Electric Double Layer Capacitors(Gold Capacitor)/HW
Radial lead Type
Series:
n Feature
lThe smallest size and high-capacitance, low-resistance
lCan be charged and discharged more times than secondary batteries
lPollution free operation since the activated carbon and organic electrolyte
are used as main materials
lPolyvinyl chloride and lead are not in use
n Recommended Applications
lSolar battery circuit(e.g. Road guidance flasher)
lQuick charge motor drive through quick charge(e.g. Toy car)
lBack-up Power Supplies(e.g. UPS)
n Specifications
Category temp. range
Maximum Operating Voltage
Nominal Cap. Range
Capacitance Tolerance
Characteristics at Low
Temperature
Endurance
Shelf Life
Moisture Resistance
HW
-25 to +70°C
2.3 V .DC
1 to 22 F
-20 to +40%
Capacitance change
Internal resistance
After 1000 hours application of 2.3V. DC at +70°C(+60°C), the capacitor shall meet the following limits.
Capacitance change
Internal resistance
±30% of initial measured value at +20°C (-25 to +70°C, +60°C)
< 4 times of initial measured value at +20°C (at -25°C)
±30% of initial measured value
< 2 time of initial specified value
After 1000 hours storage at +70°C(+60°C) without load, the capacitor shall meet the specified
limits for Endurance.
After 500 hours storage at +55°C, 90 to 95% R.H., the capacitor shall meet the specified
limits for Endurance.
Country of Origin
Japan
-25 to +60°C
2.3 V .DC
30, 50 F
n Dimensions in mm (not to scale)
sleeve
Vent(>8.0 mm dia.)
L+2 max. 14 min. 3 min.
n Standard products
Category temp.
range
(°C)
-25 to +70
-25 to +60
Max. Operating
Voltage
(V.DC)
2.3
Capacitance
(F)
1.0
3.3
4.7
10
22
30
50
fd ±
0.05
Internal
resistance
(W) at 1kHz
< 1.0
< 0.3
< 0.3
< 0.2
< 0.1
< 0.1
< 0.1
f
10
<
f
D+0.5 max.
Size(mm)
fD L fd P
8.0
12.5
12.5
12.5
18.0
18.0
18.0
22.0
23.0
23.0
35.0
35.0
35.0
40.0
0.7
0.8
0.8
0.8
0.8
0.8
0.8
0.5
±
P
EECHW0D105
3.5
EECHW0D335
5.0
EECHW0D475
5.0
EECHW0D106
5.0
EECHW0D226
7.5
EECHW0D306
7.5
EECHW0D506
7.5
f8 >
f
D+0.5 max.
Part number
0.5
±
P
Min. Packaging
QTY
(pcs)
200
200
200
100
50
50
50
Design, and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase
and / or use. Should a safety consern arise regarding this product,please be sure to contact us immediately.
¾ EE201 ¾
