RFP10N15
March 1999 File Number 1445.3Data Sheet
10A, 150V, 0.300 Ohm, N-Channel Power
MOSFETs
These are N-channel enhancement-mode silicon-gate
power field effect transistors designed for applications such
as switching regulators, switching converters, motor drivers,
relay drivers, and drivers for high-power bipolar switching
transistors requiring high speed and low gate-drive power.
These types can be operated directly from integrated
circuits.
Formerly developmental type TA09192.
Ordering Information
PART NUMBER PACKAGE BRAND
RFP10N15 TO-220AB RFP10N15
NOTE: When ordering, include the entire part number.
Packaging
TO-220AB
Features
• 10A, 150V
•r
DS(ON)
• Related Literature
- TB334 “Guidelines for Soldering Surface Mount
= 0.300Ω
Components to PC Boards”
Symbol
D
G
S
SOURCE
DRAIN
GATE
DRAIN (FLANGE)
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper ESD Handling Procedures.
http://www.intersil.com or 407-727-9207
| Copyright © Intersil Corporation 1999
Page 2
RFP10N15
Absolute Maximum Ratings T
= 25oC, Unless Otherwise Specified
C
RFP10N15 UNITS
Drain to Source Voltage (Note 1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
Drain to Gate Voltage (RGS = 20kΩ) (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .V
DGR
Continuous Drain Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .I
Pulsed Drain Current (Note 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I
Gate to Source Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .V
Maximum Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P
DS
D
DM
GS
D
150 V
150 V
10 A
25 A
±20 V
60 W
Linear Derating Factor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.48 W/oC
Operating and Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TJ, T
STG
-55 to 150
Maximum Temperature for Soldering
Leads at 0.063in (1.6mm) from Case for 10s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T
Package Body for 10s, See TB334. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .T
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operationofthe
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
L
pkg
300
260
o
C
o
C
o
C
NOTE:
1. TJ= 25oC to 125oC.
Electrical Specifications T
= 25oC, Unless Otherwise Specified
C
PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNITS
Drain to Source Breakdown Voltage BV
Gate Threshold Voltage V
Zero Gate Voltage Drain Current I
Gate to Source Leakage Current I
Drain to Source On Resistance(Note 2) r
DS(ON)ID
Drain to Source On Voltage (Note 2) V
Turn-On Delay Time t
DSSID
GS(TH)
DSS
GSS
DS(ON)ID
d(ON)
= 250µA, VGS = 0 150 - - V
VGS = VDS, ID = 250µA, (Figure 8) 2 - 4 V
VDS= Rated BV
VDS= 0.8 x Rated BV
, VGS = 0V - - 1 µA
DSS
, TC = 125oC- - 25 mA
DSS
VGS = ±20V, VDS = 0 - - ±100 nA
= 10A, VGS = 10V, (Figures 6, 7) - - 0.300 Ω
= 10A, VGS = 10V - - 3.0 V
I
≈ 5A, V
D
= 75V, R
DD
= 50Ω,
G
-4060ns
VGS = 10V, RL= 14.7Ω
Rise Time t
Turn-Off Delay Time t
d(OFF)
Fall Time t
Input Capacitance C
r
f
ISS
(Figures 10, 11, 12)
VGS = 0V, VDS = 25V,
- 165 250 ns
- 90 135 ns
- 90 135 ns
- - 850 pF
f = 1MHz, (Figure 9)
Output Capacitance C
Reverse Transfer Capacitance C
OSS
RSS
- - 230 pF
- - 100 pF
Thermal Resistance Junction to Case RFP10N15 - - 2.083oC/W
Source to Drain Diode Specifications
PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNITS
Source to Drain Diode Voltage (Note 2) V
Diode Reverse Recovery Time t
SD
rr
NOTES:
2. Pulse Test: Pulse Width ≤300µs, Duty Cycle ≤ 2%
3. Repetitive rating: pulse width is limited by maximum junction temperature.
2
ISD = 5A - - 1.4 V
ISD = 4A, dISD/dt = 100A/µs - 200 - ns
Page 3
Typical Performance Curves
RFP10N15
1.2
1.0
0.8
0.6
0.4
0.2
POWER DISSIPATION MULTIPLIER
0
0 50 100 150
TC, CASE TEMPERATURE (oC)
FIGURE 1. NORMALIZED POWER DISSIPATION vs CASE
TEMPERATURE
100
ID MAX CONTINUOUS
10
DC
TC = 25oC
12
10
8
6
4
, DRAIN CURRENT (A)
D
I
2
0
25 50 75 100 125 150
, CASE TEMPERATURE (oC)
T
C
FIGURE 2. MAXIMUM CONTINUOUS DRAIN CURRENT vs
CASE TEMPERATURE
20
PULSE DURATION = 80µs
DUTY CYCLE ≤ 2%
= 25oC
T
C
15
10
VGS = 8V
VGS = 20V
VGS = 10V
VGS = 7V
OPERATION IN THIS AREA
1
MAY BE LIMITED BY R
, DRAIN CURRENT (A)
D
I
0.1
1 10 100 1000
VDS, DRAIN TO SOURCE VOLTAGE (V)
DS(ON)
DRAIN CURRENT (A)
D,
5
I
0
1
02345
V
DRAIN TO SOURCE VOLTAGE (V)
DS,
6789
FIGURE 3. FORWARD BIAS SAFE OPERATING AREA FIGURE 4. SATURATION CHARACTERISTICS
20
VDS= 10V
PULSE DURATION = 80µs
DUTY CYCLE ≤2%
15
10
5
DRAIN TO SOURCE CURRENT (A)
125oC
DS(ON),
0
I
0246810
GATE TO SOURCE VOLTAGE (V)
V
GS,
-40oC
-40oC
25oC
125oC
0.7
VGS = 10V
PULSE DURATION = 80µs
0.6
DUTY CYCLE ≤2%
0.5
0.4
0.3
DRAIN TO SOURCE ON
RESISTANCE (Ω)
0.2
0.1
DS(ON),
r
0
02 8 12 16
4 6 10 14
ID,DRAIN CURRENT (A)
VGS = 6V
VGS = 5V
VGS = 4V
125oC
o
25
C
o
C
-40
FIGURE 5. TRANSFER CHARACTERISTICS FIGURE 6. DRAIN TOSOURCE ONRESISTANCEvs DRAIN
CURRENT
3
Page 4
RFP10N15
Typical Performance Curves
2.0
PULSE DURATION = 80µs
= 5A
I
D
VGS = 10V
1.5
(Continued)
1.0
ON RESISTANCE
0.5
NORMALIZED DRAIN TO SOURCE
0
-50
0
T
JUNCTION TEMPERATURE (oC)
J,
50 100 150
FIGURE 7. NORMALIZED DRAIN TO SOURCE ON
RESISTANCE vs JUNCTION TEMPERATURE
1000
800
600
400
C, CAPACITANCE (pF)
200
0
01020304050
V
DRAIN TO SOURCE VOLTAGE (V)
DS,
VGS = 0V, f = 1MHz
= CGS + C
C
ISS
C
= C
RSS
OSS
GD
≈ CDS + C
C
ISS
C
OSS
C
RSS
C
FIGURE 9. CAPACITANCE vs DRAIN TO SOURCE VOLTAGE
GD
GD
1.4
ID= 250µA
VDS = V
1.3
GS
1.2
1.1
1.0
0.9
NORMALIZED GATE
0.8
THRESHOLD VOLTAGE
0.7
-50 0 50 100
JUNCTION TEMPERATURE (oC)
T
J,
FIGURE 8. NORMALIZED GATE THRESHOLD VOLTAGE vs
JUNCTION TEMPERATURE
150
112.5
75
37.5
, DRAIN TO SOURCE VOLTAGE (V)
DS
V
VDD= BV
DSS
SOURCE
VOLTAGE
RL = 15Ω
I
G(REF)
V
GS
0.75BV
DSS
0.50BV
DSS
0.25BV
DSS
DRAIN SOURCE
0
I
G(REF)
20 80
I
G(ACT)
VOLTAGE
t, TIME (µs)
GATE
= 1mA
= 10V
0.75BV
0.50BV
0.25BV
DSS
DSS
DSS
= BV
V
DD
DSS
I
G(REF)
I
G(ACT)
10
8
6
4
2
0
NOTE: Refer to Intersil Applications Notes AN7254 and AN7260
FIGURE 10. NORMALIZED SWITCHINGWAVEFORMS FOR
CONSTANT GATE CURRENT
150
, GATE TO SOURCE VOLTAGE (V)
GS
V
Test Circuits and Waveforms
R
G
V
GS
FIGURE 11. SWITCHING TIME TEST CIRCUIT FIGURE 12. RESISTIVE SWITCHING WAVEFORMS
4
t
ON
t
d(ON)
t
R
L
+
V
DD
-
V
DS
90%
0
r
10%
DUT
V
GS
10%
0
50%
PULSE WIDTH
t
d(OFF)
90%
t
OFF
50%
t
f
90%
10%
Page 5
RFP10N15
Test Circuits and Waveforms
CURRENT
REGULATOR
12V
BATTERY
0
0.2µF
50kΩ
I
G(REF)
0.3µF
G
IG CURRENT
SAMPLING
RESISTOR RESISTOR
FIGURE 13. GATE CHARGE TEST CIRCUIT
(Continued)
V
DS
(ISOLATED
SUPPLY)
SAME TYPE
AS DUT
D
DUT
S
CURRENT
I
D
SAMPLING
V
DD
Q
g(TOT)
Q
gd
Q
gs
V
DS
0
V
DS
0
I
G(REF)
V
GS
FIGURE 14. GATE CHARGE WAVEFORMS
All Intersil semiconductor products are manufactured, assembled and tested under ISO9000 quality systems certification.
Intersil semiconductor products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design and/or specifications at any time without notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be accurate and
reliable. However, no responsibility is assumed by Intersil or its subsidiaries forits use; nor for any infringements of patents or other rights of third parties which may result
from its use. No license is granted by implication or otherwise under any patent or patent rights of Intersil or its subsidiaries.
For information regarding Intersil Corporation and its products, see web site http://www.intersil.com
