Top View
Elektronische Bauelemente
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
DESCRIPTION
These miniature surface mount MOSFETs
utilize a high cell density trench process to provide
low R
and to ensure minimal power loss and
DS(on)
heat dissipation.
FEATURES
Low R
provides higher efficiency and
DS(on)
extends battery life
Low thermal impedance copper leadframe
DFN3x3-8PP saves board space
Fast switching speed
High performance trench technology
APPLICATION
DC-DC converters and power management in portable
and battery-powered products such as computers,
printers, PCMCIA cards, cellular and cordless telephones.
PACKAGE INFORMATION
Package MPQ Leader Size
SSPS924NE
9.2A , 20V , R
N-Ch Enhancement Mode Power MOSFET
REF.
A 0.70 0.90 θ 0° 12
12 mΩ
DS(ON)
DFN3x3-8PP
REF.
ΩΩΩ
DFN3x3-8PP 3K 13 inch
MAXIMUM RATINGS
Drain-Source Voltage VDS 20 V
Gate-Source Voltage VGS ±8 V
Continuous Drain Current 1
Pulsed Drain Current 2 IDM 50 A
Continuous Source Current (Diode Conduction) 1 IS 2.6 A
Total Power Dissipation 1
Operating Junction & Storage Temperature Range TJ, T
Thermal Resistance Junction-Ambient 1
Notes:
1. Surface Mounted on 1” x 1” FR4 Board.
2. Pulse width limited by maximum junction temperature.
(TA=25°C unless otherwise specified)
Parameter
TA=25°C
TA=70°C 7.5 A
TA=25°C
TA=70°C 1 W
Thermal Resistance Ratings
t ≦ 10sec
Steady State
Symbol Ratings Unit
ID
PD
-55~150 °C
STG
R
θJA
9.2 A
1.5 W
83 °C / W
120 °C / W
http://www.SeCoSGmbH.com/ Any changes of specification will not be informed individually.
06-Mar-2012 Rev. A Page 1 of 4
Page 2
SSPS924NE
9.2A , 20V , R
Elektronische Bauelemente
N-Ch Enhancement Mode Power MOSFET
DS(ON)
12 mΩ
ΩΩΩ
ELECTRICAL CHARACTERISTICS
(TA=25°C unless otherwise specified)
Parameter Symbol Min. Typ. Max. Unit Teat Conditions
Static
Gate-Threshold Voltage V
Gate-Body Leakage Current I
Zero Gate Voltage Drain Current I
On-State Drain Current 1 I
Drain-Source On-Resistance 1 R
Forward Transconductance 1 gfs - 40 - S VDS=10V, ID=7.4A
Diode Forward Voltage VSD - 0.7 - V IS=1.3A, VGS=0
1 - - V VDS=VGS, ID=250µA
GS(th)
- - ±10 µA VDS=0, VGS=±8V
GSS
DSS
25 - - A VDS=5V, VGS=4.5V
D(on)
- - 25 VDS=16V, VGS=0, TJ=55°C
- - 12
- - 1
DS(ON)
- - 14 VGS=2.5V, ID=6.8A
VDS=16V, VGS=0
µA
VGS=4.5V, ID=7.4A
mΩ
Dynamic 2
Total Gate Charge Qg - 17 Gate-Source Charge Qgs - 4.4 Gate-Drain Charge Qgd - 3.9 Input Capacitance C
Output Capacitance C
Reverse Transfer Capacitance C
Turn-On Delay Time T
- 1663 -
iss
- 145 -
oss
- 139 -
rss
- 16 -
d(on)
Rise Time Tr - 14 Turn-Off Delay Time T
- 75 -
d(off)
Fall Time Tf - 17 -
Notes:
1. Pulse test：PW≦300µs duty cycle≦2%.
2. Guaranteed by design, not subject to production testing.
nC
pF
nS
VDS=10V,
VGS=4.5V,
ID=7.4A
VDS=15V,
VGS=0
f=1MHz
VDS=10V
ID=7.4A
V
=4.5V
GEN
RL=1.4Ω
R
=6Ω
GEN
http://www.SeCoSGmbH.com/ Any changes of specification will not be informed individually.
06-Mar-2012 Rev. A Page 2 of 4
Page 3
Elektronische Bauelemente
CHARACTERISTIC CURVE
SSPS924NE
9.2A , 20V , R
N-Ch Enhancement Mode Power MOSFET
DS(ON)
12 mΩ
ΩΩΩ
http://www.SeCoSGmbH.com/ Any changes of specification will not be informed individually.
06-Mar-2012 Rev. A Page 3 of 4
Page 4
Elektronische Bauelemente
CHARACTERISTIC CURVE
SSPS924NE
9.2A , 20V , R
N-Ch Enhancement Mode Power MOSFET
DS(ON)
12 mΩ
ΩΩΩ
http://www.SeCoSGmbH.com/ Any changes of specification will not be informed individually.
06-Mar-2012 Rev. A Page 4 of 4
