Datasheet SP8400 Datasheet (MITEL)

Very Low Phase Noise Synthesiser Divider

The SP8400 is a very low phase noise programmable
divider which is based on a divide by 8/9 dual modulus
prescaler and a 12 stage control counter. This gives a minimum
division ratio of 56 (64 for fractional - N synthesis applications),
and a maximum division ratio of 4103. Special circuit
techniques have been used to reduce the phase noise
considerably below that produced by standard dividers.The
data inputs are CMOS or TTL compatible.

The SP8400 is packaged in a 28 pin plastic SO package.

FEATURES

■ Very low Phase Noise (Typically -156dBc/Hz at 1kHz

offset)

■ Supply Voltage 5V

ABSOLUTE MAXIMUM RATINGS

Supply Voltage 6.5V

Output Current 20mA

Storage Temperature Range -55°C to +125°C

Maximum Clock Input Voltage 2.5V p-p

M2
M1
M0

+5V

V

CC

GND

INPUT

CLOCK
CLOCK INPUT
CLOCK INPUT

INPUT

CLOCK

GND

V

+5V

CC

+5V

V

CC

GND

A0

Fig.1 Pin connections - top view

1
2
3
4
5
6
7
8

9
10
11
12
13
14 15

28
27
26
25
24
23
22
21
20
19
18
17
16

SP8400

DS3739 - 2.1 April 1994

M3
M4
M5
M6
M7
M8
N/C
OUTPUT
OUTPUT
N/C
V

+5V

CC

N/C
A2
A1

MP28

ORDERING INFORMATION

SP8400 KG MPES(Commercial Grade)

0
–10
–20
–30
–40
–50
–60
–70
–80
–90

–100

(f) (dBc/Hz) –3dB

–110
–120
–130
–140
–150
–160
–170

10 100 1k 10k 100k

Frequency (Hz)

Fig.2 Typical single sideband phase noise measured at 300MHz

SP8400

ELECTRICAL CHARACTERISTICS

Guaranteed over: Supply voltage VCC = +4.75V to +5.25V Temperature T
Tested at +4.75V and +5.25V at T

= +25°C

amb

= -10°C to +75°C

amb

Characteristic

Supply current
Output voltage swing

Input sensitivity 200MHz to 1.5GHz

Data Inputs

Logic high voltage
Low low voltage
Input current

600

500

400

300

mV rms

in

V

200

100

Pin

4, 11, 12, 18

20, 21

7, 8

Value

Min. Typ. Max.

137

122
320

152

410

140
(-4)

2.2

0.8

180

OPERATING WINDOW

Units

mA
mV

mV

dBm

V
V

µA

Conditions

Output loaded with 300R See Fig.4
p-p @ 1.5GHz input ÷ 71 mode
See Fig.4
RMS Sine wave into 50 Ohms
(dBm equivalent) See Fig.3

5V Data input voltage

355mV

140mV

0 200 400 600 800 1000 1200 1400

FREQUENCY MHz

1600

Fig.3 Typical input sensitivity

2

VCC

TTL/CMOS
MODULUS
CONTROL

50R

GENERATOR

TTL/CMOS
MODULUS
CONTROL

1nF

RF

SIGNAL

1
2
3
4
5
6
7

SP8400

8

9
10
11
12
13
14 15

SP8400

28
27
26
25
24
23
22
21
20
19
18
17
16

OUTPUT

220nF

Fig.4 Test circuit

APPLICATIONS INFORMATION

Circuit description, synthesiser divider

The divider is based on a divide by 8/9 modulus prescaler,
and a 12 stage control counter. This gives minimum fractional
– N division ratio of 64 (56 for general division), and a maximum
division ratio of 4103. The inputs to the control counter are TTL/
CMOS compatible. There is a fixed offset of 8 between the
number on the data lines and the actual division ratio.

The output is one transition only per divide cycle. This
eliminates the problem of where to put the redundant edge
when the divider is used in a fractional–N system, and also
avoids the problem of how to define the output pulse width. This
means that the overall division ratio conventionally defined in
terms of the rate of edges of the same polarity is twice the
selected division ratio.

10nF10nF1nF 1nF

50R

2x330R

Equations for division

The M and A data inputs form a 12 bit number with A0
being the least significant bit and M8 being the most significant
bit.

Definition 1: Division ratio – (input frequency to output

edges, positive or negative).
= Number loaded + 8

Definition 2: Division ratio – (input frequency to output

frequency).
= (Number loaded + 8) x 2

3

SP8400

Available division ratio

All division ratios of 64 to 4103 (Definition 1) will return the
divider to the same internal state at the end of the count and
hence these are the only divisional ratios to be used for
fractional–N synthesiser application.
All division ratios of 56 to 4103 are available for general division
purposes. Additional division ratios available for general
division are:-

8,9
16, 17, 18
24, 25, 26, 27
32, 33, 34, 35, 36
40, 41, 42, 43, 44, 45
48, 49, 50, 51, 52, 53, 54

+5V

M

INPUTS

CLOCK INPUT

A

INPUTS

1nF

50R

1
2
3
4
5
6
7

SP8400

8

9
10
11
12
13
14 15

28
27
26
25
24
23
22
21
20
19
18
17
16

2 x BF569
(or similar)

+15V

1k

10nF

330R

10nF10nF1nF 1nF

2x330R

Fig.5 Typical application combining output to increase signal and retain low phase noise

4
