BOR HURNG ELECTRONIC CO., LTD.
ALUMINIUM ELECTROLYTIC CAPACITORS
●FEATURES
■ High temperature, super miniature, 7mm high
■ Suited for high density assembly
●SPECIFICATIONS
Item Key Features
SERIES: SS
Operating Temperature
Range
Rated Working Voltage
Range
Nominal Capacitance
Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
23
Low T emperature Features
High Temperature
Load Features
-40℃~+105℃
6.3VDC~63VDC
0.1μF~330μF
±20%(M) (+25℃,100/120Hz)
LC≤0.01CV or 3μA whichever is bigger, 2-minute application of rated working voltage, (+25℃)
C: Nominal Capacitance in μF V: Rated Working Voltage in V LC: Leakage Current in μA
Rated Working Voltage (V)
DF (MAX)
(+25℃, 100/120Hz)
Rated Working Voltage (V)
Impedance Ratio
(MAX) (100/120Hz)
After applying rated working voltage to capacitors for 1,000 hours at 105℃ and test the stabilized
capacitors at +25℃, the capacitors shall meet the following limits.
Capacitance Change Within ± 20 % of the initial measured value
Dissipation Factor Less than 200 % of the specified value
6.3 10 16 25 35 50 63
0.24 0.20 0.16 0.14 0.12 0.10 0.09
6.3 10 16~25 35~63
-40℃
+25℃
8 6 4 3
Leakage Current Within the specified value
After storage with no voltage application for 500 hours at 105℃ and test the stabilized capacitors at
+25℃, the capacitors shall meet the following limits.
High Temperature
Storage Features
● CORRECTION COEFFICIENT OF RIPPLE CURRENT
■ Frequency Coefficient ■ Temperature Coefficient
Freq.(Hz)
Cap.(μF)
0.1~47 0.8 1.0 1.2 1.3 1.5
68~330 0.8 1.0 1.1 1.15 1.2
50
(60)
Capacitance Change
Dissipation Factor Less than 200 % of the specified value
Leakage Current Less than 200 % of the specified value
100
(120)
500 1K 10K
Within ± 20 % of the initial measured value
Temperature(℃)
Factor 1.0 1.7 2.1
+105 +85 +65
Page 2
R
●
BOR HURNG ELECTRONIC CO., LTD.
SERIES: SS
ALUMINIUM ELECTROLYTIC CAPACITORS
R
SIZE I
R
SIZE I
R
SIZE I
R
●DIMENSIONS DXL(mm) AND MAXIMUM RIPPLE CURRENT(mA·rms at 105℃, 100/120Hz)
W.V.
(V)
CAP.
(μF)
0.1 4×7 1.3 4×7 1.7
0.22 4×7 2.9 4×7 3.7
0.33 4×7 4.4 4×7 5.0
0.47 4×7 5.7 4×7 6.0
0.68 4×7 7.1 4×7 7.8
1 4×7 8.3 4×7 8.7
2.2 4×7 12 4×7 13
6.3 10 16 25 35 50 63
SIZE IRSIZE IRSIZE I
SIZE I
R
3.3 4×7 15 4×7 16
4.7 4×7 18 4×7 21
6.8 4×7 23 5×7 28
1 0 4 × 7 2 1 4× 7 2 2 4 × 7 2 4 5 × 7 3 0 6.3×7 3 6
22 4×7 25 4×7 27 4×7 31 5×7 37 5×7 44 6.3× 7 50
3 3 4 × 7 31 4 × 7 3 6 4 × 7 3 8 5× 7 4 8 6.3×7 5 6
47 4×7 37 4×7 41 5×7 52 6.3× 7 62 6.3×7 68
68 5×7 45 5×7 49 6.3×7 58 6.3×7 71
100 5×7 59 6.3× 7 76 6.3×7 85
2 2 0 6.3×7 7 6
330
8×7
8×9
108
6.3× 7
8× 9
8× 7
8× 9
6.3×7
102
8×9
135
6.3× 7
8×9
123
8×7
8×9
108 8×9 120
6.3× 7
8× 9
8× 7
8× 9
89
64
91
CASE SIZE AND DI MENSIONS (MM)
Capacitor External Diametre D, Lead Diametre d, Lead Spacing F
8× 7
8× 9
8× 7
8× 9
24
58
70
D
F
d
α
4 5 6.3 8
1.5 2.0 2.5 3.5
0.45 0.45 0.50 0.50
1.0
