NEC SCHOTT Thermal Cutoffs SEFUSE®
SF/R Series Specification
Dimension
Marking
eature
F
Higher Tm rating & Quicker responsiveness
ROHS and REACH compliance products
15A marking
Ratings
Safety standards
*1
Part
Number
SF70R0 73 70+/-2 58
SF76R0 77 76+0/-4 62
SF81R0 84 81+3/-1 69
SF94R0 99 94+/-2 84
SF113R0 113 108+/-2 98 2003
SF119R0 121 119+/-2 106
SF129R0 133 129+/-2 118
SF139R0 142 139+/-2 127
SF150R0 152 150+1/-3 137
SF167R0 167 164+/-2 153
SF184R0 184 182+/-2 174
SF188R0 192 188+3/-1 177
SF214R0 216 214+1/-3
SF229R0 229 227+/-2
SF240R0 240 237+/-2
*1 Part number indicates thermal cutoff with standard lead length. For long lead length type, type number is changed to SF**R1.
*2 Holding Temperature is the maximum temperature at which, when applying a rated current to the thermal cutoff, the state of conductivity
is not changed during specified time not less 168 hours(1week). The Th rating is only specified by UL.
*3 Maximum temperature limit is the temperature up to which thermal cutoffs will not change its state of cutoff without impairing.
*4 The electrical rating according to the various safety standards are shown in the following table.
*SF/R is available for 10A and 15A marking for PSE. Rating 10A marking is applied for Article, and 15A marking is applied
Rated
Functioning
Temperature
T
f
(deg.C)
Rated Voltage UL / cUL VDE CCC PSE *
AC120V 20A(Res.)
AC250V 15A(Res.)
for Article 2 of the technical requirement of the METI ordinance J60691.
Operating
Temperature
(deg.C)
16A(Res.)
*2
Th
(deg.C)
200
*3
T
m
(deg.C)
165
175
210
250
375
380 2009
15A 15A 10A
*4
Electrical
Ratings
15A/
250V ac
15A
UL /
cUL
E71747
VDE
677802
-1171
-0015
CCC PSE
Thailand
made
20130102
05600209
Thailand
Made
(JET1974-
32001-***)
2001
2002 SF90R0 94 90+/-2 79
2004
2005 SF144R0 144 142+/-2 129
2006
2007
2008
