Continental Device India Limited
An ISO/TS16949 and ISO 9001 Certified Company
COMPLEMENTARY SILICON PLANAR EPITAXIAL TRANSISTORS CSA1020 PNP
CSC2655 NPN
TO-92
Plastic Package
ABSOLUTE MAXIMUM RATINGS (Ta=25ºC unless specified otherwise)
DESCRIPTION SYMBOL VALUE UNIT
Collector Emitter Voltage
Collector Base Voltage
Emitter Base Voltage
Collector Current
Collector Power Dissipation
Operating And Storage Junction
V
CEO
V
CBO
V
EBO
I
C
P
C
, T
T
j
stg
50 V
50 V
5V
2A
900 mW
-55 to +150 ºC
Temperature Range
ELECTRICAL CHARACTERISTICS (Ta=25ºC unless specified otherwise)
DESCRIPTION SYMBOL TEST CONDITION min typ max UNIT
Collector Emitter Voltage
Collector Cut off Current
Emitter Cut off Current
DC Current Gain
Collector Emitter Saturation
BV
CEOIC
I
CBO
I
EBO
h
FE
V
CE(sat)IC
=10mA,IB=0
VCB=50V, IE = 0
VEB=5V, IC = 0
VCE=2V,IC=500mA *
V
=2V,IC=1.5A
CE
=1A, IB=50mA
50 - V
- 1.0
- 1.0
µA
µA
70 240
40 -
- 0.5 V
Voltage
Base Emitter Saturation Voltage
V
BE(sat)IC
=1A, IB=50mA
- 1.2 V
DYNAMIC CHARACTERISTICS
Gain Bandwidth Product
Output Capacitance
f
T
C
ob
IC=500mA, VCE=2V
IE=0, VCB=10V,f=1MHz
PNP -40 -
NPN -30 -
Switching Time
Turn on Time
Storage Time
Fall Time
t
on
t
stg
t
VCC=30V, IB1=IB2=
50mA, RL=30Ω
Duty Cycle=1% - 0.1 - us
f
Classification O Y
*
h
FE
Continental Device India Limited
70 - 140 120 - 240
Data Sheet Page 1 of 3
- 100 - MHz
F
P
F
P
- 0.1 - us
- 1.0 - us
Page 2
TO-92 Plastic Package
Packing D
il
6
TO-92 Transistors on Tape and Ammo Pack
CSA1020 PNP
CSC2655 NPN
TO-92
Plastic Package
B
Dimension With 'L'
Uncontrolled
L
1
2
Beyond 'L'
3
Solderability Ensured
D
A
A
G
3 2 1
F
H
F
PIN CONFIGURA TION
1. BASE
2. COLLECTOR
3. EMITTER
C
A
K
D
SEC AA
DIM MIN. MAX.
A 4.32 5.33
B 4.45 5.20
C 3.18 4.19
D 0.41 0.55
E 0.35 0.50
F5 DEG
G 1.14 1.40
H 1.14 1.53
K
L
All diminsions in mm.
E
12.70
1.982
3
2
—
2.082
MECHANICAL DATA
T
hh
A
H1
H0
L
t1
t
A1
F1 F2
F
P2
Po
P
(p)
W2
Wo
Do
Adhesive Tape on Top Side
FLAT SIDE
LABEL
W1
W
Ammo Pack Style
4
2
3
Flat Side of Transistor and
Adhesive Tape Visible
2000 pcs./Ammo Pack
All dimensions in mm unless specified otherwise
ITEM
1
BODY WIDTH
BODY HEIGHT
BODY THICKNESS
PITCH OF COMPONENT
FEED HOLE PITCH
FEED HOLE CENTRE TO
COMPONENT CENTRE
DISTANCE BETWEEN OUTER
LEADS
COMPONENT ALIGNMENT
TAPE WIDTH
HOLD-DOWN TAPE WIDTH
HOLE POSITION
HOLD-DOWN TAPE POSITION
LEAD WIRE CLINCH HEIGHT
COMPONENT HEIGHT
LENGTH OF SNIPPED LEADS
FEED HOLE DIAMETER
TOTAL TAPE THICKNESS
LEAD - TO - LEAD DISTANCEF1,
CLINCH HEIGHT
PULL - OUT FORCE
NOTES
1. MAXIMUM ALIGNMEN T DEVIATION BETWEEN LEADS NOT TO BE G REATER THAN 0.2 mm.
2. MAXIMUM NON-CUMULATIVE VARIATION BETWEEN TAPE FEED HOLES SHALL NOT EXCEED 1 mm IN 20
PITCHES .
3. HOLDDO WN TAPE NOT TO EXCEED BEYOND THE EDGE(S) OF CARRIER TAPE AND THERE SHALL BE NO
EXPOSURE OF ADHESIVE.
4. NO MORE THAN 3 CONSECUTIVE MISSING COMPONENTS ARE PERMITTED.
5. A TAPE TRAILE R, HAVING AT LEAST TH REE FEED H OLES ARE REQUIRED AF TER THE L AST COMPO NENT.
. SPLICES SHALL NOT INTERFERE WITH THE SPROCKET FEED HOLES.
SYMBOL
A1
A
T
P
Po
P2
F
h
W
Wo
W1
W2
Ho
H1
L
Do
t
F2
H2
(P)
SPECIFICATION
MIN.
NOM.
4.0
4.8
3.9
12.7
12.7
6.35
5.08
0
18
6
9
0.5
16
4
2.54
6N
MAX.
4.8
5.2
4.2
1
23.25
11.0
1.2
3
TOL .
±1
±0.3
±0.4
+0.6
-0.2
±0.5
±0.2
+0.7
-0.5
±0.2
±0.5
±0.2
+0.4
-0.1
D
E
E
F
Carrier
Strip
183
1
3
REMARKS
CUMULATIVE PITCH
ERROR 1.0 mm/20
PITCH
TO BE MEASURED AT
BOTTOM OF CLINCH
AT TOP OF BODY
t1 0.3 - 0.6
PACKAGE
TO-92 Bulk
TO-92 T&A
eta
STANDARD PACK INNER CARTON BOX
Details
1K/polybag
2K/ammo box
Continental Device India Limited
Net Weight/Qty
200 gm/1K pcs
645 gm/2K pcs
OUTER CARTON BOX
Qty
3" x 7.5" x 7.5"
12.5" x 8" x 1.8"
Data Sheet Page 2 of 3
5K
2K
17" x 15" x 13.5"
17" x 15" x 13.5"
Qty Gr WtSize Size
80K
32K
23 kgs
12.5 kgs
Page 3
Notes
CSA1020
CSC2655
TO-92
Plastic Package
Disclaimer
The product information and the selection guides facilitate selection of the CDIL's Discrete Semiconductor Device(s) best suited
for application in your product(s) as per your requirement. It is recommended that you completely review our Data Sheet(s) so as
to confirm that the Device(s) meet functionality parameters for your application. The information furnished in the Data Sheet and
on the CDIL Web Site/CD is believed to be accurate and reliable. CDIL however, does not assume responsibility for inaccuracies
or incomplete information. Furthermore, CDIL does not assume liability whatsoever, arising out of the application or use of any
CDIL product; neither does it convey any license under its patent rights nor rights of others. These products are not designed for
use in life saving/support appliances or systems. CDIL customers selling these products (either as individual Discrete
Semiconductor Devices or incorporated in their end products), in any life saving/support appliances or systems or applications do
so at their own risk and CDIL will not be responsible for any damages resulting from such sale(s).
CDIL strives for continuous improvement and reserves the right to change the specifications of its products without prior notice.
CDIL is a registered Trademark of
Continental Device India Limited
C-120 Naraina Industrial Area, New Delhi 110 028, India.
Telephone + 91-11-2579 6150, 5141 1112 Fax + 91-11-279 5290, 5141 1119
CSA1020/CSC2655/25072001
Continental Device India Limited
[email protected] www.cdilsemi.com
Data Sheet Page 3 of 3
