ST20C2/C4 Core

Instruction Set

Reference Manual

72-TRN-273-01 January 1996

2/212



3/212



Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

1.1 Instruction name.............................................5

1.2 Code . . . . . . . . . . . . . . . . . . . . . . . . . . . ...........................5

1.3 Description .................................................6

1.4 Definition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

1.5 Error signals . . . . . . ..........................................7

1.6 Comments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.7 Notation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . .8

1.7.1 The processor state....................................8

1.7.2 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..8

1.7.3 Undefined values. . . . . . . . . . . . . . . . . . . . . .................9

1.7.4 Data types . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . .. . . . . . .9

1.7.5 Representing memory . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .9

1.7.6 On-chip peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

1.8 Block move registers. . . . . . . . . . . . . . . . .........................11

1.9 Constants . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

1.10 Operators used in the definitions . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .13

1.11 Functions . . . . . . . . . . . . . . . . . .. . . . . . . . .. . . . . . . . . . .. . . . . .. .. . .14

1.12 Conditions to instructions . . . . . . . . . . . . . . . . . . . . . . . . . . ...........14

2 Addressing and data representation...............................17

2.1 Word address and byte selector . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . .17

2.2 Ordering of information. . .. . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . .17

2.3 Signed integers and sign extension . . . . . . .. . . . . . . . . . . . . . . . . . . . . .18

3 Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

3.1 Machine registers . . . . . . . . . . . . . . . . . . . . . . . ....................20

3.1.1 Process state registers.. . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . .20

3.1.2 Other machine registers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

3.2 The process descriptor and its associated register fields. . . . . . . . . . . . .24

4 Instruction representation . . .....................................25

4.1 Instruction encoding . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . .25

4.1.1 An instruction component.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

4.1.2 The instruction data value and prefixing . . . . . . . . . . . . . . . . . . .25

4.1.3 Primary Instructions. . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . .26

4.1.4 Secondary instructions. . . . . . . . .. . . . .. . . . . . . . . . . . . . . . . . .27

4.1.5 Summary of encoding . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

4.2 Generating prefix sequences . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . .28

4.2.1 Prefixing a constant . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . .28

4.2.2 Evaluating minimal symbol offsets. . . . . . . . . . . . . . . . . . . . . . . .29

5 Instruction Set Reference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Contents

4/212



5/212



1 Introduction

This manual provides a summary and referenceto the ST20 instruction setfor C2 and
C4 cores. The instructions are listed in alphabetical order, one to a page. Descriptions
are presented in a standard format with the instruction mnemonic and full name of the
instruction at the top of the page,followed by these categories of information:

• Code: the instruction code;

• Description: a brief summary of the purpose and behavior of the instruction;

• Definition: a more complete description of the instruction, using the notation

described below in section 1.7;

• Error signals: a list of errors and other signals which can occur;

• Comments: a list of other important features of the instruction;

• See also: for some instructions, a cross reference is providedto other instruc-

tions with a related function.

These categories are explained in more detail below, using the

add

instruction as an

example.

1.1 Instruction name

The header at the top of each pageshows the instruction mnemonic and, on the right,
the full name of the instruction. For primary instructions the mnemonic is followed by
‘n’ to indicate the operand to the instruction; the same notation is used in the
description to showhow the operand is used.

1.2 Code

For secondary instructions the instruction ‘operation code’ is shown as the memory
code — the actual bytes, including any prefixes, which are stored in memory. The
value is givenas a sequence of bytesin hexadecimal, decoded left to right.The codes
are stored in memory in ‘little-endian’ format — with the first byte at the lowest
address.

For primary instructions the code stored in memory is determined partly by the value
of the operand to the instruction. In this case the op-code is shown as ‘Functionx’
wherexis the function code in the last byte of the instruction. For example,

adc(add

constant

) is shownas ‘Function 8’.

Example

The entry forthe

add

instruction is:

Code:F5



6/212

1.3 Description

The description section providesan indication of the purpose of the instruction as well
as a summary of the behavior. This includes details of the use of registers, whose
initial values may be used as parameters and into which results maybe stored.

Example

The

add

instruction contains the followingdescription:

Description: Add Areg and Breg, with checking for overflow.

1.4 Definition

The definitionsection provides a formal description of the behavior of the instruction.
The behavior is defined in terms of its effect on the state of the processor (i.e. the
values in registers and memory before and after the instruction has executed).

The effects of the instruction on registers, etc. are given as relationships of the
following form:

register′←

expression involvingregisters, etc.

Primed names (e.g. Areg′ ) represent values after instruction execution, while
unprimed names represent values when instruction execution starts. For example,
Areg represents the value in Areg before the execution of the instruction while Areg′
represents the value in Areg afterwards. So, the example above states that the
register on the left hand side becomes equal to the value of the expression on the
right hand side after the instruction has been executed.

The description is written with the main function of the instruction stated first(e.g. the
main function of the

add

instruction is to put the sum of Areg and Breg into Areg).
This is followedby the other effectsof the instruction (e.g. popping thestack). There is
no temporal ordering implied by the order in which the statements are written.

The notation is described more fully in section 1.7.

Example

The

add

instruction contains the followingdescription:

Definition:

Areg′←Breg +

checked

Areg

Breg′←Creg
Creg′←

undefined

This says that the integer stack is popped and Areg assigned the sum of the values
that were initially in Breg and Areg. After the instruction has executedBreg contains
the value that wasoriginally in Creg, and Creg is undefined.

7/212



1.5 Error signals

This section lists the errors and other exceptional conditions that can be signalled by
the instruction. This only indicates the error signal, not the action that willbe takenby
the processor - this will depend on the trap enable bits which are set, the value in the
trap handler location, etc.

The order of the error signals listed is significantin that if a particular error is signalled
then errors later in the list may not be signalled. The errors that maybe signalled are
as follows:

IntegerError

indicates a variety of general errors such as a valueout of range.

IntegerOverflow

indicates that an overflowoccurred during an integer arithme-

tic operation.

LoadTrap

indicates that an attempt has been madeto loada newtrap handler.
This provides a basic mechanism fora supervisor kernel to manage user proc­esses installing trap handlers.

StoreTrap

, analogous to

LoadTrap

, indicates that an attempt has been made to
store a traphandler so that it can be inspected. Again this allows a supervisor
kernel to manage the trap system used byuser processes.

Example

As an example,the error signals listed forthe

add

instruction are:

Error signals:

IntegerOverflow

can be signalled by +

checked

So,the only error that can be causedby

add

is an integer overflowduring the addition

of Areg and Breg.

1.6 Comments

This section is used for listing other information about the instructions that may be of
interest. Firstly, there is an indication of the type ofthe instruction.These are:

“Primary instruction” — indicates one of the 13 functions which are directly
encoded in a single byte instruction.

“Secondary instruction” — indicates aninstruction which is encoded using

opr

.

Then there is information concerning the scheduling of the process:

“Instruction is a descheduling point” — a process maybe descheduled after
executing this instruction.

“Instruction is a timeslicing point” — a process maybe timesliced after execut­ing this instruction.

“Instruction is interruptible” — the execution of this instruction maybe inter­rupted bya high priority process.



8/212

This section also describes any situations where the operation of the instruction is
undefinedor invalid.

Example

Using the

add

instruction as an example again, the comments listed are:

Comments:

Secondary instruction.

This says that

add

is a secondaryinstruction.

1.7 Notation

The following sections give a full description of the notation used in the ‘definition’
section ofthe instruction descriptions.

1.7.1 The processorstate
The processor state consists of the registers (mainly Areg, Breg, Creg, Iptr, and

Wptr), the contents of memory, and various flags and special registers (such as the

error flags,process queue pointers,clock registers, etc.).
The Wptr register is used for the address of the workspace of the current process.

This address is word aligned and therefore has the two least significant bits set to
zero.Wdesc is used for the ‘process descriptor’— the value that is held in memory as
an identifier of the process when the process is not being executed. This value is
composed of the top 31 bits of the Wptr plus the process priority stored in bit 0 of the
word. Bit 0 is set to 0 for high priority processes and 1 forlow priority processes. Bit 1
of the process descriptor is always 0.

1.7.2 General

The instruction descriptions are not intended to describe the way the instructions are
implemented, but only their effect on the state of the processor.So, for example, the
blockmove instructions are described in terms ofa sequence of

byte

reads and writes

even though the instructions are implemented to perform the minimum number of

word

reads andwrites.

Comments (in

italics

) are used to both clarify the description and to describe actions

or values that cannot easily be represented by the notation used here; e.g.

start next

process

. These actions may be performed in another subsystem in the device, such
as the communications subsystem, and so any changes to machine state are not
necessarily completely synchronized with the execution of the instruction (as the
different subsystems work independently and in parallel).

Ellipses are used to show a range of values; e.g. ‘i = 0..31’ means that i has
values from 0 to 31, inclusive.

9/212



Subscripts are used to indicate particular bits in aword; e.g. Aregifor bit i of Areg;and
Areg

0..7

forthe least significantbyte of Areg. Note that bit 0 is the least significantbit in

a word, and bit 31 is the most significantbit.
Generally, if the description does not mention the state of a register or memory

location after the instruction, then the value will not be changed by the instruction.
One exception to this general rule is Iptr, which is assigned the address of the next

instruction in the code

before

every instruction executionstarts. The Iptr is included in

the description only when it is

directly

affected by the instruction (e.g. in the

jump

instruction). In these cases the address of the next instruction is indicated by the
comment “

next instruction

”.

Scheduling operations

Some registers, such as the timer and scheduling list pointers and some special
workspace locations,can be changed at anytime by scheduling operations.Changes
to these are included in the description only when they are

directly

caused by the
instruction, and not just as an effect of any scheduling operation which might take
place.

1.7.3 Undefined values

Many instructions leavethe contents of a register or memory location in an undefined
state. This means that thevalue of the location may be changed by the instruction, but
the new value cannot be easily defined,or isnot a meaningful result of the instruction.
For example, when the integer stackis popped, Creg becomes undefined,i.e. it does
not contain any meaningful data. An undefined value is represented by the name

undefined

. The values of registers which become undefined as a result of executing
an instruction are implementation dependent and are not guaranteed to be the same
on different members of the ST20 familyof processors.

1.7.4 Data types

The instruction set includes operations on four sizes of data: 8, 16, 32 and 64-bit
objects. 8-bit and 16-bit data can represent signed or unsigned integers; 32-bit data
can represent addresses, signed or unsigned integers, or single length floating point
numbers; and 64-bit data can represent signed orunsigned integers,or double length
floating point values. Normally it is clear from the context (e.g. from the operators
used) whether a particular object represents a signed, unsigned or floating point
number.A subscripted label is added (e.g.Areg

unsigned

) to clarify where necessary.

1.7.5 Representing memory

The memory isrepresented by arrays of each data type.These areindexedby a value
representing a byte address. Access to the four data types is represented in the
instruction descriptions in the following way:

byte[

address

]references a byte in memory at the givenaddress

sixteen[

address

]references a 16-bit object in memory



10/212

word[

address

]references a 32-bit word in memory

For all of these,the state of the machine referenced is that

before

the instruction if the

function is used without a prime (e.g. word[]), and that

after

the instruction if the

function is used with a prime (e.g.word′[]).
For example, writing a value given by an expression,

expr

, to the word in memory at

address

addr

is represented by:

word′[

addr

] ←

expr

and reading a wordfrom a memory location is achievedby:

Areg′←word[

addr

]

Writing to memory in any of these wayswill updatethe contents of memory,and these
updates will be consistently visible to the other representations of the memory, e.g.
writing a byte at address 0 will modify the least significantbyte of the word at address

0.
Reading and writing in this way cannot be used to access on-chip peripherals.

Reading or writing to memory addresses between

PeripheralStart

and

PeripheralEnd

will have undefinedeffects.

Data alignment

Each of these data items have restrictions on their alignment in memory.Byte values
can be accessed at any byte address, i.e. they are byte aligned. 16-bit objects can
only be accessed at even byte addresses, i.e. the least significant bit of the address
must be 0. 32-bit and 64-bit objects must be word aligned, i.e. the 2 least significant
bits of the address must be zero.

Address calculation

An address identifiesa particular bytein memory.Addresses are frequently calculated
from a baseaddress and an offset. For different instructions the offset maybe givenin
units of bytes, words or double words depending on the data type being accessed. In
order to calculate the address of the data, the offset must be converted to a byte offset
before being added to the base address.This is done by multiplying the offset by the
number of bytes in the particular units being used. So, for example, a word offset is
converted to a byte offset by multiplying it by the number of bytesin a word (4 in the
case of the ST20).

As there are many accesses to memory at wordoffsets, a shorthand notation is used
to represent the calculation of a word address. The notation

register@x

is used to

represent an address which is offset byxwords (4xbytes) from

register

. For example,

in the specification of

load non-local

there is:

Areg′← word[Areg @ n]

Here, Areg is loaded with the contents of the word that is n words from the address
pointed to byAreg (i.e.Areg + 4n).

In all cases, if the givenbase address has the correct alignment then any offset used
will also givea correctly aligned address.

11/212



1.7.6 On-chip peripherals

On-chip peripherals may have memory-mapped registers in the address range

PeripheralStart

to

PeripheralEnd

. Access to these registers is represented in the

following way:

PeripheralByte[

address

] references an 8-bit peripheral register

PeripheralSixteen[

address

] references a 16-bit peripheral register

PeripheralWord[

address

] references a 32-bit peripheral register

For all of these, the state of the peripheral referenced is that

before

the instruction if

the function is used without a prime (e.g. PeripheralWord[]), and that

after

the

instruction if the function is used with a prime (e.g. PeripheralWord′[]).
For example, writing a value given by an expression,

expr

, to the register at address

addr

is represented by:

PeripheralWord′[

addr

] ←

expr

and reading a wordfrom a peripheral is achieved by:

Areg′←PeripheralWord[

addr

]

1.8 Block move registers

A group of registers is used in the implementation of blockmoves. These are referred
to as the ‘block move registers’ and include

Move2dBlockLength,Move2dDestStride

,

and

Move2dSourceStride

.

1.9 Constants

A number of data structures have been defined in this book. Each comprises a
number of data slots that are referenced by name in the text and the following
instructions descriptions.

These data structures is listed in Table1.2 to Table1.4.

word offset slot name purpose

0 pw.Temp slot used by some instructions forstoring temporary values

-1 pw.Iptr the instruction pointer ofa descheduled process

-2 pw.Link the address of the workspace of the next process in scheduling list

-3 pw.Pointer saved pointer to communication data area

-3 pw.State savedalternative state

-4 pw.TLink address of the workspace of the next process on the timer list

-5 pw.Time time that a process on a timer list is waiting for

Table1.1 Process workspacedata structure



12/212

In addition, a number of constants are used to identify word length related values etc.;
These are listed in Table 1.5 .

A number of values are used bythe ST20 to indicate the state of a process and other
conditions. These are listed in Table 1.6.

word offset slot name purpose

0 le.Index contains the loop control variable
1 le.Count contains number of iterationsleft to perform

Table 1.2 Loop end data structure

word offset slot name purpose

1 pp.Count contains unsigned count of parallel processes
0 pp.IptrSucc contains pointer to firstinstruction of successor process

Table 1.3 Parallelprocess data structure

word offset slot name purpose

2 s.Back back of waiting queue
1 s.Front front of waitingqueue
0 s.Count number of extraprocesses that the semaphore will allow to continue

running on a

wait

request

Table 1.4 Semaphore data structure

Name Value Meaning

BitsPerByte

8 The number of bits in a byte.

BitsPerWord

32 The number of bits in a word.

ByteSelectMask

#00000003 Used to select the byte select bits of an address.

WordSelectMask

#FFFFFFFC Used to select the byte select bits of an address.

BytesPerWord

4 The number of bytes in a word.

MostNeg

#80000000 The most negative integer value.

MostPos

#7FFFFFFF The most positive signed integer value.

MostPosUnsigned

#FFFFFFFF The most positive unsigned integer value.

PeripheralStart

#20000000 The lowest address reserved for memory-mapped on-

chip peripherals.

PeripheralEnd

#3FFFFFFF The highest address reserved for memory-mapped on-

chip peripherals.

Table 1.5 Constants used in the instructiondescriptions

13/212



Product identity values

These are values returned by the

lddevid

and

ldprodid

instructions. For specific

product ids in the ST20 family refer to SGS-THOMSON.

1.10 Operators used in the definitions

Modulo operators

Arithmetic on addresses is done using

modulo

arithmetic — i.e. there is no checking
for errors and, if the calculation overflows, the result ‘wraps around’ the range of
values representable in the word length of the processor — e.g. adding 1 to the
address at the top of the address map produces the address of the byte at the bottom
of the address map. There is also a number of instructions for performing modulo
arithmetic, such as

sum,prod

, etc. These operators are represented by the symbols

‘+’, ‘−’, etc.

Name Value Meaning

DeviceId

Depends on pro­cessor type. See
below.

A value used to identify the type and revision of processor.
Returned by the

ldprodid

and

lddevid

instructions.

Disabling.p MostNeg

+ #03

#80000003

Stored in the pw.State location while an alternative is being
disabled.

Enabling.p MostNeg

+ #01

#80000001

Stored in the pw.State location while an alternative is being
enabled.

false

0 The boolean value ‘false’.

NoneSelected.o

-1

#FFFFFFFF

Storedinthepw.Tempslot of a process’workspacewhile no
branch of an alternative has yet been selected during the
waiting and disabling phases.

NotProcess.p MostNeg

#80000000

Used,wherevera process descriptor isexpected, to indicate
that there is no process.

Ready.p MostNeg

+ #03

#80000003

Stored inthe pw.Statelocation during the enablingphase of
an alternative,to indicate that a guard is ready.

TimeNotSet.p MostNeg

+ #02

#80000002

Stored in pw.TLink location during enablingof atimer alter­native after a time to wait for has been encountered.

TimeSet.p MostNeg

+ #01

#80000001

Stored in pw.TLink location during enablingof atimer alter­native after a time to wait for has been encountered.

true

1 The boolean value ‘true’.

Waiting.p MostNeg

+ #02

#80000002

Stored inthepw.Statelocation by

altwt

and

taltwt

toindicate

that the alternative is waiting.

HighPriority

0 High priority

LowPriority

1 Low priority

Table 1.6 Constants used within the ST20



14/212

Error conditions

Any errors that can occur in instructions which are defined in terms of the modulo
operators are indicated explicitly in the instruction description. For example the

div

(

divide

) instruction indicates the cases that can cause overflow,independently of the

actual division:

if (Areg = 0) or ((Breg = MostNeg) and (Areg = -1))
{

Areg′←

undefined

IntegerOverflow

}

else

Areg′← Breg /Areg

Breg′← Creg
Creg′←

undefined

Checked operators

To simplify the description of

checked

arithmetic, the operators ‘+

checked

’, ‘−

checked

’,

etc. are used to indicate operations that perform checked arithmetic on signed
integers. These operators signal an

IntegerOverflow

if an overflow,divide by zero, or
other arithmetic error occurs. If no trap is taken, the operators also deliver the modulo
result.

A number of comparison operators are also used and there are versions of some of
these that treat the operands as unsigned integers. A full list of the operators used in
the instruction definitions is given in Table 1.7.

1.11 Functions

Type conversions

The following function is used to indicate a type conversion:

unsign(x) causes the bit-pattern in x to beinterpreted as an unsigned integer.

1.12 Conditions to instructions

In many cases, the action of an instruction depends on the current state of the
processor. In these cases the conditions are shownby an if clause; this can take one
of the following forms:

• if

condition

statement

• if

condition

statement

else

statement

15/212



• if

condition

statement

else if

condition

statement

else

statement

These conditions can be nested. Braces, {}, are used to group statements which are
dependent on a condition. For example, thecj(

conditional jump

) instruction contains

the following lines:

if (Areg = 0)

IptrReg′←

next instruction

+ n

Symbol Meaning

Integer arithmetic with overflow checking

+

checked

−

checked

×

checked

Add, subtract, and multiply of signed integers. If the computation overflows an

IntegerOverflow

is signalled and the result of theoperation is truncated to the

word length.

Unchecked (modulo) integer arithmetic

+

−

×

/

rem

Integer add, subtract, multiply, divide and remainder. If the computation over­flowsthe result of the operationis truncated to the word length. If a divide or
remainder byzero occurs theresult of the operationis undefined.Noerrorsare
signalled. The operator ‘−’ is also used as a monadicoperator.The sign of the
remainder is the same as the sign of the dividend.

Signed comparison operators

<
>

≤
≥

=

≠

Comparisons of signed integer and floatingpoint values: ‘less than’, ‘greater
than’, ‘less than or equal’, ‘greater than or equal’, ‘equal’ and ‘not equal’.

Unsigned comparison operators

<

unsigned

>

unsigned

≥

unsigned

after

Comparisons ofunsigned integer values:‘less than’,‘greaterthan’, ‘greaterthan
or equal’, and ‘after’ (for comparison of times).

Logical bitwise operations

∼ (or BITNOT)

∧ (or BITAND)

∨ (or BITOR)

⊗ (or BITXOR)

>>
<<

‘Not’ (1’scomplement), ‘and’, ‘or’, ‘exclusive or’, and logical left and right shift
operations on bits in words.

Boolean operators

not

and

or

Boolean combination in conditionals.

Table 1.7 Operators used in the instruction descriptions



16/212

else

{

IptrReg′←

next instruction

Areg′← Breg
Breg′← Creg
Creg′←

undefined

}

This says that if the value in Areg is zero, then the jump is taken (the instruction
operand, n, is added to the instruction pointer), otherwise the stack is popped and
execution continues with the next instruction.

17/212



2 Addressing and data representation

The ST20 processor is a 32-bit word machine, with byte addressing and a 4 Gbyte
address space. This chapter explains how data is loaded from and stored into that
address space, explains how signed arithmetic is represented, and defines the
arithmetic significance of ordering of data items.

2.1 Word address and byte selector

A machine address is a single word of data which identifies a byte in memory - i.e. a
byte address. It comprises two parts, a word address and a byte selector. The byte
selector occupies the two least significantbits of the word; the wordaddress the thirty
most significant bits. An address is treated as a signed value, the range of which
starts at the most negative integer and continues, through zero, to the most positive
integer. This enables the standard comparison functions to be used on pointer
(address) values in the same waythat theyare used on numerical values.

Certain values can never be used as pointers because they represent reserved
addresses at the bottom of memory space. They are reserved for use by the
processor and initialization. In this text,names are used to represent these and other
values (e.g.

NotProcess.p,Disabling.p

). A full list of names and values of constants

used in this book is given in section1.9.

2.2 Ordering of information

The ST20 is ‘little-endian’ — i.e. less significant data is always held in lower
addresses. This applies to bits in bytes,bytes in words and words in memory.Hence,
in a word of data representing an integer, one byte is more significant than another if
its byte selector is the larger of the two. Figure 2.1 shows the ordering of bytes in
words and memory for the ST20. Note that this ordering is compatible with Intel
processors, but not Motorola or SPARC.

Figure 2.1 Bytes in memory and words

words (wordlength is 32 bits)

X

is a word-aligned byte address

X+n

is the bytenbytes past

X

X+7
X+6
X+5
X+4
X+3
X+2
X+1
X+0

Memory

(bytes)

X+3 X+2 X+1 X+0

MSB LSB

31 24 23 16 15 8 7 0

X+7 X+6 X+5 X+4

MSB LSB

31 24 23 16 15 8 7 0



18/212

Most instructions that involvefetching data from or storing data into memory,use word
aligned addresses (i.e. bits 1 and 0 are set to 0) and load or store four contiguous
bytes. However,there are some instructions that can manipulate part of the bit pattern
in a word,and a fewthat use doublewords.

A data item that is represented in two contiguous bytes, is referred to as a 16-bit
object. This can be stored, either in the least significant 16-bits of a word location or in
the most significant 16 bits, hence addresses of such locations are 16-bit aligned (i.e.
bit 0 is set to 0).

A data item that is represented in two contiguous words is referred to as a 64-bit
object or a doubleword.

Similarly, a data item represented in a single byte is sometimes referredto as an 8-bit
object.

2.3 Signed integers and sign extension

A signed integer is stored in twos-complement format and may be represented by an
N-bit object. Most commonly a signed integer is represented by a single word (32-bit
object), but as explained, it may be stored, for example, in a 64-bit object, a 16-bit
object, or an8-bit object. In each of theseformats,all the bits within the object contain
useful information.

Consider the example shown in Figure 2.2, which showshowthe value-10 is stored in
a 32-bit register,firstly as an 8-bit object and secondly asa 32-bit object. Observe that
bits 31 to 8 are meaningful for a 32-bit object but not for an 8-bit object. Thesebits are
set to 1 in the 32-bit object to preserve the negative sign of the integer being
represented.

Figure 2.2 Storinga signed integer in different length objects

11110110these bit values not related to integer value

07831bit position

11110110

07831bit position

11 1...

signed integer value (-10) stored as an 8-bit object (byte)

signed integer value (-10) stored as a 32-bit object(word)

19/212



The length of the object that stores a signed integer can be increased (i.e. the object
size can be increased). This operation is knownas ‘sign extension’. The extra bits that
are allocated for the larger object, are meaningful to the value of the signed integer.
They must therefore be set to the appropriate value. The value forall these extrabits
is in fact the same as the value of the most significant bit - i.e. the sign bit - of the
smaller object. The ST20 providesinstructions that sign extend byte and half-word to
word, and 32 bits to 64 bits.



20/212

3 Registers

3.1 Machine registers

This section introduces the ST20 processor registers that are visible to the
programmer. Firstly the set of registers known as state registers are presented and
discussed. These fully define the state of the executing process. Secondly the other
registers of interest to the programmer,are presented.

3.1.1 Process state registers

The state of a executing process at any instant is defined by the contents of the
machine registers listed in Table 3.1. The ‘register’ column gives the abbreviated
name of the register. The ‘full name / description’ column provides the full textual
name which is usually used when referencing a register in this manual; and where
unclear, a brief description of the information contained in this register.

In addition there is a small number of registers used to implement blockmoves.

Status register

The Status register contains status bits which describe the current state of the
process and any errors which may have occurred. The contents of the Status register
are shown in Table3.2.

‘Shadow’ registers

When a high priority process interruptsa lowpriority process, the state of the currently
executing process needs to be saved. For this purpose, two sets of process state
registers are provided,one each for high and low priority. On interrupt, the processor
switches to using the high priority registers, leaving the low priority registers to
preservethe lowpriority state.

A high priority process may manipulate the low priority ‘shadow’ registers with the
instructions

ldshadow

and

stshadow

. In the definitions of these instructions, the

process state registers havea subscript (e.g. Areg[LowPriority]) indicating the priority.

register full name / description process modes
Status status register
Wptr workspace pointer - contains the address of theworkspace of the currently execut-

ing process

Iptr instruction pointer register - pointer to nextinstruction to be executed
Areg integer stack register A
Breg integer stack register B
Creg integer stack register C

Table 3.1 Process state registers

21/212



bit number full name / description

0 breakpoint trap status bit
1 integer error trap status bit
2 integer overflow trap status bit
3 illegal opcode trap status bit
4 load trap trap status bit
5 store trap trap status bit
6 internal channel trap status bit
7 external channel trap status bit
8 timer trap status bit

9 timeslice trap status bit
10 run trap status bit
11 signal trap status bit
12 process interrupt trapstatus bit
13 queue empty trap status bit
14 reserved
15 causeerror status bit

17-16 Scheduler trap return priority status bits:

00 - high priority
01 - lowpriority

19-18 Trap group status bits:

00 - Breakpoint
01 - Error
10 - System
11 - Scheduler

20 timeslice enable bit

25-21 reserved
30-26 Interrupted operation status bits:

00000 - None
00001 -

move

00010 -

devmove

00011 -

move2dall

00100 -

move2dzero

00101 -

move2dnonzero

00110 -

in

00111 -

out

01000 -

tin

01001 -

tin

restart

01010 -

taltwt

01011 -

taltwt

restart

01100 -

dist

01101 -

dist

restart

01110 -

enbc

01111 -

disc

10000 -

resetch

31 status valid

Table 3.2 Status register



22/212

If the process state registers are referred to without subscriptsthen the current priority
is implied.

3.1.2 Other machine registers

There are several other registers which the programmershould know about, but which
are not part of the process state. These are presented in Table 3.3.

Enables register

The Enables register contains:

•

TrapEnables

bits (0..15) which can be used to control the taking of traps;

•

GlobalInterruptEnables

bits (16..31) which are used to control timeslicing and

interruptibility. These are normally set to 1.

Bits of

TrapEnables

may be set using the

trapenb

instruction and cleared using

trapdis

. Bits of

GlobalInterruptEnables

may be set using the instruction

gintenb

and

disabled using

gintdis

.

The contents of the Enables register are shown in Table 3.4.

ClockEnables

ClockEnables

is a pair of flags which enable the timers ClockReg to tick. Bit zero of

ClockEnables

controls ClockReg[0] and bit 1 controls ClockReg[1]. In each case,

register full name / description
ProcQueueFPtr[0] high priority front pointer register- contains pointer to first process on the high

priority scheduling list

ProcQueueFPtr[1] low priority front pointer register - contains pointer to firstprocess onthe low

priority scheduling list

ProcQueueBPtr[0] high priority back pointer register - contains pointer to last process on the high

priority scheduling list

ProcQueueBPtr[1] low priority back pointer register - contains pointer to last process on the low

priority scheduling list

ClockReg[0] high priority clock register - contains current value of high priority clock
ClockReg[1] low priority clock register - contains current value of low priority clock
TptrReg[0] high priority timer list pointer register - contains pointer to the firstprocess on

the high priority timer list

TptrReg[1] low priority timerlistpointerregister-contains pointerto the firstprocess on the

low priority timer list

TnextReg[0] high priority alarm register - contains the time of the first process on the high

priority timer queue

TnextReg[1] low priority alarm register - contains the time of the first process on thelow

priority timer queue

Enables trap and globalinterrupt enables register

Table 3.3 Other machine registers

23/212



the timer will tick if the

ClockEnables

bit is set to1.

ClockEnables

can be set using the

clockenb

instruction and cleared using

clockdis

.

Error flags

The other machine flags referred to in the instruction definitionsare listed in Table 3.4.

ErrorFlag

is a pair of flags, one for each priority,set by the processor if an integer error
or integer overflow error occurs and the corresponding trap is not enabled. The
processor will immediately halt if the

HaltOnError

flag is also set, or will continue

bit number full name / description

0 breakpoint trap enable bit
1 integer error trap enable bit
2 integer overflow trap enable bit
3 illegal opcode trap enable bit
4 load trap trap enable bit
5 store trap trap enablebit
6 internal channel trap enable bit
7 external channel trap enable bit
8 timer trap enable bit

9 timeslice trap enable bit
10 run trap enable bit
11 signal trap enable bit
12 process interrupt trapenable bit
13 queue empty trap enable bit

15-14 reserved

16 low priority processinterrupt enablebit
17 low priority timesliceenable bit
18 low priority externaleventenable bit
19 low priority timeralarm enable bit
20 high priority process interrupt enable bit
21 high priority timeslice enablebit
22 high priority external event enable bit
23 high priority timer alarm enable bit

31-24 reserved

Table 3.4 Enables register

flag name description

ErrorFlag

Untrapped arithmetic error flags

HaltOnErrorFlag

Halt the processor if the

ErrorFlag

is set

Table 3.5 Error flags



24/212

otherwise. The

ErrorFlag

s may also be set by the

seterr

instruction or tested and

cleared by the

testerr

instruction. The

stoperr

instruction stops the current process if

the

ErrorFlag

is set. The low priority

ErrorFlag

is copied to the high priority when the

processor switches from low to high priority. The

HaltOnError

flag may be set by the

sethalterr

instruction, cleared by

clrhalterr

and tested by

testhalterr

.

3.2 The process descriptor and its associated register fields

In order to identify a process completely it is necessary to know: its workspace
address (in which the byte selector is always 0), and its priority (high or low). This
information is contained in the process descriptor. The workspace address of the
currently executing process is held in the workspace pointer register (Wptr) and the
priority is held in the flag Priority.

Wptr points to the current process workspace, which is always word-aligned. Priority
is the priority of the currently executing process where the value 1 indicates low
priority and 0 indicates high priority.

The process descriptor is formed from a pointer to the process workspace or-ed with
the priority flag at bit 0. Bit 1 is always set to 0.

Wdesc is defined so that the following invariants are obeyed:

Wptr = Wdesc ∧

WordSelectMask

Priority = Wdesc ∧ 1

Figure 3.1 Constituents of a process descriptor

Workspace address

21 0

Priority0

31

25/212



4 Instruction representation

The instruction encoding is designed so thatthe most commonly executedinstructions
occupy the least number of bytes. This chapter describes the encoding mechanism
and explains how it achievesthis.

A sequence of single byte

instruction components

is used to encode an instruction.
The ST20 interprets this sequence at the instruction fetch stage of execution. Most
users (working at the level of microprocessor assembly language or high-level
languages) need not be aware of the existence of instruction components and do not
need to think about the encoding. The first section (4.1) has been included to provide
a background.The following section (4.2) need only concern the reader that wants to
implement a code generator.

4.1 Instruction encoding

4.1.1 An instruction component

Each instruction component is one byte long, and is divided into two 4-bit parts. The
four most significant bits of the byte are a

function code

, and the four least significant

bits are used to build an

instruction data value

as shown in Figure 4.1.

Figure 4.1 Instruction format

The representation provides for sixteen instruction components (one for each
function), each with a data field ranging from 0 to15.

There are three categories of instruction component. Firstly there are those that
specify the instruction directly in the function field. These are used to implement

primary instructions

. Secondly there are the instruction components that are used to

extend the instruction data value - this process of extension is referred to as

prefixing

.

Thirdly there is the instruction component

operate(opr

) which specifies the instruction

indirectly using the

instruction data value.opr

is used to implement

secondary

instructions

.

4.1.2 The instruction data value and prefixing

The data fieldof an instruction component is used to create an instructiondata value’
Primary instructions interpret the instruction data value as the operand of the
instruction. Secondary instructions interpret it as the operation code forthe instruction
itself.

function code data

0347



26/212

The instruction data value is asigned integer that is represented as a 32-bitword. For
each newinstruction sequence, the initial valueof this integer is zero.Since there are
only 4 bits in the data field of a single instruction component, it is only possible for
most instruction components to initially assign an instruction data value in the range 0
to 15. However two instruction components are used to extend the range of the
instruction data value. Hence one or more prefixing components may be needed to
create the correct instruction data value. These are shown in Table 4.1 and explained
below.

All instruction components initially load the four data bits into the least significant four
bits of the instruction data value.

pfix

loads its fourdata bits into the instruction data value,and then shifts this value up

four places.

nfix

is similar, except that it complements the instruction data value

†

before shifting it up. Consequently, a sequence of one or more prefixes can be
included to extend the value.Instruction data values in the range -256 to 255 can be
represented using one prefixinstruction.

When the processor encounters an instruction component other than

pfix

or

nfix

,it
loads the data field into the instruction data value. The instruction encoding is now
complete and the instruction can be executed. When the processor is ready to fetch
the next instruction component, it starts to create a new instruction data value.

4.1.3 Primary Instructions

Research has shown that computers spend most of the time executing instructions
such as: instructions to load and store from a small number of ‘local’ variables,
instructions to add and compare with small constants, and instructions to jump to or
call other parts of the program. For efficiency therefore, these are encoded directly as
primary instructions using the function field of an instruction component.

Thirteen of the instruction components are used to encode the most important
operations performed by any computer executing a high level language. These are
used (in conjunction with zeroor more prefixes) to implement the primary instructions.
Primary instructions interpret the instruction data value as an operand for the
instruction. The mnemonic for a primary instruction will therefore normally include a
this operand - n - when referenced.

The mnemonics and names for the primary instructions are listed in Table4.2.

mnemonic name

pfix

n prefix

nfix

n negative prefix

Table 4.1 Prefixinginstruction components

mnemonic name

adc

n add constant

Table 4.2 Primary instructions

† Note that it inverts

all

32 bits of the instruction data value.

27/212



4.1.4 Secondary instructions

The ST20 encodes all other instructions (secondary instructions) indirectly using the
instruction data value.

The instruction component

opr

causes the instruction data value to be interpreted as
the operation code of the instruction to be executed. This selects an operation to be
performed on the valuesheld in the integer stack.This allows a further 16 operations
to be encoded in a singlebyte instruction. Howeverthe prefix instructions can be used
to extend the instruction data value, allowing any number of operations to be
performed.

Secondary instructions do not have an operand specified by the encoding, because
the instruction data value has been used to specify the operation.

To ensure that programs are represented as compactly as possible,the operations are
encoded in such a way that the most frequent secondary instructions are represented
without usingprefix instructions.

4.1.5 Summary of encoding

The encoding mechanism has important consequences.

• Firstly, it simplifies language compilation, by providing a completely uniform
way of allowing a primary instruction to takean operand of anysize up to the
processor word-length.

• Secondly,it allowsthese operands to be represented ina form independent of

ajw

n adjust workspace

call

n call

cj

n conditional jump

eqc

n equals constant

j

n jump

ldc

n load constant

ldl

n load local

ldlp

n load local pointer

ldnl

n load non-local

ldnlp

n load non-local pointer

stl

n store local

stn

l n store non-local

mnemonic name

opr

operate

Table 4.3 Operate instruction

mnemonic name

Table 4.2 Primary instructions



28/212

the word-lengthof the processor.

• Thirdly,it enablesany number of secondary instructions to be implemented.

The following provides some simple examples of encoding:

• The instruction

ldc

17 is encoded with the sequence:

pfix1;ldc

1

• The instruction

add

is encoded by:

opr

5

• The instruction

and

is encoded by:

opr 70

which isin turn encoded with the sequence:

pfix4;opr

6

To aid clarity and brevity, prefix sequences and the use of

opr

are not explicitlyshown
in this guide. Each instruction is represented by a mnemonic, and for primary
instructions an item of data, which stands for the appropriate instruction component
sequence. Hence in the above examples, these are just shown as:

ldc 17,add

, and

and

. (Also, where appropriate, an expression may be placed in a code sequence to

represent the code needed toevaluatethat expression.

4.2 Generating prefix sequences

Prefixing is intended to be performed by a compiler or assembler.Prefixing by hand is
not advised.

Normally a value can be loaded into the instruction data valueby a variety of different
prefix sequences . It is important to use the shortest possible sequence as this
enhances both code compaction and executionspeed. The best method of optimizing
object code so as to minimize the number of prefix instructions needed is shown
below.

4.2.1 Prefixinga constant

The algorithm to generate a constant instruction data valueefor a function

op

is

described bythe following recursive function.

prefix(op,e ) = IF

e<16 AND e 0

op( e )

e 16

prefix(pfix, e

>>

4 ); op( e∧#F)

e<0

prefix(nfix, (~e)

>>

4 ); op( e∧#F)

where

( op,e )

is the instruction component with function codeopand data field

e, ~

is a bitwise NOT, and >> is a logical right shift.

29/212



4.2.2 Evaluating minimal symbol offsets

Several primary instructions have an operand that is an offset between the current
value of the instruction pointer and some other part of the code. Generating the
optimal prefix sequence to create the instruction data value for one of these
instructions is more complicated. This is because two, or more, instructions with offset
operands can interlock so that the minimal prefix sequences for each instruction is
dependent on the prefixingsequences used for theothers.

For example consider the interlocking jumps below which can be prefixed in two
distinct ways. The instructionsjandcjare respectively

jump

and

conditional jump

.

These are explained in more detail later.The sequence:

cj

+16;j-257

can be coded as

pfix1;cj0;pfix1;nfix0;j

15

but this can be optimizedto be

cj

15;

nfix

15;j1

which is the encoding for the sequence

cj

+15;j-255

This is because when the two offsets are reduced, their prefixing sequences take 1
byte less so that the two interlocking jumps will still transfer control to the same
instructions as before.This compaction of non-optimal prefix sequences is difficult to
perform and a better method is to slowly build up the prefix sequences so that the
optimal solutionis achieved.The following algorithm performs this.

1 Associate with eachjump instruction or offset loadan ‘estimate’ ofthe number

of bytes required to code it and initially set them all to 0.

2 Evaluate all jump and load offsets under the current assumptions of the sizeof

prefixsequences to the jumps and offset loads

3 For each jump or load offset set the number of bytes needed to the numberin

the shortest sequence that will build up the current offset.

†

4 If any change was made to the number of bytesrequired then go backto 2 oth-

erwise the code has reached astable state.
The stable state that is achievedwill be the optimal state.
Steps 2 and 3 can be combined so that the number of bytes required by each jump is

updated as the offset is calculated. This does mean that if an estimate is increased
then some previously calculated offsets may have been invalidated, but step 4 forces
another loop to be performed when those offsets can be corrected.

By initially setting the estimated size of offsets to zero, all jumps whose destination is
the next instruction are optimized out.

† Where thecode being analyzed hasalignment directives, then it ispossible that this algorithm will notreach a stable state. One
solution to this, is to allow the algorithm to increase the instruction size but not allow it to reduce the size. This is achieved by
modifying stage 3 to choose the larger of: the currently calculated length, and the previously calculated length. This approach
does not always lead to minimal sizedcode, but it guarantees termination of the algorithm.



30/212

Knowledge of the structure of code generated by the compiler allows this process to
be performed on individual blocks of code rather than on the whole program. For
example it is often possible to optimize the prefixing in the code for the sub­components ofa programminglanguage constructbefore the code for the construct is
optimized. When optimizing the construct it is known that the sub-components are
already optimal so they can be considered as an unshrinkableblock of code.

This algorithm may not be efficient for long sections of code whose underlying
structure is not known. If no knowledge of the structure is available (e.g. in an
assembler), all the code must be processed at once. In this case a code shrinking
algorithm where in step one the initial number of bytes is set to twice the number of
bytes per wordis used. The prefixsequences then shrink on each iteration of the loop.
1 or 2 iterations produce fairlygood codealthough this method will notalwaysproduce
optimal code as it will not correctly prefix the pathological example givenabove.

31/212



5 Instruction Set Reference

adc n



32/212

adc

n add constant

Code: Function 8
Description: Add a constant to Areg, with checkingfor overflow.
Definition:

Areg′←Areg +

checked

n

Error signals:

IntegerOverflow

can be signalled by +

checked

Comments:

Primary instruction.

See also:

add ldnlp sum

add

33/212



add

add

Code: F5
Description: Add Areg and Breg, with checkingfor overflow.
Definition:

Areg′←Breg +

checked

Areg

Breg′←Creg
Creg′←

undefined

Error signals:

IntegerOverflow

can be signalled by+

checked

Comments:

Secondary instruction.

See also:

adc sum

ajw n



34/212

ajw

n adjust workspace

Code: Function B
Description: Move the workspace pointer by the number of words specified in the

operand, in order to allocate orde-allocate the workspace stack.

Definition:

Wptr′←Wptr @ n

Error signals: none
Comments:

Primary instruction.

See also:

call gajw

alt

35/212



alt

alt start

Code: 24 F3
Description: Start of a non-timer alternative sequence. The pw.State location of the

workspace isset to

Enabling.p.

Definition:

word′[Wptr @ pw.State] ← Enabling.p

Enter alternativesequence

Error signals: none
Comments:

Secondary instruction.

See also:

altend altwt disc diss dist enbc enbs enbt talt taltwt

altend



36/212

altend

alt end

Code: 24 F5
Description: End of alternative sequence. Jump to start of selected process.
Definition:

Terminate alternativesequence

Iptr′←

next instruction

+ word [Wptr @ pw.Temp]

Error signals: none
Comments:

Secondaryinstruction.
Uses the pw.Temp slot in the process workspace.

See also:

alt altwt disc diss dist enbc enbs enbt talt taltwt

altwt

37/212



altwt

alt wait

Code: 24 F4
Description: Wait until one of the enabled guards of an alternative has become

ready,and initialize workspace foruse during the disabling sequence.

Definition:

if (word[Wptr @ pw.State]≠ Ready.p)

{

word′[Wptr @ pw.State] ← Waiting.p

Deschedule process and waitfor one of the guards to become ready

}
word′[Wptr @ pw.Temp] ← NoneSelected.o
Areg′←

undefined

Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.
Instruction is a descheduling point.
Uses the pw.Temp slot in the process workspace.

See also:

alt altend disc diss dist enbc enbs enbt talt taltwt

and



38/212

and

and

Code: 24 F6
Description: Bitwise and of Areg and Breg.
Definition:

Areg′←Breg ∧ Areg
Breg′←Creg

Creg′←

undefined

Error signals: none
Comments:

Secondaryinstruction.

See also:

not or xor

bcnt

39/212



bcnt

byte count

Code: 23 F4
Description: Produce the length, in bytes, of a multiword data object. Converts the

value in Areg, representing a number of words, to the equivalent number of bytes.
Definition:

Areg′←Areg ×BytesPerWord

Error signals: none
Comments:

Secondary instruction.

bitcnt



40/212

bitcnt

count bits set in word

Code: 27 F6
Description: Count the number of bits set in Areg and addthis to the value in Breg.
Definition:

Areg′←Breg +

number of bits set to 1 in

Areg

Breg′←Creg
Creg′←

undefined

Error signals: none
Comments:

Secondaryinstruction.

bitrevnbits

41/212



bitrevnbits

reverse bottom n bits in word

Code: 27 F8
Description: Reverse the order of the bottomAreg bits ofBreg.
Definition:

if (0 ≤ Areg) and (Areg ≤ BitsPerWord)

{

Areg′

0..Areg-1

←

reversed

Breg

0..Areg-1

Areg′

Areg..BitsPerWord-1

← 0

}

else

Undefinedeffect

Breg′←Creg
Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.
The effect of the instruction is undefinedif the number of bits specifiedis more
than the wordlength.

See also:

bitrevword

bitrevword



42/212

bitrevword

reversebits in word

Code: 27 F7
Description: Reverse the order of all thebits inAreg.
Definition:

Areg′←

reversed

Areg

Error signals: none
Comments:

Secondaryinstruction.

See also:

bitcnt bitrevnbits

bsub

43/212



bsub

byte subscript

Code: F2
Description: Generate the address of the element which is indexedby Breg, in the

byte array pointed to byAreg.
Definition:

Areg′←Areg +Breg
Breg′←Creg

Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.

See also:

ssub sum wsub wsubdb

call n



44/212

call

n call

Code: Function 9
Description: Adjust workspace pointer, saveevaluation stack, and call subroutine at

specifiedbyte offset.

Definition:

Wptr′←Wptr @ -4
word′[Wptr′ @0] ← Iptr

word′[Wptr′ @1] ← Areg
word′[Wptr′ @2] ← Breg
word′[Wptr′ @3] ← Creg

Iptr′←

next instruction

+ n

Areg′←Iptr
Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Primary instruction.

See also:

ajw gcall ret

causeerror

45/212



causeerror

cause error

Code: 62 FF
Description: Take a trap with the trap type set to the value in Areg. Only one bit in

Areg should be set; the position of the bit indicates the trap to be signalled. When the

trap is taken the causeerror bit in the status register is set to indicate a user generated
trap.

In the case of a scheduler trap being set then the bottom bit of Breg is used to
determine the priority of the scheduler trap. In addition when the scheduler trap is
trapping a process scheduling operation(e.g. the

run

trap) the Breg is interpreted as

the process descriptor to be scheduled.

Definition:

if (Areg=2i) and (

trap typeiis enabled

)

{

set causeerror bit in Status
cause trap type

i

}

else

Undefinedeffect

Error signals: The causeerror bit is set and the indicated trap signalled if enabled.
Comments:

Secondary instruction.
Sets traps independently of trapenables state.

See also:

tret sttraph ldtrap

cb



46/212

cb

check byte

Code: 2B FA
Description: Check that the value in Areg can be represented as an 8-bit signed

integer.

Definition:

if (Areg < -27) or (Areg ≥ 27)

IntegerError

Error signals:

IntegerError

signalled ifAreg is not in range.

Comments:

Secondaryinstruction.

See also:

cbu cir ciru cs csu

cbu

47/212



cbu

check byte unsigned

Code: 2B FB
Description: Check that the value in Areg can be represented as an 8-bit unsigned

integer.

Definition:

if (Areg < 0) or (Areg ≥ 28)

IntegerError

Error signals:

IntegerError

signalled if Areg is not in range.

Comments:

Secondary instruction.

See also:

cb cir ciru cs csu

ccnt1



48/212

ccnt1

check count from 1

Code: 24 FD
Description: Check that Breg is inthe range1..Areg inclusive,interpreting Areg and

Breg as unsigned numbers.
Definition:

if (Breg = 0) or (Breg

unsigned

> Areg

unsigned

)

IntegerError

Areg′←Breg
Breg′←Creg
Creg′←

undefined

Error signals:

IntegerError

signalled ifAreg is not in range.

Comments:

Secondaryinstruction.

See also:

csub0

cflerr

49/212



cflerr

check floatingpoint error

Code: 27 F3
Description: Checks if Areg represents an Inf or NaN.
Definition:

if (Areg ∧ #7F800000 = #7F800000)

IntegerError

Error signals:

IntegerError

signalled if Areg represents an Inf or NaN.

Comments:

Secondary instruction.

See also:

unpacksn roundsn postnormsn ldinf

cir



50/212

cir

check in range

Code: 2C F7
Description: Check that Creg is in the range Areg..Breg inclusive.
Definition:

if (Creg < Areg) or (Creg > Breg)

IntegerError

Areg′←Creg
Breg′←

undefined

Creg′←

undefined

Error signals:

IntegerError

signalled ifCreg is not in range.

Comments:

Secondaryinstruction.

See also:

ciru

ciru

51/212



ciru

check in range unsigned

Code: 2C FC
Description: Check that Creg is the range Areg..Breg inclusive, treating all as

unsigned values.

Definition:

if (Creg

unsigned

< Areg

unsigned

) or (Creg

unsigned

> Breg

unsigned

)

IntegerError

Areg′←Creg
Breg′←

undefined

Creg′←

undefined

Error signals:

IntegerError

signalled ifCreg is not in range.

Comments:

Secondary instruction.

See also:

cir

cj n



52/212

cj

n conditional jump

Code: Function A
Description: Jump if Areg is 0 (i.e. jump if

false

). The destination of the jump is

expressed as a byteoffset from the instruction following.

Definition:

if (Areg = 0)

Iptr′←

next instruction

+ n

else

{

Iptr′←

next instruction

Areg′←Breg
Breg′←Creg
Creg′←

undefined

}

Error signals: none
Comments:

Primary instruction.

See also:

j lend

clockdis

53/212



clockdis

clock disable

Code: 64 FE
Description: Stops the clocksspecified in bits 0 and 1 of Areg where bit 0 indicates

the high priority clock and bit 1 the low priority clock. The original values of these two
clock enable bits are returned in Areg.

Definition:

Areg′

1..0

← ClockEnables

Areg′

31..2

← 0

ClockEnables′←ClockEnables ∧ ∼Areg

Error signals: none
Comments:

Secondary instruction.

See also:

clockenb

clockenb



54/212

clockenb

clock enable

Code: 64 FF
Description: Starts or restarts the clocks specified in bits 0 and 1 of Areg, where bit

0 indicates the high priority clock and bit 1 indicates the low priority clock. The original
values of these twoclock enable bits are returned in Areg.

Definition:

Areg′

1..0

← ClockEnables

Areg′

31..2

← 0

ClockEnables′←ClockEnables ∨ Areg

Error signals: none
Comments:

Secondaryinstruction.

See also:

clockdis

clrhalterr

55/212



clrhalterr

clear halt-on-error

Code: 25 F7
Description: Clear the HaltOnError flag.
Definition:

HaltOnErrorFlag′←

clear

Error signals: none
Comments:

Secondary instruction.

See also:

sethalterr testhalterr

crcbyte



56/212

crcbyte

calculate CRC on byte

Code: 27 F5
Description: Generate a CRC (cyclic redundancy check) checksum from the most

significant byte of Areg. Breg contains the previously accumulated checksum and
Creg the polynomial divisor (or ‘generator’). The new CRC checksum, the polynomial

remainder, is calculated by repeatedly (8 times) shifting the accumulated checksum
left, shifting in successivebits from the Areg and if the bit shifted out of the checksum
was a 1,then the generator is exclusive-ored into the checksum.

Definition:

Areg′←temp(8)
Breg′←Creg
Creg′←

undefined

where

temp(0) = Breg
for i = 1..8

temp(i) = (temp(i -1) << 1) + Areg

BitsPerWord-i

)

⊗ (Creg ×temp(i −1)

BitsPerWord-1

)

Error signals: none
Comments:

Secondaryinstruction.

See also:

crcword

crcword

57/212



crcword

calculate CRC on word

Code: 27 F4
Description: Generate a CRC (cyclic redundancy check)checksum from Areg. Breg

contains the previously accumulated checksum and Creg the polynomial divisor (or
‘generator’). The new CRC checksum, the polynomial remainder, is calculated by
repeatedly (BitsPerWord times) shifting the accumulated checksum left, shifting in
successive bits from the Areg and if the bit shifted out of the checksumwas a 1, then
the generator is exclusive-ored into the checksum.

Definition:

Areg′←temp(BitsPerWord)
Breg′←Creg
Creg′←

undefined

where

temp(0) = Breg
for i = 1..32

temp(i) = (temp(i -1) << 1) + Areg

BitsPerWord-i

)

⊗ (Creg × temp(i −1)

BitsPerWord-1

)

Error signals: none
Comments:

Secondary instruction.

See also:

crcbyte

cs



58/212

cs

check sixteen

Code: 2F FA
Description: Check that the value in Areg can be represented as a 16-bit signed

integer.

Definition:

if (Areg < -215) or (Areg ≥ 215)

IntegerError

Error signals:

IntegerError

signalled ifAreg is not in range.

Comments:

Secondaryinstruction.

See also:

cb cbu cir ciru csngl csucword

csngl

59/212



csngl

check single

Code: 24 FC
Description: Check that the two word signed value in Areg and Breg (most

significantword in Breg) can be represented as a single length signed integer.
Definition:

if ((Areg ≥ 0) and (Breg ≠ 0)) or ((Areg < 0) and (Breg ≠ −1))

IntegerError

Error signals:

IntegerError

signalled if Areg is not in range.

Comments:

Secondary instruction.

See also:

cb cbu cir ciru cs csu cword

csu



60/212

csu

check sixteen unsigned

Code: 2F FB
Description: Check that the value in Areg can be represented as a 16-bit unsigned

integer.

Definition:

if (Areg < 0) or (Areg ≥ 216)

IntegerError

Error signals:

IntegerError

signalled ifAreg is not in range.

Comments:

Secondaryinstruction.

See also:

cb cbu cir ciru cs csngl cword

csub0

61/212



csub0

check subscript from 0

Code: 21 F3
Description: Check that Breg is in therange 0..(Areg-1), interpretingAreg and Breg

as unsigned numbers.

Definition:

if (Breg

unsigned

≥ Areg

unsigned

)

Integer Error

Areg′←Breg
Breg′←Creg
Creg′←

undefined

Error signals:

IntegerError

signalled if Breg is not in range.

Comments:

Secondary instruction.

See also:

ccnt1

cword



62/212

cword

check word

Code: 25 F6
Description: Check that the value in Breg can be represented as an N-bit signed

integer. Areg contains 2

(N-1)

to indicate the valueof N (i.e. bit N-1 of Areg is set to 1

and allother bits are set tozero).

Definition:

if (Breg <−Areg) or (Breg ≥ Areg)

IntegerError

Areg′←Breg
Breg′←Creg
Creg′←

undefined

Error signals:

IntegerError

signalled ifBreg is not in range.

Comments:

The result of the instruction is undefinedif Areg is not an integral power of 2.
Undefinedif Areg has more than one bit set.
Secondaryinstruction.

See also:

cb cs csngl xword

devlb

63/212



devlb

device load byte

Code: 2F F0
Description: Perform a device read from memory, a memory-mapped device or a

peripheral. The byte addressed by Areg is read into Areg as an unsigned value. The
memoryaccess performed by this instruction is guaranteed to be correctly sequenced
with respect to other device-accessinstructions. Also the instruction is guaranteed to
be executedafter allnormal memory load instructions thatappear beforeit in the code
sequence, and before all normal memory loads that appear later.

Definition:

if (PeripheralStart ≤ Areg ≤ PeripheralEnd)

Areg′

0..7

← PeripheralByte[Areg]

else

Areg′

0..7

← byte[Areg]

Areg′

8..31

← 0

Error signals: none
Comments:

Secondary instruction.

See also:

devls devlw devsb lb

devls



64/212

devls

device load sixteen

Code: 2F F2
Description: Perform a device read from memory, a memory-mapped device or a

peripheral. The 16-bit object addressed by Areg is read into Areg as an unsigned
value. The memory access performed by this instruction is guaranteedto be correctly
sequenced with respect to other device-access instructions. Also the instruction is
guaranteed to be executed after all normal memory load instructions that appear
before it in the code sequence,and beforeall normal memory loads that appear after
it.

Definition:

if (PeripheralStart ≤ Areg ≤ PeripheralEnd)

Areg′

0..15

← PeripheralSixteen[Areg]

else

Areg′

0..15

← sixteen[Areg]

Areg′

16..31

← 0

Error signals: none
Comments:

Secondaryinstruction.

See also:

devlb devlw devsbls

devlw

65/212



devlw

device load word

Code: 2F F4
Description: Perform a device read from memory, a memory-mapped device or a

peripheral. The word addressed by Areg is read into Areg. The memory access
performed by this instruction is guaranteed to be correctly sequenced with respect to
other device-access instructions. Also the instruction is guaranteed to be executed
after all normal memory load instructions that appear before it in the code sequence,
and before all normal memory loads that appear after it.

Definition:

if (PeripheralStart ≤ Areg ≤ PeripheralEnd)

Areg′←PeripheralWord[Areg]

else

Areg′←word[Areg]

Error signals: none
Comments:

Secondary instruction.

See also:

devlb devls devswldnl

devmove



66/212

devmove

device move

Code: 62 F4
Description: Perform a device copy between memory or memory-mapped devices.

Copies Areg bytes to address Breg from address Creg. Onlythe minimumnumber of
reads and writes required to copy the data will be performed. Each read will be to a
strictly higher (more positive) address than the one before and each write will be to a
strictly higher byte address than the one before.There is no guarantee of the relative
ordering of read and write cycles, except that a write cannot occur until the
corresponding read has been performed. The memory accesses performed by this
instruction are guaranteed to be correctly sequenced with respect to other device­access instructions. Also the instruction is guaranteed to be executed after all normal
memoryaccess instructions that appear before it in the code sequence, and before all
normal memory accesses that appear after it.

Definition:

if (

source and destination overlap

)

Undefinedeffect

else for i = 0 .. (Areg

unsigned

− 1)

byte′[Breg + i] ← byte[Creg + i]

Areg′←

undefined

Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Secondaryinstruction.
The effect of the instruction is undefinedif the source and destination overlap.
Instruction is interruptible.
Devmovewill not operate from or to peripheraladdresses.

See also:

move

devsb

67/212



devsb

device store byte

Code: 2F F1
Description: Perform a device write from memory, a memory-mapped device or a

peripheral. Store the least significant byte of Breg into the byte addressed by Areg.
The memory access performed by this instruction is guaranteed to be correctly
sequenced with respect to other device-access instructions. Also the instruction is
guaranteed to be executed after all normal memory store instructions that appear
before it in the code sequence,and beforeall normal memory stores that appear after
it.

Definition:

if (PeripheralStart ≤ Areg ≤ PeripheralEnd)

PeripheralByte′[Areg] ← Breg

0..7

else

byte′[Areg] ← Breg

0..7

Areg′←Creg
Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.

See also:

devlb devss devswsb

devss



68/212

devss

device store sixteen

Code: 2F F3
Description: Perform a device write from memory, a memory-mapped device or a

peripheral. Store bits 0..5 of Breg into the sixteen bits addressed byAreg. A memory
access performed by this instruction is guaranteed to be correctly sequenced with
respect to other device-access instructions. Also the instruction is guaranteed to be
executed after all normal memory store instructions that appear before it in the code
sequence, and before all normal memory stores that appearafter it.

Definition:

if (PeripheralStart ≤ Areg ≤ PeripheralEnd)

PeripheralSixteen′[Areg]← Breg

0..15

else

sixteen′[Areg] ← Breg

0..15

Areg′←Creg
Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Secondaryinstruction.

See also:

devls devsb devsw ss

devsw

69/212



devsw

device store word

Code: 2F F5
Description: Perform a device write from memory, a memory-mapped device or a

peripheral. Store Breg into the word of memory addressed by Areg. The memory
access performed by this instruction is guaranteed to be correctly sequenced with
respect to other device-access instructions. Also the instruction is guaranteed to be
executed after all normal memory store instructions that appear before it in the code
sequence, and before all normal memory stores that appear after it.

Definition:

if (PeripheralStart ≤ Areg ≤ PeripheralEnd)

PeripheralWord′[Areg] ← Breg

else

word′[Areg] ← Breg

Areg′←Creg
Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.

See also:

devlw devsb devss stnl

diff



70/212

diff

difference

Code: F4
Description: Subtract Areg from Breg, without checkingfor overflow.
Definition:

Areg′←Breg − Areg
Breg′←Creg

Creg′←

undefined

Error signals: none
Comments:

Secondaryinstruction.

See also:

sub

disc

71/212



disc

disable channel

Code: 22 FF
Description: Disable a channel guard in an alternative sequence. Areg is the offset

from the byte following the

altend

to the start of the guarded process, Breg is the
boolean guard andCreg is a pointer to the channel. If this is the first ready guard then
the value in Areg is stored in workspace and Areg is set to

true

, otherwise Areg is set

to

false

. Note that this instruction should be used as part of an alternative sequence

following an

altwtortaltwt

instruction.

Definition:

if (Breg =

false

)–

boolean guard is false

Areg′←

false

else if (Creg

is internal channel

)

{

if (word[Creg] = NotProcess.p) –

guard already disabled

Areg′←

false

else if (word[Creg] =Wdesc)

– this guard is not ready

{

word′[Creg] ← NotProcess.p
Areg′←

false

}
else if (word[Wptr @ pw.Temp] = NoneSelected.o)
{

– this is the firstready guard

word′[Wptr @ pw.Temp] ← Areg
Areg′←

true

}

else

– a previousguard selected

Areg′←

false

}
else if (Creg i

s external channel

)

{

Disable comms subsystem and receive status

if (

channel not ready

)

– channel not waiting

Areg′←

false

else if (word[Wptr @ pw.Temp] = NoneSelected.o)
{–

this is the first ready guard

word′[Wptr @ pw.Temp] ← Areg
Areg′←

true

}

else

- a previous guard selected

Areg′←

false

}
Breg′←

undefined

Creg′←

undefined

disc



72/212

Error signals: none
Comments:

Secondaryinstruction.
Uses the pw.Temp slot in the process workspace.

See also:

alt altend altwt enbc talt taltwt

diss

73/212



diss

disable skip

Code: 23 F0
Description: Disable a ‘skip’ guard in an alternative sequence. Areg is the offset

from the byte following the

altend

to the start of the guarded process and Breg is the
boolean guard. If this is the first ready guard then the value in Areg is stored in
workspace and Areg is set to

true

, otherwise Areg is set to

false

. Note that this

instruction should be used as part of an alternative sequence following an

altwt

or

taltwt

instruction.

Definition:

if (Breg =

false

)–

boolean guard is false

Areg′←

false

else if (word[Wptr @ pw.Temp] = NoneSelected.o)

Areg′←

false – this is the firstready guard

else –

another guard was selected

{

word′[Wptr @ pw.Temp] ← Areg
Areg′←

true

}
Breg′←Creg

Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.
Uses the pw.Temp slot in the process workspace.

See also:

alt altend altwt enbs talt taltwt

dist



74/212

dist

disable timer

Code: 22 FE
Description: Disable a timer guard in an alternative sequence. Areg is the offset

from the byte following the

altend

to the start of the guarded process, Breg is the
boolean guard and Creg is the time after which this guard will be ready. If this is the
first ready guard then the value in Areg is stored in pw.Temp, andAreg is set to

true

.

Note that this instruction should be used as part of an alternativesequence following a

taltwt

instruction.

Definition:

if (Breg =

false

)–

boolean guard is false

Areg′←

false

else if (word[Wptr @ pw.TLink]= TimeNotSet.p)

– no timer is ready

Areg′←

false

else if (word[Wptr @ pw.TLink]= TimeSet.p) –

a timer is ready

{

if not (word[Wptr @ pw.Time] after Creg)

– but not this one

Areg′←

false

else if (word[Wptr @ pw.Temp] = NoneSelected.o)

– this is the firstready guard

{

word′[Wptr @ pw.Temp] ← Areg
Areg′←

true

}

else

– a previousguard selected

Areg′←

false

}

else

Areg′←

false

Remove this process from the timer list

Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Secondaryinstruction.
Instruction is interruptible.
Uses the pw.Temp slot in the process workspace.

See also:

altend enbt talt taltwt

div

75/212



div

divide

Code: 22 FC
Description: Divide Breg by Areg, with checking for overflow. The result when not

exact is rounded towardszero.

Definition:

if (Areg = 0) or ((Breg = MostNeg) and (Areg = -1))

{

Areg′←

undefined

IntegerOverflow

}

else

Areg′←Breg / Areg

Breg′←Creg
Creg′←

undefined

Error signals:

IntegerOverflow

can be signalled.

Comments:

Secondary instruction.

See also:

rem

dup



76/212

dup

duplicate top of stack

Code: 25 FA
Description: Duplicate the top of the integer stack.
Definition:

Areg′←Areg
Breg′←Areg
Creg′←Breg

Error signals: none
Comments:

Secondaryinstruction.

See also:

pop rev

enbc

77/212



enbc

enable channel

Code: 24 F8
Description: Enable a channel guard in an alternative sequence. Areg is the

boolean guard and Breg is a pointer to the channel. Note that this instruction should
only be used as part of an alternative sequence following an

altortalt

instruction.

Definition:

if (Areg ≠

false

)

{

if (Breg

is internal channel

)

{

if (word[Breg] = NotProcess.p) –

not ready

word′[Breg] ← Wdesc

else if (word[Breg] ≠ Wdesc) –

not previously enabled

word′[Wptr @ pw.State] ← Ready.p
}
else if (Breg

is external channel

)

{

Request Comms Subsystem to enableexternal channel
and receivecurrent status of channel

if (

channel ready

)-

word′[Wptr @ pw.State] ← Ready.p
}

}
Breg′←Creg

Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.

See also:

alt altend altwt disc talt taltwt

enbs



78/212

enbs

enable skip

Code: 24 F9
Description: Enable a ‘skip’ guard in an alternative sequence. Areg is the boolean

guard. Note that this instruction should only be used as part of an alternative
sequence following an

altortalt

instruction.

Definition:

if (Areg ≠

false

)

word′[Wptr @ pw.State] ← Ready.p

Error signals: none
Comments:

Secondaryinstruction.

See also:

alt altend altwt diss talt taltwt

enbt

79/212



enbt

enable timer

Code: 24 F7
Description: Enable a timer guard in an alternative sequence. Areg is the boolean

guard and Breg is the time after which the guard may be selected. Note that this
instruction should only be used as part of an alternative sequence following a

talt

instruction; in this case the location pw.State will have been initialized to

Enabling.p

and thepw.Tlink slot initialized to

TimeNotSet.p

.

Definition:

if (Areg ≠

false

)

{

if (word[Wptr @ pw.TLink]= TimeNotSet.p) –

this is the first enbt

{

word′[Wptr @ pw.TLink] ← TimeSet.p

word′[Wptr @ pw.Time] ← Breg
}
else if (word[Wptr @ pw.TLink]= TimeSet.p) –

this is not the firstenbt

{

if (word[Wptr @ pw.Time]after Breg) –

this enbt has earlier time

word′[Wptr @ pw.Time] ← Breg

}

}
Breg′←Creg

Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.

See also:

altend dist talt taltwt

endp



80/212

endp

end process

Code: F3
Description: Synchronize the termination of a parallel construct. When all branches

have executed an

endp

instruction a ‘successor’ process then executes. Areg points
to the workspace of this successor process.This workspace contains a data structure
which holds the instruction pointer of the successor process and the number of
processes still active.

Definition:

if (word[Areg @ pp.Count]= 1)

{

Iptr′←word[Areg @ pp.IptrSucc]
Wptr′←Areg

}

else

word′[Areg @ pp.Count] ← word[Areg @ pp.Count]−1

start nextprocess

Areg′←

undefined

Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Secondaryinstruction.
Instruction is a descheduling point.

See also:

startp stopp

eqc n

81/212



eqc

n equals constant

Code: Function C
Description: Compare Areg to a constant.
Definition:

if (Areg = n)

Areg′←

true

else

Areg′←

false

Error signals: none
Comments:

Primary instruction.

fmul



82/212

fmul

fractional multiply

Code: 27 F2
Description: Multiply Areg by Breg treating the values as fractions, rounding the

result. The values in Areg and Breg are interpreted as fractions in the range greater
than or equal to -1 and less than 1 - i.e. the integer values divided by 2

BitsPerWord-1

.
The result is rounded. The rounding mode used is analogous to IEEE round nearest;
that is the result produced is the fraction which is nearest tothe exactproduct, and, in
the event of the product being equidistant between two factions, the fraction with least
significantbit 0 is produced.

Definition:

if (Areg = MostNeg) and (Breg = MostNeg)

– MostNeg interpreted as -1

{

Areg′←

undefined

IntegerOverflow

}

else

Areg′←(Breg × Areg) /

roundnearest

2

BitsPerWord-1

Breg′←Creg
Creg ←

undefined

Error signals:

IntegerOverflow

can occur.

Comments:

Secondaryinstruction.

fptesterr

83/212



fptesterr

test for FPU error

Code: 29 FC
Description: Test for an error in the FPU, if present. This instruction always returns

true

on a processor without an FPU.

Definition:

Areg′←

true

Breg′←Areg
Creg′←Breg

Error signals: none
Comments:

Secondary instruction.

gajw



84/212

gajw

general adjust workspace

Code: 23 FC
Description: Set the workspace pointer to the address in Areg, saving the previous

value in Areg.
Definition:

Wptr′←Areg
Areg′←Wptr

Error signals: none
Comments:

Secondaryinstruction.

Areg should be word aligned.

See also:

ajw call gcall

gcall

85/212



gcall

general call

Code: F6
Description: Jump to the address in Areg, savingthe previousaddress inAreg.
Definition:

Iptr′←Areg
Areg′←Iptr

Error signals: none
Comments:

Secondary instruction.

See also:

ajw call gajw ret

gintdis



86/212

gintdis

global interrupt disable

Code: 2C FD
Description: Disable the global interrupt events specified in the bit mask in Areg.

This allows parts of the built-in scheduler, such as response to external events,
timeslicing etc., to be disabled by software. The original value of the global interrupt
enable register is returned in Areg.

Definition:

GlobalInterruptEnables′← GlobalInterruptEnables ∧ ∼Areg

7..0

Areg′

7..0

← GlobalInterruptEnables

Areg′

31..8

← 0

Error signals: none
Comments:

Secondaryinstruction.

See also:

gintenb

gintenb

87/212



gintenb

global interrupt enable

Code: 2C FE
Description: Enable the global interrupt events specified in the bit mask in Areg.
Definition:

GlobalInterruptEnables′← GlobalInterruptEnables ∨ Areg

7..0

Areg′

7..0

← GlobalInterruptEnables

Areg′

8..31

← 0

Error signals: none
Comments:

Secondary instruction.

See also:

gintdis

gt



88/212

gt

greater than

Code: F9
Description: Compare the top two elements of the stack, returning

true

if Breg is

greater than Areg.

Definition:

if (Breg > Areg)

Areg′←

true

else

Areg′←

false

Breg′←Creg
Creg′←

undefined

Error signals: none
Comments:

Secondaryinstruction.

gtu

89/212



gtu

greater than unsigned

Code: 25 FF
Description: Compare the top two elements of the stack, treating both as unsigned

integers, returning

true

if Breg is greater than Areg.

Definition:

if (Breg

unsigned

> Areg

unsignded

)

Areg′←

true

else

Areg′←

false

Breg′←Creg
Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.

in



90/212

in

input message

Code: F7
Description: Input a message. The corresponding output is performed by an

out

,

outwordoroutbyte

instruction, and must specify a message of the same length. Areg
is the unsigned length in bytes,Breg is a pointer to the channel and Creg is a pointer
to where the message is to be stored. The process executinginwill be descheduled if
the channel is external or is not ready,and is rescheduled whenthe communicationis
complete.

Definition:

Synchronize, and input

Areg

unsigned

bytes from channel

Breg

to address

Creg

Areg′←

undefined

Breg′←

undefined

Creg′←

undefined

Error signals: Can cause

InternalChannelorExternalChannel

trap to be signalled (if

enabled) when the process is rescheduled after synchronization.

Comments:

Secondaryinstruction.
Instruction is a descheduling point.
Instruction is interruptible.

See also:

out

insertqueue

91/212



insertqueue

insert at front of scheduler queue

Code: 60 F2
Description: Insert a list of processes at the front of the scheduling list of priority

indicated by Areg, where 0 indicates high priority and 1 indicates low priority. Breg
and Creg are the front and back, respectively,of thelist to be inserted.

Definition:

if (Breg ≠ NotProcess.p)

{

ProcQueueFPtr′[Areg]←Breg
if (ProcQueueFPtr[Areg] = NotProcess.p)

ProcQueueBPtr′[Areg]←Creg

else

word′[Creg @ pw.Link] ← ProcQueueFPtr[Areg]

}
Areg′←

undefined

Breg′←

undefined

Creg′←

undefined

Error signals: none
Comments:

Secondary instruction.

See also:

swapqueue

intdis



92/212

intdis

(localised) interrupt disable

Code: 2C F4
Description: Disable interruption by high priority processes until either an

intenb

instruction is executedor the process deschedules.Timeslicing does not occur while
interrupts are disabled.This instruction is only meaningful forlow priority processes.

Definition:

Disable high priority interrupts

Error signals: none
Comments:

Secondaryinstruction.

See also:

intenb settimeslice

intenb

93/212



intenb

(localised) interrupt enable

Code: 2C F5
Description: Enable interruption by high priority processes. This instruction is only

meaningful for low priority processes.

Definition:

Enable high priority interrupts

Error signals: none
Comments:

Secondary instruction.

See also:

intdis settimeslice

iret



94/212

iret

interrupt return

Code: 61 FF
Description: Return from external interrupt. Signal

iret

to interrupt handlerand return
to the context of the interrupted process and resume execution. The interrupted high
priority state is recovered from the workspace – if this does not contain a running
process the processor switchesto the interrupted lowpriority state held in the shadow
registers.

Definition:

Status′←word[Wptr]
if (Status

has valid bit set

)

{

Wptr′←word[Wptr + 1]
Iptr′←word[Wptr + 2]
Areg′←word[Wptr + 3]
Breg′←word[Wptr + 4]
Creg′←word[Wptr + 5]

}

else

Return to interrupted low priority state

Error signals: none
Comments:

Secondaryinstruction.

jn

95/212



j

n jump

Code: Function 0
Description: Unconditional relative jump. The destinationof thejump is expressedas

a byte offset from the firstbyte after the current instruction.j0 causes a breakpoint.

Definition:

if (n = 0)

Take a

breakpoint

trap

else

Iptr′←

next instruction

+ n

Areg′←

undefined

Breg′←

undefined

Creg′←

undefined

Error signals:j0 can cause a

breakpoint

trap to be signalled.

Comments:

Primary instruction.
Instruction is a descheduling point.
Instruction is a timeslicing point.

See also:

cj lend

ladd



96/212

ladd

long add

Code: 21 F6
Description: Add with carry in and check for overflow.The result of the operation is

the sum of Areg, Breg and bit 0 of Creg.
Definition:

if (sum > MostPos)

{

Areg′←sum − 2

BitsPerWord

IntegerOverflow

}
else if (sum < MostNeg)
{

Areg′←sum + 2

BitsPerWord

IntegerOverflow

}

else

Areg′←sum

Breg′←

undefined

Creg′←

undefined

where sum = Areg + Breg + Creg

0

– the value of

sum

is calculated to unlimited precision

Error signals:

IntegerOverflow

can be signalled.

Comments:

Secondaryinstruction.

See also:

lsum

lb

97/212



lb

load byte

Code: F1
Description: Load the unsigned byte addressed byAreg into Areg.
Definition:

Areg′

0..7

← byte[Areg]

Areg′

8..BitsPerWord-1

← 0

Error signals: none
Comments:

Secondary instruction.

See also:

bsub devlb lbx ls ldul

lbx



98/212

lbx

load byte and sign extend

Code: 2B F9
Description: Load the byte addressed by Areg into Areg and sign extend to a word.
Definition:

Areg′

0..7

← byte[Areg]

Areg′

8..BitsPerWord-1

← Areg′

7

Error signals: none
Comments:

Secondaryinstruction.

See also:

bsub devlb lb xbword lsx ldul

ldc n

99/212



ldc

n load constant

Code: Function 4
Description: Load constant into Areg.
Definition:

Areg′←n
Breg′←Areg

Creg′←Breg

Error signals: none
Comments:

Primary instruction.

See also:

adc mint

ldclock



100/212

ldclock

load clock

Code: 64 FD
Description: Load into Areg the current value of ClockReg, of the priority selected

by Areg, where 0 indicates high priority and 1 indicates lowpriority.
Definition:

Areg′←ClockReg[Areg]

Error signals: none
Comments:

Secondaryinstruction.

See also:

stclock
