R2E190-AO26-05
Nominal data
Type R2E190-AO26-05
Motor M2E068-BF
AC centrifugal fan
backward curved, single inlet
ebm-papst Mulfingen GmbH & Co. KG
Bachmühle 2
74673 Mulfingen
Phone: +49 7938 81-0
Fax: +49 7938 81-110
www.ebmpapst.com
info1@de.ebmpapst.com
Phase 1~ 1~
Nominal voltage [V] 230 230
Frequency [Hz] 50 60
Type of data definition rfa rfa
Valid for approval / standard CE CE
Speed
Power input [W] 58 75
Current draw [A] 0.26 0.34
Motor capacitor [µF] 2 2
Capacitor voltage [VDB] 400 400
Capacitor standard P0 (CE) P0 (CE)
Min. back pressure [Pa] 0 0
Max. ambient temperature [°C] 50 55
Air flow
Back pressure [Pa] 0 0
Sound pressure level [dB(A)] 62 64
ml = max. load · me = max. efficiency · rfa = running at free air · cs = customer specs · cu = customer unit
Subject to alterations
[min-1]
[m3/h]
2500 2700
570 620
Item no.: 10281-5-9980 · Revision index: KM64302 · Print-out on 26.01.2009 · Created by Yvonne Uhlmann (VM-TDO) · Page 1 of 6
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · 74673 Mulfingen · Phone: +49 7938 81-0 · Fax: +49 7938 81-110 · www.ebmpapst.com · info1@de.ebmpapst.com
Page 2
R2E190-AO26-05
AC centrifugal fan
backward curved, single inlet
Technical features
Leackage current < 0,75 mA
Size 190 mm
Operation mode S1
Mounting position Shaft horizontal or rotor on bottom; rotor on top on request
Direction of rotation Clockwise, seen on rotor
Insulation class "B"
Cable exit Variable
Condensate discharge holes Rotor-side
Bearing-motor Ball bearing
Mass 1.2 kg
Material of impeller PA plastic 6, fiberglass-reinforced
Motor protection Thermal overload protector (TOP) wired internally
Product conforming to
standard
Surface of rotor Coated in black
Number of blades 7
Type of protection IP 44
Protection class I
Approval CCC; GOST
CE; EN 60335-1
Item no.: 10281-5-9980 · Revision index: KM64302 · Print-out on 26.01.2009 · Created by Yvonne Uhlmann (VM-TDO) · Page 2 of 6
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · 74673 Mulfingen · Phone: +49 7938 81-0 · Fax: +49 7938 81-110 · www.ebmpapst.com · info1@de.ebmpapst.com
Page 3
R2E190-AO26-05
Product drawing
AC centrifugal fan
backward curved, single inlet
1 Connection line PVC, 4x brass lead tips crimped
2 Accessory part: Inlet nozzle 09576-2-4013, not included in the standard scope of delivery
3 Screw depth max. 5 mm
4 Direction of rotation clockwise, seen on rotor
Item no.: 10281-5-9980 · Revision index: KM64302 · Print-out on 26.01.2009 · Created by Yvonne Uhlmann (VM-TDO) · Page 3 of 6
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · 74673 Mulfingen · Phone: +49 7938 81-0 · Fax: +49 7938 81-110 · www.ebmpapst.com · info1@de.ebmpapst.com
Page 4
R2E190-AO26-05
AC centrifugal fan
backward curved, single inlet
Connection screen
U1 blue Z brown U2 black
PE green/yellow
Item no.: 10281-5-9980 · Revision index: KM64302 · Print-out on 26.01.2009 · Created by Yvonne Uhlmann (VM-TDO) · Page 4 of 6
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · 74673 Mulfingen · Phone: +49 7938 81-0 · Fax: +49 7938 81-110 · www.ebmpapst.com · info1@de.ebmpapst.com
Page 5
R2E190-AO26-05
Charts: Air flow 50 Hz
AC centrifugal fan
backward curved, single inlet
340
330
320
310
300
290
280
270
260
250
240
230
220
210
200
190
180
170
Pfa [Pa]
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
4
V [cfm]
3
2
V [m^3/h]
Pfa
350300250200150100500
1,35
1,3
1,25
1,2
1,15
1,1
1,05
1
0,95
0,9
0,85
0,8
0,75
0,7
0,65
Pfa_E [IN H2O]
0,6
0,55
0,5
0,45
0,4
0,35
0,3
0,25
0,2
0,15
0,1
0,05
1
0
600550500450400350300250200150100500
Measured values
U
[V]
1
2
3
4
230
230
230
230
f
[Hz]
50
50
50
50
n
[min-1]
2515
2470
2420
2505
P
[W]
58
60
61
58
I
1
[A]
0.26
0.26
0.27
0.25
η
[%]
12
43
52
39
°
V
TL
[m3/h]
570
470
310
160
p
[Pa]
0
78
169
234
fa
Item no.: 10281-5-9980 · Revision index: KM64302 · Print-out on 26.01.2009 · Created by Yvonne Uhlmann (VM-TDO) · Page 5 of 6
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · 74673 Mulfingen · Phone: +49 7938 81-0 · Fax: +49 7938 81-110 · www.ebmpapst.com · info1@de.ebmpapst.com
Page 6
R2E190-AO26-05
Charts: Air flow 60 Hz
AC centrifugal fan
backward curved, single inlet
440
420
400
380
360
340
320
300
280
260
240
220
Pfa [Pa]
200
180
160
140
120
100
80
60
40
20
0
4
V [cfm]
3
2
V [m^3/h]
Pfa
400350300250200150100500
1,75
1,7
1,65
1,6
1,55
1,5
1,45
1,4
1,35
1,3
1,25
1,2
1,15
1,1
1,05
1
0,95
0,9
0,85
0,8
Pfa_E [IN H2O]
0,75
0,7
0,65
0,6
0,55
0,5
0,45
0,4
0,35
0,3
0,25
0,2
0,15
0,1
0,05
1
0
650600550500450400350300250200150100500
Measured values
U
[V]
1
2
3
4
230
230
230
230
f
[Hz]
60
60
60
60
n
[min-1]
2750
2690
2570
2720
P
[W]
75
76
79
76
I
1
[A]
0.34
0.34
0.35
0.34
η
[%]
12
44
52
40
°
V
TL
[m3/h]
620
505
330
175
p
[Pa]
0
91
191
276
fa
Item no.: 10281-5-9980 · Revision index: KM64302 · Print-out on 26.01.2009 · Created by Yvonne Uhlmann (VM-TDO) · Page 6 of 6
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · 74673 Mulfingen · Phone: +49 7938 81-0 · Fax: +49 7938 81-110 · www.ebmpapst.com · info1@de.ebmpapst.com
