Page 1
Sang Jing Electronics Co., Ltd.
Series
Type
Features
Applications
Temperature
( ºc )
Voltage
( VDC)
Capacitan
ce
(µ F)
Load
Life
UMR
UM3R
Radial
Ultra-Miniaturized
Height 5mm
-40 to +85º c
4-50
0.1-470
1000Hr
s
MR
Radial
Miniaturized Type
Height 7mm
-40 to +105º c
6.3-63
0.1-470
1000Hr
s
MHR
Radial
105ºC
Miniaturized Type
Height 7mm
-40 to +105º c
6.3-63
0.1-470
1000Hr
s
GPR
Radial
85ºC
General Purpose
-40 to +85º c
6.3-100
0.1-22000
2000Hr
s
-25 to +85º c
160-450
0.47-820
RH
Radial
105ºC
General Purpose
-40 to +105º c
6.3-100
0.1-15000
2000Hr
s
-25 to +105º c
160-450
0.47-330
LL
Radial
Low-Leakage Current
-40 to +105º c
6.3-63
0.1-2200
2000Hr
s
NP
Axial Radial
Non-Polarized
-40 to +105º c
10-250
0.47-2200
2000Hr
s
SERIES OF CAPACITORS
Page 2
BP
Radial
Bi-Polarized
High Ripple
-40 to +105º c
6.3-100
0.47-6800
2000Hr
s
GLR
Radial
Low Impedance/
Low E.S.R.
-55 to +105º c
6.3-100
0.47-4700
5000Hr
s
AX
Axial
105ºC
Axial Type Capacitors
105ºC
-40 to +105º c
6.3-100
0.47-15000
2000Hr
s
-25 to +105º c
160-400
0.47-220
LPR
Snap-in
PCB Snap-in
Large Size
-40 to +85º c
10-100
470-68000
2000Hr
s
-25 to +85º c
160-450
47-2700
HPR
Snap-in
105ºC
Snap-in Large
Size
105ºC
-40 to +105º c
10-100
330-68000
2000Hr
s
-25 to +105º c
160-400
33-2200
ST
Screw
Screw Terminal Type
Capacitors
-40 to +85º c
10-100
220-
330,000
2000Hr
s
-25 to +85º c
160-450
ERC
Radial
E.R.C.Radial Type
Capacitors
-40 to +105º c
6.3-50
0.1-470
2000Hr
s
