45 31 57 1949
Finland: Sinikalliontie 3, FIN-02630 ESPOO,
Tel. +358 9 615800, Fax. +358 9 61580/xxx
France: 4 Rue du Port-aux-Vins, BP317, 92156 SURESNES Cedex,
Tel. +33 1 40 99 6161, Fax. +33 1 40 99 6427
Germany: Hammerbrookstraße 69, D-20097 HAMBURG,
Tel. +49 40 23 53 60, Fax. +49 40 23 536 300
Greece: No. 15, 25th March Street, GR 17778 TAVROS/ATHENS,
Tel. +30 1 4894 339/239, Fax. +30 1 4814 240
Hungary: see Austria
India: Philips INDIA Ltd, Shivsagar Estate, A Block, Dr. Annie Besant Rd.
Worli, MUMBAI 400 018, Tel. +91 22 4938 541, Fax. +91 22 4938 722
Indonesia: see Singapore
Ireland: Newstead, Clonskeagh, DUBLIN 14,
Tel. +353 1 7640 000, Fax. +353 1 7640 200
Israel: RAPAC Electronics, 7 Kehilat Saloniki St, TEL AVIV 61180,
Tel. +972 3 645 0444, Fax. +972 3 649 1007
Italy: PHILIPS SEMICONDUCTORS, Piazza IV Novembre 3,
20124 MILANO, Tel. +39 2 6752 2531, Fax. +39 2 6752 2557
Japan: Philips Bldg 13-37, Kohnan 2-chome, Minato-ku, TOKYO 108,
Tel. +81 3 3740 5130, Fax. +81 3 3740 5077
Korea: Philips House, 260-199 Itaewon-dong, Yongsan-ku, SEOUL,
Tel. +82 2 709 1412, Fax. +82 2 709 1415
Malaysia: No. 76 Jalan Universiti, 46200 PETALING JAYA, SELANGOR,
Tel. +60 3 750 5214, Fax. +60 3 757 4880
Mexico: 5900 Gateway East, Suite 200, EL PASO, TEXAS 79905,
Tel. +9-5 800 234 7381
Middle East: see Italy
Printed in The Netherlands 547027/1200/01/pp20 Date of release: 1997 Feb 20 Document order number: 9397 750 01725
Loading...
