RM84

miniature relays

RM84

RM84-...-01

❶

• Cadmium - free contacts • Height 15,7 mm

• 5000 V / 10 mm reinforced insulation

• For PCB and plug-in sockets

• Accessories: sockets and modules • AC and DC coils

• Available special versions: with transparent cover
with the increased dielectric strength of the contact clearance

❶;

❷

• Compliance with standard PN-EN 60335-1

Contact data

Number and type of contacts
Contact material
Rated / max. switching voltage AC
Min. switching voltage
Rated load (capacity) AC1
AC15
AC3
DC1
DC13
Min. switching current
Max. inrush current
Rated current
Max. breaking capacity AC1
Min. breaking capacity
Contact resistance

• Recognitions, certi cations, directives: RoHS,

2 CO, 2 NO ❷
AgNi, AgNi/Au 5 µm, AgSnO2
250 V / 440 V

5 V

AgNi, 5 V AgNi/Au 5 µm, 10 V AgSnO2

8 A / 250 V AC
3 A / 120 V 1,5 A / 240 V (B300)
550 W (single-phase motor)
8 A / 24 V DC (see Fig. 3)
0,22 A / 120 V 0,1 A / 250 V (R300)

5 mA

AgNi, 2 mA AgNi/Au 5 µm, 10 mA AgSnO2

15 A AgSnO2

8 A

2 000 VA

0,3 W

AgNi, 0,05 W AgNi/Au 5 µm, 1 W AgSnO2

 100 m

Max. operating frequency

• at rated load AC1

• no load

600 cycles/hour
72 000 cycles/hour

Coil data

Rated voltage 50/60 Hz AC
DC

Must release voltage

Operating range of supply voltage
Rated power consumption AC
DC

12 ... 240 V
3 ... 110 V

AC:  0,15 Un DC:  0,1 Un

see Tables 1, 2 and Fig. 4, 5
0,75 VA
0,4 ... 0,48 W

Insulation according to PN-EN 60664-1

Insulation rated voltage

Rated surge voltage
Overvoltage category

Insulation pollution degree

Dielectric strength • between coil and contacts

• contact clearance

• pole - pole

Contact - coil distance • clearance

• creepage

400 V AC

4 000 V

1,2 / 50 µs

III
3

5 000 V AC

type of insulation: reinforced

1 000 V AC type of clearance: micro-disconnection
2 000 V AC contacts 2 NO, type of clearance: full-disconnection ❷
2 500 V AC type of insulation: basic

 10 mm
 10 mm

General data

Operating / release time (typical values)
Electrical life (number of cycles)

• resistive AC1

• cos

• DC L/R=40 ms
Mechanical life (cycles)
Dimensions (L x W x H) / Weight

Ambient temperature • storage

• operating

Cover protection category
Environmental protection
Shock resistance

Vibration resistance

(NO/NC)

Solder bath temperature / Soldering time

The data in bold type pertain to the standard versions of the relays.

❶ For special version - relays in transparent cover: only available with IP 40 and RTII, operating temperature -40...+70 °C - see ”Ordering codes”
❷ For special version with contacts 2 NO: relays with increased contact gap, dielectric strength 2000 V AC - see ”Ordering codes”

7 ms / 3 ms

5

> 10

8 A, 250 V AC

see Fig. 2

5

> 10

0,15 A, 220 V DC

> 3 x 10

7

29 x 12,7 x 15,7 mm / 14 g

-40...+85

AC: -40...+70

o

C

o

C DC: -40...+85 oC -40...+70 oC ❶

IP 40 ❶ or IP 67 PN-EN 60529
RTII ❶ or RTIII PN-EN 116000-3

20 g

10 g / 5 g

10...150 Hz

max. 270 oC / max. 5 s

14.07.2014

1

www.relpol.com.pl

Export Sales Department phone [phone], 951 • e-mail: [e-mail]

RM84

miniature relays

Coil data - DC voltage version Table 1

Coil code

1003

1005

1006

1009

1012

1018

1024

1036

1048

1060

1110

The data in bold type pertain to the standard versions of the relays.

Rated voltage

V DC

3

5

6

9

12

18

24

36

48

60

110

Coil resistance

at 20 °C



200

360

710

1 440

3 140

5 700

7 500

25 200

22

60

90

Acceptable

resistance

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

Coil operating range

V DC

min. (at 20 °C) max. (at 20 °C)

2,1

3,5

4,2

6,3

8,4

12,6

16,8

25,2

33,6

42,0

77,0

7,6

12,7

15,3

22,9

30,6

45,9

61,2

91,8

122,4

153,0

280,0

Coil data - AC 50/60 Hz voltage version Table 2

Coil code

5012

5024

5048

5060

5110

5115

5120

5220

5230

5240

The data in bold type pertain to the standard versions of the relays.

Rated voltage

V AC

12

24

48

60

110

115

120

220

230

240

Coil resistance

at 20 °C



100

400

1 550

2 600

8 900

9 600

10 200

35 500

38 500

42 500

Acceptable

resistance

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 10%

± 15%

Coil operating range

V AC 50 Hz

min. (at 20 °C) max. (at 20 °C)

9,6

19,2

38,4

48,0

88,0

92,0

96,0

176,0

184,0

192,0

13,2

28,8

57,6

72,0

132,0

138,0

144,0

264,0

276,0

288,0

Dimensions Connection diagrams (pin side view)

7,5

12,7

15

29

15,7

3,9

5

5

2,5

12,7

15,7

3,9

2 CO 2 NO

Terminal (pin) A1(1); A2(2) 22(3); 21(4); 24(5);

[mm]

Drilling hole:

• for relays Ø 1,3 + 0,1 mm

• for sockets Ø 1,5 + 0,1 mm

Ø 0,6

12(6); 11(7); 14(8)

0,5 x 0,9

14.07.2014

2

www.relpol.com.pl

Export Sales Department phone [phone], 951 • e-mail: [e-mail]

RM84

miniature relays

AC1

N - electrical life

at AC1

DC1

In = 8 A

www.relpol.com.pl

14.07.2014

3

Export Sales Department phone [phone], 951 • e-mail: [e-mail]

RM84

miniature relays

Pinout (solder side view)

2 CO

2 NO

Ordering codes

Type Contact

material

Mounting

Relays RM84 ❸ are designed for: • direct PCB mounting • screw termi­nals plug-in sockets GZT80
GZM80-0041; plug-in sockets GZS80

❹ and GZM80 ❹ with clip GZT80-0040 or

❹ with clip GZS-0040 or GZM80-0041,

35 mm rail mount acc. to PN-EN 60715 or on panel mounting with one
M3 screw • spring terminals plug-in sockets GZMB80

❺ with clip

GZMB80-0040 or GZM80-0041, 35 mm rail mount acc. to PN-EN 60715.
Signalling / protecting modules type M... are available with sockets
(see page 8) • plug-in sockets for PCB mounting EC 50 with clip MP16-2,
MH16-2; plug-in sockets PW80 with clip MH16-2; plug-insockets GD50 with
clip MP16-2, GD-0016, MH16-2.

❸ For special version - relays in transparent cover: the distance of min. 5 mm between the

mounting relays.

❹ Plug-in sockets GZT80, GZM80, GZS80 may be linked with inter con nection strip type ZGGZ80

(see page 9).

❺ For sockets GZMB80 - see page 6 (wire connection).

Cover protection

category

Number and type

of contacts

Connection

mode

Coil code Cover Special

version

R M 8 4

Contact material

20 - AgNi
23 - AgNi/Au 5 µm
30 - AgSnO2

Number and type of contacts

12 - 2 CO
22 - 2 NO

Cover protection category

2 - in cover, IP 40 version
3 - in cover, IP 67 waterproof version

Connection mode

5 - for PCB and sockets

❶ For special version - relays in transparent cover: only available with IP 40 and RTII, operating temperature -40...+70 °C
❷ For special version with contacts 2 NO: relays with increased contact gap, dielectric strength 2000 V AC

— — —

see Tables 1, 2 page 2

Cover

without marks - standard cover (no transparent, white colour)
01 - transparent cover (special version, without signs recognitions) ❶

—

Special version

without marks - basic version,

dielectric strength of contact clearance 1000 V AC
(51) - contacts 2 NO, increased contact gap

- dielectric strength 2000 V AC

❷

Examples of ordering code:

RM84-3012-25-5024 relay RM84, for PCB and sockets, two changeover contacts,contact material AgSnO

coil voltage 24 V AC 50/60 Hz, in standard cover (no transparent, white colour) IP 40

RM84-2012-25-1012-01 relay RM84, for PCB and sockets, two changeover contacts, contact material AgNi, coil

voltage 12 V DC in transparent cover (special version, without signs recognitions) IP 40

RM84-2322-35-1024 (51) relay RM84, special version with increased contact gap, for PCB and sockets, two

normally open contacts, contact material AgNi/Au 5 µm, coil voltage 24 V DC, in
standard cover (no transparent, white colour) IP 67

2,

14.07.2014

www.relpol.com.pl

4
